Masterflex 77495-00, 77496-00, 77496-20 Instruction Manual
WARRANTY
Use only MASTERFLEX precision tubing with MASTERFLEX pumps to ensure optimum performance. Use of other tubing may void applicable warranties.
The Manufacturer warrants this product to be free from significant deviations from published specifications. If repair or adjustment is necessary within the warranty period, the problem will be corrected at no charge if it is not due to misuse or abuse on your part as determined by the Manufacturer. Repair costs outside the warranty period, or those resulting from product misuse or abuse, may be invoiced to you.
The warranty period for this product is noted on the Warranty Card.
PRODUCT RETURN
To limit charges and delays, contact the seller or Manufacturer for authorization and shipping instructions before returning the product, either within or outside of the warranty period. When returning the product, please state the reason for the return. For your protection, pack the product carefully and insure it against possible damage or loss. Any damages resulting from improper packaging are your responsibility.
TECHNICAL ASSISTANCE
If you have any questions about the use of this product, contact the Manufacturer or authorized seller.
Cole-Parmer Instrument Co. |
|
|
625 East Bunker Court |
|
|
Vernon Hills, Illinois U.S.A. 60061-1844 |
|
|
1-800-MASTERFLEX (627-8373) (U.S. and Canada only) |
|
|
11(847) 549-7600 (outside U.S.) |
|
|
(847) 549-7600 (Local) |
|
|
FAX (847) 247-2929 (U.S. and Canada only) |
|
|
11(847) 549-1700 (Fax outside U.S.) |
|
|
www.masterflex.com |
|
|
e-mail:techinfo@coleparmer.com |
|
|
SUPPLIER CERTIFIED |
|
|
Barnant Company |
|
|
28W092 Commercial Ave. |
|
|
Barrington, Illinois U.S.A. 60010-2392 |
|
|
1-800-637-3739 (U.S. and Canada only) |
|
|
11(847) 381-7050 (outside U.S.) |
|
|
(847) 381-7050 (Local) |
|
|
11(847) 381-7053 (Fax outside U.S.) |
|
|
(847) 381-7053 (Local Fax) |
|
|
www.barnant.com |
Printed in U.S.A. |
|
e-mail:barnant@barnant.com |
||
041201 |
OPERATING MANUAL
® |
® |
NEMA AND IEC MOTOR-TO-PUMP
ADAPTERS
NEMA |
IEC |
|
Model No. |
Model No. |
Gear Ratio |
77495-00 |
77496-00 |
3.7:1 |
77495-20 |
77496-20 |
18.3:1 |
|
|
|
Cole-Parmer Instrument Co.
1-800-MASTERFLEX (627-8373) (U.S. and Canada only) 11 (847) 549-7600 (outside U.S.)
(847) 549-7600 (Local) www.masterflex.com
Barnant Company
1-800-637-3739 (U.S. and Canada only) 11 (847) 381-7050 (outside U.S.)
(847) 381-7050 (Local) www.barnant.com
A-1299-0412
Edition 04
SUPPLIER CERTIFIED
WARNING: PRODUCT USE LIMITATION
This product is not designed for, nor intended for use in, patient connected applications; including, but not limited to, medical and dental use and, accordingly, has not been submitted for FDA approval.
DESCRIPTION
Series 77495 and 77496 MOTOR-TO-PUMP ADAPTERS enable compatible NEMA 56C and IEC motors to drive MASTERFLEX® L/S® Pump Heads. All kinds of liquids can be delivered at desired flow rates. Each assembly is composed of a planetary gear system in a rugged aluminum housing with a mounting gasket, plus a motor shaft adapter.
Two Adapter models for NEMA motors and two for IEC motors, each with different gear ratios, are available to obtain desired flow rates, depending upon motor speed, pump head type, tubing size and material, plus backpressure conditions.
The Adapters are compatible with all MASTERFLEX® L/S® Pump Heads.
C-FLEX - Reg TM Consolidated Polymer Technologies, Inc.
NORPRENE, PHARMED, TYGON - Reg TM Norton Co.
VITON - Reg TM E.I. DuPont Dow Elastomers, L.L.C.
Trademarks bearing the ® symbol in this publication are registered in the U.S. and other countries.
SPECIFICATIONS
NEMA |
IEC |
Gear Ratio |
Input Speed |
Output Speed |
|
Model |
Model |
||||
(max) |
(max) |
||||
No. |
No. |
|
|||
|
|
|
|||
77495-00 |
77496-00 |
3.7:1 |
2200 rpm |
600 |
|
|
|
|
|
|
|
77495-20 |
77496-20 |
18.3:1 |
3600 rpm |
200 |
|
|
|
|
|
|
Drive Mounting: NEMA 56C (77495)
IEC 72 Series 63, IMB5 (77496)
Pump Mounting: MASTERFLEX® L/S®
Operating Temperature: 32°F (0°C) to 122°F (50°C)
Storage Temperature Range: 14°F (-10°C) to 149°F (65°C)
Weight: 2 lbs (.9 kg)
Dust/Water Resistance: NEMA 4 or IP56 with pump and motor mounted
Torque Output: 170 oz-in (12 kg-cm) (3.7:1 Gear Ratio) 210 oz-in (15 kg-cm) (18.3:1 Gear Ratio)
Dimensions: 5 3/4 in x 6 1/2 in x 6 1/2 in
L x W x H (146 x 165 x 165 mm)
Humidity: 0-95%
Altitude: Less than 2000 meters
