Customizing xPC Target Drivers

• “Introduction” on page 1-2

• “Before You Start” on page 1-8

• “Creating a Custom Driver” on page 1-11

• “Debugging Notes” on page 1-16

1 Customizing xPC Target™ Drivers

Introduction

In this section...

“xPC Target Drivers” on page 1-2

“When to Write Your Own Drivers” on page 1-3

“Restrictions on Customizing xPC Target Drivers” on page 1-3

“Expected Background” on page 1-3

“Resources for Customizing xPC Target Drivers” on page 1-4

“What Makes Up an xPC Target Driver?” on page 1-6

xPC Target Drivers

The xPC Target™ software provides device drivers for a variety of third-party boards. xPC Target users access these drivers as Simulink the xPC Target library ( Target so ftw are does not supply a driver, you can write your own. This guide provides guidelines for writing custom xPC Target device d rivers.

blocks from

xpclib). If you have a board for which the xPC

1-2

The xPC Target driver library contains drivers that support third-party boards with many I/O capabilities and applications. This includes drivers for different types of I/O boards, including

g-to-digital

Analo Digital-to-analog Audio

ters

Coun Shared memory

There are also drivers that support particular protocols, including

232, RS-422, RS-485

RSGPIB CAN

UD ARINC 429 MIL-1553

Introduction

When to Write You

Consider writin

• No xPC Target dr

• You are unable

• You need to ext

• The MathWorks

board.

Restrictio

The xPC Targ drivers aim from a driv Target ker layers tha

The xPC Ta runs to th own driv

• You cann

er:

the manu depend

able will not be able to load the DLL.

execut

g your own device drivers for the xPC Target block library if:

iver exists for your I/O needs.

to use a bo ard that t he xPC Target software supports.

end t h e functionality of an existing xPC Target driver.

xPC Target te am will not write a device driver fo r your

ns on Customizing xPC Target Drivers

et software has its own kernel, and you will be writing device

ed at that kernel. An xPC Target driver is therefore different

er for another en vironment, such as Microsoft W indows. The xPC

nel is optimized and small, and does not have the operating system

t traditional kernels do.

rget software installs its own kernel on the target PC. This kernel

e exclusion of any other operating system. When writing your

ot use a driver DLL that accompanies the I/O board from

facturer. A manufacturer-supplied DLL will have external

encies that the xPC Target kernel cannot resolve. The xPC Target

rOwnDrivers

• Do not c

• If you

you no acces able

Expe

s guide assumes that you are already knowle dgeable about w riting device

Thi

vers. It describes the steps specific to writing device drivers for the xPC

dri

get environment. To write your own device drivers for the xPC Target

Tar

tem, you need the following background:

sys

reate your own driver DLL.

do not have access to the register programming information, neither r The MathWorks can write a device driver for the board. If you have

s to the source code of an existing driver for the board, you m ig ht be

to port it to the xPC Target kernel.

cted Background

1-3

1 Customizing xPC Target™ Drivers

• Good C programming skills

• Knowledge of how Simulink simulation works, for example, the type and

order of calls

• Knowledge of writing S-functions and compiling those functions a s C-MEX

functions. This includes a comprehensive knowledge of Simulink callback methods and the Simulink

• Basic knowledge of Real-Time Workshop

• Understanding of I/O hardware. Because of the real-time nature of the

xPC Target software, you must develop drivers with minimal latency. Most drivers access the I/O hardware at the lowest possible level (register programming). Therefore, you must understand how to control the board with register information.

• Knowledge of port and memory I/O access over various buses. You need

this information to access I/O hardware at the register level.

• Knowledge of PC hardware fundamentals and internals

SimStruct functions.

Resources for Customizing xPC Target Drivers

This section lists the resources that a re available to you from The MathWorks.

References

The following MathWorks documentation provides information that you can refer to when customizing xPC Target drivers:

See...

Simulink User’s Guide Overall description of the Simulink environment and how the

MATLAB®External Interfaces

1-4

For...

Simulink software performs simulations.

How to write MATLAB MEX-files.

Introduction

See...

For...

Developing S-Functions How to write MATLAB C-MEX S-functions (noninlined S-functions).

Note the following references in this guide:

• “S-Function Callback Methods — Alphabetical List” the Simulink

software invokes these methods when simulating a model with S-functions. Real-Time Workshop uses the same methods in generated real-time applications.

• “SimStruct Functions — Alphabetical List” Contains detailed

descriptions of the functions that access the fields of an S-function’s simulation data structure (

SimStruct). S-function callback

methods use these functions to store and retrieve information about an S-function.

Real-Time Workshop Target Language Compiler

Real-Ti User’s G

me Workshop

uide

How to write target language compiler (TLC) files to inline S-function drivers. This is an optional reference and depends on whether or not youchoosetoinlineyourdriver.

Overall description of Real-Time Workshop fundamentals, and guidelines on understanding I/O boards and low-level programming for drivers for those boards.

MathWorks Consulting

You can about

alternatively contact the MathWorks Consulting Services Group

the fee-based creation of a driver for your board.

Source Code

an examine the source code for existing xPC Target device drivers as a

You c

rence for your custom drivers. Refer to the following directory:

refe

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks

Note In this directory, you might notice that some drivers use outdated xPC Target driver functions. F or the current functions to use, see “xPC Target Exported Functions” on page 1-6.

1-5

1 Customizing xPC Target™ Drivers

xPC Target Exported Functions

The xPC Target software provides kernel functions that you can use when writing your device drivers. These functions enable you to input and output data, configure PCI devices, and specify time-out intervals. Use only the functions documented in this guide. The guidelines in this document are not applicable if you are using an xPC Target software version prior to xPC Target software version 3.2 (R2007a). See Chapter 11, “I/O Functions — Alphabetical List”, for a descriptio n of these functions.

Third-Party Directory

The xPC Target software provides the following directory to help you integrate your custom driver.

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\thirdpartydrivers

This directory provides template files that you copy and customize for your drivers. Place all files that support your drivers in this directory.

1-6

What Makes Up an xPC Target Driver?

An xPC Target device driver is an S-function with functions that access an I/O board.

Like any device driver, an xPC Target driver interfaces between the user and an I/O device. Unlike typical device drivers, xPC Target device drivers:

• Can have the following parts

- Driver code, that is C code written as an S-function using exported xPC

Target kernel functions (see “xPC Target Exported Functions” on page 1-6)

- Optional Simulink block interface (Simulink mask) that users use to

configure the device and access output

- Optional MATLAB code that you can w rite to perform o perations such as

cross-block checking or parameter value range checking. You reference this file through the Simulink mask.

• Can be included in a Simulink library

• Are configured like any other Simulink block

Block mask

Introduction

Underlying driver code (C-file)

Mask editor

Anatomy of an xPC Target™ Driver

Mask initialization (M-file)

1-7

1 Customizing xPC Target™ Drivers

Before You Start

In this section...

“Introduction” on page 1-8

“Driver Types” on page 1-9

“Bus Types and Register Access” on page 1-9

“Register Access” on page 1-10

“Inlining xPC Target Drivers” on page 1-10

Introduction

This topic assumes that you satisfy the requirements outlined earlier in “Expected Background” on page 1-3 and that you have reviewed the following sections to prepare:

• “References” on page 1-4

1-8

• “Source Code” on page 1-5

• “xPC Target Exported Functions” on page 1-6

• “Third-Party Directory” on page 1-6

It also assumes that you already have a board for which you want to write a driver. Before you start, use the following checklist to specify the driver you want to write:

• Determine the functions of your board that you want to access with your

driver.

• Determinethebustypefortheboard.

- PCI

- ISA

• Select the I/O access mapping type.

- I/O port mapped

- Memory address mapped

Before You Start

• Select polling versus interrupt.

• Specify the blocks for the drivers. Identify

- Input and output ports

- Mask parameters

- Work variables to be shared between driver start, output, and terminate

routines

• Determine your timing considerations.

• Decide whether you use Inlined functions.

If yes, see the Target Language Compiler documentation of the Real-Time Workshop.

Driver Types

• Standard I/O

• Communication

• DMA

• Interrupt-driven

Bus Types and Register Access

The xPC Target software supports the two standard PC bus types, ISA and PCI. The ISA bus is a 16-bit bus with an 8 MHz clock. Another form of ISA bus is the PC/104. The PCI bus is a 32-bit or 64-bit bus with a 33 MHz or 66 MHz clock. Another form of PCI bus is the PC/104+ (PC/104-Plus).

A driver performs I/O accesses through either I/O ports or memory addresses (memory mapped).

The xPC Target software accesses I/O port addresses for ISA and PCI buses as follows:

1-9

1 Customizing xPC Target™ Drivers

Bus Access

ISA Board switches or jumpers usually select I/O port address and any

PCI The BIOS determines the I/O port address during PCI PNP (Plug

The m e mory space for I/O boards is different for ISA and PCI boards.

memory-mapped region.

and Play) configurations.

Bus

ISA The xPC Target software only permits use of the memory address

PCI Upper memory address space, typically greater than 2 GB

Memory Space

between 0xA0000 and 0xFFFFF

A device board supports either I/O port or memory-mapped access to onboard registers. See the board manufacturer’s register programming documentation.

Inlining xPC Target Drivers

You can choose to inline or not inline xPC Target drivers. Note the distinction between Simulinkand Real-Time Workshop conditional compilation. Writing a device driver as an inlined S-function ensures that the driver can coexist with xPC Target device drivers.

Inlining drivers allows you to customize code generated from Real-Time Workshop. If you choose to create inlined drivers, yo u must use the Real-Time Workshop Target Language Compiler.

Note For convenience, you can create a noninlined version of the driver first, and create an inlined driver for the Target Language Compiler from the first driver.

1-10

Creating a Custom Driver

The following is a generic procedure for how to create a custom device driver. For additional notes on writing custom xPC Target drivers, see Chapter 6, “Custom xPC Target Driver Notes”. For a description of a tool that helps you create simple custom drivers, see Chapter 7, “Creating Custom Drivers Using the xPC Target Driver Authoring Tool”. A simple custom device driver is one which performs no DMA or interrupt handling.

Note You might need administrative or write privileges to add a custom device driver to the xPC Target system. Otherwise, see “Creating Custom Blocks” in the Simulink User’s Guide.Thistopicdescribeshowtoaddcustom blocks to a library.

1 Write your driver in C, using the approved I/O functions as appropriate

(see Chapter 9, “I/O Structures — Alphabetical List” and Chapter 11, “I/O Functions — Alphabetical List”). An example device driver for the analog inputs of the Diamond MM-32 board is available at

Creating a Custom Driver

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\ addiamondmm32.c

2 As you write your device driver, you will want to compil e and link the

driver, then test it. Compile and link the driver into a MEX-file. For example:

mex driver.c

This step creates the MEX-file executable, driver.mexw32.

Note A MEX-file is used for simulation on the host and to set data structure sizes during code generation. It is not used during target execution.

3 CreateafileofMATLABcodetosupplementthemainCdriverandsupport

the block mask. For an example of this file, see

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\ diamondmm32.m

1-11

1 Customizing xPC Target™ Drivers

4 Open the Simulink Library Browser a nd create a new library, for example,

your_company_namelib.mdl (see “Creating Block Libraries” in the

“Working with Block Libraries” in the chapter of Simulink User’s Guide). Use a unique library name to prevent conflicts with other libraries.

5 In the new library, create an S-function block. From the Simulink Library

Browser, drag an S-Function block to the new library.

6 Configure the S-Function block.

a In the new library, right-click the S-Function block and select

S-Function Parameters.

b In S-function nam e, enter the name, without extension, of the driver.

For example, step 1).

c In S-function param eters, enter the parameters you defined for the

driver. The parameter names you enter here must match the names you will later enter for the driver block mask (through the Parameters and Initialization panes of the Mask Editor dialog box). For example,

firstChan, numChans, range, sampleTime, baseDec.Step7

describes the block mask creation.

addiamondmm32. (This is the driver C-file you created in

1-12

d Leave the S-function modules parameter with the default value,

unless you need to separate your driv er C-file into multiple files. If that is the case, see “Specifying Additional Source Files for an S-Function” in the “Integrating External Code W ith Generated C and C++ Code” chapter of the Real-Time Workshop User’s Guide.

Creating a Custom Driver

7 Double-click the S-Function block and create a block mask (see Chapter 4,

“Masking Drivers”).

8 Save and close the S-Function block.

9 At the bottom of the S-Function block, enter a block name. For example,

MM-32.

10 Save and close the library.

11 To make your new library visible in the Simulink Library Browser, move

it to

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\thirdpartydrivers

12 Copy and paste sample_xpcblocks.m in

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\thirdpartydrivers

1-13

1 Customizing xPC Target™ Drivers

Rename this file your_company_namelib_xpcblocks. m and edit this file as follows:

• Set

• Set out.Name to a string, such as the library name.

This string will appear in the Simulink Library Brow ser.

out.Library to your new library.

out.Library = 'your_company_namelib';

out.Name = 'your_company_namelib Blockset';

• Ensure that

out.IsFlat = 0;

out.IsFlat is set to 0.

Note Ensure that you create a function that calls the out structure.

13 (Optional for PCI boards) To enable the getxpcpci function to account for

your new board, copy

sample_supported.m toauniquefilename. For

example:

your_company_namelib_supported.m

Edit your copy of the file. For each board for which you add a device driver:

a Copy one of the commented structures in the file.

b Remove the comment symbols (%).

c Starting with 1, change the ID number as necessary. Number the device

structures sequentially, starting with

d Replace the field entries with your equivalents.

A structure entry might look like:

boards(1).VendorID = '18f7'; boards(1).DeviceID = '0004'; boards(1).SubVendorID = '-1'; boards(1).SubDeviceID = '-1'; boards(1).DeviceName = '422/2-PCI-335';

1-14

Creating a Custom Driver

boards(1).VendorName = 'Commtech'; boards(1).DeviceType = 'Serial Ports';

e Save and close the file.

f To confirm your entries, type getxpcpci('all') in the MATLAB

Command Window.

14 Ensure that all you r driver files, including include f il es, are in the directory:

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\thirdpartydrivers

Ensure that these files have unique names to prevent conflicts.

15 To update the directories that you added, at the MATLAB Command

Window, type

rehash toolbox

When you are done, your library will appear in the Simulink Library Browser with

xPC Target: added to the beginning of the library name.

xPC Target: your_company_namelib Blockset

1-15

1 Customizing xPC Target™ Drivers

Debugging Notes

While developing your custom driver, you can use printf statements in your code. This displays output on the left-hand side of the target PC monitor. If your

printf statements scroll off the monitor, consider disabling the target

PC scope area to provide more display area for these statements:

1 At the MATLAB Command Window, type xpcexplr to start xPC Target

Explorer.

2 In xPC Target Explorer, navigate to target_P C_node >

Configuration > Appearance.

3 Clear the En

4 Recreate the target boot disk and reboot the target PC.

The scope area on the target PC monitor no longer appears.

5 Continue

able target scope check box.

with the device driver development.

1-16

PCI Drivers

• “PCI Bus Considerations” on page 2-2

• “Sample PCI Device Driver” on page 2-8

2 PCI Drivers

PCI Bus Considerations

In this section...

“Introduction” on page 2-2

“PCI Configuration Space API” on page 2-3

“Memory-Mapped Accesses” on page 2-6

“I/O Port Accesses” on page 2-6

Introduction

When writing xPC Target drivers for PCI devices, consider the memory access method. A PCI device can be either I/O port mapped or memory mapped.

• I/O port m apped — The BIOS assigns a port range.

• Memory mapped — The BIOS assigns a memory region, if your device

is memory mapped.

2-2

The PC BIOS automatically assigns a conflict-free set of resources to any PCI device found in the system at boot-up. You typically do not know where the board resides (base address) before driver initialization. However, you can obtain this information by que ryi ng the PCI configuration space at run time. The xPC Target software provides functions to accomplish this (see the “PCI Configuration Information” on page 10-2 functions).

To locate a PCI device, you need the following:

• Vendor and device ID

• Optionally, subsystem vendor and subsystem device ID

Note You need the subsystem vendor and subsystem device ID if the

vendor and device ID do not uniquely identify the board.

• Slot number or bus and slot number

PCI Bus Considerations

You can have the drivers locate PCI devices in one of the following ways:

• If the system has one board of any one type, you can use the driver

slot

option to search for the first board that matches a vendor and device ID. To initiate this search, set this option to

• If the system contains multiple boards of the same type, setting the

-1.

slot

option to -1 does not find the additional boards. In that case, specify the bus and slot numbers with the vendor and device IDs.

PCI Configuration Space API

Before you can access a PCI device, you need to access the configuration space to locate the board in the target PC memory. This section describes the proceduretodothis.

For PCI devices, the driver will need to access the PCI configuration space for the board. This space contains relevant board information such as the base address and acces s type (I/O port or memory mapped). The xPC Target software prov ides functions that allow the driver to access this space.

• Vendor and device ID — The driver searches all boards for the specified

vendor (manufacturer) and device ID. The PCI Steering Committee, an independent standards body, assigns a unique vendor ID ( PCI board vendor. Each vendor then assigns a unique ID to each PCI board type it supports.

uint16)toeach

Note Vendor and device IDs do not always uniquely identify a board. For example, all boards that use the PLX-9080 bus interface chip have a vendor ID of 10B5 (the vendor ID assigned to PLX Technology, Inc.). The device ID for the chip is 9080. In cases like this, to select a particular board that contains this chip, you must use a subvendor and subdevice ID in addition to the vendor and device IDs.

• Slot number or bus and slot number — The driver looks only for the board

that matches the specified vendor and device ID and slot number.

2-3

2 PCI Drivers

PCI Device Information

Use the xpcGetPCIDeviceInfo function to get information for a PCI device in your system. The syntax for this function is:

int xpcGetPCIDeviceInfo (uint16_T vendorId, uint16_T deviceId, uint16_T subVendorId, uint16_T subDeviceId, uint16_T bus, uint16_T slot, xpcPCIDevice *pciInfo);

This function returns the xpcPCIDevice structure filled according to the following:

If You Supply...

This Function....

All the parameters Looks for a device that matches all the parameters

and returns the

xpcPCIDevice structure for that

device. Use this form if you know that your system has multiple boards from the same vendor with the same ID and you want your user to specify the exact device.

XPC_NO_SUB for

the

subVendorId

or subDeviceId parameter

Does not consider the subvendor or subdevice ID when looking for a match for the specified device. It returns the

xpcPCIDevice structure for a device that matches

the other parameters. You can use this form if you do not plan to use the

subVendorId or subDeviceId

values.

XPC_NO_BUS_SLOT

for the slot for the device

Returns the first PCI device it finds that matches the remaining parameters. You can use this form if you know that your system has only one board with aparticularIDset.

Passing Slot Information from the Block Mask to Its Driver

xPC Target drivers use the following convention to fill in slot parameters and retrieve slot information. Choose the convention that will work best for you.

2-4

PCI Bus Considerations

Set...

To...

Set slot = -1 Assume bus = 0 and call the xpcGetPCIDeviceInfo

function to find the first instance of the board.

Set slot = S Assume bus = 0 and call the xpcGetPCIDeviceInfo

function to find the specified board. If the board matches the IDs, return the PCI information to the driver. Otherwise, return an error.

Set slot = [B, S]CheckbusB and slot S f o r the specified board . If the

board match es the IDs, return the PCI information to the driver. Otherwise, return an error.

Setting

slot = [0, S]isidenticaltosl ot = S.

The following example illustrates how to use the xpcGetPCID eviceInfo function to program the driver to accept slot number input or slot and bus number input from the driver block.

1 Call this function from the mdlStart callback function.

2 Pass the slot number or slot and bus number into the xpcG etPC IDeviceInfo

function using code like the following:

uint16_T vendorId, deviceId;

int32_T bus, slot, subvendor, subdevice;

xpcPCIDevice pciInfo;

/* S_PCI_SLOT_ARG is passed in fr om the mask */

/* Typically the slot arg is a scalar containing -1 if there is only one board of

this type in the target */

/* If there are multiple boards of this type the slot arg is a vector containing bus

and slot info */

/* This code snipped parses the slot arg into bus and slot */

if ( (int_T)(mxGetN(ssGetSFcnParam(S, S_PCI_SLOT_ARG))) == 1 ) {

bus = 0;

slot = (int32_T)(mxGetPr(ssGetSFcnParam(S, S_PCI_SLOT_ARG))[ 0]);

} else {

bus = (int32_T)(mxGetPr(ssGetSFcnParam(S, S_PCI_SLOT_ARG))[0]);

slot = (int32_T)(mxGetPr(ssGetSFcnParam(S, S_PCI_SLOT_ARG))[ 1]);

}

2-5

2 PCI Drivers

vendorId = (uint16_T)0x1234;

deviceId = (uint16_T)0x9876;

subvendor = (uint16_T)0x5678;

subdevice = (uint16_T)0x8765;

/* Set subvendor and subdevice to XPC_NO_SUB, XPC_NO_SUB if they are not necessary */

/* xpcGetPCIDeviceInfo() populates the pciInfo struct */

if ( xpcGetPCIDeviceInfo(vendorId, deviceId,

subvendor, subdevice,

bus, slot,

&pciInfo) ) {

sprintf(msg, "Board 0x%x not found at bus %d slot %d", deviceId, bus, slot);

ssSetErrorStatus(S, msg);

return;

}

For detailed information on the xpcPCIDevice structure, see xpcPCIDevice.

2-6

Memory-Mapped Accesses

A memory-mapped PCI board uses up to six memory regions to access board regions and memory. Each region might also have a different length. You must call the

xpcReserveMemoryRegion function for each PCI memory region

you want to access; use the returned virtual address to access the region. Failure to do this will result in a segmentation fault.

To access a memory mapped location, do the following:

1 Declareapointeroftheappropriatesizetothememory. Forexample:

volatile uint32 *csr; /* Control and status register */

Note that you will want to use the volatile keyword here; otherwise, the compiler might optim i ze away accesses to this location.

2 Set its value (address) to the physical address at which the register resides.

I/O Port Accesses

To access I/O ports, use the following functions:

PCI Bus Considerations

• xpcInpB, xpcInpW, xpcInpDW — I/O port input functions for byte, word,

anddoublewordaccesses

•

xpcOutpB, xpcOutpW, xpcOutpDW — I/O port output functions for byte,

word, and double word accesses

2-7

2 PCI Drivers

Sample PCI Device Driver

For example PCI device driver code, see

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\dikpc

i1800.c

This driver illustrates digital input driver code for the Keithley 1800 series PCI devices.

Note Remember to enter the C-file name (without the extension) as the S-function name for the S-Function block.

2-8

ISA and PC/104 Drivers

3 ISA and PC/104 Drivers

ISA and PC/104 Bus Considerations

In this section...

“Introduction” on page 3-2

“I/O Mapped” on page 3-2

“Memory Mapped” on page 3-3

Introduction

When writingxPC Target drivers for ISA and PC/104 devices, consider the memory access method. A PCI device can be either port mapped or memory mapped. Most ISA and PC/104 boards are port mapped. Those that are memory mapped typically need large register banks or are interfaced via dual-port memory.

Note ThexPC Target kernel does not support ISA and PC/104 PNP boards. This means that you can write xPC Target device drivers only for ISA and PC/104 boards for which you can set the base address manually. To manually set the base address, insert jumpers or move DIP switches on the board.

3-2

• Port mapped

The base port address on the board is set via jumpers or switches. You might need to reset the s e addresses if there are conflicts.

• Memory mapped

The I/O and memory on the board are set via jumpers or switches. You might need to reset the s e addresses if there are conflicts.

I/O Mapped

The base port address on the board is set via jumpers or switches. D riv ers cannot discover these addresses on their own; you must specify these addresses to the driver.

Memory Mapped

The I/O and memor cannot discover addresses to th

Reserved Space on the Target PC

The xPC Target memory-mapp addresses in

this range.

y on the board is set via jumpers or switches. D rivers

these addresses on their own; you must specify these

e driver.

kernel reserves space in the region (C0000 to DC000) for

ed I/O cards. You must set up ISA and PC/104 cards to use

ISA and PC/104 Bus Considerations

3-3

3 ISA and PC/104 Drivers

3-4

Masking Drivers

• “Creating Driver S ubsystem Masks” on page 4-2

• “Driver Mask Guidelines” on page 4-3

• “Cross-Block Checking” on page 4-5

• “When You Are Done” on page 4-6

• “Sample Driver Mask” on page 4-7

4 Masking Drivers

Creating Driver Subsystem M asks

This chapter describes guidelines for creating a Simulink block user interface (mask) for the S-Function block associated your driver. A mask defines the menu items that will be passed to the S-function. The mask can call a MATLABfiletodoparameterorrangevaluechecking. Youcanalsomodify the labels of a block to show port numbers or other information. After you create the C code for an xPC Target device driver:

1 Create an optional MATLAB file.

2 Create an S-Function block for the driver.

3 Create a mas

This is the basic Simulink mask, with parameters and descriptions as necessary. Whenyouaredone,youcanmakethedevicedriverandits mask available for users to add to their models.

k for the S-Function block.

4-2

Driver Mask Guidelines

This topic lists guidelines you should follow when creating a mask for your xPC Target driver. You should already know how to create masked blocks. See the “Working with Block Masks” chapter in Simulink User’s Guide for further information.

Users access the masked block to interact with the driver, w h ich in turn interacts with the device.

• Create an S-Function block for the driver.

• Decide on the set of parameters the user will need to provide to the driver.

You should have already programmed this into the driver C code itself.

• Select appropriate descriptive names for these parameters.

• For each parameter, decide if the parameter can accept a finite number of

possible input values. If ye s, consider using one of the following widgets:

- Check box — For yes/no or 1/0 inputs

Driver Mask Guidelines

- Drop-down list — For a finite list of choices

Yourmaskcanalsobedynamic,wherethe dialog changes according to user selections.

• Choose readable and appropriate variable names.

• As necessary and appropriate, configure the library block so that the block

mask modifies its label according to user input. For example, a check box might cause the dialog to change.

• Ensure that the title beneath the driver block terminates with a blank

space. This is because if a model contains more than one block of any given type, Simulink appends a num ber to the title under the block. Adding a blank space to the end of the label ensures readability.

• Name the block appropriately so that it indicates the purpose of the driver.

• If you w ant to link help information to the mask Help button, see “Defining

Mask Documentation” in the “Working with Block Masks” chapter of Simulink User’s Guide for details.

• From within the mask, you can call a custom file to perform a number of

operations, including the following:

4-3

4 Masking Drivers

- Range checking for all parameters. For example, if you expect input

values from values greater than 10.

1 to 10, do not allow users to enter negative values, or

- Cross-block checking (see “Cross-Block Checking” on page 4-5).

4-4

Cross-Block Checking

Cross-block checking determines if multiple blocks are trying to access the same hardware. You should include cross-block checking in your driver to prevent such conflicts. You can perform cross -block checking by calling

find_system from the block mask in a number of ways. Use the following

guidelines when performing cross-block checking:

Cross-Block Checking

• Therecommendedwayistocallthe

InitFcn callback function. There are two phases of MATLAB file execution

during an update system operation. If you call the from a block

InitFcn callback function, defined in the Block Parameters

find_system function from the block

find_system function

dialog of the block, no additional updates are triggered.

• Decide on the level of cross-block checking for your hardware. For example,

boards that use the 8255 chip for digital I/O need to check if two different blocks are requesting opposing directions (for example, input and output) for the same group of 8 bits. On this chip, there are three groups of 8 bits. You can configure each group for input or output. The associated xPC Target driver generates an error in

InitFcn if find_system detects that

two blocks are trying to use the same group of 8 bits for input and output. See

matlabroot\toolbox\rtw\targets\xpc\target\build\xpcblocks\mpci8255.m

which is called as mpci8255(1) for the Measurement Computing PCI-DAS 1200 digital input and output blocks. During an update diagram sequence, Simulink calls the

InitFcn callback function once for each block. Simulink

might call the initialization commands in the mask multiple times.

4-5

4 Masking Drivers

When You Are Done

After you write the driver S-function and create the S-Function block, optional block mask, and MATLAB file for it, be sure to:

• Check the text of each error message for spelling and appropriateness.

• (Optional) Use a coding standard indentation such as four or eight spaces

with no tabs.

• Copy your new blocks into a custom directory with a unique name.

To enable your new blocks to be viewable in the Simulink Library Browser, see “Creating a Custom D river” on page 1-11.

• Test the driver f or the following:

- Run the mex commandonthedrivertobuildthedriverforsimulation

- Verify the hardware I/O under as many conditions as possible.

and code generation.

4-6

Sample Driver Mask

The f ol lowing is the b lock mask for t he Diamond MM-32 Analog Input block.

Sample Driver Mask

If you were to create this mask as a new mask, you would:

1 Open the Mask Edito r for the block.

2 Select the Parameters tab and click the Add button on t he left three tim es.

Three blank lines appear in the Dialog parameters section. Fill them in as follows, starting with the first line:

• In the Prompt column, enter

Channel configuration

First channel number:

4-7

4 Masking Drivers

Number of channels:

Range

Sample time:

Base address (for examp le 0x300):

• In the Variable co lumn, enter the parameter names. Be sure that these

names match the S-function parameters field of the S-Function block.

configuration

firstChan

numChans

range

sampleTime

base

• In the Type column, select:

4-8

popup

edit

popup

edit

• In the Evaluate and Tunable columns, ensure that the first five check

boxes of Evaluate and all the check boxes for Tunable are selected.

Sample Driver Mask

3 Select the Initialization tab. The tab displays the dialog variables you

entered in the Parameters tab.

4 In the Initialization code section, type

phase = 2; [baseDec, maskDisplay, maskDescription] = maddiamondmm32(phase, configuration, firstChan, numChans, range, base); set_param(gcb, 'MaskDescription', maskDescription); set_param(gcb, 'MaskDisplay', maskDisplay);

where maddiamondmm32 references the maddiamondmm32.m file for the driver.

In this file, you should check the range values of the parameters. Checking the mask here will catch illegal values early in the build process.

4-9

4 Masking Drivers

This example returns a string to display on the block with the variable

port_label commands with which to label the input and output ports. The

number and content of the

vector

5 Select the Documentation tab. This tab contains three fields, Mask type,

that the user enters in the mask.

port_label commands depend on the channel

Mask description,andMask help.

In the Mask type field, enter the type of driv er. For example:

addiamondmm32

In the Mask description field, enter a description for the d river. For example:

MM-32 Diamond Analog Input

In the Mask help field, if you are providing any online documentation to associate with the Help button, you can call that online documentation from this field. See “Defining Mask Documentation” in the “Working with Block Masks” chapter of Simulink User’s G uide for details.

4-10

6 Click OK to save the mask.

After you create the block mask, you can define an

InitFcn callback for the

block. A model calls this callback at the start of model simulation.

1 Right-clicktheblockandselectBlock Properties from the drop-down list.

2 Select the Callback tab from the dialog. From the list, select InitFcn.

Enter MATLAB code in the edit box.

Oneconventionistousethesamefunctionthatisusedatmask initialization time (for example, argument that indicates that this is being called at

maddiamondmm32(1)

maddiamondmm32.m), but with a single

InitFcn time.

Sample Driver Mask

At InitFcn time, no variables in the mask exist yet. You cannot pass them into the using the

InitFcn. However, in the function, you can get the string values

get_param function. For example:

function [baseDec, maskDisplay, maskDescription] = ...

maddiamondmm32(phase, configuration, firstChan, numChans, range, base) %#ok

vendorName = 'Diamond';

deviceName = 'MM-32';

description = 'Analog Input';

maskType = 'addiamondmm32';

if phase ~= 2 % assume InitFcn unless phase 2

base = get_param( gcb, 'base' );

blocks = find_system(bdroot, 'FollowLinks', 'on', ...

'LookUnderMasks', 'all', 'MaskType', maskType, 'base', base);

if length(blocks) > 1

error('xPCTarget:DiamondMM32:Block',...

'Only one Diamond Systems MM-32 A /D block per ...

physical board allowed in a model - each block of ...

this type must have a distinct ISA address.');

end

return

end

4-11

4 Masking Drivers

4-12

Interrupt Support

• “xPC Target Interrupts” on page 5-2

• “Adding Interrupt Support” on page 5-7

• “Hook Function Prototypes — Alphabetical List” on page 5-15

5 Interrupt Support

xPC Target Interrupts

In this section...

“Introduction” on page 5-2

“Interrupt Process ing in the xPC Target Environment” on page 5-2

Introduction

If your device supports interrupts, you can use the procedures in this chapter to add your custom interrupt functions to the xPC Target framework.

Your users can use interrupts in xPC Target applications in one of the following ways:

• Use the interrupt with the xPC Target Async IRQ Source block to execute a

function-call subsystem when an interrupt occurs.

• Use the interrupt to run the model in place of the timer interrupt, available

through the model Configuration Parameters dialog box in the Real-Time

Workshop > xPC Target options pane.

5-2

Note Although users can use interrupts inoneoftwoways,youprogramfor these interrupts using the same procedure, as described in “Adding Interrupt Support” on page 5-7. However, before you start programming the interrupts, see “Interrupt Processing in the xPC Target Environment” on page 5-2 for a description of the flow of xPC Target interrupt processing.

Interrupt Processing in the xPC Target Environment

When a model executes, it executes in the following order:

1 Call all mdlStart routines in block execution order.

2 Call the Start function, if one exists.

ow background graphics and network tasks to run until an interrupt

3 All

curs.

xPC Target™ Interrupts

The following illustrates the flow of processing once a hardware interrupt occurs. This is background information to help you understand the context in which the interrupt functions run.

5-3

5 Interrupt Support

Interrupt occurs

Call PreHookFunction (if one exists)

For each device on this IRQ

Did PreHookFunction return a value of XPC_RUN_ISR?

Yes

Function call on interrupt?

Yes

Async IRQ source block only

(Call interrupt service function call subsystem; interrupt preemption disallowed)

Yes

Call PostHookFunction (if one exists)

Another device?

Send wakeup to model thread

5-4

Return from interrupt

Model thread executes after return from interrupt; new interrupts might preempt

xPC Target™ Interrupts

When a hardware interrupt occurs, the generated code uses the following steps for each device on this IRQ to determine which device generated the interrupt:

1 Call the PreHook function, if one exists. The return value determines the

action.

2 The generated code determines whether this device generated the interrupt.

• If the

PreHook function returns XPC_RUN_ISR, execution continues to

step 3.

• If the

PreHook function returns XPC_DROP_ISR, the generated code goes

to step 5.

3 The generated code determines whether the Async IRQ Source block has a

function-call subsystem connected.

• If so, the generated code calls the interrupt service function-call

subsystem. When the interrupt service function subsystem returns, the generatedcodegoestostep4onpage5-5.

• If this board is configured to run the model, and this board did interrupt,

send a wakeup call to the model thread. The model thread does not immediately execute. It waits until after all the boards that use this IRQ have been checked and the return from the interrupt has been executed.

4 Call the PostHook function, if one exists. If one does not e xist, the

generated code g oes to step 5.

5 The generated code checks whether a nother device using the same IRQ

exists in the system.

If so, execution returns to the beginning of step 1.

If no other device exists, generated code goes to step 6.

6 Returns from the interrupt.

The xPC Target kernel now runs the highest priority thread. The highest priority ready thread is the model if a wakeup call was sent to it.

5-5

5 Interrupt Support

Note The Allow preemption of function call subsystem check box has

no effect. Interrupts are never enabled when the function-call subsystem is executed.

5-6

Adding Interrupt Support

In this section...

“Introduction” on page 5-7

“Guidelines for Creating Interrupt Functions” on page 5-9

“Filling in the Driver board Structure” on page 5-10

Introduction

To add interrupt handling for a custom driver, you must create

• A descriptor file to connect a board type to the functions needed to start,

handle, and stop interrupts

• A C file to implement these functions

Include the following functions. See “Hook Function Prototypes — Alphabetical List” on page 5-15 for the prototype details.

Adding Interrupt Support

Functio

PreHook

PostHook

Descrip

Runs just before either a function-call subsystem or entire model is called. Program this function to acknowledge the interrupt and cause the board to stop issuing the interrupt signal.

Runs after return from function call on interrupt, and before model execution. It is typically not used.

tion

5-7

5 Interrupt Support

Function Description

Start

Runs as the last item when starting a model, just before the model runs. It is typically used to turn on interrupt generation. Program this function to enable interrupts on the board and start any action.

Stop

Runs at the beginning of a stop request, before any

mdlTerminate entries for any block in the model

runs. It is typically used to turn off interrupt generation. Program this function to disable interrupts from the board and stop any action. This is the first action called, when a target application stops executing.

Note You mu them on in t should ca

To add int

1 Create a

matlabroot\toolbox\rtw\targets\xpc\target\build\

xpcblocks\thirdpartydrivers

st use the

Start function. In this way, the stop and start functions

ncel each other.

errupts for your custom driver, use the following general steps:

hook file in the following directory:

Stop function to turn off interrupts if you have turned

5-8

Hook fi

matla

xpc68

2 Name the hook file something like:

3 As necessary, create the interrupt functions the PreHook, PostHook, Start,

and

les are C files (

broot\toolbox\rtw\targets\xpc\target\build\src 04hooks.c

your_company_name_board_hook.c

Stop functions and add them to the hook file. See “Guidelines for

.c). For example, look at files in

,suchas

Creating Interrupt Functions” on page 5-9 for information on how to create these functions.

Adding Interrupt Support

4 Copy the file sample_int.m toauniquefilenameinthefollowingdirectory:

matlabroot\toolbox\rtw\targets\xpc\target\build\

xpcblocks\thirdpartydrivers

For example:

your_company_name_int.m

The x PC Target software searches in this directory for file names that end with

_int.m and looks for board interrupt descriptions.

5 Open and edit the following file:

matlabroot\toolbox\rtw\targets\xpc\target\build\

xpcblocks\thirdpartydrivers\

your_company_name_int.m

Addtothisfileaboard structure for each xPC Target supported board for which interrupt functions have been written. See “Filling in the Driver

board Structure” on page 5-10 for a description of how to fill in a board

structure.

6 Save and close the file.

7 At the MATLAB Command Window, type:

rehash toolbox

8 Restart the MATLAB interface to update the Async IRQ Source block and

Configuration Parameters dialogs.

Guidelines for Creating Interrupt Functions

xPC Target interrupt functions have predefined purposes and typically follow a particular order. This section describes the guidelines on creating interrupt functions. See “Hook Function Prototypes — Alphabetical List” on page 5-15 for the prototypes for these functions.

To prepare for the creation of the hook file, examine the existing xPC Target hook files ( copy and modify one that is the same board type, PCI or ISA, as the board for which you are creating a custom driver. For example, an ISA board. Place your new file in

matlabroot\toolbox\rtw\targets\xpc\target\build\src) and

xpc6804hooks.c is for

5-9

5 Interrupt Support

matlabroot\toolbox\rtw\targets\xpc\target\build\

xpcblocks\thirdpartydrivers\

When modifying an existing hook f ile:

• Change the nam es of all of the functions to match those you have selected

for your board.

• Do not change the function signatures.

• Do not remove the

• The

PreHook and PostHook functions run with interrupts disabled. Do not

__cdecl string.

change the interrupt status in these functions.

When writing the interrupt functions, note the following:

• When an interrupt occurs, the kernel calls the

PreHook function.

Note This function is run with interrupts disabled. If this function cannot turn off the interrupt, an infinite loop will occur because the interrupt service routine (ISR) will continuously call the

PreHook function.

• Because the PostHook function has limited use, you most likely do not need

to define this function. Set this function to

• The generated code calls the

Start function during the startup phase of

model execution as the last action, after the model has called all

'NULL' if you do not need it.

mdlStart

routines.

This function is typically used to enable interrupts from the board. The target application is ready to accept interrupts a few microseconds after this function is called. Do not try to enable interrupts from the board

mdlStart function.

5-10

• When a target application stops executing, the generated code calls the

Stop function first. Disable interrupts from the board in this function.

Filling in the Driver board Structure

This section describes how to fill in a driver board structure, element by element.

Adding Interrupt Support

• Depending on the bus type of your board, select a board structure of an

existing board that has the same bus type. The information passed to the functions is slightly different for an ISA board or a PCI board. You will use this structure as a template for your own board entry. The following is a structure for an ISA or PC/104 device:

board.name = 'RTD_DM6804'; board.VendorId = -1; board.DeviceId = 1; board.SubVendorId = -1; board.SubDeviceId = -1; board.PreHookFunction = 'xpc6804'; board.PostHookFunction = 'NULL'; board.HookIncludeFile = 'xpc6804hooks'; board.StartFunction = 'xpc6804start'; board.StopFunction = 'xpc6804stop';

The following is a structure for a PCI device:

board.name = 'General Standards 24DSI12'; board.VendorId = hex2dec('10b5'); board.DeviceId = hex2dec('9080'); board.SubVendorId = hex2dec('10b5'); board.SubDeviceId = hex2dec('3100'); board.PreHookFunction = 'xpcgs24dsi12prehook'; board.PostHookFunction = 'NULL'; board.HookIncludeFile = 'xpcgs24dsi12hooks'; board.StartFunction = 'xpcgs24dsi12start'; board.StopFunction = 'xpcgs24dsi12stop';

• name — Enter an appropriate board name string. The xPC Target

software uses this string to populate the drop-down list for the I/O board generating the interrupt parameter in the following:

- Async IRQ Source block

- PCI slot (-1: autosearch) or ISA base address parameter in the

xPC Target Options section of the model Co n figuration Parameters dialog box

•

VendorId, DeviceId, SubVendorId, SubDeviceId — Enter the appropriate

ID strings. If you have a PCI board, the board manufacturer identifies

5-11

5 Interrupt Support

that board with either two or four ID values, depending on the specific hardware. When calling the hook functions, the xPC Target kernel obtains thePCIinformationfortheboardandpassesittothehookfunctions. Use these parameters to help identify the interrupting board.

- For VendorId and DeviceId, enter the IDs you get from the board

manufacturer.

- Many boards do not have SubVendorId and SubDeviceId values. In

these cases, i nsert the value from checking for them.

If you have an ISA bo ard, it does not have a vendor or device ID; instead, the generated code will insert the ISA base address in the first base address entry of the PCI structure. To indicate to the kernel that this is an ISA board, set

If you do not need hook functions:

VendorId to -1 and DeviceId to 1.

-1 to prevent The xPC Target software

- Set VendorId to -1 and DeviceId to -1.

- Set Fnc and PostHookFcn to 'NULL'.

5-12

- Set StartFunction and StopFunction to 'NULL'.

The Async IRQ Source b lo ck will s ti ll call the subsystem when an interrupt occurs.

The following table summarizes your options for this element:

VendorId DeviceId

+ID +ID

-1 +1

-1 -1

• Enter the names of the interrupt functions. See “Hook Function Prototypes

— Alphabetical List” on page 5-15 for the prototype details.

Usage

PCI board

ISA board

Special case: If the driver does not need hook functions. The driver can still use the Async IRQ Source block. As an example, see the source code for the serial communication driver.

- PreHookFunct ion

Prototype:

int __cdecl your_ company_name_boardPreHook(xpcPCIDevice *pciInfo);

- PostHookFunc tion

Prototype:

void __cdecl your_company_name_boardPostHook(xpcPCIDevice *pciInfo);

- StartFunctio n

Prototype:

void __cdecl your_company_name_boardStart(xpcPCIDevice *pciInfo);

- StopFunction

Prototype:

Adding Interrupt Support

void __cdecl your_company_name_boardStop(xpcPCIDevice *pciInfo);

If any of these four functions does not need to exist, set the corresponding

board structure entry to ' NULL' to prevent calls to that function in that

context.

Note The differences between hook functions for PCI and ISA devices are:

- PCI devices — A hook function for a PCI device has all fields of the

xpcPCIDevice structure filled in except the VirtAddress field. To get

the virtual address for a physical memory, in the the

xpcReserveMemoryRegion function and save the resulting virtual

address in the pointer to the same instance of this structure is passed to all four functions. This action makes data, such as virtual addresses, available to all functions.

VirtAddress field of the xpcPCIDevice structure. A

Start function, call

- ISA devices — A hook function for an ISA device has the base I/O

address entered in the first physical address. No other fields in the

xpcPCIDevice structure are filled in.

5-13

5 Interrupt Support

• HookIncludeFile — Interrupt handling file that contains the

PreHookFunction, PostHookFunction, StartFunction,andStopFunction

functions for this board. Specify this name without the .c extension.

• Specify this structure for each board for which interrupt functions have

been written. For example:

board(1).name = 'name1'; . . . board(2).name = 'name2';

5-14

Hook Function Prototypes — Alphabetical List

• your_company_name_boardPostHook

• your_company_name_boardPreHook

• your_company_name_boardStart

• your_company_name_boardStop

5-15

your_company_name_boardPostHook

Purpose Run after return from interrupt service routine function-call subsystem

or after sending wakeup call to model thread

Syntax void __cdecl your_company_name_boardPostHook(xpcPCIDevice

*pciInfo);

Argument

pciInfo

Pointer to the PciDevice structure.

Description your_company_name_boardPostHook is not typically required. If you

do not need this function, set it to

matlabroot\toolbox\rtw\targets\xpc\target\build\

xpcblocks\thirdpartydrivers\

'NULL' in

your_company_name_int.m

See Also xpcPCIDevice

5-16

your_company_name_boardPreHook

Purpose Run just before the interrupt service routine

Syntax int __cdecl your_company_name_boardPreHook(xpcPCIDevice

*pciInfo);

Argument

pciInfo

Pointer to the PciDevice structure.

Description your_company_name_boardPreHook runs just before the model-level

interrupt service routine (either a function-call subsystem or entire model) is called.

Return This function must check the status register on the b oard to determine

if the board caused the interrupt. It returns one of the following:

•

XPC_RUN_ISR — If the function determines that the board did cause

the interrupt, the function must perform the required operation to stop the board from generating the interrupt. The function then returns this value.

•

XPC_DROP_ISR — If the function determines that the board did not

cause the interrupt, this function returns this value.

See Also xpcPCIDevice

5-17

your_company_name_boardStart

Purpose Run as the last item in mdlStart

Syntax void __cdecl your_company_name_boardStart(xpcPCIDevice

*pciInfo);

Argument

pciInfo

Pointer to the PciDevice structure.

Description your_company_name_boardStart runs as the last item a fter all

mdlStart functions. It is typically used to turn on interrupt generation.

See Also xpcPCIDevice

5-18

your_company_name_boardStop

Purpose Run at the beginning of mdlTerminate

Syntax void __cdecl your_company_name_boardStop(xpcPCIDevice

*pciInfo);

Argument

pciInfo

Pointer to the PciDevice structure.

Description your_company_name_boardStop runs before the mdlTerminate function

of the blocks i n the model. It is typically used to turn off interrupt generation.

See Also xpcPCIDevice

5-19

your_company_name_boardStop

5-20

Custom xPC Target Driver Notes

• “S-Function Guidelines” on page 6-2

• “mdlStart and mdlTerminate Considerations” on page 6-4

• “DMA Considerations” on page 6-5

• “Passing Parameters” on page 6-6

• “Accessing Registers” on page 6-7

6 Custom xPC Target™ Driver Notes

S-Function Guidelines

You implement xPC Target device driver blocks using Simulink S-functions. An S-function is a set of subroutines that implements a function. On the host, youcanwriteanS-functioninMATLABcode,C,orFortran. ForxPCTarget device drivers, you must write an S-function in C.

Simulink S-functions have a number of callback methods. For xPC Target drivers, you typically need to write C code for the following callback methods:

Method

mdlInitializeSizes

mdlInitializeSampleTimes

mdlStart

mdlOutputs

mdlTerminate

After you create the S-function, createamaskforit.SeeChapter4,“Masking Drivers”. Also, refer to the Simulink documentation (in particular, Developing S-Functions).

Of particular note when writing S-functions:

• Keep track of the input parameters the driver will require. When you

create a mask for the driver, you will need to know this.

• Work vectors are not shared between runs. All S-function work variables

are cleared after calling S-function calls

• Declare all memory-mapped registers as

Description

Initializes the S-function with the number of inputs, outputs, states, parameters, and other characteristics.

Initializes the sample rates of the S-function.

Initializes the state vectors of this S-function. It also initializes hardware as necessary.

Computes the signals that this block emits.

Performs any actions required at termination of the simulation.

mdlTerminate. This implies that each time the

mdlStart, you must reinitialize all work variables.

volatile.

6-2

• An S-function is compiled into a M EX-file to run as part of the simulated

model on the host PC. During code generation, the S-function calls the

mdlInitializeSizes and mdlInitializeSampleTimes functions to

determine the data structures that are used on the target. The same C-file

S-Function Guidelines

is also compiled with your application to run on the target PC. Because of the following reasons, you must conditionally compile code for the host PC and the target PC.

- The host PC runs Windows and the target PC runs the xPC Target

kernel.

- The host PC does not have the same I/O hardware as the target PC.

The preprocessor symbol for simulation (via Target environment. Use this s ymbol to conditionally compile host PC or target PC specific code. For example:

#ifdef MATLAB_MEX_FILE /* host/simulation */

/* simulation code, typic ally nothing */

#else /* target */

/* code to access I/O board */

# endif

IfyouwantthecodetorunonboththehostandtargetPCs,donot conditionalize the code.

• Include the

This provides definitions for the functions exported by the xPC Target kernel. The xPC Target kernel exports a number of functions for use in device drivers.

See “mdlStart and mdlTerminate Consi de rations” on page 6-4 for notes on specific applications of the callback methods.

xpctarget.h file in your S-function.

MATLAB_MEX_FILE is defin e d when you compile

mex). Undefine this symbol when compiling for the xPC

6-3

6 Custom xPC Target™ Driver Notes

mdlStart and mdlTerminate Considerations

When you load a target application onto a target PC, the driver executes the

mdlStart callback m ethod. If the execution is successful, the driver then

executes

mdlStart does not successfully complete, the application does not execute

mdlTerminate.(Typically,mdlStart might not successfully complete if

the application cannot find a referenced I/O board or if the board does not successfully initialize.)

mdlTerminate.

When the target application does start, it executes repeatedly executes the application calls the

With the above considerations, write they cancel each other out. Ensure that resources that you allocated in to high in

mdlStart, reset it to the default level in mdlTerminate.(Failure

mdlOutputs. At the end of target application execution,

mdlTerminate function.

mdlStart and mdlTerminate so that

mdlTerminate deallocates any

mdlStart. For example, if you set an output

mdlStart again, then

to reset the output causes a high output before the application starts.) As another example, if, in the mdlStart function, you allocate memory, have mdlTerminate free the memory.

Although this description distinguishes between the driver initia l iza tio n and application start phases, you do not nee d to actually differentiate betw een them. If you do need to do so, use the returns

1 while the model is initializing, and 0 otherwise.

xpcIsModelInit function. This function

6-4

DMA Considerations

If your board directly accesses system RAM, such as a DMA controller, you must allocate that memory using the This function allocates the buffer such that the buffer v irtual address is the same as its physical address.

DMA Considerations

xpcAllocPhysicalMemory function.

6-5

6 Custom xPC Target™ Driver Notes

Passing Parameters

See “Passing Parameters to S-Functions” in Developing S-Functions.

6-6

Accessing Registers

In this section...

“I/O Space” on page 6-7

“Memory-Mapped Space” on page 6-7

I/O Space

For registers in I/O space, use the xPC Target I/O read and write functions:

• Read functions

uint32_T xpcInpDW(uint16_T port ); // read a 32 bit word uint16_T xpcInpW(uint16_T port ); // read a 16 bit word uint8_T xpcInpB(uint16_T port ); // read an 8 bit byte

Accessing Registers

• Write fun

void xpc

ctions

OutpDW(uint16_T port, uint32_T value ); // write 32 bits

OutpW(uint16_T port, uint16_T value ); // write 16 bits

OutpB(uint8_T port, uint8_T value ); // write a byte

TheportaddressisthevaluereturnedintheBaseAddress array.

Memory-Mapped Space

For registers in memory-mapped space, access them by dereferencing through a pointer that contains the virtual address returned by the

xpcReserveMemoryRegion function. Because modern compilers have

aggressive optimizers, you must declare the pointer to be volatile. Doing so ensures that the compiler does not optimize out reads and writes using that pointer. The following pseudocode illustrates this using two methods: structure and array.

6-7

6 Custom xPC Target™ Driver Notes

• Structure

struct bdregs {

};

If your hardware uses registers with different lengths, it might be easier to use the structure method.

• Array

#define REG1 0 #define REG2 1 etc.

volatile int reg1; volatile int reg2; etc.

struct bdregs *regs = pciInfo.Virtua lAddress[1];

regs->reg1 = 0x1234; // Sets reg1 to that value regs->reg2 = 0x56789abc; etc.

6-8

volatile int *aregs = pciInfo.Virtua lAddress[1];

aregs[REG1] = 0x1234; aregs[REG2] = 0x56789abc;

Creating Custom Drivers Using the xPC Target Driver Authoring Tool

• “xPC Target Driver Authoring Tool” on page 7-2

• “Generating Custom Driver Templates” on page 7-4

7 Creating Custom Drivers Using the xPC Target™ Drive r Authoring Tool

xPC Target Driver Authoring Tool

xPC Target Driver Authoring Tool helps you create templates for simple custom device drivers. A simple custom device driver is one that does not perform DMA or interrupt processing. The xPC Target Driver Authoring Tool is not useful for these more complicated applications.

Based on the inputs you provide to xPC Target Driver Authoring Tool, it can create a number of files, including the following. Of these files, you need to edit only the source C code file. You can also optionally edit the block mask file.

File

driver_name.c

driver_name.h

sfcn_driver_name.c

sfcn_dr

driv

sfcn_driver_name.mexw32

iver_name.tlc

er_block_name.mdl

Description

Template for the source C code for driver. You need to enter your C code.

Header file for driver.

S-function file for driver. This file contains S-function callback methods and options for the driver.

Optiona generat only if See “In 1-10 for f Drive wheth

Optio Afte crea bloc Simu fil box

Optional. If you requested the creation of a C MEX file, the tool generates one for you.

l. Real-Time Workshop TLC code

ion file. You typically need a

youwanttoinlineyourcustomdriver.

lining xPC Target Drivers” on page

urther information. The xPC Target

r Authoring Tool creates this file for you

er or not you want to inline the driver.

nal. Blockmaskmodelfilefordriver. r the xPC Target D river Authoring Tool tes the supporting files, it creates the

kmaskforthedriveranddisplaysitinthe

link model window. The tool creates this

eonlyifyouselecttheMEX C file check

.tlc file

7-2

xPC Target™ Driver Authoring Tool

Note The xPC Target Driver Autho ring Tool creates custom driver templates using the Legacy Code Tool (LCT). You do not need any prior knowledge of the Legacy Code Tool to use the xPC T arget Driver Authoring Tool. If you want to read about the Legacy Code Tool, see “Integrating Existing C Functions into Simulink Models with the Legacy Code Tool” in Developing S-Functions.

7-3

7 Creating Custom Drivers Using the xPC Target™ Drive r Authoring Tool

Generating Custom Driver Templates

In this section...

“Using the xPC Target Driver Authoring Tool” on page 7-4

“Setting Up Driver Variables” on page 7-4

“Saving the Configuration” on page 7-7

“Reloading the Configuration” on page 7-8

“Creating the C File Template” on page 7-8

“Creating a C MEX File for the Driver” on page 7-8

“Customizing the Device Driver Mask” on page 7-9

Using the xPC Target Driver Authoring Tool

The prerequisites for creating a custom xPC Target device driver using the xPC Target Driver Authoring Tool are the same as those for creating a device driver manually. See “Expected Background” on page 1-3 and “Before You Start” on page 1-8 for further information.

7-4

The following sections assume that you have identified the following component specifications for the driver. See “Before You Start” on page 1-8 for guidelines for the following driver components, including their data type and size:

Input ports Output ports Parameters Work variables

Setting Up Driver Variables

1 In the MATLAB Command Window, change directory to the one in which

you want to save the driver code.

2 Start xPC Target Driver Authoring Tool. Type

xpcdrivertool

The xPC Target Driver A uthoring Tool is displayed.

Generating Custom Driver Templates

3 In the Main tab, enter:

• Driver name — The name for your driver. The tool will cre ate supporting

files using this string as the prefix. For example, type

testdriver.

• Sample time — Select one of the following:

Mask parameter — If you want the block sample time to be settable

–

as a block dialog box parameter (Sample Time).

–

Inherited — If you want the block to inh erit its sample time from

a connected block. No Sample Time parameter is displayed in the block dialog box.

4 If you have input ports for the block, click the Input Ports tab.

The Inport Ports tab is displayed.

5 Click the Add button. Enter your input port information in the following

fields. Repeat as necessary for your defined input ports.

• Variable —Enterthenameoftheinput. Forexample,

speed.

7-5

7 Creating Custom Drivers Using the xPC Target™ Drive r Authoring Tool

• Size — Enter the maximum size number of storage locations to b e

allocated for the parameter. If you want this number to b e a variable one, enter a value of 0. This setting means that you can pass an additional function argument that contains the size into the start, output, and/or terminate functions along with the port/parameter variable.

• Type — From the list, select the data type for the input port.

• Output — This check box is always selected. It ensures that the input

portvaluewillbepassedintotheS-function method.

6 If you have o utput ports for the block, click the Output Ports tab.

The Output Ports tab is displayed.

7 Click the Add button. Enter your output port information in the following

fields. Repeat as necessary for your defined output ports.

mdlOutputs callback

• Variable — Enter the name of the output. For example,

speed.

• Size — Enter the maximum size number of storage locations to b e

allocated for the size.

• Type — From the list, select the data type for the output port.

• Output — This check box is always selected. It ensures that the output

portvaluewillbepassedintotheS-function

mdlOutputs callback

method.

8 If you have parameters for the block, click the Parameters tab.

The Parameters tab is displayed.

9 Click the Add button. Enter your parameter info rm ation in the following

fields. Repeat as necessary for your defined parameters.

• Variable —Enterthenameoftheparameter.Forexample,

speed.

• Type — From the list, select the data type for the parameter.

• Size — Enter the maximum size number of storage locations to b e

allocated for the parameter. If you want this number to be a variable one, enter a value of 0. This means that you can pass an additional

7-6

Generating Custom Driver Templates

function argument that contains the size into the start, output and/or terminate functions along with the port/parameter variable.

• Start — Select the check b ox if you want the parameter value to be

passed into the S-function

mdlStart callback method.

• Output — Se lect the check box if yo u want the parameter value to be

passed into the S-function

mdlOutputs callback method.

• Terminate — Select the check box if you want the parameter value to

be passed into the S-function

10 If you h ave work varia bles to be shared between the start, output, and

mdlTerminate callback method.

terminate routines for the block, click the Work Variables tab.

The Work Variables tab is displayed.

11 Click the Add button. Enter your work variables information in the

following fields. Repeat as necessary for your defined parameters.

• Variable — Enter the name of the work variable. For ex ample,

speed.

• Type — From the list, select the data type for the work variable.

• Size — Enter the maximum size of the work variable.

• Start — Select the check box if you want the work variable value to be

passed into the S-function

mdlStart callback method.

• Output — Select the check box if you want the work variable value to be

passed into the S-function

mdlOutputs callback method.

• Terminate — Select the check box if you want the work variable value

to be passed into the S-function

mdlTerminate callback method.

Saving the Configuration

The xPC Target Driver Authoring Tool allows you to save your configuration session as a MAT-file.

1 In the xPC Target Driver Authoring T ool, click the Main tab.

2 Click Save settings.

The tool saves the

testdriver.mat file in the current working directory.

7-7

7 Creating Custom Drivers Using the xPC Target™ Drive r Authoring Tool

You can iteratively change the configuration and resave the MAT-file as often as you like.

Reloading the Configuration

The xPC Target Driver Authoring Tool allows you to reload your configuration session as a MAT-file.

1 In the xPC Target Driver Authoring T ool, click the Main tab.

2 Click Load settings.

The tool loads the

testdriver.mat file into the tool.

Creating the C File Template

To generate a template for the d river C source code file:

1 In the xPC Target Driver Authoring T ool, click the Main tab.

2 Select Generate C file template.

3 Click the Build button.

The tool creates the following files:

•

testdriver.c

• testdriver.h

• sfcn_testdriver.c

• sfcn_testdriver.tlc

4 With your favorite editor, open the testdriver .c file and edit i t. This is the

source C code for your driver. The S-function code in will reference this C file.

sfcn_testdriver.c

Creating a C MEX File for the Driver

To create a C MEX file for the driver, you can use either the xPC Target Driver Authoring Tool or the

mex function.

7-8

Generating Custom Driver Templates

Note Use the xPC Target Driver Authoring Tool to build the C Mex file if you have not edited the C source code file (

testdriver.c). If you h a ve edited

thisfileandwanttokeepthosechanges, do not use the xPC Target Driver Authoring Tool to build the driver. Doing so overwrites your changes to the C source code. Instead, use the

mex function (see “Creating a C MEX File

UsingthemexFunction”onpage7-9).

Creating a C MEX File Using the xPC Target Authoring Tool

1 In the xPC Target Driver Authoring T ool, click the Main tab.

2 Select Generate block and mask.

3 Click the Build button.

Thetoolcreatesthefile

sfcn_testdriver.mexw32.

Creating a C MEX File Using the mex Function

1 In the MATLAB Command Window, change directory to the one that

contains the driver files.

2 Compile and link the MEX-file. For example:

mex sfcn_testdriver.c testdriver.c

This function creates the sfcn_testdriver.win32mex file.

Customizing the Device Driver Mask

The xPC Target Driver Authoring Tool creates a mask for the device driver. You can customize this block mask as described in Chapter 4, “Masking Drivers”. If you customize the mask, do not use the xPC Target Driv er Authoring Tool again to build your files . Doing so overwrites the driver files and you will lose your mask customizations.

7-9

7 Creating Custom Drivers Using the xPC Target™ Drive r Authoring Tool

7-10

I/O Structures — B y Category

xpcPCIDevice

xpcTime

Type definition for PCI configuration space structure

Type definition of time structure

8 I/O Structures — By Category

8-2

I/O Structures — Alphabetical List

xpcPCIDevice

Purpose Type definition for PCI configuration space structure

Prototype typedef struct xpcPCIDeviceStruct{

uint32_T BaseAddress[6]; uint32_T VirtAddress[6]; uint32_T Length[6]; uint16_T AddressSpaceIndicator[6]; uint16_T MemoryType[6]; uint16_T Prefetchable[6]; uint16_T InterruptLine; uint16_T VendorId; uint16_T DeviceId; uint16_T SubDeviceId; uint16_T SubVendorId;

} xpcPCIDevice;

Header File

Members

xpctarget.h

BaseAddress

VirtAddress

Length

Physical base addresses that are assigned by the PCI BIOS.

Virtual address of device. As necessary, enter the return value from

xpcReserveMemoryRegion.See

“Description” on page 9-3 for details.

Length of each region. This value contains the number of b ytes that the board segment responds to during the configuration space read. This value might be larger than the space required by the registers as specified in the hardware manufacturer manua l.

9-2

xpcPCIDevice

AddressSpaceIndicator

MemoryType

Prefetchable

InterruptLine

VendorId

DeviceId

SubDeviceId

SubVendorId

Indicates whether the b oard is I/O port mapped or memory-mapped. Values are one of t h e following. Verify this value in the hardware manufacturer manual for accuracy.

Memory-mapped

I/O port mapped

Type of memory. This field is relevant only

AddressSpaceIndicator has a value of 0.

Located anywhere in the 32-bit address space

Located below 1 MB

Located anywhere in the 64-bit address space

Indicates whether or not the memory is prefetchable. Typically, this field is not required.

Contains the assigned interrupt line, values between 0 and 15. The BIOS assigns this value. You need this value only if you are writing an interrupt driver.

Contains vendor ID.

Contains device ID.

Contains subdevice ID.

Contains subvendor ID.

Description The xpcPCIDevice structure defines the PCI configuration space

structure. The following are additional notes on the

• The PCI specification allows the definition of up to six different base

addresses (addressable regions). Most boards respond to one or two

BaseAddress field:

9-3

xpcPCIDevice

of these addresses. Base addresses are filled in during the BIOS plug and play initialization, before the xPC Target kernel starts to execute. The hardware designer of the board decides how many address spaces are defined and what they are used for. Many boards use one address space to contain all of the registers for the board, other boards separate functions into different address spaces. See the board hardware manufacturer manual for this information.

• For memory-mapped segments, call the

function to convert the physical address in BaseAddress to a virtual address that is suitable for the CPU to read and w rite the segment. You can then optionally save this address in the You might want to save the address if you have several segments and you want to pass them all to a board access library.

xpcReserveMemoryRegion

See Also xpcGetPCIDeviceInfo, xpcShowPCIDeviceInfo

VirtAddress field.

9-4

Purpose Type definition of time structure

Prototype typedef struct xpcTime64Struct{

uint32_T NanoSecondsLo; uint32_T NanoSecondsHi;

} xpcTime64;

typedef union xpcTimeStruct{

xpcTime64 U64; //uint64_T NanoSeconds;

} xpcTime;

xpcTime

Header

xpctarget.h

File

Members

U64.NanoSecondsLo

U64.NanoSecondsHi

Bottom 32 bits of 64-bit value.

Top 32 bits of 64-bit value.

Description The xPCTime structure holds the time value in nanoseconds, as a 64-bit

integer. 32 bits, respectively. The functions use this structure to return time values.

NanoSecondsLo and NanoSecondsHi hold the lower and upper

xpcGetElapsedTime and xpcSubtractTime

See Also xpcGetElapsedTime, xpcSubtractTime

9-5

xpcTime

9-6

I/O Functions — By Category

Port I/O (p. 10-2) I/O port input and output functions

for byte, word and double word accesses

PCI Configuration Information (p. 10-2)

Physical Memory (p. 10-2) PCI memory management functions

Time (p. 10-2) xPC Target timing functions

Miscellaneous (p. 10-3) Miscellaneous functions

Work with PCI devices through the PCI configuration space

10 I/O Functions — By Category

Port I/O

xpcInpB, xpcInpW, xpcInpDW

xpcOutpB, xpcOutpW, xpcOutpDW

PCI Configur

ation Information

xpcGetPCIDeviceInfo

xpcShowPCIDeviceInfo

Physical Memory

xpcAllo

xpcFree

xpcReserveMemoryRegion

cPhysicalMemory

PhysicalMemory

I/O port input functions for byte, word, a nd double word accesses

I/O port output functions for byte, word, a nd double word accesses

Return information for PCI device

Display contents of PCIDevice structure

Allocate

Free physical memory

Return virtual address that corresponds to physical address and mark region as readable/writable

physical memory

10-2

Time

GetElapsedTime

xpc

xpcSubtractTime

Return time since system boot

Return difference between two times

Miscellaneous

xpcBusyWait

xpcIsModelInit

Wait for specified length of time in seconds

Return target application load state

10-3

10 I/O Functions — By Category

10-4

I/O Functions — Alphabetical List

xpcAllocPhysicalMemory

Purpose Allocate physical memory

Prototype void *xpcAllocPhysicalMemor y(uint32_T numBytes)

Header

xpctarget.h

File

Arguments

numBytes

Allocate specified number of bytes of memory.

Description The xpcAllocPhysicalMemory function allocates the requested bytes

of physical memory. Functions such as memory.

xPCAllocPhysicalMemory allocates physical memory, where physical

memory is the same as the virtual address. Use this function only when absolutely necessary, such as for DMA transfers.

malloc only return virtual
