SimEvents

Reference

How to Contact The MathWorks

www.mathworks. comp.soft-sys.matlab Newsgroup www.mathworks.com/contact_TS.html Technical Support

suggest@mathworks.com Product enhancement suggestions

bugs@mathwo doc@mathworks.com Documentation error reports service@mathworks.com Order status, license renewals, passcodes

info@mathwo

com

rks.com

Web

Bug reports

Sales, prici

ng, and general information

508-647-7000 (Phone)

508-647-7001 (Fax)

The MathWorks, Inc. 3 Apple Hill Drive Natick, MA 01760-2098

For contact information about worldwide offices, see the MathWorks Web site.

SimEvents

The software described in this document is furnished under a license agreement. The software may be used or copied only under the terms of the license agreement. No part of this manual may be photocopied or reproduced in any form without prior written consent from The MathW orks, Inc.

FEDERAL ACQUISITION: This provision applies to all acquisitions of the Program and Documentation by, for, or through the federal government of the United States. By accepting delivery of the Program or Documentation, the government hereby agrees that this software or documentation qualifies as commercial computer software or commercial computer software documentation as such terms are used or defined in FAR 12.212, DFARS Part 227.72, and DFARS 252.227-7014. Accordingly, the terms and conditions of this Agreement and only those rights specified in this Agreement, shall pertain to and govern theuse,modification,reproduction,release,performance,display,anddisclosureoftheProgramand Documentation by the federal government (or other entity acquiring for or through the federal government) and shall supersede any conflicting contractual terms or conditions. If this License fails to meet the government’s needs or is inconsistent in any respect with federal procurement law, the government agrees to return the Program and Docu mentation, unused, to The MathWorks, Inc.

Trademarks

MATLAB and Simulink are registered trademarks of The MathWorks, Inc. See

www.mathworks.com/trademarks for a list of additional trademarks. Other product or brand

names may be trademarks or registered trademarks of their respective holders.

Patents

The MathWorks products are protected by one or more U.S. patents. Please see

www.mathworks.com/patents for more information.

Reference

Revision History

March 2007 Online only Revised for Version 2.0 ( Release 2007a). Previously part

of SimEvents

User’s Guide.

September 2007 Online only Revised for Version 2.1 (Release 2007b) March 2008 Online only Revised for Version 2.2 (Release 2008a) October 2008 Online only Revised for Version 2.3 (Release 2008b) March 2009 Online only Revised for Version 2.4 (Release 2009a) September 2009 Online only Revised for Version 3.0 (Release 2009b) March 2010 Online only Revised for Version 3.1 (Release 2010a)

Function Reference

Library and Models ................................ 1-2

Contents

Simulation Settings

Debugger

Debugger Session Simulation Control State Inspection Breakpoints Debugger Information

Seed Management

................................ 1-3

......................................... 1-4

................................. 1-4

................................ 1-4

................................... 1-5

...................................... 1-5

.............................. 1-6

................................. 1-7

Alphabetical List

Block Reference

Generators ........................................ 3-2

Entity Generators Event Generators Signal Generators

SimEvents Sinks

Attributes

......................................... 3-4

................................. 3-2

................................... 3-3

Queues ........................................... 3-5

Servers

Routing

Gates

Entity M a nagem en t

Signal Management

SimEvents Ports and Subsystems

Timing

Event Translation

Probes

SimEvents U ser-Defined Functions

........................................... 3-6

........................................... 3-7

............................................. 3-8

................................ 3-9

................................ 3-10

............................................ 3-12

................................. 3-13

............................................ 3-14

................... 3-11

.................. 3-15

vi Contents

Blocks — Alphabetical List

Configuration Parameters

SimEvents Pane ................................... 5-2

SimEvents Pane Overview Execution order Seed for event randomization

................................... 5-5

.......................... 5-4

........................ 5-6

Maximum events per block .......................... 5-7

Maximum events per model

......................... 5-8

SimEvents Diagnostics Pane

Diagnostics Pane Overview Attribute output de layed relative to entities Response to function call delayed relative to entities Statistical output delayed relative to entities Modification of attribute values used for decision

making

Identical seeds for random number generators

........................................ 5-17

........................ 5-9

......................... 5-10

............ 5-11

..... 5-13

........... 5-15

.......... 5-19

Glossary

Index

vii

viii Contents

Function Reference

Library and Models (p. 1-2) Open the library and example

models

Simulation Settings (p. 1-3) Configure models for discrete-event

simulation

Debugger (p. 1-4)

Seed Management (p. 1-7) Manage seeds of random n umber

Run and examine simulations in debug mode

generators

1 Function Reference

Library and Models

simeventsdocex

simeventslib

Open SimEvents example model

Open SimEvents library

documentation

1-2

Simulation Settings

simeventsconfig Assign model settings for

Simulation Settings

discrete-event simulation

simeventsstartup

Set default model settings for discrete-event simulation

1-3

1 Function Reference

Debugger

Debugger Session (p. 1-4) Start and stop the debugger

Simulation Control (p. 1-4) Stop, suspend or resume the

simulation

State Inspection (p. 1-5) Query the model for information

about the simulation

Breakpoints (p. 1-5) Create and manage breakpoints in

the debugger

Debugger Information (p. 1-6) Start a n d configure the debugger

Debugger Session

sedb.quit

sedebug Debug discrete-event simulation

dbopts

se_get

Simul

sedb.

sedb

sed

ation Control

cont

.runtoend

b.step

Quit discrete-event simulation debugging session

SimEvents debugger options structure

Continue simulation until next breakpoint

Run until end of discrete-event simulation

Single step in discrete-e ven t simulation

1-4

State Inspection

sedb.blkinfo Block information in discrete-event

simulation

Debugger

sedb.blklist

sedb.currentop

sedb.eninfo Entity information in discrete-event

sedb.evcal

sedb.evinfo Event information in discrete-event

sedb.gceb

sedb.gcebid

sedb.gcen

sedb.gcev

sedb.simtime

Blocks and their identifiers in discrete-event simulation

Current operation in discrete-event simulation

simulation

Event calendar of discrete-event simulation

simulation

Name of currently executing block in discrete-event simulation

Identifier of currently executing block in discrete-event simulation

Identifier of entity currently undergoing operation

Identifier of current event

Current time in discrete-event simulation

Breakpoints

sedb.bdelete Delete breakpoints in discrete-event

simulation

edb.blkbreak

sedb.breakpoints List breakpoints in discrete-event

Set breakpoint for discrete-event simulation block

simulation

1-5

1 Function Reference

sedb.disable Disable breakpoints in discrete-event

simulation

sedb.enable Enable breakpoints in discrete-event

simulation

sedb.evbreak

sedb.tbreak

Debugger Information

help

sedb.detail

Setbreakpointforexecutionor cancelation of event

Set timed breakpoint in discrete-event simulation

Help for debugger functions

Customize debugger simulation log in discrete-event simulation

1-6

Seed Management

se_getseeds

se_randomizeseeds Randomize seeds to make them

se_setseeds

Seed values of random number generators in blocks

unique

Set seed values for blocks with random number generators

1-7

1 Function Reference

1-8

Alphabetical List

help

Purpose Help for debugger functions

Syntax help

help sedb help functionname

Description help, at the SimEvents debugger command prompt, displays a

summary of debugger commands in the Command Window.

help sedb also displays a summary of debugger commands. This

syntax is valid at either the SimEvents debugger command prompt or the MATLAB

help functionname displays a brief description and the syntax for functionname in the Command Window.

How To • “Starting the SimEvents Debugger”

• “Overview of the SimEve n ts Debugger”

command prompt.

2-2

se_getdbopts

Purpose SimEvents debugger options structure

Syntax opts_struct = se_getdbopts

Description opts_struct = se_getdbopts returns an empty options structure that

you can configure and then use as an input to the You can set the

StartFcn field of opts_str uct to a cell array of strings

representing commands that the debugger executes after the debugger session begins.

Examples Set breakpoints upon starting the debugger:

1 At the MATLAB command prompt, create an options structure to

use in future debugger sessions:

opts_struct = se_getdbopts; opts_struct.StartFcn = {'tbreak 1', ' tbreak 2'};

2 For a particular model, begin a debugger session using a syntax

that includes argument causes the debugger to execute the commands in the

opts_struct.StartFcn field automatically:

opts_struct as an input argument. Using this

sedebug function.

sedebug('sedemo_outputswitch', opts_struct)

The output in the MATLAB Command Window reflects model initialization followed by the setting of two b reakpoints:

*** SimEvents Debugger ***

Functions | Help | Watch Video Tutorial

%==============================================================================%

Initializing Model sedemo_outputswitch

Set b1 : Breakpoint for first operation at or after time 1.000000

Set b2 : Breakpoint for first operation at or after time 2.000000

2-3

se_getdbopts

3 Proceed in the simulation until the first breakpoint. At the

sedebug>> prompt, enter:

cont

The output is:

%==============================================================================%

Initializing Time-Based Entity Generators

%..........................................................................%

Scheduling EntityGeneration Event (ev1)

: EventTime = 1.000000000000000

: Priority = 500

: Block = Time-Based Entity Generator

Hit b1 : Breakpoint for first operation at or after time 1.000000

%==============================================================================%

Executing EntityGeneration Event (ev1) Time = 1.000000000000000

: Entity = <none> Priority = 500

: Block = Time-Based Entity Generator

4 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

Values for Replicate Block:

•

'Inactive'

2-20

• 'Replicating X/Y'. X is the index

of the entity output port through which the replica will depart.

is the Number of entity output ports parameter of the block

Values for Entity Combine r B loc k:

•

'Inactive'

• 'Combining'

Values for Entity Splitter Block:

•

'Inactive'

sedb.blkinfo

Field Block

MemoryValue

Count

Entities

Signal Latch Value of the internal memory of the

Entity Departure Counter

All blocks that possess an entity input port

Description

• 'Splitting'

block

Number of entities th at have departed from this block and arrived at subsequent storage b locks, since the simulation start or the last reset, whichever occurred later.

Structure array, of which each element has these fields:

•

ID — Entity identifier

Status (queue and server blocks

•

only) — Status of the en tit y with respect to the block.

Entity Status Values in Queue

Blocks:

- 'Advancing'

- 'Queuing'

- 'Queued'

- 'Timed Out'

Entity Status Values in Server

Blocks:

- 'Advancing'

- 'In Service'

- 'Service Completed'

- 'Preempted'

- 'Timed Out'

2-21

sedb.blkinfo

Field Block

Examples View information about a block:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_start_timer_read_timer')

2 Proceed in the simulation. At the sedebug>> prompt, enter:

tbreak 2.51 cont

Description

• Event (server blocks only) —

Identifier of the service completion event for the entity

•

EventTime (server blocks only) —

Time of the service completion event for the entity

•

TimeInQueue (queue blocks only) —

Length of time the entity has been in the queue

2-22

The partial output indicates that the server is about to execute a service completion event:

Hit b1 : Breakpoint for first operation at or after time 2.510000

%==============================================================================%

Executing ServiceCompletion Event (ev8) Time = 2.581301297500028

: Entity = en4 Priority = 1

: Block = Infinite Server

3 View information about the block that is a bout to execute the event:

sedb.blkinfo

blkname = gceb blkid = gcebid

The output is:

blkname =

sedemo_start_timer_read_timer/Infinite Server

blkid =

blk7

4 Proceed further in the simulation:

step

The output shows that the entity is about to depart from the server:

%..........................................................................%

Entity Advancing (en4)

: From = Infinite Server

: To = Read Timer

5 Use the identifier, blkid, to get information about the block and

the status of entities in it:

% Display information in Command Win dow. blkinfo(blkid) % Store information in str uct ure. blkdetails = blkinfo(blkid) % Store status of entities in cell array. blkentities = {blkdetails.Entities.Status}'

The output is:

2-23

sedb.blkinfo

Infinite Server Current State T = 2.581301297500028

Block (blk7): Infinite Server

Entities (Capacity = Inf):

Pos ID Status Event EventTime

1 en2 In Service ev4 2.7303849396254689

2 en4 Advancing ev8 2.581301297500028

3 en5 In Service ev10 2.974736350905304

blkdetails =

Time: 2.5813

Block: 'sedemo_start_timer_read_timer/Infinite Server'

BlockID: 'blk7'

BlockType: 'Infinite Server'

Capacity: Inf

Entities: [1x3 struct]

2-24

blkentities =

'In Service'

'Advancing'

'In Service'

6 Get more information about one of the entities by using data from the

blkdetails structure as an input argument to the eninfo function:

adv_eninfo = eninfo(blkdetails.Entities(1).ID); time_in_system = adv_eninfo.Timers.ElapsedTime

The output is:

time_in_system =

1.5813

7 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.blkbreak | sedb.blklist | sedb.gceb

How To • “Inspecting Entities, Blocks, and Events”

sedb.blkinfo

2-25

sedb.blklist

Purpose Blocks and their identifiers in discrete-event simulation

Syntax blklist

blk_cell = blklist

Description blklist displays a list of event-based blocks and block identifiers in

the model that you are debugging. The list includes all blocks for which

blkinfo or blkbreak is valid. The list excludes virtual subsystems but

includes relevant blocks inside virtual s ubsystems. In the Command Window, you can click hyperlinks to highlight the blocks in the model window.

blk_cell = blklist returns the same information as blklist in a cell

array of strings. The first column of The corresponding cells in the second column contain block path names.

Examples In the Command Window, view the block list and store it in a variable:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

blk_cell contains block identifiers.

2-26

sedebug('sedemo_count_attributes')

2 View the list of blocks. At the sedebug>> prompt, enter:

blklist

The output is:

List of blocks in model: sedemo_count_attributes

blk1 Entity Data blk5 Entity Sink blk4 Get Attribute blk3 Set Attribute blk2 Time-Based Entity Generator

sedb.blklist

3 Store the list of blocks in a variable and exam ine one row of the

cell array:

x = blklist; x{1,:}

The output indicates the identifier and path name of one block in the model:

ans =

blk1

ans =

sedemo_count_attributes/Entity Data

4 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.blkbreak | sedb.blkinfo

How To •“InspectingBlocks”

2-27

sedb.breakpoints

Purpose List breakpoints in discrete-event simulation

Syntax breakpoints

b_struct = breakpoints

Description breakpoints displays a list of all breakpoints in the simulation. The

list includes disabled breakpoints, as well as breakpoints that the debugger already hit.

b_struct = breakpoints returns a structure array that stores

information about breakpoints in the simulation.

Output Arguments

b_struct

Structure a rray that stores information about breakpoints. The following table describes the fields of each structure in the array.

Field

Type

Value

Enabled

Examples Set and view breakpoints:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2 Establish breakpoints and then view them in the Command Window.

At the

sedebug>> prompt, enter:

Description

Breakpoint identifier

Type of breakpoint

Value associated with the breakpoint, as a string

1, if the breakpoint is enabled; 0 otherwise

2-28

tbreak 0.5

sedb.breakpoints

tbreak 1 tbreak 1.5 breakpoints

The output confirms the setting of breakpoints and displays th e list of breakpoints:

Set b1 : Breakpoint for first operation at or after time 0.500000

Set b2 : Breakpoint for first operation at or after time 1.000000

Set b3 : Breakpoint for first operation at or after time 1.500000

List of Breakpoints:

ID Type Value Enabled

b1 Timed 0.5 yes

b2 Timed 1 yes

b3 Timed 1.5 yes

3 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

Manipulate the structure array that is the output from breakpoints:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2 Establish b reakpoints and then record them in a structure variable.

At the

sedebug>> prompt, enter:

tbreak 0.5 tbreak 1 tbreak 1.5 b = breakpoints

2-29

sedb.breakpoints

The output confirms the setting of breakpoints and displays an initial view of the structure

3 View information about the first breakpoint:

The output is a structure:

Set b1 : Breakpoint for first operation at or after time 0.500000

Set b2 : Breakpoint for first operation at or after time 1.000000

Set b3 : Breakpoint for first operation at or after time 1.500000

1x3 struct array with fields:

Type

Value

Enabled

b1 = b(1)

2-30

b1 =

ID: 'b1'

Type: 'Timed'

Value: '0.5'

Enabled: 1

4 Store the IDs of the enabled breakpoints in a cell array, bid:

idx = find([b.Enabled]); bid = {b(idx).ID}

The output is:

bid =

sedb.breakpoints

'b1' 'b2' 'b3'

5 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.blkbreak | sedb.tbreak | sedb.evbreak | sedb.bdelete |

sedb.disable

How To •“DefiningaBreakpoint”

2-31

sedb.cont

Purpose Continue simulation until next breakpoint

Syntax cont

Description cont continues the simulation until it reaches the next breakpoint or

the end, whichever comes first.

Examples Establish a breakpoint at T=2 and then run the simulation until that

point:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2 Proceed in the simulation. At the sedebug>> prompt, enter:

tbreak 2 detail none cont

2-32

Theoutputendswithamessagedescribingthecontextofthe simulation at T=2:

Set b1 : Breakpoint for first operation at or after time 2.000000

Event Operations (ev) : off

Entity Operations (en) : off

Event Calendar (cal) : off

Hit b1 : Breakpoint for first operation at or after time 2.000000

%==============================================================================%

Executing EntityGeneration Event (ev10) Time = 2.000000000000000

: Entity = <none> Priority = 1

: Block = Time-Based Entity Generator

3 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.blkbreak | sedb.tbreak | sedb.evbreak

How To •“DefiningaBreakpoint”

• “Using Breakpoints During Debugging”

sedb.cont

2-33

sedb.currentop

Purpose Current operation in discrete-event simulation

Syntax currentop

Description currentop displays the most recent message in the simulation log.

If this message represents a depe nde nt operation, the output also includes a message about the most recent independent operation in the simulation log.

Definitions Independent Opera tion

An independent operation is one of these operations:

• Initialization of the mode l or any Time-Bas ed Entity Generator blocks

in the model. For more information, see “Initialization Messages”.

• Execution of an event on the event calendar. How ev er, if the

application executes an event without scheduling it on the event calendar, the event cannot be the basis of an independent operation. To learn which events are on the event calendar, see “Role of the Event Calendar”.

• Detection by a reactive port or a monitoring port o f a relevant update

in a time-based i n put sign al. You can think of these relevant updates as zero crossings or level crossings. However, if the input signal is an event-based signal or if the input port is not a reactive or monitoring port, the update is not an independent operation.

For more information, see “Independent Operations and Consequences in the Debugger”.

Dependent Operation

A dependent operation is a consequence of an independent operation.

Examples Compare the current operation display with the simulation log:

opts_struct = se_getdbopts; opts_struct.StartFcn={'step over','step',...

2-34

sedb.currentop

'step','step','currentop','quit'};

sedebug('sedemo_event_priorities',opts_struct)

The output shows that the display of the current operation includes the last entry in the simulation log, which is the current operation. The display a lso includes the last unindented entry in the simulation log, representing the latest independent operation.

2-35

sedb.currentop

*** SimEvents Debugger ***

Functions | Quick Start | Debugger Help

%==============================================================================% Initializing Model sedemo_event_priorities %==============================================================================% Initializing Time-Based Entity Generators

%..........................................................................%

Scheduling EntityGeneration Event (ev1) : EventTime = 0.000000000000000 (Now) : Priority = 2 : Block = Time-Based Entity Generator %==============================================================================%

%==============================================================================%

Executing EntityGeneration Event (ev1) Time = 0.000000000000000

: Entity = <none> Priority = 2

: Block = Time-Based Entity Generator

%..........................................................................%

Generating Entity (en1) : Block = Time-Based Entity Generator

%..........................................................................%

Entity Advancing (en1) : From = Time-Based Entity Generator : To = FIFO Queue

%..........................................................................%

Entity Advancing (en1)

: From = FIFO Queue

: To = Single Server

Current Operation:

%==============================================================================% Executing EntityGeneration Event (ev1) Time = 0.000000000000000 : Entity = <none> Priority = 2 : Block = Time-Based Entity Generator

%..........................................................................%

Entity Advancing (en1) : From = FIFO Queue : To = Single Server

SimEvents Debugger: Abort

Independent operation

Dependent operation

How To •“SimulationLogintheDebugger”

• “Independent Operations and Consequences in the Debugger”

• “Inspecting the Current Point in the Debugger”

2-36

sedb.detail

Purpose Customize debugger simulation log in discrete-event simulation

Syntax detail('none')

detail('default') detail('all') prev = detail(...) detail(struc) detail(paramname1, paramvalue1, paramname2, paramvalue2,...) detail curr = detail

Description detail('none') configures the debugger to omit all simulation log

messages, except upon reaching breakpoints. This syntax is the same as

detail('en',0,'ev',0,'cal',0). Y ou cannot use the step function to

step to anything other than breakpoints when the debugger omits all simulation log messages.

detail('default') resets the detail settings to their default values.

This syntax is the same as

detail('en',1,'ev',1,'cal',0).

detail('all') configures the debugger to show all

simulation log messages. This syntax is the same as

detail('en',1,'ev',1,'cal',1).

prev = detail(...) configures the debugger based on the inputs, and

also returns a structure that describes the previous detail settings.

detail(struc) uses the structure struc to establish detail settings.

detail(paramname1, paramvalue1, paramname2, paramvalue2,...)

configures the debugger to show or omit certainkindsofmessagesinthesimulationlog. Youcanspecifyone, two, or three pairs of parameter names, values,

detail displays the current detail settings.

curr = detail returns a structure that describes the current detail

paramvalueN.

paramnameN,andparameter

settings.

2-37

sedb.detail

Input Arguments

paramnameN

Name of detail setting.

'ev'

'en'

'cal'

paramvalueN

Value of detail setting.

Event operations, except if at least one detail setting is 1, independent operations representing event executions appear. The exception holds true even if the

Entity operations

Event calendar information

Omit messages, except upon reaching a breakpoint. Omitting entity messages or event messages also means that you cannot rely on the to an operation that corresponds to an omitted message.

Show messages.

'ev' setting is 0.

step function to step

Output Arguments

2-38

struc

Structure having three fields describing the detail settings that you want. Field names are the same as the names in the table that describes the as the values in the table that describes the

curr

Structure that describes the current detail settings. Field names a re the same as the names in the table that describes the

paramnameN input. Field values are the same as the values in the

table that describes the

paramnameN input. Field values are the same

paramvalueN input.

Structure that describes the pr evious detail settings before changing them. Field names are the same as the names in the table that describes the

paramnameN input. Field values are the

same as the values in the table that describes the input.

Examples Configure displays for breakpoints and stepping:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2 Proceed in the simulation, suppressing the simulation log until the

debugger reaches a breakpoint. At the

tbreak 2 prev = detail('none') cont

sedebug>> prompt, enter:

sedb.detail

paramvalueN

The output ends with the context of the simulation at T =2:

Set b1 : Breakpoint for first operation at or after time 2.000000

prev =

ev: 1

en: 1

cal: 0

Hit b1 : Breakpoint for first operation at or after time 2.000000

%==============================================================================%

Executing EntityGeneration Event (ev10) Time = 2.000000000000000

: Entity = <none> Priority = 1

2-39

sedb.detail

: Block = Time-Based Entity Generator

3 Now that the simulation is at a point of interest, configure the

debugger to show the simulation log. This configuration makes subsequent

step operations more informative. Then move forward

in the simulation:

detail(prev) step over

The output confirms the change in detail settings and then shows the result of enabling the simulation log:

Event Operations (ev) : on

Entity Operations (en) : on

Event Calendar (cal) : off

%..........................................................................%

Generating Entity (en4)

: Block = Time-Based Entity Generator

%..........................................................................%

Entity Advancing (en4)

: From = Time-Based Entity Generator

: To = Schedule Timeout

%..........................................................................%

Scheduling Timeout Event (ev11)

: EventTime = 3.000000000000000

: Priority = 1700

: Entity = en4

: Block = Schedule Timeout

%..........................................................................%

Entity Advancing (en4)

: From = Schedule Timeout

: To = Infinite Server

%..........................................................................%

Scheduling ServiceCompletion Event (ev12)

: EventTime = 2.581301297500028

2-40

sedb.detail

: Priority = 1

: Entity = en4

: Block = Infinite Server

%..........................................................................%

Executing Scope

: Block = Number of En tities Time-Stamped

%..........................................................................%

Scheduling EntityGeneration Event (ev13)

: EventTime = 2.500000000000000

: Priority = 1

: Block = Time-Based Entity Generator

%==============================================================================%

Executing Timeout Event (ev5) Time = 2.000000000000000

: Entity = en2 Priority = 1700

: Block = Infinite Server

4 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.blkbreak | sedb.cont | sedb.evbreak | sedb.tbreak

How To • “Customiz ing the Debugger Simulation Log”

2-41

sedb.disable

Purpose Disable breakpoints in discrete-event simulation

Syntax disable id1 id2 ...

disable(id_array) disable all

Description disable id1 id2 ... disables the breakpoints having identifiers

id1, id2, and so on. To see breakpoints and their identifiers, use

sedb.breakpoints. A disabled breakpoint remains in the list but the sedb.cont function ignores it.

disable(id_array) disables the breakpoints in the cell array id_array.

disable all disables all breakpoints.

Examples Manipulate timed breakpoints and run the simulation until a

breakpoint:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

2-42

sedebug('sedemo_timeout')

2 Establish and view breakpoints. At the sedebug>> prompt, enter:

tbreak 0.5 tbreak 1 tbreak 1.5 breakpoints

The output lists the breakpoints:

Set b1 : Breakpoint for first operation at or after time 0.500000

Set b2 : Breakpoint for first operation at or after time 1.000000

Set b3 : Breakpoint for first operation at or after time 1.500000

List of Breakpoints:

sedb.disable

ID Type Value Enabled

b1 Timed 0.5 yes

b2 Timed 1 yes

b3 Timed 1.5 yes

3 Delete, disable, and enable some of the breakpoints. View the

resulting list:

bdelete b2 disable b3 disable b1 enable b3 breakpoints

The output is:

Deleted b2 : Breakpoint for f irst operation at or after time 1.000000

Disabled b3 : Breakpoint for firs t operation at or after time 1.500000

Disabled b1 : Breakpoint for firs t operation at or after time 0.500000

Enabled b3 : Breakpoint for first operation at or after time 1.500000

List of Breakpoints:

ID Type Value Enabled

b1 Timed 0.5 no

b3 Timed 1.5 yes

4 Run the simulation until the first enabled breakpoint:

cont

The partial output shows that b3 is the breakpoint at which the debugger stops. The debugger ignores the disabled breakpoint, and doe s not consider the previously deleted breakpoint,

Hit b3 : Breakpoint for first operation at or after time 1.500000

%==============================================================================%

b2.

b1,

2-43

sedb.disable

Executing EntityGeneration Event (ev7) Time = 1.500000000000000

: Entity = <none> Priority = 1

: Block = Time-Based Entity Generator

5 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.breakpoints | sedb.enable | sedb.bdelete

How To • “Using Breakpoints During Debugging”

2-44

sedb.enable

Purpose Enable breakpoints in discrete-event simulation

Syntax enable id1 id2 ...

enable all

Description enable id1 id2 ... enables the breakpoints having identifiers

id1, id2, and so on. To see breakpoints and their identifiers, use

sedb.breakpoints.

enable(id_array) enables the breakpoints in the cell array, id_array.

enable all enables all breakpoints.

Examples Manipulate timed breakpoints and run the simulation until a

breakpoint:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2 Establish and view breakpoints. At the sedebug>> prompt, enter:

tbreak 0.5 tbreak 1 tbreak 1.5 breakpoints

The output lists the breakpoints:

Set b1 : Breakpoint for first operation at or after time 0.500000

Set b2 : Breakpoint for first operation at or after time 1.000000

Set b3 : Breakpoint for first operation at or after time 1.500000

List of Breakpoints:

ID Type Value Enabled

b1 Timed 0.5 yes

2-45

sedb.enable

b2 Timed 1 yes

b3 Timed 1.5 yes

3 Delete, disable, and enable some of the breakpoints. View the

resulting list:

bdelete b2 disable b3 disable b1 enable b3 breakpoints

The output is:

Deleted b2 : Breakpoint for f irst operation at or after time 1.000000

Disabled b3 : Breakpoint for firs t operation at or after time 1.500000

Disabled b1 : Breakpoint for firs t operation at or after time 0.500000

Enabled b3 : Breakpoint for first operation at or after time 1.500000

List of Breakpoints:

2-46

ID Type Value Enabled

b1 Timed 0.5 no

b3 Timed 1.5 yes

4 Run the simulation until the first enabled breakpoint:

cont

The partial output shows that b3 is the breakpoint at which the debugger stops. The debugger ignores the disabled breakpoint, and doe s not consider the previously deleted breakpoint,

Hit b3 : Breakpoint for first operation at or after time 1.500000

%==============================================================================%

Executing EntityGeneration Event (ev7) Time = 1.500000000000000

: Entity = <none> Priority = 1

b2.

b1,

: Block = Time-Based Entity Generator

5 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.breakpoints | sedb.disable | sedb.bdelete

How To • “Using Breakpoints During Debugging”

sedb.enable

2-47

sedb.eninfo

Purpose Entity information in discrete-event simulation

Syntax eninfo(enid)

en_struct = eninfo(enid)

Description eninfo(enid) displays information about the location, attributes,

timers, and timeouts on an entity.

en_struct = eninfo(enid) returns a structure that stores information

about the entity.

enid is the identifier of the entity.

Output Arguments

en_struct

Structure that stores information about the entity. The following table describes the

Field

Time

Location

Attributes

Timers

Timeouts

en_struct fields.

Description

Current simulation time

Path name of the block containing the entity

Structure whose field names and values match the names and values of the attributes of the entity

Structure array, of which each element has these fields:

•

Tag —Timertag

ElapsedTime — Time elapsed since the

•

timer started

Structure array, of which each element has these fields:

•

Tag —Timeouttag

2-48

sedb.eninfo

Field

Description

• TimeOfTimeout — Scheduled time of

timeout event

•

Event— Identifier of timeout event

Examples View the values of the attributes of an entity:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_star_routing')

2 Proceed in the simulation. At the sedebug>> prompt, enter:

tbreak 0.1 cont

The partial output shows the entity identifier, en1,inthedisplay:

Hit b1 : Breakpoint for first operation at or after time 0.100000

%==============================================================================%

Executing ServiceCompletion Event (ev2) Time = 0.300000000000000

: Entity = en1 Priority = 5

: Block = Distribution Center/Infinite Server

3 Get the ID of an entity:

% Get ID of current entity. enid = gcen

The workspace variable, enid, holds the same entity identifier, en1, from the display:

enid =

2-49

sedb.eninfo

en1

4 Use the identifier, enid, to get information about the entity:

% Display information in Command Win dow. eninfo(enid) % Store information in str uct ure. endetails = eninfo(enid) % View attributes. enattrs = endetails.Attributes % View one attribute. enServiceProcess = enattrs.ServiceProcess % Equivalently, view one attribute starting from endetails. enServiceProcess = endetails.Attributes.ServiceProcess;

The output is:

Entity (en1) Current State T = 0.300000000000000

Location: Distribution Center/Infinite Server

2-50

Attributes:

Name Value

CurrentRoute 1

CurrentServiceTime 2

CurrentStep 2

JobClass 1

JobID 1

JobServiceStatus [1x15]

LastServiceLocation 0

ServiceProcess [6x1]

ServiceTime [6x1]

Timeouts, Timers: None

endetails =

sedb.eninfo

Time: 0.3

Location: 'sedemo_star_routing/Distribution Center/Infinite Server'

Attributes: [1x1 struct]

Timers: [0x0 struct]

Timeouts: [0x0 struct]

enattrs =

CurrentRoute: 1

CurrentServiceTime: 2

CurrentStep: 2

JobClass: 1

JobID: 1

JobServiceStatus: [0 NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN NaN]

LastServiceLocation: 0

ServiceProcess: [6x1 double]

ServiceTime: [6x1 double]

enServiceProcess =

5 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.gcen | sedb.blkinfo | sedb.evinfo | sedb.currentop

How To • “Obtaining Entity Identifiers”

2-51

sedb.eninfo

• “Inspecting Entities, Blocks, and Events”

2-52

sedb.evbreak

Purpose Set breakpoint for execution or cancelation of event

Syntax evbreak(evid)

bid = evbreak(evid)

Description evbreak(evid) sets a breakpoint for execution or cancelation of the

event with identifier, on the event calendar and their identifiers, use

bid = evbreak(evid) returns the identifier of the breakpoint.

Examples Set a breakpoint on a service completion event:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_server_service_time')

2 Proceed in the simulation. At the sedebug>> prompt, enter:

evid,inthesimulation. Toobtainalistofevents

sedb.evcal.

step over

The output is:

%==============================================================================%

Initializing Time-Based Entity Generators

%..........................................................................%

Scheduling EntityGeneration Event (ev1)

: EventTime = 0.000000000000000 (Now)

: Priority = 500

: Block = Time-Based Entity Generator

%..........................................................................%

Scheduling EntityGeneration Event (ev2)

: EventTime = 0.000000000000000 (Now)

: Priority = 500

: Block = Time-Based Entity Generator 1

%..........................................................................%

Scheduling EntityGeneration Event (ev3)

2-53

sedb.evbreak

: EventTime = 0.000000000000000 (Now)

: Priority = 500

: Block = Time-Based Entity Generator 3

%==============================================================================%

Executing EntityGeneration Event (ev1) Time = 0.000000000000000

: Entity = <none> Priority = 500

: Block = Time-Based Entity Generator

3 Proceed further:

step over

The output shows that a service completion event with identifier,

ev4, appears on the event calendar. The scheduled time of the event

is T=1.

%..........................................................................%

Generating Entity (en1)

: Block = Time-Based Entity Generator

%..........................................................................%

Entity Advancing (en1)

: From = Time-Based Entity Generator

: To = Single Server

%..........................................................................%

Scheduling ServiceCompletion Event (ev4)

: EventTime = 1.000000000000000

: Priority = 500

: Entity = en1

: Block = Single Server

%..........................................................................%

Executing Scope

: Block = Num. Entities

%..........................................................................%

Scheduling EntityGeneration Event (ev5)

: EventTime = 1.000000000000000

: Priority = 500

: Block = Time-Based Entity Generator

%==============================================================================%

2-54

sedb.evbreak

Executing EntityGeneration Event (ev2) Time = 0.000000000000000

: Entity = <none> Priority = 500

: Block = Time-Based Entity Generator 1

4 Set a bre

to exec

akpoint that causes the debugger to stop when it is about

utetheservicecompletionevent,

ev4:

evbreak ev4

The output confirms the operation:

Set b1 : Breakpoint for execu tion or cancelation of event ev4

5 Run the simulation until the breakpoint:

cont

The partial output shows that the debugger proceeds through a different event at T=1, and stops upon hitting the breakpoint at event

ev4. Because that event is not the first event the simulation executes

at that time, the example shows how an event breakpoint differs from a timed breakpoint. A timed breakpoint at T=1 would have caused the debugger to stop upon the first event at this time,

%==============================================================================%

Executing ServiceCompletion Event (ev6) Time = 1.000000000000000

: Entity = en2 Priority = 300

: Block = Infinite Server

%..........................................................................%

Entity Advancing (en2)

: From = Infinite Server

: To = Entity Sink2

%..........................................................................%

Destroying Entity (en2)

: Block = Entity Sink2

ev6.

Hit b1 : Breakpoint for execution or cancelation of event ev4

%==============================================================================%

2-55

sedb.evbreak

Executing ServiceCompletion Event (ev4) Time = 1.000000000000000

: Entity = en1 Priority = 500

: Block = Single Server

6 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

See Also sedb.evcal | sedb.cont | sedb.breakpoints | sedb.bdelete

How To •“DefiningaBreakpoint”

2-56

sedb.evcal

Purpose Event calendar of discrete-event simulation

Syntax evcal

cal_struct = evcal

Description evcal displays the list of events on the event calendar. The listing

for the event in progress or the event selected for execution includes the characters identifier. The display includes this event unless all its immediate consequences are complete.

cal_struct = evcal returns a structure that stores information about

the event calendar.

=>. These characters appear to the left of the event

Output Arguments

cal_struct

Structure that stores information about the event calendar. The

cal_struct fields are in the following table.

Field

Time

ExecutingEvent

Description

Current simulation time

Structure that describes the event in progress or selected for execution. The structure has these fields:

•

ID —Eventidentifier

EventType — Type of event

•

EventTime — Scheduled time of event

•

Priority —Priorityofevent

•

Entity — Identifier of entity associated

•

with the event

•

Block — Path name of block that executes

the event

2-57

sedb.evcal

Field

PendingEvents

Description

Structure array that describes events that are not in progress or selected for execution. Each structure in the array has these fields:

•

ID —Eventidentifier

EventType — Type of event

•

EventTime — Scheduled time of event

•

Priority —Priorityofevent

•

Entity — Identifier of entity associated

•

with the event

•

Block — Path name of block that executes

the event

Examples View the event calendar and then manipulate a structure variable that

storesthesameinformation:

1 Begin a debug ger session for a particular model. At the MATLAB

command prompt, enter:

sedebug('sedemo_timeout')

2-58

2 Proceed in the simulation. At the sedebug>> prompt, enter:

tbreak 2 detail none cont

Theoutputendswithamessagedescribingthecontextof simulation at T=2:

Set b1 : Breakpoint for first operation at or after time 2.000000

Event Operations (ev) : off

the

sedb.evcal

Entity Operations (en) : off

Event Calendar (cal) : off

Hit b1 : Breakpoint for first operation at or after time 2.000000

%==============================================================================%

Executing EntityGeneration Event (ev10) Time = 2.000000000000000

: Entity = <none> Priority = 1

: Block = Time-Based Entity Generator

3 View t

he event calendar:

% View event calendar. evcal

The following output lists all events on the event calendar:

Current Time = 2.000000000000000

%------------------------------------------------------------------------------%

Events in the Event Calendar

ID EventTime EventType Priority Entity Block

=> ev10 2.000000000000000 EntityGeneration 1 <none> Time-Based Entity Generator

ev5 2.000000000000000 Timeout 1700 en2 Infinite Server

ev6 2.730384939625469 ServiceCompletion 1 en2 Infinite Server

4 Store the event calendar as a structure and get more information

about the first pending event:

% Store event calendar as a structure. cal_struct = evcal ev5struct = cal_struct.PendingEvents(1)

The output is:

cal_struct =

Time: 2

2-59

sedb.evcal

ExecutingEvent: [1x1 struct]

PendingEvents: [2x1 struct]

ev5struct =

ID: 'ev5'

EventType: 'Timeout'

EventTime: 2

Priority: '1700'

Entity: 'en2'

Block: 'sedemo_timeout/Infinite Server'

5 Find the types of pending events whose scheduled time is the current

simulation time:

idx = find([cal_struct.PendingEvents.EventTime] == simtime); simult_event_types = {cal_struct.PendingEvents(idx).EventType}'

The output is:

2-60

simult_event_types =

'Timeout'

6 Store all event times in a vector:

ev_times = cal_struct.ExecutingEvent.EventTime; ev_times = [ev_times, cal_struct.PendingEvents.EventTime]'

The output is:

ev_times =

2.0000

2.7304

7 End the debugger session. At the sedebug>> prompt, enter:

sedb.quit

After the debugger session ends, cal_str uct and the other variables remain in the workspace.
