Tech Note #8

VPN

Summary

This document describes the use of VPN in the Matrox iSwitch. It contains the following:



A list of products that support this feature



A description of VPN and its features.

Applicability

This feature is available in the following products:



The Matrox iSwitch 8.

VPN

What Is It?

Virtual Private Network (VPN) is a technology that allows a business to create a private Wide
Area Network (WAN) utilizing more cost-effective public networks as a backbone. Since data

flows over a public network, such as the Internet, encryption technology protects the data. Only
networking equipment that contains the correct algorithms and the correct decoding keys could
read the data that the VPN transfers over the public network. Since the decoding keys are user
configurable, administrators are able to create VPNs.

How Does It Work?

The main ingredients of the VPN are Identification, Encapsulation and Encryption.
Identification:

Transmission:

When a LAN client sends a packet, it must be determined whether this packet is destined
for the local LAN, the Internet or a remote LAN. The Matrox iSwitch compares the
destination IP address of the packet to the addresses defined in the VPN table. If the
Matrox iSwitch identifies the packet as being destined for a remote LAN, then it must be
processed as a VPN packet.

Reception:

When a Matrox iSwitch receives a packet from the WAN, it checks the IP header to
determine if it is VPN packet. If so, then the Matrox iSwitch processes it as a VPN
packet.

© Matrox Networks 1999

TechNote #8 - VPN Page 2 of 4

Encapsulation:

Encapsulation, also known as tunneling, is the process of taking the original LAN packet
that contains private IP addresses and wrapping it in a new IP packet that contains
routable Internet addresses. The two sets of addresses are required to allow
communication on both the private and public networks.

Transmission:

The Matrox iSwitch identifies the packet's new IP address as a VPN destination by
looking it up in the VPN table. Then the Matrox iSwitch again consults the VPN table to
determine the correct tunnel endpoint IP address for when the VPN process encapsulates
the packet with the new addresses.

Reception:

In the case of reception, the Matrox iSwitch simply removes the extra header after the
source IP address uniquely identified the correct VPN table entry. The Matrox iSwitch
requires this information to allow the correct choice of encryption algorithm and
decoding keys.

Encryption:

Once the identification and encapsulation steps have allowed the packets to be correct
routed across both the private and public networks, then the only remaining component is
the encryption choice to allow for privacy and data security.

In the case of encryption, the Matrox iSwitch makes no distinction between transmission
and reception since it uses the same algorithm and keys for a given tunnel. The Matrox
iSwitch encrypts transmitted data before it encapsulates. Decryption occurs once the

Matrox iSwitch removes the encapsulation from the original packet.
Example:
To clarify this process, an example based upon Figure 1 follows. Assume that we will follow a

packet as it goes from client A on LAN 1 to client B on LAN 3. The sequence of events is as
follows:

1. Client A (192.168.18.9) on LAN 1 builds a packet to send to Client B (192.168.20.5) on

LAN 3.

2. The packet arrives at the default gateway of client A: Matrox iSwitch # 1 at 192.168.18.120.

3. Matrox iSwitch #1 recognizes that the destination Subnet ID of the packet exists in its VPN

table. The VPN table indicates that it is destined for LAN 3 with a corresponding Internet
destination address of 132.11.1.12. The entry also indicates the encryption parameters the
Matrox iSwitch should use.

4. Matrox iSwitch #1 encrypts the complete packet. It then encapsulates the result in a new

packet with a destination IP address of 132.11.1.12, a source IP address of 200.200.10.1, and
a setting to indicate that the payload contains a Generic Routing Encapsulation (GRE)
packet.

5. Matrox iSwitch #1 ships this packet across a WAN port to the ISP. The packet is routed

through the Internet to eventually arrive at Matrox iSwitch #3.

c. Matrox Networks 1998

TechNote #8 - VPN Page 3 of 4

(

)

(

)

(

)

(

)

6. Matrox iSwitch #3 inspects the received packet and notes that it contains a GRE packet. It

then extracts the source IP address of 200.200.10.1 and looks for a matching entry in its VPN
table. The matching entry allows the encryption parameters to be obtained (the parameters
are identical to the parameters used by Matrox iSwitch #1 in step 3).

7. Before applying the encryption parameters, Matrox iSwitch #3 removes the IP header that

was added by Matrox iSwitch #1 in step 4. The encryption algorithm is applied and the result
is the original packet sent by Client A.

8. The Matrox iSwitch #3's switching engine examines the packet and sends it to the port to

which Client B connects.

9. The secure transmission of a packet over the Internet is only complete when Client B

receives the packet.

LAN 1

Private Network

192.168.18.x
Client A

192.168.18.9

LAN 2

Private Network

192.168.19.x

192.168.18.120

Matrox
iSwitch

#1

200.200.10.1

132.11.1.12

192.168.20.120

Matrox
iSwitch

#3

192.168.19.120

Internet

public Network

LAN 3

Private Network

192.168.20.x

Matrox
iSwitch

#2

204.50.31.5

Client B

192.168.20.5

Figure 1 - Simple VPN Example

c. Matrox Networks 1998

TechNote #8 - VPN Page 4 of 4

What You Should Know

• Each tunnel can have a different encryption keys, encryption type and key length.

• The blowfish encryption algorithm will provide better throughput that the Proprietary

algorithm.

• The Matrox iSwitch at each tunnel endpoint should have a statically assigned IP

address to avoid reconfiguring the IP addresses in the VPN table.

• Each remote LAN segment must use a unique subnet. Select an IP Address for this

subnet from the non-routable (on the Internet) set specified in RFC 1918.

• To ensure that the VPN is not deprived of bandwidth non-mission critical applications

(WWW, FTP, E-Mail, …), configure a WAN access port to be dedicated exclusively
to VPN.

• The Random key generation feature is useful for creating a password but this

password must be sent to the peer endpoint on the other side of the tunnel (they must
be the same). While you can accomplish this through a telephone communication, we
suggest that you obtain a secure E-mail program. This allows for simple cut-and-paste
operations that are less error-prone than typing in keys manually. This process also
removes the possibility of eavesdroppers obtaining the key.

c. Matrox Networks 1998
