USER MANUAL — ME03 EARPHONES
1
SOUND TOOLS FOR CREATIVE MINDS
Our obsession is the interaction between sound and creativity. Our
passion is building beautifully designed, technically sophisticated
sound tools for creative minds.
Our earphones are designed to deliver our signature sound with a
refined appearance and thoughtful details, all in a compact format.
DESIGNED FOR DAILY USE
Our earphones are built from machined anodized aluminum and utilize
heavy-duty cables. We use custom 8mm neodymium drivers and
oxygen-free copper cables to deliver rich, warm sound. Our tuning is
designed to accommodate a diversity of tastes and musical genres.
We separated the microphone from the remote for increased vocal
clarity and reduced noise, removing the need to hold the remote while
you speak on the phone.
SPECS
MIC AND REMOTE
DIMENSIONS
23mm x 10mm
WEIGHT
25g
SOUND PROFILE
Noise-Isolating
IMPEDANCE
16 ohms
DRIVERS
8mm Neodymium
High-Performance Drivers
XXXXXXXXXXXX
Serial Number
The microphone is separated from the remote
and placed closer to your mouth for increased
vocal clarity and reduced noise.
volume up
Side button:
press 1x | to answer a call, or to hang up
press 1x | to play or pause audio
quickly press 2x | to skip forward
quickly press 3x | to skip backward
volume down
Remote for use with Apple products.
GETTING STARTED
M
S
XS
Choose an ear tip size included with the package that best fits your
ears. This helps ensure a comfortable fit and seal to achieve optimal
sound quality.
Attach the ear tip you have chosen to the earphone nozzle. Push the ear
tip past the rib on the nozzle so that there is no separation during use.
L
Gently insert the earphone into your ear for a good seal.
Earphones are marked left (L) and right (R). Be sure to insert
accordingly. When removing the earphone from your ear, pull
on the earphone. Never pull on the cable.
Canvas earphone case and leather box for storage.
TROUBLESHOOTING
No Sound:
•
Check to make sure the
earphone plug is fitted
completely into the audio
source.
Earphone Plug
•
Check source device
to make sure sound is
coming out.
•
If there is weak bass,
check ear tip seal or try
a different ear tip size.
•
If ear tips detach, check
diagram on how to firmly
attach ear tips to earphone
nozzle.
•
If there is low sound quality,
check for blockage in nozzle
by removing ear tips, do not
clean with sharp objects.
If you have lost or misplaced
your ear tips, replacements
are available to order on
our website:
www.masterdynamic.com
MAINTENANCE
•
When disconnecting the
earphones from the audio
source, avoid pulling on
the cable. Hold the plug at
the end of the cable and
pull to disconnect.
•
Store in a clean, dry
environment, preferably
in a box or canvas case.
•
To avoid damage, do not
store other items in the
canvas case along with
your earphones.
•
Do not drop, sit on, or
allow the earphones to
be exposed to water,
moisture, or temperature
extremes.
HEARING HEALTH AND FITNESS
Our ability to hear is amazing. Treat your ears like the precious tools
they are, and they will continue to provide you with exceptional data,
as well as a lifetime of incredible sonic experiences.
In general, do not listen “too loud or for too long,” and be attentive
to your own ears. Ringing, discomfort, or sensitivity to high
frequencies and treble may be a signal from your ears that you are
pushing them to their limits and causing damage.
As a general practice, find what seems to be your preferred
listening level and then adjust the volume down another 10% or
more. Surprisingly, your ears will attune to a slightly lower volume
over time, and what seems quiet at first can be perfect for longer
listening periods.
If your co-workers (3 – 10 feet away) are always singing along or
commenting on your music choices, chances are good you may be
listening too loud. See an audiologist to have your hearing tested.
If you are interested in tuning your ear to have a more refined
sonic palate, there are some apps and training programs you can
find online.
PREVENTION OF NIHL (NOISE INDUCED HEARING LOSS)
NIHL is a preventable condition caused by both one-time and
extended exposure to excessive decibel (dB) levels. This harm to
sensitive inner ear structures is irreversible and people of all ages
can be affected. Damage can happen in a single event or gradually
over time. One-time exposure to sounds louder than 110 decibels
and extended exposure to sounds over 85 decibels can cause harm.
Indicators of NIHL include hearing loss and tinnitus, a condition of
sensing constant ringing, buzzing or roaring. The NIDCD (National
Institute on Deafness and Other Communication Disorders) offers
this simple rule of thumb: avoid sound exposure that is “too loud,
too close or too long.” Here are some general references to sound
levels that occur in everyday life: refrigerator humming (45 dB);
normal conversation (60 dB); city traffic (85 dB); motorcycles
(95 dB); an MP3 player at full volume (105 dB); sirens (120 dB);
firecrackers (150 dB).
WARRANTY AND CUSTOMER SERVICE
Master & Dynamic guarantees this product against defects in
materials or workmanship for a period of two years from the date
of original purchase from an authorized Master & Dynamic retailer
or reseller. Master & Dynamic will either repair or replace the
defective product
at our discretion if the product is returned within the warranty
period.
This limited warranty is in lieu of all other warranties, expressed
or implied, including, but not limited to, any implied warranty of
merchantability or fitness for a particular purpose.
Master & Dynamic shall have no liability of any kind for any direct,
indirect, incidental or consequential damages or expenses that
arise from the use of this product. Master & Dynamic does not cover
normal wear and tear, blown drivers, cut cords, bent jacks, loss or
theft. You will void this warranty if you disassemble your earphones
or expose them to excessive moisture.
If you believe this product is defective within the warranty period,
contact us via our support page at www.masterdynamic.com/support.
Once your warranty is verified, you will be issued a return
authorization and instructions for return shipment. Proof of
purchase may be required. Products with unreadable or removed
serial numbers will not be covered.
For questions regarding your product’s warranty, contact
Master & Dynamic Support at support@masterdynamic.com.
ME03-M-051614
The r emote and mic a re suppor ted only by iP hone 3GS or l ater, iPad, iPo d touch (2n d gener ation or la ter),
iPod c lassic (12 0GB, 160GB) , and iP od nano (4th gen eration or l ater). The r emote is sup ported by i Pod
shuf fle (3rd ge neration o r later). Aud io is suppor ted by all iPa d and iPod mod els.
“Mad e for iP od,” “Made fo r iPhone,” and “ Made for iP ad” me an that an ele ctronic a ccessor y has been
desig ned to conne ct specif ically to i Pod, iPho ne, or iP ad, respe ctively, a nd has been ce rtifie d by the
deve loper t o meet Appl e perform ance stan dards. Ap ple is not re sponsible f or the oper ation of thi s device
or its c omplianc e with safe ty and reg ulat ory stand ards.
Designed and Developed by New Audio LLC
New York, NY 10001. Made in China.
© Copyright 2014 New Audio LLC. All rights reserved. Master & Dynamic,
the Stylized M logo and Sound Tools for Creative Minds are trademarks
of New Audio LLC. Patents Pending.
212038
