Fittings &
Nipples
CALIFORNIA • TEXAS • ILLINOIS • GEORGIA • NEW YORK
Table of Contents
ITEM NAME ITEM NAME ITEM NAME
Fittings
A
API Line Couplings ......................................................................... 44
B
Brass Cleanout Plug ...................................................................... 77
Brass Compression Couplings ............................................ 81
Brass Fire Hydrant Adapter & Cap ................................... 76
Brass Insert Fittings ................................................................ 84-85
Brass Meter Coupling .................................................................. 87
Brass Meter Elbow .......................................................................... 87
Brass Pex Cold Expansion Fittings .............................65-66
Brass Pex Fittings ..................................................................... 63-64
Brass Pipe Fittings ................................................................... 47-51
Brass Pipe Fittings - Domestic .................................... 52-61
Bronze Adapters ............................................................................... 87
Bronze Meter Flanges / Kits ................................................... 86
C
Cast Brass Sweat Adapter Fittings ................................... 67
Cast Iron Boiler Plug ...................................................................... 75
Cast Iron Meter Flanges ............................................................ 86
Cast Iron Threaded Fittings ........................................... 15-16
Chrome Plated Brass Fittings ............................................... 62
Cold Expansion Brass Pex Fittings .............................65-66
Cold Expansion Pex x CPVC Transition Fittings ..... 80
Cold Expansion Poly Pex Fittings ................................... 29
Compression Fittings ................................................. 78-79, 81
Copper Fittings ............................................................................68-71
CPVC Brass Adapter ...................................................................... 80
CPVC Compression Fittings .................................................. 79
CPVC Stainless Steel Adapters ............................................ 80
D
Dielectric Unions .............................................................................. 74
Drop Ear Elbow .................................................................................. 80
Drop Well Coupling ...................................................................... 88
Domestic Brass Fittings ..................................................... 52-61
PAGE NUMBER PAGE NUMBER PAGE NUMBER
Fittings Continued
I
Iron Body Cleanout ....................................................................... 77
L
Lead “Fit-All” Plug .............................................................................. 75
M
Malleable Iron Cap Tapped ........................................... 75
Malleable Pipe Fittings 150 Lb. ............................... 5-12
Malleable Pipe Fittings 300 Lb. ............................ 13-14
Malleable Pipe Fittings Part #
Breakdown ..................................................................................... 4
Meter Coupling ....................................................................... 87
Meter Elbow .............................................................................. 87
Meter Flanges / Kits ............................................................... 84
N
No Hub Couplings ............................................................... 72
P
Poly Pex Cold Expansion Fittings .............................. 29
Poly Pex Fittings ...................................................................... 28
PVC Compression Fittings ...................................... 78-79
Nipples
B
Boiler Headers ....................................................................... 101
Brass Pipe Nipples ................................................... 111-112
Brass Pipe Nipples - Domestic ....................... 114-115
Brass Pre-Cut Pipe .............................................................. 113
C
Chrome Plated Brass Nipples ................................... 122
D
Dielectric Nipples ............................................................... 121
Domestic Brass Pipe Nipples ......................... 114-115
G
Grooved Nipples ................................................................. 120
N
Nipple Part # Breakdown ................................................ 90
P
Pre-Cut Pipe Welded Steel .................................. 97-100
PVC Nipples .................................................................. 107-110
S
R
Radiator Valve Nut & Tailpiece ..................................... 75
Repair Clamps .......................................................................... 83
Seamless Steel Nipples ....................................... 105-106
Stainless Steel 304 Nipples .............................. 116-117
Stainless Steel 316 Nipples .............................. 118-119
Steel Pipe Nipple Assortment .................................. 101
S
Stainless Steel 304 Fittings ...................................... 37-39
Stainless Steel 316 Fittings ...................................... 40-42
Stainless Steel Adapters ................................................... 80
Stainless Steel Drop Ear Elbow ................................... 80
Stainless Steel Insert Fittings ...........................................82
Steel Merchant Couplings ..................................... 43-44
Steel Plugs & Bushings .............................................. 45-46
Stieners ....................................................................................... 88
W
Welded Sch.40 ................................................................. 91-96
Welded Sch.80 ........................................................... 102-104
F
Flare Fittings .......................................................................................... 88
Flexible Groove Couplings .......................................................73
Flexible Rubber Couplings ..................................................... 72
Forged Steel Branch Outlets ........................................ 26-27
Forged Steel Fittings ............................................................ 17-25
T
Tank Tee ......................................................................................... 88
Test Plug ........................................................................................ 77
Transition Fittings .....................................................................80
Torque Wrench ........................................................................ 72
U
G
Galvanized Compression Couplings ........................... 81
Galvanized & Steel Insert Fittings ..................................... 82
H
Heating Products ............................................................................. 75
Hose Adapter ...................................................................................... 76
Hydrant Adapter ..................................................................... 76, 85
Hydrant Tee ........................................................................................... 85
Copyright ©2018 by MATCO-NORCA Incorporated. Reproduction or duplication of the contents herein prohibited without permission.
MATCO-NORCA reserves the right to change products depicted herein at any time, and accepts no liability for errors or ommissions.
Union Elbow - With Nut & Tailpiece ....................... 75
W
Water Service Products ............................................. 76-88
Weld Fittings ...................................................................... 30-33
Weld Flanges ..................................................................... 34-36
Wire Brushes .............................................................................. 71
Wrot Copper Fittings .................................................. 68-71
Certications & Approvals
Matco-Norca is committed to maintaining a high standard of quality for all the products we oer. Most products in this
catalog are labeled with a designated approval or certication code. Below is a brief description of these approvals.
ADA American Disabilities Act — Protecting the rights of people with physical or mental disabilities.
ANSI American National Standards Institute — Organization that coordinates work among
U.S. Standards writing groups; Works in conjunction with other groups such as ISO,
ASME, ASTM, etc.
ASME American Society of Mechanical Engineers — Develops standards and testing criteria
for nished products.
ASSE American Society of Sanitary Engineering — Develops standards and qualies products
for plumbing and sanitary installations.
ASTM American Society for Testing Materials — Develops standards for materials, products,
systems and services.
AWWA American Water Works Association — Promotes public health through improvement
of water quality. Develops standards for valves, ttings and equipment.
CSA Canadian Standards Association — Develops standards, tests and qualies products
used in gas lines and gas appliance installations.
CEC California Energy Commission — As the state’s primary energy policy and planning agency, the
California Energy Commission is committed to reducing energy costs and environmental impacts of
energy use - such as greenhouse gas emissions - while ensuring a safe, resilient, and reliable supply
of energy.
I.S.O. 9002
CERTIFIED
EPA EPA WaterSense® — A U.S. Environmental Protection Agency (EPA) program designed to encourage
water eciency in the United States through the use of a special label on consumer products.
FM Factory Mutual — Develops standards and qualies products for use by the general public.
ISO International Standards Association — A worldwide process control organization. An
internationally recognized certication for manufacturers that comply with high standards
of quality control. Developed standards ISO-9000 through ISO-9004
MSS Mechanics Standardization Society of the Valves & Fittings Industry, Inc. — A committee
of manufacturers that develops technical codes and standards for the valve & tting industry.
NACE National Association of Corrosion Engineers — Equips society to protect people, assets and the
environment from the adverse eects of corrosion.
NSF NSF International — An organization committed to public health that writes standards and
certies products for food, water and consumer products.
SDWA The Safe Drinking Water Act — Is the main federal law that ensures the quality of Americans’
drinking water. Under SDWA, EPA sets standards for drinking water quality and oversees the states,
localities, and water suppliers who implement those standards. Weighted average lead content of
water contact components must be 0.25% or less.
UL Underwriter’s Laboratory — Tests and qualies valve and ttings products under
UL standards for safety.
UPC Uniform Plumbing Code — Developed by the International Association of Plumbing and
Mechanical Ocials to govern the installation and inspection of plumbing systems as a means
of promoting the public’s health, safety and welfare.
USC University of Southern California — Foundation for Cross-Connection Control and
Hydraulic Research that lists approved backow prevention assemblies.
Fittings & Nipples
Global sourcing. National compliance. Local service.
3
Malleable Pipe Fittings Part # Breakdown
ZMBT08PREFIX
M (Z) B T 08
Prex
M Thailand Malleable
(Z) M Chinese Malleable
Part Group
B Black, 150 LB.
G Galvanized, 150 LB.
Part # Breakdown
Malleable Fittings
BX Black, 300 LB.
GX Galvanized, 300 LB.
Part Code
L90 90˚Elbow
LST90 90˚Street Elbow
LR Elbow Reducing
L45 45˚ Elbow
LST45 45˚Street Elbow
LSO Elbow Side Outlet
T Tee
TSO Tee Side Outlet (Thai Only)
ST Street (Service) Tee
TR Tee Reducing
PL Square Head Plug
CR Cross
X Extension Piece
FF Floor Flange
UN Union
CA Cap
CP Coupling Banded
LN Locknut
CPR Coupling Reducing
BU Hex Bushing
Sample Part # is:
Chinese Malleable
Black, 150LB, Tee, 2”
Size
0 1/8
1 1/4
2 3/8
3 1/2
4 3/4
5 1
6 1-1/4
7 1-1/2
8 2
9 2-1/2
10 3
11 4
12 5
13 6
4
Global sourcing. National compliance. Local service.
Fittings & Nipples
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
90º Elbow
MBL9000 MGL9000 1/8” 50 600
MBL9001 MGL9001 1/4” 35 420
MBL9002 MGL9002 3/8” 90 360
MBL9003 MGL9003 1/2” 50 200
MBL9004 MGL9004 3/4” 35 105
MBL9005 MGL9005 1” 20 60
MBL9006 MGL9006 1-1/4” 20 40
MBL9007 MGL9007 1-1/2” 10 30
MBL9008 MGL9008 2” 8 16
MBL9009 MGL9009 2-1/2” 1 12
MBL9010 MGL9010 3” 1 8
MBL9011 MGL9011 4” 1 2
MBL9012 MGL9012 5” 1 2
MBL9013 MGL9013 6” 1 1
90º Street Elbow
MBLST9000 MGLST9000 1/8” 60 720
MBLST9001 MGLST9001 1/4” 35 420
MBLST9002 MGLST9002 3/8” 40 240
MBLST9003 MGLST9003 1/2” 60 180
MBLST9004 MGLST9004 3/4” 35 105
MBLST9005 MGLST9005 1” 45 90
MBLST9006 MGLST9006 1-1/4” 25 50
MBLST9007 MGLST9007 1-1/2” 9 27
MBLST9008 MGLST9008 2” 8 16
MBLST9009 MGLST9009 2-1/2” 5 10
MBLST9010 MGLST9010 3” 1 8
MBLST9011 MGLST9011 4” 1 4
MATCONORCA
MODEL NUMBER
Reducing Elbow
MBLR0100 MGLR0100 1/4” x 1/8” 40 480
MBLR0200 MGLR0200 3/8” x 1/8” 70 420
MBLR0201 MGLR0201 3/8” x 1/4” 60 360
MBLR0300 MGLR0300 1/2” x 1/8” 40 240
MBLR0301 MGLR0301 1/2” x 1/4” 40 240
MBLR0302 MGLR0302 1/2” x 3/8” 40 240
MBLR0400 MGLR0400 3/4” x 1/8” 40 160
MBLR0401 MGLR0401 3/4” x 1/4” 40 160
MBLR0402 MGLR0402 3/4” x 3/8” 40 160
MBLR0403 MGLR0403 3/4” x 1/2” 40 160
MBLR0501 MGLR0501 1” x 1/4” 25 100
MBLR0502 MGLR0502 1” x 3/8” 25 100
MBLR0503 MGLR0503 1” x 1/2” 25 100
MBLR0504 MGLR0504 1” x 3/4” 25 100
MBLR0603 MGLR0603 1-1/4” x 1/2” 20 80
MBLR0604 MGLR0604 1-1/4” x 3/4” 15 60
MBLR0605 MGLR0605 1-1/4” x 1” 10 40
MBLR0703 MGLR0703 1-1/2” x 1/2” 15 60
MBLR0704 MGLR0704 1-1/2” x 3/4” 10 40
MBLR0705 MGLR0705 1-1/2” x 1” 10 40
MBLR0706 MGLR0706 1-1/2” x 1-1/4” 15 30
MBLR0803 MGLR0803 2” x 1/2” 10 40
MBLR0804 MGLR0804 2” x 3/4” 9 36
MBLR0805 MGLR0805 2” x 1” 14 28
MBLR0806 MGLR0806 2” x 1-1/4” 10 20
MBLR0807 MGLR0807 2” x 1-1/2” 10 20
MBLR0903 – 2-1/2” x 1/2” 10 20
MBLR0904 MGLR0904 2-1/2” x 3/4” 10 20
MBLR0905 MGLR0905 2-1/2” x 1” 8 16
MBLR0906 MGLR0906 2-1/2” x 1-1/4” 8 16
MBLR0907 MGLR0907 2-1/2” x 1-1/2” 6 12
MBLR0908 MGLR0908 2-1/2” x 2” 6 12
MBLR1007 MGLR1007 3” x 1-1/2” 4 8
MBLR1008 MGLR1008 3” x 2” 4 8
MBLR1009 MGLR1009 3” x 2-1/2” 4 8
MBLR1108 MGLR1108 4” x 2” 2 4
MBLR1109 MGLR1109 4” x 2-1/2” 1 2
MBLR1110 MGLR1110 4” x 3” 1 2
CARTON QUANTITIES
INNER MASTER
150 LB.
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Fittings & Nipples
Global sourcing. National compliance. Local service.
5
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
150 LB.
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
MBL4500 MGL4500 1/8” 50 600
MBL4501 MGL4501 1/4” 30 360
MBL4502 MGL4502 3/8” 50 300
MBL4503 MGL4503 1/2” 50 200
MBL4504 MGL4504 3/4” 40 120
MBL4505 MGL4505 1” 20 60
MBL4506 MGL4506 1-1/4” 20 40
MBL4507 MGL4507 1-1/2” 10 30
MBL4508 MGL4508 2” 12 24
MBL4509 MGL4509 2-1/2” 1 12
MBL4510 MGL4510 3” 1 10
MBL4511 MGL4511 4” 1 4
MBL4512 MGL4512 5” 1 1
MBL4513 MGL4513 6” 1 1
45º Street Elbow
MBLST4500 MGLST4500 1/8” 70 840
MBLST4501 MGLST4501 1/4” 40 480
MBLST4502 MGLST4502 3/8” 50 400
MBLST4503 MGLST4503 1/2” 75 225
MBLST4504 MGLST4504 3/4” 40 120
MBLST4505 MGLST4505 1” 25 75
MBLST4506 MGLST4506 1-1/4” 10 40
MBLST4507 MGLST4507 1-1/2” 10 30
MBLST4508 MGLST4508 2” 12 24
MBLST4509 MGLST4509 2-1/2” 6 12
MBLST4510 MGLST4510 3” 3 6
MBLST4511 MGLST4511 4” 1 4
MATCONORCA
MODEL NUMBER
Side Outlet Elbow
MBLSO01 MGLSO01 1/4” 50 300
MBLSO02 MGLSO02 3/8” 50 200
MBLSO03 MGLSO03 1/2” 45 135
MBLSO04 MGLSO04 3/4” 20 80
MBLSO05 MGLSO05 1” 20 40
MBLSO06 MGLSO06 1-1/4” 15 30
MBLSO07 MGLSO07 1-1/2” 12 24
MBLSO08 MGLSO08 2” 5 10
Tee
MBT00 MGT00 1/8” 80 480
MBT01 MGT01 1/4” 50 300
MBT02 MGT02 3/8” 30 180
MBT03 MGT03 1/2” 40 120
MBT04 MGT04 3/4” 35 70
MBT05 MGT05 1” 20 40
MBT06 MGT06 1-1/4” 14 28
MBT07 MGT07 1-1/2” 12 24
MBT08 MGT08 2” 8 16
MBT09 MGT09 2-1/2” 4 8
MBT10 MGT10 3” 1 6
MBT11 MGT11 4” 1 2
MBT12 MGT12 5” 1 1
MBT13 MGT13 6” 1 1
CARTON QUANTITIES
INNER MASTER
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
6
Global sourcing. National compliance. Local service.
Fittings & Nipples
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
Side Outlet Tee
MBTSO03 MGTSO03 1/2” 25 100
MBTSO04 MGTSO04 3/4” 15 60
MBTSO05 MGTSO05 1” 20 40
MBTSO06 MGTSO06 1-1/4” 12 24
MBTSO07 MGTSO07 1-1/2” 8 16
MBTSO08 MGTSO08 2” 4 8
Street (Service) Tee
MBST03 MGST03 1/2” 40 120
MBST04 MGST04 3/4” 25 75
MBST05 MGST05 1” 20 40
- MGST06 1-1/4” 15 30
MBST07 MGST07 1-1/2” 8 16
Bull Head Tee
MBTR030304 MGTR030304 1/2” x 1/2” x 3/4” 30 120
MBTR030305 MGTR030305 1/2” x 1/2” x 1” 25 100
MBTR040405 MGTR040405 3/4” x 3/4” x 1” 20 80
MBTR040406 MGTR040406 3/4” x 3/4” x 1-1/4” 25 100
MBTR050506 MGTR050506 1” x 1” x 1-1/4” 11 44
MBTR050507 MGTR050507 1” x 1” x 1-1/2” 9 36
MBTR050508 MGTR050508 1” x 1” x 2” 12 24
MBTR060607 MGTR060607 1-1/4” x 1-1/4” x 1-1/2” 12 24
MBTR060608 MGTR060608 1-1/4” x 1-1/4” x 2” 12 24
MBTR070708 MGTR070708 1-1/2” x 1-1/2” x 2” 8 16
MBTR080809 MGTR080809 2” x 2” x 2-1/2” 6 12
Reducing Tee - Reduce 2 Sizes
MBTR0100 MGTR0100 1/4” x 1/8” 25 300
- MGTR0200 3/8” x 1/8” 40 240
MBTR0201 MGTR0201 3/8” x 1/4” 40 240
MBTR0300 MGTR0300 1/2” x 1/8” 40 160
MBTR0301 MGTR0301 1/2” x 1/4” 20 160
MBTR0302 MGTR0302 1/2” x 3/8” 20 160
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
CARTON QUANTITIES
INNER MASTER
Reducing Tee - Reduce 2 Sizes (Continued)
MBTR0401 MGTR0401 3/4” x 1/4” 25 100
MBTR0402 MGTR0402 3/4” x 3/8” 25 100
MBTR0403 MGTR0403 3/4” x 1/2” 20 80
MBTR0501 MGTR0501 1” x 1/4” 20 80
MBTR0502 MGTR0502 1” x 3/8” 15 60
MBTR0503 MGTR0503 1” x 1/2” 15 60
MBTR0504 MGTR0504 1” x 3/4” 12 48
MBTR0602 MGTR0602 1-1/4” x 3/8” 20 40
MBTR0603 MGTR0603 1-1/4” x 1/2” 20 40
MBTR0604 MGTR0604 1-1/4” x 3/4” 20 40
MBTR0605 MGTR0605 1-1/4” x 1” 20 40
- MGTR0702 1-1/2” x 3/8” 18 36
MBTR0703 MGTR0703 1-1/2” x 1/2” 18 36
MBTR0704 MGTR0704 1-1/2” x 3/4” 15 30
MBTR0705 MGTR0705 1-1/2” x 1” 15 30
MBTR0706 MGTR0706 1-1/2” x 1-1/4” 12 24
MBTR0803 MGTR0803 2” x 1/2” 10 20
MBTR0804 MGTR0804 2” x 3/4” 10 20
MBTR0805 MGTR0805 2” x 1” 10 20
MBTR0806 MGTR0806 2” x 1-1/4” 8 16
MBTR0807 MGTR0807 2” x 1-1/2” 8 16
MBTR0903 MGTR0903 2-1/2” x 1/2” 6 12
MBTR0904 MGTR0904 2-1/2” x 3/4” 6 12
MBTR0905 MGTR0905 2-1/2” x 1” 5 10
MBTR0906 MGTR0906 2-1/2” x 1-1/4” 5 10
MBTR0907 MGTR0907 2-1/2” x 1-1/2” 5 10
MBTR0908 MGTR0908 2-1/2” x 2” 4 8
MBTR1003 MGTR1003 3” x 1/2” 4 8
MBTR1004 MGTR1004 3” x 3/4” 3 6
MBTR1005 MGTR1005 3” x 1” 3 6
MBTR1006 MGTR1006 3” x 1-1/4” 3 6
MBTR1007 MGTR1007 3” x 1-1/2” 3 6
MBTR1008 MGTR1008 3” x 2” 3 6
MBTR1009 MGTR1009 3” x 2-1/2” 3 6
MBTR1103 – 4” x 1/2” 2 4
MBTR1104 – 4” x 3/4” 2 4
MBTR1105 MGTR1105 4” x 1” 2 4
MBTR1106 MGTR1106 4” x 1-1/4” 2 4
MBTR1107 MGTR1107 4” x 1-1/2” 2 4
MBTR1108 MGTR1108 4” x 2” 1 3
MBTR1109 MGTR1109 4” x 2-1/2” 1 3
MBTR1110 MGTR1110 4” x 3” 1 2
MATCONORCA
MODEL NUMBER
• 1/8” - 6” Diameter
• Lead Free
CARTON QUANTITIES
INNER MASTER
Malleable Fittings
150 LB.
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Fittings & Nipples
Global sourcing. National compliance. Local service.
7
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
150 LB.
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
Reducing Tee - Reduce 3 Sizes
MBTR040303 MGTR040303 3/4” x 1/2” x 1/2” 25 100
MBTR040304 MGTR040304 3/4” x 1/2” x 3/4” 20 80
MBTR040305 MGTR040305 3/4” x 1/2” x 1” 18 72
MBTR050303 MGTR050303 1” x 1/2” x 1/2” 20 80
MBTR050304 MGTR050304 1” x 1/2” x 3/4” 20 80
MBTR050305 MGTR050305 1” x 1/2” x 1” 15 60
MBTR050403 MGTR050403 1” x 3/4” x 1/2” 20 80
MBTR050404 MGTR050404 1” x 3/4” x 3/4” 15 60
MBTR050405 MGTR050405 1” x 3/4” x 1” 15 60
MBTR060303 MGTR060303 1-1/4” x 1/2” x 1/2” 25 50
MBTR060304 MGTR060304 1-1/4” x 1/2” x 3/4” 25 50
MBTR060305 MGTR060305 1-1/4” x 1/2” x 1” 20 40
MBTR060306 MGTR060306 1-1/4” x 1/2” x 1-1/4” 20 40
MBTR060403 MGTR060403 1-1/4” x 3/4” x 1/2” 10 40
MBTR060404 MGTR060404 1-1/4” x 3/4” x 3/4” 10 40
MBTR060405 MGTR060405 1-1/4” x 3/4” x 1” 10 40
MBTR060406 MGTR060406 1-1/4” x 3/4” x 1-1/4” 10 40
MBTR060503 MGTR060503 1-1/4” x 1” x 1/2” 20 40
MBTR060504 MGTR060504 1-1/4” x 1” x 3/4” 20 40
MBTR060505 MGTR060505 1-1/4” x 1” x 1” 20 40
MBTR060506 MGTR060506 1-1/4” x 1” x 1-1/4” 15 30
MBTR060507 MGTR060507 1-1/4” x 1” x 1-1/2” 18 36
MBTR070304 MGTR070304 1-1/2” x 1/2” x 3/4” 12 48
MBTR070305 MGTR070305 1-1/2” x 1/2” x 1” 18 36
MBTR070306 MGTR070306 1-1/2” x 1/2” x 1-1/4” 15 30
MBTR070307 MGTR070307 1-1/2” x 1/2” x 1-1/2” 12 24
MBTR070403 MGTR070403 1-1/2” x 3/4” x 1/2” 15 30
MBTR070404 MGTR070404 1-1/2” x 3/4” x 3/4” 15 30
MBTR070406 MGTR070406 1-1/2” x 3/4” x 1-1/4” 12 24
MBTR070407 MGTR070407 1-1/2” x 3/4” x 1-1/2” 12 24
MBTR070503 MGTR070503 1-1/2” x 1” x 1/2” 15 30
MBTR070504 MGTR070504 1-1/2” x 1” x 3/4” 15 30
MBTR070505 MGTR070505 1-1/2” x 1” x 1” 15 30
MBTR070506 MGTR070506 1-1/2” x 1” x 1-1/4” 12 24
MBTR070507 MGTR070507 1-1/2” x 1” x 1-1/2” 12 24
MBTR070603 MGTR070603 1-1/2” x 1-1/4” x 1/2” 12 24
MBTR070604 MGTR070604 1-1/2” x 1-1/4” x 3/4” 12 24
MBTR070605 MGTR070605 1-1/2” x 1-1/4” x 1” 12 24
MBTR070606 MGTR070606 1-1/2” x 1-1/4” x 1-1/4” 12 24
MBTR070607 MGTR070607 1-1/2” x 1-1/4” x 1-1/2” 12 24
MBTR070608 MGTR070608 1-1/2” x 1-1/4” x 2” 8 16
MBTR080308 MGTR080308 2” x 1/2” x 2” 8 16
MBTR080404 MGTR080404 2” x 3/4” x 3/4” 12 24
MBTR080408 MGTR080408 2” x 3/4” x 2” 8 16
CARTON QUANTITIES
INNER MASTER
Reducing Tee - Reduce 3 Sizes (Continued)
MBTR080505 MGTR080505 2” x 1” x 1” 12 24
MBTR080507 MGTR080507 2” x 1” x 1-1/2” 10 20
MBTR080508 MGTR080508 2” x 1” x 2” 8 16
MBTR080605 MGTR080605 2” x 1-1/4” x 1” 8 16
MBTR080606 MGTR080606 2” x 1-1/4” x 1-1/4” 8 16
MBTR080607 MGTR080607 2” x 1-1/4” x 1-1/2” 8 16
MBTR080608 MGTR080608 2” x 1-1/4” x 2” 8 16
MBTR080704 MGTR080704 2” x 1-1/2” x 3/4” 10 20
MBTR080705 MGTR080705 2” x 1-1/2” x 1” 10 20
MBTR080706 MGTR080706 2” x 1-1/2” x 1-1/4” 8 16
MBTR080707 MGTR080707 2” x 1-1/2” x 1-1/2” 8 16
MBTR080708 MGTR080708 2” x 1-1/2” x 2” 8 16
MBTR090808 MGTR090808 2-1/2” x 2” x 2” 5 10
MBTR090809 MGTR090809 2-1/2” x 2” x 2-1/2” 4 8
Square Head Plug
MBPL00 MGPL00 1/8” 300 3600
MBPL01 MGPL01 1/4” 150 1800
MBPL02 MGPL02 3/8” 100 1200
MBPL03 MGPL03 1/2” 50 600
MBPL04 MGPL04 3/4” 30 360
Above sizes are also available in steel.
Please see our Steel Plug & Bushing Price List.
MBPL05 MGPL05 1” 20 240
MBPL06 MGPL06 1-1/4” 40 120
MBPL07 MGPL07 1-1/2” 30 90
MBPL08 MGPL08 2” 20 60
MBPL09 MGPL09 2-1/2” 16 32
MBPL10 MGPL10 3” 16 32
MBPL11 MGPL11 4” 6 12
MBPL12 MGPL12 5” 5 10
MBPL13 MGPL13 6” 5 10
Bar Style
ZMBPL11B - 4” 8 12
ZMBPL13B - 6” 5 10
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
8
Global sourcing. National compliance. Local service.
Fittings & Nipples
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Cross
MBCR00 MGCR00 1/8” 30 360
MBCR01 MGCR01 1/4” 40 240
MBCR02 MGCR02 3/8” 25 150
MBCR03 MGCR03 1/2” 30 90
MBCR04 MGCR04 3/4” 20 60
MBCR05 MGCR05 1” 15 30
MBCR06 MGCR06 1-1/4” 10 20
MBCR07 MGCR07 1-1/2” 8 16
MBCR08 MGCR08 2” 5 10
MBCR09 MGCR09 2-1/2” 3 6
MBCR10 MGCR10 3” 2 4
MBCR11 MGCR11 4” 1 2
MATCONORCA
MODEL NUMBER
Floor Flange With Holes
MBFF01 MGFF01 1/4” 25 75
MBFF02 MGFF02 3/8” 25 75
MBFF03 MGFF03 1/2” 25 50
MBFF04 MGFF04 3/4” 15 45
MBFF05 MGFF05 1” 15 30
MBFF06 MGFF06 1-1/4” 10 30
MBFF07 MGFF07 1-1/2” 8 24
MBFF08 MGFF08 2” 8 16
CARTON QUANTITIES
INNER MASTER
150 LB.
Extension Piece
MBX03 MGX03 1/2” 50 300
MBX04 MGX04 3/4” 40 160
MBX05 MGX05 1” 30 90
MBX06 MGX06 1-1/4” 30 60
MBX07 MGX07 1-1/2” 20 40
MBX08 MGX08 2” 15 30
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Fittings & Nipples
Union
MBUN00 MGUN00 1/8” 30 240
MBUN01 MGUN01 1/4” 20 240
MBUN02 MGUN02 3/8” 20 160
MBUN03 MGUN03 1/2” 50 100
MBUN04 MGUN04 3/4” 35 70
MBUN05 MGUN05 1” 20 40
MBUN06 MGUN06 1-1/4” 15 30
MBUN07 MGUN07 1-1/2” 10 20
MBUN08 MGUN08 2” 6 12
MBUN09 MGUN09 2-1/2” 4 8
MBUN10 MGUN10 3” 4 8
MBUN11 MGUN11 4” 2 4
Reducing Union
MBUN0403 MGUN0403 3/4” x 1/2” 30 90
Global sourcing. National compliance. Local service.
9
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
150 LB.
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Cap
MBCA00 MGCA00 1/8” 120 1440
MBCA01 MGCA01 1/4” 80 960
MBCA02 MGCA02 3/8” 60 720
MBCA03 MGCA03 1/2” 75 300
MBCA04 MGCA04 3/4” 40 160
MBCA05 MGCA05 1” 25 100
MBCA06 MGCA06 1-1/4” 20 80
MBCA07 MGCA07 1-1/2” 18 54
MBCA08 MGCA08 2” 12 36
MBCA09 MGCA09 2-1/2” 20 40
MBCA10 MGCA10 3” 1 24
MBCA105 - 3-1/2” 6 12
MBCA11 MGCA11 4” 6 12
MBCA12 MGCA12 5” 5 10
MBCA13 MGCA13 6” 2 4
MATCONORCA
MODEL NUMBER
Locknut
MBLN00 MGLN00 1/8” 250 3000
MBLN01 MGLN01 1/4” 125 1500
MBLN02 MGLN02 3/8” 125 1500
MBLN03 MGLN03 1/2” 100 600
MBLN04 MGLN04 3/4” 60 360
MBLN05 MGLN05 1” 40 240
MBLN06 MGLN06 1-1/4” 30 180
MBLN07 MGLN07 1-1/2” 45 135
MBLN08 MGLN08 2” 25 75
MBLN09 MGLN09 2-1/2” 20 40
MBLN10 MGLN10 3” 20 40
MBLN11 MGLN11 4” 7 14
MBLN12 MGLN12 5” 5 10
MBLN13 MGLN13 6” 4 8
CARTON QUANTITIES
INNER MASTER
10
Banded Coupling
MBCP00 MGCP00 1/8” 70 840
MBCP01 MGCP01 1/4” 40 480
MBCP02 MGCP02 3/8” 40 480
MBCP03 MGCP03 1/2” 60 240
MBCP04 MGCP04 3/4” 50 150
MBCP05 MGCP05 1” 25 100
MBCP06 MGCP06 1-1/4” 16 64
MBCP07 MGCP07 1-1/2” 18 36
MBCP08 MGCP08 2” 12 24
MBCP09 MGCP09 2-1/2” 8 16
MBCP10 MGCP10 3” 1 12
MBCP11 MGCP11 4” 3 6
MBCP12 MGCP12 5” 1 2
MBCP13 MGCP13 6” 1 2
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Global sourcing. National compliance. Local service.
Right & Left Coupling - Chinese Only
ZMBRLC03 ZMGRLC03 1/2” 40 320
ZMBRLC04 ZMGRLC04 3/4” 50 150
ZMBRLC05 ZMGRLC05 1” 25 100
ZMBRLC06 ZMGRLC06 1-1/4” 20 64
ZMBRLC07 ZMGRLC07 1-1/2” 12 36
ZMBRLC08 ZMGRLC08 2” 12 24
ZMBRLC09 – 2-1/2” 8 32
ZMBRLC10 – 3” 12 24
ZMBRLC11 – 4” 6 12
Fittings & Nipples
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Coupling
MBCPR0100 MGCPR0100 1/4” x 1/8” 50 600
MBCPR0200 MGCPR0200 3/8” x 1/8” 35 420
MBCPR0201 MGCPR0201 3/8” x 1/4” 30 360
MBCPR0300 MGCPR0300 1/2” x 1/8” 50 300
MBCPR0301 MGCPR0301 1/2” x 1/4” 75 300
MBCPR0302 MGCPR0302 1/2” x 3/8” 60 240
MBCPR0400 MGCPR0400 3/4” x 1/8” 35 210
MBCPR0401 MGCPR0401 3/4” x 1/4” 30 180
MBCPR0402 MGCPR0402 3/4” x 3/8” 30 180
MBCPR0403 MGCPR0403 3/4” x 1/2” 60 180
MBCPR0501 MGCPR0501 1” x 1/4” 45 135
MBCPR0502 MGCPR0502 1” x 3/8” 30 120
MBCPR0503 MGCPR0503 1” x 1/2” 30 120
MBCPR0504 MGCPR0504 1” x 3/4” 25 100
MBCPR0602 MGCPR0602 1-1/4” x 3/8” 25 75
MBCPR0603 MGCPR0603 1-1/4” x 1/2” 25 75
MBCPR0604 MGCPR0604 1-1/4” x 3/4” 25 75
MBCPR0605 MGCPR0605 1-1/4” x 1” 15 60
MBCPR0702 MGCPR0702 1-1/2” x 3/8” 30 60
MBCPR0703 MGCPR0703 1-1/2” x 1/2” 20 60
MBCPR0704 MGCPR0704 1-1/2” x 3/4” 15 60
MBCPR0705 MGCPR0705 1-1/2” x 1” 25 50
MBCPR0706 MGCPR0706 1-1/2” x 1-1/4” 12 48
MBCPR0802 MGCPR0802 2” x 3/8” 12 36
MBCPR0803 MGCPR0803 2” x 1/2” 12 36
MBCPR0804 MGCPR0804 2” x 3/4” 12 36
MBCPR0805 MGCPR0805 2” x 1” 12 36
MBCPR0806 MGCPR0806 2” x 1-1/4” 9 27
MBCPR0807 MGCPR0807 2” x 1-1/2” 9 27
MBCPR0903 MGCPR0903 2-1/2” x 1/2” 10 20
MBCPR0904 MGCPR0904 2-1/2” x 3/4” 10 20
MBCPR0905 MGCPR0905 2-1/2” x 1” 10 20
MBCPR0906 MGCPR0906 2-1/2” x 1-1/4” 10 20
MBCPR0907 MGCPR0907 2-1/2” x 1-1/2” 7 14
MBCPR0908 MGCPR0908 2-1/2” x 2” 7 14
MBCPR1003 – 3” x 1/2” 7 14
MBCPR1004 MGCPR1004 3” x 3/4” 7 14
MBCPR1005 MGCPR1005 3” x 1” 6 12
MBCPR1006 MGCPR1006 3” x 1-1/4” 6 12
MBCPR1007 MGCPR1007 3” x 1-1/2” 6 12
MATCONORCA
MODEL NUMBER
Reducing Coupling (Continued)
MBCPR1008 MGCPR1008 3” x 2” 6 12
MBCPR1009 MGCPR1009 3” x 2-1/2” 5 10
MBCPR1105 MGCPR1105 4” x 1” 3 6
MBCPR1106 MGCPR1106 4” x 1-1/4” 3 6
MBCPR1107 MGCPR1107 4” x 1-1/2” 3 6
MBCPR1108 MGCPR1108 4” x 2” 3 6
MBCPR1109 MGCPR1109 4” x 2-1/2” 3 6
MBCPR1110 MGCPR1110 4” x 3” 3 6
MBCPR1310 MGCPR1310 6” x 3” 1 2
MBCPR1311 MGCPR1311 6” x 4” 1 2
Waste Nut - Galvanized Only
MGWN03 1/2” 90 360
MGWN04 3/4” 80 240
MGWN05 1” 50 200
MGWN06 1-1/4” 30 120
MGWN07 1-1/2” 50 100
MGWN08 2” 30 60
CARTON QUANTITIES
INNER MASTER
150 LB.
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Fittings & Nipples
Global sourcing. National compliance. Local service.
11
Malleable Pipe Fittings 150 LB.
• Thailand Fittings UL/FM Certied
• Chinese Fittings UL/FM Certied
• ISO 9001: 2000
• All Fittings are 100% Pressure Tested
• Pressure Rating: Fittings: ANSI/ASME B16.3
Bushings/Plugs: ANSI/ASME B16.14
• 1/8” - 6” Diameter
• Lead Free
150 LB.
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Hex Bushing
MBBU0100 MGBU0100 1/4” x 1/8” 120 1440
MBBU0200 MGBU0200 3/8” x 1/8” 75 900
MBBU0201 MGBU0201 3/8” x 1/4” 75 900
MBBU0300 MGBU0300 1/2” x 1/8” 100 600
MBBU0301 MGBU0301 1/2” x 1/4” 150 600
MBBU0302 MGBU0302 1/2” x 3/8” 150 600
MBBU0400 MGBU0400 3/4” x 1/8” 50 300
MBBU0401 MGBU0401 3/4” x 1/4” 50 300
MBBU0402 MGBU0402 3/4” x 3/8” 50 300
MBBU0403 MGBU0403 3/4” x 1/2” 75 300
MBBU0500 MGBU0500 1” x 1/8” 50 200
MBBU0501 MGBU0501 1” x 1/4” 50 200
MBBU0502 MGBU0502 1” x 3/8” 50 200
MBBU0503 MGBU0503 1” x 1/2” 50 200
MBBU0504 MGBU0504 1” x 3/4” 50 200
MBBU0601 MGBU0601 1-1/4” x 1/4” 30 120
MBBU0602 MGBU0602 1-1/4” x 3/8” 30 120
MBBU0603 MGBU0603 1-1/4” x 1/2” 30 120
MBBU0604 MGBU0604 1-1/4” x 3/4” 30 120
MBBU0605 MGBU0605 1-1/4” x 1” 30 120
MBBU0700 - 1-1/2” x 1/8” 25 75
MBBU0701 MGBU0701 1-1/2” x 1/4” 25 75
MBBU0702 MGBU0702 1-1/2” x 3/8” 25 75
MBBU0703 MGBU0703 1-1/2” x 1/2” 25 75
MBBU0704 MGBU0704 1-1/2” x 3/4” 25 75
MBBU0705 MGBU0705 1-1/2” x 1” 25 75
MBBU0706 MGBU0706 1-1/2” x 1-1/4” 25 75
MBBU0801 MGBU0801 2” x 1/4” 20 60
MBBU0802 MGBU0802 2” x 3/8” 20 60
MBBU0803 MGBU0803 2” x 1/2” 20 60
MBBU0804 MGBU0804 2” x 3/4” 20 60
MBBU0805 MGBU0805 2” x 1” 20 60
MBBU0806 MGBU0806 2” x 1-1/4” 20 60
MBBU0807 MGBU0807 2” x 1-1/2” 20 60
MATCONORCA
MODEL NUMBER
Hex Bushing (Continued)
MBBU0903 MGBU0903 2-1/2” x 1/2” 15 30
MBBU0904 MGBU0904 2-1/2” x 3/4” 15 30
MBBU0905 MGBU0905 2-1/2” x 1” 15 30
MBBU0906 MGBU0906 2-1/2” x 1-1/4” 15 30
MBBU0907 MGBU0907 2-1/2” x 1-1/2” 15 30
MBBU0908 MGBU0908 2-1/2” x 2” 15 30
MBBU1004 MGBU1004 3” x 3/4” 12 24
MBBU1005 MGBU1005 3” x 1” 12 24
MBBU1006 MGBU1006 3” x 1-1/4” 12 24
MBBU1007 MGBU1007 3” x 1-1/2” 12 24
MBBU1008 MGBU1008 3” x 2” 12 24
MBBU1009 MGBU1009 3” x 2-1/2” 12 24
MBBU10507 MGBU10507 3-1/2” x 1-1/2” 8 16
MBBU10510 MGBU10510 3-1/2” x 3” 8 16
MBBU1105 MGBU1105 4” x 1” 5 10
MBBU1106 MGBU1106 4” x 1-1/4” 5 10
MBBU1107 MGBU1107 4” x 1-1/2” 5 10
MBBU1108 MGBU1108 4” x 2” 5 10
MBBU1109 MGBU1109 4” x 2-1/2” 5 10
MBBU1110 MGBU1110 4” x 3” 5 10
MBBU1210 MGBU1210 5” x 3” 2 4
MBBU1211 MGBU1211 5” x 4” 2 4
MBBU1308 MGBU1308 6” x 2” 2 4
MBBU1310 MGBU1310 6” x 3” 2 4
MBBU1311 MGBU1311 6” x 4” 2 4
MBBU1312 MGBU1312 6” x 5” 2 4
CARTON QUANTITIES
INNER MASTER
12
Add Z Prex For Chinese Malleable Fittings: ZMB (Black) / ZMG (Galvanized)
Global sourcing. National compliance. Local service.
Fittings & Nipples
Malleable Pipe Fittings 300 LB. Extra Heavy
• Chinese Fittings
• 1/4” - 4” Diameter
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
XH 90º Elbow
MBXL9001 MGXL9001 1/4” 90 360
MBXL9002 MGXL9002 3/8” 60 240
MBXL9003 MGXL9003 1/2” 40 80
MBXL9004 MGXL9004 3/4” 30 60
MBXL9005 MGXL9005 1” 20 40
MBXL9006 MGXL9006 1-1/4” 12 24
MBXL9007 MGXL9007 1-1/2” 8 16
MBXL9008 MGXL9008 2” 6 12
MBXL9009 MGXL9009 2-1/2” 8 16
MBXL9010 MGXL9010 3” 4 8
MBXL9011 MGXL9011 4” 1 2
• All Fittings are 100% Pressure Tested
• Meets All Applicable ANSI & ASTM Standards
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
• ISO 9001: 2000
• Lead Free
MATCONORCA
MODEL NUMBER
XH 90º Street Elbow
MBXLST9001 MGXLST9001 1/4” 90 360
MBXLST9002 MGXLST9002 3/8” 60 240
MBXLST9003 MGXLST9003 1/2” 40 160
MBXLST9004 MGXLST9004 3/4” 30 60
MBXLST9005 MGXLST9005 1” 20 40
MBXLST9006 MGXLST9006 1-1/4” 12 24
MBXLST9007 MGXLST9007 1-1/2” 8 16
MBXLST9008 MGXLST9008 2” 6 12
MBXLST9011 – 4” 1 2
CARTON QUANTITIES
INNER MASTER
Malleable Fittings
300 LB.
XH 45º Elbow
MBXL4501 MGXL4501 1/4” 90 360
MBXL4502 MGXL4502 3/8” 60 240
MBXL4503 MGXL4503 1/2” 40 80
MBXL4504 MGXL4504 3/4” 30 60
MBXL4505 MGXL4505 1” 20 40
MBXL4506 MGXL4506 1-1/4” 12 24
MBXL4507 MGXL4507 1-1/2” 8 16
MBXL4508 MGXL4508 2” 6 12
MBXL4509 MGXL4509 2-1/2” 8 16
MBXL4510 MGXL4510 3” 4 8
MBXL4511 MGXL4511 4” 1 2
XH Tee
MBXT01 MGXT01 1/4” 60 240
MBXT02 MGXT02 3/8” 45 180
MBXT03 MGXT03 1/2” 30 60
MBXT04 MGXT04 3/4” 20 40
MBXT05 MGXT05 1” 12 24
MBXT06 MGXT06 1-1/4” 10 20
MBXT07 MGXT07 1-1/2” 6 12
MBXT08 MGXT08 2” 4 8
MBXT09 MGXT09 2-1/2” 1 2
MBXT10 MGXT10 3” 1 2
MBXT11 MGXT11 4” 1 2
Fittings & Nipples
Global sourcing. National compliance. Local service.
13
Malleable Pipe Fittings 300 LB. Extra Heavy
• Chinese Fittings
• 1/4” - 4” Diameter
• All Fittings are 100% Pressure Tested
• Meets All Applicable ANSI & ASTM Standards
• ISO 9001: 2000
• Lead Free
300 LB.
Malleable Fittings
MATCONORCA
MODEL NUMBER
BLACK GALVANIZED BLACK GALVANIZED
CARTON QUANTITIES
SIZE SIZE
INNER MASTER
XH Reducing Tee
MBXTR0403 MGXTR0403 3/4” x 1/2” 45 90
MBXTR0503 MGXTR0503 1” x 1/2” 16 32
MBXTR0504 MGXTR0504 1” x 3/4” 30 60
MBXTR0604 MGXTR0604 1-1/4” x 3/4” 12 24
MBXTR0605 MGXTR0605 1-1/4” x 1” 12 24
MBXTR0705 MGXTR0705 1-1/2” x 1” 12 24
MBXTR0706 - 1-1/2” x 1-1/4” 12 24
MBXTR0806 MGXTR0806 2” x 1-1/4” 10 20
MBXTR0807 MGXTR0807 2” x 1-1/2” 10 20
MBXTR0908 - 2-1/2” x 2” 4 8
MBXTR1008 - 3” x 2” 2 4
XH Union
MBXUN00 MGXUN00 1/8” 100 400
MBXUN01 MGXUN01 1/4” 60 240
MBXUN02 MGXUN02 3/8” 90 180
MBXUN03 MGXUN03 1/2” 40 80
MBXUN04 MGXUN04 3/4” 30 60
MBXUN05 MGXUN05 1” 18 36
MBXUN06 MGXUN06 1-1/4” 12 24
MBXUN07 MGXUN07 1-1/2” 10 20
MBXUN08 MGXUN08 2” 6 12
MBXUN09 MGXUN09 2-1/2” 6 12
MBXUN10 MGXUN10 3” 4 8
MBXUN11 MGXUN11 4” 2 2
XH Cap
MBXCA02 MGXCA02 3/8” 60 240
MBXCA03 MGXCA03 1/2” 80 160
MBXCA04 MGXCA04 3/4” 50 100
MBXCA05 MGXCA05 1” 30 60
MBXCA06 MGXCA06 1-1/4” 20 40
MBXCA07 MGXCA07 1-1/2” 15 30
MBXCA08 MGXCA08 2” 10 20
MBXCA09 MGXCA09 2-1/2” 8 16
MBXCA10 MGXCA10 3” 5 10
MBXCA11 MGXCA11 4” 3 6
MATCONORCA
MODEL NUMBER
XH Coupling
MBXCP01 MGXCP01 1/4” 100 400
MBXCP02 MGXCP02 3/8” 75 300
MBXCP03 MGXCP03 1/2” 40 80
MBXCP04 MGXCP04 3/4” 30 60
MBXCP05 MGXCP05 1” 20 40
MBXCP06 MGXCP06 1-1/4” 12 24
MBXCP07 MGXCP07 1-1/2” 12 24
MBXCP08 MGXCP08 2” 6 12
MBXCP09 - 2-1/2” 4 8
MBXCP10 - 3” 3 6
MBXCP11 MGXCP11 4” 2 4
XH Reducing Coupling
MBXCPR0201 – 3/8” x 1/4” 120 240
MBXCPR0301 MGXCPR0301 1/2” x 1/4” 100 200
MBXCPR0302 MGXCPR0302 1/2” x 3/8” 100 200
MBXCPR0402 MGXCPR0402 3/4” x 3/8” 90 180
MBXCPR0403 MGXCPR0403 3/4” x 1/2” 90 180
MBXCPR0503 MGXCPR0503 1” x 1/2” 75 150
MBXCPR0504 MGXCPR0504 1” x 3/4” 40 80
MBXCPR0603 MGXCPR0603 1-1/4” x 1/2” 35 70
MBXCPR0604 MGXCPR0604 1-1/4” x 3/4” 35 70
MBXCPR0605 MGXCPR0605 1-1/4” x 1” 20 40
MBXCPR0703 MGXCPR0703 1-1/2” x 1/2” 30 60
MBXCPR0704 MGXCPR0704 1-1/2” x 3/4” 30 60
MBXCPR0705 MGXCPR0705 1-1/2” x 1” 18 36
MBXCPR0706 MGXCPR0706 1-1/2” x 1-1/4” 18 36
MBXCPR0803 MGXCPR0803 2” x 1/2” 12 24
MBXCPR0804 MGXCPR0804 2” x 3/4” 16 32
MBXCPR0805 MGXCPR0805 2” x 1” 12 24
MBXCPR0806 MGXCPR0806 2” x 1-1/4” 8 16
MBXCPR0807 MGXCPR0807 2” x 1-1/2” 8 16
MBXCPR0908 MGXCPR0908 2-1/2” x 2” 4 8
MBXCPR1008 – 3” x 2” 4 8
MBXCPR1009 – 3” x 2-1/2” 4 8
CARTON QUANTITIES
INNER MASTER
14
Global sourcing. National compliance. Local service.
Fittings & Nipples
Cast Iron Threaded Fittings
• Conforms with ANSI B16.4 Standards
• Stocked in Sizes 1/2” - 4”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
CIL9003 1/2” 75 150
CIL9004 3/4” 50 100
CIL9005 1” 30 60
CIL9006 1-1/4” 18 36
CIL9007 1-1/2” 13 26
CIL9008 2” 7 14
CIL9009 2-1/2” 1 6
CIL9010 3” 1 10
CIL9011 4” 1 8
Tee
CIT03 1/2” 1 100
CIT04 3/4” 1 60
CIT05 1” 26 52
CIT06 1-1/4” 1 29
CIT07 1-1/2” 11 22
CIT08 2” 6 12
CIT09 2-1/2” 1 6
CIT10 3” 5 10
CIT11 4” 1 8
Reducing Couplings
CIRC0503 1” x 1/2” 50 100
CIRC0504 1” x 3/4” 50 100
CIRC0605 1-1/4” x 1” 25 50
CIRC0805 2” x 1” 1 50
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
CIL4503 1/2” 75 150
CIL4504 3/4” 50 100
CIL4505 1” 35 70
CIL4506 1-1/4” 20 40
CIL4507 1-1/2” 15 30
CIL4508 2” 9 18
CIL4509 2-1/2” 5 20
CIL4510 3” 5 15
CIL4511 4” 5 15
90º Reducing Elbow
CIRL0403 3/4” x 1/2” 1 125
CIRL0503 1” x 1/2” 50 100
CIRL0504 1” x 3/4” 40 80
CIRL0603 1-1/4” x 1/2” 35 70
CIRL0604 1-1/4” x 3/4” 1 55
CIRL0605 1-1/4” x 1” 1 45
CIRL0703 1-1/2” x 1/2” 25 50
CIRL0704 1-1/2” x 3/4” 20 40
CIRL0705 1-1/2” x 1” 18 36
CIRL0706 1-1/2” x 1-1/4” 14 28
CIRL0803 2” x 1/2” 16 32
CIRL0804 2” x 3/4” 16 32
CIRL0805 2” x 1” 13 26
CIRL0806 2” x 1-1/4” 11 22
CIRL0807 2” x 1-1/2” 9 18
CIRL0905 2-1/2” x 1” 1 15
CIRL0908 2-1/2” x 2” 1 15
CIRL1008 3” x 2” 1 8
Cast Iron Threaded
Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
15
Cast Iron Threaded Fittings
• Conforms with ANSI B16.4 Standards
• Stocked in Sizes 1/2” - 4”
Fittings
Cast Iron Threaded
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Reducing Tee
CIRT0503 1” x 1/2” 1 60
CIRT050305 1” x 1/2” x 1” 28 56
CIRT0504 1” x 3/4” 1 50
CIRT050405 1” x 3/4” x 1” 1 50
CIRT0603 1-1/4” x 1/2” 1 30
CIRT060306 1-1/4” x 1/2” x 1-1/4” 1 30
CIRT0604 1-1/4” x 3/4” 1 30
CIRT060406 1-1/4” x 3/4” x 1-1/4” 1 30
CIRT0605 1-1/4” x 1” 1 30
CIRT060503 1-1/4” x 1” x 1/2” 25 50
CIRT060504 1-1/4” x 1” x 3/4” 1 45
CIRT060505 1-1/4” x 1” x 1” 19 35
CIRT060506 1-1/4” x 1” x 1-1/4” 1 33
CIRT0703 1-1/2” x 1/2” 1 30
CIRT070306 1-1/2” x 1/2” x 1-1/4” 1 20
CIRT070307 1-1/2” x 1/2” x 1-1/2” 1 20
CIRT0704 1-1/2” x 3/4” 1 30
CIRT070406 1-1/2” x 3/4” x 1-1/4” 1 20
CIRT070407 1-1/2” x 3/4” x 1-1/2” 1 20
CIRT0705 1-1/2” x 1” 1 25
CIRT070503 1-1/2” x 1” x 1/2” 20 40
CIRT070504 1-1/2” x 1” x 3/4” 18 36
CIRT070505 1-1/2” x 1” x 1” 16 32
CIRT070506 1-1/2” x 1” x 1-1/4” 1 27
CIRT070507 1-1/2” x 1” x 1-1/2” 12 24
CIRT0706 1-1/2” x 1-1/4” 1 20
CIRT070603 1-1/2” x 1-1/4” x 1/2” 15 30
CIRT070604 1-1/2” x 1-1/4” x 3/4” 15 30
CIRT070605 1-1/2” x 1-1/4” x 1” 15 30
CIRT070606 1-1/2” x 1-1/4” x 1-1/4” 1 25
CIRT070607 1-1/2” x 1-1/4” x 1-1/2” 11 22
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Tee (Continued)
CIRT0803 2” x 1/2” 1 18
CIRT0804 2” x 3/4” 1 18
CIRT0805 2” x 1” 1 15
CIRT080508 2” x 1” x 2” 8 16
CIRT0806 2” x 1-1/4” 1 15
CIRT080608 2” x 1-1/4” x 2” 6 12
CIRT0807 2” x 1-1/2” 1 15
CIRT080703 2” x 1-1/2” x 1/2” 12 24
CIRT080704 2” x 1-1/2” x 3/4” 12 24
CIRT080705 2” x 1-1/2” x 1” 1 19
CIRT080706 2” x 1-1/2” x 1-1/4” 8 16
CIRT080707 2” x 1-1/2” x 1-1/2” 8 16
CIRT080708 2” x 1-1/2” x 2” 7 14
CIRT1006 3” x 1-1/4” 1 10
CIRT1007 3” x 1-1/2” 1 10
CIRT1008 3” x 2” 1 10
Bull Head Tee
CIRT050506 1” x 1” x 1-1/4” 21 42
CIRT050507 1” x 1” x 1-1/2” 17 34
CIRT060507 1-1/4” x 1” x 1-1/2” 1 27
CIRT060607 1-1/4” x 1-1/4” x 1-1/2” 12 24
CIRT060608 1-1/4” x 1-1/4” x 2” 10 20
CIRT070608 1-1/2” x 1-1/4” x 2” 1 17
CIRT070708 1-1/2” x 1-1/2” x 2” 9 18
16
Global sourcing. National compliance. Local service.
Fittings & Nipples
Forged Steel Fittings Class 2000 - Threaded
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
• Stocked in Sizes 1/8” - 4”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
FT2L9001 1/4” 150 150
FT2L9002 3/8” 100 100
FT2L9003 1/2” 80 80
FT2L9004 3/4” 50 50
FT2L9005 1” 30 30
FT2L9006 1-1/4” 20 20
FT2L9007 1-1/2” 15 15
FT2L9008 2” 8 8
FT2L9009 2-1/2” 4 4
FT2L9010 3” 2 2
FT2L9011 4” 1 1
Tee
FT2T01 1/4” 100 100
FT2T02 3/8” 80 80
FT2T03 1/2” 50 50
FT2T04 3/4” 35 35
FT2T05 1” 20 20
FT2T06 1-1/4” 15 15
FT2T07 1-1/2” 10 10
FT2T08 2” 6 6
FT2T09 2-1/2” 3 3
FT2T10 3” 2 2
FT2T11 4” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
FT2L4501 1/4” 150 150
FT2L4502 3/8” 100 100
FT2L4503 1/2” 80 80
FT2L4504 3/4” 50 50
FT2L4505 1” 30 30
FT2L4506 1-1/4” 20 20
FT2L4507 1-1/2” 15 15
FT2L4508 2” 10 10
FT2L4509 2-1/2” 5 5
FT2L4510 3” 2 2
FT2L4511 4” 1 1
Cross
FT2CR01 1/4” 40 40
FT2CR02 3/8” 40 40
FT2CR03 1/2” 40 40
FT2CR04 3/4” 30 30
FT2CR05 1” 20 20
FT2CR06 1-1/4” 10 10
FT2CR07 1-1/2” 6 6
FT2CR08 2” 4 4
FT2CR09 2-1/2” 3 3
Forged Steel Fittings
Class 2000
Fittings & Nipples
Global sourcing. National compliance. Local service.
17
Forged Steel Fittings Class 3000 - Threaded
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
• Stocked in Sizes 1/8” - 4”
Class 3000
Forged Steel Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
FT3L9000 1/8” 100 100
FT3L9001 1/4” 100 100
FT3L9002 3/8” 80 80
FT3L9003 1/2” 50 50
FT3L9004 3/4” 25 25
FT3L9005 1” 20 20
FT3L9006 1-1/4” 15 15
FT3L9007 1-1/2” 6 6
FT3L9008 2” 5 5
FT3L9009 2-1/2” 2 2
FT3L9010 3” 2 2
FT3L9011 4” 1 1
Tee
FT3T00 1/8” 80 80
FT3T01 1/4” 80 80
FT3T02 3/8” 50 50
FT3T03 1/2” 35 35
FT3T04 3/4” 20 20
FT3T05 1” 15 15
FT3T06 1-1/4” 10 10
FT3T07 1-1/2” 5 5
FT3T08 2” 4 4
FT3T09 2-1/2” 2 2
FT3T10 3” 1 1
FT3T11 4” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
FT3L4500 1/8” 100 100
FT3L4501 1/4” 100 100
FT3L4502 3/8” 80 80
FT3L4503 1/2” 50 50
FT3L4504 3/4” 30 30
FT3L4505 1” 20 20
FT3L4506 1-1/4” 15 15
FT3L4507 1-1/2” 8 8
FT3L4508 2” 6 6
FT3L4509 2-1/2” 2 2
FT3L4510 3” 2 2
FT3L4511 4” 1 1
Cross
FT3CR00 1/8” 40 40
FT3CR02 3/8” 20 20
FT3CR03 1/2” 30 30
FT3CR04 3/4” 20 20
FT3CR05 1” 12 12
FT3CR06 1-1/4” 6 6
FT3CR07 1-1/2” 4 4
FT3CR08 2” 4 4
FT3CR09 2-1/2” 2 2
FT3CR10 3” 2 2
18
Reducer Tee
FT3RT0403 3/4” x 1/2” 1 1
FT3RT0504 1” x 3/4” 1 1
FT3RT0704 1-1/2” x 3/4” 1 1
FT3RT0705 1-1/2” x 1” 1 1
Global sourcing. National compliance. Local service.
90º Street Elbow
FT3LST9000 1/8” 25 25
FT3LST9001 1/4” 150 150
FT3LST9002 3/8” 80 80
FT3LST9003 1/2” 50 50
FT3LST9004 3/4” 30 30
FT3LST9005 1” 20 20
FT3LST9006 1-1/4” 15 15
FT3LST9007 1-1/2” 8 8
FT3LST9008 2” 5 5
Fittings & Nipples
Forged Steel Fittings Class 3000 - Threaded
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
• Stocked in Sizes 1/8” - 4”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Couplings
FT3CP00 1/8” 15 15
FT3CP01 1/4” 250 250
FT3CP02 3/8” 200 200
FT3CP03 1/2” 100 100
FT3CP04 3/4” 70 70
FT3CP05 1” 35 35
FT3CP06 1-1/4” 20 20
FT3CP07 1-1/2” 15 15
FT3CP08 2” 10 10
FT3CP09 2-1/2” 5 5
FT3CP10 3” 3 3
FT3CP11 4” 2 2
Half Coupling
FT3HC00 1/8” 800 800
FT3HC01 1/4” 800 800
FT3HC02 3/8” 500 500
FT3HC03 1/2” 250 250
FT3HC04 3/4” 150 150
FT3HC05 1” 80 80
FT3HC06 1-1/4” 35 35
FT3HC07 1-1/2” 30 30
FT3HC08 2” 20 20
FT3HC09 2-1/2” 12 12
FT3HC10 3” 6 6
FT3HC11 4” 4 4
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducer Coupling
FT3RC0100 1/4” x 1/8” 250 250
FT3RC0200 3/8” x 1/8” 200 200
FT3RC0201 3/8” x 1/4” 200 200
FT3RC0300 1/2” x 1/8” 100 100
FT3RC0301 1/2” x 1/4” 100 100
FT3RC0302 1/2” x 3/8” 100 100
FT3RC0400 3/4” x 1/8” 70 70
FT3RC0401 3/4” x 1/4” 70 70
FT3RC0402 3/4” x 3/8” 70 70
FT3RC0403 3/4” x 1/2” 70 70
FT3RC0500 1” x 1/8” 35 35
FT3RC0501 1” x 1/4” 35 35
FT3RC0502 1” x 3/8” 35 35
FT3RC0503 1” x 1/2” 35 35
FT3RC0504 1” x 3/4” 35 35
FT3RC0601 1-1/4” x 1/4” 20 20
FT3RC0603 1-1/4” x 1/2” 20 20
FT3RC0604 1-1/4” x 3/4” 20 20
FT3RC0605 1-1/4” x 1” 20 20
FT3RC0702 1-1/2” x 3/8” 15 15
FT3RC0703 1-1/2” x 1/2” 15 15
FT3RC0704 1-1/2” x 3/4” 15 15
FT3RC0705 1-1/2” x 1” 15 15
FT3RC0706 1-1/2” x 1-1/4” 15 15
FT3RC0803 2” x 1/2” 10 10
FT3RC0804 2” x 3/4” 10 10
FT3RC0805 2” x 1” 10 10
FT3RC0806 2” x 1-1/4” 10 10
FT3RC0807 2” x 1-1/2” 10 10
FT3RC0908 2-1/2” x 2” 5 5
Forged Steel Fittings
Class 3000
Cap
FT3CA00 1/8” 300 300
FT3CA01 1/4” 300 300
FT3CA02 3/8” 250 250
FT3CA03 1/2” 130 130
FT3CA04 3/4” 80 80
FT3CA05 1” 50 50
FT3CA06 1-1/4” 30 30
FT3CA07 1-1/2” 25 25
FT3CA08 2” 15 15
FT3CA09 2-1/2” 10 10
FT3CA10 3” 4 4
FT3CA11 4” 3 3
Fittings & Nipples
Union
FT3UN00 1/8” 70 70
FT3UN01 1/4” 70 70
FT3UN02 3/8” 70 70
FT3UN03 1/2” 50 50
FT3UN04 3/4” 30 30
FT3UN05 1” 20 20
FT3UN06 1-1/4” 14 14
FT3UN07 1-1/2” 10 10
FT3UN08 2” 6 6
FT3UN09 2-1/2” 3 3
FT3UN10 3” 2 2
Global sourcing. National compliance. Local service.
19
Forged Steel Fittings
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
-
Threaded
• Stocked in Sizes 1/8” - 4”
Forged Steel Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Square Head Plug
FTSP00 1/8” 800 800
FTSP01 1/4” 800 800
FTSP02 3/8” 500 500
FTSP03 1/2” 300 300
FTSP04 3/4” 200 200
FTSP05 1” 150 150
FTSP06 1-1/4” 80 80
FTSP07 1-1/2” 50 50
FTSP08 2” 30 30
FTSP09 2-1/2” 15 15
FTSP10 3” 10 10
FTSP11 4” 3 3
Hex Head Plug
FTHP00 1/8” 800 800
FTHP01 1/4” 800 800
FTHP02 3/8” 600 600
FTHP03 1/2” 250 250
FTHP04 3/4” 150 150
FTHP05 1” 100 100
FTHP06 1-1/4” 35 35
FTHP07 1-1/2” 25 25
FTHP08 2” 20 20
FTHP09 2-1/2” 8 8
FTHP10 3” 6 6
FTHP11 4” 3 3
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Hex Bushing
FTBU0100 1/4” x 1/8” 600 600
FTBU0201 3/8” x 1/4” 500 500
FTBU0300 1/2” x 1/8” 400 400
FTBU0301 1/2” x 1/4” 400 400
FTBU0302 1/2” x 3/8” 400 400
FTBU0400 3/4” x 1/8” 200 200
FTBU0401 3/4” x 1/4” 200 200
FTBU0402 3/4” x 3/8” 200 200
FTBU0403 3/4” x 1/2” 200 200
FTBU0501 1” x 1/4” 100 100
FTBU0502 1” x 3/8” 100 100
FTBU0503 1” x 1/2” 100 100
FTBU0504 1” x 3/4” 100 100
FTBU0604 1-1/4” x 3/4” 60 60
FTBU0605 1-1/4” x 1” 60 60
FTBU0704 1-1/2” x 3/4” 50 50
FTBU0705 1-1/2” x 1” 50 50
FTBU0706 1-1/2” x 1-1/4” 50 50
FTBU0801 2” x 1/4” 25 25
FTBU0802 2” x 3/8” 25 25
FTBU0803 2” x 1/2” 25 25
FTBU0804 2” x 3/4” 25 25
FTBU0805 2” x 1” 25 25
FTBU0806 2” x 1-1/4” 25 25
FTBU0807 2” x 1-1/2” 25 25
FTBU0905 2-1/2” x 1” 15 15
FTBU0907 2-1/2” x 1-1/2” 15 15
FTBU0908 2-1/2” x 2” 15 15
FTBU1005 3” x 1” 10 10
FTBU1008 3” x 2” 10 10
FTBU1009 3” x 2-1/2” 10 10
FTBU1105 4” x 1” 5 5
FTBU1108 4” x 2” 5 5
FTBU1110 4” x 3” 5 5
20
Round Head Plug
FTRP00 1/8” 250 250
FTRP01 1/4” 250 250
FTRP02 3/8” 200 200
FTRP03 1/2” 150 150
FTRP04 3/4” 100 100
FTRP05 1” 80 80
FTRP07 1-1/2” 30 30
FTRP08 2” 15 15
Global sourcing. National compliance. Local service.
Fittings & Nipples
Forged Steel Fittings
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
Class 3000 - Socket Weld
• Stocked in Sizes 1/8” - 4”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
FW3L9000 1/8” 150 150
FW3L9001 1/4” 150 150
FW3L9002 3/8” 100 100
FW3L9003 1/2” 80 80
FW3L9004 3/4” 50 50
FW3L9005 1” 30 30
FW3L9006 1-1/4” 20 20
FW3L9007 1-1/2” 15 15
FW3L9008 2” 8 8
FW3L9009 2-1/2” 4 4
FW3L9010 3” 2 2
FW3L9011 4” 1 1
Tee
FW3T00 1/8” 100 100
FW3T01 1/4” 100 100
FW3T02 3/8” 80 80
FW3T03 1/2” 50 50
FW3T04 3/4” 35 35
FW3T05 1” 20 20
FW3T06 1-1/4” 15 15
FW3T07 1-1/2” 10 10
FW3T08 2” 6 6
FW3T09 2-1/2” 3 3
FW3T10 3” 2 2
FW3T11 4” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
FW3L4500 1/8” 150 150
FW3L4501 1/4” 150 150
FW3L4502 3/8” 100 100
FW3L4503 1/2” 80 80
FW3L4504 3/4” 50 50
FW3L4505 1” 30 30
FW3L4506 1-1/4” 20 20
FW3L4507 1-1/2” 15 15
FW3L4508 2” 10 10
FW3L4509 2-1/2” 5 5
FW3L4510 3” 2 2
FW3L4511 4” 1 1
Cross
FW3CR00 1/8” 40 40
FW3CR01 1/4” 40 40
FW3CR02 3/8” 40 40
FW3CR03 1/2” 40 40
FW3CR04 3/4” 30 30
FW3CR05 1” 20 20
FW3CR06 1-1/4” 10 10
FW3CR07 1-1/2” 6 6
FW3CR08 2” 4 4
FW3CR09 2-1/2” 3 3
FW3CR10 3” 2 2
Forged Steel Fittings
Class 3000
Fittings & Nipples
Global sourcing. National compliance. Local service.
21
Forged Steel Fittings
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
Class 3000 - Socket Weld
• Stocked in Sizes 1/8” - 4”
Class 3000
Forged Steel Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Coupling
FW3CP00 1/8” 350 350
FW3CP01 1/4” 350 350
FW3CP02 3/8” 250 250
FW3CP03 1/2” 120 120
FW3CP04 3/4” 80 80
FW3CP05 1” 50 50
FW3CP06 1-1/4” 30 30
FW3CP07 1-1/2” 25 25
FW3CP08 2” 15 15
FW3CP09 2-1/2” 10 10
FW3CP10 3” 6 6
FW3CP11 4” 4 4
Half Coupling
FW3HC00 1/8” 400 400
FW3HC01 1/4” 400 400
FW3HC02 3/8” 300 300
FW3HC03 1/2” 120 120
FW3HC04 3/4” 80 80
FW3HC05 1” 50 50
FW3HC06 1-1/4” 30 30
FW3HC07 1-1/2” 25 25
FW3HC08 2” 15 15
FW3HC09 2-1/2” 10 10
FW3HC10 3” 6 6
FW3HC11 4” 4 4
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Cap
FW3CA00 1/8” 300 300
FW3CA01 1/4” 300 300
FW3CA02 3/8” 250 250
FW3CA03 1/2” 130 130
FW3CA04 3/4” 80 80
FW3CA05 1” 50 50
FW3CA06 1-1/4” 30 30
FW3CA07 1-1/2” 25 25
FW3CA08 2” 15 15
FW3CA09 2-1/2” 10 10
FW3CA10 3” 4 4
FW3CA11 4” 3 3
Union
FW3UN00 1/8” 70 70
FW3UN01 1/4” 70 70
FW3UN02 3/8” 70 70
FW3UN03 1/2” 50 50
FW3UN04 3/4” 30 30
FW3UN05 1” 20 20
FW3UN06 1-1/4” 14 14
FW3UN07 1-1/2” 10 10
FW3UN08 2” 6 6
FW3UN09 2-1/2” 3 3
FW3UN10 3” 2 2
22
Global sourcing. National compliance. Local service.
Fittings & Nipples
Forged Steel Fittings
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
Class 3000 - Socket Weld
• Stocked in Sizes 1/8” - 4”
MATCONORCA
MODEL NUMBER SIZESIZE
CARTON QUANTITIES
INNER MASTER
Reducer Coupling
FW3RC0100 1/4” x 1/8” 250 250
FW3RC0200 3/8” x 1/8” 200 200
FW3RC0201 3/8” x 1/4” 200 200
FW3RC0300 1/2” x 1/8” 100 100
FW3RC0301 1/2” x 1/4” 100 100
FW3RC0302 1/2” x 3/8” 100 100
FW3RC0400 3/4” x 1/8” 70 70
FW3RC0401 3/4” x 1/4” 70 70
FW3RC0402 3/4” x 3/8” 70 70
FW3RC0403 3/4” x 1/2” 70 70
FW3RC0500 1” x 1/8” 35 35
FW3RC0501 1” x 1/4” 35 35
FW3RC0502 1” x 3/8” 35 35
FW3RC0503 1” x 1/2” 35 35
FW3RC0504 1” x 3/4” 35 35
FW3RC0601 1-1/4” x 1/4” 20 20
FW3RC0602 1-1/4” x 3/8” 20 20
FW3RC0603 1-1/4” x 1/2” 20 20
FW3RC0604 1-1/4” x 3/4” 20 20
FW3RC0605 1-1/4” x 1” 20 20
FW3RC0702 1-1/2” x 3/8” 15 15
FW3RC0703 1-1/2” x 1/2” 15 15
FW3RC0704 1-1/2” x 3/4” 15 15
FW3RC0705 1-1/2” x 1” 15 15
FW3RC0706 1-1/2” x 1-1/4” 15 15
FW3RC0803 2” x 1/2” 10 10
FW3RC0804 2” x 3/4” 10 10
FW3RC0805 2” x 1” 10 10
FW3RC0806 2” x 1-1/4” 10 10
FW3RC0807 2” x 1-1/2” 10 10
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Reducer Insert
FW3RI0301 1/2” x 1/4” 150 150
FW3RI0302 1/2” x 3/8” 150 150
FW3RI0401 3/4” x 1/4” 100 100
FW3RI0402 3/4” x 3/8” 100 100
FW3RI0403 3/4” x 1/2” 100 100
FW3RI0501 1” x 1/4” 80 80
FW3RI0502 1” x 3/8” 80 80
FW3RI0503 1” x 1/2” 80 80
FW3RI0504 1” x 3/4” 80 80
FW3RI0601 1-1/4” x 1/4” 60 60
FW3RI0602 1-1/4” x 3/8” 60 60
FW3RI0603 1-1/4” x 1/2” 60 60
FW3RI0604 1-1/4” x 3/4” 60 60
FW3RI0605 1-1/4” x 1” 60 60
FW3RI0702 1-1/2” x 3/8” 40 40
FW3RI0703 1-1/2” x 1/2” 40 40
FW3RI0704 1-1/2” x 3/4” 40 40
FW3RI0705 1-1/2” x 1” 40 40
FW3RI0706 1-1/2” x 1-1/4” 40
FW3RI0803 2” x 1/2” 25 25
FW3RI0804 2” x 3/4” 25 25
FW3RI0805 2” x 1” 25 25
FW3RI0806 2” x 1-1/4” 25 25
FW3RI0807 2” x 1-1/2” 25 25
FW3RI0904 2-1/2” x 3/4” 12 12
FW3RI0905 2-1/2” x 1” 12 12
FW3RI0906 2-1/2” x 1-1/4” 12 12
FW3RI0907 2-1/2” x 1-1/2” 12 12
FW3RI0908 2-1/2” x 2” 12 12
FW3RI1005 3” x 1” 10 10
FW3RI1006 3” x 1-1/4” 10 10
FW3RI1007 3” x 1-1/2” 10 10
FW3RI1008 3” x 2” 10 10
FW3RI1009 3” x 2-1/2” 10 10
Forged Steel Fittings
Class 3000
Fittings & Nipples
Global sourcing. National compliance. Local service.
23
Forged Steel Fittings Class 6000 - Threaded
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
• Stocked in Sizes 1/8” - 4”
Class 6000
Forged Steel Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
FT6L9003 1/2” 25 25
FT6L9004 3/4” 20 20
FT6L9005 1” 12 12
FT6L9006 1-1/4” 5 5
FT6L9007 1-1/2” 4 4
FT6L9008 2” 2 2
FT6L9009 2-1/2” 1 1
FT6L9010 3” 1 1
Coupling
FT6CP01 1/4” 200 200
FT6CP02 3/8” 100 100
FT6CP03 1/2” 60 60
FT6CP04 3/4” 35 35
FT6CP05 1” 20 20
FT6CP06 1-1/4” 15 15
FT6CP07 1-1/2” 10 10
FT6CP08 2” 5 5
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
FT6L4504 3/4” 20 20
FT6L4505 1” 12 12
FT6L4506 1-1/4” 5 5
FT6L4507 1-1/2” 4 4
FT6L4508 2” 2 2
FT6L4509 2-1/2” 1 1
FT6L4510 3 1 1
Tee
FT6T03 1/2” 20 20
FT6T04 3/4” 12 12
FT6T05 1” 10 10
FT6T06 1-1/4” 5 5
FT6T07 1-1/2” 2 2
FT6T08 2” 2 2
FT6T09 2-1/2” 1 1
24
Half Coupling
FT6HC01 1/4” 150 150
FT6HC02 3/8” 80 80
FT6HC03 1/2” 80 80
FT6HC04 3/4” 50 50
FT6HC05 1” 35 35
FT6HC06 1-1/4” 25 25
FT6HC07 1-1/2” 20 20
FT6HC08 2” 6 6
Global sourcing. National compliance. Local service.
Cap
FT6CA05 1” 30 30
FT6CA06 1-1/4” 25 25
FT6CA07 1-1/2” 15 15
FT6CA08 2” 10 10
FT6CA10 3” 3 3
Union
FT6UN03 1/2” 30 30
FT6UN04 3/4” 20 20
FT6UN05 1” 15 15
FT6UN06 1-1/4” 10 10
FT6UN07 1-1/2” 6 6
FT6UN08 2” 3 3
Fittings & Nipples
Forged Steel Fittings Class 6000 - Threaded
• Meets All Applicable ANSI & MSS Standards
• Material Conforms with ASTM A105N
• Stocked in Class 2000, 3000 & 6000
• Material Test Reports (MTR’S) Available
• Stocked in Sizes 1/8” - 4”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
FW6L9003 1/2” 50 50
FW6L9005 1” 20 20
FW6L9006 1-1/4” 15 15
FW6L9007 1-1/2” 6 6
FW6L9008 2” 5 5
FW6L9010 3” 1 1
FW6L9011 4” 1 1
Tee
FW6T03 1/2” 50 50
FW6T04 3/4” 35 35
FW6T05 1” 20 20
FW6T06 1-1/4” 15 15
FW6T07 1-1/2” 10 10
FW6T08 2” 6 6
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45º Elbow
FW6L4503 1/2” 50 50
FW6L4504 3/4” 30 30
FW6L4505 1” 20 20
FW6L4506 1-1/4” 15 15
FW6L4507 1-1/2” 8 8
FW6L4508 2” 6 6
Cap
FW6CA04 3/4” 50 50
FW6CA05 1” 35 35
Forged Steel Fittings
Class 6000
Coupling
FW6CP03 1/2” 100 100
FW6CP04 3/4” 70 70
FW6CP05 1” 35 35
FW6CP06 1-1/4” 20 20
FW6CP07 1-1/2” 15 15
FW6CP08 2” 10 10
Reducer Coupling
FW6RC0403 3/4” x 1/2” 70 70
FW6RC0503 1” x 1/2” 35 35
FW6RC0504 1” x 3/4” 35 35
FW6RC0604 1-1/4” x 3/4” 20 20
FW6RC0605 1-1/4” x 1” 20 20
FW6RC0705 1-1/2” x 1” 15 15
FW6RC0706 1-1/2” x 1-1/4” 15 15
FW6RC0804 2” x 3/4” 10 10
FW6RC0806 2” x 1-1/4” 10 10
FW6RC0807 2” x 1-1/2” 10 10
Fittings & Nipples
Union
FW6UN03 1/2” 30 30
FW6UN04 3/4” 20 20
FW6UN05 1” 15 15
FW6UN06 1-1/4” 10 10
FW6UN07 1-1/2” 6 6
FW6UN08 2” 3 3
Reducer Insert
FW6RI0804 2” x 3/4” 20 20
FW6RI0805 2” x 1” 20 20
Global sourcing. National compliance. Local service.
25
Forged Steel Branch Outlets
• Material Conforms with ASTM A105N & MSS-SP-97 • Straight Through Bore Design
• Material Test Reports (MTR’S) Available • Stocked in Threaded, Socket Weld
& Butt Weld
Forged Steel Branch
Outlets
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
3000# Threaded
T360201 36” - 3/8” RUN x 1/4” 1 60
T360302 36” - 1/2” RUN x 3/8” 1 60
T360403 36” - 3/4” RUN x 1/2” 1 150
T360504 36” -1” RUN x 3/4” 1 100
T070605 1-1/2” - 1-1/4” RUN x 1” 1 50
T360805 36” - 2” RUN x 1” 1 50
T0706 1-1/2” RUN x 1-1/4” 1 35
T100806 3” - 2” RUN x 1-1/4” 1 35
T3610506 36” - 3-1/2” RUN x 1-1/4” 1 35
T0807 2” RUN x 1-1/2” 1 25
T110907 4” - 2-1/2” RUN x 1-1/2” 1 25
T361207 36” - 5” RUN x 1-1/2” 1 25
T0908 2-1/2” RUN x 2” 1 15
T1051008 3-1/2” - 3” RUN x 2” 1 15
T131108 6” - 4” RUN x 2” 1 15
T361408 36” - 8” RUN x 2” 1 15
T1009 3” RUN x 2-1/2” 1 10
T1110509 4” - 3-1/2” RUN x 2-1/2” 1 10
T141209 8” - 5” RUN x 2-1/2” 1 10
T361509 36” - 10” RUN x 2-1/2” 1 10
T10510 3-1/2” RUN x 3” 1 6
T1110 4” RUN x 3” 1 6
T1210 5” RUN x 3” 1 6
T1310 6” RUN x 3” 1 6
T161410 12” - 8” RUN x 3” 1 3
T361710 36” - 14” RUN x 3” 1 3
T1211 5” RUN x 4” 1 3
T1311 6” RUN x 4” 1 3
T1411 8” RUN x 4” 1 3
T1511 10” RUN x 4” 1 3
T181611 16” - 12” RUN x 4” 1 3
T361911 36” - 18” RUN x 4” 1 3
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
3000# Socket Weld
SW360403 36” - 3/4” RUN x 1/2” 1 150
SW360504 36” - 1” RUN x 3/4” 1 100
SW070605 1-1/2” - 1-1/4” RUN x 1” 1 50
SW360805 36” - 2” RUN x 1” 1 50
SW0706 1-1/2” RUN x 1-1/4” 1 35
SW100806 3” - 2” RUN x 1-1/4” 1 35
SW3610506 36” - 3-1/2” RUN x 1-1/4” 1 35
SW0807 2” RUN x 1-1/2” 1 25
SW110907 4” - 2-1/2” RUN x 1-1/2” 1 25
SW361207 36” - 5” RUN x 1-1/2” 1 25
SW0908 2-1/2” RUN x 2” 1 15
SW1051008 3-1/2” - 3” RUN x 2” 1 15
SW131108 6” - 4” RUN x 2” 1 15
SW361408 36” - 8” RUN x 2” 1 15
SW1009 3” RUN x 2-1/2” 1 10
SW1110509 4” - 3-1/2” RUN x 2-1/2” 1 10
SW141209 8” - 5” RUN x 2-1/2” 1 10
SW361509 36” - 10” RUN x 2-1/2” 1 10
SW10510 3-1/2” RUN x 3” 1 6
SW1110 4” RUN x 3” 1 6
SW1210 5” RUN x 3” 1 6
SW1310 6” RUN x 3” 1 6
SW161410 12” - 8” RUN x 3” 1 3
SW361710 36” - 14” RUN x 3” 1 3
SW1211 5” RUN x 4” 1 3
SW1311 6” RUN x 4” 1 3
SW1411 8” RUN x 4” 1 3
SW1511 10” RUN x 4” 1 3
SW181611 16” - 12” RUN x 4” 1 3
SW361911 36” - 18” RUN x 4” 1 3
26
Global sourcing. National compliance. Local service.
Fittings & Nipples
Forged Steel Branch Outlets
• Material Conforms with ASTM A105N & MSS-SP-97 • Straight Through Bore Design
• Material Test Reports (MTR’S) Available • Stocked in Threaded, Socket Weld
& Butt Weld
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Butt Weld - Schedule 80
BW360403 36” - 3/4” RUN x 1/2” 1 150
BW360504 36” - 1” RUN x 3/4” 1 100
BW070605 1-1/2” - 1-1/4” RUN x 1” 1 50
BW360805 36” - 2” RUN x 1” 1 50
BW0706 1-1/2” RUN x 1-1/4” 1 35
BW100806 3” - 2” RUN x 1-1/4“ 1 35
BW3610506 36” - 3-1/2” RUN x 1-1/4” 1 35
BW0807 2” RUN x 1-1/2” 1 25
BW110907 4” - 2-1/2” x 1-1/2” 1 25
BW361207 36” - 5” RUN x 1-1/2” 1 25
BW0908 2-1/2” RUN x 2” 1 15
BW1051008 3-1/2” - 3” RUN x 2” 1 15
BW131108 6” - 4” RUN x 2” 1 15
BW361408 36” - 8” RUN x 2” 1 15
BW1009 3” RUN x 2-1/2” 1 10
BW1110509 4” - 3-1/2” RUN x 2-1/2” 1 10
BW141209 8” - 5” RUN x 2-1/2” 1 10
BW361509 36” - 10” RUN x 2-1/2” 1 10
BW10510 3-1/2” RUN x 3” 1 6
BW1110 4” RUN x 3” 1 6
BW1210 5” RUN x 3” 1 6
BW1310 6” RUN x 3” 1 6
BW161410 12” - 8” RUN x 3” 1 3
BW361710 36” - 14” RUN x 3” 1 3
BW1211 5” RUN x 4” 1 3
BW1311 6” RUN x 4” 1 3
BW1411 8” RUN x 4 “ 1 3
BW1511 10” RUN x 4” 1 3
BW181611 16” - 12” RUN x 4” 1 3
BW361911 36” - 18” RUN x 4” 1 3
BW1513 10” RUN x 6” 1 3
BW1614 12” RUN x 8” 1 3
For more information about Forged Steel
Branch Outlets contact the Matco-Norca
Commercial / Industrial Sales Team
5899 Preston Road, Suite 1201, Frisco, TX 75034
TEL: 877-362-5122 • FAX: 469-362-8100
www.matco-norca.com
Forged Steel Branch
Outlets
Fittings & Nipples
Global sourcing. National compliance. Local service.
27
Poly Pex Fittings
• Modied Polyphenylsulfone (PPSU) Molded
From Acudel® Resin
• NSF 14, NSF/ANSI 61/Annex G, ASTM
F2159, F877 & CSA B137.5 Approved
• 200º F Max Service Temperature
• For Use in Hot and Cold Potable Water
Distribution Systems
• Lead Free Compliant
Poly Pex Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Adapter - Pex Barb x MIP
PPSUM0303 1/2” x 1/2” 25 1000
PPSUM0304 1/2” x 3/4” 25 600
PPSUM0403 3/4” x 1/2” 25 600
PPSUM0404 3/4” x 3/4” 25 500
Adapter (Nipple) - MIP x MIP
PPSUMN03 1/2” x 1/2” 25 750
Adapter - Pex Barb x FIP
PPSUF0303 1/2” x 1/2” 25 600
Swivel Adapter - Pex Barb x FIP
PPSUF0203S 3/8” x 1/2” 25 600
PPSUF0303S 1/2” x 1/2” 25 600
PPSUF0378S 1/2” x 7/8” 25 600
Coupling - Pex Barb x Pex Barb
PPSUCP02 3/8” 20 3000
PPSUCP03 1/2” 25 2000
PPSUCP04 3/4” 25 1000
PPSUCP05 1” 10 600
PPSUCPR0302 1/2” x 3/8” 25 2500
PPSUCPR0403 3/4” x 1/2” 25 1250
PPSUCPR0504 1” x 3/4” 10 600
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Elbow - Pex Barb x Pex Barb
PPSUL02 3/8” 25 2250
PPSUL03 1/2” 25 1250
PPSUL04 3/4” 25 600
PPSULR0403 3/4” x 1/2” 25 750
PPSUL05 1” 10 300
Elbow - Pex Barb x MIP
PPSULMR0302 1/2” x 3/8” 25 750
PPSULM0303 1/2” x 1/2” 25 750
PPSULM0404 3/4” x 3/4” 25 400
Tee - Pex Barb
PPSUT02 3/8” 25 1500
PPSUT03 1/2” 25 750
PPSUT04 3/4” 25 400
PPSUT05 1” 10 200
PPSUTR030304 1/2” x 1/2” x 3/4” 25 600
PPSUTR040303 3/4” x 1/2” x 1/2” 25 600
PPSUTR040304 3/4” x 1/2” x 3/4” 25 500
PPSUTR040403 3/4” x 3/4” x 1/2” 25 500
PPSUTR050404 1” x 3/4” x 3/4” 25 300
PPSUTR050405 1” x 3/4” x 1” 10 300
PPSUTR050503 1” x 1” x 1/2” 10 300
PPSUTR050504 1” x 1” 3/4” 10 300
Tee - Pex Barb x Pex Barb x MIP
PPSUT03M 1/2” x 1/2” x 1/2” 25 600
28
Plug - Pex Barb
PPSUTP02 3/8” 25 6000
PPSUTP03 1/2” 25 3500
PPSUTP04 3/4” 25 1000
PPSUTP05 1” 10 1000
Global sourcing. National compliance. Local service.
Fittings & Nipples
F1960 Cold Expansion Pex Fittings
• Used in Hot & Cold Potable Water Distribution Systems
• NSF 14, NSF/ANSI 372, NSF/ANSI 61, cNSFus pw-G
ASTM F1960, U.P. Code & CSA B137.5 Approved
• Max. Working Temp./Pressure: 210ºF @ 150 PSI
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Coupling
PPCECP03
PPCECP04
PPCECP05
PPCECPR0403
PPCECPR0504
1/2”
3/4”
1”
3/4” x 1/2”
1” x 3/4”
25
25
10
25
25
Elbow
PPCEL03
PPCEL04
PPCEL05
PPCELR0403
1/2”
3/4”
1”
3/4” x 1/2”
25
10
10
10
• Max. Temp. (no pressure): 320ºF
• Lead Free Compliant
• Modied Polyphenylsulfone (PPSU)
Molded From RADEL @ R-5100 BK937
MATCONORCA
MODEL NUMBER SIZE
Tee
1000
400
250
600
250
750
300
180
550
PPCET03
PPCET04
PPCET05
PPCETR030304
PPCETR0403
PPCETR040303
PPCETR040304
PPCETR0503
PPCETR0504
PPCETR050404
PPCETR050405
Ring with Stop
PPCER03
PPCER04
PPCER05
1/2”
3/4”
1”
1/2” x 1/2” x 3/4”
3/4” x 1/2”
3/4” x 1/2” x 1/2”
3/4” x 1/2” x 3/4”
1” x 1/2”
1” x 3/4”
1” x 3/4” x 3/4”
1” x 3/4” x 1”
1/2”
3/4”
1”
CARTON QUANTITIES
INNER MASTER
25
10
10
25
10
10
10
10
10
10
10
50
50
50
500
150
100
400
250
350
250
120
120
120
120
1500
1000
500
Cold Expansion
Pex Fittings
Male Adapter
PPCEM0303
PPCEM0404
1/2” x 1/2”
3/4” x 3/4”
Plug
PPCETP03
PPCETP04
PPCETP05
1/2”
3/4”
1”
Fittings & Nipples
25
10
50
25
25
850
500
2000
800
500
Global sourcing. National compliance. Local service.
29
Weld Fittings
Standard Weight
• Standard & Extra Heavy Wall Dimensions
• Conforms to ASTM / ASME A/SA 234-WPB ANSI B16.9, B16.28 and B16.25
• Stocked 2” - 12”
Weld Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Long Radius 90° Elbow
MN90LR08 2” 1 1
MN90LR09 2-1/2” 1 1
MN90LR10 3” 1 1
MN90LR105 3-1/2” 1 1
MN90LR11 4” 1 1
MN90LR12 5” 1 1
MN90LR13 6” 1 1
MN90LR14 8” 1 1
MN90LR15 10” 1 1
MN90LR16 12” 1 1
Short Radius 90° Elbow
MN90SR08 2” 1 1
MN90SR09 2-1/2” 1 1
MN90SR10 3” 1 1
MN90SR105 3-1/2” 1 1
MN90SR11 4” 1 1
MN90SR12 5” 1 1
MN90SR13 6” 1 1
MN90SR14 8” 1 1
MN90SR15 10” 1 1
MN90SR16 12” 1 1
45° Elbow
MN4508 2” 1 1
MN4509 2-1/2” 1 1
MN4510 3” 1 1
MN45105 3-1/2” 1 1
MN4511 4” 1 1
MN4512 5” 1 1
MN4513 6” 1 1
MN4514 8” 1 1
MN4515 10” 1 1
MN4516 12” 1 1
Cap
MNCA08 2” 1 1
MNCA09 2-1/2” 1 1
MNCA10 3” 1 1
MNCA105 3-1/2” 1 1
MNCA11 4” 1 1
MNCA12 5” 1 1
MNCA13 6” 1 1
MNCA14 8” 1 1
MNCA15 10” 1 1
MNCA16 12” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Tee
MNT08 2” 1 1
MNT09 2-1/2” 1 1
MNT10 3” 1 1
MNT105 3-1/2” 1 1
MNT11 4” 1 1
MNT12 5” 1 1
MNT13 6” 1 1
MNT14 8” 1 1
MNT15 10” 1 1
MNT16 12” 1 1
Reducing Tee
MNRT0804 2” x 3/4” 1 1
MNRT0805 2” x 1” 1 1
MNRT0807 2” x 1-1/2” 1 1
MNRT0904 2-1/2” x 3/4” 1 1
MNRT0905 2-1/2” x 1” 1 1
MNRT0907 2-1/2” x 1-1/2” 1 1
MNRT1007 3” x 1-1/2” 1 1
MNRT1008 3” x 2” 1 1
MNRT1009 3” x 2-1/2” 1 1
MNRT10510 3-1/2” x 3” 1 1
MNRT10508 3-1/2” x 2” 1 1
MNRT1108 4” x 2” 1 1
MNRT1109 4” x 2-1/2” 1 1
MNRT1110 4” x 3” 1 1
MNRT1209 5” x 2-1/2” 1 1
MNRT1210 5” x 3” 1 1
MNRT1211 5” x 4” 1 1
MNRT1310 6” x 3” 1 1
MNRT1311 6” x 4” 1 1
MNRT1312 6” x 5” 1 1
MNRT1411 8” x 4” 1 1
MNRT1412 8” x 5” 1 1
MNRT1413 8” x 6” 1 1
MNRT1512 10” X 5” 1 1
MNRT1513 10” x 6” 1 1
MNRT1514 10” x 8” 1 1
MNRT1613 12” x 6” 1 1
MNRT1614 12” x 8” 1 1
MNRT1615 12” x 10” 1 1
30
Global sourcing. National compliance. Local service.
Fittings & Nipples
Weld Fittings
Standard Weight
• Standard & Extra Heavy Wall Dimensions
• Conforms to ASTM / ASME A/SA 234-WPB ANSI B16.9, B16.28 and B16.25
• Stocked 2” - 12”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Concentric Reducer
MNCR0804 2” x 3/4” 1 1
MNCR0805 2” x 1” 1 1
MNCR0807 2” x 1-1/2” 1 1
MNCR0905 2-1/2” x 1” 1 1
MNCR0907 2-1/2” x 1-1/2” 1 1
MNCR0908 2-1/2” x 2 “ 1 1
MNCR1007 3” x 1-1/2” 1 1
MNCR1008 3” x 2” 1 1
MNCR1009 3” x 2-1/2” 1 1
MNCR1107 4” x 1-1/2” 1 1
MNCR1108 4” x 2” 1 1
MNCR1109 4” x 2-1/2” 1 1
MNCR1110 4” x 3” 1 1
MNCR1210 5” x 3” 1 1
MNCR1211 5” x 4” 1 1
MNCR1308 6” x 2” 1 1
MNCR1309 6” x 2-1/2” 1 1
MNCR1310 6” x 3” 1 1
MNCR1311 6” x 4” 1 1
MNCR1312 6” x 5” 1 1
MNCR1411 8” x 4” 1 1
MNCR1412 8” x 5” 1 1
MNCR1413 8” x 6” 1 1
MNCR1513 10” x 6” 1 1
MNCR1514 10” x 8” 1 1
MNCR1613 12” x 6” 1 1
MNCR1614 12” x 8” 1 1
MNCR1615 12” x 10” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Eccentric Reducer
MNER0804 2” x 3/4” 1 1
MNER0805 2” x 1” 1 1
MNER0807 2” x 1-1/2” 1 1
MNER0905 2-1/2” x 1” 1 1
MNER0907 2-1/2” x 1-1/2” 1 1
MNER0908 2-1/2” x 2” 1 1
MNER1007 3” x 1-1/2” 1 1
MNER1008 3” x 2” 1 1
MNER1009 3” x 2-1/2” 1 1
MNER1108 4” x 2” 1 1
MNER1109 4” x 2-1/2” 1 1
MNER1110 4” x 3” 1 1
MNER1209 5” x 2-1/2” 1 1
MNER1210 5” x 3” 1 1
MNER1211 5” x 4” 1 1
MNER1310 6” x 3” 1 1
MNER1311 6” x 4” 1 1
MNER1312 6” x 5” 1 1
MNER1411 8” x 4” 1 1
MNER1413 8” x 6” 1 1
MNER1513 10” x 6” 1 1
MNER1514 10” x 8” 1 1
MNER1613 12” x 6” 1 1
MNER1614 12” x 8” 1 1
MNER1615 12” x 10” 1 1
Weld Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
31
Weld Fittings
Extra Heavy
• Standard & Extra Heavy Wall Dimensions
• Conforms to ASTM / ASME A/SA 234-WPB ANSI B16.9, B16.28 and B16.25
• Stocked 2” - 12”
Weld Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
XH 45° Elbow
MN45XH08 2” 1 1
MN45XH09 2-1/2” 1 1
MN45XH10 3” 1 1
MN45XH105 3-1/2” 1 1
MN45XH11 4” 1 1
MN45XH12 5” 1 1
MN45XH13 6” 1 1
MN45XH14 8” 1 1
MN45XH15 10” 1 1
MN45XH16 12” 1 1
XH Long Radius 90° Elbow
MN90LRXH08 2” 1 1
MN90LRXH09 2-1/2” 1 1
MN90LRXH10 3” 1 1
MN90LRXH105 3-1/2” 1 1
MN90LRXH11 4” 1 1
MN90LRXH12 5” 1 1
MN90LRXH13 6” 1 1
MN90LRXH14 8” 1 1
MN90LRXH15 10” 1 1
MN90LRXH16 12” 1 1
XH Short Radius 90° Elbow
MN90SRXH08 2” 1 1
MN90SRXH09 2-1/2” 1 1
MN90SRXH10 3” 1 1
MN90SRXH105 3-1/2” 1 1
MN90SRXH11 4” 1 1
MN90SRXH12 5” 1 1
MN90SRXH13 6” 1 1
MN90SRXH14 8” 1 1
MN90SRXH15 10” 1 1
MN90SRXH16 12” 1 1
XH Cap
MNCAXH08 2” 1 1
MNCAXH09 2-1/2” 1 1
MNCAXH10 3” 1 1
MNCAXH105 3-1/2” 1 1
MNCAXH11 4” 1 1
MNCAXH12 5” 1 1
MNCAXH13 6” 1 1
MNCAXH14 8” 1 1
MNCAXH15 10” 1 1
MNCAXH16 12” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
XH Tee
MNTXH08 2” 1 1
MNTXH09 2-1/2” 1 1
MNTXH10 3” 1 1
MNTXH105 3-1/2” 1 1
MNTXH11 4” 1 1
MNTXH12 5” 1 1
MNTXH13 6” 1 1
MNTXH14 8” 1 1
MNTXH15 10” 1 1
MNTXH16 12” 1 1
XH Reducing Tee
MNRTXH0805 2” x 1” 1 1
MNRTXH0806 2” x 1-1/4” 1 1
MNRTXH0807 2” x 1-1/2” 1 1
MNRTXH0905 2-1/2” x 1” 1 1
MNRTXH0907 2-1/2” x 1-1/2” 1 1
MNRTXH0908 2-1/2” x 2” 1 1
MNRTXH1007 3” x 1-1/2” 1 1
MNRTXH1008 3” x 2” 1 1
MNRTXH1009 3” x 2-1/2” 1 1
MNRTXH10507 3-1/2” x 1-1/2” 1 1
MNRTXH10508 3-1/2” x 2” 1 1
MNRTXH1108 4” x 2” 1 1
MNRTXH1109 4” x 2-1/2” 1 1
MNRTXH1110 4” x 3” 1 1
MNRTXH1210 5” x 3” 1 1
MNRTXH1211 5” x 4” 1 1
MNRTXH1311 6” x 4” 1 1
MNRTXH1312 6” x 5” 1 1
MNRTXH1411 8” x 4” 1 1
MNRTXH1413 8” x 6” 1 1
MNRTXH1513 10” x 6” 1 1
MNRTXH1514 10” x 8” 1 1
MNRTXH1614 12” x 8” 1 1
MNRTXH1615 12” x 10” 1 1
32
Global sourcing. National compliance. Local service.
Fittings & Nipples
Weld Fittings
Extra Heavy
• Standard & Extra Heavy Wall Dimensions
• Conforms to ASTM / ASME A/SA 234-WPB ANSI B16.9, B16.28 and B16.25
• Stocked 2” - 12”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
XH Concentric Reducer
MNCRXH0805 2” x 1” 1 1
MNCRXH0806 2” x 1-1/4” 1 1
MNCRXH0807 2” x 1-1/2” 1 1
MNCRXH0905 2-1/2” x 1” 1 1
MNCRXH0906 2-1/2” x 1-1/4” 1 1
MNCRXH0907 2-1/2” x 1-1/2” 1 1
MNCRXH0908 2-1/2” x 2” 1 1
MNCRXH1007 3” x 1-1/2” 1 1
MNCRXH1008 3” x 2” 1 1
MNCRXH1009 3” x 2-1/2” 1 1
MNCRXH1107 4” x 1-1/2” 1 1
MNCRXH1108 4” x 2” 1 1
MNCRXH1109 4” x 2-1/2” 1 1
MNCRXH1110 4” x 3” 1 1
MNCRXH1210 5” x 3” 1 1
MNCRXH12105 5” x 3-1/2” 1 1
MNCRXH1211 5” x 4” 1 1
MNCRXH1310 6” x 3” 1 1
MNCRXH1311 6” x 4” 1 1
MNCRXH1312 6” x 5” 1 1
MNCRXH1412 8” x 5” 1 1
MNCRXH1413 8” x 6” 1 1
MNCRXH1513 10” x 6” 1 1
MNCRXH1514 10” x 8” 1 1
MNCRXH1613 12” x 6” 1 1
MNCRXH1614 12” x 8” 1 1
MNCRXH1615 12” x 10” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
XH Eccentric Reducer
MNERXH0805 2” x 1” 1 1
MNERXH0806 2” x 1-1/4” 1 1
MNERXH0807 2” x 1-1/2” 1 1
MNERXH0906 2-1/2” x 1-1/4” 1 1
MNERXH0907 2-1/2” x 1-1/2” 1 1
MNERXH0908 2-1/2” x 2” 1 1
MNERXH1007 3” x 1-1/2” 1 1
MNERXH1008 3” x 2” 1 1
MNERXH1009 3” x 2-1/2” 1 1
MNERXH1108 4” x 2” 1 1
MNERXH1109 4” x 2-1/2” 1 1
MNERXH1110 4” x 3” 1 1
MNERXH1210 5” x 3” 1 1
MNERXH1211 5” x 4” 1 1
MNERXH1310 6” x 3” 1 1
MNERXH1311 6” x 4” 1 1
MNERXH1312 6” x 5” 1 1
MNERXH1411 8” x 4” 1 1
MNERXH1412 8” x 5” 1 1
MNERXH1413 8” x 6” 1 1
MNERXH1513 10” x 6” 1 1
MNERXH1514 10” x 8” 1 1
MNERXH1614 12” x 8” 1 1
MNERXH1615 12” x 10” 1 1
Weld Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
33
Weld Flanges
150 LB.
• 150# and 300# Pressure Rating
• Conforms to ASTM / ASME A/SA 105 ANSI B16.9 and B16.25
• Stocked 2” - 12”
Weld Fittings
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
150 LB Raised Face Blind Flange
MN150BF08 2” 1 1
MN150BF09 2-1/2” 1 1
MN150BF10 3” 1 1
MN150BF105 3-1/2” 1 1
MN150BF11 4” 1 1
MN150BF12 5” 1 1
MN150BF13 6” 1 1
MN150BF14 8” 1 1
MN150BF15 10” 1 1
MN150BF16 12” 1 1
150 LB Flat Face Threaded Flange
MN150FTF08
MN150FTF09
MN150FTF10
MN150FTF11
2”
2-1/2”
3”
4”
1
1
1
1
150 LB Flat Face Blind Flange
MN150FBF08 2” 1 1
MN150FBF10 3” 1 1
MN150FBF11 4” 1 1
MN150FBF13 6” 1 1
MN150FBF14 8” 1 1
MN150FBF15 10” 1 1
MN150FBF16 12” 1 1
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
150 LB Slip On Flat Face Flange
MN150FSF08 2” 1 1
MN150FSF10 3” 1 1
MN150FSF105 3-1/2” 1 1
MN150FSF11 4” 1 1
MN150FSF12 5” 1 1
MN150FSF13 6” 1 1
MN150FSF14 8” 1 1
MN150FSF15 10” 1 1
MN150FSF16 12” 1 1
150 LB Lap Joint Flat Face Flange
MN150LF08 2” 1 1
1
1
1
1
MN150LF09 2-1/2” 1 1
MN150LF10 3” 1 1
MN150LF105 3-1/2” 1 1
MN150LF11 4” 1 1
MN150LF12 5” 1 1
MN150LF13 6” 1 1
MN150LF14 8” 1 1
MN150LF15 10” 1 1
MN150LF16 12” 1 1
150 LB Socket Weld Raised Face Flange
MN150SWF08 2” 1 1
MN150SWF09 2-1/2” 1 1
MN150SWF10 3” 1 1
MN150SWF11 4” 1 1
MN150SWF13 6” 1 1
MN150SWF14 8” 1 1
34
150 LB Weld Neck Flat Face Flange
MN150FWF08 2” 1 1
MN150FWF10 3” 1 1
MN150FWF11 4” 1 1
MN150FWF13 6” 1 1
MN150FWF14 8” 1 1
MN150FWF15 10” 1 1
MN150FWF16 12” 1 1
Global sourcing. National compliance. Local service.
Fittings & Nipples
Weld Flanges
150 LB.
• 150# and 300# Pressure Rating
• Conforms to ASTM / ASME A/SA 105 ANSI B16.9 and B16.25
• Stocked 2” - 12”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
150 LB Slip on Raised Face Flange
MN150SF08 2” 1 1
MN150SF09 2-1/2” 1 1
MN150SF10 3” 1 1
MN150SF105 3-1/2” 1 1
MN150SF11 4” 1 1
MN150SF12 5” 1 1
MN150SF13 6” 1 1
MN150SF14 8” 1 1
MN150SF15 10” 1 1
MN150SF16 12” 1 1
150 LB Threaded Raised Face Flange
MN150TF08 2” 1 1
MN150TF09 2-1/2” 1 1
MN150TF10 3” 1 1
MN150TF105 3-1/2” 1 1
MN150TF11 4” 1 1
MN150TF12 5” 1 1
MN150TF13 6” 1 1
MN150TF14 8” 1 1
MN150TF16 12” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
150 LB Weld Neck Raised Face Flange
MN150WF08 2” 1 1
MN150WF09 2-1/2” 1 1
MN150WF10 3” 1 1
MN150WF105 3-1/2” 1 1
MN150WF11 4” 1 1
MN150WF12 5” 1 1
MN150WF13 6” 1 1
MN150WF14 8” 1 1
MN150WF15 10” 1 1
MN150WF16 12” 1 1
150 LB XH Weld Neck Raised Face Flange
MN150XHWF08 2” 1 1
MN150XHWF09 2-1/2” 1 1
MN150XHWF10 3” 1 1
MN150XHWF105 3-1/2” 1 1
MN150XHWF11 4” 1 1
MN150XHWF12 5” 1 1
MN150XHWF13 6” 1 1
MN150XHWF14 8” 1 1
MN150XHWF15 10” 1 1
MN150XHWF16 12” 1 1
Weld Fittings
150 LB XH Socket Weld Raised Face Flange
MN150XHSWF08 2” 1 1
MN150XHSWF09 2-1/2” 1 1
MN150XHSWF10 3” 1 1
MN150XHSWF11 4” 1 1
Fittings & Nipples
Global sourcing. National compliance. Local service.
35
Weld Flanges
300 LB.
• 150# and 300# Pressure Rating
• Conforms to ASTM / ASME A/SA 105 ANSI B16.9 and B16.25
• Stocked 2” - 8”
Weld Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
300 LB Raised Face Blind Flange
MN300BF08 2” 1 1
MN300BF09 2-1/2” 1 1
MN300BF10 3” 1 1
MN300BF105 3-1/2” 1 1
MN300BF11 4” 1 1
MN300BF12 5” 1 1
MN300BF13 6” 1 1
MN300BF14 8” 1 1
300 LB Lap Joint Flat Face Flange
MN300LF08 2” 1 1
MN300LF09 2-1/2” 1 1
MN300LF10 3” 1 1
MN300LF105 3-1/2” 1 1
MN300LF11 4” 1 1
MN300LF12 5” 1 1
MN300LF13 6” 1 1
MN300LF14 8” 1 1
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
300 LB Threaded Raised Face Flange
MN300TF08 2” 1 1
MN300TF09 2-1/2” 1 1
MN300TF10 3” 1 1
MN300TF105 3-1/2” 1 1
MN300TF11 4” 1 1
MN300TF12 5” 1 1
MN300TF13 6” 1 1
MN300TF14 8” 1 1
300 LB Weld Neck Raised Face Flange
MN300WF08 2” 1 1
MN300WF09 2-1/2” 1 1
MN300WF10 3” 1 1
MN300WF105 3-1/2” 1 1
MN300WF11 4” 1 1
MN300WF12 5” 1 1
MN300WF13 6” 1 1
MN300WF14 8” 1 1
36
300 LB Slip on Raised Face Flange
MN300SF08 2” 1 1
MN300SF09 2-1/2” 1 1
MN300SF10 3” 1 1
MN300SF105 3-1/2” 1 1
MN300SF11 4” 1 1
MN300SF12 5” 1 1
MN300SF13 6” 1 1
MN300SF14 8” 1 1
300 LB Socket Weld Raised Face Flange
MN300SWF08 2” 1 1
MN300SWF09 2-1/2” 1 1
MN300SWF10 3” 1 1
MN300SWF11 4” 1 1
MN300SWF12 5” 1 1
Global sourcing. National compliance. Local service.
300 LB XH Socket Weld Raised Face Flange
MN300XHSWF08 2” 1 1
MN300XHSWF10 3” 1 1
MN300XHSWF11 4” 1 1
300 LB XH Weld Neck Raised Face Flange
MN300XHWF08 2” 1 1
MN300XHWF09 2-1/2” 1 1
MN300XHWF10 3” 1 1
MN300XHWF105 3-1/2” 1 1
MN300XHWF11 4” 1 1
MN300XHWF12 5” 1 1
MN300XHWF13 6” 1 1
MN300XHWF14 8” 1 1
Fittings & Nipples
304 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90° Elbow
SSF304L9000 1/8” 120 480
SSF304L9001 1/4” 100 400
SSF304L9002 3/8” 50 200
SSF304L9003 1/2” 30 120
SSF304L9004 3/4” 18 72
SSF304L9005 1” 10 40
SSF304L9006 1-1/4” 5 20
SSF304L9007 1-1/2” 4 16
SSF304L9008 2” 2 8
SSF304L9009 2-1/2” 1 8
SSF304L9010 3” 1 5
SSF304L9011 4” 1 2
90° Street Elbow
SSF304STL9001 1/4” 100 400
SSF304STL9002 3/8” 60 240
SSF304STL9003 1/2” 35 140
SSF304STL9004 3/4” 18 72
SSF304STL9005 1” 10 40
SSF304STL9006 1-1/4” 5 20
SSF304STL9007 1-1/2” 4 16
SSF304STL9008 2” 2 8
SSF304STL9009 2-1/2” 1 6
SSF304STL9010 3” 1 4
SSF304STL9011 4” 1 2
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Tee
SSF304T01 1/4” 70 280
SSF304T02 3/8” 40 160
SSF304T03 1/2” 20 80
SSF304T04 3/4” 12 48
SSF304T05 1” 8 32
SSF304T06 1-1/4” 4 16
SSF304T07 1-1/2” 1 20
SSF304T08 2” 1 10
SSF304T09 2-1/2” 1 6
SSF304T10 3” 1 4
SSF304T11 4” 1 2
Weld Flanges
Hex Head Plug
SSF304HP01 1/4” 250 1,000
SSF304HP02 3/8” 200 800
SSF304HP03 1/2” 100 400
SSF304HP04 3/4” 60 240
SSF304HP05 1” 35 140
SSF304HP06 1-1/4” 18 72
SSF304HP07 1-1/2” 15 60
SSF304HP08 2” 6 24
SSF304HP09 2-1/2” 1 30
SSF304HP10 3” 1 20
SSF304HP11 4” 1 10
45° Elbow
SSF304L4501 1/4” 100 400
SSF304L4502 3/8” 60 240
SSF304L4503 1/2” 40 160
SSF304L4504 3/4” 20 80
SSF304L4505 1” 10 40
SSF304L4506 1-1/4” 6 24
SSF304L4507 1-1/2” 4 16
SSF304L4508 2” 2 8
SSF304L4509 2-1/2” 1 8
SSF304L4510 3” 1 5
SSF304L4511 4” 1 2
Fittings & Nipples
Square Head Plug
SSF304SP01 1/4” 400 1,600
SSF304SP02 3/8” 300 1,200
SSF304SP03 1/2” 150 600
SSF304SP04 3/4” 90 360
SSF304SP05 1” 40 160
SSF304SP06 1-1/4” 30 120
SSF304SP07 1-1/2” 24 96
SSF304SP08 2” 12 48
SSF304SP09 2-1/2” 1 40
SSF304SP10 3” 1 24
SSF304SP11 4” 1 14
Global sourcing. National compliance. Local service.
37
304 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
Stainless Steel
Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Union
SSF304UN01 1/4” 50 200
SSF304UN02 3/8” 30 120
SSF304UN03 1/2” 25 100
SSF304UN04 3/4” 12 48
SSF304UN05 1” 12 48
SSF304UN06 1-1/4” 3 12
SSF304UN07 1-1/2” 3 12
SSF304UN08 2” 2 8
SSF304UN09 2-1/2” 1 10
SSF304UN10 3” 1 4
SSF304UN11 4” 1 2
Cap
SSF304CA01 1/4” 200 800
SSF304CA02 3/8” 120 480
SSF304CA03 1/2” 80 320
SSF304CA04 3/4” 50 200
SSF304CA05 1” 25 100
SSF304CA06 1-1/4” 16 64
SSF304CA07 1-1/2” 15 60
SSF304CA08 2” 8 32
SSF304CA09 2-1/2” 1 30
SSF304CA10 3” 1 20
SSF304CA11 4” 1 10
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Coupling
SSF304CP00 1/8” 200 800
SSF304CP01 1/4” 120 480
SSF304CP02 3/8” 100 400
SSF304CP03 1/2” 50 200
SSF304CP04 3/4” 30 120
SSF304CP05 1” 20 80
SSF304CP06 1-1/4” 12 48
SSF304CP07 1-1/2” 10 40
SSF304CP08 2” 4 16
SSF304CP09 2-1/2” 1 15
SSF304CP10 3” 1 10
SSF304CP11 4” 1 6
Half Coupling
SSF304HC01 1/4” 300 1200
SSF304HC02 3/8” 200 800
SSF304HC03 1/2” 120 480
SSF304HC04 3/4” 70 280
SSF304HC05 1” 40 160
SSF304HC06 1-1/4” 24 96
SSF304HC07 1-1/2” 20 80
SSF304HC08 2” 10 40
SSF304HC09 2-1/2” 1 50
SSF304HC10 3” 1 25
SSF304HC11 4” 1 12
38
Global sourcing. National compliance. Local service.
Fittings & Nipples
304 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Bushing
SSF304BU0100 1/4” x 1/8” 300 1,200
SSF304BU0201 3/8” x 1/4” 120 480
SSF304BU0301 1/2” x 3/8” 100 400
SSF304BU0302 1/2” x 3/8” 100 400
SSF304BU0401 3/4” x 1/4” 60 240
SSF304BU0402 3/4” x 3/8” 60 240
SSF304BU0403 3/4” x 1/2” 60 240
SSF304BU0501 1” x 1/4” 36 144
SSF304BU0502 1” x 3/8” 36 144
SSF304BU0503 1” x 1/2” 36 144
SSF304BU0504 1” x 3/4” 36 144
SSF304BU0603 1-1/4” x 1/2” 18 72
SSF304BU0604 1-1/4” x 3/4” 18 72
SSF304BU0605 1-1/4” x 1” 18 72
SSF304BU0703 1-1/2”x 1/2” 18 72
SSF304BU0704 1-1/2” x 3/4” 18 72
SSF304BU0705 1-1/2” x 1” 18 72
SSF304BU0706 1-1/2” x 1-14” 18 72
SSF304BU0803 2” x 1/2” 18 36
SSF304BU0804 2” x 3/4” 18 36
SSF304BU0805 2” x 1” 18 36
SSF304BU0806 2” x 1-1/4” 18 36
SSF304BU0807 2” x 1-1/2” 18 36
SSF304BU0905 2-1/2” x 1” 4 16
SSF304BU0906 2-1/2” x 1-1/4” 4 16
SSF304BU0907 2-1/2” x 1-1/2” 4 16
SSF304BU0908 2-1/2” x 1-2” 4 16
SSF304BU1005 3” x 1” 3 12
SSF304BU1007 3” x 1-1/2” 3 12
SSF304BU1008 3” x 2” 3 12
SSF304BU1009 3” x 2-1/2” 3 12
SSF304BU1107 4” x 1-1/2” 1 4
SSF304BU1108 4” x 2” 1 4
SSF304BU1109 4” x 2-1/2” 1 4
SSF304BU1110 4” x 3” 1 4
SSF304RC1110 4” x 3” 1 4
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Coupling
SSF304RC0100 1/4” x 1/8” 150 600
SSF304RC0201 3/8” x 1/4” 60 240
SSF304RC0301 1/2” x 1/4” 40 160
SSF304RC0302 1/2” x 3/8” 40 160
SSF304RC0401 3/4” x 1/8” 24 96
SSF304RC0402 3/4” x 1/8” 24 96
SSF304RC0403 3/4” x 1/8” 24 96
SSF304RC0501 1” x 1/4” 12 48
SSF304RC0502 1” x 3/8” 12 48
SSF304RC0503 1” x 1/2” 12 48
SSF304RC0504 1” x 3/4” 12 48
SSF304RC0603 1-1/4” x 1/2” 12 48
SSF304RC0604 1-1/4” x 3/4” 12 48
SSF304RC0605 1-1/4” x 1” 12 48
SSF304RC0603 1-1/2” x 1/2” 8 32
SSF304RC0604 1-1/2” x 3/4” 8 32
SSF304RC0605 1-1/2” x 1” 8 32
SSF304RC0605 1-1/2” x 1-1/4” 8 32
SSF304RC0603 2” x 1/2” 4 16
SSF304RC0604 2” x 3/4” 4 16
SSF304RC0605 2” x 1” 4 16
SSF304RC0605 2” x 1-1/4” 4 16
SSF304RC0605 2” x 1-1/2” 4 16
SSF304RC0907 2-1/2” x 1-1/2” 1 16
SSF304RC0908 2-1/2” x 2” 1 9
SSF304RC1005 3” x 1” 1 9
SSF304RC1007 3” x 1-1/2” 1 9
SSF304RC1008 3” x 2” 1 9
SSF304RC1108 4” x 2” 1 3
SSF304RC1109 4” x 3” 1 3
Stainless Steel
Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
39
316 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
Stainless Steel
Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90° Elbow
SSF316L9001 1/4” 100 400
SSF316L9002 3/8” 50 200
SSF316L9003 1/2” 30 120
SSF316L9004 3/4” 18 72
SSF316L9005 1” 10 40
SSF316L9006 1-1/4” 5 20
SSF316L9007 1-1/2” 4 16
SSF316L9008 2” 2 8
SSF316L9009 2-1/2” 1 8
SSF316L9010 3” 1 5
SSF316L9011 4” 1 2
90° Street Elbow
SSF316STL9001 1/4” 100 400
SSF316STL9002 3/8” 60 240
SSF316STL9003 1/2” 35 140
SSF316STL9004 3/4” 18 72
SSF316STL9005 1” 10 40
SSF316STL9006 1-1/4” 4 16
SSF316STL9007 1-1/2” 2 4
SSF316STL9008 2” 2 8
SSF316STL9009 2-1/2” 1 4
SSF316STL9010 3” 1 4
SSF316STL9011 4” 1 2
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
45° Elbow
SSF316L4501 1/4” 100 400
SSF316L4502 3/8” 60 240
SSF316L4503 1/2” 40 160
SSF316L4504 3/4” 20 80
SSF316L4505 1” 10 40
SSF316L4506 1-1/4” 6 24
SSF316L4507 1-1/2” 4 16
SSF316L4508 2” 2 8
SSF316L4509 2-1/2” 1 8
SSF316L4510 3” 1 5
SSF316L4511 4” 1 2
Tee
SSF316T00 1/8” 75 300
SSF316T01 1/4” 70 280
SSF316T02 3/8” 40 160
SSF316T03 1/2” 20 80
SSF316T04 3/4” 12 48
SSF316T05 1” 8 32
SSF316T06 1-1/4” 4 16
SSF316T07 1-1/2” 1 20
SSF316T08 2” 1 10
SSF316T09 2-1/2” 1 6
SSF316T10 3” 1 4
SSF316T11 4” 1 2
40
Square Head Plug
SSF316SP01 1/4” 400 1600
SSF316SP02 3/8” 300 1200
SSF316SP03 1/2” 100 400
SSF316SP04 3/4” 60 240
SSF316SP05 1” 36 144
SSF316SP06 1-1/4” 28 112
SSF316SP07 1-1/2” 24 96
SSF316SP08 2” 9 36
SSF316SP09 2-1/2” 5 20
SSF316SP10 3” 3 12
SSF316SP11 4” 1 10
Global sourcing. National compliance. Local service.
Hex Head Plug
SSF316HP00 1/8” 400 1600
SSF316HP01 1/4” 250 1000
SSF316HP02 3/8” 200 800
SSF316HP03 1/2” 100 400
SSF316HP04 3/4” 60 240
SSF316HP05 1” 35 140
SSF316HP06 1-1/4” 18 72
SSF316HP07 1-1/2” 15 60
SSF316HP08 2” 6 24
SSF316HP09 2-1/2” 1 30
SSF316HP10 3” 1 20
SSF316HP11 4” 1 10
Fittings & Nipples
316 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Cap
SSF316CA01 1/4” 200 800
SSF316CA02 3/8” 120 480
SSF316CA03 1/2” 80 320
SSF316CA04 3/4” 50 200
SSF316CA05 1” 25 100
SSF316CA06 1-1/4” 16 64
SSF316CA07 1-1/2” 15 60
SSF316CA08 2” 8 32
SSF316CA09 2-1/2” 1 30
SSF316CA10 3” 1 20
SSF316CA11 4” 1 10
Union
SSF316UN01 1/4” 50 50
SSF316UN02 3/8” 30 30
SSF316UN03 1/2” 25 25
SSF316UN04 3/4” 12 12
SSF316UN05 1” 12 12
SSF316UN06 1-1/4” 3 3
SSF316UN07 1-1/2” 3 3
SSF316UN08 2” 2 2
SSF316UN09 2-1/2” 1 1
SSF316UN10 3” 1 1
SSF316UN11 4” 1 1
MATCONORCA
MODEL NUMBERSIZE
SIZE
CARTON QUANTITIES
INNER MASTER
Coupling
SSF316CP01 1/4” 120 480
SSF316CP02 3/8” 100 400
SSF316CP03 1/2” 50 240
SSF316CP04 3/4” 30 120
SSF316CP05 1” 20 80
SSF316CP06 1-1/4” 12 48
SSF316CP07 1-1/2” 10 40
SSF316CP08 2” 4 16
SSF316CP09 2-1/2” 1 15
SSF316CP10 3” 1 10
SSF316CP11 4” 1 6
Half Coupling
SSF316HC01 1/4” 300 1200
SSF316HC02 3/8” 200 800
SSF316HC03 1/2” 120 480
SSF316HC04 3/4” 70 280
SSF316HC05 1” 40 160
SSF316HC06 1-1/4” 24 96
SSF316HC07 1-1/2” 20 80
SSF316HC08 2” 10 40
SSF316HC09 2-1/2” 1 50
SSF316HC10 3” 1 25
SSF316HC11 4” 1 12
Stainless Steel
Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
41
316 Stainless Steel Fittings
• Casting Conforms to ASTM A351
• NPT Threads Conform to ASME B1.20.1
• ISO 9001:2008 Certied
• RoHS Compliant
• Fittings Meet Applicable Chemical & Physical Properties
• Stocked 1/8” - 4” Diameter
Fittings
Stainless Steel
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Reducing Coupling
SSF316RC0100 1/2” x 1/8” 150 600
SSF316RC0201 3/8” x 1/4” 60 240
SSF316RC0301 1/2” x 1/4” 40 160
SSF316RC0302 1/2” x 3/8” 40 160
SSF316RC0401 3/4” x 1/4” 24 96
SSF316RC0402 3/4” x 3/8” 24 96
SSF316RC0501 1” x 1/4” 12 48
SSF316RC0502 1” x 3/8” 12 48
SSF316RC0503 1” x 1/2” 12 48
SSF316RC0504 1” x 3/4” 12 48
SSF316RC0603 1-1/4” x 1/2” 12 48
SSF316RC0604 1-1/4” x 3/4” 12 48
SSF316RC0605 1-1/4” x 1” 12 48
SSF316RC0703 1-1/2” x 1/2” 8 32
SSF316RC0704 1-1/2” x 3/4” 8 32
SSF316RC0705 1-1/2” x 1” 8 32
SSF316RC0706 1-1/2” x 1-1/4” 8 32
SSF316RC0803 2” x 1/2” 4 16
SSF316RC0804 2” x 3/4” 4 16
SSF316RC0805 2” x 1” 4 16
SSF316RC0806 2” x 1-1/4” 4 16
SSF316RC0807 2” x 1-1/2” 2 8
SSF316RC0907 2-1/2” x 1-1/2” 1 16
SSF316RC0908 2-1/2” x 2” 1 16
SSF316RC1005 3” x 1” 1 16
SSF316RC1007 3” x 1-1/2” 1 9
SSF316RC1008 3” x 2” 1 9
SSF316RC1108 4” x 2” 3 3
SSF316RC1110 4” x 3” 1 3
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Bushing
SSF316BU0100 1/4” x 1/8” 300 1200
SSF316BU0201 3/8” x 1/4” 120 480
SSF316BU0301 1/2” x 1/4” 100 400
SSF316BU0302 1/2” x 3/8” 100 400
SSF316BU0401 3/4” x 1/4” 60 240
SSF316BU0402 3/4” x 3/8” 60 240
SSF316BU0403 3/4” x 1/2” 60 240
SSF316BU0501 1” x 1/4” 36 144
SSF316BU0502 1” x 3/8” 36 144
SSF316BU0503 1” x 1/2” 36 144
SSF316BU0504 1” x 3/4” 36 144
SSF316BU0603 1-1/4” x 1/2” 36 144
SSF316BU0604 1-1/4” x 3/4” 18 72
SSF316BU0605 1-1/4” x 1” 36 144
SSF316BU0703 1-1/2” x 1/2” 18 72
SSF316BU0704 1-1/2” x 3/4” 18 72
SSF316BU0705 1-1/2” x 1” 18 72
SSF316BU0706 1-1/2” x 1-1/4” 18 72
SSF316BU0803 2” x 1/2” 9 36
SSF316BU0804 2” x 3/4” 9 36
SSF316BU0805 2” x 1” 9 36
SSF316BU0806 2” x 1-1/4” 9 36
SSF316BU0807 2” x 1-1/2” 9 36
SSF316BU0905 2-1/2” x 1” 4 16
SSF316BU0906 2-1/2” x 1-1/4” 4 16
SSF316BU0907 2-1/2” x 1-1/2” 4 16
SSF316BU0908 2-1/2” x 2 4 16
SSF316BU1005 3” x 1” 3 12
SSF316BU1007 3” x 1-1/2” 3 12
SSF316BU1008 3” x 2” 3 12
SSF316BU1009 3” x 2-1/2” 4 16
42
Global sourcing. National compliance. Local service.
SSF316BU1107 4” x 1-1/2” 3 12
SSF316BU1108 4” x 2” 1 8
SSF316BU1110 4” x 3” 1 4
Fittings & Nipples
Steel Merchant Couplings
& Half Couplings
• Black & Galvanized
• Meets or Exceeds All Applicable
ASTM, ANSI & API Standards
MATCONORCA
MODEL NUMBER
• Merchant Couplings Stocked
1/8” - 6” Diameters
CARTON QUANTITIES
INNER MASTER
Black Steel Merchant Couplings - Straight
M-CB00 1/8” 100 1200
M-CB01 1/4” 100 1200
M-CB02 3/8” 100 800
M-CB03 1/2” 100 400
M-CB04 3/4” 1 50
M-CB05 1” 1 30
M-CB06 1-1/4” 1 25
M-CB07 1-1/2” 1 25
M-CB08 2” 1 20
• Full Stock of Specialty Couplings, Such as
Half Couplings and Right & Left Couplings
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Merchant Couplings - Straight
M-CG00 1/8” 100 1200
M-CG01 1/4” 100 1200
M-CG02 3/8” 100 800
M-CG03 1/2” 100 400
M-CG04 3/4” 1 50
M-CG05 1” 1 30
M-CG06 1-1/4” 1 25
M-CG07 1-1/2” 1 25
M-CG08 2” 1 20
Steel Merchant
Couplings
Black Steel Merchant Couplings - Tapered
M-CB09T 2-1/2” 1 24
M-CB11T 4” 1 12
M-CB12T 5” 1 6
M-CB13T 6” 1 4
Black Merchant Half Couplings - Straight
M-HCB00 1/8” 200 2400
M-HCB01 1/4” 200 2400
M-HCB02 3/8” 200 1600
M-HCB03 1/2” 200 800
M-HCB04 3/4” 100 800
M-HCB05 1” 100 400
M-HCB06 1-1/4” 50 200
M-HCB07 1-1/2” 50 200
M-HCB08 2” 100 100
Galvanized Steel Merchant Couplings - Tapered
M-CG09T 2-1/2” 1 24
M-CG10T 3” 1 18
M-CG11T 4” 1 12
M-CG12T 5” 1 6
M-CG13T 6” 1 4
Black Merchant Half Couplings - Tapered
M-HCB09T 2-1/2” 1 48
M-HCB10T 3” 1 36
M-HCB11T 4” 1 24
M-HCB12T 5” 1 12
M-HCB13T 6” 1 8
Add Z Prex For Chinese Merchant Couplings: ZM-CB (Black) / ZM-CG (Galvanized)
Fittings & Nipples
Global sourcing. National compliance. Local service.
43
Steel Merchant Couplings
& API Line Couplings
• Black & Galvanized
• Meets or Exceeds All Applicable
ASTM, ANSI & API Standards
MATCONORCA
MODEL NUMBER
API Line Couplings - Black
M-APIB00 1/8” 1 100
M-APIB01 1/4” 1 100
M-APIB02 3/8” 1 100
M-APIB03 1/2” 1 100
M-APIB04 3/4” 1 50
M-APIB05 1” 1 25
M-APIB06 1-1/4” 1 25
M-APIB07 1-1/2” 1 20
M-APIB08 2” 1 1
Couplings
Steel Merchant
M-APIB09 2-1/2” 1 1
M-APIB10 3” 1 1
M-APIB11 4” 1 1
M-APIB12 5” 1 1
M-APIB13 6” 1 1
M-APIB14 8” 1 1
M-APIB15 10” 1 1
• Merchant Couplings Stocked
1/8” - 6” Diameters
CARTON QUANTITIES
INNER MASTER
• Full Stock of Specialty Couplings, Such as
Half Couplings and Right & Left Couplings
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
API Line Couplings - Galvanized
M-APIG01 1/4” 1 1
M-APIG02 3/8” 1 1
M-APIG03 1/2” 1 1
M-APIG04 3/4” 1 1
M-APIG05 1” 1 1
M-APIG06 1-1/4” 1 1
M-APIG07 1-1/2” 1 1
M-APIG08 2” 1 1
M-APIG09 2-1/2” 1 1
M-APIG10 3” 1 1
M-APIG11 4” 1 1
M-APIG13 6” 1 1
44
Global sourcing. National compliance. Local service.
Fittings & Nipples
Steel Plugs & Bushings
• Black & Galvanized
• Meets or Exceeds All Applicable
ASTM, ANSI & API Standards
• Steel Plugs: Square Head, Hex Head:
Stocked 1/8” - 2”
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Hex Bushings - Black
M-BUB0100 1/4” x 1/8” 1 100
M-BUB0200 3/8” x 1/8” 1 100
M-BUB0201 3/8” x 1/4” 1 100
M-BUB0300 1/2” x 1/8” 1 100
M-BUB0301 1/2” x 1/4” 1 100
M-BUB0302 1/2” x 3/8” 1 100
M-BUB0400 3/4” x 1/8” 1 50
M-BUB0401 3/4” x 1/4” 1 50
M-BUB0402 3/4” x 3/8” 1 50
M-BUB0403 3/4” x 1/2” 1 50
M-BUB0501 1” x 1/4” 1 1
M-BUB0502 1” x 3/8” 1 1
M-BUB0603 1-1/4” x 1/2” 1 1
Hex Caps - Black
M-CAB00 1/8” 1 100
M-CAB01 1/4” 1 100
M-CAB02 3/8” 1 100
M-CAB03 1/2” 1 75
M-CAB04 3/4” 1 50
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Hex Bushings - Galvanized
M-BUG0100 1/4” x 1/8” 1 100
M-BUG0200 3/8” x 1/8” 1 100
M-BUG0201 3/8” x 1/4” 1 100
M-BUG0300 1/2” x 1/8” 1 100
M-BUG0301 1/2” x 1/4” 1 100
M-BUG0302 1/2” x 3/8” 1 100
M-BUG0400 3/4” x 1/8” 1 50
M-BUG0401 3/4” x 1/4” 1 50
M-BUG0402 3/4” x 3/8” 1 50
M-BUG0403 3/4” x 1/2” 1 50
Hex Caps - Galvanized
M-CAG00 1/8” 1 100
M-CAG01 1/4” 1 100
M-CAG02 3/8” 1 100
M-CAG03 1/2” 1 75
M-CAG04 3/4” 1 50
& Bushings
Steel Plugs
Square Head Plugs - Black
M-PB00 1/8” 1 100
M-PB01 1/4” 1 100
M-PB02 3/8” 1 100
M-PB03 1/2” 1 100
M-PB04 3/4” 1 50
M-PB05 1” 1 50
M-PB06 1-1/4” 1 25
M-PB07 1-1/2” 1 1
M-PB08 2” 1 1
Fittings & Nipples
Square Head Plugs - Galvanized
M-PG00 1/8” 1 100
M-PG01 1/4” 1 100
M-PG02 3/8” 1 100
M-PG03 1/2” 1 100
M-PG04 3/4” 1 50
M-PG05 1” 1 50
M-PG06 1-1/4” 1 25
M-PG07 1-1/2” 1 1
Solid
M-PSG07 1-1/2” 1 1
M-PSG07 2” 1 1
Global sourcing. National compliance. Local service.
45
Steel Plugs & Bushings
• Black & Galvanized
• Meets or Exceeds All Applicable
ASTM, ANSI & API Standards
• Steel Plugs: Square Head, Hex Head:
Stocked 1/8” - 2”
• Steel Countersunk Plugs:
Square Socket, Hex Socket Stocked 1/8” - 2”
Steel Plugs
& Bushings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Countersunk Plugs - Hex Socket - Black
M-PHSB00 1/8” 1 100
M-PHSB01 1/4” 1 100
M-PHSB02 3/8” 1 100
M-PHSB03 1/2” 1 100
M-PHSB04 3/4” 1 100
M-PHSB05 1” 1 75
M-PHSB06 1-1/4” 1 25
M-PHSB07 1-1/2” 1 25
M-PHSB08 2” 1 20
Countersunk Plugs - Square Socket - Black
M-PSSB01 1/4” 1 100
M-PSSB02 3/8” 1 100
M-PSSB03 1/2” 1 100
M-PSSB04 3/4” 1 100
M-PSSB05 1” 1 75
M-PSSB06 1-1/4” 1 25
M-PSSB07 1-1/2” 1 25
M-PSSB08 2” 1 20
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Countersunk Plugs - Hex Socket - Galvanized
M-PHSG00 1/8” 1 100
M-PHSG01 1/4” 1 100
M-PHSG02 3/8” 1 100
M-PHSG03 1/2” 1 100
M-PHSG04 3/4” 1 100
M-PHSG05 1” 1 75
M-PHSG06 1-1/4” 1 25
M-PHSG07 1-1/2” 1 25
M-PHSG08 2” 1 20
Countersunk Plugs - Square Socket - Galvanized
M-PSSG01 1/4” 1 100
M-PSSG02 3/8” 1 100
M-PSSG03 1/2” 1 100
M-PSSG04 3/4” 1 100
M-PSSG05 1” 1 75
M-PSSG06 1-1/4” 1 25
M-PSSG07 1-1/2” 1 25
M-PSSG08 2” 1 20
46
Hex Head Plugs - Black
M-PHHB00 1/8” 1 100
M-PHHB01 1/4” 1 100
M-PHHB02 3/8” 1 100
M-PHHB03 1/2” 1 100
M-PHHB04 3/4” 1 50
Global sourcing. National compliance. Local service.
Hex Head Plugs - Galvanized
M-PHHG00 1/8” 1 100
M-PHHG01 1/4” 1 100
M-PHHG02 3/8” 1 100
M-PHHG03 1/2” 1 100
M-PHHG04 3/4” 1 100
Fittings & Nipples
Brass Pipe Fittings
• Meets All Applicable ANSI Standards
• Stocked From 1/8” - 4” Diameters
• Brass Material is to ASTM B62 Standard
• UL Approved
• Lead Free Version Available
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
B-L9000 1/8” 25 600
B-L9001 1/4” 25 300
B-L9002LF 3/8” 25 300
B-L9003 1/2” 25 200
B-L9004 3/4” 25 100
B-L9005 1” 25 75
B-L9006 1-1/4” 1 50
B-L9007 1-1/2” 1 35
B-L9008 2” 1 20
B-L9009LF 2-1/2” 1 15
B-L9010 3” 1 6
B-L9011LF 4” 1 4
45º Elbow
B-L4500 1/8” 25 1200
B-L4501 1/4” 25 600
B-L4502 3/8” 25 400
B-L4503LF 1/2” 25 200
B-L4504 3/4” 25 100
B-L4505 1” 25 75
B-L4506 1-1/4” 1 50
B-L4507LF 1-1/2” 1 40
B-L4508 2” 1 25
B-L4509LF 2-1/2” 1 12
B-L4510 3” 1 8
B-L4511 4” 1 3
Cross
B-CR00 1/8” 1 1
B-CR01LF 1/4” 25 200
B-CR02 3/8” 25 100
B-CR03 1/2” 25 75
B-CR04 3/4” 10 40
B-CR05LF 1” 20 40
B-CR06LF 1-1/4” 1 24
B-CR07 1-1/2” 1 24
B-CR08LF 2” 1 12
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Elbow
B-RL0201LF 3/8” x 1/4” 25 300
B-RL0301 1/2” x 1/4” 25 150
B-RL0302LF 1/2” x 3/8” 25 150
B-RL0400 3/4” x 1/8” 25 200
B-RL0401 3/4” x 1/4” 25 200
B-RL0402 3/4” x 3/8” 25 200
B-RL0403 3/4” x 1/2” 25 100
B-RL0501 1” x 1/4” 25 100
B-RL0502 1” x 3/8” 25 100
B-RL0503 1” x 1/2” 25 100
B-RL0504 1” x 3/4” 25 100
B-RL0603 1-1/4” x 1/2” 1 85
B-RL0604 1-1/4” x 3/4” 1 70
B-RL0605LF 1-1/4” x 1” 1 60
B-RL0703LF 1-1/2” x 1/2” 1 60
B-RL0704 1-1/2” x 3/4” 1 60
B-RL0705 1-1/2” x 1/2” 1 60
B-RL0706LF 1-1/2” x 1-1/4” 1 35
B-RL0805 2” x 1” 1 35
B-RL0806 2” x 1-1/4” 1 30
B-RL0807 2” x 1-1/2” 1 30
B-RL0908 2-1/2” x 2” 1 15
Cap
B-CA00 1/8” 25 1400
B-CA01 1/4” 25 1400
B-CA02 3/8” 25 600
B-CA03 1/2” 25 300
B-CA04LF 3/4” 25 200
B-CA05 1” 25 200
B-CA06 1-1/4” 1 100
B-CA07 1-1/2” 1 100
B-CA08 2” 1 70
B-CA09 2-1/2” 1 35
B-CA10 3” 1 25
B-CA11LF 4” 1 10
Add LF Sux for Lead Free Version. Some Only
Available in Lead Free. They will have LF on the Part #.
Brass Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
47
Brass Pipe Fittings
Brass Fittings
• Meets All Applicable ANSI Standards
• Stocked From 1/8” - 4” Diameters
MATCONORCA
MODEL NUMBER
• Brass Material is to ASTM B62 Standard
• UL Approved
CARTON QUANTITIES
INNER MASTER
90º Street Elbow
B-ST9000 1/8” 25 1000
B-ST9001 1/4” 25 700
B-ST9002 3/8” 25 400
B-ST9003 1/2” 25 200
B-ST9004 3/4” 25 100
B-ST9005 1” 25 75
B-ST9006LF 1-1/4” 20 40
B-ST9007 1-1/2” 1 35
B-ST9008 2” 1 20
B-ST9009LF 2-1/2” 1 11
B-ST9010LF 3” 1 6
B-ST9011LF 4” 1 2
45º Street Elbow
B-ST4500 1/8” 25 600
B-ST4501 1/4” 25 600
B-ST4502 3/8” 25 300
B-ST4503 1/2” 25 200
B-ST4504 3/4” 25 100
B-ST4505 1” 25 75
B-ST4506LF 1-1/4” 1 60
B-ST4507 1-1/2” 1 45
B-ST4508 2” 1 20
Tee
B-T00 1/8” 25 600
B-T01 1/4” 25 300
B-T02 3/8” 25 200
B-T03 1/2” 25 100
B-T04 3/4” 25 75
B-T05 1” 25 40
B-T06 1-1/4” 1 35
B-T07 1-1/2” 1 24
B-T08 2” 1 15
B-T09LF 2-1/2” 1 8
B-T10LF 3” 1 4
B-T11LF 4” 1 2
• Lead Free Version Available
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Tee
B-RT0201 3/8” x 1/4” 25 200
B-RT0301 1/2” x 1/4” 25 200
B-RT0302 1/2” x 3/8” 25 100
B-RT030304LF 1/2” x 1/2” x 3/4” 25 100
B-RT0401 3/4” x 1/4” 25 100
B-RT0402 3/4” x 3/8” 25 100
B-RT0403 3/4” x 1/2” 25 100
B-RT040303 3/4” x 1/2” x 1/2” 25 100
B-RT040304 3/4” x 1/2” x 3/4” 25 100
B-RT040405 3/4” x 3/4” x 1” 10 60
B-RT0501LF 1” x 1/4 10 60
B-RT0502 1” x 3/8” 1 50
B-RT0503LF 1” x 1/2” 10 40
B-RT050303 1” x 1/2” x 1/2” 1 50
B-RT050304LF 1” x 1/2” x 3/4” 1 50
B-RT050305LF 1” x 1/2” x 1” 1 50
B-RT0504 1” x 3/4” 10 40
B-RT050404 1” x 3/4” x 3/4” 1 50
B-RT050405LF 1” x 3/4” x 1” 1 50
B-RT0603 1-1/4” x 1/2” 1 45
B-RT060306 1-1/4” x 1/2” x 1-1/4” 1 30
B-RT0604 1-1/4” x 3/4” 1 40
B-RT0605LF 1-1/4” x 1” 1 35
B-RT060506LF 1-1/4” x 1” x 1-1/4” 1 30
B-RT0703 1-1/2” x 1/2” 1 40
B-RT070307LF 1-1/2” x 1/2” x 1-1/2” 1 40
B-RT0704 1-1/2” x 3/4” 1 30
B-RT0705LF 1-1/2” x 1” 1 30
B-RT0706 1-1/2” x 1-1/4” 1 26
B-RT070606 1-1/2” x 1-1/4” x 1-1/4” 1 25
B-RT0803 2” x 1/2” 1 25
B-RT0804LF 2” x 3/4” 1 25
B-RT0805LF 2” x 1” 1 25
B-RT0806 2” x 1-1/4” 1 20
B-RT0807 2” x 1-1/2” 1 20
B-RT0906LF 2-1/2” x 1-1/4” 1 20
B-RT0908 2-1/2” x 2” 1 15
B-RT1008LF 3” x 2” 1 5
48
Add LF Sux for Lead Free Version. Some Only Available in Lead Free. They will have LF on the Part #.
Global sourcing. National compliance. Local service.
Fittings & Nipples
Brass Pipe Fittings
• Meets All Applicable ANSI Standards
• Stocked From 1/8” - 4” Diameters
• Brass Material is to ASTM B62 Standard
• UL Approved
• Lead Free Version Available
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Coupling
B-CP00 1/8” 25 600
B-CP01 1/4” 25 600
B-CP02LF 3/8” 25 300
B-CP03 1/2” 25 200
B-CP04 3/4” 25 100
B-CP05 1” 25 100
B-CP06 1-1/4” 1 75
B-CP07 1-1/2” 1 50
B-CP08 2” 1 30
B-CP09 2-1/2” 1 18
B-CP10 3” 1 12
B-CP11LF 4” 1 8
Union
B-UN00 1/8” 25 300
B-UN01LF 1/4” 25 150
B-UN02LF 3/8” 25 150
B-UN03 1/2” 25 75
B-UN04 3/4” 25 75
B-UN05 1” 10 40
B-UN06 1-1/4” 1 35
B-UN07 1-1/2” 1 25
B-UN08 2” 1 18
B-UN09LF 2-1/2” 1 10
B-UN10LF 3” 1 8
B-UN11LF 4” 1 3
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Coupling
B-RC0100 1/4” x 1/8” 25 600
B-RC0200 3/8” x 1/8” 25 300
B-RC0201 3/8” x 1/4” 25 300
B-RC0300 1/2” x 1/8” 25 300
B-RC0301LF 1/2” x 1/4” 25 200
B-RC0302LF 1/2” x 3/8” 25 200
B-RC0401 3/4” x 1/4” 25 200
B-RC0402 3/4” x 3/8” 25 200
B-RC0403 3/4” x 1/2” 25 200
B-RC0502 1” x 3/8” 25 100
B-RC0503 1” x 1/2” 25 100
B-RC0504 1” x 3/4” 25 100
B-RC0603 1-1/4” x 1/2” 1 90
B-RC0604 1-1/4” x 3/4” 1 90
B-RC0605 1-1/4” x 1” 1 70
B-RC0703 1-1/2” x 1/2” 1 70
B-RC0704 1-1/2” x 3/4” 1 80
B-RC0705 1-1/2” x 1” 1 75
B-RC0706LF 1-1/2” x 1-1/4” 1 60
B-RC0803 2” x 1/2” 1 60
B-RC0804 2” x 3/4” 1 35
B-RC0805LF 2” x 1” 1 60
B-RC0806 2” x 1-1/4” 1 60
B-RC0807 2” x 1-1/2” 1 50
B-RC0905LF 2-1/2” x 1” 1 1
B-RC0906 2-1/2” x 1-1/4” 1 20
B-RC0907LF 2-1/2” x 1-1/2” 1 20
B-RC0908LF 2-1/2” x 2” 1 20
B-RC1005LF 3” x 1” 1 1
B-RC1008 3” x 2” 1 12
B-RC1009LF 3” x 2-1/2” 1 12
B-RC1108 LF 4” x 2” 1 10
B-RC1110LF 4” x 3” 1 4
Brass Fittings
Locknut
B-LN02 3/8” 25 1400
B-LN03 1/2” 25 450
B-LN04 3/4” 25 300
B-LN05 1” 25 200
B-LN06 1-1/4” 1 160
B-LN08 2” 40 80
Add LF Sux for Lead Free Version. Some Only Available in Lead Free. They will have LF on the Part #.
Fittings & Nipples
Global sourcing. National compliance. Local service.
49
Brass Pipe Fittings
• Meets All Applicable ANSI Standards
• Stocked From 1/8” - 4” Diameters
• Brass Material is to ASTM B62 Standard
• UL Approved
• Lead Free Version Available
Brass Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Bushings
B-BU0100 1/4” x 1/8” 25 600
B-BU0200 3/8” x 1/8” 25 600
B-BU0201LF 3/8” x 1/4” 25 600
B-BU0300 1/2” x 1/8” 25 450
B-BU0301 1/2” x 1/4” 25 450
B-BU0302 1/2” x 3/8” 25 450
B-BU0400LF 3/4” x 1/8” 25 300
B-BU0401 3/4” x 1/4” 25 300
B-BU0402 3/4” x 3/8” 25 300
B-BU0403 3/4” x 1/2” 25 300
B-BU0501LF 1” x 1/4” 25 150
B-BU0502 1” x 3/8” 25 150
B-BU0503 1” x 1/2” 25 150
B-BU0504 1” x 3/4” 25 150
B-BU0603 1-1/4” x 1/2” 1 120
B-BU0604 1-1/4” x 3/4” 1 120
B-BU0605 1-1/4” x 1” 1 120
B-BU0701LF 1-1/2” x 1/4” 1 120
B-BU0702 1-1/2” x 3/8” 1 120
B-BU0703LF 1-1/2” x 1/2” 1 120
B-BU0704 1-1/2” x 3/4” 1 120
B-BU0705 1-1/2” x 1” 1 100
B-BU0706 1-1/2” x 1-1/4” 1 100
B-BU0803LF 2” x 1/2” 1 90
B-BU0804 2” x 3/4” 1 90
B-BU0805 2” x 1” 1 90
B-BU0806LF 2” x 1-1/4” 1 80
B-BU0807 2” x 1-1/2” 1 80
B-BU0905 2-1/2” x 1” 1 60
B-BU0906 2-1/2” x 1-1/4” 1 60
B-BU0907LF 2-1/2” x 1-1/2” 1 60
B-BU0908LF 2-1/2” x 2” 1 60
B-BU1007 3” x 1-1/2” 1 30
B-BU1008 3” x 2” 1 30
B-BU1009LF 3” x 2-1/2” 1 24
B-BU1108LF 4” x 2” 1 24
B-BU1109 4” x 2-1/2” 1 24
B-BU1110LF 4” x 3” 1 24
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Floor Flange
B-FF03LF 1/2” 25 100
B-FF04LF 3/4” 25 75
B-FF05LF 1” 10 40
B-FF06LF 1-1/4” 1 40
B-FF07LF 1-1/2” 1 40
Companion Flange Threaded
B-CF03LF 1/2” 1 75
B-CF05 1” 1 40
B-CF07LF 1-1/2” 1 30
B-CF08 2” 1 20
B-CF09 2-1/2” 1 10
B-CF10 3” 1 8
B-CF11 4” 1 6
B-CF13LF 6” 1 2
Companion Flange Sweat
B-CFC07LF 1-1/2” 1 12
B-CFC08LF 2” 1 6
B-CFC09LF 2-1/2” 1 4
B-CFC10LF 3” 1 4
B-CFC11LF 4” 1 2
50
Add LF Sux for Lead Free Version. Some Only Available in Lead Free. They will have LF on the Part #.
Global sourcing. National compliance. Local service.
Fittings & Nipples
Brass Pipe Fittings
• Meets All Applicable ANSI Standards
• Stocked From 1/8” - 4” Diameters
• Brass Material is to ASTM B62 Standard
• UL Approved
• Lead Free Version Available
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Cored Plug
B-PL00 1/8” 25 1400
B-PL01 1/4” 25 1400
B-PL02LF 3/8” 25 1400
B-PL03 1/2” 25 600
B-PL04 3/4” 25 300
B-PL05 1” 25 200
B-PL06 1-1/4” 1 180
B-PL07 1-1/2” 1 120
B-PL08 2” 1 50
B-PL09LF 2-1/2” 1 40
B-PL10LF 3” 1 30
B-PL11LF 4” 1 20
Countersunk Plug
B-CSP03 1/2” 1 100
B-CSP04 3/4” 1 100
B-CSP05LF 1” 75 300
B-CSP07LF 1-1/2” 35 140
B-CSP08LF 2” 20 80
B-CSP09LF 2-1/2” 20 60
B-CSP10LF 3” 1 25
B-CSP11 4” 1 15
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Lead Free Bronze Adapter - Female x TP*
B-CTP03LF 1/2” 80 320
B-CTP04LF 3/4” 50 200
B-CTP05LF 1” 90 180
B-CTP06LF 1-1/4” 48 96
B-CTP07LF 1-1/2” 40 80
B-CTP08LF 2” 24 48
B-CTP09LF 2-1/2” 9 18
B-CTP10LF 3” 6 12
B-CTP11LF 4” 2 4
Lead Free Bronze Adapter - Female x TP*
B-XTP03LF 1/2” 100 400
B-XTP04LF 3/4” 70 280
B-XTP05LF 1” 35 140
B-XTP06LF 1-1/4” 48 96
B-XTP07LF 1-1/2” 40 80
B-XTP08LF 2” 24 48
B-XTP09LF 2-1/2” 8 16
B-XTP10LF 3” 6 12
B-XTP11LF 4” 3 6
Brass Fittings
Solid Plug
B-PLS03 1/2” 25 600
B-PLS04 3/4” 25 300
B-PLS05 1” 25 200
B-PLS06LF 1-1/4” 1 140
B-PLS07LF 1-1/2” 1 100
B-PLS08LF 2” 1 50
Lead Free Bronze Adapter - Female x TP*
B-CCTP03LF 1/2” 100 400
B-CCTP04LF 3/4” 70 280
B-CCTP05LF 1” 35 140
B-CCTP06LF 1-1/4” 48 96
B-CCTP07LF 1-1/2” 40 80
B-CCTP08LF 2” 24 48
B-CCTP09LF 2-1/2” 8 16
B-CCTP10LF 3” 6 12
B-CCTP11LF 4” 3 6
*TP = Brass Threadless Pipe
Extension Piece
B-X03 1/2” 25 400
B-X04 3/4” 25 200
Add LF Sux for Lead Free Version. Some Only Available in Lead Free. They will have LF on the Part #.
Fittings & Nipples
Global sourcing. National compliance. Local service.
51
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
•
Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
Brass Pipe Fittings
Lead Free Domestic
MATCONORCA
MODEL NUMBER
90º Elbow
DB-L9000LF
DB-L9001LF
DB-L9002LF
DB-L9003LF
DB-L9004LF
DB-L9005LF
DB-L9006LF
DB-L9007LF
DB-L9008LF
DB-L9009LF
DB-L9010LF
DB-L9011LF
DB-L9012LF
DB-L9013LF
45º Elbow
DB-L4500LF
DB-L4501LF
DB-L4502LF
DB-L4503LF
DB-L4504LF
DB-L4505LF
DB-L4506LF
DB-L4507LF
DB-L4508LF
DB-L4509LF
DB-L4510LF
Reducing Elbow
DB-RL0100LF
DB-RL0200LF
DB-RL0201LF
DB-RL0301LF
DB-RL0302LF
DB-RL0401LF
DB-RL0402LF
DB-RL0403LF
SIZE
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
1/4” x 1/8”
3/8” x 1/8”
3/8” x 1/4”
1/2” x 1/4”
1/2” x 3/8”
3/4” x 1/4”
3/4” x 3/8”
3/4” x 1/2”
CARTON QUANTITIES
INNER MASTER
25
25
25
25
25
25
10
5
5
1
1
1
1
1
25
25
25
25
25
25
10
10
5
1
1
25
25
25
25
25
25
25
25
500
300
300
150
100
75
40
20
20
15
500
300
300
150
100
100
40
40
20
10
500
300
300
300
300
150
150
100
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Elbow (Continued)
DB-RL0501LF
DB-RL0502LF
DB-RL0503LF
DB-RL0504LF
DB-RL0603LF
DB-RL0604LF
DB-RL0605LF
DB-RL0703LF
DB-RL0704LF
5
4
2
1
DB-RL0705LF
DB-RL0706LF
DB-RL0803LF
DB-RL0804LF
DB-RL0805LF
DB-RL0806LF
DB-RL0807LF
DB-RL0907LF
DB-RL0908LF
DB-RL1008LF
DB-RL1009LF
1” x 1/4”
1” x 3/8”
1” x 1/2”
1” x 3/4”
1-1/4” x 1/2”
1-1/4” x 3/4”
1-1/4” x 1”
1-1/2” x 1/2”
1-1/2” x 3/4”
1-1/2” x 1”
1-1/2” x 1-1/4”
2” x 1/2”
2” x 3/4”
2” x 1”
2” x 1-1/4”
2” x 1-1/2”
2-1/2” x 1-1/2”
2-1/2” x 2”
3” x 2”
3” x 2-1/2”
25
25
25
25
10
10
10
5
5
5
5
5
5
1
5
1
1
1
1
1
100
100
100
100
40
40
40
20
20
20
20
30
20
35
25
25
10
10
10
5
90º Street Elbow
DB-ST9000LF
DB-ST9001LF
5
DB-ST9002LF
DB-ST9003LF
DB-ST9004LF
DB-ST9005LF
DB-ST9006LF
DB-ST900605LF
DB-ST9007LF
DB-ST9008LF
DB-ST9009LF
DB-ST9010LF
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/4” x 1”
1-1/2”
2”
2-1/2”
3”
25
25
25
25
25
10
10
5
10
5
1
1
500
500
300
150
100
40
40
40
30
20
10
5
52
Global sourcing. National compliance. Local service.
Fittings & Nipples
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
MATCONORCA
MODEL NUMBER
45º Street Elbow
DB-ST4501LF
DB-ST4502LF
DB-ST4503LF
DB-ST4504LF
DB-ST4505LF
DB-ST4506LF
DB-ST4507LF
DB-ST4508LF
Cap
DB-CA00LF
DB-CA01LF
DB-CA02LF
DB-CA03LF
DB-CA04LF
DB-CA05LF
DB-CA06LF
DB-CA07LF
DB-CA08LF
DB-CA09LF
DB-CA10LF
DB-CA11LF
Coupling
DB-CP00LF
DB-CP01LF
DB-CP02LF
DB-CP03LF
DB-CP04LF
DB-CP05LF
DB-CP06LF
DB-CP07LF
DB-CP08LF
DB-CP09LF
DB-CP105LF
DB-CP10LF
DB-CP11LF
DB-CP12LF
DB-CP13LF
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3-1/2”
3”
4”
5”
6”
SIZE
CARTON QUANTITIES
INNER MASTER
25
25
25
25
10
5
5
5
25
25
25
25
25
25
25
10
10
5
1
1
25
25
25
25
25
25
10
10
5
1
1
1
1
1
1
500
300
150
100
40
20
20
20
500
500
500
300
150
100
100
40
40
20
15
10
500
500
300
200
100
100
40
40
20
25
10
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Reducing Coupling
DB-RC0100LF
DB-RC0200LF
DB-RC0201LF
DB-RC0300LF
DB-RC0301LF
DB-RC0302LF
DB-RC0401LF
DB-RC0402LF
DB-RC0403LF
DB-RC0501LF
DB-RC0502LF
DB-RC0503LF
DB-RC0504LF
DB-RC0603LF
DB-RC0604LF
DB-RC0605LF
DB-RC0703LF
DB-RC0704LF
DB-RC0705LF
DB-RC0706LF
DB-RC0803LF
DB-RC0804LF
DB-RC0805LF
DB-RC0806LF
DB-RC0807LF
DB-RC0906LF
DB-RC0907LF
DB-RC0908LF
DB-RC1005LF
DB-RC1006LF
DB-RC1009LF
DB-RC1108LF
DB-RC1110LF
DB-RC1311LF
6
8
4
2
1/4” x 1/8”
3/8” x 1/8”
3/8” x 1/4”
1/2” x 1/8”
1/2” x 1/4”
1/2” x 3/8”
3/4” x 1/4”
3/4” x 3/8”
3/4” x 1/2”
1” x 1/4”
1” x 3/8”
1” x 1/2”
1” x 3/4”
1-1/4” x 1/2”
1-1/4” x 3/4”
1-1/4” x 1”
1-1/2” x 1/2”
1-1/2” x 3/4”
1-1/2” x 1”
1-1/2” x 1-1/4”
2” x 1/2”
2” x 3/4”
2” x 1”
2” x 1-1/4”
2” x 1-1/2”
2-1/2” x 1-1/4”
2-1/2” x 1-1/2”
2-1/2” x 2”
3” x 1”
3” x 1-1/4”
3” x 2-1/2”
4” x 2”
4” x 3”
6” x 4”
25
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
10
10
5
1
1
1
1
1
1
1
1
1
500
300
300
300
300
300
150
150
200
100
100
100
100
80
60
40
40
40
40
40
40
40
40
40
20
10
15
15
10
10
10
Lead Free Domestic
Brass Pipe Fittings
6
5
2
Fittings & Nipples
Global sourcing. National compliance. Local service.
53
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
Brass Pipe Fittings
Lead Free Domestic
MATCONORCA
MODEL NUMBER
Tee
DB-T00LF
DB-T01LF
DB-T02LF
DB-T03LF
DB-T04LF
DB-T05LF
DB-T06LF
DB-T07LF
DB-T08LF
DB-T09LF
DB-T10LF
DB-T105LF
DB-T11LF
DB-T12LF
DB-T13LF
Reducing Tee
DB-RT0100LF
DB-RT010102LF
DB-RT0200LF
DB-RT020102LF
DB-RT0201LF
DB-RT020203LF
DB-RT0300LF
DB-RT030103LF
DB-RT0301LF
DB-RT030202LF
DB-RT030203LF
DB-RT0302LF
DB-RT030304LF
DB-RT030305LF
DB-RT0401LF
DB-RT040203LF
DB-RT0402LF
DB-RT040303LF
DB-RT040304LF
DB-RT0403LF
DB-RT040405LF
DB-RT040407LF
DB-RT0501LF
DB-RT0502LF
DB-RT050303LF
DB-RT050304LF
SIZE
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
3-1/2”
4”
5”
6”
1/4” x 1/8”
1/4” x 1/4” x 3/8”
3/8” x 1/8”
3/8” x 1/4” x 3/8”
3/8” x 1/4”
3/8” x 3/8” x 1/2”
1/2” x 1/8”
1/2” x 1/4” x 1/2”
1/2” x 1/4”
1/2” x 3/8” x 3/8”
1/2” x 3/8” x 1/2”
1/2” x 3/8”
1/2” x 1/2” x 3/4”
1/2” x 1/2” x 1”
3/4” x 1/4”
3/4” x 3/8” x 1/2”
3/4” x 3/8”
3/4” x 1/2” x 1/2”
3/4” x 1/2” x 3/4”
3/4” x 1/2”
3/4” x 3/4” x 1”
3/4” x 3/4” x 1-1/2”
1” x 1/4”
1” x 3/8”
1” X 1/2” x 1/2”
1” X 1/2” x 3/4”
CARTON QUANTITIES
INNER MASTER
25
25
25
25
25
10
5
5
5
1
1
1
1
1
1
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
10
25
10
10
10
10
10
10
10
10
10
500
300
200
100
100
40
20
20
15
300
200
200
200
200
200
200
200
200
200
100
100
100
100
100
60
100
60
60
80
40
40
40
40
40
40
5
5
1
2
2
2
MATCONORCA
MODEL NUMBER
SIZE
Reducing Tee (Continued)
DB-RT050305LF
DB-RT0503LF
DB-RT050403LF
DB-RT050404LF
DB-RT050405LF
DB-RT0504LF
DB-RT050506LF
DB-RT050507LF
DB-RT060306LF
DB-RT0603LF
DB-RT060404LF
DB-RT060406LF
DB-RT0604LF
DB-RT060503LF
DB-RT060504LF
DB-RT060505LF
DB-RT060506LF
DB-RT0605LF
DB-RT060607LF
DB-RT070307LF
DB-RT0703LF
DB-RT070407LF
DB-RT0704LF
DB-RT070505LF
DB-RT070506LF
DB-RT070507LF
DB-RT0705LF
DB-RT070606LF
DB-RT070607LF
DB-RT0706LF
DB-RT070708LF
DB-RT0803LF
DB-RT080407LF
DB-RT080408LF
DB-RT0804LF
DB-RT080508LF
DB-RT0805LF
DB-RT080608LF
DB-RT0806LF
DB-RT080705LF
DB-RT080706LF
DB-RT080707LF
DB-RT080708LF
DB-RT0807LF
1” X 1/2” x 1”
1” X 1/2”
1” X 3/4” x 1/2”
1” X 3/4” x 3/4”
1” X 3/4” x 1”
1” X 3/4”
1” X 1” x 1-1/4”
1” X 1” x 1-1/2”
1-1/4” x 1/2” x 1-1/4”
1-1/4” x 1/2”
1-1/4” x 3/4” x 3/4”
1-1/4” x 3/4” x 1-1/4”
1-1/4” x 3/4”
1-1/4” x 1” x 1/2”
1-1/4” x 1” x 3/4”
1-1/4” x 1” x 1”
1-1/4” x 1” x 1-1/4”
1-1/4” x 1”
1-1/4” x 1-1/4” x 1-1/2”
1-1/2” x 1/2” x 1-1/2”
1-1/2” x 1/2”
1-1/2” x 3/4” x 1-1/2”
1-1/2” x 3/4”
1-1/2” x 1” x 1”
1-1/2” x 1” x 1-1/4”
1-1/2” x 1” x 1-1/2”
1-1/2” x 1”
1-1/2” x 1-1/4” x 1-1/4”
1-1/2” x 1-1/4” x 1-1/2”
1-1/2” x 1-1/4”
1-1/2” x 1-1/2” x 2”
2” x 1/2”
2” x 3/4” x 1-1/2”
2” x 3/4” x 2”
2” x 3/4”
2” x 1” x 2”
2” x 1”
2” x 1-1/4” x 2”
2” x 1-1/4”
2” x 1-1/2” x 1”
2” x 1-1/2” x 1-1/4”
2” x 1-1/2” x 1-1/2”
2” x 1-1/2” x 2”
2” x 1-1/2”
CARTON QUANTITIES
INNER MASTER
10
10
10
10
10
10
10
10
10
5
10
10
10
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
1
1
5
1
5
1
5
1
1
1
5
5
40
40
40
40
40
40
40
40
40
20
10
30
40
30
30
20
20
20
20
20
20
20
20
20
20
20
20
30
20
20
20
20
35
10
20
10
20
10
20
25
25
20
15
15
54
Global sourcing. National compliance. Local service.
Fittings & Nipples
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
MATCONORCA
MODEL NUMBER
SIZE
Reducing Tee (Continued)
DB-RT080809LF
DB-RT080810LF
DB-RT0904LF
DB-RT0905LF
DB-RT0906LF
DB-RT090709LF
DB-RT0907LF
DB-RT090808LF
DB-RT090809LF
DB-RT0908LF
DB-RT1005LF
DB-RT1007LF
DB-RT100808LF
DB-RT100810LF
DB-RT1008LF
DB-RT100909LF
DB-RT1009LF
DB-RT1108LF
2” x 2” x 2-1/2”
2” x 2” x 3”
2-1/2” x 3/4”
2-1/2” x 1”
2-1/2” x 1-1/4”
2-1/2” x 1-1/2” x 2-1/2”
2-1/2” x 1-1/2”
2-1/2” x 2” x 2”
2-1/2” x 2” x 2-1/2”
2-1/2” x 2”
3” x 1”
3” x 1-1/2”
3” x 2” x 2”
3” x 2” X 3”
3” x 2”
3” x 2-1/2” x 2-1/2”
3” x 2-1/2”
4” x 2”
Street Tee
DB-ST02LF
DB-ST03LF
DB-ST04LF
DB-ST05LF
DB-ST06LF
DB-ST08LF
3/8”
1/2”
3/4”
1”
1-1/4”
2”
Bushing
DB-BU0100LF
DB-BU0200LF
DB-BU0201LF
DB-BU0300LF
DB-BU0301LF
DB-BU0302LF
DB-BU0400LF
DB-BU0401LF
1/4” x 1/8”
3/8” x 1/8”
3/8” x 1/4”
1/2” x 1/8”
1/2” x 1/4”
1/2” x 3/8”
3/4” x 1/8”
3/4” x 1/4”
CARTON QUANTITIES
INNER MASTER
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
25
25
10
10
1
1
100
50
50
50
100
25
50
100
10
10
10
10
15
10
10
10
10
100
100
40
40
25
10
600
300
300
300
600
200
200
500
MODEL NUMBER
5
5
5
5
5
5
5
5
4
MATCONORCA
Bushing (Continued)
DB-BU0402LF
DB-BU0403LF
DB-BU0500LF
DB-BU0501LF
DB-BU0502LF
DB-BU0503LF
DB-BU0504LF
DB-BU0602LF
DB-BU0603LF
DB-BU0604LF
DB-BU0605LF
DB-BU0701LF
DB-BU0702LF
DB-BU0703LF
DB-BU0704LF
DB-BU0705LF
DB-BU0706LF
DB-BU0801LF
DB-BU0803LF
DB-BU0804LF
DB-BU0805LF
DB-BU0806LF
DB-BU0807LF
DB-BU0903LF
DB-BU0905LF
DB-BU0906LF
DB-BU0907LF
DB-BU0908LF
DB-BU1005LF
DB-BU1006LF
DB-BU1007LF
DB-BU1008LF
DB-BU1009LF
DB-BU10510LF
DB-BU1105LF
DB-BU1107LF
DB-BU1108LF
DB-BU1109LF
DB-BU1110LF
DB-BU11105LF
3/4” x 3/8”
3/4” x 1/2”
1” x 1/8”
1” x 1/4”
1” x 3/8”
1” x 1/2”
1” x 3/4”
1-1/4” x 3/8”
1-1/4” x 1/2”
1-1/4” x 3/4”
1-1/4” x 1”
1-1/2” x 1/4”
1-1/2” x 3/8”
1-1/2” x 1/2”
1-1/2” x 3/4”
1-1/2” x 1”
1-1/2” x 1-1/4”
2” x 1/4”
2” x 1/2”
2” x 3/4”
2” x 1”
2” x 1-1/4”
2” x 1-1/2”
2-1/2” x 1/2”
2-1/2” x 1”
2-1/2” x 1-1/4”
2-1/2” x 1-1/2”
2-1/2” x 2”
3” x 1”
3” x 1-1/4”
3” x 1/2”
3” x 2”
3” x 2-1/2”
3-1/2” x 3”
4” x 1”
4” x 1-1/2”
4” x 2”
4” x 2-1/2”
4” x 3”
4” x 3-1/2”
SIZE
CARTON QUANTITIES
INNER MASTER
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
5
5
5
5
1
1
5
5
1
1
1
1
1
1
1
1
200
200
200
150
200
150
200
100
100
100
100
100
100
100
100
100
100
40
40
40
60
40
40
40
40
20
20
20
25
20
20
20
25
15
10
10
16
15
10
15
Lead Free Domestic
Brass Pipe Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
55
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
Brass Pipe Fittings
Lead Free Domestic
MATCONORCA
MODEL NUMBER
Plug
DB-PL03LF
DB-PL04LF
DB-PL05LF
DB-PL06LF
DB-PL07LF
DB-PL08LF
DB-PL09LF
DB-PL10LF
DB-PL105LF
DB-PL11LF
DB-PL13LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
3-1/2”
4”
6”
Solid Plug
DB-PLS02LF
DB-PLS03LF
DB-PLS04LF
DB-PLS05LF
DB-PLS06LF
DB-PLS07LF
DB-PLS08LF
DB-PLS09LF
DB-PLS10LF
DB-PLS11LF
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
Countersunk Plug
DB-CSP03LF
DB-CSP04LF
DB-CSP05LF
DB-CSP06LF
DB-CSP07LF
DB-CSP08LF
DB-CSP09LF
DB-CSP10LF
DB-CSP11LF
DB-CSP13LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
6”
SIZE
CARTON QUANTITIES
INNER MASTER
25
25
25
25
25
10
5
1
1
1
1
25
25
25
25
25
10
10
5
1
1
25
25
25
25
25
10
1
1
1
1
500
300
150
100
100
40
20
25
15
15
300
300
300
150
100
60
40
20
15
500
500
200
150
100
60
30
20
20
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Cross
DB-CR00LF
DB-CR01LF
DB-CR02LF
DB-CR03LF
DB-CR0403LF
DB-CR04LF
DB-CR05LF
DB-CR0604LF
DB-CR06LF
5
DB-CR07LF
DB-CR08LF
DB-CR09LF
DB-CR10LF
DB-CR11LF
1/8”
1/4”
3/8”
1/2”
3/4” x 1/2”
3/4”
1”
1-1/4” x 3/4”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
25
25
25
25
10
10
5
10
5
1
1
1
1
1
300
300
100
100
40
40
20
40
20
20
10
Lead Free Domestic
Brass Pipe Fittings
5
4
2
Locknut
DB-LN00LF
DB-LN01LF
DB-LN02LF
DB-LN03LF
DB-LN04LF
6
4
DB-LN05LF
DB-LN06LF
DB-LN07LF
DB-LN08LF
DB-LN09LF
DB-LN10LF
DB-LN11LF
1/8”
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
25
25
25
25
25
25
25
25
10
10
1
1
600
500
500
600
300
300
150
100
60
40
50
25
56
Global sourcing. National compliance. Local service.
Fittings & Nipples
Lead Free Domestic Brass
Pipe Fittings
125 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
MATCONORCA
MODEL NUMBER
Union
DB-UN01LF
DB-UN02LF
DB-UN03LF
DB-UN04LF
DB-UN05LF
DB-UN06LF
DB-UN07LF
DB-UN08LF
Drop Ear Elbow
DB-DEL9001LF
DB-DEL9002LF
DB-DEL9003LF
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
1/4”
3/8”
1/2”
SIZE
CARTON QUANTITIES
INNER MASTER
25
25
25
25
10
5
5
1
25
25
25
300
100
100
300
200
100
75
40
20
20
15
MATCONORCA
MODEL NUMBER
Extension Piece
DB-X03LF
DB-X04LF
DB-X05LF
DB-X06LF
DB-X07LF
DB-X08LF
Lateral Y-Branch
DB-Y02LF
DB-Y03LF
DB-Y04LF
DB-Y05LF
DB-Y06LF
DB-Y07LF
DB-Y08LF
DB-Y09LF
DB-Y10LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
SIZE
CARTON QUANTITIES
INNER MASTER
25
25
1
1
1
1
25
25
10
5
5
1
1
1
1
200
100
150
100
75
50
40
25
40
20
20
15
10
Lead Free Domestic
Brass Pipe Fittings
5
4
Drop Ear Tee
DB-DET02LF 3/8” 25 100
Fittings & Nipples
Global sourcing. National compliance. Local service.
57
Lead Free Domestic Brass
Pipe Fittings
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
• Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
Flanges Class 150 lbs & 300 lbs
•
• Castings to ASME B16.15
Brass Pipe Fittings
Lead Free Domestic
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Bronze Blind Flange - 150#
DB-CFB08LF
DB-CFB09LF
DB-CFB10LF
DB-CFB11LF
DB-CFB12LF
DB-CFB13LF
2”
2-1/2”
3”
4”
5”
6”
1
1
1
1
1
1
Floor Flange
DB-FF01LF
DB-FF02LF
DB-FF03LF
DB-FF04LF
DB-FF05LF
DB-FF06LF
DB-FF07LF
DB-FF08LF
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
25
25
25
25
10
10
10
5
Bronze Companion Flange - Threaded 150#
DB-CF03LF
DB-CF04LF
DB-CF05LF
DB-CF06LF
DB-CF07LF
DB-CF08LF
DB-CF09LF
DB-CF10LF
DB-CF11LF
DB-CF12LF
DB-CF13LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
1
1
1
1
1
1
1
1
1
1
1
14
300
150
100
100
40
40
40
20
45
30
25
28
16
10
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Companion Flange - Sweat 125#
DB-CFCL04LF
7
6
3
4
3
DB-CFCL05LF
DB-CFCL06LF
DB-CFCL07LF
DB-CFCL08LF
DB-CFCL09LF
DB-CFCL10LF
DB-CFCL11LF
DB-CFCL12LF
DB-CFCL13LF
DB-CFCL14LF
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
8”
1
1
1
1
1
1
1
1
1
1
1
30
30
30
20
10
5
6
3
4
2
1
Companion Flange - Sweat 150#
DB-CFCH03LF
DB-CFCH04LF
DB-CFCH05LF
DB-CFCH06LF
DB-CFCH07LF
DB-CFCH08LF
DB-CFCH09LF
DB-CFCH10LF
DB-CFCH11LF
DB-CFCH12LF
DB-CFCH13LF
DB-CFCH14LF
5
4
4
3
4
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
8”
1
1
1
1
1
1
1
1
1
1
1
1
40
30
20
15
10
5
5
5
3
2
2
1
58
Global sourcing. National compliance. Local service.
Fittings & Nipples
Domestic Brass
Pipe Fittings
125 LB.
• CSA Approved
• Class 125 lbs & 250 lbs
• Flanges Class 150 lbs & 300 lbs • Castings to ASME B16.15
• NPT Threads to ASME B1.20.1 • NSF/ANSI 61 Certied
• Stocked 1/2” - 10” Diameter • Buy American Act & ARRA. DEFARS 252.225-7008
MATCONORCA
MODEL NUMBER
SIZE
Companion Flange - Sweat 125#
DB-CFCL04
DB-CFCL05
DB-CFCL06
DB-CFCL07
DB-CFCL08
DB-CFCL09
DB-CFCL10
DB-CFCL11
DB-CFCL12
DB-CFCL13
DB-CFCL14
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
8”
Companion Flange - Sweat 150#
DB-CFCH03
DB-CFCH04
DB-CFCH05
DB-CFCH06
DB-CFCH07
DB-CFCH08
DB-CFCH09
DB-CFCH10
DB-CFCH11
DB-CFCH12
DB-CFCH13
DB-CFCH14
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
4”
5”
6”
8”
CARTON QUANTITIES
INNER MASTER
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
30
30
30
20
10
40
30
20
15
10
MATCONORCA
MODEL NUMBER
SIZE
CARTON QUANTITIES
INNER MASTER
Southern Cleanout Plug - Countersunk
DB-CPCS05
DB-CPCS06
DB-CPCS07
DB-CPCS08
DB-CPCS09
5
6
3
4
2
1
DB-CPCS10
DB-CPCS105
DB-CPCS11
DB-CPCS115
DB-CPCS12
DB-CPCS125
DB-CPCS13
DB-CPCS14
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
3-1/2”
4”
4-1/2”
5”
5-1/2”
6”
8”
1
1
1
1
1
1
1
1
1
1
1
1
1
600
400
300
200
175
100
75
50
40
25
30
20
10
Lead Free Domestic
Brass Pipe Fittings
Southern Cleanout Plug
DB-CPS05
DB-CPS06
5
5
5
3
2
2
1
DB-CPS07
DB-CPS08
DB-CPS09
DB-CPS10
DB-CPS105
DB-CPS11
DB-CPS115
DB-CPS12
DB-CPS125
DB-CPS13
DB-CPS14
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
3-1/2”
4”
4-1/2”
5”
5-1/2”
6”
8”
1
1
1
1
1
1
1
1
1
1
1
1
1
500
300
300
200
150
100
75
50
40
35
30
20
10
Ohio Cleanout Plug
DB-CPO07
DB-CPO08
DB-CPO09
DB-CPO10
DB-CPO105
DB-CPO11
DB-CPO12
DB-CPO14
DB-CPO15
1-1/2”
2”
2-1/2”
3”
3-1/2”
4”
5”
8”
10”
Fittings & Nipples
1
1
1
1
1
1
1
1
1
100
100
75
50
40
30
20
10
5
Global sourcing. National compliance. Local service.
59
Lead Free Domestic Brass
Pipe Fittings
250LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
•
Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
Brass Pipe Fittings
Lead Free Domestic
MATCONORCA
MODEL NUMBER
XH 90º Elbow
DB-LX9001LF
DB-LX9002LF
DB-LX9003LF
DB-LX9004LF
DB-LX9005LF
DB-LX9006LF
DB-LX9007LF
DB-LX9008LF
DB-LX9009LF
DB-LX9010LF
XH 90º Street Elbow
DB-LSTX9005LF
DB-LSTX9007LF
SIZE
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
1”
1-1/2”
CARTON QUANTITIES
INNER MASTER
25
25
25
25
10
5
1
1
1
1
10
1
300
200
100
100
40
20
20
10
10
40
25
MATCONORCA
MODEL NUMBER
5
SIZE
XH Coupling
DB-CPX01LF
DB-CPX02LF
DB-CPX03LF
DB-CPX04LF
DB-CPX05LF
DB-CPX06LF
DB-CPX07LF
DB-CPX08LF
DB-CPX09LF
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
XH Reducing Coupling
DB-RCX0403LF
DB-RCX0503LF
DB-RCX0504LF
DB-RCX0605LF
DB-RCX0705LF
DB-RCX0706LF
DB-RCX0807LF
DB-RCX0908LF
3/4” x 1/2”
1” x 1/2”
1” x 3/4”
1-1/4” x 1”
1-1/2” x 1”
1-1/2” x 1-1/4”
2” x 1-1/2”
2-1/2” x 2”
CARTON QUANTITIES
INNER MASTER
10
10
10
25
10
5
5
5
1
10
10
10
5
5
5
10
1
240
150
120
100
60
30
20
25
20
50
40
60
20
20
20
25
10
60
XH 45º Elbow
DB-LX4503LF
DB-LX4504LF
DB-LX4505LF
DB-LX4506LF
DB-LX4507LF
DB-LX4508LF
DB-LX4509LF
DB-LX4510LF
Global sourcing. National compliance. Local service.
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
3”
10
10
10
5
5
4
1
1
50
80
40
20
30
15
10
XH Cap
5
DB-CAX03LF
DB-CAX04LF
DB-CAX05LF
DB-CAX06LF
DB-CAX07LF
DB-CAX08LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
25
10
25
10
10
10
300
60
100
40
40
30
Fittings & Nipples
Lead Free Domestic Brass
Pipe Fittings
250 LB.
• NPT Threads to ASME B1.20.1
• NSF/ANSI 61 Certied
• Stocked 1/8” - 8” Diameter
•
Buy American Act & ARRA. DEFARS 252.225-7008
• CSA Approved
• Class 125 lbs & 250 lbs
•
Flanges Class 150 lbs & 300 lbs
• Castings to ASME B16.15
MATCONORCA
MODEL NUMBER
XH Tee
DB-TX01LF
DB-TX02LF
DB-TX03LF
DB-TX04LF
DB-TX05LF
DB-TX06LF
DB-TX07LF
DB-TX08LF
DB-TX09LF
DB-TX11LF
XH Reducing Tee
DB-TRX0301LF
DB-TRX050305LF
DB-TRX0503LF
DB-TRX0504LF
DB-TRX0603LF
SIZE
1/4”
3/8”
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
2-1/2”
4”
1/2” x 1/4”
1” x 1/2” x 1”
1” x 1/2”
1” x 3/4”
1-1/4” x 1/2”
CARTON QUANTITIES
INNER MASTER
25
25
25
1
10
5
5
2
1
1
20
10
10
10
1
300
100
100
25
40
20
15
12
80
40
40
40
30
5
2
MATCONORCA
MODEL NUMBER
XH Companion Flange
DB-CFX07LF
DB-CFX08LF
DB-CFX09LF
DB-CFX10LF
DB-CFX11LF
1-1/2”
2”
2-1/2”
3”
4”
XH Union
DB-XUN03LF
DB-XUN04LF
DB-XUN05LF
DB-XUN06LF
DB-XUN07LF
DB-XUN08LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
SIZE
CARTON QUANTITIES
INNER MASTER
1
1
1
1
1
10
10
10
5
5
10
10
10
5
4
4
50
40
40
20
20
10
Lead Free Domestic
Brass Pipe Fittings
XH Cross
DB-CRX03LF
DB-CRX04LF
DB-CRX05LF
DB-CRX06LF
DB-CRX07LF
DB-CRX08LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
Fittings & Nipples
10
10
5
1
5
1
40
40
20
10
15
XH Union Elbow
DB-XUNL03LF
DB-XUNL04LF
DB-XUNL05LF
DB-XUNL06LF
DB-XUNL07LF
5
DB-XUNL08LF
1/2”
3/4”
1”
1-1/4”
1-1/2”
2”
Global sourcing. National compliance. Local service.
1
10
1
1
1
1
65
40
35
20
10
8
61
Lead Free Chrome
Plated Brass Fittings
• Meets NSF/ANSI Standard 61
Section 8 (2011) & Annex F
• Meets All Applicable ASTM Standards
• Stocked From 3/8” - 3/4” Diameters
Brass Fittings
Chrome Plated
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
90º Elbow
C-L9002LF 3/8” 25 300
C-L9003LF 1/2” 25 200
C-L9004LF 3/4” 25 100
90º Street Elbow
C-ST9002LF 3/8” 25 400
C-ST9003LF 1/2” 25 200
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Coupling
C-CP02LF 3/8” 25 300
C-CP03LF 1/2” 25 200
C-CP04LF 3/4” 25 100
C-RC0302LF 1/2” x 3/8” 25 200
Bushing
C-BU0302LF 1/2” x 3/8” 25 450
C-BU0403LF 3/4” x 1/2” 25 300
62
45º Elbow
C-L4502LF 3/8” 25 400
C-L4503LF 1/2” 25 200
C-L4504LF 3/4” 25 100
Tee
C-T02LF 3/8” 25 200
C-T03LF 1/2” 25 100
C-T04LF 3/4” 25 75
Global sourcing. National compliance. Local service.
Union
C-UN02LF 3/8” 25 150
C-UN03LF 1/2” 25 75
C-UN04LF 3/4” 25 75
Plug
C-PL02LF 3/8” 25 1400
C-PL03LF 1/2” 25 600
C-PL04LF 3/4” 25 300
Fittings & Nipples
Lead Free Brass
Pex Fittings
• NSF & UPC Approved • Used with Pex Tubing
• Manufactured to ASTM Standard F1807 • Manufactured to ASTM Standard F876-877
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Elbow - Pex Barb
PXL02LF 3/8” 25 800
PXL03LF 1/2” 25 500
PXL58LF 5/8” 25 300
PXL04LF 3/4” 25 300
PXL05LF 1” 15 150
Reducer Elbow - Pex Barb x Pex Barb
PXRL0403LF 3/4” x 1/2” 25 400
Elbow - Pex Barb x MIP
PXLM0303LF 1/2” x 1/2” 25 250
PXLM0304LF 1/2” x 3/4” 15 300
PXLM0404LF 3/4” x 3/4” 25 250
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Tee - Pex Barb
PXT02LF 3/8” 50 500
PXT03LF 1/2” 25 500
PXT58LF 5/8” 25 300
PXT04LF 3/4” 25 250
PXT05LF 1” 10 120
Reducing Tee - Pex Barb
PXRT030304LF 1/2” x 1/2” x 3/4” 25 300
PXRT040303LF 3/4” x 1/2” x 1/2” 25 300
PXRT040304LF 3/4” x 1/2” x 3/4” 25 250
PXRT040403LF 3/4” x 3/4” x 1/2” 25 250
PXRT040405LF 3/4” x 3/4” x 1” 15 120
PXRT050304LF 1” x 1/2” x 3/4” 15 120
PXRT050305LF 1” x 1/2” x 1” 15 120
PXRT050403LF 1” x 3/4” x 1/2” 15 120
PXRT050404LF 1” x 3/4” x 3/4” 15 120
PXRT050405LF 1” x 3/4” x 1” 15 120
PXRT050503LF 1” x 1” x 1/2” 15 120
PXRT050504LF 1” x 1” x 3/4” 15 120
Brass Pex Fittings
Elbow - Female Sweat x Pex Barb
PXLFC0303LF 1/2” x 1/2” 25 500
PXLFC0304LF 1/2” x 3/4” 15 300
PXLFC0403LF 3/4” x 1/2” 15 300
PXLFC0404LF 3/4” x 3/4” 15 300
PXLFC0505LF 1” x 1” 15 120
Elbow - Male Sweat x Pex Barb
PXLMC0303LF 1/2” x 1/2” 25 300
PXLMC0404LF 3/4” x 3/4” 25 250
Fittings & Nipples
Coupling - Pex Barb
PXCP02LF 3/8” 50 1,000
PXCP03LF 1/2” 50 1,000
PXCP58LF 5/8” 25 500
PXCP04LF 3/4” 25 500
PXCP05LF 1” 10 200
Reducing Coupling - Pex Barb
PXCPR0302LF 1/2” x 3/8” 50 1,000
PXCPR0403LF 3/4” x 1/2” 25 500
PXCPR0504LF 1” x 3/4” 25 300
Global sourcing. National compliance. Local service.
63
Lead Free Brass
Pex Fittings
• NSF & UPC Approved • Used with Pex Tubing
• Manufactured to ASTM Standard F1807 • Manufactured to ASTM Standard F876-877
Brass Pex Fittings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Male & Female Adapter - Pex Barb x IP
Male Adapter - Pex Barb x MIP
PXMA0303LF 1/2” x 1/2” 25 500
PXMA0304LF 1/2” x 3/4” 25 250
PXMA5803LF 5/8” x 1/2” 25 400
PXMA0403LF 3/4” x 1/2” 25 300
PXMA0404LF 3/4” x 3/4” 25 250
PXMA0405LF 3/4” x 1” 15 120
PXMA0504LF 1” x 3/4” 25 120
PXMA0505LF 1” x 1” 15 120
Female Adapter - Pex Barb x FIP
PXFA0303LF 1/2” x 1/2” 25 300
PXFA0304LF 1/2” x 3/4” 25 250
PXFA0404LF 3/4” x 3/4” 25 200
PXFA0405LF 3/4” x 1” 10 100
PXFA0505LF 1” x 1” 10 100
Male & Female Sweat Adapter - Sweat x Pex Barb
Male Sweat Adapter
PXMAS0302LF 1/2” x 3/8” 50 1000
PXMAS0303LF 1/2” x 1/2” 50 1000
PXMAS0358LF 1/2” x 5/8” 50 1000
PXMAS0304LF 1/2” x 3/4” 25 500
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Plug - Pex Barb
PXPL02LF 3/8” 100 2000
PXPL03LF 1/2” 100 1500
PXPL04LF 3/4” 50 1000
PXPL05LF 1” 25 400
Drop Ear Elbow - Pex Barb x FIP
PXLD0303LF 1/2” x 1/2” 25 250
Pex Crimp Ring - Copper & Stainless Steel
Lead Free Only
Copper
PXCR03LF 1/2” 100 2000
PXCR04LF 3/4” 100 1500
PXCR05LF 1” 50 800
64
PXMAS0404LF 3/4” x 3/4” 25 500
PXMAS0505LF 1” x 1” 15 120
Female Sweat Adapter
PXFAC0302LF 1/2” x 3/8” 50 1000
PXFAC0303LF 1/2” x 1/2” 50 1000
PXFAC0358LF 1/2” x 5/8” 50 1000
PXFAC0304LF 1/2” x 3/4” 50 1000
PXFAC0403LF 3/4” x 1/2” 25 500
PXFAC0404LF 3/4” x 3/4” 25 500
PXFAC0505LF 1” x 1” 15 120
Global sourcing. National compliance. Local service.
Only Available in Standard
Stainless Steel
PXSSCR02 3/8” 100 4000
PXSSCR03 1/2” 100 2000
PXSSCR58 5/8” 50 2500
PXSSCR04 3/4” 50 2000
PXSSCR05 1” 50 1300
Fittings & Nipples
F1960 Cold Expansion
Lead Free Brass
Pex Fittings
• For use in Hot and Cold
Potable Water Distribution Systems
• Max. Working Temp./Pressure:
180° F @ 100 PSI
• Manufactured and tested in
accordance with ASTM F1960 and F877
• Compliant with CSA B137.5
• ASTM F1960
• CSA B137.5
• NSF/ANSI 14
NSF/ANSI 61
NSF/ANSI 372
• cNSFus
• cUPC
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Elbow - Pex Barb
PXCEL03LF 1/2” 25 250
PXCEL04LF 3/4” 25 150
PXCEL05LF 1” 10 70
Reducing Elbow - Pex Barb
PXCERL0403LF 3/4” x 1/2” 25 200
Elbow - Female Sweat x Pex Barb
PXCELFC0303LF 1/2” x 1/2” 25 250
PXCELFC0304LF 1/2” x 3/4” 15 150
PXCELFC0403LF 3/4” x 1/2” 15 150
PXCELFC0404LF 3/4” x 3/4” 15 150
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Drop Ear Elbow - Pex Barb x FPT
PXCELD0303LF 1/2” x 1/2” 10 200
Coupling - Pex Barb
PXCECP03LF 1/2” 50 500
PXCECP04LF 3/4” 25 250
PXCECP05LF 1” 10 100
Reducing Coupling - Pex Barb
PXCECPR0302LF 1/2” x 3/8” 50 500
PXCECPR0403LF 3/4” x 1/2” 25 250
PXCECPR0504LF 1” x 3/4” 25 150
Brass Pex Fittings
Cold Expansion
PXCELFC0505LF 1” x 1” 15 60
Elbow - Pex Barb x MIP
PXCELM0303LF 1/2” x 1/2” 25 250
PXCELM0404LF 3/4” x 3/4” 25 150
Elbow - Male Sweat x Pex Barb
PXCELMC0303LF 1/2” x 1/2” 25 300
PXCELMC0404LF 3/4” x 3/4” 25 150
Fittings & Nipples
Tee - Pex Barb
PXCET03LF 1/2” 25 150
PXCET04LF 3/4” 25 100
PXCET05LF 1” 25 50
Reducing Tee - Pex Barb
PXCERT030304LF 1/2” x 1/2” x 3/4” 25 150
PXCERT040303LF 3/4” x 1/2” x 1/2” 25 150
PXCERT040304LF 3/4” x 1/2” x 3/4” 15 120
PXCERT040403LF 3/4” x 3/4” x 1/2” 15 120
PXCERT040405LF 3/4” x 3/4” x 1” 15 60
PXCERT050305LF 1” x 1/2” x 1” 25 50
PXCERT050404LF 1” x 3/4” x 3/4” 15 60
PXCERT050405LF 1” x 3/4” x 1” 25 50
PXCERT050503LF 1” x 1” x 1/2” 25 50
PXCERT050504LF 1” x 1” x 3/4” 25 50
Global sourcing. National compliance. Local service.
65
F1960 Cold Expansion
Lead Free Brass
Pex Fittings
• For use in Hot and Cold
Potable Water Distribution Systems
• Max. Working Temp./Pressure:
180° F @ 100 PSI
• Manufactured and tested in
accordance with ASTM F1960 and F877
• Compliant with CSA B137.5
• ASTM F1960
• CSA B137.5
• NSF/ANSI 14,
NSF/ANSI 61,
NSF/ANSI 372
• cNSFus
• cUPC
MATCONORCA
MODEL NUMBER
Male & Female Adapter - Pex Barb x IP
Male Adapter - Pex Barb x MIP
PXCEMA0303LF 1/2” x 1/2” 25 250
PXCEMA0304LF 1/2” x 3/4” 25 250
PXCEMA0403LF 3/4” x 1/2” 25 300
PXCEMA0404LF 3/4” x 3/4” 25 250
PXCEMA0405LF 3/4” x 1” 15 120
PXCEMA0504LF 1” x 3/4” 25 100
PXCEMA0505LF 1” x 1” 15 120
Female Adapter - Pex Barb x FIP
PXCEFA0303LF 1/2” x 1/2” 25 300
PXCEFA0404LF 3/4” x 3/4” 25 200
PXCEFA0505LF 1” x 1” 10 100
Cold Expansion
Brass Pex Fittings
Male & Female Sweat Adapter - Sweat x Pex Barb
Male Sweat Adapter
PXCEMAS0303LF 1/2” x 1/2” 50 500
PXCEMAS0404LF 3/4” x 3/4” 25 200
PXCEMAS0505LF 1” x 1” 10 120
Female Sweat Adapte
PXCEFAC0303LF 1/2” x 1/2” 25 400
PXCEFAC0304LF 1/2” x 3/4” 25 250
CARTON QUANTITIES
INNER MASTER
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Plug - Pex Barb
PXCEPL03LF 1/2” 100 700
PXCEPL04LF 3/4” 50 300
PXCEPL05LF 1” 25 200
66
PXCEFAC0403LF 3/4” x 1/2” 25 300
PXCEFAC0404LF 3/4” x 3/4” 25 300
PXCEFAC0505LF 1” x 1” 15 120
Global sourcing. National compliance. Local service.
Fittings & Nipples
Cast Brass Sweat
Adapter Fittings
• Complete Line of Cast Brass Fittings
• Primarily Used for Heating Systems as a Transition Applicator
• Lead Free Version Available
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Cast Brass Reducing Adapter Tee
CRTF030304LF 1/2” IP x 1/2” IP x 3/4” C 25 200
CRTF0304T03LF 1/2” C x 3/4” FIP x 1/2” C 25 200
CRTF0403 3/4” C x 3/4” C x 1/2” FIP 25 200
CRTF0403L 3/4” C x 3/4” C x 1/2” FIP Long 25 150
CRTF040303 3/4” IP x 1/2” IP x 1/2” C 25 200
CRTF040304 3/4” IP x 1/2” IP x 3/4” C 25 200
CRTF0403T04 3/4” C x 1/2” FIP x 3/4” C 25 200
CRTF0503 1” C x 1” C x 1/2” FIP 8 80
CRTF0503T05 1” C x 1/2” FIP x 1” C 15 120
CRTF0504 1” C x 1” C x 3/4” FIP 8 80
CRTF0504T05 1” C x 3/4” FIP x 1” C 15 120
CRTF0603 1-1/4” C x 1-1/4” C x 1/2” FIP 6 60
CRTF0604 1-1/4” C x 1-1/4” C x 3/4” FIP 6 60
CRTF0703 1-1/2” C x 1-1/2” C x 1/2” FIP 6 60
CRTF0704 1-1/2” C x 1-1/2” C x 3/4” FIP 6 60
Cast Brass Union
CUN03M 1/2” C x 1/2” MIP 25 200
CUN04M 3/4” C x 3/4” MIP 25 200
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Cast Brass Adapter Tee
CTF0303 1/2” C x 1/2” C x 1/2” FIP 25 250
CTF03T03 1/2” C x 1/2” FIP x 1/2” C 25 200
CTF0404 3/4” C x 3/4” C x 3/4” FIP 25 250
CTF04T04 3/4” C x 3/4” FIP x 3/4” C 25 200
CTFT04T04LF 3/4” FIP x 3/4” FIP x 3/4” C 25 200
Cast Brass Adapter Elbow
CLF0303 1/2” C x 1/2” FIP 25 250
CLF0403 3/4” C x 1/2” FIP 25 250
CLF0404 3/4” C x 3/4” FIP 25 250
CLFM0303 1/2” C x 1/2” MIP 25 250
CLFM0404 3/4” C x 3/4” MIP 25 250
CLFM0505LF 1” C x 1” MIP 10 120
Cast Brass Adapter
CFAB0304 1/2” C x 3/4” FIP 25 250
Cast Brass Sweat
Adapter Fittings
Cast Brass Adapter Tee - Extra Long
CRTFM040304 3/4” MIP x 1/2” FIP
x 3/4” C x 4-1/2” Long 1 1
Cast Brass Baseboard Tee
BBT03LF 1/2” C x 1/8” FIP x 1/2” C 25 250
BBT04 3/4” C x 1/8” FIP x 3/4” C 25 200
BBT04V 3/4” C x 1/8” FIP x 3/4” C
With Vent Cap 25 200
BBT05 1” C x 1/8” FIP x 1” C 25 250
Cast Bronze Drop Ear 90º Elbow
DE-0203 3/8” NPT x 1/2” C 25 250
DE-0303 1/2” NPT x 1/2” C 25 250
DE-0303C 1/2” C x 1/2” C 25 250
DE-0304 1/2” NPT x 3/4” C 25 250
DE-0403 3/4” NPT x 1/2” C 25 250
DE-0404 3/4” NPT x 3/4” C 25 250
Lead Free Cast Brass Coupling
CCP03VLF 1/2” C With Weep Cap 25 250
CCP04VLF 3/4” C With Weep Cap 25 250
Add LF Sux for Lead Free Version. Some Only Available in Lead Free. They will have LF on the Part #.
Fittings & Nipples
Global sourcing. National compliance. Local service.
67
Wrot Copper Fittings
Wrot Solder Joint
• NSF 61 Compliant
• IAPMO Approved
• Meets ANSI 16
• Materials Specications
to ASTM B88
• Lead Free
Fittings
Wrot Copper
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
90º Elbow - Copper x Copper - Close Rough
CL9000 1/8” 1/4” 25 3000
CL9001 1/4” 3/8” 25 1200
CL9002 3/8” 1/2” 25 1000
CL9003 1/2” 5/8” 100 800
CL9058 5/8” 3/4” 25 300
CL9004 3/4” 7/8” 25 250
CL9005 1” 1-1/8” 10 100
CL9006 1-1/4” 1-3/8” 50 50
CL9007 1-1/2” 1-5/8” 35 35
CL9008 2” 2-1/8” 17 17
CL9009 2-1/2” 2-5/8” 8 8
CL9010 3” 3-1/8” 13 13
CL9011 4” 4-1/8” 6 6
CL9013 6” 6-1/8” 1 1
Reducing Elbow
CLR0403 3/4” x 1/2” 7/8” x 5/8” 25 200
90º Elbow - Copper x Copper - Long Turn
CLL9000 1/8” 1/4” 25 2000
CLL9001 1/4” 3/8” 25 1200
CLL9002 3/8” 1/2” 25 75
CLL9003 1/2” 5/8” 25 350
CLL9058 5/8” 3/4” 25 200
CLL9004 3/4” 7/8” 10 120
CLL9005 1” 1-1/8” 10 70
CLL9006 1-1/4” 1-3/8” 35 35
CLL9007 1-1/2” 1-5/8” 25 25
CLL9008 2” 2-1/8” 12 12
45º Elbow - Copper x Copper - Close Rough
CL4501 1/4” 3/8” 25 2000
CL4502 3/8” 1/2” 25 800
CL4503 1/2” 5/8” 25 500
CL4558 5/8” 3/4” 25 200
CL4504 3/4” 7/8” 25 200
CL4505 1” 1-1/8” 10 100
CL4506 1-1/4” 1-3/8” 60 60
CL4507 1-1/2” 1-5/8” 40 40
CL4508 2” 2-1/8” 18 18
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
90º Street Elbow - Fitting x Copper - Close Rough
CLST9002 3/8” 1/2” 25 1000
CLST9003 1/2” 5/8” 25 500
CLST9058 5/8” 3/4” 25 300
CLST9004 3/4” 7/8” 25 200
CLST9005 1” 1-1/8” 10 100
CLST9006 1-1/4” 1-3/8” 50 50
CLST9007 1-1/2” 1-5/8” 35 35
CLST9008 2” 2-1/8” 17 17
CLST9010 3” 3-1/8” 13 13
CLST9011 4” 4-1/8” 6 6
90º Street Elbow - Fitting x Copper - Long Turn
CLLST9001 1/4” 3/8” 25 1200
CLLST9002 3/8” 1/2” 25 750
CLLST9003 1/2” 5/8” 25 350
CLLST9058 5/8” 3/4” 25 200
CLLST9004 3/4” 7/8” 10 120
CLLST9005 1” 1-1/8” 10 80
45º Street Elbow - Fitting x Copper - Close Rough
CLST4503 1/2” 5/8” 25 500
CLST4558 5/8” 3/4” 25 300
CLST4504 3/4” 7/8” 25 200
CLST4505 1” 1-1/8” 10 100
CLST4506 1-1/4” 1-3/8” 60 60
CLST4507 1-1/2” 1-5/8” 40 40
CLST4508 2” 2-1/8” 18 18
68
Global sourcing. National compliance. Local service.
Fittings & Nipples
Wrot Copper Fittings
Wrot Solder Joint
• NSF 61 Compliant
• IAPMO Approved
• Meets ANSI 16
• Materials Specications
to ASTM B88
• Lead Free
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Street Male Adapter - Fitting x Male
CMAST03 1/2” 5/8” x 1/2” 25 500
CMAST04 3/4” 7/8” x 3/4” 25 250
CMAST05 1” 1-1/8” x 1” 10 130
CMAST06 1-1/4” 1-3/8” x 1-1/4” 80 80
CMAST07 1-1/2” 1-5/8” x 1-1/2” 50 50
CMAST08 2” 2-1/8” x 2” 38 38
Male Adapter - Copper x Male
CMA02 3/8” 1/2” x 3/8” 25 1000
CMA03 1/2” 5/8” x 1/2” 25 600
CMA0302 1/2” x 3/8” 5/8” x 3/8” 25 800
CMA0304 1/2” x 3/4” 5/8” x 3/4” 25 250
CMA04 3/4” 7/8” x 3/4” 25 250
CMA0403 3/4” x 1/2” 7/8” x 1/2” 25 250
CMA0405 3/4” x 1” 7/8” x 1” 10 150
CMA05 1” 1-1/8” x 1” 10 150
CMA0503 1” x 1/2” 1-1/8” x 1-1/2” 10 180
CMA0504 1” x 3/4” 1-1/8” x 3/4” 10 150
CMA06 1-1/4” 1-3/8” x 1-1/4” 110 110
CMA07 1-1/2” 1-5/8” x 1-1/2” 65 65
CMA08 2” 2-1/8” x 2” 38 38
CMA09 2-1/2” 2-5/8” x 2-1/2” 48 48
CMA10 3” 3-1/8” x 3” 36 36
CMA11 4” 4-1/8” x 4” 12 12
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Street Female Adapter - Fitting x Female
CFAST03 1/2” 5/8” x 1/2” 25 500
CFAST04 3/4” 7/8” x 3/4” 25 250
CFAST08 2” 2-1/8” x 2” 5 40
Female Adapter - Copper x Female
CFA02 3/8” 1/2” x 3/8” 25 800
CFA03 1/2” 5/8” x 1/2” 25 450
CFA0302 1/2” x 3/8” 5/8” x 3/8” 25 800
CFA0304 1/2” x 3/4” 5/8” x 3/4” 25 300
CFA04 3/4” 7/8” x 3/4” 25 200
CFA0403 3/4” x 1/2” 7/8” x 1/2” 25 300
CFA0405 3/4” x 1” 7/8” x 1” 10 140
CFA05 1” 1-1/8” x 1” 10 140
CFA0503 1” x 1/2” 1-1/8” x 1/2” 10 100
CFA0504 1” x 3/4” 1-1/8” x 3/4” 10 150
CFA06 1-1/4” 1-3/8” x 1-1/4” 10 100
CFA07 1-1/2” 1-5/8” x 1-1/2” 10 100
CFA08 2” 2-1/8” x 2” 5 50
Wrot Copper
Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
69
Wrot Copper Fittings
Wrot Solder Joint
• NSF 61 Compliant
• IAPMO Approved
• Meets ANSI 16
• Materials Specications
to ASTM B88
• Lead Free
Fittings
Wrot Copper
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Coupling With Rolled Stop - Copper x Copper
CCP01 1/4” 3/8” 25 2000
CCP02 3/8” 1/2” 25 1200
CCP03 1/2” 5/8” 25 800
CCP58 5/8” 3/4” 25 400
CCP04 3/4” 7/8” 25 300
CCP05 1” 1-1/8” 10 150
CCP06 1-1/4” 1-3/8” 100 100
CCP07 1-1/2” 1-5/8” 60 60
CCP08 2” 2-1/8” 40 40
CCP11 4” 4-1/8” 5 5
Reducing Coupling - Copper x Copper
CCPR0100 1/4” x 1/8” 3/8” x 1/4” 25 2000
CCPR0201 3/8” x 1/4” 1/2” x 3/8” 25 800
CCPR0301 1/2” x 1/4” 5/8” x 3/8” 25 800
CCPR0302 1/2” x 3/8” 5/8” x 1/2” 25 800
CCPR5802 5/8” x 3/8” 3/4” x 1/2” 25 500
CCPR5803 5/8” x 1/2” 3/4” x 5/8” 25 600
CCPR0403 3/4” x 1/2” 7/8” x 5/8” 25 350
CCPR0458 3/4” x 5/8” 7/8” x 3/4” 25 400
CCPR0502 1” x 3/8” 1-1/8” x 1/2” 10 180
CCPR0503 1” x 1/2” 1-1/8” x 5/8” 10 200
CCPR0504 1” x 3/4” 1-1/8” x 7/8” 10 160
CCPR0603 1-1/4” x 1/2” 1-3/8” x 5/8” 100 100
CCPR0604 1-1/4” x 3/4” 1-3/8” x 7/8” 100 100
CCPR0605 1-1/4” x 1” 1-3/8” x 1-1/8” 100 100
CCPR0703 1-1/2” x 1/2” 1-5/8” x 5/8” 100 100
CCPR0704 1-1/2” x 3/4” 1-5/8” x 7/8” 100 100
CCPR0705 1-1/2” x 1” 1-5/8” x 1-1/8” 100 100
CCPR0706 1-1/2” x 1-1/4” 1-5/8” x 1-3/8” 100 100
CCPR0803 2” x 1/2” 2-1/8” x 5/8” 50 50
CCPR0804 2” x 3/4” 2-1/8” x 7/8” 50 50
CCPR0805 2” x 1” 2-1/8” x 1-1/8” 50 50
CCPR0806 2” x 1-1/4” 2-1/8” x 1-3/8” 50 50
CCPR0807 2” x 1-1/2” 2-1/8” x 1-5/8” 50 50
CCPR1008 3” x 2” 3-1/8” x 2-1/8” 20 20
CCPR1009 3” x 2-1/2” 3-1/8” x 2-5/8” 15 15
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Coupling Less Stop - Copper x Copper
CCPS01 1/4” 3/8” 25 2000
CCPS03 1/2” 5/8” 25 800
CCPS04 3/4” 7/8” 25 300
CCPS58 5/8” 3/4” 25 400
CCPS05 1” 1-1/8” 10 150
CCPS06 1-1/4” 1-3/8” 100 100
CCPS07 1-1/2” 1-5/8” 60 60
CCPS08 2” 2-1/8” 40 40
Fitting Reducer - Fitting x Copper
CBU0100 1/4” x 1/8” 3/8” x 1/4” 25 3300
CBU0200 3/8” x 1/8” 1/2” x 1/4” 25 800
CBU0201 3/8” x 1/4” 1/2” x 3/8” 25 1200
CBU0301 1/2” x 1/4” 5/8” x 3/8” 25 1000
CBU0302 1/2” x 3/8” 5/8” x 1/2” 25 1000
CBU0403 3/4” x 1/2” 7/8” x 5/8” 25 400
CBU0458 3/4” x 5/8” 7/8” x 3/4” 25 400
CBU0502 1” x 3/8” 1-1/8” x 1/2” 10 200
CBU0503 1” x 1/2” 1-1/8” x 5/8” 10 200
CBU0504 1” x 3/4” 1-1/8” x 7/8” 10 160
CBU0558 1” x 5/8” 1-1/8” x 3/4” 10 400
CBU0603 1-1/4” x 1/2” 1-3/8” x 5/8” 100 100
CBU0604 1-1/4” x 3/4” 1-3/8” x 7/8” 100 100
CBU0605 1-1/4” x 1” 1-3/8” x 1-1/8” 100 100
CBU0703 1-1/2” x 1/2” 1-5/8” x 5/8” 100 100
CBU0704 1-1/2” x 3/4” 1-5/8” x 7/8” 100 100
CBU0705 1-1/2” x 1” 1-5/8” x 1-1/8” 100 100
CBU0706 1-1/2” x 1-1/4” 1-5/8” x 1-3/8” 100 100
CBU0803 2” x 1/2” 2-1/8” x 5/8” 50 50
CBU0804 2” x 3/4” 2-1/8” x 7/8” 50 50
CBU0805 2” x 1” 2-1/8” x 1-1/8” 50 50
CBU0806 2” x 1-1/4” 2-1/8” x 1-3/8” 50 50
CBU0807 2” x 1-1/2” 2-1/8” x 1-5/8” 50 50
70
Global sourcing. National compliance. Local service.
Fittings & Nipples
Wrot Copper Fittings
Wrot Solder Joint
• NSF 61 Compliant
• IAPMO Approved
• Meets ANSI 16
• Materials Specications
to ASTM B88
• Lead Free
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Tee - Copper x Copper x Copper
CT00 1/8” 1/4” 25 2000
CT01 1/4” 3/8” 25 1300
CT02 3/8” 1/2” 25 600
CT03 1/2” 5/8” 50 500
CT58 5/8” 3/4” 25 200
CT04 3/4” 7/8” 20 160
CT05 1” 1-1/8” 10 60
CT06 1-1/4” 1-3/8” 35 35
CT07 1-1/2” 1-5/8” 20 20
CT08 2” 2-1/8” 10 10
CT10 3” 2-7/8” 10 10
CT11 4” 3-7/8” 5 5
Reducing Tee - Copper x Copper x Copper
CRT0302 1/2” x 3/8” 5/8” x 1/2” 25 400
CRT0304 1/2” x 1/2” x 3/4” 5/8” x 5/8” x 7/8” 10 180
CRT0403 3/4” x 1/2” 7/8” x 5/8” 10 170
CRT040303 3/4” x 1/2” x 1/2” 7/8” x 5/8” x 5/8” 10 180
CRT040304 3/4” x 1/2” x 3/4” 7/8” x 5/8” x 7/8” 10 120
CRT0405 3/4” X 3/4” X 1” 7/8” x 7/8” x 1-1/8” 10 80
CRT0503 1” x 1/2” 1-1/8” x 5/8” 10 100
CRT0504 1” x 3/4” 1-1/8” x 7/8” 10 60
CRT050404 1” x 3/4” x 3/4” 1-1/8” x 7/8” x 7/8” 10 60
CRT0603 1-1/4” x 1/2” 1-3/8” x 5/8” 50 50
CRT0604 1-1/4” x 3/4” 1-3/8” x 7/8” 50 50
CRT0605 1-1/4” x 1” 1-3/8” x 1-1/8” 40 40
CRT0703 1-1/2” x 1/2” 1-5/8” x 5/8” 40 40
CRT0704 1-1/2” x 3/4” 1-5/8” x 7/8” 35 35
CRT0705 1-1/2” x 1” 1-5/8” x 1-1/8” 35 35
CRT0706 1-1/2” x 1-1/4” 1-5/8” x 1-3/8” 25 25
CRT0803 2” x 1/2” 2-1/8” x 5/8” 20 20
CRT0804 2” x 3/4” 2-1/8” x 7/8” 20 20
CRT0805 2” x 1” 2-1/8” x 1-1/8” 18 18
CRT0806 2” x 1-1/4” 2-1/8” x 1-3/8” 15 15
CRT0807 2” x 1-1/2” 2-1/8” x 1-5/8” 10 10
MATCONORCA
MODEL NUMBER
NO M. O.D.
SIZE SIZE
CARTON QUANTITIES
INNER MASTER
Cap
CCA00 1/8” 1/4” 25 3300
CCA02 3/8” 1/2” 25 3300
CCA03 1/2” 5/8” 25 1400
CCA04 3/4” 7/8” 25 500
CCA05 1” 1-1/8” 10 300
CCA06 1-1/4” 1-3/8” 200 200
CCA07 1-1/2” 1-5/8” 140 140
CCA08 2” 2-1/8” 60 60
Union - Copper x Copper
Lead Free Brass Seat
CUN02 3/8” 1/2” 25 500
CUN03 1/2” 5/8” 25 250
CUN58 5/8” 3/4” 25 250
CUN04 3/4” 7/8” 25 100
CUN05 1” 1-1/8” 10 50
CUN06 1-1/4” 1-3/8” 30 30
CUN07 1-1/2” 1-5/8” 25 30
CUN08 2” 2-1/8” 25 25
Tube Strap - Copper x Copper
CSTR03 1/2” 5/8” 25 1000
CSTR04 3/4” 7/8” 25 600
CSTR05 1” 1-1/8” 25 500
Wire Brushes
CFB03 1/2” 24 288
CFB04 3/4” 24 288
CFB05 1” 24 288
CFB06 1-1/4” 24 288
CFB07 1-1/2” 24 288
CFB08 2” 24 288
Wrot Copper
Fittings
Fittings & Nipples
Global sourcing. National compliance. Local service.
71
Flexible Rubber Couplings
No Hub Couplings
• Stainless Steel Bands • UPC Approved
• Durable Rubber for All Schedule • Stocked in Sizes 1-1/4” - 6”
40 Pipe Applications Both Regular & Reducing
Flexible Rubber &
No Hub Couplings
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Flexible Rubber Coupling - Elastomeric PVC
4560606 1-1/4” 1 100
4560706 1-1/2” x 1-1/4” 1 100
4560707 1-1/2” 1 100
4560807 2” x 1-1/2” 1 100
4560808 2” 1 100
4561007 3” x 1-1/2” 1 80
4561008 3” x 2” 1 80
4561010 3” 1 80
4561107 4” x 1-1/2” 1 60
4561108 4” x 2” 1 60
4561110 4” x 3” 1 60
4561111 4” 1 60
4561212 5” 1 30
4561311 6” x 4” 1 20
4561313 6” 1 20
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
No Hub Coupling - Standard Duty
452007 1-1/2” 1 100
452008 2” 1 100
452010 3” 1 100
452011 4” 1 100
452012 5” 1 20
452013 6” 1 25
452014 8” 1 15
452015 10” 1 12
452016 12” 1 10
452087 2” x 1-1/2” 1 100
452108 3” x 2” 1 100
4521108 4” x 2” 1 50
4521110 4” x 3” 1 50
72
Flexible Rubber Trap & Drain Coupling
4560706TD 1-1/2” x 1-1/4” 1 100
4560807TD 2” x 1-1/2” 1 100
Flexible Rubber End Cap - Elastomeric PVC
456007C 1-1/2” 1 100
456008C 2” 1 100
456010C 3” 1 100
456011C 4” 1 100
Global sourcing. National compliance. Local service.
No Hub Coupling - Heavy Duty
452007H 1-1/2” 1 75
452008H 2” 1 75
452010H 3” 1 48
452011H 4” 1 48
452012H 5” 1 15
452013H 6” 1 15
452014H 8” 1 15
452015H 10” 1 10
452016H 12” 1 10
No Hub 60lbs Torque Wrench
452TW 100 100
Fittings & Nipples
Flexible Groove Couplings
• Painted and Galvanized
• Ductile Iron Body ASTM A536
• UL/FM Approved
• EPDM Gaskets
• 300 PSI
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Flexible Groove Coupling - Painted
GCPFP05 1” 50 50
GCPFP06 1-1/4” 40 40
GCPFP07 1-1/2” 40 40
GCPFP08 2” 25 25
GCPFP09 2-1/2” 20 20
GCPFP10 3” 35 35
GCPFP11 4” 25 25
GCPFP13 6” 12 12
GCPFP14 8” 6 6
GCPFP15 10” 2 2
GCPFP16 12” 3 3
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Flexible Groove Coupling - Galvanized
GCPFG05 1” 50 50
GCPFG06 1-1/4” 40 40
GCPFG07 1-1/2” 40 40
GCPFG08 2” 25 25
GCPFG09 2-1/2” 20 20
GCPFG10 3” 35 35
GCPFG11 4” 25 25
GCPFG13 6” 12 12
GCPFG14 8” 6 6
GCPFG15 10” 2 2
GCPFG16 12” 3 3
Flexible Grove
Couplings
Fittings & Nipples
Global sourcing. National compliance. Local service.
73
Lead Free
Dielectric Unions
• Used to Properly Connect
Dissimilar Metal Piping
• P
revents the Deterioration of the Pipe
Connections and Stray Induced Electrical Currents
• Meets ASTM F-492-95
• Temperature Rated 110˚C/230˚F
Dielectric Unions
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Female - FIP X Sweat
Female Iron Pipe x Sweat
DUN-0509LF 1/2” x 1/2” 10 100
DUN-0759LF 3/4” x 3/4” 10 80
DUN-7559LF 3/4” x 1/2” 10 80
DUN-1009LF 1” x 1” 10 50
DUN-1259LF 1-1/4” x 1-1/4” 5 40
DUN-1509LF 1-1/2” x 1-1/2” 4 24
DUN-2009LF 2” x 2” 2 18
Female - FIP X BPT
Female Iron Pipe x Brass Pipe Thread
DUN-EA03LF 1/2” 10 100
DUN-EA04LF 3/4” 10 80
DUN-EA05LF 1” 10 50
DUN-EA06LF 1-1/4” 5 40
DUN-EA07LF 1-1/2” 4 24
DUN-EA08LF 2” 2 18
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Male - MIP X Sweat
Male Iron Pipe x Sweat
DUN-0509MLF 1/2” x 1/2” 10 100
DUN-759MLF 3/4” x 3/4” 10 80
Flanged Unions
IPT x Sweat (Iron Pipe Thread x Sweat)
DUN-0909LF 2-1/2” x 2-1/2” 1 4
DUN-1010LF 3” x 3” 1 4
DUN-1111LF 4” x 4” 1 6
IPT x BPT (Iron Pipe Thread x Brass Pipe Thread)
DUNGA09LF 2-1/2” x 2-1/2” 1 4
DUNGA10LF 3” x 3” 1 4
DUNGA11LF 4” x 4” 1 2
74
Global sourcing. National compliance. Local service.
Fittings & Nipples
Heating Products
NT
ENT
BTP
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Radiator Valve Nut & Tailpiece - Brass
NT-100 1” 10 100
NT-125 1-1/4” 10 100
Union Elbow - With Nut & Tailpiece - Brass
IPS x IPS
ENT-050 1/2” 1 100
ENT-075 3/4” 1 100
ENT-100 1” 10 50
Sweat x Sweat
ENT-050C 1/2” 10 100
ENT-075C 3/4” 10 100
Cast Iron Boiler Tube Plug
BTP-150 1-1/2” 1 60
BTP-200 2” 1 50
BTP-250 2-1/2” 1 30
BTP-300 3” 1 24
Heating Products
Fittings & Nipples
LFP
TBC
Lead “Fit-All” Plug
LFP200 2” 1 1
LFP250 2-1/2” 1 48
LFP300 3” 1 24
LFP350 3-1/2” 1 24
LFP400 4” 1 24
LFP450 4-1/2” 1 12
LFP500 5” 1 12
LFP550 5-1/2” 1 1
LFP600 6” 1 12
Tapped Black Malleable Iron Cap
TBC-0600 1-1/4” x 1/8” 20 160
Global sourcing. National compliance. Local service.
75
Water Service Products
Hydrant Adapters & Tees
MATCONORCA
MODEL NUMBER SIZE
HYDLF
Products
Water Service
Lead Free Brass Fire Hydrant Adapter & Cap
Hydrant Adapters
HYDF-0704GLF
HYDF-0904GLF
HYDF-0904MLF
HYDF-0905MLF
HYDF-0907MLF
HYDF-0908MLF
Double Male Adapters
HYDM-0505MLF
HYDM-0707MLF
HYDM-0908MLF
HYDM-0909HLF
HYDM-0909MLF
HYDM-0910MLF
Swivel Hydrant Adapters
HYDFS-0908MLF
HYDFS-0910MLF
Hydrant Caps
HYDC-07LF
HYDC-09LF
FNST: Female National Standard Thread
MNST: Male National Standard Thread
MIP: Male Iron Pipe Thread
1-1/2” FNST x 3/4” Hose Thread
2-1/2” FNST x 3/4” Hose Thread
2-1/2” FNST x 3/4” MIP
2-1/2” FNST x 1” MIP
2-1/2” FNST x 1-1/2” MIP
2-1/2” FNST x 2” MIP
1” MNST x 1” MIP
1-1/2” MNST x 1-1/2” MIP
2-1/2” MNST x 2” MIP
2-1/2” MNST x 2-1/2” MNST
2-1/2” MNST x 2-1/2” MIP
2-1/2” MNST x 3” MIP
2-1/2” FNST x 2” MIP
2-1/2” FNST x 3” MIP
1-1/2” FNST Cap with Chain
2” FNST Cap with Chain
CARTON QUANTITIES
INNER MASTER
12
5
5
5
5
5
12
12
2
2
2
2
2
2
12
5
72
60
60
60
60
60
120
72
20
20
20
20
20
12
72
60
76
HA
Global sourcing. National compliance. Local service.
Hose Adapter - Brass
HA-0304M 1/2” MIP x 3/4”
Male Garden Hose Thread 20 200
HA-040304 3/4” MIP & 1/2” FIP x 3/4”
Male Garden Hose Thread 50 500
HA-04M04GLF 3/4” MIP x 3/4”
Female Garden Hose Thread 20 200
Fittings & Nipples
Water Service Products
Miscellaneous Plugs
CP-CPC
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Brass Cleanout Plug (Trap Screws) - Southern Code
Raised Square Head
CP-100 1” 100 500
CP-125 1-1/4” 100 500
CP-150 1-1/2” 100 200
CP-200 2” 100 200
CP-250 2-1/2” 50 200
CP-300 3” 20 160
CP-350 3-1/2” 20 120
CP-400 4” 10 80
CP-500 5” 1 60
CP-600 6” 1 40
CP-800 8” 1 20
Countersunk Square Head
CPC-150 1-1/2” 100 400
CPC-200 2” 100 200
CPC-250 2-1/2” 50 200
CPC-300 3” 20 160
CPC-350 3-1/2” 20 120
CPC-400 4” 10 80
CPC-500 5” 10 60
CPC-600 6” 10 40
CPC-800 8” 10 20
Water Service
Products
TP
IBC
Test Plug - Metal - With Rubber Gasket & Wing Nut
TP-07 1-1/2” 6 36
TP-08 2” 6 36
TP-10 3” 6 36
TP-11 4” 1 36
TP-13 6” 1 36
Iron Body Cleanout
Raised Head Square Plug
IBC-43
IBC-435
IBC-65
Countersunk Plug
IBC-43CS
IBC-435CS
IBC-65CS
4” Pipe Size x 3”
4” Pipe Size x 3-1/2”
6” Pipe Size x 5”
4” Pipe Size x 3”
4” Pipe Size x 3-1/2”
6” Pipe Size x 5”
1
1
1
1
1
1
300
600
170
300
300
170
Fittings & Nipples
Global sourcing. National compliance. Local service.
77
Water Service Products
PVC Compression Fittings
MATCONORCA
MODEL NUMBER SIZE
470
460
Products
Water Service
Union - PVC - Schedule 80 - Fits Schedule 40 & 80 Pipe
Solvent Threaded
470S03 470T03 1/2” 12 96
470S04 470T04 3/4” 12 72
470S05 470T05 1” 12 60
470S06 470T06 1-1/4” 6 48
470S07 470T07 1-1/2” 6 36
470S08 470T08 2” 6 24
470S09 470T09 2-1/2” 1 20
470S10 470T10 3” 1 10
470S11 470T11 4” 1 6
Expandable Coupling - PVC - Union Style & Double O-Ring Slider
Size Expands
From To
460T03 1/2” 5-3/4” 8-1/2” 1 28
460T04 3/4” 7-1/2” 9-3/4” 1 24
460T05 1” 8-3/4” 11-1/4” 1 40
460T06 1-1/4” 9” 11-3/4” 1 30
460T07 1-1/2” 10” 13” 1 16
460T08 2” 11-1/4” 14-1/4” 1 12
460T09 2-1/2” 12-1/2” 17” 1 4
460T10 3” 13-1/4” 17-3/4” 1 3
460T11 4” 14-3/4” 19-1/2” 1 2
CARTON QUANTITIES
INNER MASTER
400
Compression Coupling - PVC - Fits Iron Pipe Size
400T03 1/2” 10 200
400T04 3/4” 10 120
400T05 1” 10 120
400T06 1-1/4” 10 80
400T07 1-1/2” 10 60
400T08 2” 5 50
400T09 2-1/2” 3 24
400T10 3” 3 12
400T11 4” 3 6
400T13 6” 1 5
78
Global sourcing. National compliance. Local service.
Fittings & Nipples
Water Service Products
PVC & CPVC Compression Fittings
420
410
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Male x Compression Adapter - PVC
420T03 1/2” 10 200
420T04 3/4” 10 240
420T05 1” 20 120
420T06 1-1/4” 20 80
420T07 1-1/2” 20 80
420T08 2” 20 80
Compression Tee - PVC
410T03 1/2” 24 96
410T04 3/4” 10 80
410T05 1” 20 80
410T06 1-1/4” 12 60
410T07 1-1/2” 12 48
410T08 2” 10 40
Water Service
Products
Fittings & Nipples
401
Compression Coupling - CPVC - Fits Copper Tube Size
401S03 1/2” 20 200
401S04 3/4” 20 240
401S05 1” 10 200
Global sourcing. National compliance. Local service.
79
Water Service Products
CPVC Fittings
CPVCLF
CPVCPXCELF
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Lead Free CPVC x Brass Adapter
Female Adapter
CPVCFA03LF 1/2” CPVC x 1/2” 24 288
CPVCFA04LF 3/4” CPVC x 3/4” 24 288
CPVCFA05LF 1” CPVC x 1” 24 144
CPVCFA06LF 1-1/4” CPVC x 1-1/4” 12 96
CPVCFA07LF 1-1/2” CPVC x 1-1/2” 12 72
CPVCFA08LF 2” CPVC x 2” 12 48
Male Adapter
CPVCMA03LF 1/2” CPVC x 1/2” 24 288
CPVCMA04LF 3/4” CPVC x 3/4” 24 288
CPVCMA05LF 1” CPVC x 1” 24 168
CPVCMA06LF 1-1/4” CPVC x 1-1/4” 12 96
CPVCMA07LF 1-1/2” CPVC x 1-1/2” 12 72
CPVCMA08LF 2” CPVC x 2” 12 48
Lead Free Brass Cold Expansion Pex x CPVC Transition Fitting
CPVCPXCE03LF 1/2” Pex F1960 x CPVC 50 400
CPVCPXCE04LF 3/4” Pex F1960 x CPVC 50 300
CPVCPXCE05LF 1” Pex F1960 x CPVC 25 200
Products
Water Service
CPVCDELF
CPVCSS
CPVCDE
Lead Free CPVC x Brass Drop Ear Elbow
CPVCDE0303LF 1/2” CPVC x 1/2” 24 288
CPVC x Stainless Steel Adapter
Female Adapter
CPVCFA03SS 1/2” CPVC x 1/2” 24 288
CPVCFA04SS 3/4” CPVC x 3/4” 24 288
CPVCFA05SS 1” CPVC x 1” 24 144
CPVCFA06SS 1-1/4” CPVC x 1-1/4” 12 96
CPVCFA07SS 1-1/2” CPVC x 1-1/2” 12 72
CPVCFA08SS 2” CPVC x 2” 12 48
Male Adapter
CPVCMA03SS 1/2” CPVC x 1/2” 24 288
CPVCMA04SS 3/4” CPVC x 3/4” 24 288
CPVCMA05SS 1” CPVC x 1” 24 168
CPVCMA06SS 1-1/4” CPVC x 1-1/4” 12 96
CPVCMA07SS 1-1/2” CPVC x 1-1/2” 12 72
CPVCMA08SS 2” CPVC x 2” 12 48
CPVC x Stainless Steel Drop Ear Elbow
CPVCDE0303SS 1/2” CPVC x 1/2” 20 200
80
Global sourcing. National compliance. Local service.
Fittings & Nipples
Water Service Products
Galvanized & Brass Compression Couplings
440
450L
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Compression Coupling - Long - Galvanized
Fits Iron
Pipe Length
440L03C 1/2” 3-11/16” 12 48
440L04C 3/4” 4-1/8” 12 48
440L05C 1” 4-5/16” 6 24
440L06C 1-1/4” 4-1/2” 6 24
440L07C 1-1/2” 4-3/4” 6 24
440L08C 2” 5-1/16” 6 12
440L09C 2-1/2” 5-3/4” 3 12
440L10C 3” 6-3/4” 2 6
440L11C 4” 8” 2 4
See Our Clampette Catalog for More Compression Fittings
Compression Coupling - Long - Brass - 5” Length
Lead Free Version Available
Fits Iron Fits Copper
Pipe Tubing Size
450L02 3/8” 1/2” 24 120
450L03 1/2” 3/4” 12 120
450L04 3/4” 1” 60
450L05 1” 1-1/4” 12 60
450L06 1-1/4” 1-1/2” 12 48
450L07 1-1/2” - 12 36
450L08 2” - 12 36
450L08C - 2” 12 36
Water Service
Products
450T
450
Compression Coupling - Short - Brass - 3” Length
Lead Free Version Available
Fits Iron Fits Copper
Pipe Tubing Size
450T02 3/8” 1/2” 24 120
450T03 1/2” 3/4” 12 120
450T04 3/4” 1” 12 60
450T05 1” 1-1/4” 12 60
450T06 1-1/4” 1-1/2” 12 48
450T07 1-1/2” - 12 36
450T08 2” - 12 36
Compression Tee - Brass
Fits Iron Fits Copper Side
Pipe Tubing Size Outlet
450-09 1/2” 3/4” 3/4” IPS 12 96
450-10 3/4” 1” 1” IPS 12 48
450-11 1/2” 3/4” 1/2” IPS 12 96
CPVCDE0303LF 1/2” CPVC x 1/2” 24 288
Fittings & Nipples
Global sourcing. National compliance. Local service.
81
Water Service Products
Galvanized & Stainless Steel Insert Fittings
Products
IGMA
IGMAX
MATCONORCA
MODEL NUMBER SIZE
Insert x Male Adapter - Galvanized - For Polyethylene Pipe
IGMA03 1/2” 24 360
IGMA04 3/4” 20 300
IGMA05 1” 16 192
IGMA06 1-1/4” 12 108
IGMA07 1-1/2” 6 90
IGMA08 2” 5 75
IGMA09 2-1/2” 1 15
IGMA10 3” 1 12
IGMA11 4” 1 9
IGMA0605 1-1/4” Insert x 1” Male 10 100
Extra Long Barb Insert x Male Adapter
IGMAX05 1” Extra Long 12 120
IGMAX06 1-1/4” Extra Long 1 1
Venturi Male Adapter - Galvanized - For Polyethylene Pipe
IGMAX056 1” x 6” 12 96
IGMAX058 1” x 8” 1 1
IGMAX068 1-1/4” x 8” 1 1
IGMAX0610 1-1/4” x 10” 1 1
CARTON QUANTITIES
INNER MASTER
Water Service
82
IGCP
ISMA
Global sourcing. National compliance. Local service.
Insert x Insert Coupling - Galvanized
IGCP03 1/2” 30 360
IGCP04 3/4” 20 300
IGCP05 1” 20 240
IGCP06 1-1/4” 16 144
IGCP07 1-1/2” 12 108
IGCP08 2” 5 60
Male Adapter - 304 Stainless Steel - For Polyethylene Pipe
ISMA04 3/4” Insert x Male Adapter 10 200
ISMA05 1” Insert x Male Adapter 10 100
ISMA0605 1-1/4” Male x 1” Insert 5 100
Fittings & Nipples
Water Service Products
Repair Clamps
460
465
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Pipe Repair Clamp - Galvanized - For IPS Size
With Rubber Gasket & Two Bolts
460003 1/2” 10 100
460004 3/4” 10 100
460005 1” 5 50
460006 1-1/4” 5 50
460007 1-1/2” 5 50
400008 2” 5 50
400009 2-1/2” 3 30
460010 3” 3 30
See our Clampette Catalog for clamps made in the USA
Pipe Repair Clamp - Stainless Steel - For IPS Size
3” Clamp With One Bolt
465023 3/8” 6 72
465033 1/2” 6 72
465043 3/4” 6 72
465053 1” 6 72
465063 1-1/4” 6 72
465073 1-1/2” 6 72
465083 2” 6 72
465093 2-1/2” 6 48
465103 3” 6 48
465113 4” 6 24
6” Clamp With Two Bolts
465026 3/8” 6 36
465036 1/2” 6 36
465046 3/4” 6 36
465056 1” 6 36
465066 1-1/4” 6 36
465076 1-1/2” 6 36
465086 2” 6 36
465096 2-1/2” 6 24
465106 3” 6 24
465116 4” 6 24
Water Service
Products
Fittings & Nipples
See our Clampette Catalog for clamps made in the USA
Global sourcing. National compliance. Local service.
83
Water Service Products
Lead Free Brass Insert Fittings
IBMALF
IBMARLF
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Lead Free Insert x Male Adapter - Brass - Standard - For Polyethylene Pipe
IBMA03LF 1/2” 10 200
IBMA04LF 3/4” 10 200
IBMA05LF 1” 1 100
IBMA06LF 1-1/4” 10 100
IBMA07LF 1-1/2” 5 80
IBMA08LF 2” 5 50
IBMA0504LF 1” x 3/4” 10 100
IBMA0506LF 1” x 1-1/4” 10 100
IBMA0604LF 1-1/4” x 3/4” 10 100
IBMA0605LF 1-1/4” x 1” 10 100
Lead Free Rope Adapter - Brass - Insert x Male - With Rope Eye
IBMAR05LF 1” x 1” 10 100
IBMAR06LF 1-1/4” x 1-1/4” 10 100
Products
Water Service
IBFALF
IBCPLF
Lead Free Female Adapter - Brass - Insert x Female
IBFA03LF 1/2” 10 200
IBFA04LF 3/4” 10 100
IBFA05LF 1” 10 100
IBFA06LF 1-1/4” 10 100
IBFA07LF 1-1/2” 5 50
IBFA08LF 2” 5 50
Lead Free Insert x Insert Coupling - Brass - For Polyethylene Pipe
IBCP03LF 1/2” 10 200
IBCP04LF 3/4” 10 200
IBCP05LF 1” 10 100
IBCP06LF 1-1/4” 10 100
IBCP07LF 1-1/2” 5 50
IBCP08LF 2” 5 50
IBCP0504LF 1” x 3/4” 10 100
IBCP0605LF 1-1/4” x 1” 10 100
IBCP0705LF 1-1/2” x 1” 10 100
84
Global sourcing. National compliance. Local service.
Fittings & Nipples
Water Service Products
Lead Free Brass Insert Fittings
IBILLF
IBHLLF
IBITLF
MATCONORCA
MODEL NUMBER SIZE
Lead Free Insert x Insert Elbow - Brass
IBIL04LF
IBIL05LF
IBIL06LF
IBLR0705LF
3/4”
1”
1-1/4”
1-1/2” x 1”
Lead Free Insert x Male Hydrant Adapter Elbow - Brass
IBHL04LF
IBHL05LF
IBHL0504LF
IBHL06LF
3/4”
1”
1” x 3/4”
1-1/4”
Lead Free Insert x Insert Tee - Brass
IBIT04LF
IBIT05LF
IBIT06LF
3/4”
1”
1-1/4”
CARTON QUANTITIES
INNER MASTER
10
10
10
10
10
10
10
10
10
10
5
200
100
50
100
200
100
50
100
Water Service
Products
100
100
50
Fittings & Nipples
IBHTLF
IBHTFLF
Lead Free Insert x Male Hydrant Tee - Brass
IBHT04LF
IBHT05LF
IBHT06LF
IBHT0504LF
IBHT0604LF
3/4”
1”
1-1/4”
1” BARB x 1” BARB x 3/4” MIP Outlet
1-1/4” BARB x 1-1/4” BARB x 3/4” MIP Outlet
Lead Free Insert x Female Hydrant Adapter Tee - Brass
IBHT0504FLF
IBHT0505FLF
1” BARB x 1” BARB x 3/4” FIP Outlet
1” BARB x 1” BARB x 1” FIP Outlet
Global sourcing. National compliance. Local service.
10
10
10
10
10
10
10
100
100
100
100
100
100
100
85
Water Service Products
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
431LF
431DLF
431PLF
Lead Free Meter Flange - Oval - Bronze
IPS SWT
431T07LF 431C07LF 1-1/2” 1 32
431T08LF 431C08LF 2” 6 48
Domestic Lead Free Meter Flange - Oval - Brass
431T07DLF 1-1/2” 10 80
431T08DLF 2” 10 80
Lead Free Meter Flange Kit - Oval - Bronze
Kits Contain Two Flanges, Two Gaskets, Four Nuts and Necessary Bolts
IPS SWT
Four Bolts Four Bolts
431T07PLF 431C07PLF 1-1/2” 1 24
431T08PLF 431C08PLF 2” 1 10
Eight Bolts
431T10PLF - 3” 1 1
Sixteen Bolts
431T11PLF - 4” 1 1
431T13PLF - 6” 1 1
Products
Water Service
431RRPLF
431SPLF
432P
Lead Free Meter Flange Kit - Oval - Bronze - Red Rubber Gaskets
Kits Contain Two Flanges, Two Full Face Red Rubber Gaskets,
Four Nuts (SS304) and Four Bolts
431T07RRPLF 1-1/2” 1 12
431T08RRPLF 2” 1 12
Lead Free Single Meter Flange Kit - Oval - Bronze
Kits Contain One Flange, One Gasket, Two Nuts and Two Bolts
431T07SPLF 1-1/2” 1 12
431T08SPLF 2” 1 10
Meter Flange Kit - Oval - Cast Iron
Kits Contain Two Flanges, Two Gaskets, Four Nuts and Four Bolts
432T07P 1-1/2” 2 24
432T08P 2” 2 24
86
Global sourcing. National compliance. Local service.
Fittings & Nipples
Water Service Products
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
433DLF
433LF
433LLF
Domestic Lead Free Meter Coupling - With Gasket - Brass
433T03DLF 1/2” MIP X 2-1/4” 20 160
433T04DLF 3/4” MIP X 2-1/2” 20 160
433T05DLF 1” MIP X 2-5/8” 10 80
433T07DLF 1-1/2” MIP X 2-7/8” 6 24
433T08DLF 2” MIP X 3” 6 24
Lead Free Meter Coupling - With Gasket - Brass
433T03LF 1/2” 20 160
433T04LF 3/4” 20 100
433T05LF 1” 10 80
433T07LF 1-1/2” 6 24
433T08LF 2” 6 24
433T04MLF 3/4” MIP x 3” L 10 100
433T04XLF 3/4” MIP x 8-1/2” L 10 60
433T05XLF 1” MIP x 8-1/2” L 10 40
Lead Free Meter Elbow - Brass
433L9004LF 3/4” 10 80
Water Service
Products
WSFCPLF
WSFFALF
WSFMALF
Lead Free Flare x Flare Bronze Coupling
WSFCP05LF 1” 6 60
WSFCP06LF 1-1/4” 3 36
WSFCP07LF 1-1/2” 2 24
WSFCP08LF 2” 1 12
Lead Free Flare x Flare Bronze Female Adapter
WSFFA05LF 1” 6 60
WSFFA06LF 1-1/4” 3 36
WSFFA07LF 1-1/2” 2 24
WSFFA08LF 2” 1 12
Lead Free Flare x MIP Bronze Male Adapter
WSFMA04LF 3/4” 1 300
WSFMA05LF 1” 1 60
WSFMA06LF 1-1/4” 1 36
WSFMA07LF 1-1/2” 1 24
WSFMA08LF 2” 1 12
Fittings & Nipples
Global sourcing. National compliance. Local service.
87
Water Service Products
TTLF
DWCLF
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Lead Free Tank Tee - Bronze
With Two 1/2” & Two 1/4” Taps
Length
TT0511LF 1” MIP & 3/4” FIP 11” 2 24
TT0514LF 1” MIP & 3/4” FIP 14” 2 20
Lead Free Drop Well Coupling - Bronze
DWC06LF 1-1/4” 12 72
ISP
Products
Water Service
ISCP
Stainless Steel Stiener - Flanged & Dimpled - Fits IPS Polyethylene Pipe
ISP04
ISP05
ISP06
ISP07
ISP08
3/4”
1”
1-1/4”
1-1/2”
2”
25
25
10
10
10
100
100
Stainless Steel Stiener - Flanged & Dimpled - Fits CTS Polyethylene Pipe
ISCP04
ISCP05
ISCP06
ISCP07
ISCP08
3/4”
1”
1-1/4”
1-1/2”
2”
25
25
10
10
10
100
100
40
40
40
40
40
40
88
Global sourcing. National compliance. Local service.
Fittings & Nipples
Pipe Nipples
Welded Steel - Schedule 40 - Black & Galvanized
Pre-Cut - Welded Steel - Schedule 40
Welded Steel - Schedule 80
Seamless Steel - Schedule 80
PVC - Schedule 80
Brass
304 Stainless Steel - Schedule 40
316 Stainless Steel - Schedule 40
Swage - Schedule 40 & 80
Chrome Plated Brass
Grooved
Dielectric
Pipe Nipples
Fittings & Nipples
Global sourcing. National compliance. Local service.
89
Steel Nipple Part # Breakdown
ZNB036PREFIX
Prex
ZN
Chinese Standar
Chinese P
N
Part Group
B Black
G
Steel Nipple
Part # Breakdown
G
alvanized
Pipe Size
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
re-Cut
1/8
1/4
3/8
1/2
3/4
1
1-1/4
1-1/2
2
2-1/2
3
4
5
6
8
d
Sample Part # is:
ZNB036 - Standard Black, 1/2” x 6”
NB0318 - Pre-Cut Black, 1/2” x 18”
(Z)
Z N B 03 6
N B 03 18
Length Size
Standard Pre-Cut
1-1/2
2
2-1/2
3
3-1/2
4
4-1/2
5
5 1/2
6
6 1/2
7
8
9
10
11
12
18
24
30
48
60
72
90
Global sourcing. National compliance. Local service.
Fittings & Nipples
Nipples - Welded Steel
Schedule 40 - Black
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 8” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Black Steel Nipples - Schedule 40
ZNB00CL 1/8” x Close 25 450
ZNB00112 1/8” x 1-1/2” 25 450
ZNB002 1/8” x 2” 25 450
ZNB00212 1/8” x 2-1/2” 25 450
ZNB003 1/8” x 3” 25 450
ZNB00312 1/8” x 3-1/2” 25 450
ZNB004 1/8” x 4” 25 450
ZNB00412 1/8” x 4-1/2” 25 300
ZNB005 1/8” x 5” 25 300
ZNB00512 1/8” x 5-1/2” 25 300
ZNB006 1/8” x 6” 25 300
ZNB007 1/8” x 7” 25 150
ZNB008 1/8” x 8” 25 150
ZNB009 1/8” x 9” 25 150
ZNB0010 1/8” x 10” 25 150
ZNB0012 1/8” x 12” 25 100
ZNB01CL 1/4” x Close 25 450
ZNB01112 1/4” x 1-1/2” 25 450
ZNB012 1/4” x 2” 25 450
ZNB01212 1/4” x 2-1/2” 25 450
ZNB013 1/4” x 3” 25 450
ZNB01312 1/4” x 3-1/2” 25 450
ZNB014 1/4” x 4” 25 450
ZNB01412 1/4” x 4-1/2” 25 300
ZNB015 1/4” x 5” 25 300
ZNB01512 1/4” x 5-1/2” 25 300
ZNB016 1/4” x 6” 25 300
ZNB01612 1/4” x 6-1/2” 25 150
ZNB017 1/4” x 7” 25 100
ZNB018 1/4” x 8” 25 150
ZNB019 1/4” x 9” 25 100
ZNB0110 1/4” x 10” 25 100
ZNB0111 1/4” x 11” 25 100
ZNB0112 1/4” x 12” 25 100
ZNB02CL 3/8” x Close 25 450
ZNB02112 3/8” x 1-1/2” 25 450
ZNB022 3/8” x 2” 25 450
ZNB02212 3/8” x 2-1/2” 25 450
ZNB023 3/8” x 3” 25 450
ZNB02312 3/8” x 3-1/2” 25 450
ZNB024 3/8” x 4” 25 450
ZNB02412 3/8” x 4-1/2” 25 300
ZNB025 3/8” x 5” 25 300
ZNB02512 3/8” x 5-1/2” 25 300
ZNB026 3/8” x 6” 25 300
ZNB027 3/8” x 7” 25 150
ZNB028 3/8” x 8” 25 150
ZNB02812 3/8” x 8-1/2” 25 150
ZNB029 3/8” x 9” 25 150
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Black Steel Nipples - Schedule 40
ZNB0210 3/8” x 10” 25 100
ZNB0211 3/8” x 11” 25 100
ZNB0212 3/8” x 12” 25 100
ZNB03CL 1/2” x CLOSE 25 450
ZNB03112 1/2” x 1-1/2” 25 450
ZNB032 1/2” x 2” 25 450
ZNB03212 1/2” x 2-1/2” 25 300
ZNB033 1/2” x 3” 25 300
ZNB03312 1/2” x 3-1/2” 25 300
ZNB034 1/2” x 4” 25 300
ZNB03412 1/2” x 4-1/2” 25 200
ZNB035 1/2” x 5” 25 200
ZNB03512 1/2” x 5-1/2” 25 200
ZNB036 1/2” x 6” 25 200
ZNB03612 1/2” x 6-1/2” 25 150
ZNB037 1/2” x 7” 25 150
ZNB038 1/2” x 8” 25 150
ZNB03812 1/2” x 8-1/2” 25 150
ZNB039 1/2” x 9” 25 100
ZNB03912 1/2” x 9-1/2” 25 100
ZNB0310 1/2” x 10” 25 100
ZNB031012 1/2” x 10-1/2” 25 150
ZNB0311 1/2” x 11” 25 100
ZNB031112 1/2” x 11-1/2” 25 200
ZNB0312 1/2” x 12” 25 100
ZNB04CL 3/4” x CLOSE 25 450
ZNB04112 3/4” x 1-1/2” 25 450
ZNB042 3/4” x 2” 25 300
ZNB04212 3/4” x 2-1/2” 25 200
ZNB043 3/4” x 3” 25 200
ZNB04312 3/4” x 3-1/2” 25 200
ZNB044 3/4” x 4” 25 150
ZNB04412 3/4” x 4-1/2” 25 150
ZNB045 3/4” x 5” 25 150
ZNB04512 3/4” x 5-1/2” 25 150
ZNB046 3/4” x 6” 25 150
ZNB04612 3/4” x 6-1/2” 25 100
ZNB047 3/4” x 7” 25 100
ZNB04712 3/4” x 7-1/2” 25 100
ZNB048 3/4” x 8” 25 100
ZNB049 3/4” x 9” 25 100
ZNB0410 3/4” x 10” 25 100
ZNB0411 3/4” x 11” 25 100
ZNB0412 3/4” x 12” 25 100
Schedule 40 Black
Steel Nipples
Fittings & Nipples
Global sourcing. National compliance. Local service.
91
Nipples - Welded Steel
Schedule 40 - Black
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 8” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
Steel Nipples
Schedule 40 Black
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Black Steel Nipples - Schedule 40
ZNB05CL 1” x CLOSE 25 200
ZNB052 1” x 2” 25 200
ZNB05212 1” x 2-1/2” 25 150
ZNB053 1” x 3” 25 150
ZNB05312 1” x 3-1/2” 25 150
ZNB054 1” x 4” 25 100
ZNB05412 1” x 4-1/2” 25 100
ZNB055 1” x 5” 25 100
ZNB05512 1” x 5-1/2” 25 100
ZNB056 1” x 6” 25 100
ZNB05612 1” x 6-1/2” 25 80
ZNB057 1” x 7” 10 60
ZNB05712 1” x 7-1/2” 25 60
ZNB058 1” x 8” 6 60
ZNB05812 1” x 8-1/2” 25 60
ZNB059 1” x 9” 10 40
ZNB05912 1” x 9-1/2” 25 25
ZNB0510 1” x 10” 10 40
ZNB0511 1” x 11” 10 40
ZNB0512 1” x 12” 10 40
ZNB06CL 1-1/4” x Close 5 90
ZNB062 1-1/4” x 2” 5 90
ZNB06212 1-1/4” x 2-1/2” 5 90
ZNB063 1-1/4” x 3” 5 90
ZNB06312 1-1/4” x 3-1/2” 5 90
ZNB064 1-1/4” x 4” 5 90
ZNB06412 1-1/4” x 4-1/2” 5 60
ZNB065 1-1/4” x 5” 5 60
ZNB06512 1-1/4” x 5-1/2” 5 60
ZNB066 1-1/4” x 6” 5 60
ZNB06612 1-1/4” x 6-1/2” 5 30
ZNB067 1-1/4” x 7” 5 30
ZNB068 1-1/4” x 8” 5 30
ZNB069 1-1/4” x 9” 5 20
ZNB0610 1-1/4” x 10” 5 20
ZNB0611 1-1/4” x 11” 5 20
ZNB0612 1-1/4” x 12” 5 20
ZNB07CL 1-1/2” x Close 5 90
ZNB072 1-1/2” x 2” 5 90
ZNB07212 1-1/2” x 2-1/2” 5 60
ZNB073 1-1/2” x 3” 5 60
ZNB07312 1-1/2” x 3-1/2” 5 60
ZNB074 1-1/2” x 4” 5 60
ZNB07412 1-1/2” x 4-1/2” 5 40
ZNB075 1-1/2” x 5” 5 40
ZNB07512 1-1/2” x 5-1/2” 5 40
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Black Steel Nipples - Schedule 40
ZNB076 1-1/2” x 6” 5 40
ZNB077 1-1/2” x 7” 5 30
ZNB078 1-1/2” x 8” 5 30
ZNB079 1-1/2” x 9” 5 20
ZNB0710 1-1/2” x 10” 5 20
ZNB0711 1-1/2” x 11” 5 20
ZNB0712 1-1/2” x 12” 5 20
ZNB08CL 2” x CLOSE 5 60
ZNB08212 2” x 2-1/2” 5 40
ZNB083 2” x 3” 5 40
ZNB08312 2” x 3-1/2” 5 40
ZNB084 2” x 4” 5 40
ZNB08412 2” x 4-1/2” 5 30
ZNB085 2” x 5” 5 30
ZNB08512 2” x 5-1/2” 5 30
ZNB086 2” x 6” 5 30
ZNB08612 2” x 6-1/2” 5 20
ZNB087 2” x 7” 5 20
ZNB088 2” x 8” 5 20
ZNB089 2” x 9” 5 20
ZNB0810 2” x 10” 5 20
ZNB0811 2” x 11” 5 20
ZNB0812 2” x 12” 5 20
ZNB09CL 2-1/2” x Close 1 35
ZNB093 2-1/2” x 3” 1 35
ZNB09312 2-1/2” x 3-1/2” 1 25
ZNB094 2-1/2” x 4” 1 25
ZNB09412 2-1/2” x 4-1/2” 1 25
ZNB095 2-1/2” x 5” 1 20
ZNB09512 2-1/2” x 5-1/2” 1 20
ZNB096 2-1/2” x 6” 1 20
ZNB09612 2-1/2” x 6-1/2” 1 15
ZNB097 2-1/2” x 7” 1 15
ZNB098 2-1/2” x 8” 1 15
ZNB099 2-1/2” x 9” 1 10
ZNB0910 2-1/2” x 10” 1 10
ZNB0911 2-1/2” x 11” 1 10
ZNB0912 2-1/2” x 12” 1 10
ZNB10CL 3” x Close 1 25
ZNB103 3” x 3” 1 25
ZNB10312 3” x 3-1/2” 1 20
ZNB104 3” x 4” 1 20
ZNB10412 3” x 4-1/2” 1 15
ZNB105 3” x 5” 1 15
ZNB10512 3” x 5-1/2” 1 15
ZNB106 3” x 6” 1 15
ZNB107 3” x 7” 1 10
92
Global sourcing. National compliance. Local service.
Fittings & Nipples
Nipples - Welded Steel
Schedule 40 - Black
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 8” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Black Steel Nipples - Schedule 40
ZNB108 3” x 8” 1 10
ZNB109 3” x 9” 1 10
ZNB1010 3” x 10” 1 10
ZNB1011 3” x 11” 1 10
ZNB1012 3” x 12” 1 10
ZNB11CL 4” x CLOSE 1 15
ZNB114 4” x 4” 1 15
ZNB11412 4” x 4-1/2” 1 10
ZNB115 4” x 5” 1 10
ZNB11512 4” x 5-1/2” 1 10
ZNB116 4” x 6” 1 10
ZNB117 4” x 7” 1 5
ZNB118 4” x 8” 1 5
ZNB119 4” x 9” 1 5
ZNB1110 4” x 10” 1 5
ZNB1111 4” x 11” 1 5
ZNB1112 4” x 12” 1 5
ZNB12CL 5” x CLOSE 1 10
ZNB124 5” x 4” 1 6
ZNB125 5” x 5” 1 6
ZNB12512 5” x 5-1/2” 1 6
ZNB126 5” x 6” 1 4
ZNB128 5” x 8” 1 3
ZNB1210 5” x 10” 1 3
ZNB1212 5” x 12” 1 3
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Black Right/Left Nipples - Schedule 40
NRLB034 1/2” x4” 25 300
NRLB044 3/4” x 4” 25 150
NRLB054 1” x 4” 25 150
NRLB064 1-1/4” x 4” 5 90
NRLB074 1-1/2” x 4” 5 90
NRLB084 2” x 4” 5 40
Schedule 40 Black
Steel Nipples
ZNB13CL 6” x CLOSE 1 9
ZNB134 6” x 4” 1 6
ZNB135 6” x 5” 1 4
ZNB136 6” x 6” 1 4
ZNB137 6” x 7” 1 2
ZNB138 6” x 8” 1 2
ZNB139 6” x 9” 1 2
ZNB1310 6” x 10” 1 2
ZNB1312 6” x 12” 1 2
ZNB14CL 8” x CLOSE 1 1
ZNB146 8” x 6” 1 1
ZNB148 8” x 8” 1 1
ZNB1410 8” x 10” 1 1
ZNB1412 8” x 12” 1 1
Fittings & Nipples
Global sourcing. National compliance. Local service.
93
Nipples - Welded Steel
Schedule 40 - Galvanized
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 8” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
Steel Nipples
Schedule 40 Galvanized
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Nipples - Schedule 40
ZNG00CL 1/8” x Close 25 450
ZNG00112 1/8” x 1-1/2” 25 450
ZNG002 1/8” x 2” 25 450
ZNG00212 1/8” x 2-1/2” 25 450
ZNG003 1/8” x 3” 25 450
ZNG00312 1/8” x 3-1/2” 25 450
ZNG004 1/8” x 4” 25 450
ZNG00412 1/8” x 4-1/2” 25 150
ZNG005 1/8” x 5” 25 300
ZNG00512 1/8” x 5-1/2” 25 300
ZNG006 1/8” x 6” 25 300
ZNG007 1/8” x 7” 25 150
ZNG008 1/8” x 8” 25 150
ZNG009 1/8” x 9” 25 150
ZNG0010 1/8” x 10” 25 200
ZNG0011 1/8” x 11” 25 150
ZNG0012 1/8” x 12” 25 100
ZNG01CL 1/4” x Close 25 450
ZNG01112 1/4” x 1-1/2” 25 450
ZNG011 1/4” x 1” 25 450
ZNG012 1/4” x 2” 25 450
ZNG01212 1/4” x 2-1/2” 25 450
ZNG013 1/4” x 3” 25 450
ZNG01312 1/4” x 3-1/2” 25 450
ZNG014 1/4” x 4” 25 450
ZNG01412 1/4” x 4-1/2” 25 300
ZNG015 1/4” x 5” 25 300
ZNG01512 1/4” x 5-1/2” 25 300
ZNG016 1/4” x 6” 25 300
ZNG017 1/4” x 7” 25 150
ZNG018 1/4” x 8” 25 150
ZNG019 1/4” x 9” 25 100
ZNG0110 1/4” x 10” 25 100
ZNG0111 1/4” x 11” 25 100
ZNG0112 1/4” x 12” 25 100
ZNG02CL 3/8” x Close 25 450
ZNG02112 3/8” x 1-1/2” 25 450
ZNG022 3/8” x 2” 25 450
ZNG02212 3/8” x 2-1/2” 25 450
ZNG023 3/8” x 3” 25 450
ZNG02312 3/8” x 3-1/2” 25 450
ZNG024 3/8” x 4” 25 450
ZNG02412 3/8” x 4-1/2” 25 300
ZNG025 3/8” x 5” 25 300
ZNG02512 3/8” x 5-1/2” 25 100
ZNG026 3/8” x 6” 25 300
ZNG027 3/8” x 7” 25 150
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Nipples - Schedule 40
ZNG028 3/8” x 8” 25 150
ZNG029 3/8” x 9” 25 100
ZNG0210 3/8” x 10” 25 100
ZNG0211 3/8” x 11” 25 100
ZNG0212 3/8” x 12 25 100
ZNG03CL 1/2” x Close 25 450
ZNG03112 1/2” x 1-1/2” 25 450
ZNG032 1/2” x 2” 25 450
ZNG03212 1/2” x 2-1/2” 25 300
ZNG033 1/2” x 3” 25 300
ZNG03312 1/2” x 3-1/2” 25 300
ZNG034 1/2” x 4” 25 300
ZNG03412 1/2” x 4-1/2” 25 200
ZNG035 1/2” x 5” 25 200
ZNG03512 1/2” x 5-1/2” 25 200
ZNG036 1/2” x 6” 25 200
ZNG03612 1/2” x 6-1/2” 25 200
ZNG037 1/2” x 7” 25 150
ZNG03712 1/2” x 7-1/2” 25 150
ZNG038 1/2” x 8” 25 150
ZNG03812 1/2” x 8-1/2” 25 100
ZNG039 1/2” x 9” 25 100
ZNG0310 1/2” x 10” 25 100
ZNG0311 1/2” x 11” 25 100
ZNG031112 1/2” x 11-1/2” 25 200
ZNG0312 1/2” x 12” 25 100
ZNG04CL 3/4” x Close 25 450
ZNG04112 3/4” x 1-1/2” 25 450
ZNG042 3/4” x 2” 25 300
ZNG04212 3/4” x 2-1/2” 25 200
ZNG043 3/4” x 3” 25 200
ZNG04312 3/4” x 3-1/2” 25 200
ZNG044 3/4” x 4” 25 150
ZNG04412 3/4” x 4-1/2” 25 150
ZNG045 3/4” x 5” 25 150
ZNG04512 3/4” x 5-1/2” 25 150
ZNG046 3/4” x 6” 25 150
ZNG04612 3/4” x 6-1/2” 25 100
ZNG047 3/4” x 7” 25 100
ZNG04712 3/4” x 7-1/2” 25 100
ZNG048 3/4” x 8” 25 100
ZNG04812 3/4” x 8-1/2” 25 100
ZNG049 3/4” x 9” 25 100
ZNG0410 3/4” x 10” 25 100
ZNG041012 3/4” x 10-1/2” 25 100
ZNG0411 3/4” x 11” 25 100
ZNG0412 3/4” x 12” 25 100
94
Global sourcing. National compliance. Local service.
Fittings & Nipples
Nipples - Welded Steel
Schedule 40 - Galvanized
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 6” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Nipples - Schedule 40
ZNG05CL 1” x CLOSE 25 200
ZNG052 1” x 2” 25 200
ZNG05212 1” x 2-1/2” 25 150
ZNG053 1” x 3” 25 150
ZNG05312 1” x 3-1/2” 25 150
ZNG054 1” x 4” 25 100
ZNG05412 1” x 4-1/2” 25 100
ZNG055 1” x 5” 25 100
ZNG05512 1” x 5-1/2” 25 100
ZNG056 1” x 6” 25 100
ZNG057 1” x 7” 10 60
ZNG058 1” x 8” 10 60
ZNG059 1” x 9” 10 40
ZNG0510 1” x 10” 10 40
ZNG0511 1” x 11” 10 40
ZNG0512 1” x 12” 10 40
ZNG06CL 1-1/4” x CLOSE 5 90
ZNG062 1-1/4” x 2” 5 90
ZNG06212 1-1/4” x 2-1/2” 5 90
ZNG063 1-1/4” x 3” 5 90
ZNG06312 1-1/4” x 3-1/2” 5 90
ZNG064 1-1/4” x 4” 5 90
ZNG06412 1-1/4” x 4-1/2” 5 60
ZNG065 1-1/4” x 5” 5 60
ZNG06512 1-1/4” x 5-1/2” 5 60
ZNG066 1-1/4” x 6” 5 60
ZNG067 1-1/4” x 7” 5 30
ZNG068 1-1/4” x 8” 5 30
ZNG069 1-1/4” x 9” 5 20
ZNG0610 1-1/4” x 10” 5 20
ZNG0611 1-1/4” x 11” 5 20
ZNG0612 1-1/4” x 12” 5 20
ZNG07CL 1-1/2” x CLOSE 5 90
ZNG072 1-1/2” x 2” 5 90
ZNG07212 1-1/2” x 2-1/2” 5 60
ZNG073 1-1/2” x 3” 5 60
ZNG07312 1-1/2” x 3-1/2” 5 60
ZNG074 1-1/2” x 4” 5 60
ZNG07412 1-1/2” x 4-1/2” 5 40
ZNG075 1-1/2” x 5” 5 40
ZNG07512 1-1/2” x 5-1/2” 5 40
ZNG076 1-1/2” x 6” 5 40
ZNG07612 1-1/2” x 6-1/2” 5 30
ZNG077 1-1/2” x 7” 5 30
ZNG078 1-1/2” x 8” 5 30
ZNG079 1-1/2” x 9” 5 20
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Nipples - Schedule 40
ZNG0710 1-1/2” x 10” 5 20
ZNG0711 1-1/2” x 11” 5 20
ZNG0712 1-1/2” x 12” 5 20
ZNG08CL 2” x CLOSE 5 60
ZNG08212 2” x 2-1/2” 5 40
ZNG083 2” x 3” 5 40
ZNG08312 2” x 3-1/2” 5 40
ZNG084 2” x 4” 5 40
ZNG08412 2” x 4-1/2” 5 30
ZNG085 2” x 5” 5 30
ZNG08512 2” x 5-1/2” 5 30
ZNG086 2” x 6” 5 30
ZNG08612 2” x 6-1/2” 5 20
ZNG087 2” x 7” 5 20
ZNG088 2” x 8” 5 20
ZNG089 2” x 9” 5 20
ZNG0810 2” x 10” 5 20
ZNG0811 2” x 11” 5 20
ZNG0812 2” x 12” 5 20
ZNG09CL 2-1/2” x CLOSE 1 35
ZNG093 2-1/2” x 3” 1 35
ZNG09312 2-1/2” x 3-1/2” 1 25
ZNG094 2-1/2” x 4” 1 25
ZNG09412 2-1/2” x 4-1/2” 1 25
ZNG95 2-1/2” x 5” 1 20
ZNG09512 2-1/2” x 5-1/2” 1 20
ZNG096 2-1/2” x 6” 1 20
ZNG097 2-1/2” x 7” 1 15
ZNG098 2-1/2” x 8” 1 15
ZNG099 2-1/2” x 9” 1 10
ZNG0910 2-1/2” x 10” 1 10
ZNG0911 2-1/2” x 11” 1 10
ZNG0912 2-1/2” x 12” 1 10
ZNG10CL 3” x CLOSE 1 25
ZNG103 3” x 3” 1 25
ZNG10312 3” x 3-1/2” 1 20
ZNG104 3” x 4” 1 20
ZNG10412 3” x 4-1/2” 1 15
ZNG105 3” x 5” 1 15
ZNG10512 3” x 5-1/2” 1 15
ZNG106 3” x 6” 1 15
ZNG107 3” x 7” 1 10
ZNG108 3” x 8” 1 10
ZNG109 3” x 9” 1 10
ZNG1010 3” x 10” 1 10
ZNG1011 3” x 11” 1 10
ZNG1012 3” x 12” 1 10
Schedule 40 Galvanized
Steel Nipples
Fittings & Nipples
Global sourcing. National compliance. Local service.
95
Nipples - Welded Steel
Schedule 40 - Galvanized
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 8” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
Steel Nipples
Schedule 40 Galvanized
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Steel Nipples - Schedule 40
ZNG11CL 4” x Close 1 15
ZNG114 4” x 4” 1 15
ZNG11412 4” x 4-1/2” 1 10
ZNG115 4” x 5” 1 10
ZNG11512 4” x 5-1/2” 1 10
ZNG116 4” x 6” 1 10
ZNG117 4” x 7” 1 5
ZNG118 4” x 8” 1 5
ZNG119 4” x 9” 1 5
ZNG1110 4” x 10” 1 5
ZNG1111 4” x 11” 1 5
ZNG1112 4” x 12” 1 5
ZNG12CL 5” x Close 1 10
ZNG124 5” x 4” 1 6
ZNG126 5” x 6” 1 4
ZNG128 5” x 8” 1 3
ZNG1212 5” x 12” 1 3
ZNG13CL 6” x Close 1 9
ZNG134 6” x 4” 1 6
ZNG136 6” x 6” 1 4
ZNG137 6” x 7” 1 2
ZNG138 6” x 8” 1 2
ZNG139 6” x 9” 1 2
ZNG1310 6” x 10” 1 2
ZNG1312 6” x 12” 1 2
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Right/Left Nipples - Schedule 40
NRLG034 1/2” x 4” 25 300
NRLG044 3/4” x 4” 25 150
NRLG054 1” x 4” 25 150
NRLG064 1-1/4” x 4” 5 90
NRLG074 1-1/2” x 4” 5 90
NRLG084 2” x 4” 5 40
96
Global sourcing. National compliance. Local service.
Fittings & Nipples
Pre-Cut Pipe - Welded Steel
Schedule 40 - Black
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 6” Diameter
•
Specialty Items Such as
Toe Nipples are Available
• ISO 9001: 2000
• Available in Long Lengths up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Black Pre-Cut Pipe - Schedule 40
NB0114 1/4” x 14” 1 25
NB0124 1/4” x 24” 1 5
NB0136 1/4” x 36” 1 5
NB0148 1/4” x 48” 1 5
NB0218 3/8” x 18” 1 5
NB0224 3/8” x 24” 1 5
NB0230 3/8” x 30” 1 5
NB0236 3/8” x 36” 1 5
NB0248 3/8” x 48” 1 5
NB02120 3/8” x 120” 1 5
NB0313 1/2” x 13” 1 5
NB0314 1/2” x 14” 1 5
NB0315 1/2” x 15” 1 5
NB0316 1/2” x 16” 1 5
NB0318 1/2” x 18” 1 5
NB0320 1/2” x 20” 1 5
NB0321 1/2” x 21” 1 5
NB0322 1/2” x 22” 1 5
NB0324 1/2” x 24” 1 5
NB0327 1/2” x 27” 1 5
NB0330 1/2” x 30” 1 5
NB0336 1/2” x 36” 1 5
NB0342 1/2” x 42” 1 5
NB0348 1/2” x 48” 1 5
NB0360 1/2” x 60” 1 5
NB0372 1/2” x 72” 1 5
NB0414 3/4” x 14” 1 1
NB0415 3/4” x 15” 1 5
NB0416 3/4” x 16” 1 1
NB0418 3/4” x 18” 1 5
NB0422 3/4” x 22” 1 5
NB0424 3/4” x 24” 1 5
NB0426 3/4” x 26” 1 5
NB0430 3/4” x 30” 1 5
NB0436 3/4” x 36” 1 5
NB0442 3/4” x 42” 1 5
NB0448 3/4” x 48” 1 5
NB0454 3/4” x 54” 1 5
NB0460 3/4” x 60” 1 5
NB0472 3/4” x 72” 1 5
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Black Pre-Cut Pipe - Schedule 40
NB0513 1” x 13” 1 3
NB0514 1” x 14” 1 3
NB0515 1” x 15” 1 3
NB0516 1” x 16” 1 3
NB0518 1” x 18” 1 3
NB0520 1” x 20” 1 3
NB0524 1” x 24” 1 3
NB0530 1” x 30” 1 3
NB0536 1” x 36” 1 3
NB0542 1” x 42” 1 3
NB0548 1” x 48” 1 3
NB0554 1” x 54” 1 3
NB0560 1” x 60” 1 3
NB0572 1” x 72” 1 3
NB0613 1-1/4” x 13” 1 5
NB0614 1-1/4” x 14” 1 3
NB0616 1-1/4” x 16” 1 3
NB0618 1-1/4” x 18” 1 3
NB0624 1-1/4” x 24” 1 3
NB0630 1-1/4” x 30” 1 3
NB0636 1-1/4” x 36” 1 3
NB0642 1-1/4” x 42” 1 3
NB0648 1-1/4” x 48” 1 3
NB0660 1-1/4” x 60” 1 3
NB0672 1-1/4” x 72” 1 3
NB0716 1-1/2” x 16” 1 3
NB0718 1-1/2” x 18” 1 3
NB0724 1-1/2” x 24” 1 3
NB0730 1-1/2” x 30” 1 3
NB0736 1-1/2” x 36” 1 3
NB0742 1-1/2” x 42” 1 3
NB0748 1-1/2” x 48” 1 3
NB0760 1-1/2” x 60” 1 3
NB0772 1-1/2” x 72” 1 3
NB0814 2” x 14” 1 3
NB0815 2” x 15” 1 3
NB0816 2” x 16” 1 3
NB0818 2” x 18” 1 3
NB0824 2” x 24” 1 3
NB0828 2” x 28” 1 3
NB0830 2” x 30” 1 3
NB0836 2” x 36” 1 3
NB0842 2” x 42” 1 3
Schedule 40 Galvanized
Pre-Cut Pipe
Fittings & Nipples
Global sourcing. National compliance. Local service.
97
Pre-Cut Pipe - Welded Steel
Schedule 40 - Black
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 6” Diameter
• ISO 9001: 2000
•
Specialty Items Such as
Toe Nipples are Available
• Available in Long Lengths
up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Black Pre-Cut Pipe - Schedule 40
NB0848 2” x 48” 1 3
NB0860 2” x 60” 1 3
NB0872 2” x 72” 1 3
NB0918 2-1/2” x 18” 1 3
NB0924 2-1/2” x 24” 1 3
NB0936 2-1/2” x 36” 1 3
NB1018 3” x 18” 1 3
NB1024 3” x 24” 1 3
NB1030 3” x 30” 1 3
NB1040 3” X 40” 1 2
NB1036 3” x 36” 1 3
NB1048 3” x 48” 1 3
NB1118 4” x 18” 1 2
NB1124 4” x 24” 1 2
NB1130 4” x 30” 1 2
NB1136 4” x 36” 1 2
NB1148 4” x 48” 1 2
Nipple Rack - RACK1 / RACK3
Pre-Cut Pipe
Schedule 40 Black
98
Global sourcing. National compliance. Local service.
Fittings & Nipples
Pre-Cut Pipe - Welded Steel
Schedule 40 - Galvanized
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 6” Diameter
• ISO 9001: 2000
•
Specialty Items Such as
Toe Nipples are Available
• Available in Long Lengths
up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER
CARTON QUANTITIES
INNER MASTER
Galvanized Pre-Cut Pipe - Schedule 40
NG0114 1/4” x 14” 1 5
NG0116 1/4” x 16” 1 5
NG0118 1/4” x 18” 1 5
NG0120 1/4” x 20” 1 5
NG0124 1/4” x 24” 1 5
NG0136 1/4” x 36” 1 5
NG0148 1/4” x 48” 1 5
NG0160 1/4” x 60” 1 5
NG0172 1/4” x 72” 1 5
NG0218 3/8” x 18” 1 5
NG0224 3/8” x 24” 1 5
NG0230 3/8” x 30” 1 5
NG0236 3/8” x 36” 1 5
NG0242 3/8” x 42” 1 5
NG0248 3/8” x 48” 1 5
NG0254 3/8” x 54” 1 5
NG0260 3/8” x 60” 1 5
NG0266 3/8” x 66” 1 5
NG0272 3/8” x 72” 1 5
NG0314 1/2” x 14” 1 5
NG0316 1/2” x 16” 1 5
NG0318 1/2” x 18” 1 5
NG0324 1/2” x 24” 1 5
NG0326 1/2” x 26” 1 5
NG0330 1/2” x 30” 1 5
NG0336 1/2” x 36” 1 5
NG0342 1/2” x 42” 1 5
NG0348 1/2” x 48” 1 5
NG0353 1/2” x 53” 1 5
NG0354 1/2” x 54” 1 5
NG0360 1/2” x 60” 1 5
NG0366 1/2” x 66” 1 5
NG0372 1/2” x 72” 1 5
NG0414 3/4” x 14” 1 5
NG0415 3/4” x 15” 1 5
NG0416 3/4” x 16” 1 5
NG0418 3/4” x 18” 1 5
NG0424 3/4” x 24” 1 5
NG0430 3/4” x 30” 1 5
NG0436 3/4” x 36” 1 5
NG0440 3/4” x 40” 1 5
NG0442 3/4” x 42” 1 5
NG0448 3/4” x 48” 1 5
NG0454 3/4” x 54” 1 5
NG0460 3/4” x 60” 1 5
NG0472 3/4” x 72” 1 5
MATCONORCA
MODEL NUMBERSIZE SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Pre-Cut Pipe - Schedule 40
NG0514 1” x 14” 1 3
NG0515 1” x 15” 1 3
NG0516 1” x 16” 1 3
NG0518 1” x 18” 1 3
NG0520 1” x 20” 1 3
NG0524 1” x 24” 1 3
NG0530 1” x 30” 1 3
NG0536 1” x 36” 1 3
NG0542 1” x 42” 1 3
NG0548 1” x 48” 1 3
NG0554 1” x 54” 1 3
NG0560 1” x 60” 1 3
NG0572 1” x 72” 1 3
NG0614 1-1/4” x 14” 1 3
NG0615 1-1/4” x 15” 1 3
NG0618 1-1/4” x 18” 1 3
NG0624 1-1/4” x 24” 1 3
NG0630 1-1/4” x 30” 1 3
NG0636 1-1/4” x 36” 1 3
NG0648 1-1/4” x 48” 1 3
NG0660 1-1/4” x 60” 1 3
NG0672 1-1/4” x 72” 1 3
NG0714 1-1/2” x 14” 1 3
NG0718 1-1/2” x 18” 1 3
NG0724 1-1/2” x 24” 1 3
NG0730 1-1/2” x 30” 1 3
NG0736 1-1/2” x 36” 1 3
NG0742 1-1/2” x 42” 1 3
NG0748 1-1/2” x 48” 1 3
NG0760 1-1/2” x 60” 1 3
NG0772 1-1/2” x 72” 1 3
NG0818 2” x 18” 1 3
NG0824 2” x 24” 1 3
NG0830 2” x 30” 1 3
NG0836 2” x 36” 1 3
NG0842 2” x 42” 1 3
NG0848 2” x 48” 1 3
NG0860 2” x 60” 1 3
NG0872 2” x 72” 1 3
Schedule 40 Galvanized
Pre-Cut Pipe
Fittings & Nipples
Global sourcing. National compliance. Local service.
99
Pre-Cut Pipe - Welded Steel
Schedule 40 - Galvanized
• Meets or Exceeds All Applicable
ASTM & ANSI Standards
• Stocked 1/8” - 6” Diameter
• ISO 9001: 2000
•
Specialty Items Such as
Toe Nipples are Available
• Available in Long Lengths
up to 10 Ft.
• Various Assortments in Stock
• Lead Free
MATCONORCA
MODEL NUMBER SIZE
CARTON QUANTITIES
INNER MASTER
Galvanized Pre-Cut Pipe - Schedule 40
NG0918 2-1/2” x 18” 1 3
NG0924 2-1/2” x 24” 1 3
NG0930 2-1/2” x 30” 1 3
NG0936 2-1/2” x 36” 1 3
NG0948 2-1/2” x 48” 1 3
NG0972 2-1/2” x 72” 1 3
NG1018 3” x 18” 1 3
NG1024 3” x 24” 1 3
NG1030 3” x 30” 1 3
NG1036 3” x 36” 1 3
NG1048 3” x 48” 1 3
NG1060 3” x 60” 1 3
NG1072 3” x 72” 1 3
NG1114 4” x 14” 1 2
NG1118 4” x 18” 1 2
NG1124 4” x 24” 1 2
NG1130 4” x 30” 1 2
NG1136 4” x 36” 1 2
NG1148 4” x 48” 1 2
NG1160 4” x 60” 1 2
NG1172 4” x 72” 1 2
Nipple Rack - RACK1 / RACK3
Pre-Cut Pipe
NG1318 6” x 18” 1 2
NG1324 6” x 24” 1 2
Schedule 40 Galvanized
100
Global sourcing. National compliance. Local service.
Fittings & Nipples
Loading...
