Mathworks MATLAB BUILDER NE 3 user guide

MATLAB®Builder™ N

User’s Guide

How to Contact The MathWorks

www.mathworks. comp.soft-sys.matlab Newsgroup www.mathworks.com/contact_TS.html Technical Support

suggest@mathworks.com Product enhancement suggestions bugs@mathwo doc@mathworks.com Documentation error reports service@mathworks.com Order status, license renewals, passcodes info@mathwo

com

rks.com

Web

Bug reports

Sales, prici

ng, and general information

508-647-7000 (Phone)

508-647-7001 (Fax)

The MathWorks, Inc. 3 Apple Hill Drive Natick, MA 01760-2098

For contact information about worldwide offices, see the MathWorks Web site.

MATLAB

The software described in this document is furnished under a license agreement. The software may be used or copied only under the terms of the license agreement. No part of this manual may be photocopied or reproduced in any form without prior written consent from The MathW orks, Inc.

FEDERAL ACQUISITION: This provision applies to all acquisitions of the Program and Documentation by, for, or through the federal government of the United States. By accepting delivery of the Program or Documentation, the government hereby agrees that this software or documentation qualifies as commercial computer software or commercial computer software documentation as such terms are used or defined in FAR 12.212, DFARS Part 227.72, and DFARS 252.227-7014. Accordingly, the terms and conditions of this Agreement and only those rights specified in this Agreement, shall pertain to and govern theuse,modification,reproduction,release,performance,display,anddisclosureoftheProgramand Documentation by the federal government (or other entity acquiring for or through the federal government) and shall supersede any conflicting contractual terms or conditions. If this License fails to meet the government’s needs or is inconsistent in any respect with federal procurement law, the government agrees to return the Program and Docu mentation, unused, to The MathWorks, Inc.

Trademarks

MATLAB and Simulink are registered trademarks of The MathWorks, Inc. See

www.mathworks.com/trademarks for a list of additional trademarks. Other product or brand

names may be trademarks or registered trademarks of their respective holders.

Patents

The MathWorks products are protected by one or more U.S. patents. Please see

www.mathworks.com/patents for more information.

Builder™ NE User’s Guide

Revision History

March 2006 Online only New for Version 2.0 (Release 2006a) September 2006 Online only Revised for Version 2.1 (Release 2006b) March 2007 Online only Revised for Version 2.2 (Release 2007a) September 2007 Online only Revised for Version 2.2.1 (Release 2007b) March 2008 Online only Revised for Version 2.2.2 (Release 2008a) October 2008 Online only Revised for Version 3.0 (Release 2008b) March 2009 Online only Revised for Version 3.0.1 (Release 2009a) September 2009 Online only Revised for Version 3.0.2 (Release 2009b) March 2010 Online only Revised for Version 3.1 (Release 2010a)

Contents

Getting Started

Product Overview ................................. 1-2

MATLAB Common Language Specification (CLS) Compliancy Data Conversion, Indexing, and Array Formatting Error Handling Remotable Components COM Components Supported Microsoft .NET Framework Versions Limitations of Support

Before You Use MATLAB

Your Role in the .NET Application Deployment Process What You Need to Know Install Required Products

Deploying a Component Using the Magic Square

Example

About This Example Magic Square Example: MATLAB Programmer Tasks Using the Command Line to Create .NET Components Magic Square Example: .NET Programmer Tasks

Next Steps

Compiler Extension ...................... 1-2

..... 1-2

...... 1-3

................................... 1-3

............................ 1-3

................................. 1-3

........ 1-4

............................. 1-4

Builder NE ............... 1-5

.. 1-5

............................ 1-7

........................... 1-8

........................................ 1-9

............................... 1-9

... 1-10 ... 1-17

....... 1-23

........................................ 1-34

Writing Deployable MATLAB Code

The MATLAB Application Deployment Products ..... 2-2

Building Your Application w ith the Application

Deployment Products and the D e ploy ment Tool

What Is the Difference Between the Deployment Tool and

the mcc Command Line?

How Does MATLAB

Application?

What You Should Know About the Dependency Analysis

Function (depfun) Compiling MEX-Files, DLLs, or Shared Lib rari es The Role of the Component Technology File (CTF

Archive)

....................................... 2-7

Compiler Software Build My

.................................... 2-4

............................... 2-5

......................... 2-4

.... 2-4

....... 2-6

Guidelines for Writing Deployable MATLAB Code

Compiled Applications Do No t Process MATLAB Files at

Runtime Do Not Rely on Changing Directory or Path to Control the

Execution of MATLAB Files Use ismcc and isdeployed Functions To Execute

Deployment-Specific Code Paths Gradually Refactor Applications That Depend o n

Noncompilable Functions Do Not Create or Use Nonconstant Static State

Variables

Working with MATLAB Data Files Using Load and

Save

Using Load/Save Functions to Process MATLAB Data for

Deployed Applications

....................................... 2-10

....................... 2-11

................... 2-11

......................... 2-12

...................................... 2-12

............................................ 2-14

........................... 2-14

Using Components Created by the MATLAB

Builder NE Product

.... 2-10

vi Contents

Installing the Components on the Development

Machine

Specifying Component Assembly and Namespace

Creating an Instance of a Class

........................................ 3-2

..................... 3-4

..... 3-3

Using Dispose to E x plicitly Free Resources .......... 3-5

ImprovingDataAccessUsingtheMCRUserData

Interface and MATLAB

Code Snippets Example

Dynamically Specifying Run-Time Options to the

MCR

What Run-Time Options Can You Specify? Getting MCR Option Values Using MWMCR

Accessing Real or Imaginary Components Within

Complex Arrays

Extracting Real or Imaginary Components Returning Values with Component Indexing Assigning Values with Component Indexing Converting MATLAB Arrays to .NET Arrays Using

Blocking Execution of a Console Application that

Creates Figures

WaitForFiguresToDie Method Code Fragment: Using WaitForFiguresToDie to Block

........................................... 3-11

Component Indexing

Execution

.................................... 3-6

......................................... 3-7

...................................... 3-18

Builder NE ............... 3-6

............. 3-11

........... 3-11

................................. 3-14

............. 3-14

........... 3-14

............ 3-15

............................. 3-15

................................. 3-17

....................... 3-17

Using MATLAB API Functions in a C# Program

Overview Example: Using functions engOpen and engEvalString

from the MATLAB Engine API in a C# Program

Handling Errors

Overriding Default CTF Archive Embedding for

Components Using the MCR Component Cache

Using Enhanced XML Documentation Files

........................................ 3-20

................................... 3-22

.......... 3-26

...... 3-20

.... 3-24

vii

Sample Applications (C#)

Simple Plot Example ............................... 4-2

Purpose Procedure

......................................... 4-2

........................................ 4-2

Passing Variable Arguments

Spectral Analysis Example

Purpose Procedure

Matrix Math Example

Purpose Procedure MATLAB F unctions to Be Encapsulated Understanding the MatrixMath Program

Phonebook Example

Purpose Procedure

......................................... 4-13

........................................ 4-15

......................................... 4-20

........................................ 4-21

......................................... 4-28

........................................ 4-28

Sample Applications (Microsoft®Visual Basic

........................ 4-7

......................... 4-13

.............................. 4-20

............... 4-26

.............. 4-27

............................... 4-28

.NET)

viii Contents

Magic Square Example (Visual Basic) ............... 5-3

Create Plot Example (Visual Basic)

Variable Arguments Example (Visual Basic)

Spectral Analysis Example (Visual Basic)

.................. 5-7

......... 5-11

............ 5-15

Matrix Math Example (Visual Basic) ................. 5-20

Phonebook Example (Visual Basic)

makephone Function Procedure

........................................ 5-25

............................... 5-25

.................. 5-25

Deploying a MATLAB Figure Over the Web

Using WebFigures

About the WebFigures Feature ...................... 6-2

Supported Renderers for WebFigures

Before You Use WebFigures

Your Role in the .NET WebFigure Deployment Process What You Need to Know to Implement WebFigures Required Products Assumptions About the Examples

Quick Start: Implementing a WebFigure

Overview Procedure

........................................ 6-7

................................. 6-5

........................ 6-3

................. 6-2

.................... 6-6

............. 6-7

... 6-3

..... 6-5

Advanced Configuration of a WebFigure

Overview Manually Installing WebFigureService Retrieving Multiple WebFigu r es From a Component Attaching a WebFigu re Setting Up WebFigureControl for Remote Invocation Getting an Embeddable String That References a

WebFigure Attached to a WebFigureService

Improving Processing Times for JavaScript Using

Minification

Using Global Application Class (Global.asax) to Create

WebFigures at Server Start-Up

Upgrading Your WebFigures

........................................ 6-15

............................. 6-21

.................................... 6-27

.................... 6-28

........................ 6-30

............. 6-15

................ 6-17

..... 6-18

.... 6-23

......... 6-25

Troubleshooting ................................... 6-31

Logging Levels

.................................... 6-33

Working with MATLAB Figures and Images

Your Role in Working with Figures and Images ...... 7-2

Creating an d Modifying a MATLAB Figure

Preparing a MATLAB F igure for Export Changing the Figure (Optional) Exporting the Figure Cleaning Up the Figure Window Example: Modifying and Exporting Figure Data

Working with MATLAB Figure and Image Data

For More Comprehensive Examples Working with Figures Working with Images

............................... 7-4

.............................. 7-6

...................... 7-3

..................... 7-4

.................. 7-6

........... 7-3

............... 7-3

........ 7-4

...... 7-6

x Contents

Sharing Components Across Distributed

Applications Using .NET Remoting

Overview ......................................... 8-2

What Are Remotable Co mponents? Benefits of Using .NET Remoting

Your Role in Building Distributed Applications

Selecting th e Best Method of Accessing Your

Component: MWArray API or Native .NET API

Using Native .NET Structure and Cell Arrays

................... 8-2

.................... 8-2

...... 8-4

.......... 8-6

..... 8-5

Creating a Remotable .NET Component ............. 8-7

Building a Remotable Component Using the Deployment

Tool

.......................................... 8-7

Building a Remotable Component Using the mcc

Command

Files Generated by the Compilation Process

..................................... 8-10

............ 8-10

Enabling Access to a Remotable .NET Component

UsingtheMWArrayAPI Using the Native .NET API: The Magic Square Example Using the Native .NET API: The Cell and Struct

Example

....................................... 8-26

........................... 8-12

Troubleshooting

Troubleshooting the Build Process ................. 9-2

Viewing the Latest Build Log Generating Verbose Output

Failure to Find a Required File

Diagnostic Messages

Enhanced E rror Diagnostics Using mstack Trace

............................... 9-4

........................ 9-2

......................... 9-2

..................... 9-3

....... 9-6

.... 8-12

.. 8-19

Reference Information

Requirements for the MATLAB®Builder NE Product .. 10-2

System Require ments Compiler Requirements Path M odifications Required for Accessibility Limitations and Restrictions

Data Conversion Rules

............................. 10-2

............................ 10-2

........... 10-3

........................ 10-3

............................. 10-4

Managed Types to M ATLA B Arrays .................. 10-4

MATLAB Arrays to Managed Types Character and String Conversion Unsupported MATLAB Array Types

.................. 10-5

.................... 10-5

.................. 10-6

Overview of Data Conversion Classes

Overview Returning Data from MATLAB to Managed Code Example of MWNumericArray in a .NET Application Interfaces Generated by the MATLAB

Product

MWArray Class Specification

........................................ 10-7

....................................... 10-8

....................... 10-14

............... 10-7

....... 10-8

Builder NE

.... 10-8

Function Reference

Creating and Installing COM Components

Building a Deployable COM Component ............. 12-2

xii Contents

Packaging a Deployable COM Component

About Embedded CTF Archives

Using the Command-Line Interface

Installing COM Components on a Target Computer

..................... 12-5

................. 12-6

........... 12-4

... 12-9

Programming with COM Components Created

by the MATLAB

General Techniques ................................ 13-2

Builder NE Product

Registering and Referencing the Utility Library

Creating an Instance of a Class in Microsoft

Basic

Advantages and Disadvantages CreateObject Function Microsoft Advantages of Each Technique Declaring a Reusable Class Instance

Calling the Methods of a Class Instance

Standard Mapping Technique Variant Examples of Passing Input and Output Parameters

Calling a COM Object in a Visual C++ Program

Using the MATLAB

Using the Component in a Visual C++ Program

Using a COM Component in a .NET Application

Overview C# Implementation Microsoft

........................................... 13-5

...................... 13-5

............................. 13-5

Visual Basic New Operator ................ 13-6

...................... 13-7

.................. 13-7

....................... 13-8

.......................................... 13-9

Builder NE Product to Create the

Object

......................................... 13-11

........................................ 13-14

................................ 13-14

Visual Basic Implementation ............... 13-17

Visual

.............. 13-8

......... 13-12

...... 13-4

..... 13-9

....... 13-11

...... 13-14

Adding Events to COM Objects

MATLAB Language Pragma Using a Callback with a Microsoft

Passing Arguments

Overview Creating and Using a varargin Array in Microsoft

Basic Programs

........................................ 13-26

................................ 13-26

................................. 13-26

...................... 13-21

........................ 13-21

Visual Basic Event ... 13-22

Visual

xiii

Creating and Using varargout in Microsoft®Visual Basic

Programs Passing an Empty varargin From Microsoft

Code

Using Flags to Control Array Formatting and Data

Conversion

Overview Array Formatting Flags Using Array Formatting Flags Using Data Conversion Flags Special Flags for Some Microsoft

...................................... 13-27

Visual Basic

.......................................... 13-28

..................................... 13-29

........................................ 13-29

............................ 13-30

....................... 13-30

........................ 13-33

Visual Basic Types .... 13-35

Using MATLAB Global Variables in Microsoft

Basic

Blocking Execution of a Console Application that

Creates Figures

MCRWaitForFigures Using MCR WaitForFig ures to Block Execution

Obtaining Registry Information

Handling Errors During a Method Call

........................................... 13-36

................................. 13-39

............................... 13-39

..................... 13-42

Visual

......... 13-40

.............. 13-44

Using COM Components in Microsoft®Visual

Basic Applications

Magic Square Example ............................. 14-2

Example Overview Creating the MATLAB File Using the Deployment Tool to Create and Build the

Project Creating the Microsoft Creating the User Interface Creating the Executable in Microsoft Testing the Application

........................................ 14-3

................................ 14-2

......................... 14-2

Visual Basic Project ........... 14-4

......................... 14-4

Visual Basic ...... 14-7

............................. 14-7

xiv Contents

Packaging the Component .......................... 14-8

Creating an Excel Add-In: Spectral Analysis

Example

Example Overview Building th e Component Integrating the Component with VBA Creating the Microsoft Adding the Spectral A nalysis Menu Item to Microsoft

........................................ 14-9

................................ 14-9

............................ 14-9

................. 14-11

Visual Basic Form ............. 14-13

Excel ......................................... 14-18

Saving the Add-In Testing the Add-in Packaging and Distributing the Add-In

................................. 14-19

................................. 14-20

................ 14-22

Univariate Interpolation Example

Example Overview

................................ 14-24

.................. 14-24

Using the Deployment Tool to Create and Build the

Component Using the Component in Microsoft Creating the Microsoft

Matrix Calculator Example

Example Overview Building th e Component Using the Component in Microsoft Creating the Microsoft

Curve Fitting Example

Example Overview Building th e Component Building the Project Using the Component in Microsoft Creating the Microsoft

Bouncing Ball Simulation Example

Example Overview Building th e Component Using the Component in Microsoft Creating the Microsoft

.................................... 14-24

Visual Basic Form ............. 14-26

Visual Basic ........ 14-25

......................... 14-32

................................ 14-32

............................ 14-32

Visual Basic Form ............. 14-34

Visual Basic ........ 14-33

............................. 14-43

................................ 14-43

............................ 14-43

............................... 14-44

Visual Basic Form ............. 14-45

Visual Basic ........ 14-44

.................. 14-51

................................ 14-51

............................ 14-51

Visual Basic Form ............. 14-53

Visual Basic ........ 14-52

How the MATLAB®Builder NE Product Creates

COM Components

Overview of Internal Processes ..................... 15-2

How Is a MATLAB Code Generation Create Interface Definitions C++ Compilation Linking and Resource Binding Registration of the DLL

Component Registration

Self-Registering Components Globally Unique Identifier Versioning

Data Conversion

Conversion Rules Array Formatting Flags Data Conversion Flags

Calling Conventions

Producing a COM Class IDL Mapping Microsoft

Visual Basic Mapping ..................... 15-25

Builder NE Component Created? ... 15-2

.................................. 15-2

......................... 15-3

.................................. 15-3

....................... 15-3

............................ 15-3

........................... 15-4

........................ 15-4

.......................... 15-5

....................................... 15-7

................................... 15-9

.................................. 15-9

............................ 15-19

............................. 15-21

............................... 15-23

............................ 15-23

..................................... 15-24

xvi Contents

Utility Library for Microsoft COM Components

Referencing U tility Classes ......................... 16-2

Utility Library Classes

Class MWUtil Class MWFlags Class MWStruct Class MWField

.................................... 16-3

................................... 16-10

................................... 16-23

............................. 16-3

.................................. 16-16

Class MWComplex ................................ 16-24

Class MWSparse Class MWArg

.................................. 16-26

..................................... 16-29

Enumerations

Enum mwArrayFormat Enum mwDataType Enum mwDateFormat

..................................... 16-31

............................ 16-31

............................... 16-31

............................. 16-32

Examples

Magic Square Example for .NET .................... A-2

Using Load and Save

UsingtheMCRDataInterface

Passing MCR Option Values from a C# Application

Using WaitForFiguresToDie to Block Execution

............................... A-2

...................... A-2

... A-2

...... A-2

Using functions engOpen and engEvalString from the

MATLAB Engine API in a C# Program

Sample Applications (C#)

Sample Applications (Visual Basic .NET)

Quick Start to Implementing a WebFigure

Working with Functions that Return a Single

WebFigure as the Function’s Only Output

........................... A-3

............. A-2

............ A-3

........... A-3

......... A-3

xvii

Working With Functions That Return Multiple

WebFigures In an Array as the Output

............ A-4

Attaching a WebFigure

Referencing a WebFigure Attached to the Local

Server

Referencing a WebFigure Attached to a Remote

Server

Using Global Application Class (Global.asax) to Create

WebFigures at Server Start-Up

Creating an d Modifying a MATLAB Figure

Working with MATLAB Figures

Working with Images

Building a Remotable Component Using the

Deployment Tool

Building a Remotable Component Using the mcc

Command

.......................................... A-4

....................................... A-5

............................. A-4

................... A-4

........... A-4

..................... A-5

.............................. A-5

................................ A-5

xviii Contents

Using Native .NET Structure and Cell Arrays

COM Components

Utility Library Classes for COM Components

................................. A-5

........ A-5

........ A-6

Glossary

Index

xix

xx Contents

Getting Started

• “Product Overview” on page 1-2

• “Before You Use MATLAB

• “Deploying a Component Using the Magic Square Example” on page 1-9

• “Next Steps” on page 1-34

Builder NE” on page 1-5

1 Getting Started

Product Overview

MATLAB Compiler Extension

MATLAB®Builder™ NE is an extension to MATLAB®Compiler™. The builder converts MATLAB MATLAB code written by the MATLAB programmer. All MATLAB code to be compiled must be in the form of a function. Each MATLAB Builder NE component contains one or more classes, each providing an interface to the MATLAB functions in the MATLAB code.

In this section...

“MATLAB®Compiler Extension” on page 1-2

“Common Language Specification (CLS) Compliancy” on page 1-2

“Data Conversion, Indexing, and Array Formatting” on page 1-3

“Error Handling” on page 1-3

“Remotable Components” on page 1-3

“COM Components” on page 1-3

“Supported Microsoft .NET Framework Versions” on page 1-4

“Limitations of Support” on page 1-4

functions to .NET methods that encapsulate

1-2

When you package and distribute the application to your users, you include supporting files genera ted by the builder as well as the MATLAB Compiler Runtime (MCR). For more information about the MCR, see “What Is The MATLAB Compiler Runtime (MCR)?” in the MATL AB Compiler documentation.

For more information about how this product works with MATLAB Compiler, see “Writing Deplo yable MATLAB Code”.

Common Language Specification (CLS) Compliancy

CLS is an acronym for Common Language Specification.CLSisasubsetof language features supported by the .NET common language runtime (CLR). MATLAB Builder NE classes are CLS compliant—they are guaranteed to integrate seamlessly with all .NET programming languages. CLS-compliant

Product Overview

languages are guaranteed to interoperate w ith other CLS-compliant components and tools.

UsethebuildertopackageMATLABfunctionssothat.NETprogrammers can access them from any CLS-compliant language.

Data Conversion, Indexing, and Array Formatting

The builder provides robust data conversion, indexing, and array formatting capabilities. For example, to support MATLAB data types, the MATLAB Builder NE product provides the MATLAB Builder NE your managed application to convert native arrays to MATLAB arrays and vice versa.

MWArray assembly. You reference this assembly in

MWArray data conversion classes in the

Error Handling

The builder also provides custom error handling so that errors originating from MATLAB functions are reported as standard managed exceptions. The error description contains specific references to the MATLAB code, thus simplifying the debugging process.

Remotable Components

Remotable .NET components allow you to access MATLAB functionality remotely, as part of a distributed system consisting of multiple applications, domains, browsers, or machines. They also enable your component to be deployed in other capacities, such as a Windows

For detailed instructions about creating remotable .NET components, see Chapter 8, “Sharing Components Across Distributed Applications Using .NET Remoting”.

service, for example.

COM Components

You can also use the builder to create COM components. COM stands for Component Object Model, which is a software architecture developed by Microsoft interfaces that allow applications and other components to access the features of the objects. COM objects are accessible through Microsoft

to build com ponent-based applications. COM objects expose

Visual Basic®,

1-3

1 Getting Started

C++, or any lang uage that supports CO M objects. For more information about creating and accessing COM components, see Chapter 12, “Creating and Installing COM Components” and Chapter 13, “Programming with COM Components Created by the MATLAB

Builder NE Product”.

Supported Microsoft .NET Framework Versions

As of this rele ase, version s 2.0, 3.0, and 3.5 of the Microsoft .NET Framework are supported.

All of these supported releases are based on the CLS 2.0 specification.

Specifying of the Framework installed on your system.

0.0 as the .NET Framework indicates to supply the latest version

Limitations of Support

MATLAB Builder NE provides a wide variety of support for various CLS-compliant types and objects. However, MATLAB (MCOS) objects are not supported as inputs or outputs for compiled or deployed functions.

1-4

Before You Use MATLAB Builder NE

In this section...

“Your Role in the .NET Application Deployment Process” on page 1-5

“What You Need to Know” on page 1-7

“Install Required Products” on page 1-8

Your Role in the .NET Application Deployment Process

Depending on the size of your organization, you may play one or more roles in the process of successfully deploying a .NET application. For example, your role may be to:

• Analyze user requirements and satisfy them by writing a program in

MATLAB code.

• Implement the infrastructure needed to successfully deploy a .NET

application to the Web.

Before You Use MATLAB®Builder™ NE

• Create a remotable component that can be shared across distributed

systems.

• Perform tasks associated with numerous roles (particularly in a smaller

organization).

The table Application Deployment Roles, Goals, and Tasks on page 1-6 describes some of the different roles, or jobs, that MATLAB Builder NE users typically perform and which tasks they would most likely perform when running the examples in this documentation.

1-5

1 Getting Started

Application Deployment Roles, Goals, and Tasks

Role Goals Task To A chieve Goal

MATLAB prog rammer

• Understand the

end-user business requirements and the mathematical models needed to support them.

• Build an executable

component with MATLAB tools (usually with support from a .N ET programmer).

• Package the

component for distribution to end users.

• Pass the packaged

component to the .NET programmer for rollout and further integration into the end-user environment.

See “Magic Square Example: MATLAB Programmer Tasks” on page 1-10.

1-6

.NET programmer

• Write.NETcodeto

execute the .NET assembly built by the MATLAB programmer.

• Roll out the packaged

component and integrate it into the end user’s environment.

See “Magic Square Example: .NET Programmer Tasks” on page 1-23.

Before You Use MATLAB®Builder™ NE

Application Deploym ent Roles, Goals, and Tasks (Continued)

Role Goals Task To A chieve Goal

• Use the component

in enterprise .NET applications, adding and modifying code as needed.

• Address data

conversion issues that may be encountered, according to the end user’s specifications.

• Ensure the final

.NET application executes reliably in the end user’s environment.

External user Execute the

solution created by MATLAB and .NET programmers.

Run the deployed application (outside the scope of this document).

What You Need to Know

To use the MATLAB Builder NE product, specific requirements exist for each user role.

1-7

1 Getting Started

Role

MATLAB programmer • A basic knowledge of MATLAB,

Requirements

and how to work with:

- MATLAB data types

- MATLAB structures

.NET programmer • Exposure to:

- A CLS-compliant programming

language

- .NET Framework

• Knowledge of object-oriented

programming concepts

Install Required Products

Install the following products to run the example described in this chapter:

• MATLAB

• MATLAB Compiler

• MATLAB Builder NE

1-8

• AsupportedCorC++compiler

For more information about product installation and requirements, see “Installation and Configuration”.

Deploying a Component Using the Magic Square Example

In this section...

“About This Example” on page 1-9

“Magic Square Example: MATLAB Programmer Tasks” on page 1-10

“Using the Command Line to Create .NET Components” on page 1-17

“Magic S q u a re Example: .NET Programmer Tasks” on page 1-23

About This Example

This example shows you how to transform a simple MATLAB code function into a deployable MATLAB Builder NE component.

The Magic Square example shows you how to create a .NET component named other files needed to deploy your application.

MagicSquareComp, which contains the magicSquareClass class and

The

magicSquareClass wraps a M ATLA B function, makesquare,which

computes a magic square. A magic square is a matrix containing any number of rows. These rows, added horizontally, vertically, or diagonally, equate to the same value. MATLAB contains a function, create magic squares of any dimension.

Note TheexampleshereusetheWindowsdeploytool GUI, a graphical front-end interface to MATLAB Compiler software. For information about how to perform these tasks using the command-line interface to MATLAB Compiler software, see the

Note Ifyouwishtocreatearemotable component, and for information about what this entails, see Chapter 8, “Sharing Components Across Distributed Applications Using .NET Remoting”.

mcc reference page.

magic,thatyoucanuseto

1-9

1 Getting Started

Magic Square Exa

The MATLAB progr

Key Tasks for th

Task

1. Prepare to run the example by copying the MATLAB example files into a work folder.

2.TesttheMATLABcodetoensure it is suitable for dep l oyment.

3. Create a .NET component (encapsulating your MATLAB code in a .NET class) by running the Build function in

4. Prepa Tool by d files to compon

5. Copy

re to run the Packaging

etermining what additional include with the deployed ent.

the output.

e MATLAB Programmer

deploytool.

mple: MATLAB Programmer Tasks

ammer usually performs the following tasks.

Reference

“Copying the Example Files” on page 1-10

“Testing the MATLAB File You Want to Deploy” on page 1-11

“Building Your Component” on page 1-12

“Packaging Your Component (Optional)” on page 1-16

“Copyi on pag

ng the Package You Created” e1-17

1-10

Note The MA TLAB Builder NE examples are in

matlabroot\toolbox\dotnetbuilder\Examples\VS8\NET.Thisexample

assumes the work folder is on drive

ying the Example Files

Cop

Preparetoruntheexamplebycopying needed files into your work area as follows:

vigate to

1 Na

tlabroot\toolbox\dotnetbuilder\Examples\VS8\NET\MagicSquareExample

D:.

Deploying a Component Using the Magic Square Example

Tip matlabroot is the MATLAB root folder (where MATLAB is installed). To find the value of this variable on your system, type

matlabroot at a

MATLAB command prompt.

2 Copy the MagicSquareExample folder to a work area, for example,

D:\dotnetbuilder_examples. Avoid using spaces in your folder

names, if possible. The example files should now reside in

D:\dotnetbuilder_examples\MagicSquareExample.

3 Using a command prompt, navigate to

D:\dotnetbuilder_examples\MagicSquareExample by switching to the D:

drive and entering cd \dotnetbuilder_examples\MagicSquareExample.

Testing the M ATLAB File You Want to Deploy

In this example, you test a precreated MATLAB file (magicsquare .m) containing the predefined MATLAB function baselinetocomparetotheresultsofthe function when it is finally wrappered as a deployable .NET component.

magic,inordertohavea

1 Using MATLAB, locate the magicsquare.m file at

D:\dotnetbuilder_examples\MagicSquareExample\MagicSquareComp.

Thecontentsofthefileareasfollows:

function y = makesquare(x ) %MAKESQUARE Magic square o f size x. % Y = MAKESQUARE(X) returns a magic square of size x. % This file is used as an example for the MATLAB % Builder NE product.

y = magic(x);

2 At the MATLAB command prompt, enter makesq uare(5) and view the

results. The output should appear as follows:

17 24 1 8 15 23 5 7 14 16

1-11

1 Getting Started

4 6 13 20 22 10 12 19 21 3 11 18 25 2 9

About MATLAB Function Signatures. MATLAB supports multiple signatures for function calls.

The generic MATLAB function has the following structure:

function [Out1,Out2,...,varargout]=foo(In1,In2,...,vararg in)

To the left of the equal sign, the function specifies a set of explicit and optional return arguments.

To the right of the equal sign, the function lists explicit input arguments followed by one or more optional arguments.

All arguments represent a specific MATLAB type.

1-12

When the MATLAB Builder NE product processes your MATLAB code, it creates several overloaded methods that implement the MATLAB functions. Each of these overloaded methods corresponds to a call to the generic MATLAB function with a specific number of input arguments. In addition to these methods, the builder creates another method that defines the return values of the MATLA B function as an input argument. This method simulates the

feval external API interface in MATLAB.

Building Your Component

You create a .NET component by using the Deployment Tool GUI to build a .NET class that wraps around the sample MATLAB code discussed in “Testing the MATLAB File You Want to Deploy” on page 1-11.

Use the following information when creating your component as you work through this example:

Project Name

Class Name

File to compile

magicSquareComp

magicSquareClass

makesquare.m

Deploying a Component Using the Magic Square Example

1 Start MATLAB.

2 Type deploytool at the comman d prompt and press Enter. Th e

deploytool GUI opens.

3 Create a deployment project using the Deployment Project dialog:

a TypethenameofyourprojectintheName field.

b Enter the location of the project in the Location field. Alternately,

navigate to the location.

c Sele ct the target for the deployment project from the Target drop-down

menu.

d Click OK.

Creating a .NET Project

4 On th

e Build tab:

• If yo

• If y

u are building a COM application, click Add files

ou are building a .NET application, click Add class. Type the name he class in the Class Name field, designated by the letter “c”:

of t

1-13

1 Getting Started

For this class, add files you want to compile by clicking Add files.To add another class, click Add class.

Note You may optionally add supporting files. For examples of these files, see the

deploytool Help. To add these files, in the Shared Resources

and Helper Files area:

a Click Add files/directories

b Click Open to select the file or files.

5 When you complete your changes, click the Build button ( ).

How the .NET Builder Creates a Component. To create a component, the

builder does the following:

1 Generates C# code to implement your component

1-14

The first step of the build process generates two C# files: a component data file and a component wrapper. The component data file contains static information for the component. The wrapper contains the implementation code for the .NET component and provides a .NET application programming interface (API) for the MATLAB f unctions you add to the project at design time.

2 Compiles the C# code and generates /distrib and /src subfolders

Thesecondstepofthebuildprocesscompiles the two C# files produced in step 1, creating a managed assembly for the component.

The MATLAB Builder NE product creates two subfolders under the project folder:

project-folder/src and project-folder/distrib.These

subfolders contain the following files.

Files in the Project Subfolders

Deploying a Component Using the Magic Square Example

Subfolder

src

distrib

Files

ComponentName

_mcc_component_data.cs

ClassName1.cs ...

ClassNameN.cs

ComponentName.dll

ComponentName.pdb

ComponentName.xml

ComponentNameNative.dll

MWArray.xml

component_name.xml component_name_overview.html

readme.txt

Description

C# component data file

C# wrapper class file

.NET component assembly

.NET component debug file (Debug builds only)

.NET component XML d ocumentation file

Native .NET DLL (See “Remotable Components” on page 1-3 for information).

Documentation template files. See “Using Enhanced XML Documentation Files” on page 3-26.

Readme file for users

Note When you build your project, you can specify the compilation of a private or shared assembly. A private assembly is copied to an application subfolder and is owned exclusively by the application. A shared assembly usually resides in the Global Assembly Cache, and can be directly referenced by multiple applications.

1-15

1 Getting Started

For information about how the builder works in conjunction w ith MATLAB Compiler, see “How D oe s MATLAB

Compiler Software Build My

Application?” on page 2-4 in the MATLAB Compiler User’s Guide.

Packaging Your Component (Optional)

Bundling the .NET component with additional files you can distribute to users is called packaging. You perform this step using the packaging function of

deploytool. Alternately, copy the contents of the distrib folder and the

MCR Installer to a local folder of your choice. If you are creating a shared component and want to include additional code with the component, you m ust perform this step.

1 On the Package tab, add the MATLAB Compiler Runtime (the MCR) by

clicking Add MCR.

2 Next, add others files useful for end users. The readme.txt file contains

important information about others files useful for end users. To package additional files or folders, click Add file/directories, select the file or folder you want to package, and click Open.

3 In the Deployment Tool, click the Packaging button ( ).

4 On Windo

other t

distri

ws, the package is a self-extracting executable. O n platforms

han Windows, it is a

folder contains the files you specified.

.zip file. Verify that the contents of the

1-16

Note W

VCRED

of Mic appl

What

lowing files into a single self-extracting executable,

fol

•

com

• co

hen the self-extracting executable is uncompressed on a system,

SIT_X86

is installed. VCREDSIT_X86 installs run-time components

rosoft Visual C++ libraries necessary for running Visual C++

ications.

Happens in the Packaging Process?. Thepackageprocesszipsthe

ponentName.dll

mponentNameNative.dll

componentName.exe:

Deploying a Component Using the Magic Square Example

Note See “Remotable Components” on page 1-3 and Chapter 8, “Sharing Components Across Distributed Applications Using .NET Remoting” for more details.

• componentName.xml

• componentName.pdb (if the Debug option is selected)

MCRInstaller.exe (if the Include MCR option is selected)

•

_install.bat (script run by the self-extracting executable)

•

How the MCR Is Shared Among Classes. The builder creates a single

MCR instance for each MATLAB Builder NE class in an application. This MCR instance is reused and shared among all subsequent class instances within the component, resulting in more efficie nt memory usage and eliminating the MCR startup cost in each subsequent class instantiation. All class instances share a single MATLAB workspace and share global variables in the MATLAB files used to build the component.

The following example creates a .NET component called

mycomponent

containing a single .NET class named myclass with methods foo and bar.

If and when multiple instances of only one MCR is initialized, and it is shared by all instances of

mcc -B 'dotnet:mycomponent,myclass,2.0,Private,local' foo.m bar.m

myclass are instantiated in an application,

myclass.

Copying the Package You Created

Copy the package that you created from the distrib folder to the local folder of your choice or send them directly to the .NET programmer.

Using the Command Line to Create .NET Components

Instead of using the Deployment Tool to create .NET components, you can use the

mcc command.

1-17

1 Getting Started

The following sections describe the subset of mcc command options that you need to create .NET components. The sections provide detailed

mcc syntax

with examples.

To learn more about the Compiler documentation.

Command-Line Syntax Description

The following command defines the complete mcc command syntax with all required and optional arguments used to create a .NET component. Brackets indicate optional parts of the syntax.

mcc - W 'dotnet:component_name,class_name,

0.0|framework_version, Private|Encryption_Key_Path,loca l|remote' file1 [file2...fileN] [,file2,...,fileN]},...

Note For complete information about the mcc command, including the -W option, see mcc in the function reference section of this user’s guide.

Using the Command Line to Start the Deployment Tool GUI

Desired Result Command

Starts Deployment Tool GUI with the New/Open dialog active

Starts Deployment Tool GUI and loads

project_name

Starts Deployment Tool command line interface and build s

project_name after

initializing

deploytool (default)

deploytool -n

deploytool project_name.prj

deploytool -build project_name.prj

mcc command and all of its options, see the MATLAB

[class{class_name:file1

[-d output_dir_path] -T link:lib

1-18

Desired Result Command

Starts Deployment

deploytool -package project_name.prj

Tool command line interface and packages

project_name after

initializing

Displays M ATLAB Help for the

deploytool

deploytool -?

command

Using the .NET Bundle Files to Simplify the Command

To simplify the command line used to create .N ET components, you can use the .NET Builder bundle file, named components easier. When using this bundle file, you must still pass in the five parts (including donothavetospecifythe

Deploying a Component Using the Magic Square Example

dotnet, to make creating .NET

local|remote)ofthe-W argument text string, however, you

-T option.

The following example creates a .NET component called

mycomponent

containing a single .NET class named myclass with methods foo and bar. When used with the

-B option, the word dotnet specifies the name of the

predefined .NET Builder bundle file.

mcc -B 'dotnet:mycomponent,myclass,2.0,encryption_keyfil e_pa th,local'

foo.m bar.m

In this example, the builder uses the .NET Framework version 2.0 to compile the component into a shared assembly using the key file specified in

encryption_keyfile_path to sign the shared component.

See “Suppo rte d Microsoft .NET Framework Versions” on page 1-4 for a list o f supported framework versions.

Example: Creating a .NET Component Namespace

The following example creates a .NET component from tw o MATLAB files

foo.m and bar.m.

mcc -B 'dotnet:mycompany.mygroup.mycompo nent ,myclass,0.0,Private,local'

1-19

1 Getting Started

foo.m bar.m

The example creates a .NET component named mycomponent that has the following namespace: .NET class,

myclass, which contains methods foo and bar.

mycompany.mygroup. The component contains a single

To use

myclass, place the following statement in your code:

using mycompany.mygroup;

See “Suppo rte d Microsoft .NET Framework Versions” on page 1-4 for a list o f supported framework versions.

Example: Adding Multiple Classes to a Component

The following example creates a .NET component that includes more than one class. This example uses the optional command.

mcc -B 'dotnet:mycompany.mycomponent,myclass,2.0,Private,local' foo.m bar.m

class{myclass2:foo2.m,bar2.m}

The example creates a .NET component named mycom ponent with two classes:

•

myclass has methods foo and bar

• myclass2 has methods foo2 and bar2

See “Suppo rte d Microsoft .NET Framework Versions” on page 1-4 for a list o f supported framework versions.

class{...} argument to the mcc

1-20

TheMATLABCompilerBuildProcess

To generate and package an application, the use r:

1 Writes an application o r component in MATLAB

2 Invokes the MATLAB Compiler, which:

a Examines the input MATLAB files and the external dependency

database to determine the complete list of all functions used by the application or component. As part of this p rocess, MATLAB Compiler

Deploying a Component Using the Magic Square Example

determines which files are not able to be compiled and automatically excludes them.

b Dete rm ines w hi ch functions are to be made publicly visible (for example,

those that can be called from another product or environment).

c Generates the appropriate interface code files based on the public

function list and the complete function list from the preceding steps. The interface code g enerated is also dependent on what target the user wants to create (for example, a Java™ component, a standalone executable, or a Microsoft

d Packages compilable functions into a CTF archive, creating a file on the

Excel®add-in).

user’s disk. This archive is embedded by default in the binary executable.

e Optionally, invokes target specific compiler to generate a binary

application or component from the files in C and the interface code libraries provided by The MathWorks.

3 Locates the install package for the MATLAB Compiler Runtime (MCR).

4 Collects together the binary, the C TF archive, and the MCR installer (along

with other optional, user-specified files) for the user.

The deployment GUI (

deploytool) automates many o f the steps in the

process for user convenience.

1-21

1 Getting Started

1-22

Deploying a Component Using the Magic Square Example

Magic Square Exa

The following ta

Key Tasks for th

Task

1. Ensure you have the needed files from the MATLAB programmer before proceeding.

2. Use the component in a .NET application. Compile and run the component to ensure it produces the same results as your MATLAB code.

3. Archive and distribute the output to end users.

4. Integ MATLAB B existin

5. Verify your .NET application works as expected in your end user’s deployment environment.

rate classes generated by the

g .NET applications.

sks are usually performed by the .NET programmer.

e.NETProgrammer

uilder NE product into

mple: .NET Programmer Tasks

Reference

“Gathering Files Needed for Deployment” on page 1-23

“Using the Component in an Application” on page 1-25

“Distributing the Component to End Users” on page 1-28

“Integrating .NET Classes Generated by MATLAB into a .NET Application” on page 1-28

“Building and Testing the .NET Application” on page 1-33

Gathering Files Needed for Deployment

re beginning, verify you have access to the following files, created by

Befo

ATLAB programmer in “Copying the Packag e You Created” on page

the M 1-17. T copy

• MCR

•

Se in o

rom the MATLAB Builder NE help tree (left p ane of MATLAB Product Help).

hefollowingfilesarerequiredtodeploytouserswhodonothavea

of MATLAB installed:

Installer. For locations of all MCR Installers, run the

mand.

com

adme.txt

e “Packaging Your Component (Optional)” on page 1-16 for more

formation about these files. You will also want to communicate the location

f the MWArray Class Library Reference. You can also browse to this library

mcrinstaller

1-23

1 Getting Started

How Component Deployment Works. To deploy the component, run the

MCR installer. The installer does the following:

1 Installs the MCR (if not already installed on the target machine)

2 Installs the component assembly in the folder from which the installer is

run

3 Copies the MWArray assembly to the Global Assembly Cache (GAC), as

part of installing the MCR

Note Since installing the MCR requires write access to the system registry, you must have administrator privileges to run the MCR Installer.

Note On target machines where the MCR Installer is run, the MCR Installer puts the

installation_folder\toolbox\dotnetbuilder\ bin\architecture\framework_version

MWArray assembly in

1-24

See “Suppo rte d Microsoft .NET Framework Versions” on page 1-4 for a list o f supported framework versions.

The MCR Installer uses a standard Microsoft installation file that provides the following features:

• Integrates with

Add/Remove Programs in the Control Panel

• Checks software prerequisites before installation

• Checks for proper user permissions

• Rolls back the system to its prior state on installation failure

• Supports component versioning

Deploying a Component Using the Magic Square Example

Using the Component in an Application

1 Write source code for an application that uses the .NET component created

in “Building Your Component” on page 1-12.

The C# source code for the sample application for this example is in

MagicSquareExample\MagicSquareCSApp\MagicSquareApp.cs.

The program listing is shown here.

Tip Although MATLAB Builder NE generates C# code for the Ma gicS quare component and the sample application is in C#, applications that use the component do not need to be coded in C#. You can access the component from any CLS-compliant .NET language. For examples, see Chapter 5, “Sample Applications (Microsoft

MagicSquareApp.cs

Visual Basic .NET)”.

// *******************************************************************************

// MagicDemoApp.cs

// This file is an example application for the MATLAB Builder NE product.

// *******************************************************************************

using System;

using MathWorks.MATLAB.NET.Utility;

using MathWorks.MATLAB.NET.Arrays;

using MagicDemoComp;

namespace MathWorks.Demo.MagicSquareApp

{

1-25

1 Getting Started

/// <summary>

/// The MagicSquareApp demo class computes a magic square of the user-specified size.

/// </summary>

/// <remarks>

/// args[0] - a positive intege r representing the array size.

/// </remarks>

class MagicDemoApp

{

#region MAIN

/// <summary>

/// The main entry point for the application.

/// </summary>

[STAThread]

static void Main(string[] args)

{

MWNumericArray arraySize= null;

MWNumericArray magicSquare= null;

1-26

try

{

// Get user-specified command line arguments or set default

arraySize= (0 != args.Length) ? System.Do uble.Parse(args[0]) : 4;

// Create the magic square object

MagicSquareClass magic= new MagicSquare();

// Compute the magic square and print the result

magicSquare= (MWNumericArray)magic.makesquare((MWArray)arraySize);

Console.WriteLine("Magic square of order {0}\n\n{1}", arraySize, magicSquare);

// Convert the magic square array to a two-dimensional native double array

double[,] nativeArray= (double[,])magicSquare.ToArray(MWArrayComponent.Real);

Console.WriteLine("\nMagic square as native array:\n");

// Display the array elements:

for (int i= 0; i < (int)arraySize; i++)

for (int j= 0; j < (int)arraySize; j++)

#endregion

}

Deploying a Component Using the Magic Square Example

Console.WriteLine("Element({0},{1})= {2}", i, j, nativeArray[i,j]);

Console.ReadLine(); // Wait for user to exit application

}

catch(Exception exception)

{

Console.WriteLine("Error: {0}", exception);

}

2 Build the application using Visual Studio

.NET.

Note In the project file for this example, the MWArray assem bly and the magic square compone nt assembly have been prereferenced. Any references preceded by an exclamation point require you to remove the reference and rereference the affected assembly.

Note Microsoft .NET Framework version 2.0 is not supported by Visual Studio 2003.

a Open the project file for the Magic Square example

(

MagicSquareCSApp.csproj)inVisualStudio.NET.

b If necessary, add a reference to the MWArray component in

matlabroot\toolbox\dotnetbuilder\bin\ architecture\framework_version.

See “Supported Microsoft .NET Framework Versions” on page 1-4 for a list of supported framework versions.

c If necessary, add a reference to the Magic Square component

(

MagicSquareComp), which is in the distrib subfolder.

1-27

1 Getting Started

Distributing the Component to End Users

If you bundled the component as a self-extracting executable, paste it in a folder on the development machine and run it. If you are using a bundled with WinZip, unzip and extract the contents to the development machine.

.zip file

Integrating .NET Classes Generated by MATLAB into a .NET Application

• “Classes and Methods” on page 1-28

• “Component and Class Naming Conventions” on page 1-29

• “Versioning” on page 1-29

• “Managing Data Conversion Issues with M A TLA B

Conversion Classes” on page 1-29

• “Automatic Casting to MATLAB Types” on page 1-31

• “Adding Fields to Data Structure s and Data Structure Arrays” on page 1-32

Builder NE Data

1-28

• “About MATLAB Array Indexing” on page 1-32

• “Accessing Your Component On Another Computer” on page 1-32

Classes and Methods. T he builder project contains the files and settings

needed by the MATLAB Builder NE product to create a deployable .NET component. A project specifies information about classes and methods, including the MATLAB functions to be included.

The builder transforms MATLAB functions that are specified in the component’s project to methods belonging to a managed class.

When creating a component, you must provide one or more class names as well as a component name. The component name also specifies the name of the assembly that implements the component. The class name denotes the name of the class that encapsulates MATLAB functions.

To access the features and operations provided by the MATLAB functions, instantiate the managed class generated by the builder, and then call the methods that encapsulate the MATLAB functions.

Deploying a Component Using the Magic Square Example

Component and Class Naming Conventions. Typically you should specify names for components and classes that will be clear to programmers who use your components. Fo r example, if you are encapsulating many MATLAB functions, it helps to determine a scheme of function categories and to create a separate class for each category. Also, the n ame of each class should be descriptive of what the class does.

The .NET Framework General Reference recommends the use of Pascal case for capitalizing the names of identifiers of three or more characters. That is, the first letter in the identifier and the first letter of each subsequent concatenated word are capitalized. For example:

MakeSquare

In contrast, MATLAB programmers typically use all lowercase for names of functions. For example:

makesquare

By convention, the MATLAB Builder NE examples use Pascal case.

Valid characters are any alpha or numeric characters, as well a s the underscore (

_) character.

Version ing. The builder supports the standard versioning capabilities provided by the .NET Framework.

Note You can make side-by-side invocations of multiple versions of a component within the same application only if they access the same version of the MCR.

Managing Data Conversion Issues with MATLAB Builder NE Data Conversion Classes. To support data conversion between managed types

and MATLAB types, the builder provides a set of data conversion classes derived from the abstract class,

MWArray.

When you invoke a method on a component, the input and output parameters are a derived type of one of the

MWArray subclasses explicitly, or, in many cases, pass the

MWArray. To pass parameters, you can either instantiate

1-29

1 Getting Started

parameters as a managed data type and rely on the implicit data conversion feature of .NET Builder.

Overview of Classes and Methods in the Data Conversion Class Hierarchy

The data conversion classes are built as a class hierarchy that represents the major MATLAB array types.

Note See “Overview” on page 10-7 for an introduction to the classes and see MWArray Class Library Reference (available online only) for details about this class library.

The root of the hierarchy is the MWArray abstract class. The MWArray class has the following subclasses representing the major MATLAB types:

MWNumericArray, MWLogicalArray, MWCharArray, MWCellArray,and MWStructArray.

1-30

MWArray anditsderivedclassesprovidethe following functionality:

• Constructors and destructors to instantiate and dispose of MA TLAB arrays

• Properties to get and set the array data

• Indexers to support a subset of MATLAB array indexing

• Implicit and explicit data conversion operators

• General methods

Advantage of Using Data Conversion Classes

The MWArray data conversion classes allow you to pass most native .NET value types as parameters directly without using explicit data conversion. There is an implicit cast operator for most native numeric and string types that will convert the native type to the appropriate MATLAB array.

Deploying a Component Using the Magic Square Example

Automatic Casting to MATLAB Types.

Note Because the conversion process is automatic (in m ost cases), you do not

need to understand the conversion process to pass and return arguments with MATLAB Builder NE components.

In most instances, if a native .NET primitive or array is used as an input parameter in a C# program, the builder transparently converts it to an instance of the appropriate

MWArray class before it is passed on to the

component method. The builder can convert most CLS-compliant string, numeric type, or multidimensional a rray of these types to an appropriate

MWArray type.

Note This conversion is transparent in C# applications, but might require an explicit castin g operator in other languages, for example,

op_implicit

in Visual Basic®.

Here is an example. Consider the .NET statement:

result = theFourier.plotfft(3, data, interval);

In this statement the third argument, namely interval,isofthe.NET native type 1-by-1 double

System.Double. The builder casts this argument to a MATLAB

MWNumericArray type (which is a wrapper class containing a

MATLAB double array).

See “D ata Conversion Rules” on page 10-4 for a list of all the data types that are supported along with their equivalent types in the MATLAB product.

Note There are some data types commonly used in the MATLAB product that are not available as native .NET types. Examples are cell arrays, structure arrays, and arrays of complex numbers. Represent these array types as instances of

MWCellArray, MWStructArray,andMWNumericArray,

respectively.

1-31

1 Getting Started

Adding Fields to Data Structures and Data Structure Arrays. When

adding fields to data structures and data structure arrays, d o so using standard programming techniques. Do not use the

set command as a

shortcut.

For examples of how to correctly add fields to data structures and data structure arrays, see the programming examples in Chapter 4, “Sample Applications (C#)” and Chapter 5, “Sample Applications (Microsoft

Visual

Basic .NET)”.

About MATLAB Array Indexing. .NET Builder provides indexers to support a subset of MATLAB array indexing.

Note If each element in a large array returned by a .NET Builder component is to be indexed, the returned MATLAB array should first be converted to a native array using the

toArray() method. This results in much better

performance.

1-32

Don’t keep the array in MATLAB type; convert it to a native array first. See Chapter 1 , “Getting Started” for an example of native type conversion.

Accessing Your Component On Another Computer. To implement your .NET component on a computer other than the one on which it was built:

1 If the component is not already installed on the machine where you want

to develop your application, run the self-extracting executable that you created in “Deploying a Component Using the Magic Square Example” on page 1-9.

This step is not necessary if you are developing your application on the same machine where you created the .NET component.

2 Reference the .NET component in your Microsoft

Visual Studio®project or

from the command line of a CLS-compliant compiler.

You must also add a reference to the

matlabroot\toolbox\dotnetbuilder\bin\architecture\framework_version.

MWArray component in

Deploying a Component Using the Magic Square Example

See “Supported Microsoft .NET Framework Versions” on page 1-4 for a list of supported framework versions.

3 Instantiate the generated .NET Builder classes and call the class methods

as you would with any .NET class. To marshal data between the native .NET types and the MATLAB array type, you need to use either the

MWArray data conversion classes or the MWArray native API. See MWArray

Class Library Reference (available online only) for details about the

MWArray API for this class library.

Building and Testing the .NET Application

1 Build and test the .NET application as you would any application.

2 Create an application installation package for end users that includes

the files required for the .NET Builder components that encapsulate the MATLAB functions.

1-33

1 Getting Started

Next Steps

After you create and distribute the initial application, you probably want to continue to enhance it. Pointers to documentation detailing some of the more commontasksyouperformasyoudevelopyour application are listed here.

Writing .NET applications that can access .NET methods that encapsulate MATLAB code

Sample applications that access methods developed in MATLAB

Deploying .NET components over the Web

Creating a remotable component or learning about remotable components

Chapter 3, “Using Components Created by the MATLAB NE Product”

Chapter 4, “Sample Applications (C#)” and Chapter 5, “Sample Applications (Microsoft Basic .NET)”

Chapter 6, “Deploying a MATLAB Figure Over the Web Using WebFigures”

Chapter 8, “Sharing Components Across Distributed Applications Using .NET Remoting”

Visual

Builder

1-34

Writing Deployable MATLAB Code

• “The MATLAB Application Deployment Products” on page 2-2

• “Building Your Application with the Application Deployment Products and

the Deployment Tool” on page 2-4

• “Guidelines for Writing Deployable M ATLA B Code” on page 2-10

• “Working with MATLAB Data Files Using Load and Save” on page 2-14

2 Writing Deployable MATLAB

Code

The MATLAB Application Deployment Products

The MATLAB S

Product

MATLAB Compiler

MATLAB Builder NE

MATLAB Builder JA

MATLAB expert

No IT experience

MATLAB

Programmer

The followin

No access to IT systems

g tables summarizes the target applications supported by each

product.:

uite of Applic ation Deployment Products

Target

CandC++

Create Standalone Executables?

Create Function Libraries?

YesYesYesNo standalones and libraries

C# .NET

No Yes Yes Yes components Visual Basic COM components

Java

No Yes Yes Yes components

Develops model

Uses the builder tools to create a component that is given to the business service developer

Create Applications

Create Web

Applications? with Graphics?

2-2

MATLAB Builder EX

Microsoft Excel add-ins

No Yes Yes No

The MATLAB®Application Deployment Products

Each of the builder products uses the MATLAB Compiler core code to create deployable components.

2-3

2 Writing Deployable MATLAB

Code

Building Your Application with the Application Deployment Products and the

In this section...

“What Is the Difference Between the Deployment Tool and the mcc Command Line?” on page 2-4

“How Does MATLAB®Compiler Software Build My Application?” on page 2-4

“What You Should Know About the Dependency Analysis Function (depfun)” on page 2-5

“Compiling MEX-Files, DLLs, or Shared Libraries” on page 2-6

“The Role of the Component Technology File (CTF Archive)” on page 2-7

Deployment Tool

What Is th and the m

Using th would i Deploy custom the sa

Using

• Perf

• Main

• Pac

Ho Ap

nvoke using the MATLAB Compiler

ment Tool interactive menus and dialogs build

ized to your specification. As such, your MATLAB code is processe d

me way as if you were compiling it using

the Deployment Tool, you:

orm related deployment tasks with a single intuitive GUI.

tain related information in a convenient project file. Your project

e persists between sessions. Your previous project loads automatically

stat

n the Deployment Tool starts. You load previously stored compiler

whe

jects from a prepopulated menu.

pro

kage applications for distribution.

w Does MATLAB Compiler Software Build My plication?

TLAB Compiler software:

e Difference Between the Deployment Tool

cc Command Line?

e D eploym ent Tool (

deploytool) GUI, you perform any function you

mcc command-line interface. The

mcc commands that are

mcc.

2-4

Building Your Application with the Application Deployment Products and the Deployment Tool

1 Parses command-line arguments and classifies by type the files you provide.

2 Analyzes files for dependencies using the Dependency Analysis Function

(

depfun). Dependencies affect deployability and originate from file

contents—functions called by the file. Deployability is affected by:

• File type — MATLAB, Java, MEX, and so on.

• File location — MATLAB, MATLAB toolbox, user code, and so on.

• File deployability — Whether the file is deployable outside of MATLAB

For more information about

depfun, see “What You Should Know About

the D ependency Analysis Function (depfun)” on page 2-5.

3 Validates MEX-files. In particular, me xFun ction entry points are verified).

For more details about MEX-file processing, see “Compiling MEX-Files, DLLs, or Shared Libraries” on page 2-6.

4 Creates a CTF archive from the input files and their dependencies.

For more details about CTF archives see “The Role of the Component Technology File (CTF Archive)” on page 2-7.

5 Generates target-specific wrapper code. For example, the wrapper for a C

main function is very different than the wrapper for a Java interface class.

6 Invokes a third-party target-specif ic compiler to create the appropriate

binary software com ponent (a standalone executable, a Java JAR file, and so on).

For details about how MATLAB Compiler software builds your deployable component, see “The MATLAB

Compiler Build Process” on page 1-20.

What You Should Know About the Dependency Analysis Function (depfun)

MATLAB Compiler uses a dependency analysis function (depfun)to determine the list of necessary files to include in the CT F package. In some cases, this process includes an large number of files. This is often true when MATLAB object classes exist in the compilation and overloaded methods at compile time. Dependency analysis also processes

include/exclude files on each pass (see the mcc flag “-a Add to Archive”).

depfun cannot resolve

2-5

2 Writing Deployable MATLAB

Tip To improve compile time performance and lessen application size, prune

the path with “-N Clear Path”, “-p Add Directory to Path”, or by specifying Toolboxes on Path in the

depfun searches for executable content such as:

• MATLAB files

• P-files

Code

deploytool Settings

• Java classes and

.fig files

•

.jar files

• MEX-files

depfun does not search for data files of any kind (except MAT files). You

must manually

include data files.

Compiling MEX-Files, DLLs, or Shared Libraries

When you compile MATLAB functions containing MEX-files, ensure that

depfun can find them—doing so allows you to avoid many common

compilation problems. In particular, note that:

•

depfun cannot examine MEX-files, DLLs, or shared libraries to determine

their dependencies. Explicitly include all binaries these files require either with the Deployment Tool unde r Settings.

• If you have any doubts that

a MEX-file, DLL, or shared library—manually include it. Do this with either the the Deployment Tool under Settings.

• Not all functions are compatible with MATLAB Compiler. Check the file

mccExcludedFiles.log after your build completes. This file lists all

functions called from your application that you cannot deploy.

mcc -a option or the options on the Advanced tab in the

depfun can find a MATLAB function called by

mcc -a option or by using the options on the Advanced tab in

2-6

Building Your Application with the Application Deployment Products and the Deployment Tool

TheRoleoftheComponentTechnologyFile(CTF Archive)

Each application or shared library produced by MATLAB Compiler has an associated Component Technology File (CTF) archive. The archive contains all the MATLAB based content (MATLAB files, MEX-files, and so on) associated with the compo ne nt.

MATLAB Compiler also embeds a CTF) archive in each generated binary. The CTF houses all deployable files. All MATLAB files encrypt in the CTF archive using the Advanced Encryption Standard (AES) cryptosystem .

If you choose the extract the CTF archive as a separate file the files remain encrypted. For more information on how to extract the CTF archive refer to the references in the following table.

Information on CTF Archive Embedding/Extraction and Component Cache

Product

MATLAB Compiler “Overriding Default CTF Archive

MATLAB Builder NE “Overriding Default CTF Archive

MATLAB Builder JA “Using M CR Component Cache and

MATLAB Builder EX “Overriding Default CTF Archive

Refer to

Embedding Using the MCR Component Cache”

Embedding for Components Using the MCR Component Cache” on page 3-24

MWComponentOptions”

Embedding for Components Using the MCR Component Cache”

2-7

2 Writing Deployable MATLAB

Code

2-8

Building Your Application with the Application Deployment Products and the Deployment Tool

Additional Details

Multiple CTF archives, such as those generated with C OM, .NET, or Excel components, can coexist in the same user application. You cannot, however, mix and match the MATLAB files they contain. You cannot combine encrypted and compressed MATLAB files from multiple CTF archives into another CTF archive and distribute them.

All the M ATLA B files from a given CTF archive associate with a unique cryptographic key. MATLAB files with different keys, placed in the same CTF archive, do not execute. If you want to generate another application with a different mix of MATLAB files, recompile these MATLAB files into a new CTF archive.

MATLAB Compiler deleted the CTF archive and generated binary following a failed compilation, but only if these files did not exist before compilation initiates. Run

Caution Release Engineers and Software Configuration Managers: Do not use build procedures or processes that strip shared libraries on CTF archives. If you do, you can possibly strip the CTF archive from the binary, resulting in run-time errors for the driver application.

help mcc -K for more info rmation.

2-9

2 Writing Deployable MATLAB

Code

Guidelines for Writing Deployable MATLAB Code

In this section...

“Compiled Applications Do Not Process MATLAB Files at Runtime” on page 2-10

“Do Not Rely on Changing Directory or Path to Control the Execution of MATLAB Files” on page 2-11

“Use ismcc and isdeployed Functions To Execute Deployment-Specific Code Paths” on page 2-11

“Gradually Refactor Applications That Depend on Noncom pilable Functions” on page 2-12

“Do Not Create or Use Nonconstant Static State Variables” on page 2-12

Compiled Applications Do Not Process MATLAB Files at Runtime

The MATLAB Compiler was designed so that you can deploy locked down functionality. Deployable MATLAB files are suspended or frozen at the time MATLAB Compiler encrypts them—they do not change from that point onward. This does not mean that you cannot deploy a flexible application—it means that you must design your application with flexibility in mind.Ifyou want the end user to be able to choose between two different methods, for example, they both must be compiled in.

2-10

The MCR only works on MATLAB code that was encrypted when the component was built. Any function or process that dynamically generates new MATLAB code will not work against the MCR.

Some MATLAB toolboxes, such as the Neural Network Toolbox™ product, generate MATLAB code dynamically. Because the MCR only executes encrypted MATLAB files, and the Neural Network Toolbox generates unencrypted MATLAB files, some functions in the Neural Network Toolbox cannot be deployed.

Similarly, functions that need to examine the contents of a MATLAB function file cannot be deployed.

HELP, for example, is dynamic and not available in

Guidelines for Writing Deployable MATLAB®Code

deployed mode. You can use LOADLIBRARY in deployed mode if you provide it with a MATLAB function prototype.

Instead of compiling the function that generates the MATLAB code and attempting to deploy it, perform the following tasks:

1 Run the code once in MATLAB to obtain your generated function.

2 Compile the MATLAB code with MATLAB Compiler, including the

generated function.

Tip Another alternative to using EVAL or FEVAL is using anonymous function handles.

If you require the ability to create MATLAB code for dynamic runtime processing, your end-users must have an installed copy of MATLA B.

Do Not Rely on Changing Director y or Path to Control the Execution of MATLAB Files

In general, good programming practices advise against redirecting a program search path dynamically within the code. Many programmers are prone to this behavior since it mimics the actions they usually perform on the command line. However, this can lead to problems when deploying code.

For example, in a deployed application, the MATLAB and Java paths are fixed and cannot change. Therefore, any attempts to change these paths (using the

If you find you cannot avoid placing

ismcc and isdeployed. See the next section for details.

cd command or the addpath command) fails

addpath calls in your MATLAB code, use

Use ismcc and i sdeployed Functions To Execute Deployment-Specific Code Paths

The isdeployed function allows you to specify which portion of your MATLAB code is deployable, and which is not. Such specification minimizes your compilation errors and helps create m ore efficient, maintainable code.

2-11

2 Writing Deployable MATLAB

For example, you find it unavoidable to use addpath when writing your

startup.m.Usingismcc and isdeployed, you specify when and what is

compiled and executed.

Code

For an example of using a Standalone Application”.

isdeployed, see “Passing Arguments to and from

Gradually Refactor Applications That Depend on Noncompilable Functions

Over time, refactor, streamline, and modul ari ze MATLAB code containing non-compilable or non-deployable functions that use Your eventual goal is “graceful degradation” of no n-deploya ble code. In other words, the code must present the end user with as few obstacles to deployment as possible until it is practically eliminated.

Partition your code into design-time and run-time code sections:

• Design-time code is code that is currently evolving. Almost all code goes

through a phase of perpetual rewriting, debugging, and optimization. In some toolboxes, such as the Neural Network Toolbox product, the code goes through a period of self-training as it reacts to various data permutations and patterns. Such code is almost never designed to be deployed.

• Run-time code, on the other hand, has solidified or become stable—it is in a

finishedstateandisreadytobedeployedbytheenduser.

Consider creating a separate directory for code that is not meant to be deployed or for code that calls undeployable code.

ismcc and isdeployed.

2-12

Do Not Create or Use Nonconstant Static State Variables

Avoid using the following:

• Global variables in MATLAB code

• Static variables in MEX-files

• Static variables in Java code

Guidelines for Writing Deployable MATLAB®Code

The state of these variables is persistent and shared with everything in the process.

Persistent variables can cause problems because the MCR process runs in a single thread. You cannot load more than one of these non-constant, static variables into the same process. In addition, these static variables do not work well in multithrea ded applications.

If you must u se static variables, bind them to instances. For example, defining instance variables in a Java class is preferable to defining the variable as

static.

Note This guideline does not apply to MATLAB Builder EX customers. When programming with Microsoft Excel, you can assign global variables to large matrices that persist between calls.

2-13

2 Writing Deployable MATLAB

Code

Working with MATLAB Data Files Using Load and Save

If you r deployed application uses MATLAB data files (MAT-files), it is helpful to code processing.

LOAD and SAVE functions to manipulate the data and store it for later

• Use

• Specify the data file by full path name or relative to

• All MAT-files are unchanged after

For more information about C TF archives, see “The Role of the Component Technology File (CTF Archive)” on page 2-7.

Use the following example as a template for manipulating your MATLAB data inside, and outside, of MATLAB.

isdeployed to determine if your code is running in or out of the

MATLAB workspace.

ctfroot.

mcc runs. These files are not encrypted

when written to the CTF archive.

Using Load/Save Functions to Process MATLAB Data for Deployed Applications

The following example specifies three MATLAB data files:

•

user_data.mat

• userdata/extra_data.mat

• ../externdata/extern_data.mat

Compile ex_loadsave.m with the following mcc command:

2-14

mcc -mvC ex_loadsave.m -a 'user_data.mat' -a

'./userdata/extra_data.mat' -a '../externdata/extern_data.mat'

loadsave.m

ex_

function ex_loadsave

Working with MATLAB Data Files Using Load and Save

% This example shows how to work with the

% "load/save" functions on data files in

% deployed mode. There are three source data files

% in this example.

% user_data.mat

% userdata/extra_data.mat

% ../externdata/extern_data.mat

% Compile this example with the mcc command:

% mcc -mC ex_loadsave.m -a 'user_data.mat' -a

% './userdata/extra_data.mat'

% -a '../externdata/extern_data.mat'

% All the folders under the current main MATLAB file directory will

% be included as

% relative path to ctfroot; All other folders will have the

% folder

% structure included in the ctf archive file from root of the

% disk drive.

% If a data file is outside of the main MATLAB file path,

% the absolute path will be

% included in ctf and extracted under ctfroot. For example:

% Data file

% "c:\$matlabroot\examples\externdata\extern_data.mat"

% will be added into ctf and extracted to

% "$ctfroot\$matlabroot\examples\externdata\extern_data.mat".

% All mat/data files are unchanged after mcc runs. There is

% no excryption on these user included data files. They are

% included in the ctf archive.

% The target data file is:

% ./output/saved_data.mat

% When writing the file to local disk, do not save any files

% under ctfroot since it may be refreshed and deleted

% when the a pplication isnext started.

%==== load data file =============================

if isdeployed

% In deployed mode , all file under CTFRoot in the pa th are loaded

2-15

2 Writing Deployable MATLAB

Code

% by full path name or relative to $ctfroot.

% LOADFILENAME1=which(fullfile(ctfroot,mfilename,'user_data.mat'));

% LOADFILENAME2=which(fullfile(ctfroot,'userdata','extra_data.mat'));

LOADFILENAME1=which(fullfile('user_data.mat'));

LOADFILENAME2=which(fullfile('extra_data.mat'));

% For external dat a file, full path will be added in to ctf;

% you don't need specify the full path to find the file.

LOADFILENAME3=which(fullfile('extern_data.mat'));

else

%running the code in MATLAB

LOADFILENAME1=fullfile(matlabroot,'extern','examples','compiler',

'Data_Handling','user_data.mat');

LOADFILENAME2=fullfile(matlabroot,'extern','examples','compiler',

'Data_Handling','userdata','extra_data.mat');

LOADFILENAME3=fullfile(matlabroot,'extern','examples','compiler',

'externdata','extern_data.mat');

end

% Load the data file from current working directory

disp(['Load A from : ',LOADFILENAME1]);

load(LOADFILENAME1,'data1');

disp('A= ');

disp(data1);

2-16

% Load the data file from sub directory

disp(['Load B from : ',LOADFILENAME2]);

load(LOADFILENAME2,'data2');

disp('B= ');

disp(data2);

% Load extern data outside of current working directory

disp(['Load extern data from : ',LOADFILENAME3]);

load(LOADFILENAME3);

disp('ext_data= ');

disp(ext_data);

%==== multiple the data matrix by 2 ==============

result = data1*data2;

disp('A*B=');

disp(result);

Working with MATLAB Data Files Using Load and Save

%==== save the new data to a new file ===========

SAVEPATH=strcat(pwd,filesep,'output');

if ( ~isdir(SAVEPATH))

mkdir(SAVEPATH);

end

SAVEFILENAME=strcat(SAVEPATH,filesep,'saved_data.mat');

disp(['Save the A*Bresult to : ',SAVEFILENAME]);

save(SAVEFILENAME, 'result');

2-17

2 Writing Deployable MATLAB

Code

2-18
