USER MANUAL — MM800 BOOM MIC

SOUND TOOLS FOR CREATIVE MINDS

At Master & Dynamic we are obsessed with the interaction between
sound and creativity. Our passion is building beautifully designed,
technically sophisticated sound tools for creative minds.

Engineered specifically for both our MH40 and MH30 headphones, the
Boom Mic instantly transforms your headphones into a professional
communications tool.

DESIGNED FOR DAILY USE

We designed our Boom Mic to solve the challenge of communication
in the modern open workspace. Housing a unidirectional microphone in
an anodized aluminum body, the Boom Mic provides superior clarity. It
isolates your voice from environmental noise, ensuring your thoughts
and ideas are heard.

SPECS

Adjustable Hinge: Rotates 240°

Machined
Anodized
Aluminum

Unidirectional
Microphone

DIMENSIONS WEIGHT

21mm x 12mm x 145mm 25g

Microphone Ports:
Orient towards mouth

REMOTE

Remote for use with most smartphones, tablets, and computers with a
standard 3.5mm headphone jack.

Answer/End button:
Press 1x to answer
a call, or to hang up.

Some phones may require
quickly pressing 2x, or
pressing and holding,
to answer or end a call.

Serial Number

OPERATION

To operate the Boom Mic,
remove existing cable
from your MH40 or MH30
headphones and insert the
Boom Mic into the right or
left earcup jack and the

3.5mm plug into your device.

Adjust the Boom Mic up or
down and left or right for
optimal position and clarity.
The closer the microphone
is to your mouth, the greater
the clarity.

Troubleshooting:
If you can't hear the conversation
or people can't hear you, check
to ensure your plugs are fully
inserted into the headphone and
source device jacks.

If you continue to have trouble,
check to make sure cable has not
been damaged or severed.

Check to make sure you are
speaking into the correct face
of the microphone.

•

•

•

Microphone
Ports: Orient
towards mouth.

240°

WARRANTY AND CUSTOMER SERVICE

Master & Dynamic guarantees this product against defects in materials or
workmanship for a period of two years from the date of original purchase from
an authorized Master & Dynamic retailer or reseller. Master & Dynamic will
either repair or replace the defective product at our discretion if the product is
returned within the warranty period.

This limited warranty is in lieu of all other warranties, expressed or implied,
including, but not limited to, any implied warranty of merchantability or fitness
for a particular purpose.

Master & Dynamic shall have no liability of any kind for any direct, indirect,
incidental or consequential damages or expenses that arise from the use of this
product. Master & Dynamic does not cover normal wear and tear, cut cords,
bent jacks, loss or theft. You will void this warranty if you disassemble your Boom
Mic or expose it to excessive moisture.

If you believe this product is defective within the warranty period, contact us
via our support page at www.masterdynamic.com/support. Once your warranty
is verified, you will be issued a return authorization and instructions for return
shipment. Proof of purchase may be required. Products with unreadable or
removed serial numbers will not be covered.

For questions regarding your product’s warranty, contact
Master & Dynamic Support at [email protected].

131222

Designed and Developed by New Audio LLC
New York, NY 10001. Made in China.

© Copyright 2014 New Audio LLC. All rights reserved. Master & Dynamic,
the Stylized M logo and Sound Tools for Creative Minds are trademarks
of New Audio LLC. Patents Pending.

MM800-M-111714
