INSTRUCTION MANUAL
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specifications are subject to change without notice.
Weatherproof IR Bullet Camera
600TV Lines
Super High Resolution Color Camera
- ii -
WARNINGS AND CAUTIONS:
CAUTION:
CAUTIONCAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
Do not install the unit in an extremely hot or humid place or in a place subject to excessive
dust, mechanical vibration.
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use strong solvents such as thinner or benzine as they might
damage the finish of the unit.
Retain the original carton and packing materials for safe transport of this unit in the future.
Installation -----------------------------------
Cleaning --------------------------------------
PRECAUTIONS
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
- iii -
- iv -
1
INTRODUCTION
The camera provides high-quality images using Sony CCD technology especially
applications.
designed for closed-circuit television (CCTV) and security surveillance
Features:
TM
High resolution and high performance 1/3" Sony Super HAD
Technology
Excellent picture quality
600 lines(Color) of resolution
0.1 lux(Color), 0.04 lux(B/W) @ F1.2 50IRE Sensitivity
Auto electronic shutter [1/60(1/50) ~ 1/100,000]
2D-DNR(Digital Noise Reduction)
Auto white balance modes
AGC (Auto Gain Control)
VIDEO OUT BNC
2.8~12mm D&N Auto Iris Lens
Operates in 12V DC ~ Max 15V DC
Use Certified / Listed Class 2 power source only
Camera Mount : Camera mount directly to the wall or ceiling
2
BASE INSTALLATION
Position camera for best field of view then tighten camera/mount
tension adjustment screws (x2)
3X20mm Tapping Screws Tension adjustment screw
Caution
"Adjusting the position of the camera after installation could
potentially damage the cable"
* Before mounting camera see lens adjustment instructions page 5
CAMERA CONNECTIONS
The A-CBVT2812JI camera can be used in video systems with either BNC or Modular
connections.
The cable attached to the camera has a BNC connection for video output and
a power connector for a 15V DC power source(not included).
For use in applications with modular connections, the BNC-to RJ11 Adaptor cable included
with the camera provides a connection between tne BNC and Power connection from the
camera to a RJ11 cable.
The A-CBVT2812JI camera comes with the following cables and accessories:
60ft(18M) cable with RJ11 connections on each end
BNC-to-RJ11 Adapter cable
Instruction Manual
Four 3 x 20mm Tapping screws
Sun shield
TO CONKIT
DC +15V IN
BNC FEMALE VIDEO OUT
1 2 3 4
CAMERA
* Diagram of typical modular wiring system connections
The A-CBVT2812PI camera can be used in video systems with BNC.
The cable on the camera has a BNC connection for video output and a power connector
for a 12V DC power source.
The A-CBVT2812PI Camera comes with the following accessories:
12VDC Adapter
Instruction Manual
Four 3 x 20mm Tapping screws
Sun shield
BNC FEMALE VIDEO OUT
VIDEO IN
DC +12V IN
DC 12V REGULATED
POWER SUPPLY
* Diagram of typical wiring connections
Field of view: Adjust setting from Tele (T) to Wide (W)
field of View.
Focus: Adjust lens focus from near (N) to infinity ( ).
LENS ADJUSTMENT
N
T
W
Adjust Focus
Adjust Angular Field View
DC AUTO IRIS LENS
Image Size 1/3" CCD
Focal Length
Aperture Ratio
Angular
Field of View
DIAGONAL
o
2.8mm : 127.5
o
12mm : 28.8
2.8 - 12.0mm
1 : 1.4
EXTERNAL DIMENSION
Weight - Unit:
Unit: m m
1.056 lb. (0.48 kg)
51
6
6
97
171
90°
To adjust the lens field of view and focus first remove the lens cover by unscrewing
the front of the housing.
After the adjustments are made replace the lens cover making sure it is fully seated.
For outdoor installations it is desirable to use the sun shield.
Power source
Power consumption
Image sensor
Total pixels
Scanning system
Scanning frequency
Sync. system
Resolution
Min. illumination
Video output
Power input
AGC
2:1 interlace
15.734KHz(H) x 59.94Hz(V)
Internal
600 TV lines (Color)
0.1 lux(COLOR), 0.04 lux(BW at IR ON) @ F1.2, 50 IRE
More than 50dB (AGC off)
Vari-Focal 2.8 ~ 12mm(True ICR)
795(H) x 595(V)
2-pin Terminal Block
(NTSC)
375mA(4.5 Watts) - IR LED ON
811(H) x 507(V)
MODEL
S/N ratio
White Balance
SPECIFICATIONS
Power
15.625KHz(H) x 50Hz(V)
Lens
Connector
&
etc.
(PAL)
Video output
Operating Temperature
1.0 Vp-p (75 ohm, composite)
BNC Connector
]
-10°C ~ +50°C [14°F ~ 122°F
General
Operating humidity
0 ~ 96% (non-condensing)
II
1/3" Sony Super HAD CCD
Day / Night
IR LED / SENSOR
LED Lighting Distance
IR LED 30EA(850nm / 40 degree) , CDS 1EA
25M
Auto Exposure
ON
AUTO (ATW)
DC 12V +/- 10%
Lens mount
Fixed mount
Gamma
0.45
AUTO
AUTO
2D-DNR
Smart IR
ON
ON
Ingress Protection
IP67
Function
Electronic shutter
1/60 ~ 1/100,000 sec.
1/50 ~ 1/100,000 sec.
PRINTED IN KOREA
50303022A
600TV Lines
Super High Resolution Color Camera
