Matrix MTX-HSPA-PH8-P+G User Manual

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 1 Preliminary. Subject to change without prior notice

MTX-HSPA-PH8-P+G

TERMINAL

User Manual

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 2 Preliminary. Subject to change without prior notice

General Notes

Product is deemed accepted by recipient and is provided without interface to recipient’s products. The documentation and/or product are provided for testing, evaluation, integration and information purposes. The documentation and/or product are provided on an “as is” basis only and may contain deficiencies or inadequacies. The documentation and/or product are provided without warranty of any kind, express or implied. To the maximum extent permitted by applicable law, Matrix Electronica further disclaims all warranties; including without limitation any implied warranties of merchantability, completeness, fitness for a particular purpose and noninfringement of third-party rights. The entire risk arising out of the use or performance of the product and documentation remains with recipient. This product is not intended for use in life support appliances, devices or systems where a malfunction of the product can reasonably be expected to result in personal injury. Applications incorporating the described product must be designed to be in accordance with the technical specifications provided in these guidelines. Failure to comply with any of the required procedures can result in malfunctions or serious discrepancies in results. Furthermore, all safety instructions regarding the use of mobile technical systems, including GSM products, which also apply to cellular phones, must be followed. Matrix Electronica or its suppliers shall, regardless of any legal theory upon which the claim is based, not be liable for any consequential, incidental, direct, indirect, punitive or other damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information or data, or other pecuniary loss) arising out the use of or inability to use the documentation and/or product, even if Matrix Electronica has been advised of the possibility of such damages. The foregoing limitations of liability shall not apply in case of mandatory liability, e.g. under the Spanish Product Liability Act, in case of intent, gross negligence, injury of life, body or health, or breach of a condition which goes to the root of the contract. However, claims for damages arising from a breach of a condition, which goes to the root of the contract, shall be limited to the foreseeable damage, which is intrinsic to the contract, unless caused by intent or gross negligence or based on liability for injury of life, body or health. The above provision does not imply a change on the burden of proof to the detriment of the recipient. Subject to change without notice at any time. The interpretation of this general note shall be governed and construed according to Spanish law without reference to any other substantive law.

Important information

This technical description contains important information for start up and use of the MTX-HSPA-PH8-P+G Terminal. Read it carefully before you start working with the MTX-HSPA-PH8-P+G Terminal. The warranty will be void should damage occur due to non-compliance with these instructions for use. We cannot accept any responsibility for consequential loss.

Service and Support

To contact customer support please use the contact details below:

Matrix Electronica Alejandro Sanchez, 109 28019 Madrid –Spain-

gsmsupport@matrix.es

Tel. +34915602737

Information about MTX-HSPA-PH8-P+G product and accessories is available on the following web site:

http://www.mtx-terminals.com

FTP server: (ask for user & password)

ftp://ftp.matrix.es/mtx-terminals/

Or contact your local distributor / sales agent:

REVISION INFORMATION

EDITION VERSION 1.0 First Release: April 2013

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 3 Preliminary. Subject to change without prior notice

1. INTRODUCTION ..................................................................................................................................................... 5



1.1 Description ............................................................................................................................... 5

1.2 Highlights ................................................................................................................................. 6

1.3 Main Features and Services ....................................................................................................... 7

1.3.2 Short Message Service .................................................................................................................................... 9

1.3.3 Voice Calls ..................................................................................................................................................... 9

1.3.4 Data ................................................................................................................................................................ 9

1.3.5 OPERATION MODES .................................................................................................................................... 9

1.3.6 Air Interface.................................................................................................................................................. 11

1.3.8 SIM Card ...................................................................................................................................................... 12

2. MECHANICAL DESCRIPTION .......................................................................................................................... 13

2.1 Overview ............................................................................................................................... 13

2.2. Dimensions ........................................................................................................................... 14

3. ELECTRICAL DESCRIPTION ............................................................................................................................ 15

3.1 Power Connector .................................................................................................................... 15

3.2 Audio Connector ..................................................................................................................... 16

3.3 Mini USB Connector ................................................................................................................ 18

3.4 Serial Interface ASC0 .............................................................................................................. 18

3.5 UMTS-GSM Antenna Connector ................................................................................................ 19

3.6. GPS antenna connector .......................................................................................................... 19

3.7. SIM card reader ..................................................................................................................... 20

3.8 Real Time Clock ...................................................................................................................... 21

3.9. Software Updates .................................................................................................................. 21

4. OPERATION ........................................................................................................................................................... 22

4.1 Switching On the Modem ......................................................................................................... 22

4.2 Switching Off the Modem ........................................................................................................ 22

4.3 Operating States/LED .............................................................................................................. 23

MTX-HSPA-PH8-P STATUS ..................................................................................................................................... 23

GSM CS DATA CALL IN PROGRESS OR ESTABLISHED ................................................................................ 23

- GSM VOICE CALL IN PROGRESS OR ESTABLISHED ................................................................................ 23

- UMTS VOICE CALL IN PROGRESS OR ESTABLISHED .............................................................................. 23

- UMTS CS DATA CALL IN PROGRESS ............................................................................................................. 23

PERMANENTLY ON ..................................................................................................................................................... 23

- GSM PS DATA TRANSFER .................................................................................................................................. 23

- UMTS DATA TRANSFER ....................................................................................................................................... 23

PERMANENTLY ON ..................................................................................................................................................... 23

UE REGISTERED TO A NETWORK. NO CALL, NO DATA .............................................................................. 23

TRANSFER .................................................................................................................................................................... 23

PERMANENTLY ON ..................................................................................................................................................... 23

LIMITED NETWORK SERVICE (E.G. BECAUSE NO SIM/ USIM, NO PIN OR DURING NETWORK

SEARCH) ...................................................................................................................................................................... 23



500 MS ON / ............................................................................................................................................................. 23

500 MS OFF ............................................................................................................................................................... 23

5. PH8 AT COMMAND INTERPRETER ................................................................................................................ 24

6 SAFETY AND PRODUCT CARE .......................................................................................................................... 25

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 4 Preliminary. Subject to change without prior notice

6.1. Safety instructions ................................................................................................................. 25



6.2. General precautions ............................................................................................................... 25

6.3. SIM card precautions ............................................................................................................. 25

6.4. Antenna precautions .............................................................................................................. 26

6.5. Radio Frequency (RF) exposure and SAR ................................................................................. 26

6.6. Personal Medical Devices ........................................................................................................ 26

7. INSTALLATION OF THE MODEM ................................................................................................................... 27

7.1 Where to install the modem ..................................................................................................... 27

7.1.1 Environmental conditions ............................................................................................................................. 27

7.1.2 Signal strength .............................................................................................................................................. 27

7.1.3 Connections of components to MTX-HSPA-PH8-P+G Terminal ................................................................. 27

7.1.4 Network and Subscription ............................................................................................................................ 27

7.2 How to install the modem ........................................................................................................ 27

7.2.1 Power supply ................................................................................................................................................ 27

7.2.2 Securing the modem ..................................................................................................................................... 28

7.3 Antenna ................................................................................................................................. 28

7.3.1 General ......................................................................................................................................................... 28

7.3.2 Antenna type ................................................................................................................................................. 28

7.3.3 Antenna placement ....................................................................................................................................... 28

7.3.4 The antenna cable ......................................................................................................................................... 28

7.3.5 Possible communications disturbances ........................................................................................................ 29

8. ACCESSORIES ....................................................................................................................................................... 29

9. CONFORMITY ASSESSMENT ............................................................................................................................ 30

10. ROHS STATEMENT ............................................................................................................................................ 31

11. DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT (WEEE MARK) ........................... 31

12. ABBREVIATIONS................................................................................................................................................ 32

13. AT COMMAND SUMMARY .............................................................................................................................. 33

14. SALES CONTACT ............................................................................................................................................... 37

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 5 Preliminary. Subject to change without prior notice

1. INTRODUCTION

1.1 Description

When your application needs to receive data up to 3.6 Mbps download or transmit up to 386Kbps, the MTX-HSPA-PH8-P+G terminal is the solution based on HSDPA technology.

The HSPA (High Speed Downlink Packet Access) is a transmission standard based on the UMTS network which allows a download speed of up to 3.6 Mbit/s. The technology therefore enables services like broadband internet, e-mail access, high-speed download of large data files and streaming of videos or music.

The MTX-HSPA-PH8-P+G is a complete terminal that encapsulates everything you need in one compact plug-and-play unit. The integration is almost not needed because it has its own SIM card reader and a USB port plus RS232 port which minimize the need for further hardware components.

The MTX-HSPA-PH8-P+G is controlled via AT commands and standard interfaces such as Serial RS232 & USB 2.0 full speed and RIL/NDIS driver.

When the UMTS-HSDPA network operation is not present, the MTX-HSPA-PH8-P+G can operate in EDGE class 10 max. 236.8 kpbs (DL), max. 118 kbps (UL) or in GPRS class 10: max. 85.6 kbps (DL), max. 42.8 kbps (UL)

The MTX-HSPA-PH8-P+G can also work in simple CSD data transmission (GSM data rate 14.4 kpbs, V.110, UMTS data rate 57.6 kpbs V.120) as well Short Messaging (SMS) and FAX specifications. It also has an analogue interface and is capable to make voice communication calls.

As a plus feature the MTX-HSPA-PH8-P+G adds a GPS receiver and NMEA protocol in the third multiplex channel (MUX GSM 07.10 protocol is needed).

The MTX-HSPA-PH8-P+G is manufactured with SMD Technologies with the ISO 9001 & IS0 14001 Quality certifications and it is RoHs / WEEE compliant.

A full list of antennas, cables, supplies and accessories are available.

The MTX-HSPA-PH8-P+G terminal is powered by an internal SIEMENS Wireless Module PH8.

Note!

Some of the functions described inside this Technical Description are only possible when the SIM-

Card is inserted.

ORDERING INFORMATION & VERSION

ORDERING CODE: 199.801.087

Firmware Version: 2.050 Module inside: PH8 RELEASE 2

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 6 Preliminary. Subject to change without prior notice

1.2 Highlights

General features:

• HDPA 14.4 Mbps

• Tri-Band UMTS/HSPA (WCDMA/FDD) 850/1900/2100 MHz

• Quad-Band GSM 850/900/1800/1900 MHz

• EDGE (E-GPRS) multi-slot class 10

• GPRS multi-slot class 10

• UMTS/HSDPA 3GPP release 5

• GSM 3GPP release 99

• Output power:

- Class 4 (2 W) for GSM900

- Class 3 (0.25 W) for UMTS/HSDPA

- Class E2 (0.5 W) for EDGE900

- Class E2 (0.4 W) for EDGE1800

- Class 1 (1 W) for GSM1800

• Control via AT commands (Hayes 3GPP TS 27.007 and 27.005)

• Power consumption:

- Power down 50 μA

- Average Supply Current < 970mA (HSDPA data transfer)

• Temperature range

- Normal Operation: -20°C to +65°C

- Restricted Operation: -30°C to +75°C

- Storage: -40°C to +85°C

• Dimensions. Excluding connectors: 78.1 x 66.8 x 37.2 mm

• Weight: < 190 g

• Supply voltage range: 6 ... 30 V

Specification for HSDPA data transmission:

• HSDPA: max. 3.6 Mbps (DL), max. 384 kbps (UL)

• UE CAT [1-6], 11, 12 supported

• Compressed mode according to 3GPP TS25.212

Specification for UMTS data transmission:

• UMTS: max. 384 kbps (DL), max. 384 kbps (UL)

Specification for EDGE data transmission:

• EDGE class 10: max. 236.8 kpbs (DL), max. 118 kbps (UL)

• Mobile station class B

• Modulation and coding scheme MCS 1-9

Specification for GPRS data transmission:

• GPRS class 10: max. 85.6 kbps (DL), max. 42.8 kbps (UL)

• Mobile station class B

• Full PBCCH support

• Coding schemes CS 1-4

Specification for CSD data transmission:

• GSM data rate 14.4 kpbs, V.110

• UMTS data rate 57.6 kpbs V.120

• RLP (Non-transparent mode)

Interfaces:

 FME M 50 Ohm GSM-UMTS antenna connector  SMA F GPS antenna connector  USB 2.0 full speed interface  RS232 9-wire modem interface serial port  Operating status LED bi-color  SIM card interface 3 V, 1.8 V  Plug-in power supply and on/off interfaces

 Handset audio interface

Specification for SMS:

• Point-to-point MO and MT

• SMS cell broadcast

• Text and PDU mode

Specification for voice:

 Audio speech codecs  GSM: AMR, EFR, FR, HR  3GPP: AMR  DTMF supported  6 audio modes: Approval, Router, Handset, Headset,

Speakerphone and Transparent mode

 TTY support selecting a dedicated audio mode  Gains and volumes can be controlled by AT commands  9 ringing melodies  CEPT and ANSI supervisory tones supported

Special features:

• Improved power-saving modes

• NDIS/USB driver for Microsoft® Windows® XP

• RIL/NDIS/USB driver for devices based on Microsoft® Windows Mobile™5.0 and its successor

• Firmware update via USB

GPS Features

 Protocol NMEA  Modes GPS, assisted GPS (AGPS)  Acquisition sensitivity: -143dBm 

Tracking sensitivity -156dBm

 Power supply for active antenna

Ordering information: MTX-HSPA-PH8-P+G: 199.801.087 firmware 02.050

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 7 Preliminary. Subject to change without prior notice

1.3 Main Features and Services

The MTX-HSPA-PH8-P+G perform a set of telecom services (TS) according to GSM standard phase 2+, ETSI and ITU-T. The services and functions of the MTX-HSPA-PH8-P+G are implemented by AT commands issued over the USB or ASC0 RS232 interface.

1.3.1 Types of Mobile Station The MTX-HSPA-PH8-P+G is a UMTS/HSDPA and

GSM/GPRS modem with characteristics below:

Feature Implementation

General

Frequency bands Five-Band UMTS/HDPA+ 800/850/9002/1900/2100MHz

Quad-Band GSM/GPRS/EDGE 850/900/1800/1900 MHz

GSM class Small MS

Output power (according to Release 99)

Class 4 (+33dBm ±2dB) for EGSM850 Class 4 (+33dBm ±2dB) for EGSM900 Class 1 (+30dBm ±2dB) for GSM1800 Class 1 (+30dBm ±2dB) for GSM1900 Class E2 (+27dBm ± 3dB) for GSM 850 8-PSK Class E2 (+27dBm ± 3dB) for GSM 900 8-PSK Class E2 (+26dBm +3 /-4dB) for GSM 1800 8-PSK Class E2 (+26dBm +3 /-4dB) for GSM 1900 8-PSK Class 3 (+24dBm +1/-3dB) for UMTS 2100, WCDMA FDD BdI Class 3 (+24dBm +1/-3dB) for UMTS 1900,WCDMA FDD BdII Class 3 (+24dBm +1/-3dB) for UMTS AWS, WCDMA FDD BdIV1 Class 3 (+24dBm +1/-3dB) for UMTS 900, WCDMA FDD BdVIII2 Class 3 (+24dBm +1/-3dB) for UMTS 850, WCDMA FDD BdV Class 3 (+24dBm +1/-3dB) for UMTS 800, WCDMA FDD BdVI

Power supply

6V < VCC < 32V

Physical Dimensions: 78.1 x 66.8 x 37.2 mm Weight: approx. 190g

RoHS All hardware components fully compliant with EU RoHS Directive

HSPA features

3GPP Release 6, 7 DL 14.4Mbps, UL 5.7Mbps

UE CAT. 1-12 supported Compressed mode (CM) supported according to 3GPP TS25.212

UMTS features

3GPP Release 4 PS data rate – 384 kbps DL / 384 kbps UL

CS data rate – 64 kbps DL / 64 kbps UL

GSM / GPRS / EGPRS features

Data transfer GPRS: • Multi-slot Class 12

• Full PBCCH support

• Mobile Station Class B

• Coding Scheme 1 – 4

EGPRS: • Multi-slot Class 12

• EDGE E2 power class for 8 PSK

• Downlink coding schemes – CS 1-4, MCS 1-9

• Uplink coding schemes – CS 1-4, MCS 1-9

• SRB loopback and test mode B

• 8-bit, 11-bit RACH

• PBCCH support

• 1 phase/2 phase access procedures

• Link adaptation and IR

• NACC, extended UL TBF

• Mobile Station Class B

CSD: • V.110, RLP, non-transparent

• 14.4kbps

• USSD

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 8 Preliminary. Subject to change without prior notice

Feature Implementation

SMS Point-to-point

MT and MO Cell broadcast Text and PDU mode

Audio Audio speech codecs

GSM: AMR, EFR, FR, HR 3GPP: AMR Speakerphone operation, echo cancellation, noise suppression, 9 ringing tones, TTY support

GNSS Protocol NMEA

Modes

Standalone GNSS Assisted GNSS

- Control plane - E911

- User plane - gpsOneXTRA™

General

Power saving modes Power supply for active GNSS antenna supported

Software

AT commands

Hayes, 3GPP TS 27.007 and 27.005, and proprietary Cinterion Wireless Modules commands

MicrosoftTM compatibility RIL / NDIS / USB drivers for Windows MobileTM

SIM Application Toolkit SAT Release 99

Firmware update Firmware update from host application over USB or ASC0.

Interfaces

USB Supports a USB 2.0 Full Speed (12Mbit/s) device interface.

Serial Port RS232 9 wire modem interface

Wakeup Control Signal pin to wake up an inactive USB Host into an active state.

Status LED to indicate network connectivity status.

Audio 1 analog interface handset

UICC interface Supported chip cards: SIM / UICC 3V, 1.8V

Antenna 50 Ohms. External antenna can be connected via FME M antenna connector

Module interface Mini USB-B connector

Power on/off, Reset

Power on/off Switch-on by hardware pin TURN_ON

Switch-off by hardware pin TURN_OFF Switch-off by AT command

Reset Orderly shutdown and reset by AT command Emergency off Emergency off by hardware pin TURN_OFF

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 9 Preliminary. Subject to change without prior notice

1.3.2 Short Message Service

The wireless modem supports the following SMS services:

• Sending; MO (mobile-originated) with both PDU (protocol data unit) and text mode supported.

• Receiving; MT (mobile-terminated) with both PDU and text mode supported.

• CBM (cell broadcast message); a service in which a message is sent to all subscribers located in one or more specific cells in the GSM network (for example, traffic reports).

• SMS status report according to 3GPP TS 23.40.

1.3.3 Voice Calls

The wireless modem offers the capability of MO (mobile originated) and MT (mobile terminated) voice calls as well as supporting emergency calls. Multi-party, call waiting and call divert features are available. Some of these features are network operator specific.

For the inter-connection of audio, the wireless modem offers balanced analogue input and output lines. The wireless modems support HR, FR, EFR and AMR vocoders.

1.3.4 Data

The wireless modem supports the following data protocols:

 HSPA+: 14.4 Mbps DL / 5.76 Mbps UL  UMTS 384 kbps DL / 384 kbps UL  GPRS (General Packet Radio Service)

The wireless modem is a Class B terminal, multi-slot class 10.

 EGPRS Multi-slot Class 10

 CSD (Circuit Switched Data) 9.6 kbps

1.3.5 OPERATION MODES

The table below briefly summarizes the various operating modes referred to in the following chapters.

Mode Function

Normal operation

GSM / GPRS / UMTS / HSPA SLEEP

Power saving set automatically when no call is in progress and the USB connection is suspended by host or there is no active communication present via ASC0.

GSM / GPRS / UMTS / HSPA IDLE

Power saving disabled (see [1]: AT^SCFG "MEopMode/ PwrSave", <PwrSaveMode>) or a USB connection not suspended, but no call in progress.

GSM TALK/ GSM DATA

Connection between two subscribers is in progress. Power consumption depends on the GSM network coverage and several connection settings (e.g. DTX off/on, FR/EFR/HR, hopping sequences and the antenna connection). The following applies when power is measured in TALK_GSM mode: DTX off, FR and no frequency hopping.

GPRS DATA GPRS data transfer in progress. Power consumption depends on network

settings (e.g. power control level), uplink / downlink data rates and GPRS configuration (e.g. used multi-slot settings).

EGPRS DATA EGPRS data transfer in progress. Power consumption depends on network

settings (e.g. power control level), uplink / downlink data rates and EGPRS configuration (e.g. used multi-slot settings).

UMTS TALK/ UMTS DATA

UMTS data transfer in progress. Power consumption depends on network settings (e.g. TPC Pattern) and data transfer rate

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 10 Preliminary. Subject to change without prior notice

HSPA DATA HSPA data transfer in progress. Power consumption depends on network

settings (e.g. TPC Pattern) and data transfer rate.

Power Down

The internal power section is shut down. The SW on the module is not active. The interfaces are not accessible.

Airplane Mode

Airplane mode shuts down the radio part of the module, causes the module to log off from the GSM/GPRS network and disables all AT commands whose execution requires a radio connection. Airplane mode can be controlled by AT command

Average power consumption

Parameter Description Conditions Min Typ Max Unit

IBATT+

OFF State supply current

POWER DOWN 50 μA

Average GSM / GPRS supply current1

SLEEP (USB Suspend) @DRX=9 2.92 mA

SLEEP (USB Suspend) @DRX=5 3.42 mA

SLEEP (USB Suspend) @DRX=2 5.62 mA

IDLE (USB active) @DRX=2 552 mA

Voice Call GSM900; PCL=5 350 mA

GPRS Data transfer GSM900; PCL=5; 1Tx/4Rx 375 mA

GPRS Data transfer GSM900; PCL=5; 2Tx/3Rx 540 mA

EDGE Data transfer GSM900; PCL=5; 1Tx/4Rx 315 mA

EDGE Data transfer GSM900; PCL=5; 2Tx/3Rx 410 mA

Voice Call GSM1800; PCL=0 315 mA

GPRS Data transfer GSM1800; PCL=0; 1Tx/4Rx 325 mA

GPRS Data transfer GSM1800; PCL=0; 2Tx/3Rx 430 mA

EDGE Data transfer GSM1800; PCL=0; 1Tx/4Rx 290 mA

EDGE Data transfer GSM1800; PCL=0; 2Tx/3Rx 355 mA

IBATT+

Peak current during GSM transmit burst

VOICE Call GSM900; PCL=5 1.81 2.93 A

VOICE Call GSM1800; PCL=0 1.51 2.13 A

Average WCDMA supply current

SLEEP (USB Suspend) @DRX=9 2.62 mA

SLEEP (USB Suspend) @DRX=8 3.02 mA

SLEEP (USB Suspend) @DRX=6 5.32 mA

Idle (USB active) @ DRX=6 452 mA

UMTS Data transfer Band I @+10dBm 390 mA

HSDPA Data transfer Band I @+10dBm 450 mA

UMTS Data transfer Band I @+23dBm 750 8203 mA

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 11 Preliminary. Subject to change without prior notice

HSDPA Data transfer Band I @+23dBm 775 mA

IVUSB

USB transceiver supply current (average)

USB suspend 0.5 mA

USB active 3 mA

1. With an impedance of ZLOAD=50Ohm at the antenna connector.

2. Without neighbouring cells; without t3212 timer occurrence.

3. Under total mismatch conditions at antenna connector.

1.3.6 Air Interface

Parameter Conditions Min. Typical Max. Unit HSDPA / UMTS

connectivity

Band I, II, V

UMTS Frequency range Uplink (UE to Node B)

UMTS 850 Band V 824

849 MHz

UMTS 1900 Band II 1850

1910 MHz

UMTS 2100 Band I 1920

1980 MHz

UMTS Frequency range Downlink (Node B to UE)

UMTS 850 Band V 869

894 MHz

UMTS 1900 Band II 1930

1990 MHz

UMTS 2100 Band I 2110

2170 MHz

Receiver Input Sensitivity @ ARP

UMTS 850 Band V

-109

dBm

UMTS 1900 Band II

-107

dBm

UMTS 2100 Band I

-108

dBm

RF Power@ ARP with 50Ohm Load

UMTS 850 Band V +21 +23 +25 dBm UMTS 1900 Band II +21 +23 +25 dBm

UMTS 2100 Band I +21 +23 +25 dBm GPRS coding schemes Class 10, CS1 to CS4 EGPRS Class 10, MCS1 to MCS9 GSM Class Small MS GSM Frequency range

Uplink (MS to BTS)

GSM 850 824

849 MHz

E-GSM 900 880

915 MHz

GSM 1800 1710

1785 MHz

GSM 1900 1850

1910 MHz

GSM Frequency range Downlink (BTS to MS)

GSM 850 869

894 MHz

E-GSM 900 925

960 MHz

GSM 1800 1805

1880 MHz

GSM 1900 1930

1990 MHz

Static Receiver input Sensi-tivity @ ARP

GSM 850 -102 -108

dBm

E-GSM 900 -102 -108

dBm

MTX-HSPA-PH8-P+G UMTS-HSPA terminal modem http://www.matrix.es

MTX-HSPA-PH8-P+G User Manual V.1.0 Pag. 12 Preliminary. Subject to change without prior notice

GSM 1800 -102 -107

dBm

GSM 1900 -102 -107

dBm E-GSM 900 31 32 35 dBm GSM 1800 28 29.25 32 dBm GSM 1900 28 29.25 32 dBm

Parameter Conditions Min. Typical Max. Unit

RF Power@ ARP with 50Ohm Load (GSM; 1 TX)

GSM 850 31 32 35 dBm

RF Power@ ARP with 50Ohm Load (GPRS; 1 TX)

GSM 850

dBm

E-GSM 900

dBm

GSM 1800

29.25

dBm

GSM 1900

29.25

dBm

RF Power@ ARP with 50Ohm Load (EGPRS; 1 TX)

GSM 850

dBm

E-GSM 900

dBm

GSM 1800

dBm

GSM 1900

dBm

RF Power@ ARP with 50Ohm Load (GPRS; 2 TX)

GSM 850

30.50

dBm

E-GSM 900

30.50

dBm

GSM 1800

27.75

dBm

GSM 1800

27.75

dBm

RF Power@ ARP with 50Ohm Load (EGPRS; 2 TX)

GSM 850

dBm

E-GSM 900

dBm

GSM 1800

dBm

GSM 1900

dBm

1.3.8 SIM Card

The MTX-HSPA-PH8-P+G supports an external SIM card through the integrated SIM holder. Both 3V and

1.8V SIM technology is supported. Older, 5V SIM technology is not supported.

+ 25 hidden pages

Matrix MTX-HSPA-PH8-P+G User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
