Instruction Manual
GSM Cell phone
Easiphone MM910
2
Set content:
GSM cell phone
Charger
Battery
Instruction manual
Warranty card
Hands-free set
Keep the package, it may be useful
in the case of possible transport
Keep the receipt, it is inseparable
part of warranty.
If you need technical assistance, call the following hotline
(+48) 32 325 07 00 or serwis@maxcom.pl
Our website:
http://www.maxcom.pl/
Note – The phone operates in GSM 900/1800 network.
Before switching the phone on insert the SIM card
correctly.
3
GSM 900/1800 cell phone
Large highlighted keys
Colourful display
Camera
Slot for microSD memory cards
SOS button (generates alarm and automatically makes a
call and sends SMS to previously defined phone
numbers)
Large type, simple Menu
Hands-free function
Phonebook -1000 entries
Receiving and sending SMS
Quick dialing of 8 numbers
Displaying the time of a call
Loud ringtone
Bluetooth
FM Radio
Torch
Calculator
Alarm clock
Battery 1200 mAh
Standby time: to 360 hours*.
Talking time: to 8 hours*
*depending on conditions and GSM network signal
4
Table of contents
1. Safe operation .............................................................................8
2. Elements installation ...................................................................9
2.1 Installation of a SIM card and a battery .................................10
2.2 Battery charging .....................................................................12
2.3 Low battery alarm ..................................................................13
3. Keys localization........................................................................14
Basic functions of keys ....................................................................15
4. Using the phone ........................................................................16
4.1 Switching the phone on..........................................................16
4.2 Switching the phone off..........................................................17
4.3 Standby mode ........................................................................17
4.4 Keylock ...................................................................................18
4.5 Silent mode ............................................................................19
5. MENU operation ........................................................................19
6. Phonebook ................................................................................19
6.1 Saving contacts ......................................................................19
6.2 Scrolling contacts ...................................................................20
6.3 Deleting contacts ...................................................................21
6.3.1 Deleting a single contact.....................................................21
6.3.2 Deleting all contacts ............................................................21
6.4 Copying contacts ...................................................................21
6.4.1 Copying a single contact.....................................................21
6.4.2 Copying all contacts ............................................................22
6.5 Transferring a single contact .................................................22
6.5.1 Transferring all contacts .....................................................22
6.6 Phonebook settings ...............................................................22
6.6.1 Preferred storing .................................................................22
6.6.2 Additional numbers .............................................................23
6.6.3 Memory status ....................................................................23
6.6.4 Contacts backup .................................................................23
7. Calls...........................................................................................24
7.1 Direct dialing ..........................................................................24
7.2 Dialing the number from the phonebook ...............................24
7.3 Dialing numbers from recent calls list ....................................24
7.4 Quick dialing...........................................................................25
7.5 Call volume regulation ...........................................................25
7.6 Options during a call ..............................................................25
5
7.7 Emergency call.......................................................................26
7.7.1 Entering, deleting, modifying emergency contacts .............26
7.7.2 Emergency text ...................................................................27
7.7.3 SOS button .........................................................................27
7.7.4 Sending SOS message ......................................................27
7.8 Answering calls ......................................................................28
8. Call list .......................................................................................28
8.1 Call settings............................................................................29
8.1.1 Hiding the number ..............................................................29
8.1.2 Waiting call..........................................................................29
8.1.3 Transferring calls ................................................................30
8.1.4 Call barring..........................................................................31
8.1.5 Line switching .....................................................................31
8.1.6 Advanced settings ..............................................................31
9. SMS and MMS ..........................................................................32
9.1 Writing and sending SMS ......................................................32
9.2 Reading and answering SMS ................................................34
9.3 SMS boxes .............................................................................34
9.3.1 Inbox ...................................................................................34
9.3.2 Sent messages ...................................................................35
9.3.3 Drafts ..................................................................................35
9.3.4 Outbox ................................................................................35
9.3.5 Network messages .............................................................36
9.3.6 Templates ...........................................................................36
9.4 Deleting messages ................................................................36
9.5 Message settings ...................................................................36
9.5.1 SMS ....................................................................................36
9.5.2 MMS ....................................................................................37
9.5.3 Service messages ..............................................................38
9.6 Voice mail...............................................................................38
10. Organizer ...................................................................................39
10.1 SOS settings ..........................................................................39
10.2 Simple dialing .........................................................................39
10.3 Calendar .................................................................................39
10.4 Calculator ...............................................................................40
10.5 Alarm clock.............................................................................41
10.6 Tasks ......................................................................................41
11. Multimedia .................................................................................41
6
11.1 Files manager ........................................................................41
11.2 Camera ..................................................................................42
11.3 Photo browser ........................................................................45
11.4 Video recording ......................................................................45
11.5 Video player ...........................................................................45
11.6 Dictaphone .............................................................................46
11.7 Audio player ...........................................................................47
11.8 FM Radio ................................................................................48
12. Settings .....................................................................................49
12.1 Dual SIM settings ...................................................................49
12.2 Profiles ...................................................................................49
12.3 Phone settings .......................................................................50
12.3.1 Date and time settings ........................................................50
12.3.2 Planning switching on/off ....................................................50
12.3.3 Language ............................................................................51
12.3.4 Preferred method of entering the text .................................51
12.3.5 Display ................................................................................51
12.3.6 Flight mode .........................................................................51
12.4 Network settings ....................................................................51
12.5 Security settings .....................................................................52
12.5.1 PIN code .............................................................................52
12.5.2 Phone security ....................................................................52
12.5.3 Automatic keylock ...............................................................52
12.6 Communication ......................................................................52
12.6.1 Bluetooth .............................................................................52
12.6.2 Data communication ...........................................................53
12.6.3 APN profile ..........................................................................53
12.7 Restoring factory settings ......................................................54
13. Connecting the phone to the computer .....................................54
14. FAQ (Solving problems) ............................................................55
15. Use and safety terms ................................................................57
16. Warranty terms ..........................................................................59
17. Information concerning the battery ...........................................59
18. Information about SAR .............................................................61
19. Information concerning the environment protection..................63
20. Declaration of conformity ..........................................................64
7
8
1. Safe operation
Read the following information to minimize the risk of
incorrect use of the phone.
Do not use the phone in the place where it is forbidden
for example, petrol stations or hospitals. Using the
phone in such places may be dangerous for other
people. Do not switch on the phone if it may cause
the interferences in the operation of other devices!
Do not use the phone without appropriate hands-free
set while driving a car.
Do not use the phone in hospitals, planes near petrol
stations or inflammable materials.
The phone emits electromagnetic field, which may
have a negative influence on other electronic devices,
for example on medical equipment. Keep appropriate
distance, recommended by the producers, between
the phone and implanted medical devices such as a
pacemaker. People with implanted medical devices
should know and observe the guidelines provided by
the producer of the device. Persons with implanted
pacemaker should not carry the phone in breast
pocket, they should keep the phone at the ear on the
side opposite to the medical device in order to
minimize the risk of interferences and switch the
phone off in case of suspecting any interferences.
9
The phone and its accessories may consist of small
parts. The phone and its elements should be protected
against children.
Do not repair or modify the phone. All defects should
be removed by qualified service.
Do not clean the phone using any liquid or substances
in aerosol.
Do not expose the phone to high temperatures, for
example near the radiator, in heated up car.
Do not insert sharp objects into the slots of the phone,
it may cause that particular components will be
damaged.
Use only original chargers and batteries. Using
unoriginal accessories may cause the damage of the
device or its explosion.
WATERTIGHTNESS AND DUSTTIGHTNESS – the
phone have IP67 protection degree, that is it is
resistant to dust and short-term (to 30min) immersion
to maximum depth of 1 meter. Exposing the phone to
prolonged contact with liquid or its deeper immersion
will cause the damage of the phone! You may use the
phone while it is raining. Before the phone makes
contact with the liquid make sure that the seal under
the battery cover and the USB input are correctly
installed.
2. Elements installation
10
Before switching the phone on install the SIM card. Pay
particular attention not to damage the card while inserting.
Keep the SIM card away from children.
2.1 Installation of a SIM card and a battery
Before inserting the SIM card make sure that the phone is
switched off. The charger should be disconnected. To
install the SIM card first remove the battery as shown in
the figures and indicated in descriptions:
When the phone is switched off, unscrew the two
screws located on the battery cover ,
Lever the battery cover with your nail from the
bottom
Remove the battery levering it with your nail
from the top
11
Insert the SIM card to relevant „SIM SLOT” with
metal contacts directed downward. Make sure
that the cut-out on the card is directed upwards.
Over the SIM1 card slot, on the right side there is
a place for MicroSD memory card (up to 4GB).
Move the cotter pin to the right and then lift it
upwards. Insert microSD card so that its contacts
touch the phone contacts, close the cotter pin and
move it to the right.
Exercise caution while using the memory card, particularly
when inserting and removing it. Some memory cards must
be first formatted with the use of a computer.
Regularly prepare backups of the information saved on
cards used in other devices, if you use card of SD type!
Incorrect use or other factors may cause the damage or
the loss of cards content
12
Insert the battery so that, +/- contacts are
directed downwards
Make sure that the seal around the place where
the battery is installed is correctly placed.
After installing the battery, place the battery
cover. First insert the top of the cover, then
place the bottom and tighten the screws.
2.2 Battery charging
Note! Use the battery included in the set. Using other
battery may cause the damage of the phone and the loss
of warranty.
Do not connect the charger when the battery cover is
removed.
To charge the phone:
1. Plug the charger to the wall socket.
2. Move the USB seal located on the top of the right side.
3. Connect the plug of the charger to USB jack. Bars
of battery charging on the display will appear and
disappear while charging the battery.
13
4. When the battery is completely charged, disconnect
the charger from the wall socket and then the cable
from the phone.
When the process of battery charging is finished, the
display will show the following message „Charging
completed”, and the battery symbol will not pulsate.
Note:
o Before charging the battery make sure that the
battery is correctly installed.
o During battery charging do not remove the
battery–it may cause the phone damage
If the voltage of the battery is too low to make the
phone operate correctly, the display will show the
message that the phone will be automatically
switched off and then the phone will be
automatically switched off.
o If the battery is completely discharged (for
example because of the torch being switched on),
after connecting the charger, wait a few dozen
minutes before charging symbol appears
2.3 Low battery alarm
The phone will generate a sound signal (if warning sounds
are activated in profiles) together with the following
message: „Battery discharged” when the battery level will
be too low. The display will show . Charge the battery
when this message will appear.
14
3. Keys localization
1
UP/DOWN key
9
Red receiver
2
Green receiver
10
Numeric keyboard
3
M1
11
Torch button
4
M2
12
Camera button
5
SOS button
13
Micro USB/charging slot
6
Torch
14
Camera
7
Speaker
15
Ringtone speaker
8
Display
16
Battery cover
15
Basic functions of keys
Button
Function
Red receiver
Press: to return to the standby
mode; to end a call.
Press and hold: to switch on/off the
phone
Green receiver
Press: to make a call; in standby
mode to enter the call list; in MENU
to confirm the selection.
Press and hold: when the keylock is
activated to unlock it; in standby
mode to activate the keylock.
Navigation keys
Up
Menu
Down
Phonebook
1
Press: 1 digit
Press and hold: voice mail
0
Press: 0 digit; in camera, shutter
release.
Press and hold: to enter +, P, W
2-9
Press: digits from 2 to 9
Press and hold: to dial the
programmed fast dialing number
16
*
Press: to enter: *.
Press and hold: to activate SOS
function
While writing an SMS: special
characters
#
Press： to change the mode of
entry while writing SMS; to enter #
Press and hold: to switch on/off the
torch
Press twice: to activate/deactivate
the silent mode
4. Using the phone
Warning: Entering incorrect PIN code three times in
a raw will cause that the SIM card will be locked.
It can be unlocked with the use of PUK code.
Entering incorrect PUK code 10 times will cause
that the card will be locked permanently.
4.1 Switching the phone on
Press and hold the red receiver button to switch the phone
on.
After inserting new SIM card you have to choose whether
you want to use two or one SIM card.
If you are asked to enter the PIN code, you will need to
enter it. You will find it in starter set of SIM card.
After entering the code, confirm with green receiver button.
17
4.2 Switching the phone off
Only ringtone
Earphones
connected
Ringtone +
vibrations
New SMS
Vibrations, then
ringtone
New MMS
Only vibrations
Silent
3
4 6 5 2 1
To switch the phone off, in standby mode press and hold
the end call button.
4.3 Standby mode
When the phone is switched on, but no actions are taken
the unit is in standby mode.
Display description
1. Network signal
2. Icons showing functions:
18
Alarm activated
Call transfer
activated
Roaming activated
Keylock
Missed calls
Icons may differ depending on
the software version
* icon will be
displayed also in
domestic roaming in the
case when the user uses
the network of the other
operator
3. Battery level
4. Time
5. Name of the operator
6. Date
4.4 Keylock
To lock the keys in standby mode press and hold the
green receiver button. To unlock the keys press and hold
the green receiver button until the symbol of open padlock
is displayed. It is not necessary to unlock the keys to
answer the call.
NOTE: The keys are locked (automatically or manually)
only in the case when the phone is in standby mode.
19
4.5 Silent mode
In standby mode you may activate/deactivate the silent
mode pressing # key twice.
5. MENU operation
To enter the MENU in standby mode press UP key.
To scroll the MENU use UP and DOWN key.
To confirm the selected function press the green receiver
key.
To return to the previous MENU (return), press end call
key. To enter the standby mode press and hold the red
receiver.
6. Phonebook
6.1 Saving contacts
You may save new contact using one of two methods:
1. You may save the number from the list of
answered and missed calls. In order to do this in
standby mode press Up key, select call list > Call
list, and then the type of call. Search the number
you want to save, press Options > Save in
contacts, select where you want to save the
contact. Enter the name, press Options > Save.
20
2. You may add new contact directly to the
phonebook. To do this in standby mode press
Down key and then select New contact > Select.
Select, where you want to save the contact. Enter
the name and the phone number. In the case of
saving the contact in the phone memory you may
assign the ringtone to the contact. Press Options>Save.
6.2 Scrolling contacts
Method 1
1. Enter MENU and select Phonebook
2. Enter the first letter of the name you are searching
3. The phone will display the names starting with this
letter. Scroll the list with UP/DOWN navigation keys .
Pressing „#” key you change the mode of entering the
text.
Method 2
1. In standby mode press Down key.
2. Enter the first letter of the name you are searching
3. The phone will display the names starting with this
letter. Scroll the list with UP/DOWN navigation
keys .
Pressing „#” key to change the mode of entering the text.
21
6.3 Deleting contacts
6.3.1 Deleting a single contact
If you want to delete the contact from the phone or SIM
card perform the following actions:
1. In MENU select Phonebook
2. Select the contact you want to delete, press Options>Delete
3. Press green receiver button to confirm.
6.3.2 Deleting all contacts
If you want to delete all contacts from the phone or SIM
card perform the following actions:
1. In MENU select: Phonebook->Options->Settings>Delete all contacts.
2. Select whether you want to delete the contacts from
SIM card or phone memory and confirm pressing Yes
6.4 Copying contacts
6.4.1 Copying a single contact
To copy contacts from SIM card to the phone or from the
phone to the SIM card:
1. In MENU select Phonebook
2. Select the contact you want to copy
3. Press Options->Copy, and then select where you want
to copy the contact and press green receiver.
22
6.4.2 Copying all contacts
To copy all contacts from SIM card to the phone, or from
the phone to SIM card:
1. In MENU select: Phonebook->Options->Settings>Copy all
2. Select from and where you want to copy the contacts
3. Press Yes to copy
6.5 Transferring a single contact
You may transfer a contact from SIM card to the phone
memory or the other way round. In order to do this select
MENU->Phonebook->Options->Transfer. Select where
you want to transfer the contact and press Yes.
6.5.1 Transferring all contacts
To transfer all contacts from SIM card to the phone, or
from the phone to the SIM card:
4. In MENU select: Phonebook->Options->Settings->
Transfer all
5. Select from and where to transfer the contacts.
6. Press Yes to copy.
6.6 Phonebook settings
6.6.1 Preferred storing
Select MENU->Phonebook->Options->Settings->Preferred
memory and select where the new contacts are going to
be saved by default. Press Ok.
23
6.6.2 Additional numbers
In MENU select Phonebook->Options->Settings>Additional numbers->Fixed dialing number to activate or
deactivate the function of fixed dialing number.
6.6.3 Memory status
This option makes it possible to check the status of card
and phone memory.
In MENU Select ->Phonebook->Option->Settings>Memory state
6.6.4 Contacts backup
In order to make contacts backup from phone memory and
from the SIM card, select: MENU->Phonebook->Options>Settings->Making contacts backup. After „Contacts
backup for memory card?” message is displayed, select
Yes.
Restoring contacts
If you want to restore the contacts backup to the
phonebook, select: MENU->Phonebook->Options>Settings->Restoring contacts. If „Do you want to restore
the contacts from the memory card?” message is
displayed, press Yes.
24
7. Calls
For international calls it is required to enter „00”
or „+” before the number. In order to enter „+”
press and hold 0.
7.1 Direct dialing
1. Enter the phone number you want to make a call
2. Press green receiver button to call the selected
number
3. To end a call press red receiver button.
7.2 Dialing the number from the phonebook
In standby mode press Down key to enter the phonebook.
Using UP/DOWN keys, select appropriate contact. If you
want to go quickly to the contact beginning for example
with letter U, press 8 key twice. In order to call the selected
contact press green receiver button and select Call.
7.3 Dialing numbers from recent calls list
Press MENU->Call list->Call list and select the type of call
(answered, missed, dialed, all).
25
Use UP/DOWN keys to scroll the call list. Press green
receiver button, and then select Call, to make a call.
You may also in standby mode press green receiver
button to enter the recent calls list.
7.4 Quick dialing
If you have previously assigned contacts to 2-9 keys, in
standby mode press and hold appropriate key to make a
call.
7.5 Call volume regulation
During a call press Up/Down key to increase or decrease
the volume of the call.
7.6 Options during a call
During a call press Options to activate additional functions:
- Speaker: activates/deactivates the hands-free mode
- Hang up: hangs up the call
- End a call: ends the call
- New call: hangs up current call and makes a new one
(depends on the operator)
- Contacts: allows to enter the Contacts, for example to
check the number
- Call list: allows to check the call list
- Messages: allows to check received/saved messages
26
- Dictaphone: allows to record the call
- Silence: activates/deactivates the microphone
- DTMF: activates/deactivates DTMF
7.7 Emergency call
If you do not have any SOS number set, after pressing and
holding the SOS button, you will call 112.
You may set five emergency numbers. After pressing and
holding SOS button (located on the left side in the bottom
of the keyboard) SOS function will be activated. The phone
will activate the alarm and it will automatically send
emergency SMS and it will call the previously set
emergency numbers one after another, from SIM1 card.
The phone will call twice every set contact. The phone will
call the next contact when within 45 seconds it will not
make a call with the previous one.
If one of emergency calls answers the call, the phone will
activate the hands-free mode and it will end the SOS
procedure.
In order to deactivate SOS mode, press red receiver
button.
7.7.1 Entering, deleting, modifying emergency
contacts
You may select no more than 5 emergency numbers.
27
To set the emergency contact quickly, enter the main
MENU pressing UP key. Then select: Organizer->SOS
Settings->SOS numbers. Select which item you want to
change, press green receiver and select appropriate
option:
Edit, to edit the already saved emergency number or enter
the emergency number manually.
Delete to delete already saved emergency number.
If there is no number assigned to the item, after pressing
the green receiver button you will be able to select the
contact from contacts list.
7.7.2 Emergency text
You may change text of SMS, which is sent during the
emergency call. The text saved by default is as following:
„Emergency SMS! Call me” In order to change the SOS
message text, in MENU select Organizer->SOS settings>SOS message. Enter appropriate text and press Save.
7.7.3 SOS button
You may activate or deactivate SOS button. In order to do
this select in MENU: Organizer->SOS settings-> SOS
key.
7.7.4 Sending SOS message
You may set, whether you want to send SOS SMS with
emergency call. To change the setting, select in MENU:
Organizer->SOS Settings->SOS message
28
7.8 Answering calls
To answer the incoming call press the green receiver
button.
To silence the incoming call, press red receiver button.
To reject the incoming call, press the red receiver button
twice.
8. Call list
To enter the call list enter the main MENU and select Call
list->Call list, and then select:
Missed calls (to display missed calls). If you have not
answered the call, in ready mode in upper left corner the
receiver symbol will be displayed.
Dialed numbers (to display dialed numbers).
Answered calls (to display answered calls)
Delete the list (to delete selected calls from the list)
All calls (to display all calls)
After selecting appropriate call press green receiver
button, to display additional options:
- View, displays the call details
- Call, calls a given number
- Send SMS, allows to send SMS
- Send MMS, allows to send MMS
29
- Save in contacts, allows to add the number to the phone
book
- Add to the black list, allows to add the selected number
to the list of barred numbers.
- Edit before the call, allows to change the number before
making a call
- Delete, deletes a given item
8.1 Call settings
Select MENU->Call list->Call settings and then SIM1 or
SIM2
8.1.1 Hiding the number
It is the network service. If the operator offers this service,
it is necessary to make relevant configuration. This
function makes it possible to hide your own number during
a call.
Select „Determine the network”, „Hide the number” or
„Send the number” and press „Ok”.
8.1.2 Waiting call
It is the network service. If the operator offers this service,
it is necessary to make relevant configuration.
After entering MENU and the following option: Call list>Call settings->SIM1 or SIM2->Waiting calls you may
check the state of accessibility and select whether you
want to activate this function.
30
If the function of waiting for a call is activated and the user
is making a call, every next incoming call will be signaled
by the signal of the second call.
It is possible to answer the second call and hang up the
first one.
8.1.3 Transferring calls
It is the network service. If the operator offers this service,
it is necessary to make relevant configuration. The user
may set transferring the incoming calls directly to the voice
mail or to the selected number.
1. To set the function of Transferring calls in MENU enter:
Call list->Call settings->SIM1 or SIM2->Transferring calls
2. Then select, when you want to transfer the calls from
available list: 1 All voice calls (Transferring all
incoming calls to the selected number), 2 When
unavailable (Transfers calls when your phone is
switched off or when you are out of range), 3 When not
answered (Transfers the incoming calls, when you do
not answer the phone), 4 When busy (Transferring
incoming calls, when you are currently making a call), 5
Transfer all data call, 6 Cancel all transfers.
3. Press Activate and enter the number, to which you
want to transfer the calls to activate the service or
Deactivate to deactivate the service.
To check what is the currently selected state of the
service select Check status
31
8.1.4 Call barring
It is the network service. If the operator offers this service,
it is necessary to make relevant configuration. This
function makes it possible to lock different kind of calls.
1. Enter MENU and:
Call list>Call settings->SIM1 or SIM2->Call barring
2. From the list select the type of calls, which you want to
lock. You may lock all outcoming calls, all international
outcoming calls, international calls (except for calls to the
country), all incoming calls and calls incoming while
roaming is activated. You may also change the password
of the lock.
8.1.5 Line switching
For every SIM card you may select one of two lines.
8.1.6 Advanced settings
Black list: when the function is activated, the calls
incoming from the numbers placed on the black
list will not me made, the person calling from this
number will hear the busy tone.
Autorepeat: If the function is activated, when the
attempt to make a call is not successful, the phone
will automatically try to make a call again.
Call time reminder: You may set the function of
signaling the call time.
32
Every specified period of time (30-60sec) or after
a specified period of time (1-3000sec) you will
hear during a call the signal reminding that the
specified period of time has just ended.
Automatic call end: Allows to set the time (1-
9999sec), after which the call will be automatically
ended.
Answering calls: You may select to answer the
calls by pressing any key or automatically when
the hands-free set is connected.
9. SMS and MMS
The phone makes it possible to send and receive SMS
and MMS. When the display shows icon, it means
that there is at least one unread message.
In order to enter MENU SMS in standby mode press UP
key and then select Messages ->Inbox. When the inbox is
full, will flash. Delete the messages from the inbox to
solve the problem.
9.1 Writing and sending SMS
1. Enter MENU and then select: Messages->Write
message->SMS, to open the message editor.
2. Write your message.
33
Changing the method of entering the text: In order
to change the method of entering the text (digits,
capital or small letters) press „#” key, if you want to
enter the symbol press „ ” key.
3. Sending messages: Press the green receiver button
to enter the option, select „Send” and select whether
you want to enter the number manually or select from
contacts. Select the number and press OK. If you
want to send SMS to many persons, you may add
many numbers. To send the message, press „Send”,
and then select, from which card you want to send the
message.
4. Saving messages: To save the already written
message press green receiver button and then select
„Save in Drafts” . The message will be saved in Drafts
folder. You may set that the sent messages are
automatically saved, to do this enter MENU and
select: Messages->Settings->SMS->Save sent
messages
If you want to send MMS, in MENU select: Messages>Write the message->MMS, enter the text, press
Options and select the content and then select
Options and Send, choose the card you want to send
the message from.
34
9.2 Reading and answering SMS
1. When the icon of unread message is shown on the
display or when you want to read the received
messages, in MENU select: Messages->Inbox. To
read the message, press „Options” and select „View”.
While reading you may use additional options pressing
the green receiver.
2. icon next to the message means that it is unread
message.
Pressing „Options” while reading messages, you display
additional functions:
- Answer by SMS: write SMS to the sender
- Answer by MMS: write MMS to the sender
- Call: call the sender
- Delete: delete the message
- Transfer: transfer the message to the other recipient
- Advanced: allows to use the number or URL address,
copy or transfer to SIM card.
9.3 SMS boxes
9.3.1 Inbox
Transfers received messages, classified in terms of date of
receiving.
To scroll the inbox use UP/DOWN keys.
35
To display additional functions while scrolling the inbox
press „Options”:
- View: allows to read the message
- Answer by SMS: write SMS to the sender
- Answer by MMS: write MMS to the sender
- Call: call the sender
- Transfer: send the message to the other recipient
- Delete: delete the message
- Delete all: delete all messages from the inbox
- Save in contacts: save the number in the phonebook
9.3.2 Sent messages
In the case when you use „Send and save” option the sent
messages are then saved in „Sent” folder.
To scroll the inbox use UP/DOWN keys
9.3.3 Drafts
You may save unsent ,messages in „Drafts” folder. In
order to do this write your message and after pressing
green receiver button select „Save”.
Enter Drafts to send, delete or edit the saved messages.
9.3.4 Outbox
If you failed to send the message, it will be saved in the
outbox.
36
9.3.5 Network messages
Select: MENU->Messages->Network messages, to
change the settings for network messages.
9.3.6 Templates
To place ready template or add new template select:
MENU->Messages->Templates->SMS.
9.4 Deleting messages
To delete a selected message enter options and select
„Delete”.
9.5 Message settings
Enter MENU and select: Messages->Settings and then
select:
9.5.1 SMS
SIM
- Profiles: you may change the number of message
center: It intermediates between subscribers while sending
SMS. To send SMS from the cell phone, you need to have
SMS center number entered. You will receive the number
from the service provider.
- Active-time: allows to change the active-time of sent
messages
- Type of message: you may change the type of sent
messages
37
- Delivery report: You may set the phone to receive the
SMS that your message was delivered to the sender
(network service)
- Answering path: allows to activate/deactivate the
answering path
- Preferred call: allows to set the type of call while
sending the SMS
- Voice mail: you may set the voice mail number
Memory status
Allows to check the memory status on SIM card and in the
phone.
Message counter
Allows to check the number of sent and received
messages.
Save sent messages
You may activate or deactivate the function of saving sent
messages automatically
Preferred memory
Allows to select whether the messages are going to be
saved in the phone or on the card.
9.5.2 MMS
Data account
Allows to select the data account necessary to send
MMS.
Common
- Composition: allows to set the time of the slide and
automatic legend
38
- Sending: allows to set delivery reports, priority,
automatic saving.
- Receiving: allows to set receiving MMS in house
network and in roaming and set message filters
- Preferred storing: allows to select the place of saving
the message
- Memory state: allows to check the memory status.
9.5.3 Service messages
You may change the settings of service messages.
9.6 Voice mail
The voice mail is an operator’s service which allows to
leave voice messages when it is not possible to make a
call. To get more information, consult your operator. If you
want to change the number of your voice mail in MENU
select: Messages->Settings->SMS->SIM1/SIM2->Voice
mail and enter appropriate number.
You may receive the number of the voice mail from the
service provider. In order to call the voice mail press
key.
39
10. Organizer
10.1 SOS settings
See point Error! Reference source not found.
10.2 Simple dialing
In MENU select: Organizer -> Simple dialing.-> Status to
activate and deactivate quick dialing. If the function of
quick dialing is activated and numbers are assigned to 2-9
numbers, after pressing and holding relevant key, you will
make a call with the saved number.
To assign the number to the key, in MENU select
Organizer->Simple dialing>Set keys. Then select, to which
key you want to assign the number, press green receiver
button and select the number from the list of contacts and
press the green receiver button again.
10.3 Calendar
To activate the function of calendar, in MENU select:
Organizer->Calendar.
To move to the next/previous day use 4 and 6 keys.
In the calendar you may save the reminders of important
events. If you have a task set for a given day, there is a
notebook symbol next to the date. To display all the tasks
from a given day, press „Options” and then select „View”
Press „Options” and select:
40
- View: allows to view the tasks saved for a given day, you
may delete or modify the task.
- View all: allows to view all saved tasks
- Add the task: allows to set the task for a given day. You
may select the type of the task, beginning and end date,
informing with the alarm, type of the reminder, repeating
etc. After setting all options press Options and select
Save.
- Delete the task: allows to delete selected tasks
- Go to the date: enter the date, which you want to go to
- Go to today’s date: allows to go to the current date in the
calendar.
- View the week: allows to change the view in the
calendar into a week mode
- Beginning of the week: set whether the week is going to
begin on Sunday or on Monday
10.4 Calculator
To activate the calculator, in MENU select: Organizer>Calculator. You may use the following mathematical
operations: addition, subtraction, multiplication and
division.
Enter the first digit using 0-9 keys, then using UP/DOWN
keys select the operation and enter the second digit, press
Ok.
41
10.5 Alarm clock
You may set five independent alarms in the phone. In
order to activate the alarm clock in MENU select:
Organizer->Alarm. Select appropriate alarm and press
Edit. You may activate/deactivate the alarm (using * and #
keys), set the alarm time, type, the snooze time and
repeating. If the phone is switched off, the function of
alarm clock will be active if it is possible taking into
account the battery level. If the alarm is activated, press
green receiver button, to switch off the alarm clock. Press
the red receiver button to activate the snooze function, the
alarm clock will be activated again in 5 minutes.
10.6 Tasks
To view all saved tasks, select MENU->Organizer->Tasks.
Using Up/Down keys select relevant task and press green
receiver button, to display the details of the task, delete or
edit it. If an alarm has been set for the task, the phone will
emit a sound signal on indicated time and the content of
the task will be displayed.
11. Multimedia
11.1 Files manager
Select in MENU: Multimedia->Files manager
Press the green receiver button [Options] :
42
Open- select to open a given folder.
Format- to format a given drive
Details
After opening the folder the green receiver button offers
the following options:
Open
Create a folder- to create a new folder in the selected
localization
Change the folder name
Delete: delete the current folder
Sort according to: the name, type, date of creation, size
etc.
To open a given file, press the green receiver button
[Options] and select view or open. You may also select
other options.
11.2 Camera
With the use of the phone you may take photos
In order to switch on the camera, select in MENU:
Multimedia->Camera. After switching the camera on, you
will see the picture on the screen. The camera is equipped
with digital zoom (enlargement). In order to approach the
object, press Up key and in order to move it away press
Down key.
In order to change the size of the photo (220x176,
160x120, 320x240, 640x480, 1280x1024) and its quality,
43
press Options->Photo settings->, select Photo size or
Photos
Activates the photo viewer
Camera settings
Allows to change the camera settings
for example anti-flicker, time releaser,
switch on/off the photoflash lamp
Picture settings
You may change the picture size and
quality
Whiteness
balance
Allows to adjust the whiteness balance
Modes of the
scene
Automatic or night
Effects settings
Grey scale, sepia, negative
Memory
Allows to select whether the photos are
going to be saved on the memory card
or in internal memory of the phone
Restore default
Restores the default settings of the
camera
Photo quality, pressing * or # you may change the
settings. To take a photo, press 0 key. The photo will be
saved automatically. In order to display more options,
press green receiver button.
Internal memory of the camera allows to take only a few
photos. In order to store more pictures install Micro SD
memory card.
While using Photos function select appropriate picture
with Up/Down keys, * and #, press green receiver button to
display the following options:
- View, enlarges the selected photo. If you want to view the
next photo use Up/Down keys
44
- View styles, you may set the function to display the
photos in the form of list or in the form of the table.
- Send, allows to send the picture as MMS or through
Bluetooth
- Use as, use the photo as the wallpaper or screen saver
- Change the name, allows to change the name of the
- Delete, deletes the photo
- Sort, set sorting according to the name, type, and date of
creation
- Delete all, deletes all photos
- Memory, allows to choose whether the photos are going
to be displayed from the memory card or the phone
memory
- Information about the photo, displays the details of the
photo.
After enlarging the photo, press Options, to display
additional functions:
- Open – activates slideshow
- Turn view – turns the photo
- Use as – use the photo as the wallpaper or screen saver
- Send – send the photo using MMS or Bluetooth
- Information about the photo – displays the details of the
45
11.3 Photo browser
In MENU select: Multimedia->Photo browser. You may
view the previously taken photos. The options available in
photo browser are the same as in Photos function and
they are described in point Error! Reference source not
found..
11.4 Video recording
To activate the camera in MENU select: Multimedia>Camera. To set the recording options press green
receiver button.
Recording starts after pressing 0 key. To stop recording,
also use 0 key. To end recording, press red receiver
button.
To use the camera function it is necessary to install
MicroSD card (not included) and set the option of saving in
memory card.
Options ->Memory and select the memory card.
Photos taken and films recorded with the use of the phone
may be sent to the computer. You will find more
information in Connecting the phone to the computer.
11.5 Video player
In MENU select: Multimedia->Video player. Using the
video player you may watch the previously recorded films
46
(Videos folder). Select relevant recording using Up/Down
keys. To start and stop playing press green receiver
button. To stop recording press red receiver button. To
enlarge the picture in full screen mode, press 0 key. Using
* and # keys you may regulate the volume.
The phone plays the files of AVI and 3GP format.
While scrolling the list of recordings, press „Options”, to
display additional options:
- Play
- Send
- Change the name
- Delete
- Delete all
- Sort according to
- Memory
11.6 Dictaphone
In MENU select: Multimedia->Dictaphone to activate the
function of a dictaphone. Using UP key you may start/stop
the recording. To switch between the recordings use 4 and
6 keys. To start playing the recording press DOWN key.
Press the red receiver button to stop recording or playing.
To display additional options, press the green receiver
button:
- New recording
- Play
47
- Add – allows to add the continuation to the currently
played recording.
- Change the name
- Delete
- List
- Settings – you may select the place of saving and set the
recording quality.
- Use as – set the recording as a ringtone
-Send
11.7 Audio player
Using the audio player you may play the recorded sound
files. They must be located in My Music folder. If new files
were recorded, after activating the player select Options>Restore the list. To start or stop playing, press UP key. If
you do not want the files to be played in the background,
before leaving the player stop the recording pressing
DOWN key.
You may move between the previous and next recording
using 4 and 6 keys. To change the options of playing,
select:
List->Options->Settings
Press * key to change the repeat option.
The volume may be regulated with the use of * and #
keys.
The phone plays the following formats of files: WAV, AAC,
AMR.
48
11.8 FM Radio
Warning: The quality of the reception depends on the
place where you are. Many external factors influences the
reception of radio stations. This factors may cause poor
quality of reception, however it is not the basis for
submitting the complaint
The phone have inbuilt FM radio receiver. You may use it
after connecting the hands-free set, which functions also
as an antenna.
To switch on the radio in MENU select: Multimedia->Radio
FM. To switch off the radio, press DOWN key. If the
option “Play in the background” is activated, before
switching off the radio stop it using DOWN key, and then
press the red receiver button. Otherwise, the radio will be
still played.
Functions of keys while listening to the radio:
# and *: increase/decrease the volume
UP: activating/deactivating the automatic station
searching
DOWN: switching on/off the radio
* (star): automatic searching for station
Red receiver: return to menu
Green receiver – options: List of channels, entering
the frequency manually, automatic searching, settings
(play in the background, speaker)
49
4 key: decreasing the frequency by 0,1 MHz, in
automatic mode searching for the previous station
6 key: increasing the frequency by 0,1 MHz, in
automatic mode searching for the next station
12. Settings
In MENU select: Settings, and then:
12.1 Dual SIM settings
Select whether you want to use both SIM cards or only
one.
12.2 Profiles
The phone have several profiles, with the use of which you
may quickly adjust the phone to different situations. Each
of the profiles may be activated and adjusted according to
your needs. The following profiles are available: General,
Silent, Meeting, Outside, Own.
In each of the profiles using the Adjust option you may
change:
- Alert type(only ringtone, only vibration etc.)
- Ringtone type (single or repeated)
- Ringtone
- Ringtone volume
- Message ringtone
- Message ringtone volume
- Keys tones
- Keys tone volume
- Switching on tone
50
- Switching off tone
- Warnings tone(for example informing about low battery)
NOTE: In standby mode you may quickly switch on/off the
silent mode by pressing # key twice quickly.
12.3 Phone settings
12.3.1 Date and time settings
To set the date and time, in MENU select: Settings
>Phone settings->Time and date. Select “Time zone” to
set relevant city, and then “Set time/date” to enter the time
and date. To move between the date and time use
Up/Down keys, to enter date and time use 0-9 keys.
You may also set the time format (12h or 24h), date format
(DD/MM/YYYY, MM/DD/YYYY or YYYY/MM/DD).
If the battery is removed from the phone, after installing it
again you need to set the date and time.
12.3.2 Planning switching on/off
You need to set the time when the phone is going to
switch on/off automatically.
Set the time of switching on/off and relevant status.
51
12.3.3 Language
Allows to change the language of phone menu. If you set a
foreign language accidently, in standby mode press:
- 2x UP
- 1x Green receiver button
- 2sx DOWN
- 1x Green receiver button
- 2x DOWN
- 1x Green receiver button
Select relevant language and press green receiver button.
12.3.4 Preferred method of entering the text
Set the default method of entering the text, for example,
while writing SMS
12.3.5 Display
You may set the wallpaper, display contrast and the time
of highlighting. You may also set your own wallpaper (for
example the photo) and activate the function of displaying
date and time.
12.3.6 Flight mode
In flight mode all radio connections are switched off.
12.4 Network settings
This option allows to select the operator and the mode of
network selection.
52
12.5 Security settings
12.5.1 PIN code
You may activate/deactivate the request for PIN code
when switching on the phone and change the PIN code for
each of SIM cards.
12.5.2 Phone security
You may activate the phone lock. When switching on the
phone you will have to enter the lock code. The default
code is 0000.
12.5.3 Automatic keylock
This function allows to activate and set the time after which
the keys will be automatically locked.
12.6 Communication
12.6.1 Bluetooth
Thanks to Bluetooth communication you may send and
receive files. You may also connect other devices such as
for example wireless hands-free set.
In MENU select : Settings->Communication and go to
Bluetooth
53
In Bluetooth Menu you may select one of the following
Bluetooth Status
Activate or deactivate Bluetooth
Visibility
Activate so that others could find
your phone
My devices
Devices which you have previously
been connected to
Search for audio
devices
Searches for audio devices, for
example Bluetooth earphone
My name
Select the name for your device
Advanced
Set the audio path, memory, check
the device address
options:
Files sent to mm910 phone are saved in Received folder.
12.6.2 Data communication
Select the SIM card which will be used for sending data.
12.6.3 APN profile
In MENU select: Settings->Communication and go to APN
profile.
For each of SIM cards you may add the data account for
MMS and WAP communication.
The correct configuration may be obtained from your
operator. Some operators make it possible to configure the
phone remotely.
54
12.7 Restoring factory settings
Warning: Default password is: 0000
Thanks to this option you may restore the factory settings.
In MENU select:
Settings->Restore the factory settings, and then enter the
password. Finally confirm with the green receiver button.
13. Connecting the phone to the computer
You may connect the phone to the computer using USB
cable, thanks to which you may copy and transfer the files
between the phone and the computer.
Connecting:
- connect the USB cable to the phone
- connect the other end of the cable to the port in the
computer
- on the phone screen the following message will be
displayed (if keys are not locked): „Mass storage device
and „COM port”. Select the mass storage devices
55
14. FAQ (Solving problems)
„It is not
possible to
make a call”
Check whether the dialed number is correct.
While dialing the number of other country always
add a relevant prefix (for example Germany
0049 or+49)
If the user have a prepaid type card (supplying
with a card), it is necessary to check if the
resources are available on the account, to make
a call)
„ SIM card is
inserted, only
emergency
calls possible
(112)”
Check whether the SIM card is installed correctly
or whether it is not deactivated in MENU
The phone
does not
operate, after
connecting the
charger it is not
charged
It is possible that the phone is switched off,
switch on the phone pressing and holding the
relevant button (red receiver button) for about 3
seconds.
After longer period when the phone was not used
the battery may be in the state of so called” deep
discharge”, in order to restore the correct
operation of the phone connect the charger,
although there is nothing shown on the display.
„Is it possible to
make call being
abroad?”
If the user is abroad, the phone automatically
logs into the foreign network, if ROAMING is
activated. Ask the operator for more information.
The phone may be repaired only by authorized service. It
is forbidden to repair or modify the phone by yourself
otherwise the warranty may be lost!
56
„Is it possible to
make
emergency
calls in the
place where the
phone is out of
range or when
there are no
resources on
the account?”
It is not possible to make any call, if the phone is
out of range.
If the user do not have any resources on the
account it is possible to make emergency calls to
112.
„How may I
increase the
range?”
If the display shows „Does not work”, it means
lack of relevant signal; or resources on the
account. However, in this case it is possible to
make emergency calls to 112, provided that we
are within the range of other operator.
Places such as buildings restrict the range,
approach the window or go beyond the area
where there are many buildings. .
The display
shows „Hold
Unlock”, keys
do not operate”.
Keylock is activated. Unlock the keys holding the
green receiver button.
„What is SMS
center ?”
Number of operator’s center, where text
messages are stored. The number is saved on
SIM card, but in phone menu you may change it
or enter other number.
57
„When the
charge for a call
is calculated ?”
The charge is calculated just after establishing
the call. Ask the operator for the calculation
mode. .
How to check
whether SMS
was delivered
to the recipient?
Activate the option of Delivery report. After the
SMS is delivered you will get SMS with the
information that the message was delivered
(network service)
15. Use and safety terms
Do not switch on the phone if it may cause the
interference into the operation of other devices!
Do not use the phone without relevant hands-free set
while driving a car.
The phone emits electromagnetic filed, which may
negatively influence other electronic devices including,
for example, medical equipment. Keep
appropriate distance, recommended by the device
manufacturer, between the phone and implanted
medical device, such as a peacemaker. Persons with
implanted medical devices should know and obey the
manufacturer’s guidelines. Persons with implanted
pacemaker should not carry the phone in breast
pocket, they should keep the phone at the ear on the
side opposite to the medical device in order to
minimize the risk of interferences and switch the
phone off in case of suspecting any interferences;
58
Do not use the phone in hospitals, planes, near petrol
stations and near inflammable materials.
Do not repair or modify the phone by yourself. All
defects should be removed by qualified service.
The device and its accessories may consist of small
parts. The phone and its parts should be protected
against children.
The phone cannot be cleaned with chemical
substances, or caustic substances.
Do not use the phone near payment and credit cards –
it may cause the loss of data.
Because of safety reasons do not talk by the phone
when the charger is connected.
Do not expose the device to low and high
temperatures and direct influence of sunlight. Do not
place the device near heating installation, for example
radiator, heater, oven, central heating furnace, bonfire,
barbecue etc.
Protect your hearing
Long-term contact with loud sound may cause
the damage of hearing. Listen to music on
moderate level and do not hold the device close
to the ear, when you are using the speaker. Before
connecting the earphones always decrease the volume.
59
16. Warranty terms
The phone has a warranty, which inseparable element is
the proof of purchase. If the phone is damaged because of
improper use, electrostatic discharge or lighting stroke, the
user will have to pay for the repair.
If the user attempts to repair or modify the phone by
themselves it causes the loss of warranty.
The abovementioned information are presented for
informative purposes.
17. Information concerning the battery
There is a battery in the phone, which may be charged
again with the use of the charger included in the set.
The period of phone’s operation depends on different
conditions of operation. The distance from the relay station
and the length and the number of calls significantly
influence the shorter operation of the phone. While moving
the phone continuously switches between the relay
stations, which also considerably influences the period of
phone’s operation.
The battery which was charged and discharged several
hundred times naturally loses its properties. If the user
observes significant loss of efficiency, it is necessary to
buy a new battery.
60
Use only the batteries recommended by the producer. Do
not leave the charger connected for the period longer than
2-3 days.
Do not store the phone in places where the temperature is
too high. It may negatively influence the battery and the
phone itself.
Never use the battery with visible damage. It may lead to
the short circuit and the damage of the phone. The battery
must be inserted in compliance with the polarization.
Leaving the battery, where the temperature is too high or
too low, will make its life shorter. The battery must be
stored in the temperature from 15°C to 25°C. If you insert
cold battery to the phone, it may not operate correctly and
there is a risk of damage.
The set includes li-ion battery. Used
batteries are harmful for the environment.
They should be disposed in relevant point,
in appropriate container, in compliance with
relevant regulations. Batteries cannot be
disposed to the household waste, they should be left in the
place of collection.
DO NOT THROW THE BATTERIES TO THE FIRE!
61
18. Information about SAR
This model fulfils the international guidelines in the scope
of radio waves impact. This device is an emitter and
receiver of radio waves. It is designed so that not to
exceed the limits of radio waves impact, recommended by
international guidelines. These guidelines have been
prepared by independent scientific organization called
ICNIRP taking into account the safety margin in order to
guarantee the protection for all the people regardless of
age and state of health. These guidelines use the unit of
measure called Specific Absorption Rate (SAR) – specific
absorption coefficient.
The limit value of SAR specified by ICNIRP for portable
devices is 2,0 W/kg. The SAR value is measured at the
highest transmitting power, the actual value during the
operation of the device is usually lower than the
abovementioned level. It results from automatic changes
of device power level in order to ensure that the device
uses only the minimum required for providing the
connection with the network.
Although there cannot be any differences in SAR values
in the case of different models of phones, and even in the
case of different positions of use – they are all in
compliance with the regulations concerning safe level of
radiation.
World Health Organization stated, that the current
researches indicated that there is no need to use any
special restrictions concerning the use of mobile devices. It
also indicates that in order to reduce the influence of
radiation it is necessary to limit the length of calls or use
62
hands-free set while conversation in order not to hold the
phone near the body or head.
In the case of this model, the highest measured SAR value
in tests is 0.560W/kg for EGSM900 and 0.533W/kg for
DCS1800 .
SAR values may also differ depending on domestic
requirements of reporting and testing and on the frequency
band in a given network.
63
19. Information concerning the environment
protection
Note: This device is marked in compliance with European
Directive 2002/96/WE and Polish Act concerning
used electric and electronic equipment with
crossed out container.
This mark informs that this equipment, after the
period of its use cannot be placed in household
waste.
Note: This equipment cannot be thrown away together
with household waste!!! This product should be utilized by
separated collection in specially prepared places.
Correct treatment of used electric and electronic
equipment allows to avoid the consequences harmful for
people’s health and natural environment, resulting from the
presence of dangerous compounds and improper storage
and treatment of such kind of equipment.
64
20. Declaration of conformity
65
Some information presented in this instruction manual may
differ depending on the phone configuration. It depends on
the installed software, service provider and SOM card. We
reserve the right to make changes in the product and its
functions, without previous notice.
Technical assistance, - number: 32 325 07 00 or email
serwis@maxcom.pl
66
67
MM 910 v01-07-2014
0700
Maxcom MC6900 v.
2011.03
MAXCOM S.A.
43-100 Tychy,
ul Towarowa 23a
POLAND
tel. 32 327 70 89
fax 32 327 78 60
www.maxcom.pl
office@maxcom.pl
Loading...
