Matrox SOLIOSXCL, SOLIOSXA Compatibility List

Matrox Solios XA/XCL PC Compatibility List June 15, 2006 Page 1/3

Matrox Solios XA and XCL PC Compatibility List

This list identifies the platforms (systems, motherboards and industrial computers) certified by Matrox Imaging to be compatible with
the Matrox Solios XA and XCL frame grabber. Compatibility is defined as the general ability of the Matrox Solios XA/XCL to properly
function on the specified platform. It does not necessarily take into account interaction with other expansion peripherals. Therefore,
customers should perform testing based on their applications' specific needs. Compatibility is not limited to the platforms listed
below. Other platforms with similar characteristics may also be compatible. Please contact Matrox Imaging Technical Support for
details on compatibility with specific platforms. A shaded background indicates a recently added listing.

Click highlighted model numbers for detailed information.

Desktop systems

Manufacturer Model Processor Chipset Slot type(s) BIOS revision

Dell

2, 3

Optiplex GX280 Intel Pentium 4 Intel 915G 5V PCI / PCIe A03

Dell Precision Workstation 380 Intel Pentium 4 Intel 955X PCIe / 5V PCI A04

Dell

1, 3

Precision Workstation 470 Intel Xeon (Dual) Intel E7525 PCI-X / 5V PCI / PCIe A01

Dell

1, 2, 3, 7

Precision Workstation 670 Intel Xeon (Dual) Intel E7525 PCI-X / 5V PCI / PCIe A06

Motherboards

Manufacturer Model Processor Chipset Slot type(s) BIOS revision

Intel

2, 3, 8, 9

D915GEV Intel Pentium 4 Intel 915G 5V PCI / PCIe 0332

Intel

1, 2, 3

D925XCV Intel Pentium 4 Intel 925X 5V PCI / PCIe 0338

Matrox Solios XA/XCL PC Compatibility List June 15, 2006 Page 2/3

Matrox Solios XA and XCL PC Compatibility List

Motherboards (cont.)

Manufacturer Model Processor Chipset Slot type(s) BIOS revision

Intel SE7525GP2 Intel Xeon (Single) Intel E7525 PCIe / 5V PCI / PCI-X P10

SuperMicro Super P4SCT Intel Pentium 4 Intel 875P 5V PCI / PCI-X / AGP 8X 1.0C

SuperMicro Super X5DAE Intel Xeon (Dual) Intel E7505 PCI-X / AGP 8X / 5V PCI 1.0b

SuperMicro Super X6DAE-G Intel Xeon (Dual) Intel E7525 5V PCI / PCI-X / PCIe 1.3a

Super X6DHE-G2 Intel Xeon (Dual) Intel E7520 PCI-X

/ PCIe

1.3c

Industrial computers

Manufacturer Model Processor Chipset Backplane tested BIOS revision

Trenton NLT (6313) Intel Xeon (Dual) Intel E7520 A TTIGFL21 6-15-05

Backplanes

ID Manufacturer Model Slot type(s) PCI/PCIe/PCI-X bridge(s)

A Trenton BPX 3/8 (6377) x8 PCIe / PCI-X / 5V PCI (1) Intel 41210 (PCIe), (1) Intel 21154 (PCI)

SuperMicro

Matrox Solios XA/XCL PC Compatibility List June 15, 2006 Page 3/3

Matrox Solios XA and XCL PC Compatibility List

Canada and U.S.A.
Matrox Electronic Systems Ltd.
1055 St. Regis Blvd.
Dorval, Quebec H9P 2T4
Canada
Tel: [phone]
Fax: [phone]

For more information, please call: 1-800-804-6243 (toll free in North America) or [phone] or e-mail: [e-mail] or http://www.matrox.com/imaging

Notes (Contact Matrox Imaging Technical Support for details)

1. Compatible with Microsoft Windows 2000.

2. Compatible with Microsoft Windows XP Professional.

3. Tested in a single board configuration only.

4. Not compatible in all display modes (i.e., extended desktop/auxiliary)

5. Not compatible in all multi-board configurations.

6. Not compatible in all slots (e.g., obstruction, failure to grab).

7. PCI slot limitation with Matrox board. Matrox Imaging recommends to use available PCI-X or PCIe slot.
