USER MANUAL — MW60 WIRELESS OVER EAR HEADPHONES
1
SOUND TOOLS FOR CREATIVE MINDS
At Master & Dynamic our obsession is the interaction between
sound and creativity. Our passion is building beautifully designed,
technically sophisticated sound tools for creative minds.
Our MW60 Wireless Over Ear Headphones are our latest and most
advanced modern thinking cap; a tool to help you focus, inspire and
transport your mind.
2 3
EN
TECHNOLOGY MEETS SOPHISTICATION
EN
Our intuitive controls afford an elegant, tactile experience. Weight
distribution, fit and comfort are paramount. Our patent-pending antenna
provides best-in-class signal range for Bluetooth
®
connectivity distance.
4 5
A RICH, WARM SOUND
We sought a rich, warm sound signature from our custom 45mm
neodymium drivers. An expansive soundscape that perfectly
captures the exceptional detail that well recorded music has to
offer. Our tuning is designed to accommodate a diversity of tastes
and musical genres.
6 7
EN
DESIGNED FOR DECADES OF USE
EN
Our headbands are constructed with premium grain cowhide on
the exterior surface and lined with a soft lambskin. The ear pads
are made of memory foam, wrapped in lambskin, providing superior
comfort and breathability. Areas subject to heavy wear, such as the
ear pads, are built to last and be easily replaced as needed.
All high strain areas utilize stainless steel components. Our
innovative all-aluminum antenna enables maximum Bluetooth
®
range, while incorporating an elegant design element. All metals
are anodized or PVD coated, not painted.
8 9
OVERVIEW
EN
10
1
Premium Grain Leather
Headband with Lambskin
Interior
2
Removable/Replaceable
Memory Foam Ear Pads
1
R
L
6
with Lambskin Covering
3
Forged Aluminum Components
4
3.5mm Passive Audio Input
Stainless Steel Hinge
6
Premium Grain Leather Inlay
7
Micro USB Input
8
Machined Aluminum Antenna
9
Omnidirectional Microphone
10
Headphone Controls (see
11
pages 14 – 18 for details)
5
2
5
Stainless Steel Adjustment Arm
SPECS
9
3
Dimensions
200mm x 185mm x 50mm
7
Weight
345g
Bluetooth
Bluetooth
®
Profile
®
4.1 with AptX
®
10
11
11
8
4
Impedance
32 ohms
Drivers
45mm Neodymium
High-Performance Drivers
11
ADJUSTABILITY | FIT | COMFORT
Adjust earcup post
to find optimal fit.
Rotates for comfort
around neck.
Folds for compact storage.
12 13
EN
ENFUNCTIONS (AUDIO + TELEPHONE)
PASSIVE AUDIO
EN
vol+
vol-
Multi Function Button
(MFB)
14
Audio
Telephone
Factory
Reset
Play/Pause
Vol up
Vol down
Next track
Previous
MFB
vol +
vol –
vol + (≥2sec)
vol – (≥2sec)
track
Answer call
End call
Ignore call
Digital
MFB
MFB
MFB (≥2sec)
MFB (≥2sec)
assistant /
voice dial
Hold down vol+ and vol-
(≥4 seconds)
•
Plug 3.5mm audio plug into
headphone audio input to
engage passive audio
•
Headphone powers off
when audio cable is
plugged in
M&D
••Audio will work even if battery
is depleted
Microphone is disabled during
passive mode
M&D
15
TURN ON AND CHARGE
•
To turn on the MW60 slide the switch
to the middle position.
•
Each time you turn on the headphone
the battery status will be displayed. To
recall battery status, slide switch to
for less than 2 seconds.
The headphone will automatically
•
search for previously connected
devices. A solid light indicates you
are connected. If no connection is
made after 1 minute, the headphone
will enter deep-sleep mode. Cycle
power switch to awaken.
16 17
Low Battery
Med Battery
Full Battery
Connected
ON
Charging
• •
Plug in the micro USB
connector and connect to
a USB port to charge.
The headphone turns off
when the micro USB is
plugged in. Avoid using the
device while it is charging
•
A solid orange light
indicates charging and a
solid green light indicates
a full charge when the USB
cable is connected.
Charging Full Charge
EN
ENPAIRING
PAIRING TO 2 DEVICES
EN
Pairing
Connected
18
•
Hold in position for 2 seconds,
light will pulse when headphone is
in pairing mode.
Access Bluetooth
•
®
settings
on your source device. Locate
MW60 and connect. A solid light
indicates you are connected.
If no connection is made after 1 minute,
the headphone will enter deep-sleep mode.
Cycle power switch to awaken.
How to pair with two devices
1
Enter pairing mode
2
Connect to device 1
3
Enter pairing mode again
4
Device 1 will disconnect
5
Connect to device 2
6
Turn headphone off
7
Turn headphone on, headphone
will automatically connect to
device 1 and 2 simultaneously
8
Pause one device and play
from the other to swap
headphone connection
19
ACCESSORIES
EN
CHANGING/REMOVING EAR PADS
EN
RIGHT EARCUP
Canvas
Headphone Case
Leather
Cable Box
Canvas Pouch
20
Headphone Plug
Cable 01: Micro USB
Headphone Plug
M&D
Cable 02: 1.25m Straight Cable
Source Plug
M&DM&D
Source Plug
M&D
0
0
0
6
0
W
1
M
0
6
0
W
0
0
M
1
Serial Number
Ear pads are magnetized for easy removal/replacement. Reattach
ear pads by aligning the two guide posts on the earcup with the
guide holes on the inside of the ear pad. Simply hold the outside ring
of the ear pad and remove.
21
MAINTENANCE AND TROUBLESHOOTING
MAINTENANCE AND TROUBLESHOOTING
EN
Clean ear pads and
headphones with soft, slightly
damp cloth. Do not soak,
submerge or allow moisture
to enter near the drivers or
cable jacks. Ear pads and
cables can be purchased if
they are worn out at:
www.masterdynamic.com
Do not drop, sit on, or allow
the headphones to be exposed
to water, moisture, or
temperature extremes.
It is recommended that you
return your headphones to their
storage case when not in use.
To avoid damage, do not store
other items in the canvas case
along with your headphones.
CAUTION: Incorrectly rotating
or over rotating the earcups
can damage the headphones.
Temperature Range
Operate and store this product
within the temperature range
of -4°F to 113°F (-20°C to 45°C)
only. Charge the battery where
the temperature is between 41°F
and 104°F (5°C and 40°C) only.
The headphones and device
do not pair
1
Make sure the headphones
are not connected to the
charger. Cycle power switch
off and on.
Turn the Bluetooth
2
®
off, then
on again on the source device.
3
Turn off the Bluetooth® feature
on any other device that is
paired with the headphones.
4
Slide switch to and hold until
white light flashes.
5
Make sure “MW60" is selected
in the Bluetooth
®
device list
No audio or poor audio
quality from a connected
Bluetooth
Move the device closer to
•
the headphones, physical
®
device
objects between the
headphone and the source
may obstruct the signal.
Try another music application
•
or try another track.
Try a different audio device.
•
• Factory reset
Hold down vol+ and vol- for
≥4 seconds. Red and white
light flashes four times
22 23
HEARING HEALTH AND FITNESS
Our ability to hear is amazing. Treat your ears like the precious tools
they are, and they will continue to provide you with exceptional data, as
well as a lifetime of incredible sonic experiences.
In general, do not listen “too loud or for too long,” and be attentive to
your own ears. Ringing, discomfort, or sensitivity to high frequencies
and treble may be a signal from your ears that you are pushing them to
their limits and causing damage.
As a general practice, find what seems to be your preferred listening
level and then adjust the volume down another 10% or more.
Surprisingly, your ears will attune to a slightly lower volume over time,
and what seems quiet at first can be perfect for longer listening periods.
If you are interested in tuning your ear to have a more refined sonic
palate, there are some apps and training programs you can find online.
24 25
EN
PREVENTION OF NIHL (NOISE INDUCED HEARING LOSS)
NIHL is a preventable condition caused by both one-time and
extended exposure to excessive decibel (dB) levels. This harm to
sensitive inner ear structures is irreversible and people of all ages
can be affected. Damage can happen in a single event or gradually
over time. One-time exposure to sounds louder than 110 decibels
and extended exposure to sounds over 85 decibels can cause harm.
Indicators of NIHL include hearing loss and tinnitus, a condition of
sensing constant ringing, buzzing or roaring. The NIDCD (National
Institute on Deafness and Other Communication Disorders) offers
this simple rule of thumb: avoid sound exposure that is “too loud,
too close or too long.” Here are some general references to sound
levels that occur in everyday life: refrigerator humming (45 dB);
normal conversation (60 dB); city traffic (85 dB); motorcycles
(95 dB); an MP3 player at full volume (105 dB); sirens (120 dB);
firecrackers (150 dB).
26 27
EN
WARRANTY AND CUSTOMER SERVICE
Master & Dynamic guarantees this product against defects in materials
or workmanship for a period of two years from the date of original
purchase from an authorized Master & Dynamic retailer or reseller.
Master & Dynamic will either repair or replace the defective product
at our discretion if the product is returned within the warranty period.
This limited warranty is in lieu of all other warranties, expressed
or implied, including, but not limited to, any implied warranty of
merchantability or fitness for a particular purpose.
Master & Dynamic shall have no liability of any kind for any direct,
indirect, incidental or consequential damages or expenses
that arise from the use of this product. Master & Dynamic does not
cover normal wear and tear, blown drivers, cut cords, bent jacks,
torn headbands, loss or theft. You will void this warranty if you
disassemble your headphones or expose them to excessive moisture.
If you believe this product is defective within the warranty period,
contact us via our support page at www.masterdynamic.com/support. Once
your warranty is verified, you will be issued a return authorization and
instructions for return shipment. Proof of purchase may be required.
Products with unreadable or removed serial numbers will not be covered.
For questions regarding your product’s warranty, contact
Master & Dynamic Support at support@masterdynamic.com.
28 29
EN
FCC 2AGA7MW60
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. This equipment has been tested
and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
IC 20773-MW60
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following
two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne
doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
CAUTION
Danger of explosion if battery is incorrectly replaced
Replace only with the same or equivalent type
Battery shall not be exposed to excesive heat such as sunshine, fire, or the like
(1) To prevent possible hearing damage, do not listen at high volume levels for long periods.
(2) Fully understand user manual before use.
(3) Ensure your player at low volume levels or power off before you leaving.
KC
이 기기는 가정용으로 전자파적합등록을 한 기기로서 주거지역에서는 물론 모든 지역에서 사용할 수 있습니다.
(1)
(2) 당해 무선설비는 전파혼신 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없음。
JATE/MIC
018-150218
R
D15-0057018
T
Die Fer nbedienu ng und das Mik rofon wer den nur von de n Produkt en iPhone 3 GS oder spät er, iPad,
iPod Tou ch (2. G eneratio n oder späte r), iPod C lassic (12 0GB, 160G B) und dem i Pod Nano (4. Ge neration
oder sp äter) unter stütz t. Die F ernb edien ung wird auc h vom iPod Sh uffle (3. G eneratio n oder späte r)
unte rst ützt. Au dio wird von a llen Modell en des iPads o der iPods un terstü tzt.
"Mad e for iP od", "Made for i Phone" und "M ade for iPad " bedeu tet, das s ein elekt roni sche s Zubehör
dafü r entwick elt wurde b esonder s in Verbindu ng mit ei nem iPod, iP hone oder iP ad verwen det zu
werd en und dass e s vom Entwi ckle r zertif izier t wurde de n Stan dards von A pple zu ents prechen .
Appl e ist für das F unkt ionieren d es Geräts o der für dess en Einhalt en von Siche rheitss tandard s und
Regulierungen nicht verantwortlic h.
Il con trol lo remoto e i l micr ofono sono s upporta ti solo dai dis positiv i iPhone 3GS o s uccessi vo, iPad,
iPod t ouch (2a gen erazione o s uccessi va), iPod cl assic (120 GB, 160GB)e i Pod nano (4a g ener azione
o succ essiva) . Il contro llo re moto è suppo rtato dal d ispositi vo iPod shu ffle (3a ge nera zione o
succ essiva) . L’audio è supp ortato da t utti i mod elli di iPad e iP od.
Le dic itur e “Realizz ato per l’ iPod,” “Rea lizzato pe r l’iPhon e” e “Realizz ato per l’ iPad” sign ific ano che
un acc essorio el ettron ico è st ato proge ttato per c onnette rsi speci fic ament e a un iPod, un i Phon e
o un iPa d risp ettivam ente e che è st ato certi ficato d allo svilu ppat ore per sodd isfare gli s tandard
di pre stazioni A pple. App le non è respo nsabile pe r le operazi oni su quest o disposit ivo o per la su a
conf ormità agl i standar d di sicurez za e normat ivi.
O cont rolo remo to e o microf one são supo rta dos ap enas p elo iPh one 3GS ou po sterior, iPad , iPod
touc h (2ª geraç ão ou poster ior), iPod cl assi c (120 GB, 160 GB), e iPod nan o (4ª gera ção ou post erior).
O cont rolo remo to é suport ado pelo iPo d shuffl e (de 3ª ge raçã o ou poster ior). O áudio é su portado p or
todo s os modelos d e iPad e iPod.
“Fabr icado par a iPod,” “Fa bricado pa ra iPhone,” e “ Fabricad o para iPad ” signifi cam qu e um acessór io
elec trónico f oi conc ebido espe cificam ente para a l igação a iPo d, iPhone, o u iPad, res pectiva mente, e
que foi c ertifi cado pelo fa bricant e para sati sfazer os p adrões de d esen volv imento da A pple. A Appl e
não é re sponsáv el pela oper ação dest e disposit ivo ou pela su a conform idade com as n ormas de
segurança e regulamentares .
Designed and Developed by New Audio LLC
New York, NY 10001. Made in China.
© Copyright 2015 New Audio LLC. All rights reserved. Master & Dynamic,
the Stylized M logo and Sound Tools for Creative Minds are trademarks
of New Audio LLC. Patents Pending.
MW60-M-20151103
Loading...
