Mattel Tony Hawk, 95170-0920G1 Owner's Manual

95170-0920G1

OWNER’S MANUAL

Please read thoroughly before operating your vehicle. Keep these instructions for future
reference: they contain important information.

CAUTION: Surfaces may become hot
and cause burns if electronics get wet. Do
not operate vehicle through water or snow.

I. CONTENTS

• TMH®TONY HAWK SKATE­BOARD Vehicle

• Transmitter

FEATURES

• Adaptive Control System for
world-champ tricks and
stunts

• Authentic Tony Hawk rider
figure

• Available in 2 frequencies:
27 MHz & 49 MHz (refer to
labels on transmitter &
vehicle for frequency)

• Range up to 65’/20m

VEHICLE

❶ ON/OFF Switch
❷ Steering Adjuster
❸ Battery Door
❹ Battery Compartment

II. QUICK START

Please read this Owner's Manual thoroughly.

1. Start with a full charge.

2. Turn vehicle switch ON. Turn transmitter switch ON. Activate transmitter to run and control your
vehicle.

3. When you’re done driving, turn vehicle and transmitter switches OFF. Remove all batteries for
storage.

FLEXPAK

FLEXPAK

2

1

❹

❶

❸

❷

Your vehicle features the digital Adaptive Control System

for the ultimate in control…and amazing stunt action. Each
transmitter control stick has seven different positions.

Note: During excessively hard driving, your vehicle may turn itself OFF to protect its electrical
components from overheating. This does not indicate that the vehicle has a problem. If the
vehicle does shut itself OFF, simply allow it to cool down. Once it has cooled, you will be able
to resume normal driving.

TRANSMITTER (BACK VIEW)

TRANSMITTER (BACK VIEW)

LEFT ACTION BUTTON

RIGHT ACTION BUTTON

FORWARD

FAST

MEDIUM

SLOW

H
A
R
D

REVERSE

SLOW

MEDIUM

FAST

LEFT

TURN

RIGHT

TURN

In addition to the con­trol sticks, the trans­mitter features two
action buttons that let
you control the skate­boarder body…not
just the board!

If you push the action button and hold it down, the rider will turn 90°…and it will stay that
way until you release the button. If you quickly push and release the action button, the rider
will do a quick turn and immediately return to its normal position.

III. OPERATING YOUR VEHICLE

Please refer to Sections VI and VII for proper battery installation and care.

Your vehicle features the digital Adaptive Control System for the ultimate in control…and amazing

stunt action. Each transmitter control stick has seven different positions.

S
O
F
T

M

E
D

I

U

M

S
O
F
T

M

E
D

I

U

M

H
A
R
D

POWER SWITCH

ON

OFF

IV. TALK THE TALK...STICK THE TRICKS!

With the combination of advanced digital control, seven speeds and seven-position steering, and

control over the body and the board, the Tony Hawk Skateboard is the ultimate R/C skateboard.

The Tony Hawk Skateboard is designed and engineered to work like a REAL skateboard…so you’ll

need to PRACTICE to perfect your technique. Visit our website for more info: tycorc.com

TALK THE TALK!

To be a "pro" skateboarder, you

have to talk the talk!

MANUAL: A cool wheelie! The

board’s front wheels pop up

into the air, and the board rides

on its rear truck.

SLALOM: When you "Slalom"

you rock the board from side to

side, weaving back and forth

while moving forward or back.

REVERT: In a Revert, the back

end of the board slides

around…180° or a full

360°…and keeps driving in its

original direction.

TRANSFER: When a board

"transfers," it moves directly

from one obstacle to another.

STICK: To "Stick" is to land a

trick successfully…and ride

away.

STICK THE TRICKS!

This manual shows you how to do some ultra-realistic skateboard tricks. Once you master them,

you’ll realize you can do lots of other cool stunts! So practice, have fun, and invent some awe-

some tricks of your own!

GROUND TRICKS

These tricks work best on

smooth, flat surfaces.

MANUAL

Push the left stick down all

the way to drive in reverse.
Once you’ve accelerated to

full speed, quickly push the

left stick up and then release

it. Your vehicle will jam up

into a cool wheelie! For extra

stunt action, steer right or

left while your vehicle is in

wheelie mode. This will

cause the vehicle to drop

back onto all four wheels,

changing direction as it does.

This trick works best with a

"medium" left or right turn.

TIC TAC

To do this trick, simply steer

your board right and left while

driving, either forward or

reverse. The board will rock

from side to side. Try this trick

with "medium" and "hard" left

and right turns. The cool engi-

neering of the board makes it

work just like the real thing!

180° REVERT

First, push the right action

button to rotate the rider so

he’s facing backward. Now

push the left stick down all

the way to drive hard in

reverse. Then quickly push

the left action button and

hold it down, while steering

to the right. The board’s front

truck will swing around to the

left. When it comes around

180°, push the left stick for-

ward to keep driving.

RADICAL RECOVERY

Start with the board lying flat

on its side. Push either the

left or right action button to

rotate the rider. His right

hand will come around, pivot-

ing the board and bringing it
up to an angle. Steer right or
left to bring the board all the

way up! (This trick will also

1.

2.

3.

1.

2.

3.

1.

3.

+

2.

4.

1.

2.

or

or

let you "right" the board if it

tips over while you’re driving.)

RAMP/OBSTACLE TRICKS

These tricks work best on
ramps or other obstacles.

TRANSFER (& STICK)

To "Transfer" from one obstacle

to another, push the left stick

up (for forward) or down (for

reverse), steering left or right

to aim toward the obstacle you

want to "transfer" to. For maxi-

mum stability, push the left or

right action button to swing

the rider 90° left or right.

360° REVERT

This trick is similar to the 180°

Revert, but it works best on a
smooth ramp (or half-pipe), or
a very slick, flat surface. Push

the right action button to

rotate the rider so he’s facing

backward. Now push the left

stick down all the way to drive

hard in reverse. Now quickly

push the left action button and

hold it down, while steering
hard to the right. The board’s
front truck will swing around

to the left. When it comes

around a full 360°, push the left

stick up to keep driving.

180° SPIN

Push the left stick up to drive

up an inclined ramp or half-

pipe. Just before you get to the

top, hit either the left or right

action button, while steering

either left or right. The front

end of the board will swing

around 180°. Keep the left stick

pushed up to drive the board

forward coming down.

On the down slope, the
rider MUST be rotated so
that he’s facing the front of
the board.

V. QUICK TIPS

❶When your vehicle starts to

lose power, it may lose func­tions or performance. It's
time for a recharge. Your
vehicle's running time may
change depending on your
driving style.

❷Radio interference can make

your vehicle run badly.
Interference can be caused

by other R/C vehicles run­ning on the same frequency;
electrical wires; large build­ings; or CB radios. Try to stay
away from these!

❸Point your transmitter anten-

na up - not down toward
your vehicle. If your vehicle
gets too far away, it won’t
work properly.

❹Don't drive your vehicle in

sand or through water or

snow. If your vehicle does
get wet, wipe with a towel
and allow to dry completely.

❺Don’t store your vehicle near

heat or in direct sunlight.
Always turn switches OFF
and remove all batteries for
storage.

❺❹❶❸❷

or

2.

+

or

3.

1.

2.
+

or

3.

1.

VII. BATTERY

INSTALLATION

VEHICLE

❶Make sure the FlexPak

®

battery pack is fully flat, so

that the labels marked

1

and 2 are facing up, as
shown.

❷ Unlock the battery door as

shown.

❸Insert the battery pack into

the battery compartment

and slide it into the com­partment. The battery will
flex slightly as you slide it
forward to fit in the com­partment. Press down to
make sure the battery is
secure in the compartment.

BATTERY SAFETY
INFORMATION

 Insure that battery polarity

is correct.

 Use only batteries of the

type recommended (or
equivalent).

 Do not mix old and new

batteries.

 Do not mix alkaline, stan-

dard (carbon-zinc), or
rechargeable (nickel-cad­mium) batteries.

 Remove used-up batteries

immediately. Remove bat­teries if vehicle will not be

used for a long period.

 Do not recharge non-

rechargeable batteries.

 Do not short-circuit

terminals.

 Remove rechargeable bat-

teries before recharging (if
the batteries are designed
to be removable).

Recharge batteries only

under adult supervision (if
the batteries are designed
to be removable).

Dispose of batteries safely.

Do not dispose of batteries
(or products containing
non-replaceable batteries)

in fire, as batteries may
explode or leak..

Battery Performance Note:
For best performance use

alkaline batteries (where dis­posable batteries are called
for). If your vehicle is supplied
with standard (carbon-zinc)
batteries for initial use and/or
demonstration purposes, we
recommend replacing them
with alkaline batteries when
necessary. Battery life may
vary depending on battery
brand.

VI. POWER SYSTEM

(Batteries and Charger Not
Included)

FOR DETAILED INFORMATION
REGARDING VEHICLE BAT­TERY CHARGING AND SAFETY,
PLEASE FOLLOW THE SPECIF­IC INSTRUCTIONS THAT
CAME WITH YOUR TMH

®

FLEXPAK®BATTERY PACK
AND CHARGER.

• Your vehicle will not operate
without the TYCO

®

R/C

TMH

®

FlexPak®Battery
Pack and Charger. The TMH
FlexPak battery pack is
designed for use exclusively
in TYCO

®

R/C TMH Power
vehicles. It will not work in
any 6.0V or 9.6V NiCd battery
powered vehicles.

• Your TMH FlexPak battery
pack features a unique
design (Patent Pending)
which allows it to be config­ured in different ways for
use in different TMH power
vehicles. This feature allows
maximum performance for
each vehicle. To configure
your FlexPak battery pack
for use in this vehicle,
please refer to Section VII,
“Battery Installation.”

❶TMH

®

FlexPak®Battery

Pack and Charger

Note: Adult supervision recom­mended when using THM
Flexpak and Charger.

❷ALSO AVAILABLE:

Additional TMH

®

FlexPak

®

Battery Pack

Charge additional Battery
Packs ahead of time for longer
non-stop action!

❶

FPO

❷

FPO

ALSO AVAILABLE

TRANSMITTER

❶To install transmitter bat-

tery, open battery door as
shown.

❷ 2. Install one 9V battery

with polarity (+/-) as shown
inside battery compart­ment.

❸Swing battery door closed

and snap shut.

VIII. SAFETY INFORMATION

• Adults, this toy is recom­mended for children 8 years
of age and older. To ensure
that the child’s play is both
safe and fun, please review
the operating instructions
and these general safety

rules with the child.

• NEVER drive your vehicle on
streets! They’re for real cars!

• DO NOT pick up vehicle
while in motion.

• Keep fingers, hair and loose
clothing away from the tires
and the wheel hubs while

the vehicle is switched ON.

• Adult supervision is recom­mended when this vehicle is
being operated.

• To avoid accidental opera­tion, remove all batteries
when not in use.

❸

❷

❹

❶

❹ Replace the battery door

and lock it, as shown.

❺ To remove: release the

battery door and slide out
the battery pack.

Estimated run time for this
vehicle: approximately 30 min­utes

FLEXPAK

2

RECHARGEABLE BATTERY PACK

FLEXPAK

FLEXPAK

2

1

SYMPTOM

Vehicle runs slowly or will not run.

Erratic operation or only short range
possible.

Short battery life.

Vehicle doesn't work after going
through water or snow.

Vehicle stops running.

• PROBABLE CAUSE

• Loose battery connection or vehi­cle switch not ON.

• Weak or uncharged rechargeable
battery.

• Weak transmitter battery.

• Debris around rear wheels.

• Radio interference likely.

• Battery not fully charged.

• Debris around rear wheels.

• Water in the electronics area.

• Automatic protection circuit acti­vated (normal function).

• CORRECTION

• Check battery connector and vehi­cle switch.

• Charge battery or replace.

• Replace with fresh alkaline battery.

• Clear debris with small, stiff brush.

• Change location (see point 2 –
Quick Tips)

• Recharge TMH®FlexPak®battery
pack. For maximum running time,
make sure you give your battery
pack a full charge.

• Clear debris with small, stiff brush.

• Vehicle will take several hours to
dry. Allow to dry thoroughly
OVERNIGHT before trying again.

• Operate your vehicle in a dry area.
Avoid driving in water and snow.

• Allow vehicle to cool down and
resume normal driving.

T

R

O

U

B

L

E

S

H

O

O

T

I

N

G

P

R

O

B

L

È

M

E

S

P

R

O

B

L

E

M

L

Ö

S

U

N

G

P

R

O

B

L

E

M

I

P

R

O

B

L

E

M

E

N

P

R

O

B

L

E

M

A

S

P

R

O

B

L

E

M

A

S

F

E

L

T

R

O

U

B

L

E

S

H

O

O

T

I

N

G

© 2001 Mattel, Inc., Mt. Laurel,
NJ 08054 U.S.A.
PRINTED IN CHINA. All Rights
Reserved. ® and ™ designate U.S.
trademarks of Mattel, Inc.

Retain this address for future refer­ence: Mattel U.K., Ltd., V

anwall
Business Park, Maidenhead SL6 4UB.
Mattel Australia Pty., Ltd., Richmond,
Victoria 3121 - Consumer Advisory
Service: 1800 800 812 (valid only in
Australia). Mattel East Asia Limited, 930
Ocean Centre, Harbour City, HK, China.

COMPLIANCE WITH FCC REGULA­TIONS

THIS DEVICE COMPLIES WITH PART 15
OF FCC RULES. OPERATION OF THIS
DEVICE IS SUBJECT TO THE FOLLOW­ING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY
HARMFUL INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
This device generates and uses radio
frequency energy and if not used prop­erly may cause interference to radio

and television reception. It has been
tested and found to comply with the
limits set by the FCC, which are
designed to provide reasonable protec­tion against such interference.

CAUTION: Changes or modifica­tions not expressly approved by the
manufacturer responsible for compli­ance could void the user’s authority to
operate the equipment.
