OPERATING INSTRUCTIONS

To Lock:

1. Press Cable Trigger Button (A) and extend cable to
desired length.

2. Insert Cable Head (B) into Locking Port (D) until it locks
into place. Then scramble the combination dials (C).

3. Press the Cable Trigger Button (A) to reduce slack and
tighten cable.

To Un-lock:

1. Turn Dials (C) to the opening combination.

2. Press the Release Button (E) to release Cable Head (B)
from the Locking Port (D).

3. Hold down the Cable Trigger Button (A) to retract cable.
Caution: The cable return mechanism is spring loaded.
Please keep hands and face out of rebound path.

To set your own combination:

1. The combination is pre-set at the factory to 0-0-0.

2. While holding down the Cable Trigger Button (A),
push down the Cable Head (B) until you hear a “click”.

3. Rotate dials (C) to your desired combination.

4. Pull out Cable Head (B) while holding down the Cable
Trigger Button (A). Your personal combination is now set.
Note: Cable should be fully retracted for Step 1.
