Masterflex 75211-70 Instruction Manual

OPERATING MANUAL:

DIGITAL GEAR PUMP
DRIVE

Digital Gear Pump Drive 75211-70

Model Nos.

75211-70

®

A12991142

Edition 02

(US & Canada only) Toll Free 1800MASTERFLEX • 18006373739
(Outside US & Canada) 18475497600 • 18473817050
www.masterflex.com • [e-mail]

®

A-1299-1142

1 19400 2014-04-15 First Edition BK

REV ECR/ECN DATE DESCRIPTION By

© 2019 Cole-Parmer Instrument Company. All rights reserved.

Masterflex – Reg TM Cole-Parmer Instrument Company.

Trademarks bearing the ®symbol in this publication are registered in the U.S. and in other countries.

PUMP FOR LIQUIDS

ORIGINAL INSTRUCTIONS

Masterflexii Digital Gear Pump Drive Operating Manual

Masterflex Digital Gear Pump Drive Operating Manual iii

DANGER: High voltages exist and are accessible. Use extreme caution
when servicing internal components.

WARNINGS: Do not operate the Pump Drive in a manner not
specified in the documentation. Misuse of the Pump Drive may result in
a hazard and may compromise the safety protection built into the Pump
Drive. If the Pump Drive is damaged, turn it off and not use it until serv­ice-trained personnel can check its safety.

Single-Phase Only. Not to be used with Split-Phase lines.

The Power switch on the Back Panel is not the main disconnect. Main
disconnect is accomplished by disconnecting the detachable power
supply cord at the appliance coupler or at the main plug. Ensure the
power cord is easily accessible and removable, in the event of an emer­gency, which requires immediate disconnection.

The operator should check the detachable power supply cord condi­tion. The equipment should not be operated if the power supply cord is
cracked or broken. Any obvious damage to the enclosure (from a drop
or fall) should be checked by service personnel for loose or damaged
parts inside.

CAUTIONS: Power must be turned off before connecting the external
remote control cable to prevent damage to the drive.

Do not block the rear panel of the Pump Drive. The power switch must
always be easy to access. The power cord must always be easy to dis­connect.

Replace the power cord only with one of the same type and
rating. The minimum power ratings are stated on the rear panel.

The power cord set supplied with your Pump Drive meets the require­ments of the country where you purchased the Pump Drive. If you use
the Pump Drive in another country, you must use a power cord set that
meets the requirements of that country.

When using hazardous chemical and biological agents, take all suit­able protective measures, such as wearing protective glasses and
gloves resistant to the substances used. Follow local and/or national
regulations for safe operation and maintenance of the system.

CAUTION: To avoid electrical shock, the power cord protective
grounding conductor must be connected to ground. Not for
operation in wet locations as defined by EN61010-1.

CAUTIONS: Keep fingers away from magnetic coupling while pump
is in operation.

To reduce the possibility of tipping, use the stacking clip
provided with the unit.

Preface

Safety Precautions

SAFETY

PRECAUTIONS

iv Digital Gear Pump Drive Operating Manual

CAUTION: Risk of Danger. Consult Operator’s manual for nature of haz­ard and corrective actions.

CAUTION: Risk of injury. Keep fingers away from the magnetic
coupling while shaft is rotating. Do not operate without Gear Pump
Head installed.

CAUTION: Hot Surface. Do not touch.

CAUTION: Risk of electric shock. Consult Operator’s manual for nature
of hazard and corrective actions.

This product is not designed for, nor intended for use in patient con­nected applications; including, but not limited to, medical and dental
use, and accordingly has not been submitted for FDA approval.

This product is not designed for, nor intended for use in
hazardous duty areas as defined by ATEX or the NEC (National
Electrical Code); including, but not limited to use with flammable liq­uids. Consult the factory for products suitable for these types of appli­cations

Preface

Safety Precautions

Explanation of

Symbols

WARNING:

Product Use

Limitation

Masterflex

Digital Gear Pump Drive Operating Manual vMasterflex

Table of Contents

Page

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-1

General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2

INSTALLATION AND SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Before Starting the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1

Mounting the Pump Head. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Turning On the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Priming the Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3

Pump Head Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4

Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-6

Continuous Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Continuous Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Time Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

Time Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Copy Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

Copy Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

COPY Setting Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15

COPY Setting Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Volume Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17

Volume Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18

Remote Control Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20

DB-25 Pin Configuration with Wiring Scheme . . . . . . . . . . . . . . . . . . . . . . .3-23

Remote Control Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24

Open Collector Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-25

Section 1

Section 2

Section 3

vi Digital Gear Pump Drive Operating Manual Masterflex

Table of Contents

(continued)

Table of Contents

Page

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Replacement Parts and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1

Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1

Error Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-2

ACCESSORIES AND GEAR PUMP HEADS . . . . . . . . . . . . . . . . . . . . . . . .6-1

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1

WARRANTY, PRODUCT RETURN, and TECHNICAL ASSISTANCE . . .8-1

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-1

Product Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

Technical Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-2

Section 6

Section 8

Section 7

Section 4

Section 5

Figures

Page

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2

Continuous Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-7

Continuous Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-8

Time Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-9

Time Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-10

Copy Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-12

Copy Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-13

COPY Setting Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-15

COPY Setting Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-16

Volume Dispense Mode Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-17

Volume Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-18

Remote Control Menu Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-20

DB-25 Pin Configuration with Wiring Scheme . . . . . . . . . . . . . . . . . . . . . . .3-23

Terminating Open Collector Outputs to a PLC . . . . . . . . . . . . . . . . . . . . . . .3-25

Fuse Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2

Digital Gear Pump Drive Operating Manual viiMasterflex

Figures

Tables

Page

Nominal Calibration Volumes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-5

Continuous Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22

Dispense Mode Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-22

Remote Control Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-24

Gear Pump Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-1

Digital Gear Pump Drive Operating Manual ixMasterflex

Tables

Digital Gear Pump Drive Operating Manual 1-1Masterflex

Section 1 Introduction

Welcome to the Masterflex Digital Gear Pump Drive. This drive has many
of the same functions as the standard MASTERFLEX L/S® Digital Drive
for peristaltic pumps. With different Gear Pump Heads the system offers
flow rates from 0.61 to 4210mL/min.

1-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 1

Introduction

The Masterflex Digital Gear Pump Drive provides the ability to mount a
Masterflex Gear Pump Head to achieve the features of a digital dispensing
and metering pump system. Features include a small footprint, plus drives
that are stackable.

The Masterflex Digital Drive provides a motor speed repeatability of 0.1
percent to maximize productivity in precision liquid dosing, batch
dispensing and filling applications. A turndown ratio up to 100-to-1,
bidirectional flow and self-priming capabilities allow for smooth, seamless
operation and an extremely broad flow range.

In addition to high accuracy, precision, repeatability and resolution of
speed (or flow rate), the Masterflex Drive features a multi-language,
intuitive, man/machine interface with a four-line graphical LCD display
providing direct readout of pump speed (rpm), flow rate (user-selected
units), number of dispenses, and menu options.

The easy-to-use keypad eliminates setpoint overshoot and provides easy
navigation through menu options that include a number of on-screen
programming features.

This Masterflex Drive with its high turndown, superior accuracy, and
intuitive interface make it ideally suited where precise and repeatable flow
control is required. The pump accommodates a variety of product fill
volumes and batch dispensing profiles.

General Description

Digital Gear Pump Drive Operating Manual 2-1Masterflex

Section 2 Installation and Setup

• The ambient air temperature should not exceed 104° F (40° C) and
adequate air flow should be provided for.

CAUTION: Do not block the rear panel of the Pump Drive. The
power switch must always be easy to access. The power cord
must always be easy to disconnect.

WARNING: Do not operate without pump head mounted. Follow
all instructions for proper operation of gear pump head

• To maintain the best accuracy of flow rates, re-calibrate Pump Head
regularly. See Calibration Section of this manual.

•

For Pump Head information, see Pump Head information

within this

flash drive or on the web..

• When cleaning or performing maintenance, please remove power from
the drive.

CAUTION: The power cord set supplied with your Pump Drive
meets the requirements of the country where you purchased the
Pump Drive. If you use the Pump Drive in another country, you
must use a power cord set that meets the requirements of that
country.

DANGER: High voltages exist and are accessible. Use extreme
caution when servicing internal components.

Before Starting Drive

• See Pump Head information within this flash drive or on the web..

CAUTION: When using hazardous chemical and biological
agents, take all suitable protective measures, such as wearing
protective glasses and gloves resistant to the substances used.
Follow local and/or national regulations for safe operation and
maintenance of the system.

2-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 2

Installation and Setup

Mounting the

Pump Head

Digital Gear Pump Drive Operating Manual 3-1Masterflex

Section 3 Operation

WARNING: Do not operate the Pump Drive in a manner not spec­ified in the documentation. Misuse of the Pump Drive may result
in a hazard and may compromise the safety protection built into
the Pump Drive. If the Pump Drive is damaged, turn it off and not
use it until service-trained personnel can check its safety.

1. Plug the power cord into the IEC Connector, located on the rear of the
drive. Plug the opposite end of the power cord into an electrical outlet.

2. Flip the power switch located on the rear of the drive.

3. Upon turning on the drive for the first time you will be prompted to
select a language. The selected language will be set as the default but
can be changed at any time by selecting “LANGUAGE” on the main
menu.

4. After selecting your language, the Main Menu will now appear on the
LCD screen. (NOTE: Each start-up after the initial will revert to the
mode of operation screen previously in use.)

5. If the language is accidently changed and the user would like to reset it
to the default language (English), press and hold the UP/DOWN
(▲/▼) keys during power up.

6. To restore drive to default settings, press and hold the LEFT/RIGHT

(/)keys during power up.

▲

▲

Turning On the Drive

CAUTION: To avoid electrical shock, the power cord protective
grounding conductor must be connected to ground. Not for
operation in wet locations as defined by EN61010-1.

CAUTION: Power must be turned off before connecting the exter­nal remote control cable to prevent damage to the drive.

Figure 3-1. Control Panel

• To navigate all menus on the drive use the directional pad
directly to the right of the LCD screen.

• The (ENTER) key located in the middle of the directional pad
is used to enter or select a highlighted field or option. This key is often
referred to as the ENTER key in this manual.

• The (START/STOP) key located at the top right of the control
panel is used to start and pause the drive. This key is functional only
when in one of the four operating modes: Continuous, Time Dispense,
Copy Dispense, or Volume Dispense. This key is often referred to as
the START/STOP key in this manual.

• The (PRIME) key located at the bottom right of the control
panel is used to access the prime (fast forward) function. While
pressed, this key operates the drive at the maximum allowed speed/flow
rate and in the direction shown on the display. When released, the
drive returns to its original speed or flow rate.

1. Mount Pump Head to drive.

2. Connect suction and discharge to Pump Head. Follow Pump Head
instructions for priming pump.

3. Turn on pump using switch located on the back of the drive.

4. Press and hold the PRIME key on the drive console to prime the
pump. Priming will stop when key is released.

5. See Pump Head operating manual for Pump Head operation and
safety requirements.

3-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Priming the Pump

Control Panel

CONTINUOUS MODE refer to Continuous Mode in this manual.

TIME DISPENSE MODE refer to Time Dispense Mode in this manual.

COPY DISPENSE MODE refer to Copy Dispense Mode section in this
manual.

VOLUME DISPENSE MODE refer to Volume Dispense Mode section in
this manual.

REMOTE CONTROL MODE refer to Remote Control Mode section in
this manual.

CUMULATIVE VOLUME: The drive stores and displays the cumulative
volume in units based on flow rate units (see SETUP MENU in this
section). The Cumulative Volume can also be reset to zero.

NOTE: The Cumulative Volume is dependent on the Gear Pump Head
selected. (See SETUP MENU in this section.)

SOUNDS: An audible “beep” can be enabled to indicate a keypad press,
the end of a dispense and/or the end of a batch.

AUTOSTART: By default the drive will not restart when power is applied.
To enable this feature select AUTOSTART and then ON. The drive will
now restart when power is reapplied.

DISPLAY CONTRAST: This display can be adjusted using the
UP/DOWN (▲/▼) arrows after selecting this menu item.

LANGUAGE: After selecting this menu, the user will be able to select one
of seven different languages.

NOTE: If the language is accidentally changed and the user would like to
reset it to the default language (English), press and hold the UP/DOWN
(▲/▼) keys when power is reapplied.

DEFAULT SETTINGS: Selecting this menu item and pressing the
ENTER key will restore default settings. To restore drive to default settings
the user may also press and hold the LEFT/RIGHT

(/)keys when

power is reapplied.

▲

▲

Digital Gear Pump Drive Operating Manual 3-3Masterflex

Section 3

Operation

Main Menu

3-4 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Pump Head

Calibration

1. Mount Pump Head to drive.

2. Connect suction and discharge to Pump Head.

3. Follow Pump Head instructions for priming pump.

4. Container should be a graduated container or a container placed on a
scale may be used for increased accuracy.

If using a scale, an acceptable weight to volume conversion for water is
1 gram = 1 mL.

5. Turn on drive using power switch located on the rear of the drive.

6. Go to the Main Menu or Mode Setup Menu by selecting the SETUP
icon and pressing the ENTER key. Use the UP and DOWN keys
to highlight CAL in the Main or Setup Menu and press the ENTER
key.

7. Set the drive for the desired flow direction, Pump Head, and flow rate.
Note that these settings are retained and transferred to other mode
screens when entering or leaving the CAL screen.

• The flow direction is set using the directional keypad to highlight
the directional arrow. Pressing ENTER will toggle arrow between
CW and CCW.

• The Pump Head is set using the directional keypad to highlight
the Pump Head field. Press ENTER and use the UP/DOWN keys
to select the Pump Head size. Press ENTER to SAVE the selection
and return to CAL screen.

• The estimated flow rate is set using the directional keypad to
highlight the flow rate field. Press ENTER and use the
LEFT/RIGHT keys to select the digit to be changed. Use the
UP/DOWN keys to adjust the flow rate value. Press ENTER to
SAVE the setting and EXIT field using arrow keys. The drive will
adjust this flow rate after calibration is complete.

• Note that the calibration volume is fixed and cannot be changed.

8. Press and hold the prime key on the drive console to prime the
pump. Priming will stop when key is released.

9. Place a measuring container at the pump outlet. Highlight the START
field and press the ENTER key. The drive will run based on the
default volume at the estimated flow rate selected.

Digital Gear Pump Drive Operating Manual 3-5Masterflex

Section 3

Operation

10. Upon completion of the calibration run period, the CAL VOLUME
field will be highlighted. Press the ENTER key and adjust the CAL
VOLUME to the measured quantity. Use the LEFT/RIGHT keys to
select digit to be changed, use the UP/DOWN keys to adjust the
value, and press ENTER to SAVE setting and EXIT the field.

A lower case “c” should now be displayed when the calibrated Pump
Head size is selected. The volume units will depend on the flow rate
units. The flow rate unit mL/min will result in a volume unit of mL;
oz/min will result in a volume unit of oz.

Pump Head Calibration Notes

• If the drive is stopped during calibration, empty the container and
re-start the procedure.

• Calibration time at maximum allowable flow rate (default max
flow rate) is approximately 30 seconds.

• Minimum and maximum flow rates will change after a Pump
Head calibration due to a re-calculation of the vol/rev.

See Section 6-1 for gear size and model numbers.

Pump Head

Calibration

(continued)

Table 3-1. Nominal Calibration Volumes

SIZE Max. mL/min Cal. fill vol in mL

"N21" 1137.6 568.8
"N23" 2304 1152
"N25" 3276 1638
"P23" 936 468
"P25" 2088 1044
"P35" 4212 2106
"T23" 331.2 165.6
"V21" 151.2 75.6
"V23" 302.4 151.2
"X21" 61.2 30.6

3-6 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

All four operation mode screens contain a SETUP icon in the upper
right hand that gives quick access to the SETUP menu. The exact options
that can be accessed through the SETUP menu will depend on the
operating mode currently in use:

1. Selecting the SETUP Menu: In any of the four operating modes, use
the directional pad and enter key to select the SETUP icon from the
mode operation screen.

2. Navigating the SETUP Menu: Use the directional pad and the
ENTER key to select desired setting.

A breakdown of the setting features common to all modes follows. Other
settings are related to the specific operating mode currently in use and can
be accessed through the mode operation screen as well.

Flow Unit: Select desired flow unit to be displayed.

Pump Head: Size and Maximum Flow Rate are displayed. Select desired
Pump Head.

Flow Rate: Set the flow rate in flow unit listed at the top of the screen.
(NOTE: To change flow unit, see Flow Unit above.) When the entire rate
field is highlighted, press ENTER. The digits can be navigated individually
using the UP/DOWN arrows; switch between digits using the
LEFT/RIGHT arrows. After selecting an optimal flow rate, press ENTER
again to validate.

Pump Head Calibration: See Pump Head Calibration.

Pump Direction: Select the direction of the pump flow.

Sounds: Select a beep for keypad, end of dispenses, and batches.

Remote Control: See Remote Control.

Keypad Lockout: Allows for the keypad to be locked and unlocked.

Cumulative Volume: View and reset cumulative volume.

Main Menu: Return to the Main Menu.

Exit: Return to the Mode Operation screen.

Setup Menu

Digital Gear Pump Drive Operating Manual 3-7Masterflex

Section 3

Operation

Display Legend:

Below is a screenshot of the screen display for the drive in

Continuous Mode. An explanation of the information on the screen follows.

Figure 3-2. Continuous Mode Screen

A. Mode Display: Current operating mode in which the drive will operate.

Pressing ENTER key when highlighted will cycle through the different
operation modes.

B. Setup : Pressing the ENTER key on this icon goes to the Setup

screen. The Setup screen contains most functions that can be accessed
from the Continuous Mode operation screen, including: flow units,
Pump Head size, flow rate, pump direction, remote control, and keypad
lockout. The Setup screen also provides access to Pump Head calibration,
sounds, cumulative volume and the Main Menu.

C. Flow Direction: Pressing the ENTER key on this icon toggles between

clockwise and counterclockwise flow direction.

D. Flow Units: Pressing the ENTER key on this icon goes to the Flow Unit

selection screen. NOTE: % and rpm are available in Continuous Mode only.
When switching to Copy Dispense or Volume Dispense Modes % and rpm
units will change to mL/min with values dependent on Pump Head size
selected.

E. Pump Head Size: Pressing the ENTER key on this icon goes to the

Pump Head size selection screen.

F. Current Flow Rate: The center digits show the flow rate of the drive in the

unit of measure selected and shown to the right (see position D, Figure 3-2).

G. Local/Remote or : Pressing the ENTER key on this icon goes to

the Remote Control setup screen. This icon indicates whether your
drive is in local or remote control mode. If the solid rectangle appears
in the center of the figure the drive is set to be operated locally. If the
solid rectangle does not appear in the center of the figure the drive is
set to be operated by remote control.

H. Key Pad Lock : Pressing the ENTER key on this icon goes to the

Keypad Lockout screen. Locking the keypad will prevent someone from
changing the settings on the drive. When locked this icon changes to .

Continuous Mode

Screen

CONTINUOUS MODE

100.00

P25

mL/min

A

I

H

C

D

E

B

G

F

or

3-8 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Figure 3-3. Continuous Mode Operation

1. Getting Started: From the Main Menu, use the ENTER key to
select Continuous Mode to enter the Continuous Mode Operation
screen.

2. Calibrating Pump Head: For more information, see “Pump Head
Calibration.”

3. Preparing External Supplies: Insert suction end into supply fluid. Next,
insert discharge end into desired container.

4. Starting the Drive: From this operation screen, simply pressing the
START/STOP key will start the drive at the speed/flow rate and
direction shown. In Continuous Mode the drive will operate at the
displayed speed/flow rate and direction continuously.

5. Stopping the Drive: To pause or stop the drive, press the
START/STOP key in the top right hand corner of the console.

6. Changing Speed/Flow Rate: To change the speed/flow rate of the drive,
use the directional pad to highlight the numeric field in the center of the
display and press the ENTER key. This puts you in a position to change
the speed/flow rate of the drive at the farthest digit to the right (tenths,
hundredths, thousandths, etc depending on flow unit). Pressing the UP
arrow on the directional pad will increase the speed/flow rate by one
value and pressing the DOWN arrow will decrease the speed/flow rate by
one value. Pressing the ENTER key again will show all the possible digits
that can be manipulated for the specific flow unit currently in use; use the
LEFT/RIGHT arrows on the directional pad to move between digits and
the UP/DOWN arrows to increase or decrease the value, respectively.
Once desired speed/flow rate is selected, press ENTER key a final time to
set the drive to operate at that speed/flow rate.

7. Changing Flow Unit: To change the flow unit of the drive pause the
drive using the START/STOP key. Next, use the directional pad to
select the Flow Units icon and press the ENTER key. Use the
UP/DOWN arrow on the directional pad to select the desired flow
unit and press the ENTER key to choose that unit. The drive will now
operate in that flow unit. Press the START/STOP key to resume
operating the drive.

Continuous Mode

Operation

CONTINUOUS MODE

100.00

P25

mL/min

Digital Gear Pump Drive Operating Manual 3-9Masterflex

Section 3

Operation

Display Legend: Below is a screenshot of the screen display for the drive in
Time Dispense Mode. An explanation of the information on the screen follows.

Figure 3-4. Time Dispense Mode Screen

A. Mode Display: Current operating mode.

B. Setup : The Setup screen can be used to select flow units, Pump

Head size, flow rate, Pump Head calibration, sounds, cumulative
volume, and Main Menu. The Setup screen contains some functions that
can be accessed from the Time Dispense Mode operation screen,
including: pump direction, on/off time, batch count, remote control,
and keypad lockout.

C. Flow Direction: Pressing the ENTER key on this icon toggles between

clockwise and counterclockwise flow direction.

D. Pump ON Time: When this field is highlighted the drive is ON.

NOTE: The drive will not show 00:00 when switching from ON to
OFF Time.

E. Pump OFF Time: When this field is highlighted the drive is OFF.

F. Batch Count: Displays the number of cycles dispensed in the batch.

G. Local/Remote or : Pressing the ENTER key on this icon goes to

the Remote Control setup screen. This icon indicates whether your
drive is in Local or Remote Control mode. If the solid rectangle
appears in the center of the figure the drive is set to be operated locally.
If the solid rectangle does not appear in the center of the figure the
drive is set to be operated by remote control.

H. Key Pad Lock : Pressing the ENTER key on this icon goes to the

Keypad Lockout screen. Locking the keypad will prevent someone
from changing the settings on the drive. When locked this icon
changes to .

I. Time Display: The center digits show the remaining time of the drive

in the ON or OFF Time highlighted on the right of the display
(position D or E, Figure 3-4).

Time Dispense Mode

Screen

TIME DISP. MODE

00:00:00

OFF

ON

1000/2000

A

I

H

C

D

E

B

F

G

or

3-10 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Figure 3-5. Time Dispense Mode Operation

1. Getting Started: From the Main Menu, use the enter key to select Time
Dispense Mode to enter the Time Dispense Mode Operation screen.

2. Calibrating Pump Head: For more information, see “Pump Head
Calibration.”

3. Choosing Settings: Select desired flow unit, Pump Head size, flow rate,

pump direction, etc. For more information see “SETUP Menu.”

4. Preparing Pump Head: Insert suction end into supply fluid. Next,
insert discharge end into desired container.

5. Selecting Flow Rate: Use the directional pad and ENTER key to select
the Setup icon. Use the UP/DOWN arrows on the directional pad to
select Flow Rate. In the Flow Rate selection screen, press the ENTER
key and then use the UP/DOWN arrows on the directional pad to
select a desired flow rate. For faster entry, use the LEFT/RIGHT
arrows on the directional pad to move between digits and the
UP/DOWN arrows to increase or decrease the value, respectively.
Press ENTER one more time to validate the selected flow rate. Use the
directional pad to select EXIT to return to the Time Dispense Mode
Setup Screen.

6. Setting ON Time: To set the ON Time, use the directional pad and
ENTER key to select the ON field (see position D, Figure 3-4). Doing
so will highlight the timer in the center of the screen (see position I,
Figure 3-4). Pressing ENTER again, allows the timer to be set using
the UP/DOWN arrows. Switch between digits using the
LEFT/RIGHT arrows. Having selected an optimal ON Time, press
ENTER again to validate. The drive will now run for the time
appearing in the center of the screen.

Time Dispense

Mode Operation

TIME DISP. MODE

00:00:00

OFF

ON

1000/2000

Digital Gear Pump Drive Operating Manual 3-11Masterflex

Section 3

Operation

7. Setting OFF Time: To set the OFF Time, use the directional pad and
ENTER key to select the OFF field (see position E, Figure 3-4). Doing
so will highlight the timer in the center of the screen (see position I,
Figure 3-4). Pressing ENTER again, allows the timer to be set using
the UP/DOWN arrows. Switch between digits using the
LEFT/RIGHT arrows. Having selected an optimal OFF Time, press
ENTER again to validate. The drive will stop running for the time
appearing in the center of the screen. NOTE: If the OFF Time is set to
00:00:00, the drive requires a START/STOP input from the keypad or
the remote I/O Connector to start the next dispense.

8. Selecting Batch Size: Before running the drive at the selected ON/
OFF Times, select a batch size for the operation. To do so, use the
directional pad and the ENTER key to select the BATCH icon (see
position F, Figure 3-4). In the Batch Count screen, press the ENTER
key and then use the UP/DOWN arrows on the directional pad to
select a batch size. Switch between digits using the LEFT/RIGHT
arrows. Press ENTER one more time to validate the selected batch size.
When set to zero (0) the drive will run for an infinite number of cycles
and the  symbol is displayed. Use the directional pad to select EXIT
to return to the Time Dispense Operation Screen.

9. Starting the Drive: The drive is now set to operate, press the
START/STOP key in the upper right hand corner to start the drive.
The drive can be paused at any time throughout the batch to adjust
flow direction, Pump Head size, flow units, flow rate, etc.

10. Resetting Batch: To reset a batch, use the directional pad and the
ENTER key to select the BATCH icon (see position F, Figure 3-4). In
the Batch Count screen, use directional pad to select RESET and press
the ENTER key to reset the batch count, select EXIT to return to the
main Time Dispense Mode operation screen.

Time Dispense Mode

Operation (continued)

3-12 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Copy Dispense Mode

Screen

Display Legend: Below is a screenshot of the screen display for the drive in
Copy Dispense Mode. An explanation of the information on the screen
follows.

Figure 3-6. Copy Dispense Mode Screen

A. Mode Display: Current operating mode.

B. Setup : The Setup screen can be used to select flow units, Pump

Head size, flow rate, Pump Head calibration, sounds, cumulative
volume, and Main Menu. The Setup screen contains some functions
that can be accessed from the Time Dispense Mode operation screen,
including: pump direction, on/off time, batch count, remote control,
and keypad lockout.

C. Flow Direction: Pressing the ENTER key on this icon toggles between

clockwise and counterclockwise flow direction.

D. Copy Amount Screen: See Copy Setting Screen, Figure 3-8.

E. Pump OFF Time: Highlighted when the drive is OFF.

F. Batch Count: Displays the number of cycles dispensed in the batch.

G. Local/Remote or : Pressing the ENTER key on this icon goes to

the Remote Control setup screen. This icon indicates whether your
drive is in local or remote control mode. If the solid rectangle appears
in the center of the figure the drive is set to be operated locally. If the
solid rectangle does not appear in the center of the figure the drive is
set to be operated by remote control.

H. Keypad Lock : Pressing the ENTER key on this icon goes to the

Keypad Lockout screen. Locking the keypad will prevent someone
from changing the settings on the drive. When locked this icon
changes to .

I. Percentage Completed: This icon displays the portion of fluid

dispensed as a percentage.

J. Copy Volume: Displays the Copy Volume while dispensing or the

OFF Time.

COPY DISP. MODE

100.00

OFF

COPY

1000/2000

53 %

A

J

I

H

C

D

E

B

F

G

or

Digital Gear Pump Drive Operating Manual 3-13Masterflex

Section 3

Operation

Section 3

Operation

Copy Dispense Mode

Operation

Figure 3-7. Copy Dispense Mode Operation

1. Getting Started: From the Main Menu, use the ENTER key to select
Copy Dispense Mode to enter the Copy Dispense Mode operation
screen.

2. Calibrating Pump Head: For more information, see “Pump Head
Calibration.”

3. Choosing Settings: Select desired flow unit, Pump Head size, flow rate,
pump direction, etc. For more information see “Using the SETUP
Menu.”

4. Preparing Pump Head: Insert suction end into supply fluid. Next,
insert discharge end into desired container.

5. Setting Copy Amount: See Copy Setting Operation.

6. Setting OFF Time: Use the directional pad and ENTER key to select
OFF on the display to enter the Pump OFF Time. Use the directional
pad and ENTER key to set the Pump OFF Time. The timer in the
center of the screen will be highlighted, and using the UP/DOWN
arrows will increase/decrease the farthest right digit of the time
interval. Switch between digits using the LEFT/RIGHT arrows. After
selecting an optimal OFF Time, press ENTER again to validate. The
drive will now rest for the time appearing in the center of the screen.
NOTE: If the OFF Time is set to 00:00:00, the drive requires a
START/STOP input from the keypad or the remote I/O Connector
to start the next dispense.

7. Setting Batch Size: Use the directional pad and ENTER key to select
the Batch Count icon from the operation screen (see position F,
Figure 3-6). From Batch Count screen use the UP/DOWN arrows to
select batch size. Press ENTER to validate batch size. When set to zero
(0) the drive will run for an infinite number of cycles and the 
symbol is displayed. Select EXIT to return to the Copy Dispense
Mode screen.

• Batch count may be reset from BATCH COUNT screen by

selecting RESET.

COPY DISP. MODE

100.00

OFF

COPY

1000/2000

53 %

3-14 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

8. Operating Drive: Press the START/STOP key to operate the drive at
the settings selected and displayed on the screen. Press again to pause
or stop the drive. Drive will automatically stop once batch is complete.

9. Reset Batch Count: Use the directional pad and the ENTER key to
select the BATCH COUNT icon (see position F, Figure 3-6). In the
BATCH COUNT screen, select RESET and press the ENTER key to
reset the batch count. Select EXIT to return to the Copy Mode
Operation screen.

10. Maximum Dispense Time: The specification for the maximum
dispense in Copy Mode is over 80+ hours at 3600 rpm. Actual
maximum volume is dependant on Pump Head size and flow units
selected.

Copy Dispense Mode

Operation (continued)

Digital Gear Pump Drive Operating Manual 3-15Masterflex

Section 3

Operation

Display Legend: Below is a screenshot of the screen display for the drive in
Copy Setting Mode. An explanation of the information on the screen follows.

Figure 3-8. COPY Setting Screen

A. Mode Display: Current operating mode.

B. START: This icon will start drive allowing for copy volume to be set.

C. Flow Direction: Pressing the ENTER key on this icon toggles between

clockwise and counterclockwise flow direction.

D. Volume Unit: This is dependent on the flow rate selected.

E. STOP: This stops the Copy and sets the volume to be dispensed. It is

displayed in position H.

F. CLEAR: Selecting this will clear the number displayed on the screen

and will allow for a new copy volume to be selected.

G. EXIT: Return to Copy Dispense Mode.

H. Volume: This is the amount that was dispensed during the copy.

COPY Setting Screen

mL/min

COPY

STOPEXIT

START

mL

10000

A

H

C

D

E

B

GF

CLEAR

3-16 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Figure 3-9. COPY Setting Operation

1. Getting Started: From the COPY DISPENSE MODE Screen select

COPY and ENTER.

2. Clear Volume: Using the directional Keypad select CLEAR and ENTER.

3. Establish Copy Volume: 3 methods are available to the user.

a. Place the desired container at the discharge end. Press the

START/STOP key to initiate the dispensing of fluid. When you have
reached the desired volume press the START/STOP key again. Select
EXIT and press ENTER. The drive will store the value of the copy in
memory and use that value in the COPY DISPENSE MODE.

b. Place the desired container at the discharge end. Select the START field

on the screen and press the ENTER key to initiate the dispensing of
fluid. The drive will now highlight the STOP field on the screen. When
you have reached the desired volume press the ENTER key to stop.
Select EXIT and press ENTER. The drive will store the value of the
copy in memory and use that value in the COPY DISPENSE MODE.

c. Place the desired container at the discharge end. Close the contacts

on the START/STOP input to initiate the dispensing of fluid.
When you have reached the desired volume, close and release the
contacts on the START/STOP input. Select EXIT and press
ENTER. The drive will store the value of the copy in memory and
use that value in the COPY DISPENSE MODE.

NOTE: The value displayed as the volume in the COPY SETTING screen
and the COPY DISPENSE Mode screen depend on the flow units selected.
RPM, and % are invalid. If these units have been selected the drive will
display a volume in mL, in the COPY DISPENSE MODE, that is
dependent on the Pump Head size selected.

See PUMP HEAD CALIBRATION to improve the accuracy of this

conversion.

COPY Setting

Operation

mL/min

COPY

STOPEXIT

START

mL

10000

CLEAR

Digital Gear Pump Drive Operating Manual 3-17Masterflex

Section 3

Operation

Display Legend: Below is a screenshot of the screen display for the drive
in Volume Dispense Mode. An explanation of the information on the
screen follows.

Figure 3-10. Volume Dispense Mode Screen

A. Mode Display: Current operating mode.

B. Setup : The Setup screen can be used to select flow units, Pump

Head size, flow rate, Pump Head calibration, sounds, cumulative
volume, and Main Menu. The Setup screen contains some functions that
can be accessed from the Time Dispense Mode operation screen,
including: pump direction, on/off time, batch count, remote control,
and keypad lockout.

C. Flow Direction: Pressing the ENTER key on this icon toggles between

clockwise and counterclockwise flow direction.

D. Flow Units: Select desired flow unit.

E. Pump OFF Time: Highlighted when the drive is OFF.

F. Batch Count: Displays the number of cycles dispensed in the batch.

G. Local/Remote or : Pressing the ENTER key on this icon goes to

the Remote Control setup screen. This icon tells you whether your
drive is in local or remote control mode. If the solid rectangle appears
in the center of the figure the drive is set to be operated locally. If the
solid rectangle does not appear in the center of the figure the drive is
set to be operated by remote control.

H. Keypad Lock : Pressing the ENTER key on this icon goes to the

Keypad Lockout screen. Locking the keypad will prevent someone from
changing the settings on the drive. When locked this icon changes to .

I. Volume: Displays the Volume while dispensing or the OFF Time.

Volume Dispense

Mode Screen

VOL DISP. MODE

100.00

OFF

mL

1000/2000

A

I

H

C

D

E

B

F

G

or

3-18 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Figure 3-11. Volume Dispense Mode Operation

1.

Getting Started: From the Main Menu, use the ENTER key to select Volume
Dispense Mode to enter the Volume Dispense Mode operation screen.

2. Calibrating Pump Head. For more information, see “Pump Head
Calibration.”

3. Choosing Settings: Select desired flow unit, Pump Head size, flow rate,

pump direction, etc. For more information see “SETUP Menu.”

4. Preparing Tubing: Insert suction end into supply fluid. Next, insert
discharge end into desired container.

5. Setting Desired Volume: Using the directional pad highlight the numeric
field in the center of the display and press the ENTER key. This puts you
in a position to change the fluid volume of the drive at the farthest digit to
the right (tenths, hundredths, thousandths, etc., depending on your volume
unit). Pressing the UP arrow on the directional pad will increase the volume
by one value and pressing the DOWN arrow will decrease the volume by
one value. Pressing the ENTER key again will show all the possible digits
that can be manipulated for the specific volume unit currently in use; use
the LEFT/RIGHT arrows on the directional pad to move between digits
and the UP/DOWN arrows to increase or decrease the value, respectively.
Once desired volume is selected, press ENTER a final time to set the drive
to operate at that volume. Press the START/STOP key to resume operating
the drive.

6. Setting Pump OFF Time: Use the directional pad and ENTER key to
select OFF on the display (see position E, Figure 3-10) to enter the OFF
TIME. Use the directional pad and ENTER key to set the pump rest time.
The timer in the center of the screen will be highlighted, and using the
UP/DOWN arrows will increase/decrease the farthest right digit of the time
interval. If ENTER is pressed a second time while the timer is highlighted,
the digits can be navigated individually using the UP/DOWN arrows;
switch between digits using the LEFT/RIGHT arrows. After selecting an
optimal OFF time, press ENTER again to validate. The drive will now rest
for the time appearing in the center of the screen. NOTE: If the OFF Time
is set to 00:00:00, the drive requires a START/STOP input from the
keypad or the remote I/O Connector to start the next dispense.

Volume Dispense

Mode Operation

VOL DISP. MODE

100.00

OFF

mL

1000/2000

Digital Gear Pump Drive Operating Manual 3-19Masterflex

Section 3

Operation

7. Setting Batch Size: Use the directional pad and ENTER key to select
the Batch Count icon from the operation screen (see position F,
Figure 3-10). From Batch Count screen use the UP/DOWN arrows to
select batch size. Press ENTER to validate batch size. When set to zero
(0) the drive will run for an infinite number of cycles and the ∞
symbol is displayed. Select EXIT to return to drive operation screen.

• Batch count may be reset from the Batch Count screen by selecting

RESET.

8. Operating the Drive: Press the START/STOP key to operate the drive
continuously at the settings selected and displayed on the screen. Press
again to pause or stop the drive. Drive will automatically stop once
batch is complete.

9. Reset Batch Count: Use the directional pad and the ENTER key to
select the BATCH COUNT icon (see position F, Figure 3-10). In the
BATCH COUNT screen, select RESET and press the ENTER key to
reset the batch count. Select EXIT to return to the COPY MODE
OPERATION screen.

10. Maximum Dispense Time: The specification for the maximum
dispense volume in Volume Mode is over 80+ hours at 3600 rpm.
Actual maximum volume is dependant on Pump Head size and flow
units selected.

Volume Dispense

Mode Operation

(continued)

3-20 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Figure 3-12. Remote Control Menu Screen

NAVIGATION: From the Main Menu or SETUP Menu select REMOTE
CONTROL and ENTER.

LOCAL: When this is selected the drive is controlled by the front panel
keypad, Start/Stop Input, Directional Input or Prime Input.

CURRENT INPUT: When this is selected, the drive is in remote control.
This allows the user to input a current signal to control the flow. The user has
an option to adjust the minimum, maximum and middle set points for
current and flow. By default the minimum (MIN) current is set to 4.2 mA
and the flow is set to 0. The maximum (MAX) is set to 20 mA and the flow is
set to maximum. The middle (MID) is auto calculated for a current and flow
that is centered between the MIN and the MAX. The MID can be adjusted if
other profiles are needed. The scaling can be inverted if necessary. To confirm
CURRENT INPUT MODE is selected, select EXIT after returning to the
Remote Control Menu, then select CONTINUOUS PUMP MODE. To
deselect Remote Current Input Mode select LOCAL and ENTER.

NOTE: When Current Input is selected the drive will not start until the
REMOTE CONTROL MODE is exited and CONTINUOUS PUMP
MODE is selected.

CURRENT OUTPUT: This allows the user to adjust the current output for a
given flow. The user has an option to adjust the minimum, maximum and
middle setpoints for current and flow. By default the minimum (MIN) flow is set
to 0.00 and the current is set to 4.0 mA. The maximum (MAX) is set to
maximum flow and the current is set to 20.0 mA. The middle (MID) is auto
calculated for a current and flow that is centered between the MIN and the MAX.
The MID can be adjusted if other profiles are needed. This allows for a three­point calibration of the current output. The flow is linear between these points.
The scaling can be inverted if necessary. NOTE: Selecting Current Output will not
put user into REMOTE CONTROL MODE. Only selecting VOLTAGE
INPUT or CURRENT INPUT will put the user into Remote Control Mode, as
indicated by the empty house icon (see position G, Figure 3-2). NOTE: The
Current Output indicates the Running Command Speed. Use the Motor
Running contacts (normally open/closed) to indicate if pump is running.

Remote Control Menu

REMOTE CONTROL

LOCAL

CURRENT INPUT

CURRENT OUTPUT

VOLTAGE INPUT

VOLTAGE OUTPUT

START/STOP

EXIT

Digital Gear Pump Drive Operating Manual 3-21Masterflex

Section 3

Operation

Remote Control Menu

(continued)

VOLTAGE INPUT: When this is selected, the drive is in remote control.
This allows the user to input a voltage signal to control the flow. The user
has an option to adjust the minimum, maximum and middle setpoints
for voltage and flow. By default the minimum (MIN) voltage is set to

00.1 V DC and the flow is set to 00.0. The maximum (MAX) is set to

10.0 V DC and the flow is set to maximum. The middle (MID) is auto-

calculated for a voltage and flow that is centered between the MIN and
the MAX. The MID can be adjusted if other profiles are needed. The
scaling can be inverted, if necessary. To confirm VOLTAGE INPUT
MODE is selected, select EXIT after returning to the Remote Control Menu,
then select CONTINUOUS PUMP MODE. To deselect Remote Voltage
Input Mode select Local and ENTER.

NOTE: When Voltage Input is selected the drive will not start until the
REMOTE CONTROL MODE is exited and CONTINUOUS PUMP
MODE is selected.

VOLTAGE OUTPUT: This allows the user to adjust the voltage output for a
given flow. The user has an option to adjust the minimum, maximum and
middle set points for voltage and flow. By default the minimum (MIN) flow
is set to 00.00 and the voltage is set to 00.0V DC. The maximum (MAX) is
set to maximum flow and the voltage is set to 10.0V DC. The middle (MID)
is auto calculated for a voltage and flow that is centered between the MIN and
the MAX. The MID can be adjusted if other profiles are needed. This allows
for a three point calibration of the voltage output. The flow is linear between
these points. The scaling can be inverted if necessary. NOTE: Selecting Voltage
Output will not put the user into Remote Control Mode. Only selecting
Voltage Input or Current Input will put the user into Remote Control Mode,
as indicated by the empty house icon (see position G, Figure 3-2). NOTE: The
Voltage Output indicates the Running Command Speed. Use the Motor
Running outputs to indicate if pump is running.

START/STOP: The START/STOP input can be configured to be OFF
(factory default), or ON for the drive to run.

With the OFF selected (factory default), use of the START/STOP input is
optional. When the START/STOP input is open, the drive can still be started
using the START/STOP key, PRIME key, or PRIME input. In remote modes
the drive will also run if there is sufficient current or voltage at the input.

Closing the START/STOP input will cause the drive to run until the
START/STOP input opens or the START/STOP key is pressed. In Time
dispense, Copy dispense, and Volume dispense mode, only a momentary
START/STOP closure is needed to start the drive. If the drive is already
running in one of the dispense modes, a momentary START/STOP
closure will stop the drive. In SET COPY MODE, the START/STOP
input functions the same as in CONTINUOUS MODE; closing it will
cause the drive to run until it opens.

3-22 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

Remote Control Menu

(continued)

The function of the START/STOP input is considerably simplified when
the ON is selected. The drive will not run under any condition unless the
START/STOP input is closed.

Table 3-2. Continuous Mode Operation

MENU SETTINGS START/STOP INTERNAL MODE mA or V MODE
SETUP OPTIONS INPUT

AUTO START/STOP Drive State When Drive Response When Drive Running

START REQUIRED Powered OFF Powered ON (sufficient level)

When Powered OFF

Drive Response when

Powered ON

(sufficient level present)

OFF OFF OPEN Running Not running Not running
OFF OFF OPEN Not running Not running Not running
OFF OFF CLOSED Forced run due Not running Not running

to S/S CLOSED

OFF ON OPEN Forced not running Not running Not running

due to S/S OPEN

OFF ON CLOSED Forced run due Not running Not running

to S/S CLOSED
ON OFF OPEN Running Running Running
ON OFF OPEN Not running Not running Running
ON OFF CLOSED Forced run due Running Running

to S/S CLOSED
ON ON OPEN Forced not running Not running Not running

due to S/S OPEN

ON ON CLOSED Forced run due Running Running

to S/S CLOSED

NOTE: In Continuous Mode when using the START/STOP input the drive is started with a closed contact and

stopped when the contacts are opened.

Table 3-3. Dispense Mode Operation

MENU SETTING SETUP OPTIONS START/STOP Drive State When Drive Response When

INPUT Powered OFF Powered ON

AUTO START START/STOP

REQUIRED

OFF OFF OPEN Running Not running
OFF OFF OPEN Not running Not running
OFF OFF CLOSED* Forced run due Not running

to S/S CLOSED

OFF ON OPEN Forced not running Not running

due to S/S OPEN

OFF ON CLOSED Forced run due Not running

to S/S CLOSED
ON OFF OPEN Running Running
ON OFF OPEN Not running Not running
ON OFF CLOSED* Forced run due Running

to S/S CLOSED
ON ON OPEN Forced not running Not running

due to S/S OPEN

ON ON CLOSED Forced run due Running

to S/S CLOSED

* NOTE: In Dispense Modes and START/STOP MENU SETUP Option OFF the drive will start a dispense

with a momentary contact closure and stop with a momentary contact closure during both the dispense
period and interval period.

Digital Gear Pump Drive Operating Manual 3-23Masterflex

Section 3

Operation

DB-25 Pin

Configuration with

Wiring Scheme

Contact Arrangements

CAUTION: Power must be turned off before connecting the
external remote control cable to prevent damage to the drive.

NOTE: Open collector outputs in "low impedance" state are at earth
ground and when in "high impedance" state are essentially floating. See
Open Collector page following.

Figure 3-13. DB-25 Pin Configuration with Wiring Scheme

A. START/STOP
B. CW/CCW
C. OUTPUT 0-20mA; 4-20mA
D. INPUT 0-20mA; 4-20mA
E. INPUT 0-10V
F. OUTPUT 0-10V
G. TACH OUTPUT

K

HA

G

B

JI C E

D

F

M

L

13 112 11 10 9 8 7 6 5 4 3 2

25 24 23 22 21 20 19 18 17 16 15 14

H. PRIME
I. MOTOR RUNNING N.O. CONTACT (1A @ 24 V)
J. MOTOR RUNNING N.C. CONTACT (1A @ 24 V)
K. 24V (150mA max.)
L. General Alarm
M. Local.Remote Indicator

Pin No. Description
DB-25

1 Speed Control Voltage Input (0-10 V)
2 Speed Control Current Input (0-20 mA)
3 Speed Control Input Ground Return
4 Speed Signal Current Output (0-20 mA)
5 Speed Signal Output Ground Reference
6 (Motor Running N.O. Default) 1A @24 V (Open Collector)
7 Motor Running Ground Return
8 (Motor Running N.C. Default) 1A @24 V (Open Collector)
14 Speed Signal Voltage Output (0-10 V)
15 Remote Start/Stop Input
16 Remote CW/CCW Input
17 Remote Start/Stop, CW/CCW, Prime Grnd Ref.
18 Tach Ground Reference
19 Tach Output (Open Collector)
20 Remote Prime Input
19 Reserved – Not Used
10 Reserved – Not Used
11 Reserved – Not Used
12 Reserved – Not Used
21 Reserved – Not Used
22 Reserved – Not Used
23 General Alarm (Open Collector)
24 Local.Remote Indicator (Open Collector)
25 Aux 24V+ (150 mA)
13 Aux 24V- (150 mA)

NOTE: Pins 5, 13, 17, and 18 are at earth ground, all are suitable for use
with START/STOP, PRIME, Direction, Tach, LOCAL/REMOTE,
General Alarm Signals and Current and Voltage Outputs.

3-24 Digital Gear Pump Drive Operating Manual Masterflex

Section 3

Operation

INPUTS

Remote CW/CCW, Remote Start/Stop, Remote Prime, & Aux. In:

The remote control inputs work with current sinking outputs (open­collector NPN transistor outputs without passive pull-up resistors) or
contact closures to DC common (earth ground). A continuous active low
to the Remote Start/Stop input causes the drive to run, while a continuous
active low to the Remote CW/CCW input causes the drive to run CCW.
The motor is brought to a controlled stop before reversing direction. A
continuous active low to the Remote Prime input causes the drive to run
at full rated speed.

CURRENT CLOSED INPUT 1 mA TYP
VOLTAGE OPEN INPUT 3.2 V TYP
THRESHOLD CURRENT TO ACTIVATE 0.5 mA TYP

Remote Analog Input:

4-20 mA Input: 250 ohms typical input impedance ref. to signal

ground. 4 mA, Stop; 20 mA, Full Speed (Default
Settings) 10 Bit Resolution

Overload Capability: 10 V or 40 mA max.

0-10 V Input: 10 K ohms typical input impedance ref. to signal

ground. 0 V, Stop; 10 V, Full Speed (Default
Settings) 10 Bit Resolution

OUTPUTS

4-20 mA Output: 0 to 600 ohms max. load referenced to earth ground.

4 mA, Stop; 20 mA, Full Speed (Default
Settings) 10 Bit Resolution

0-10 V Output: 1.0 K ohms min. load referenced to earth

ground. 0 V, Stop; 10 V, Full Speed (Default
Settings) 10 Bit Resolution

Tach Output: Open Collector, 1.0A @ 28V DC

Frequency range: 60 to 6000Hz 50% Duty Cycle. (10 Hz = 6

pump rpm)

Logic Outputs: Open Collector, 1.0 A @ 28V DC

Motor Running Outputs: Normally Open and Normally Closed when drive is

running.

General Alarm Output: Open (High Impedance) when an alarm is displayed.

Local/Remote Indicator: Open (High Impedance) when in remote

control mode (Voltage Input or Current Input).

Remote Control Inputs

and Outputs

Table 3-4. Remote Control Inputs and Outputs

Digital Gear Pump Drive Operating Manual 3-25Masterflex

Section 3

Operation

Some remote outputs on this drive (Tachometer, Local/Remote, and
Alarm) are “open collector” type outputs and cannot be wired in the same
manner as relay outputs. An open collector output is not isolated and
must be configured differently than a relay output.When the open
collector output is active, the output is effectively switched to earth ground
and if improperly terminated could result in damage to the drive and/or
external equipment.

Recommendation

When connecting to open collector outputs, the output should be
connected to a current limiting resistor and then to a positive supply
source which is less than 28V DC. Typically this would be connected to a
24V PLC input (see Figure 3-14).

NOTE: when using the 24V supply on the interface connector, current
draw must be limited to 150 mA.

NOTE: DO NOT connect 120V supply lines to open collector outputs!

Figure 3-14. Terminating Open Collector Outputs to a PLC

Open Collector

Outputs

+24V

To PLC

Output

10k

Digital Gear Pump Drive Operating Manual 4-1Masterflex

Section 4 Maintenance

Replacement Parts

and Accessories

Description Part Number

Fuse-T3.15A, 5 x 20 mm 77500-25

Brushes (set of 2) 07520-04

Brush cap holder 07520-03

WARNINGS: The Power switch on the Back Panel is not
the main disconnect. Main disconnect is accomplished by
disconnecting the detachable power supply cord at the
appliance coupler or at the main plug. Ensure the power cord is
easily accessible and removable, in the event of an emergency,
which requires immediate disconnection.

The operator should check the detachable power supply cord
condition. The equipment should not be operated if

the power
supply cord is cracked or broken. Any obvious damage to the
enclosure (from a drop or fall) should be checked by service
personnel for loose or damaged parts inside.

CAUTIONS: Replace the power cord only with one of the same

type and rating. The minimum power ratings are stated on the
rear panel.

The power cord set supplied with your Pump Drive meets the
requirements of the country where you purchased the Pump
Drive. If you use the Pump Drive in another country, you must use
a power cord set that meets the requirements of that country.

4-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 4

Maintenance

Fuse Replacement

A

B

C

D

Item Description

A I/O Receptacle DB-25 Pin

B IEC Power Entry Module / Line Cord
C T3.15A (5 × 20 mm) Fuse – Do Not

Substitute

D Power Switch – All settings are

retained in memory

1. Place the power switch in the off position.

2. Disconnect the AC power input line cord from the receptacle.

3. Remove and check the fuse and replace if defective.

Figure 4-1. Fuse Replacement

Cleaning

Keep the drive enclosure clean with mild detergents. Do not immerse or
use excessive fluid when cleaning.

Symptom Cause Remedy

Motor does not rotate, No Power. 1. Check fuse and replace,
Display does not light. if necessary.

2. Check that unit is plugged
into a live line.

3. Check connection of
power cord.

4. Check the line cord for
continuity and replace
if defective.

5. Return for servicing.

Motor does not rotate. Defective Remote Control or 1. Place power switch in
Display lights. Setting Error. OFF position.

2. Check that remote cable
connector is fully inserted
into the receptacle.

3. Reapply power.

4. If motor still does not rotate,
select remote control in Main
Menu or Setup Menu and
verify settings.

5. Return to Mode screen and
verify icon shows
Remote Control Mode.

6. See

Remote Control Mode

in

this manual for further details.

START/STOP Mode “ON” with- 1. See

Remote Control Mode

in

out an input at I/O Connector. this manual for further details.

2. Select “OFF” in START/STOP
Menu to run without an input
at the I/O Connector cable.

Motor does not rotate. Motor brushes worn. 1. Disconnect power to
Display lights. drive by removing IEC line

cord.

2. Remove 8 screws in bottom.

3. Carefully lift off housing
without removing wiring.

4. Remove cap on brush holder
and inspect brushes.

5. Replace brushes if shorter
than 7.6mm (0.3 in) from base
to point.

Digital Gear Pump Drive Operating Manual 5-1Masterflex

Section 5 Troubleshooting

Troubleshooting Chart

5-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 5

Troubleshooting

Error #2 Motor Overspeed

Description: The drive has exceeded commanded speed value.

Error Condition(s): The motor has exceeded the commanded speed value

by 20%.

Actions: Drive will stop immediately. Verify load is correct and power

cycle drive. If error persists consult factory.

Error #3: Instantaneous Over-Current

Description: Motor is drawing too much current for a short duration

of time.

Error Condition(s): The motor current is above 4.0 A peak.

Actions: Drive will stop immediately. Verify that Pump Head is not

binding and that the load is not above recommended
maximum load. If error persists consult factory.

Error #4: Bad Flash Checksum

Description: Run-time checksum (checked at power-on) contains a

bad checksum value.

Error Condition(s): Checksum is checked at power-on for an invalid value.

Actions: Power cycle the drive. If error persists consult factory.

Error #7: Bad EEPROM Checksum (Settings)

Description: Bad EEPROM checksum on parameter values and settings, or

its data is out of range.

Error Condition(s): 1) Checksum value in EEPROM does not match

calculated value.

2) Data in EEPROM is out of range.

Actions: Error will be cleared after 10 seconds and parameters will be

reset to default values. If error persists consult factory.

Error #8: Bad EEPROM Checksum (Factory Cal)

Description: Bad EEPROM checksum for Factory Cal

Error Condition(s): 1) Checksum value in EEPROM does not match

calculated value.

2) Data in EEPROM is out of range.

Actions: Error will be cleared after 10 seconds and parameters will be

reset to default values. If error persists consult factory.

Error Definitions

Digital Gear Pump Drive Operating Manual 5-3Masterflex

Section 5

Troubleshooting

Error #9: EEPROM Write Verification Error

Description: Data written to EEPROM does not match.

Error Condition(s): Data values do not match.

Actions: Error will be cleared after 10 seconds and parameters will

be reset. If error persists consult factory.

Error #10: Bus Over Voltage

Description: The measured AC voltage reported by the drive is too high.

Error Condition(s): The drive voltage is above 260V AC.

Actions: The pump will stop immediately, check the supply line

voltage. If error persists consult factory.

Error #11: Bus Under Voltage

Description: The measured AC voltage reported by the drive is too low.

Error Condition(s): The drive voltage is below 90V AC.

Actions: The pump will stop immediately, check the supply line

voltage.

NOTE: This error when displayed during power down is considered

normal and proper. If error persists consult factory.

Error #12: Motor Stall / Motor Under Speed

Description: The motor was commanded to run, but has either slowed

down significantly or has stopped.

Error Condition(s): The motor speed is below 95% of the desired speed for too

long a period of time.

Actions: The motor will be commanded to stop. Verify the pump turns

freely and is not binding. If error persists consult factory.

Error #14: Ambient Over Temperature

Description: The motor control board is overheating.

Error Condition(s): The temperature value from motor control board is above

given threshold value.

Actions: The pump will stop immediately. Verify that the ambient air

temperature is less than 104° F (40° C). Verify the pump
turns freely and that there is no restriction of air flow.
If error persists consult factory.

Error Definitions

(continued)

5-4 Digital Gear Pump Drive Operating Manual Masterflex

Section 5

Troubleshooting

Error #15: Motor Feedback Fault

Description: Communications to the motor control board is not correct,

has disappeared, or some other communications fault.

Error Condition(s): No data coming back over the serial port from the motor

control board.

Actions: The drive will attempt to stop the pump. Power cycle drive.

If error persists consult factory.

Error #16: Invalid Interrupt or Address

Description: Software jumps to an invalid address, invalid interrupt,

or other abort/exception (i.e., Data Abort Exception).
This may occur due to invalid pointer references, or ram
memory corruption, etc.

Error Condition(s): These are handled by an Abort Exception/Interrupt within the

CPU and should branch out to their respective exception
handler functions.

Actions: Power cycle the drive to reset error. If error persists

consult factory.

Error Definitions

(continued)

Section 6 Accessories and Gear

Pump Heads

1. Footswitch w/DB-25 male 07523-92

2. Connector DB-25 male 07523-94

3. Remote Cable assembly, DB-25 connector 07523-95
with 25 ft (7.9m) cable w/stripped ends

4. Dispensing Wand DB-25 male 07523-97

Digital Gear Pump Drive Operating Manual 6-1

Masterflex

Cavity Style Pump Heads

74012-61 T23 GAT-T23 0.092 75 PPS 316 SS EPDM NO
07002-17 N21 GJ-N21 0.316 80 316 SS PTFE PTFE YES
74012-11 N21 GJ-N21 0.316 80 316 SS PPS PTFE NO
73011-00 N21 GJ-N21 0.316 80 316 SS PEEK PTFE NO
73011-02 N21 GJ-N21 0.316 80 316 SS PEEK PTFE YES
07002-23 N23 GJ-N23 0.64 80 316 SS PTFE PTFE YES
07001-80 N23 GJ-N23 0.64 80 316 SS PPS PTFE YES
73011-08 N23 GJ-N23 0.64 80 316 SS PEEK PTFE NO
74012-21 N23 GJ-N23 0.64 80 316 SS PPS PTFE NO
73011-10 N23 GJ-N23 0.64 80 316 SS PEEK PTFE YES
07001-40 N25 GJ-N25 0.91 80 316 SS PTFE PTFE YES
73011-16 N25 GJ-N25 0.91 80 316 SS PEEK PTFE NO
74012-31 N25 GJ-N25 0.91 80 316 SS PPS PTFE NO
73011-18 N25 GJ-N25 0.91 80 316 SS PEEK PTFE YES

Suction Shoe Style Pump Heads

07002-25 X21 GA-X21 0.017 75 316 SS Graphite PTFE NO
07002-26 V21 GA-V21 0.042 75 316 SS Graphite PTFE NO
07002-27 V23 GA-V23 0.084 75 316 SS Graphite PTFE NO
07002-14 T23 GA-T23 0.092 75 316 SS PPS PTFE NO
73003-14 T23 GA-T23 0.092 75 316 SS PEEK PTFE NO
73004-00 P23 GB-P23 0.261 125 316 SS PEEK Viton YES
74012-51 P23 GB-P23 0.261 125 316 SS PEEK Viton NO
07003-02 P25 GB-P25 0.58 25 316 SS PPS Viton YES
73004-02 P25 GB-P25 0.58 125 316 SS PEEK VIton YES
73004-04 P35 GB-P35 1.17 125 316 SS PEEK VIton YES
07003-04 P35 GB-P35 1.17 125 316 SS PPS Viton YES

Cat. No. Gear Pump Disp. Max Diff. Wetted Int.

Set Head (mL/rev) pressure Parts

Bypass

Model (psi) Body Gears Seals

Table 3-5. Gear Pump Heads

Section 7 Specifications

Output

Speed: 36 to 3600 rpm
Torque output, Maximum: 30 oz-in (2kg•cm)
Speed regulation: Line ±0.1% F.S.

Load ±0.1% F.S.

Drift ±0.1% F.S.
Display: 128 x 64 LCD w/ LED Backlight
Remote outputs: Voltage speed output

(0–10V DC @ 1 k

Ω min)

Current speed output

(0–20 mA @ 0–600Ω)

Tach output

(60 to 6000Hz, 50% duty cycle,

1.67 Hz/rpm)

Motor running output

(N.O. & N.C. contact closure, 1A @ 28V DC)

Input

Supply voltage limits: 90 to 260 Vrms @ 50/60 Hz

(Universal Input) Single Phase Only
Current, max.: 1.9A @ 115 Vrms, or 1.6A @ 230 Vrms
Remote Inputs: STOP/START, CW/CCW, PRIME

(Contact closure)

Voltage input (0–10V DC @ 10 k

Ω),

±50V common mode range

Current input

(0–20 mA or 4–20mA @ 250

Ω),

±50V common mode range

Digital Gear Pump Drive Operating Manual 7-1Masterflex

Construction

Dimensions (L × W × H): 10.5 in × 8 in × 8 in

(267 × 203 × 203 mm)
Weight: 15.5 lb (7.0 kg)
Enclosure Rating: IP 33 per IEC 60529

Environment

Temperature, Operating: 0° to 40°C (32° to 104°F)
Temperature, Storage: –25° to 65°C (–13° to 149°F)
Humidity (non-condensing): 10% to 90%
Altitude: Less than 2000 m
Pollution Degree: Pollution Degree 2

(Indoor use — lab, office)
Chemical Resistance: Exposed material is aluminum,

ABS plastic and vinyl

Compliance: Conforms to ANSI/UL Std 61010-1

Certified to CAN/CSA Std C22.2

No. 61010-1. This product has been tested

to the requirements of CAN/CSA-C22.2

No. 61010-1, second edition, including

Amendment 1, or a later version of the

same standard incorporating the same

level of testing requirements.

(For CE Mark):

EN61010-1 (EU Low Voltage Directive) and

EN61326 (EU EMC Directive)

7-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 7

Specifications

Section 8 Warranty, Product Return and

Technical Assistance

This product is warranted against defects in material or workmanship, and
at the option of the manufacturer or distributor, any defective product will
be repaired or replaced at no charge, or the purchase price will be refunded
to the purchaser, provided that: (a) the warranty claim is made in writing
within the period of time specified on the warranty card, (b) proof of
purchase by bill of sale or receipted invoice is submitted concurrently with
the claim and shows that the product is within the applicable warranty
period, and (c) the purchaser complies with procedures for returns set
forth in the general terms and conditions contained in the manufacturer's
or distributor's most recent catalog.

This warranty shall not apply to: (a) defects or damage resulting from: (i)
misuse of the product, (ii) use of the product in other than its normal and
customary manner, (iii) accident or neglect, (iv) improper testing,
operation, maintenance, service, repair, installation, or storage, (v)
unauthorized alteration or modification, or (b) post-expiration dated
materials.

THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
PURCHASER, AND THE MANUFACTURER AND DISTRIBUTOR
DISCLAIM ALL OTHER WARRANTIES, WHETHER EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING WITHOUT
LIMITATION, WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. NO EMPLOYEE,
AGENT, OR REPRESENTATIVE OF THE MANUFACTURER OR
DISTRIBUTOR IS AUTHORIZED TO BIND THE
MANUFACTURER OR DISTRIBUTOR TO ANY OTHER
WARRANTY. IN NO EVENT SHALL THE MANUFACTURER OR
DISTRIBUTOR BE LIABLE FOR INCIDENTAL, INDIRECT,
SPECIAL OR CONSEQUENTIAL DAMAGES.

The warranty period for this product is two (2) years from date of purchase.

Digital Gear Pump Drive Operating Manual 8-1Masterflex

Warranty

8-2 Digital Gear Pump Drive Operating Manual Masterflex

Section 8

Warranty, Product Return and
Technical Assistance

To limit charges and delays, contact the Manufacturer or authorized seller for
authorization and shipping instructions before returning the product, either
within or outside of the warranty period. When returning the product, please
state the reason for the return. For your protection, pack the product
carefully and insure it against possible damage or loss. Any damages resulting
from improper packaging are your responsibility.

If you have any questions about the use of this product, contact the
Manufacturer or authorized seller.

Product Return

Technical Assistance

US & Canada only

Toll Free 1-800-MASTERFLEX | 1-800-637-3739

Outside US & Canada

1-847-549-7600 | 1-847-381-7050

*EN809 manufactured by:

Cole-Parmer Instrument Company
28W092 Commercial Avenue, Barrington, IL 60010
[e-mail] | www.masterflex.com

®
