xcore ascend™
Technical Data
xcore ascend™ is a vinyl wall covering that is 100% waterproof. It consists of a dimensionally stable fiber cement core,
decorative layer, EVA acoustic foam backing and an embossed PU protective coating. The hybrid compound structure
has beveled edges, offers dimensional stability five times greater than traditional vinyl and is installed with ease.
Sizes, Weights & Units
Planks: 3-foot x 6-inch, 14 planks / 21 square foot / case.
Tiles: 2-foot x 1-foot, 10 tiles / 20 square foot / case.
Thickness: 5.5 mm (0.22-inch).
Weight: 18 ounce / square foot.
3-foot X 6-inch (plank) or 2-foot x 1-foot (tile) and a thickness of 5.5 mm. 18 ounce / square foot with 14 planks / case
(21 square foot) or 10 tiles / case (20 square foot).
MI Wall Seal & Adhesive
MI Wall Seal – Coverage: ~ 300 square foot / gallon.
Original Gorilla Glue – Coverage: ~ 10 – 11 square foot / fluid ounce.
Apply MI Wall Seal using a 1/8-inch or 1/4-inch paint roller for smooth surfaces.
Vertical Burning Characteristics
Class A.
ASTM E84 Measurement Uncertainty and Statistical Process Control for the Steiner Tunnel. xcore ascend™ is rated as
Class A, which requires a flame spread index of 0-25 and the smoke developed index between 0-450.
Metal Content
When tested according to ASTM F963 Standard Heavy Metal Content Analysis, xcore ascend™ was found to have no
concern with any of the listed heavy metal content.
Dimensional Stability
0.10%.
According to ISO 23999, xcore ascend™ has a total dimensional stability result of 0.10%, and from 74oF to 113oF the
expansion is only 0.01%, while from 74oF to 41oF the contraction is 0.05%. xcore ascend™ is suitable for use over
underfloor heating up to 100
o
F.
Staining
Meets requirements.
xcore ascend™ meets the requirements of ASTM F925 Standard Test Method for Resistance to Chemicals of Resilient
Flooring.
Static Load
When tested according to ASTM F970 Standard Test Method for Measuring Recovery Properties of Floor Coverings
after Static Loading at 500 lb. the residual compression is 0.003 inch which exceeds the required 0.005 at 250 lbs.
Accessories
Edge Trims and Multi-function Angles, Montinator adhesive
Edge Trims and Multi-function Angles are available to finish or cover over the cut ends, etc. Made from vinyl covered
aluminum, they are available in color coordinating sizes of 0.31-inch x 0.79-inch x 6.5-foot (8 mm x 20 mm x 2000 mm).
To install these, simply cut to size and stick into place using Liquid Nails or similar.
August 2018 xcore ascend™ Page 1 of 6
Note: Painters tape may be required to hold the trim in the correct position until the adhesive has cured.
Warranty
10 years commercial, 25 years residential.
xcore ascend™ has a limited warranty (details on www.matsinc.com) of 10 years for commercial or 25 years for
residential use when installed and maintained according to the instructions.
LEED v4
Information
Many finishing products have the potential to contribute points to LEED v4; however, the credits can only be gained
when calculating the combined performance of all the products used on a particular LEED project; therefore no single
product can guarantee you will obtain LEED v4 credits.
xcore ascend™ may contribute to the following LEED credits (points), the following is based on LEED NCv4:
v4 MRp2: Material and Resources – Construction & demolition waste management planning:
The tiles or planks reduce waste from the installation process, reducing waste in landfills.
Made from recyclable material and / or is a reusable product, reducing waste in landfills.
v4 EQc2: Indoor Environmental Quality – Low emitting materials:
Option 1 (MI Wall Seal). VOCs: Rule #1113 of California's SCAQMD, 0 grams / liter.
Option 2. Budget Calculation Method.
Installation Instructions
Information
xcore ascend™ tiles or planks are for indoor use on walls only and are not suitable for installation around any heat
source like hot pipes where the temperature can reach > 85oF or in areas continuously exposed to moisture vapor like
saunas.
Note: For confirmation of acceptable “wet-areas” and the installation requirements, please contact the Mats Inc.
technical department.
Warnings
xcore ascend™ contains a small amount of crystalline silica. The Occupational Safety and Health Administration (OSHA)
has exposure limits for those exposed to respirable crystalline silica. The published OSHA requirements and exposure
limits must be followed. All Safety Data Sheets (SDS) must be read, understood and followed. All local, state and federal
regulations must be followed. This includes but is not limited to the removal of in-place asbestos-containing material.
Conditions and Storage
The area must be enclosed, weather tight and properly conditioned at a constant (± 5°F) service temperature that is also
between 65°F and 80°F for 48 hours prior to and during the installation. Unpack pallets and restack the cases neatly and
no more than 5 cases high for 48 hours to properly acclimate. Alternatively, use a non-contact infrared digital
thermometer and check the temperature of the surface of the wall and the xcore ascend™, all of which must be at least
65°F prior to commencing the installation.
Tools & Equipment
August 2018 xcore ascend™ Page 2 of 6
MI Wall Seal – personnel protective equipment (PPE) – tape measure – straight edge or framers square – pencil –
guillotine floor cutter – utility knife with straight blades – level – 1/8-inch or 1/4-inch paint roller for smooth surfaces –
workbench – low-grab masking tape – wall roller – stirring stick and tray – Infrared thermometer and camera phone.
Surface Preparation
The wall must be structurally sound and smooth, without any ridges. Regarding flatness, test any areas of concern using
a 2-ft. straight edge placed at any point or direction on the wall. Nowhere on the wall shall have a void or gap underneath
the straight edge greater than 1/4-inch. If it does, then have the void filled / repaired first. The surface of the wall must be
cleaned to remove all contaminants like grease, dust, and dirt. The MI Wall Seal must be applied following the directions
on the label. Using the low-grab masking tape, first, protect areas that do not require the MI Wall Seal, then apply a thin
and even (smooth) coat with the 1/8-inch or 1/4-inch nap paint roller. Remove the masking tape immediately and allow to
dry, for at least 60 minutes.
Use a wide paint scraper, drywall knife, flat trowel or similar and lightly back-trowel the MI Wall Seal to remove any debris
or imperfections.
Layout
Follow any design plans if provided or have your design approved first. Carefully plan where your starting lines are
located, avoiding small cuts at the perimeters. Using a level and a pencil, mark your starting line on the wall. Typically
this should be at or near the center of the area.
Installation
Peel off the release paper from the back of the tile/plank and apply a small amount (~ ½ pea size) of “Original Gorilla
Glue” (available from home improvement stores) to every other hole plus all corners. Do not overfill as the glue will
expand during the curing process.
Carefully position the tile/plank following your start lines and then press firmly into place. Continue this process following
either your start line or previously installed tiles.
Note: if any “Original Gorilla Glue” oozes out of a seam though over application or is spilled onto the surface of the tile,
then it must be allowed to fully cure and then scraped off using a blunt instrument so as not to damage the surface of the
tile/plank.
Cutting
Measure, cut and install the perimeter cuts as you go using a suitable guillotine style flooring cutter or a framers metal
square (or similar) with a sharp utility knife.
Note: Keep your hands and body away from the direction of the blade to avoid cutting yourself in the event of a slip. Cut
through the top layer of product, scoring the cement fiberboard core. Bend the xcore ascend™ tile or plank downwards
(away from the surface) until it snaps along your cut. Using a utility knife with a sharp blade, cut through the backing and
trim off any burr if required. Continue with the installation until complete.
Grouting
Grouting seams are optional. If desired, use Mapei Flexcolor CQ Acrylic Premixed grout (available from your local
distributor). Follow the written application instructions from Mapei and allow to dry prior to use.
Note: The performance warranties of Mapei products remain with the manufacturer.
Accessories
If required, cover any cut or unfinished edges using the xcore ascend™ Edge Trims and Multi-function Angles. To
install these, simply cut to size and stick into place using Liquid Nails or similar.
Note: Painters tape may be required to hold the trim in the correct position until the adhesive has cured.
Finish
Clean up all debris, take photographs and have the end user sign a “Job Completion Ticket”.
August 2018 xcore ascend™ Page 3 of 6
Maintenance Instructions
Precautions
Follow facilities Standard Operating Procedures (SOP). All Safety Data Sheets and product label instructions must be
read, understood and followed prior to using the product.
Initial Cleaning (after installation)
xcore ascend™ does not require initial cleaning.
Finish
xcore ascend™ does not require any coats or finish to be applied.
Daily Cleaning
Damp mop when required, using a nonabrasive sponge or cloth with either Windex® or a diluted neutral
cleaner/degreaser as often as required.
Additional Information
Do not use dust mops treated with oils or silicones, acetone, strong alkaline cleaning agents, scouring powder, strong
solvents, or abrasive cleaning pads, as these can damage the product.
Note: These instructions supersede any verbal or written instructions from Mats Inc. representatives, and must be
followed in order for the Mats Inc. xcore ascend™ warranty to be in effect.
Limited Warranty
Mats Inc. (“SELLER”) warrants that xcore ascend™ (the “Product”) sold to the first end user (“END USER”) will be free of
manufacturing defects in materials provided that they are stored, installed, and maintained strictly in accordance with the
SELLER’s instructions for a period as provided in Section IV of this Limited Warranty.
Receipt and installation of the Product constitutes acceptance of this Limited Warranty and all of its terms,
conditions, limitations, and disclaimers.
This Limited Warranty applies only to installations sold to the first END USER of the Product and becomes void on the
transfer or sale of the Product or the use of the Product by any party other than END USER.
I. Installation and Maintenance Requirements
This Limited Warranty applies only if:
(A) The Product is installed on a properly prepared subfloor as detailed within the product installation instructions; and
(B) The Product must be installed properly following the installation instructions by professional flooring installers
experienced at installing commercial resilient floor covering products and having sufficient professional liability
insurance coverage (aka Errors and Omissions Insurance) for the project; and
(C) The product is maintained according to the SELLER’s instructions furnished to END USER at the time of
purchase; and
(D) The Product is not misused or abused, and there is no evidence of mishandling, neglect, modification or repair
without the approval of SELLER, or damage done to the product by anyone other than SELLER.
II. Method for Obtaining Warranty Service
To obtain a replacement product under this Limited Warranty, END USER must
August 2018 xcore ascend™ Page 4 of 6
(A) Provide SELLER with a written notice of any alleged defect within the warranty period stated in Section IV and
ten (10) days of its discovery; and
(B) Ship the photographs of the defective product(s) to SELLER, at 179 Campanelli Pkwy., Stoughton, MA 02072,
with mailing or shipping charges prepaid (“Warranty Claim Procedures”).
III. Warranty Service Provided
(A) If the Product shall be proved to SELLER’s satisfaction to be defective, within the applicable warranty period
described below, SELLER’s obligations under this Limited Warranty shall be limited to either repairing or replacing
the Product, at SELLER’s sole discretion, if such defect was caused solely by defective materials. Such repair or
replacement shall be SELLER’s sole obligation and END USER’s exclusive remedy hereunder and shall be
conditioned upon END USER’s fulfilling its obligations under SELLER’s Warranty Claim Procedures.
(B) Pursuant to Subsection (A), SELLER’s warranty services will specifically include providing END USER with
alternative wall covering of comparable quality and/or carry out necessary repairs of the Product to cover the
remainder of the warranty period necessary repairs. This includes material cost only and does not include labor.
IV. Warranty Period
This Limited Warranty of the Product, and any implied warranties provided to END USER by state law not otherwise
excluded or disclaimed in this Limited Warranty, apply for a period commencing from the date of shipment of the
Product from SELLER’s manufacturing or distribution facilities, including motor drive or other means of transportation.
The length of the xcore ascend warranty period is 10 years for commercial and 25 years for residential usage.
V. Exclusions from Warranty
(A) This Limited Warranty does not apply to Product which has been discontinued or to a particular color or design which
has been discontinued, at the time of sale, or to Product sold as seconds or B grade.
(B) This Limited Warranty does not apply to outdoor installations.
(C) The following is not included under this Limited Warranty:
1. Color deviations as compared to physical, printed, and/or electronic representations
2. Damage caused by improper storage and handling prior to installation;
3. Any use of the product which in the sole judgment of the SELLER is improper;
4. Product delivered damaged unless the SELLER is notified as soon as the Product is received;
5. Damage or Product failure including adhesive and accessories as a result of either improper substrate preparation,
installation or maintenance;
6. Damaged caused by exposure to petroleum distillants (solvents, chlorine, acidic chemicals) or industrial oils;
7. Damage caused by excessive moisture in the wall (above the ambient levels);
8. Damage caused by misuse, unreasonable use, abuse and/or negligence;
9. Damage caused by extended direct exposure to sunlight or excessive heat;
10. Labor costs for removing and/or re-installing replacement and associated freight costs are not covered
under this warranty
VI. Limitations on Warranty
This Limited Warranty is provided by SELLER, and it contains the only express warranty provided to END USER by SELLER.
SELLER does not authorize any other person to give any other warranties on SELLER's behalf.
SELLER disclaims any express warranty not provided herein and any implied warranty, guaranty or representation
as to performance, quality and absence of hidden defects, and any remedy for breach of contract, which but for this
provision, might arise by implication, operation of law, custom of trade or course of dealing, including implied
warranties of merchantability and fitness for a particular purpose. SELLER further disclaims any responsibility for
August 2018 xcore ascend™ Page 5 of 6
losses, expenses, and inconveniences, special, indirect, secondary or consequential, incidental, and contingent
damages whatsoever, including damages arising from ownership or use of the product.
Implied warranties in jurisdictions where they may not be disclaimed shall be in effect only for the duration of the express
warranty set forth herein. If END USER has a claim under this Limited Warranty or under any implied warranties provided to
END USER by state law, END USER may not file a court action based on that claim any later than one (1) year after END
USER’s right to file a court action accrues. In those states which do not allow this limitation on the time period for filing a court
action, this provision is inapplicable.
VII. Sellers Liability
SELLER’s liability with respect to the Product sold to END USER shall be limited to the warranty provided herein.
SELLER shall not be subject to any other obligations or liabilities, whether arising out of breach of contract, warranty, tort
(including negligence and strict liability) or other theories of law, with respect to products sold or services rendered by the
seller, or any undertaking, acts or omissions relating thereto.
Without limiting the foregoing, SELLER specifically disclaims any liability for property or personal injury damages,
penalties, special or punitive damages, damages for lost profits or revenues, services, downtime, shut down or slow down
costs, or for any other types of economic loss, and for claims of END USER’s customers or any third party for any such
damages. SELLER shall not be liable for and disclaims all consequential, incidental and contingent damages
whatsoever.
VIII. Miscellaneous
Any description of the Product, whether in writing or made orally by SELLER or SELLER’s agents, specifications,
samples, models, bulletins, drawings, diagrams or similar materials used in connection with END USER’s order, are for
the sole purpose of identifying the Product and shall not be construed as an express warranty. Any suggestions by
SELLER or SELLER’s agents regarding use, application, or suitability of the Product shall not be construed as an express
warranty unless confirmed in writing by SELLER to be such.
August 2018 xcore ascend™ Page 6 of 6
Loading...
