1-SERIES

E1x Elliptical

E1x_081201.indd 1 12/1/08 9:18:13 AM

E1x_081201.indd 2 12/1/08 9:18:13 AM

CHAPTER 1: IMPORTANT SAFETY INSTRUCTIONS PAGE #

1.1 Before Getting Started ....................................................................................................

1.2 Proper Usage .................................................................................................................

1.3 Read and Save These Instructions ...................................................................................

CHAPTER 2: SETUP

2.1 Getting Started ..............................................................................................................

2.2 Choosing a Location .......................................................................................................

2.3 Stabilizing the Elliptical Trainer ......................................................................................

2.4 Unpacking ....................................................................................................................

CHAPTER 3: SERIAL NUMBER LOCATION

3.1 E1x Elliptical ........................................................................................................................

CHAPTER 4: ELLIPTICAL PARTS & ASSEMBLY GUIDES

4.1 Fasteners and Assembly Tools ..................................................................................................

4.2 Exploded Diagram ..................................................................................................................

4.3 Assembly Steps .....................................................................................................................

CHAPTER 5: OVERLAY DESCRIPTION / ENGINEERING MODE

5.1 Console Display .......................................................................................................................

5.2 Workout Parameter Prompts .....................................................................................................

5.3 Workout Overviews ..................................................................................................................

5.4 Workout Tips ...........................................................................................................................

5.5 Workout Setup Steps ...............................................................................................................

5.6 Using Fitness Networking .........................................................................................................

CHAPTER 6: MANAGER’S CUSTOM MODE

6.1 List of Manager’s Custom Mode ................................................................................................

CHAPTER 7: MAINTENANCE

7.1 Daily Inspection ......................................................................................................................

7.2 Daily Maintenance ...................................................................................................................

7.3 Monthly Maintenance .............................................................................................................

7.4 Recycling the Battery .............................................................................................................

CHAPTER 8: Product Specifications

ABLE OFCONTENTS

02 02 02

03 03 03 03

05 06 07

10 11

12 14 14 17

20 20 20 20

E1x_081201.indd 1 12/1/08 9:18:13 AM

1.1 BEFORE GETTING STARTED

It is the sole responsibility of the purchaser of Matrix Fitness Systems products to instruct all individuals, whether they are the end user or supervising personnel, on proper usage of the equipment.

It is recommended that all users of Matrix Fitness Systems exercise equipment be informed of the following information prior to its use.

1.2 PROPER USAGE

Do not use the equipment in any way other than designed or intended by the manufacturer. It is imperative that all Matrix Fitness Systems equipment is used properly to avoid injury.

Keep hands and feet clear of moving parts at all times to avoid injury.

Unsupervised children must be kept away from this equipment.

Do not wear loose clothing while on equipment.

1.3 READ AND SAVE THESE INSTRUCTIONS

This Elliptical is intended for commercial use. To ensure your safety and protect the equipment, read all instructions before operating the MATRIX elliptical.

Do not use this product outdoors, near swimming pools or in areas of

high humidity.

Do not allow children or those unfamiliar with its operation on or near the

Matrix Total Body Elliptical Trainer. Do not leave children unsupervised

around the unit.

Never drop or insert objects into any opening. Keep hands away from

moving parts. If the item cannot be reached, contact the Matrix

authorized dealer for assistance.

Do not wear any clothing that might catch on any moving parts of the Total

Body Elliptical Trainer.

Do not turn pedals by hand, and do not use this product in bare feet.

Do not dismount the Total Body Elliptical Trainer until the pedals are at a

complete stop.

When mounting or dismounting the Matrix Total Body Elliptical Trainer, use

the stationary handlebar whenever additional stability is required. While

exercising, hold onto the moving arms.

Never use on the Matrix Total Body Elliptical Trainer while

facing backwards.

•

Keep the area around the Matrix Elliptical Trainer clear of any obstructions, including walls and furniture. Ensure that there are a few feet of clearance in front of the Total Body Elliptical Trainer.

Assemble and operate the Matrix Total Body Elliptical Trainer on a solid, level surface.

If you plan to move the unit, obtain help and use a hand truck. Do not grasp any plastic parts while lifting or moving the unit. The unit is too heavy and the plastic parts will break.

Never operate the unit if it is damaged, not working properly, when it has been dropped, or has been dropped in water.

Do not step on or set any object on the top of the pedal lever covers or the rear platform.

This unit is not equipped with a free wheel. Pedal speed should be reduced in a controlled manner.

CAUTION: If you experience chest pain, nausea, dizziness

or shortness of breath, STOP exercising immediately and consult a physician before continuing.

CAUTION: Any changes or modifications to this equipment

could void the product warranty.

•

CHAPTER 1: Important Safety Instructions

E1x_081201.indd 2 12/1/08 9:18:14 AM

CHAPTER 2: Setup

2.1 GETTING STARTED

Read the Owner’s Manual before setting up the Matrix Elliptical Trainer. Place the unit where it will be used before beginning the setup procedure.

2.2 CHOOSING A LOCATION

The site should be well-lit and well-ventilated. Place the E1x on a structurally solid and flat surface a few feet from the wall or any equipment. If the site has a heavy plush carpet, to protect the carpeting and machinery, you should place a rigid plastic base under the unit.

Please do not place the Total Body Elliptical Trainer in an area of high humidity, such as the vicinity of a steam room, indoor pool, or sauna. Exposure to intensive water vapour or chlorine could adversely affect the electronics, as well as other parts of the machine. To make exercise a desirable daily activity for you, the Total Body Elliptical Trainer should be in an attractive setting.

2.3 STABILIZING THE MATRIX ELLIPTICAL TRAINER

After placing the unit where it will be used, check its stability. If the Elliptical E1x is placed on a slightly, uneven surface, adjusting the adjustable levelers located underneath the base frame can help, but will not compensate for extremely uneven surfaces. To adjust, loosen the nut, and turn the leveler until the rocking motion ceases, and both levelers rest firmly on the floor. Retighten the nut.

2.4 UNPACKING THE TOTAL BODY ELLIPTICAL TRAINER

The Elliptical Trainer is carefully inspected before shipment so it should arrive in good operating condition. Matrix Fitness ships the unit in the following pieces:

Hardware Kit

(J)

(H)(G)

(A)

(F)

(I)

(C)

(E)

(B)

(D)

Main Frame Assembly Console Mast Console Mast Boot Dual-Action Handrails Pedal Arms

A) B) C) D) E)

Front Foot Handlebar Set Console Accessory Tray Hareware Kit

F) G) H) I) J)

E1x_081201.indd 3 12/1/08 9:18:16 AM

SERIAL # PLACEMENT

CHAPTER 3: Serial number location

3.1 SERIAL NUMBER LOCATION

The serial number is located under the console mast boot.

E1x_081201.indd 4 12/1/08 9:18:17 AM

CHAPTER 4: Elliptical parts and assembly Guides

PARTS NO. DESCRIPTION

QUANTITY

Z10

Z03

Z04

Z07

Z05

Z06

Z07

Z18

Z01

Z02

Z22

Z24

Z25

Z08

Z14

Z20

Z19

Z17

Socket Buttonhead Screw (M8 X 1.25p X 20mm)

Socket Buttonhead Screw (M8 X 1.25p X 80mm)

Flat Washer (Ø8.2)

Nylon Nut (M8 X 1.25p)

Bushing

Buttonhead Bolt (M8 X 1.25p X 35mm)

Nylon Nut (M8 X 1.25p)

Buttonhead Screw (M6 X 1.0p X 20mm)

Buttonhead Screw (M8 X 1.25p X 16mm)

Spring Washer (Ø8.2)

Cross Head Screw (M5 X 0.8p X 25mm)

Spring Washer (Ø8.2)

Socket Head Screw (M8 X 1.25p X 25mm)

Link Arm Cap

#5 L-type Wrench (120L)

#6 T-type Wrench (167L)

Phillips Screwdriver

Wrench (#13)

SKETCH

FASTENERS & ASSEMBLY TOOLS

COLOR OF BAG

Yellow

Red

Black

Pink

4.1 FASTNERS & ASSEMBLY TOOLS

E1x_081201.indd 5 12/1/08 9:18:17 AM

4.2 EXPLODED DIAGRAM

CHAPTER 4: Elliptical parts and assembly Guides

Z10

N22

Z05

Z07

Z08

Z06

Z18

E1x_081201.indd 6 12/1/08 9:18:20 AM

CHAPTER 4: Elliptical parts and assembly Guides

4.3 ASSEMBLY STEPS

CONSOLE MAST

Thread the Console Mast through the Console Mast Boot. Feed the cable through the Console Mast. Tape the cable to the top of the Console Mast to secure it temporarily. Attach the Console Mast to the Base Frame using two screws (Z03), four washers (Z04) and two nylon nuts (Z07). Ask your assistant to hold the Console Mast while tighten screws. Fix the water-holder bracket to the console mast using 2 bolts and then use #5 L-type wrench to tighten the screws.

CONSOLE

Connect the cable inside the Console, and unscrew the screws attached the back of the Console. Attach the Console to the top of the Console Mast using the same screws attached the back of the Console.

Lift up the Main Body at the front end. Ask your assistant to insert the wooden or hard box underneath the Main Body while you lift up the Main Body. Fasten the Front Foot to the Main Body by using two screws (Z10).

Z10

Z07

Z04

Z03

Z04

N22

Water-holder Bracket

STEP 1

Z07

Z04

Z03

Z04

N22

Water-holder Bracket

STEP 2

E1x_081201.indd 7 12/1/08 9:18:24 AM

CHAPTER 4: Elliptical parts and assembly Guides

HR HANDGRIPS

Plug in the heart rate wires to the wires from the Console Mast. Attach the heart rate handgrips to the Console Mast by using four screws (Z25) and washers (Z24).

ACCESSORY TRAY

Attach the Accessory Tray to the positioned base of the accessory tray by using two screws (Z22).

Z22

Z25

Z24

Z18

Z06

Z08

Z05

Z07

Z08

STEP 3

4.3 ASSEMBLY STEPS

E1x_081201.indd 8 12/1/08 9:18:27 AM

CHAPTER 4: Elliptical parts and assembly Guides

Attach the Dual-Action handrail (R) and (L) to the Console Mast using screws (Z18), and place the Handlebar Caps around the Handlebars. Fasten the Link Arm (R) and (L) to the Pedal Arms using screws (Z01) and washers (Z02). Attach the Dual-Action handrails to the link arms using bolts (Z06), bushings (Z05), and nylon nuts (Z07). Align the cut-out inside the link arm caps (Z08) with the link arm mounting hole. Apply pressure to the cap until it snaps into place.

Z18

G24

Z06

Z08

Z05

Z07

Z08

Z01

Z02

Z01

Z02

Z05

Z07

Z08

Z06

Z05

STEP 4

4.3 ASSEMBLY STEPS

ASSEMBLY COMPLETE

Assembly is complete. Final assembly and optional entertainment shown.

E1x_081201.indd 9 12/1/08 9:18:32 AM

CHAPTER 5: Overlay description / enGineerinG mode

WORKOUT PROFILE WINDOW:

During a workout, this window displays shapes, made of triangle columns of lights, which represent the levels of intensity in a workout-in-progress. The height of the furthest column is proportional to the current level of the intensity. Information will cycle every 30 seconds.

INSTURCTION CENTER:

This window displays step-by-step instructions for setting up a workout.

INFORMATIONAL DISPLAY:

During a workout, three sets of numbers, including Speed, Time and Distance, display statistics about the progress of the workout.

PROGRAM PLUS™ KEYS

Press the key to select one of the workouts. The program key with a symbol of plus “+” represents additional workout options. Press this key repeatedly for similar workout options.

LEVEL ARROW KEYS

During a workout, pressing the UP or DOWN arrow can adjust intensity levels.

RIGHT / LEFT ARROW KEYS

A pair of RIGHT and LEFT arrows is located on the side of SELECT. Use arrows, when setting up a workout, to change workout parameters displayed on the LCD console, such as length of workout, weight, age, heart rate, and intensity level. In addition, the pair of RIGHT and LEFT arrows is corresponding to the arrows in the LCD display.

QUICK START

Press QUICK START to begin your workout immediately, without having to select a workout program.

RESET PAUSE: If you need to PAUSE your program during a workout, stop pedaling. It will PAUSE your program for 30 seconds. Pressing START will return you to your workout. NOTE: Pause time is only available for ellipticals equipped with the battery. RESET: If you need to RESET the console during your workout, you can do so by holding down the RESET button for three seconds, or until the

display resets.

5.1 CONSOLE DISPLAY

E1x_081201.indd 10 12/1/08 9:18:34 AM

5.2 WORKOUT PARAMETER PROMPTS

CHAPTER 5: Overlay description / enGineerinG mode

PROMPT DEFAULT MINIMUM MAXIMUM UNIT

TIME

LEVEL

WEIGHT

AGE

DISTANCE

CALORIES

WATTS

Heart Rate

GENDER

68 / 150

5 / 3

500

150

n/a

MALE

34 / 75

1 / 1

MALE

182 / 400

80 / 50

5000

350

200

FEMALE

minute

kg / lbs

years old

km / mile

cal.

watt

beat

This section lists the default value and value range of workout parameters appeared in the PROMPT AREA, located in the bottom of WORKOUT PROFILE WINDOW. Before an exercise session, each parameter prompt will appear here depending on different programs.

NOTE: The workout time is a “countdown” display according to the default time or the maximum time that a user inputs. When the workout time is

inputted as “0”, the time will count up from a zero to the maximum time.

E1x_081201.indd 11 12/1/08 9:18:34 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.3 WORKOUT OVERVIEWS

This chart lists the Matrix elliptical trainer’s pre-programmed workouts.

PROGRAM

NAME

GOAL+

TIME GOAL

DISTANCE GOAL

CALORIES GOAL

TARGET HR

WEIGHT LOSS

HEART RATE+

FIT TEST

Time Goal sets exercise duration as the workout goal. Once the objective is met, the workout automatically goes into a cool-down phase and ends afterward.

Distance Goal is designed to build endurance in a certain distance. Once the objective is met, the workout automatically goes into a cool-down phase, and ends afterward.

Calories Goal is designed to burn a certain number of selected calories. Once the objective is met, the workout automatically goes into a cool-down phase and ends afterward.

Target HR is a higher intensity workout for maintain- ing a heart rate to achieve maximum exercise results. The user must wear a heart rate chest strip, or keep hands on contact heart rate grips continuously. The program adjusts the intensity level, based on the actual heart rate, to maintain the rate at 80 percent of the theoretical maximum.

Wei ght Lo ss is a low- intens ity wo rkout for burning the body’s fat reserves. The user must wear a heart rate chest strip, or keep hands on contact heart rate grips continuously. The program adjusts the intensity level, based on the actual heart rate, to maintain the rate at 65 percent of the theoretical maximum.

Fit Test measures cardiovascular fitness and can be used to monitor improvements in your endurance.

PROGRAM

NAME

DEFAULT

TIME

PROMPT

INPUT

DESCRIPTION

QUICK START

WARM UP

COOL DOWN

MANUAL

HILL INTERVAL

RANDOM HILL

INTERVAL+

MULTI FX+

N/A

20 min

N/A

Time

Time, Weight

Level, Time, Weight

Time, Weight

Watts, Time, Weight

Level, Time, Weight

Quick Start is the fastest way to begin exercising and bypasses the setup prompts. After pressing the QUICK START key, a constant-level workout begins.

Warm-up is a low-intensity phase that brings the heart rate into the lower end of the target zone and increases respiration and blood flow to working muscles.

Cool-down is a low-intensity phase that allows the body to begin removing lactic acid, and other exercise by-products, which build up in muscles and contribute to soreness.

Manual is a constant intensity level unless it is manually changed.

Hill Interval is an efficient workout by alternating work intervals and recovery intervals.

Random Hill is an interval training workout that occurs in no regular pattern or progression.

CONSTANT WATTS

RANDOM

Constant Watts is designed to maintain your watts expenditure at a constant level by controlling pedaling resistance and prompting you to pedal at a specified RPM. Watts level may vary above and below your target watts level during this program.

Random is a workout of constantly changing intensity levels that occur in no regular pattern or progression.

E1x_081201.indd 12 12/1/08 9:18:35 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.3 WORKOUT OVERVIEWS

PROGRAM

NAME

DEFAULT

TIME

PROMPT

INPUT

DESCRIPTION

GOAL+

TIME GOAL

DISTANCE GOAL

CALORIES GOAL

TARGET HR

WEIGHT LOSS

HEART RATE+

FIT TEST

20 min

N/A

20 min

12 min

Time, Weight

Distance, Weight

Calories, Weight

Age, HR, Time, Weight

Gender, Age, Level, Weight

Time Goal sets exercise duration as the workout goal. Once the objective is met, the workout automatically goes into a cool-down phase and ends afterward.

Distance Goal is designed to build endurance in a certain distance. Once the objective is met, the workout automatically goes into a cool-down phase, and ends afterward.

Calories Goal is designed to burn a certain number of selected calories. Once the objective is met, the workout automatically goes into a cool-down phase and ends afterward.

Target HR is a higher intensity workout for maintaining a heart rate to achieve maximum exercise results. The user must wear a heart rate chest strip, or keep hands on contact heart rate grips continuously. The program adjusts the intensity level, based on the actual heart rate, to maintain the rate at 80 percent of the theoretical maximum.

Fit Test measures cardiovascular fitness and can be used to monitor improvements in your endurance.

E1x_081201.indd 13 12/1/08 9:18:35 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.4 WORKOUT TIPS

Matrix Fitness strongly recommends seeing your physician for a complete physical examination before beginning any ﬁtness program. Know your

physician-recommended heart rate target zone. If, at any time while exercising, you experiences faintness, dizziness, pain, or shortness of breathe, you must

stop immediately.

To mount the elliptical trainer, grasp the front stationary handlebars and place your feet on the pedals. When you are comfortably situated, begin pedaling.

To dismount the elliptical trainer, stop pedaling, grasp the front stationary handlebars and get off the unit.

It is highly recommended that you always incorporate the warm-up and cool-down period into your workout. Warm-up brings the heart rate into the lower

end of the target zone and increases respiration and blood ﬂow to working muscles. Cool-down takes time for a user’s heart rate to return to a resting state

after vigorous exercise and reduces the amount of lactic acid in muscle tissue.

5.5 WORKOUT SETUP STEPS

Different elliptical trainer workouts require different setup procedure. This section provides details for settling up any workout program.

Begin to pedal the elliptical trainer.

Use the PROGRAM PLUS™ KEYS to enter the program, or use RIGHT / LEFT ARROW keys to scroll to desired program. The program name is displayed in

the PROMPT AREA.

Use the RIGHT / LEFT ARROW keys to scroll to desired parameter values displayed in the PROMPT AREA.

Press the SELECT key to conﬁrm each selection. Follow the steps to set up each workout.

NOTE: The PROGRAM PLUS™ KEYS with a symbol of plus “+” have couple of similar workout options included. Press the key repeatedly to select the desired program. Or, press the program key once and use RIGHT / LEFT ARROW keys to scroll to the desired program.

QUICK START

Press the “QUICK START” key and the WORKOUT PROFILE WINDOW will display “3, 2, 1, GO!” The workout begins at the default intensity level, and the workout time counts up from “0” to the maximum workout time.

WARM UP

Press the “WARM-UP” key to enter the program.

“SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.

Press START to begin a warm-up.

COOL DOWN

Press the “COOL-DOWN” key to enter the program.

“SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.

Press START to begin a cool-down.

MANUAL

Press the “MANUAL” key to enter the program.

“SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.

“SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.

Press START to begin the workout.

E1x_081201.indd 14 12/1/08 9:18:36 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.5 WORKOUT SETUP STEPS

INTERVAL +

HILL INTERVAL

Repeatedly Press the “INTERVAL+” key to select “HILL INTERVAL”, and then press SELECT. “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

RANDOM HILL

Repeatedly Press the “INTERVAL+” key to select “RANDOM HILL”, and then press SELECT. “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

MULTI FX +

CONSTANT WATTS

Repeatedly Press the “MULTI FX+” key to select “CONSTANT WATTS”, and then press SELECT. “SELECT WATTS” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

RANDOM

Repeatedly Press the “MULTI FX+” key to select “RANDOM ”, and then press SELECT. “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

GOAL +

TIME GOAL

1) Repeatedly Press the “GOAL+” key to select “TIME GOAL”, and then press SELECT.

2) “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT.

3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.

4) Press START to begin the workout.

DISTANCE GOAL

1) Repeatedly Press the “GOAL+” key to select “DISTANCE GOAL”, and then press SELECT.

2) “SELECT DISTANCE” using the RIGHT / LEFT ARROW keys, and then press SELECT.

3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.

4) Press START to begin the workout.

CALORIES GOAL

1) Repeatedly Press the “GOAL+” key to select “CALORIES GOAL”, and then press SELECT.

2) “SELECT CALORIES” using the RIGHT / LEFT ARROW keys, and then press SELECT.

3) “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT.

4) Press START to begin the workout.

E1x_081201.indd 15 12/1/08 9:18:36 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.4 WORKOUT SETUP STEPS

HEART RATE +

TARGET HR / WEIGHT LOSS

Repeatedly Press the “HEART RATE+” key to select “TARGET HR” or “WEIGHT LOSS”, and then press SELECT “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT HR” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT TIME” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

FIT TEST

“SELECT GENDER” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT AGE” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT LEVEL” using the RIGHT / LEFT ARROW keys, and then press SELECT. “SELECT WEIGHT” using the RIGHT / LEFT ARROW keys, and then press SELECT. Press START to begin the workout.

The tables below list ﬁt test results:

Male

Rating

Age

Estimated VO2 Max (ml/kg/min) Per Age Category

Very Poor Poor Fair Good Excellent Superior

15 – 19

20 – 29

30 – 39

40 – 49

50 – 59

60 +

< 35.0

< 33.0

< 31.5

< 30.2

< 26.1

< 20.5

35.0 – 38.3

33.0 – 36.4

31.5 – 35.4

30.2 – 33.5

26.1 – 30.9

20.5 – 26.0

38.4 – 45.1

36.5 – 42.4

35.5 – 40.9

33.6 – 38.9

31.0 – 35.7

26.1 – 32.2

45.2 – 50.9

42.5 – 46.4

41.0 – 44.9

39.0 – 43.7

35.8 – 40.9

32.3 – 36.4

51.0 – 55.9

46.5 – 52.4

45.0 – 49.4

43.8 – 48.0

41.0 – 45.3

36.5 – 44.2

> 55.9

> 52.4

> 49.4

> 48.0

> 45.3

> 44.2

Female

Rating

Age

Estimated VO2 Max (ml/kg/min) Per Age Category

Very Poor Poor Fair Good Excellent Superior

15 – 19

20 – 29

30 – 39

40 – 49

50 – 59

60 +

<25.0

<23.6

<22.8

<21.0

<20.2

<17.5

25.0 – 30.9

23.6 – 28.9

22.8 – 26.9

21.0 – 24.4

20.2 – 22.7

17.5 – 20.1

31.0 – 34.9

29.0 – 32.9

27.0 – 31.4

24.5 – 28.9

22.8 – 26.9

20.2 – 24.4

35.0 – 38.9

33.0 – 36.9

31.5 – 35.6

29.0 – 32.8

27.0 – 31.4

24.5 - 30.2

39.0 - 41.9

37.0 - 41.0

35.7 - 40.0

32.9 - 36.9

31.5 - 35.7

30.3 - 31.4

>41.9

>41.0

>40.0

>36.9

>35.7

>31.4

FIT TEST’S RESULT FOR FEMALE

FIT TEST’S RESULT FOR MALE

E1x_081201.indd 16 12/1/08 9:18:36 AM

CHAPTER 5: Overlay description / enGineerinG mode

5.6 USING FITNESS NETWORK

The two RJ45 networking ports are equipped in Matrix Elliptical Trainer E1x. These ports allow the bike to be connected to a fitness entertainment system and/or a fitness network, such as FitLinxx®.

C-SAFE / CARDIO PORT

The ports are located on the back of the console. The C-SAFE port enables the bike to upload user workout statistics to a fitness network database. The CARDIO port is compatible to entertainment protocol such as Cardio Theater® or BroadcastVision™.

C-SAFE

CARDIO

C-SAFE

CARDIO

E1x_081201.indd 17 12/1/08 9:18:37 AM

CHAPTER 6: ManaGer’s Custom Mode

6.1 LIST OF MANAGER’S CUSTOM MODE

The Manager’s Custom Mode allow the club owner to customize the elliptical trainer for the club.

To enter the Manager’s Custom Mode, press and hold down the “LEVEL ARROW keys“ . Continue to hold down these two keys until the INSTRUCTION CENTER displays “MANAGER MENU”.

To scroll through the list of Manager’s Custom Mode, use the “LEFT / RIGHT ARROW keys”, or “LEVEL ARROW keys”. The INSTRUCTION CENTER will display, in turn, each of custom settings.

To select a custom mode, press the SELECT key to enter.

To change the value of the setting, use the “LEFT / RIGHT ARROW keys”, or “LEVEL ARROW keys”.z

To confirm and save the value of the setting, press the QUICK START key. “SETTING SAVED” will appear in the INSTRUCTION CENTER. To exit the setting without saving, press the RESET key within 5 seconds, or if there is no key pressed, the system will resume automatically.

LIST OF MANAGER’S CUSTOM MODES:

99 min

20 min

68kg /

150lbs

N/A

20 min

5 min

34kg /

75lbs

99 min minute

max. time

182kg /

400lbs

104,000

km /

65,000

mile

MAXIMUM TIME

DEFAULT TIME

DEFAULT LEVEL

MAXIMUM LEVEL

DEFAULT WEIGHT

DEFAULT AGE

ACCUMULATED DISTANCE

CUSTOM SETTING

DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION

Control the default program time.

Control the starting resistance level for all programs.

Control the default weight used in calorie calculations. Set to default unit change (kilograms or pounds). Displayed in native units.

Enable fitness club managers to set the program maximum workout duration limits during peak and non-peak hours of club traffic. Active variable displayed in the TIME display after change.

Enable to set maximum resistance level for all programs.

Control the default users age used in target heart rate calculations.

minute

n/a

20 1 20

n/a

30 10 99

age

kg/lbs

N/A

km / mile

Accumulated distance is not editable, but only for display. Displayed in native units (miles or kilometers). After the equipment reaches the maximum distance, it will reset to "0" automatically.

E1x_081201.indd 18 12/1/08 9:18:37 AM

CHAPTER 6: ManaGer’s Custom Mode

6.1 LIST OF MANAGER’S CUSTOM MODE

N/A

0 65,000 hrs N/Ahour

30 sec

30 sec 180 sec 1second

ACCUMULATED TIME

PAUSE TIME

Accumulated time is not editable, but only for display. After the machine reaches the maximum time, it will reset to "0" automatically.

This is the maximum time during which a workout can remain in pause mode. Restrictions exist for the machine not equipped with a battery.

P10

P11

P12

P13

P14

P15

EL N/A N/A N/A

MODEL

SOFTWARE VERSION

ERROR LOG

METS

LANGUAGE

CB - Upright Bike RB - Recumbent Bike EL – Elliptical Trainer ST - Stepper

Software version is not editable, but only for display.

If this option is "ON", the METs prompt becomes an individual display in PROMPT AREA. If "OFF", there will be an alternate prompt in RPM and METs at the lower-right corner of the WORKOUT PROFILE WINDOW.

The function would clear all custom settings had stored on the unit and all settings return to manufacturer default value. Holding the Left and Right Arrow keys simultaneously to clear all custom settings values.

N/A

English

N/A N/A N/A N/A

N/A

N/A N/A

N/A

UNITS

The measurement unit prompts for weight, distance, and speed.

English

English Metric N/A N/A

N/A

N/A N/A N/A N/A

OFF

ON OFF N/A N/A

RESET ALL

N/A

N/A N/A N/A N/A

The n ative l angua ge prom pt s in th e INSTRUCTION CENTER.

Error log is not editable, but only for display. Holding the Left and Right Arrow keys simultaneously to erase the error log.

CUSTOM SETTING

DEFAULT MINIMUM MAXIMUM UNIT STEP DESCRIPTION

E1x_081201.indd 19 12/1/08 9:18:38 AM

CHAPTER 7: Maintenance

MAINTENANCE

Matrix Elliptical Trainer E1x is built for commercial environment 12 hours a day and seven days a week. However, as a club manager or owner, you are responsible for cleaning and maintaining the unit’s integrity. If you fail to maintain the elliptical trainer as described below, it could affect or void the Matrix limited warranty.

NOTE: Safety of the equipment can be maintained only if the equipment is examined regularly for damage or wear. Keep the equipment out of use until defective parts are repaired or replaced. Pay special attention to parts that are subject to wear, such as display console, console mounting screws, handrails, link arms, pedal arms and pedals.

7.1 DAILY INSPECTION

Look and listen for loose fasteners, unusual noises, and any other indications that the equipment may be in need of service. If you notice any of these, obtain service.

7.2 DAILY MAINTENANCE

Matrix Fitness recommends the E1x be cleaned before and after each workout. The following daily maintenance tips will keep your unit operating at peak performance:

Use a damp, soft cloth with water or mild liquid detergent to clean all exposed surfaces. DO NOT use ammonia, chlorine, or acid-based cleaners. Keep the display console free of fingerprints and salt build-up caused by sweat. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation of the unit.

7.3 MONTHLY MAINTENANCE

Perform the following services each month, or as needed:

Check that the console, handrails, link arms, pedal arms and pedals are secure.

7.4 RECYCLING THE BATTERY

When the Matrix elliptical trainer is about to be discarded at the end of its useful life, the rechargeable battery must first be removed and recycled. If the elliptical trainer is being equipped with the battery. To access the battery, unscrew the cover on the back of the console. To remove the battery, disconnect the cable.

E1x_081201.indd 20 12/1/08 9:18:38 AM

CHAPTER 8: Product Specifications

*Product specifications are subject to change without notice.

CONSOLE

Display Screen

Display Readout

Programs

On-the-fly Program Change

Telemetric Receiver

Contact HR Sensors

Program Quick Keys

One-Touch Quick Start

Pause Time

Language Options

TECHNICAL DATA

Resistance Technology

Resistance Levels

Drive System

Stride Drive System

Stride Length

Dimensions (L×W×H)

Product Weight

Max User Weight

Power Requirement

SPECIAL FEATURES

Handlebar Design

Remote Operation Keys

Pedals

Integrated Reading Rack

Accessory Tray

ENTERTAINMENT SOLUTIONS

Matrix® LCD TV Mount

Networking Capabilities

Workout Profile Window – 7” blue backlit graphic LCD display

Instruction Center – 14-character red LED alphanumeric display

Informational Display – 3 numeric 7-segment display (3 sets)

Time, Distance, Calories, Speed, Level, Watts, METS, Heart Rate, Profile

Manual, Interval+(Hill Interval, Random Interval), Goal+(Time Goal, Distance Goal,

Calories Goal), Multi FX+(Constant Watts, Random), Heart Rate+(Target HR, Weight

Loss), Fit Test, Warm Up, Cool Down

Yes

30 seconds

English, Italian, German, Spanish, French, Dutch, Portuguese, Japanese

JID™ generator

Two stage belt-driven

Forward and reverse

48 cm / 19”

211 × 79 × 170 cm / 83” × 31” × 52”

168 kg / 370 lbs

182 kg / 400 lbs

Self-powered

Multi-position dual action arms

Yes, equipped in the dual action arms

Auto-positioning pedals with front safety fences

Yes

CSAFE-Ready, Finlinxx™ certified

E1x

E1x_081201.indd 21 12/1/08 9:18:39 AM

E1x_081201.indd 22 12/1/08 9:18:39 AM

M AT RIX F I T N ES S S YST E M S | 1 61 0 L A N D M ARK DR I VE CO T TA GE GR OVE W I 5 352 7 U SA

To l l Fre e

8 66 .69 3 .4 8 6 3

m a t r i x fi t n e s s . co m Fa x

6 08. 8 3 9. 8 6 87

PA RT # 0 0 0 0 0 902 4 0

REV. 1.0

E1x_081201.indd 23 12/1/08 9:18:39 AM

Matrix E1x User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
