Page 1
Page 2
TABLE OF CONTENTS
SPECIFICATIONS 4
SAFETY GUIDELINES 5–14
KEY PARTS DIAGRAM 15
OPERATING INSTRUCTIONS 16–25
MAINTENANCE 25–27
EXPLODED VIEW 28
PARTS LIST 29–30
WARRANTY 31–32
3
IMPORTANT:
Read and understand this instruction manual
thoroughly before using the product. The manual
contains important information for your safety as
well as operating and maintenance advise.
Keep this instruction manual for future use. Should
thisproduct be passed on to a third party, then this
instruction manual must be included.
NOTE:
If any parts are missing or damaged, or if you have
any questions, please call our toll-free helpline at
1-800-689-9928.
E176989
JD1903U
Page 3
4
SPECIFICATIONS
SPECIFICATIONS
Motor 120V AC, 60 Hz
Amperage 15A
Speed 3800 RPM
(no load)
Disc
14"
(35.6 cm)
Arbor 1"
(2.5 cm)
Maximum
workpiece size
Vise mitre gauge to front Vise mitre gauge to rear
5⅝x3⅝" deep (14.3x9.2 cm)
Rectangular section
9x3" deep (22.9x7.6 cm)
Rectangular section
4¾" (12.1 cm) Round pipe 4½" (11.4 cm) Round pipe
Pivoting fence 0– 45º, right & left
Weight 34 lb
(15.5 kg)
GENERAL SAFETY WARNINGS
WARNING: Before using this tool or any of its accessories, read
this manual and follow all safety rules and operating instructions. The
important precautions, safeguards and instructions in this manual are not
meant to cover all possible situations. It must be understood that common
sense and caution are factors that cannot be built into the product.
This instruction manual includes the following:
• General safety rules • Operation
• Specic safety rules and symbols • Maintenance
• Functional description • Accessories
• Assembly
EYE, EAR & LUNG PROTECTION
WARNING: ALWAYS WEAR EYE PROTECTION THAT
CONFORMS
WITH CSA Z94.3 OR ANSI SAFETY STANDARD
Z8 7.1
FLYING DEBRIS can cause permanent eye damage.
Prescription eyeglasses ARE NOT a replacement for
proper eye protection.
WARNING: Non-compliant eyewear can cause serious
injury if broken while operating a power tool.
WARNING: Use hearing protection, particularly during
extended periods of operation of the tool, or if the
operation is noisy.
WARNING: Wear a dust mask that is designed to be
used when operating a power tool in a dusty
environment.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
!
!
SAFETY GUIDELINES
5
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 4
6
7
WARNING: Dust that is created by power sanding, sawing,
grinding, drilling, and other construction activities may contain
chemicals that are known to cause cancer, birth defects, or other genetic
abnormalities. These chemicals include:
• Lead from lead-based paints
• Crystalline silica from bricks, cement, and other masonry products
• Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to
how often this type of work is performed. In order to reduce exposure to
these chemicals, work in a well-ventilated area, and use approved safety
equipment, such as a dust mask that is specically designed to lter out
microscopic particles.
ELECTRICAL SAFETY
WARNING: To avoid electrical hazards, re hazards or damage to
the tool, use proper circuit protection.
This tool is wired at the factory for 120V AC operation. It must be
connected to a 120V AC, 15 A circuit that is protected by a time-delayed
fuse or circuit breaker. To avoid shock or re, replace power cord
immediately if it is worn, cut or damaged in any way.
POWER TOOL SAFETY
WARNING: Read all safety warnings and all instructions. Failure
to follow the warnings and instructions may result in electric shock, re
and/or serious injury.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
!
!
SAFETY GUIDELINES
SAFETY GUIDELINES
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks,
that may ignite the dust or fumes.
Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk of electric shock.
Avoid bodily contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Using a cord suitable for outdoor use reduces the risk of
electric shock.
If operating a power tool in a damp location is unavoidable, use a supply
protected by ground fault circuit interrupter (GFCI). Use of a GFCI
reduces the risk of electric shock.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 5
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious
personal injury.
Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes,
hard hat, or hearing protection used for appropriate conditions will
reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the Off
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your
nger on the switch or energizing power tools that have the switch
on invites accidents.
Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power
tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewelry or long hair can be caught in moving parts.
If devices are provided for the connection of dust-extraction and
dust-collection facilities, ensure these are connected and properly
used. Dust-collection can reduce dust-related hazards.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
job. The correct power tool will do the job better and safer at the
rate for which it was designed.
Do not use the power tool if the switch does not turn it On and
Off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow
people unfamiliar with the power tool or these instructions to
operate the power tool. Power tools are dangerous in the hands of
untrained users.
Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other conditions that
may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
Use the power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
dierent from those intended could result in a hazardous situation.
Hold power tools by insulated gripping surfaces when performing
an operation where the cutting tool may contact hidden wiring or
its own cord. Contact with a “live” wire will make exposed metal
parts of the tool “live” and shock the operator.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
8
9
model no. 055-6701-6 contact us 1-800-689-9928
I
SAFETY GUIDELINES
SAFETY GUIDELINES
Page 6
SERVICE
Have your power tool servised by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
SPECIFIC SAFETY RULES
WARNING: Know your chop saw. Do not plug the chop saw into
the power source until you have read and understood this manual. Learn
the tool’s uses and limitations, as well as the specic potential hazards
related to this tool. Following these rules will reduce the risk of electric
shock, re or serious injury.
Always wear eye protection. Any power tool can throw foreign objects
into your eyes and cause permanent eye damage. ALWAYS wear safety
goggles (not glasses) that comply with CSA requirements or ANSI safety
standard Z87.1. Everyday glasses have only impact-resistant lenses. They
ARE NOT safety glasses.
WARNING: Glasses or goggles not in compliance with CSA Z94.3
or ANSI Z87.1 could cause serious injury when they break.
WARNING: Always wear hearing protection and a dust mask. Use
the tool only in a well-ventilated area. Using personal safety devises and
working in a safe environment reduces the risk of injury.
DANGER: Always unplug the tool from the power source before
changing the cutting disc or when cleaning the tool.
DANGER: Never place your hands or ngers near the cutting disc
while the tool is running. Severe injury will result.
DANGER: Never install a saw blade on this tool. It is designed
ONLY for use with abrasive cut-off discs.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
!
! !
!
!
!
Use this chop saw for cutting steel only. Cutting ceramic materials will
create excessive dust and cause damage to the motor.
Always use a dust mask along with safety goggles when operating the
chop saw.
Always use hearing protection when operating the chop saw.
Do not wear gloves, neckties or loose clothing.
Do not cut material too small to be securely held in the vise.
Always keep your hands out of the path of the cut-o disc. Avoid awkward
hand positions where a sudden slip could cause your hand to move into
the path of the cut-o disc.
Secure the workpiece. Use the clamping system provided with the chop
saw. It is safer than using your hand.
Make sure there are no foreign objects in the part of the workpiece to be
cut.
The cut-o disc must be securely attached as described in this manual
before connecting the tool to the power source. Failure to do so will
increase the risk of serious injury if the cut-o disc shatters or comes
loose.
Make sure the guard is installed and in proper working order before
operating the chop saw.
Cut-o discs must be stored in a dry location to prevent deterioration.
Before attaching the cut-o disc, inspect it for visible defects. If cracked,
chipped or warped, do not install it.
Do not over tighten the clamp nut on the cut-o disc. Excessive tightening
may cause the disc to crack and possibly shatter during operation.
SAVE THESE INSTRUCTIONS FOR REFERENCE.
10
11
model no. 055-6701-6 contact us 1-800-689-9928
I
SAFETY GUIDELINES
SAFETY GUIDELINES
Page 7
Never turn the chop saw On with the cut-o disc touching the work
surface.
Use only cut-o discs in compliance with ANSI Standard B7.1 and rated for
a speed greater than 3800 RPM.
Do not use the chop saw if the disc flanges or cap screw are missing or
improperly installed.
Dust and abrasive materials should not be allowed to build up in the
workshop. Hot metal sparks could start a re.
Do not remove the soft paper in the centre of the cut-o disc.
Do not alter or enlarge the centre hole of the cut-o disc, as this could
result in the disc shattering.
EXTENSION CORD SAFETY
WARNING: Keep the extension cord clear of the working area.
Position the cord so it will not get caught on the workpiece, tools or any
other obstructions while you are working with the power tool.
Make sure any extension cord used with this tool is in good condition.
When using an extension cord, be sure to use one of heavy enough gauge
to carry the current the tool will draw. An undersized cord will cause a
drop in line voltage, resulting in loss of power and overheating.
The table below shows the correct size to use according to cord length
and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
Be sure your extension cord is properly wired and in good condition.
Always replace a damaged extension cord or have it repaired by a
qualied electrician before using it. Protect your extension cord from
sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your power tools. This circuit must not
be less than 14 gauge wire and should be protected with either a
15 A time-delayed fuse or circuit breaker. Before connecting the power
tool to the power source, make sure the switch is in the O position and
the power source is the same as indicated on the nameplate. Running at
lower voltage will damage the motor.
!
MINIMUM GAUGE (AWG) EXTENSION CORDS (120 V USE ONLY)
Amperage rating Total length
More
than
Not more
than
25’
(7.5 m)
50’
(15 m)
100’
(30 m)
150’
(45 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not applicable
12
13
model no. 055-6701-6 contact us 1-800-689-9928
I
SAFETY GUIDELINES
SAFETY GUIDELINES
Page 8
WARNING: Some of the following symbols may appear on
the chop saw. Study these symbols and learn their meaning. Proper
interpretation of these symbols will allow for more efcient and
safer operation of this tool.
!
No. Description No. Description
1 “D” handle 8 17 mm wrench
2 Arbor lock 9 Base
3 Automatic guard 10 Safety chain
4 Cut-o disc 11 Swing arm
5 Vise mitre gauge 12 Motor end cap
6 Vise quick-release nut 13 Carrying handle
7 Vise adjustment handle 14 Trigger switch
14
15
SAFETY GUIDELINES
KEY PARTS DIAGRAM
V
Volts
A
Amperes
Hz
Hertz
W
Watts
kW
Kilowatts
Microfarads
L
Litres
Kg
Kilograms
H
Hours
N/cm
2
Newtons per square
centimetre
Pa
Pascals
OPM
Oscillations per
minute
Min
Minutes
S
Seconds
or AC
Alternating current
Three phase current
Three-phase
alternating current
with neutral
Read all safety
instructions
Direct current
SYMBOLS
No load speed
Alternating or direct
current
Class II construction
Splash-proof
construction
Watertight
construction
Protective grounding
at grounding
terminal, Class I tools
Revolutions or
reciprocations per
minute
Diameter
0
O position
Directional arrow
Warning symbol
Wear your safety
glasses
Wear hearing
protection
Wear your dust mask
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 9
OPERATING INSTRUCTIONS
CARRYING THE CHOP SAW
When carrying the chop saw from one
location to another, always lower the
swing arm (1) to its lowest position and
loop the lowest safety chain link (2) over
the pin (3). This will hold the blade and
swing arm in the “down” position for
easier lifting of the chop saw. Once the
safety chain has been placed over the
pin, carefully lift the chop saw using the
carrying handle.
SELECTING THE WORK SURFACE
It is important to place the chop saw on
a solid, flat work surface that will not
shift during operation of the chop saw.
Locating the chop saw near an electrical
outlet will eliminate the need for an
extension cord.
Hot metal sparks and sharp metal pieces
will damage the work surface to some
degree. Make sure you consider this fact
when selecting the work surface. A nonflammable surface, such as a metal bench,
will be less likely to be damaged during
cutting.
WARNING!
Always disconnect your chop saw from the
power source when carrying it to another
location, replacing the cut-o blade,
clamping material in the vise, adjusting the
guard, cleaning or when not in use.
Disconnecting the chop saw will prevent
accidental starting that could cause serious
personal injury.
WARNING!
The chop saw is very heavy. For safety in
carrying the chop saw, always lift it using
one hand on the carrying handle and the
other under the base.
SETTING THE DEPTH STOP
The maximum cut depth is controlled by
adjusting the depth stop.
1. Lift the swing arm (1) upward as far as
it will go.
2. Loosen the depth stop lock nut (2) by
turning it counter-clockwise using a
14 mm wrench.
3. Turn the depth stop screw (3) to raise
or lower it. Adjust until the cut-o
blade enters the base slot no more
than 3/16” (5 mm) when the swing
arm is fully lowered and contacts the
top of the depth stop screw.
4. When the depth stop screw is
correctly set, lock it in place by
tightening the lock nut clockwise.
WARNING!
Never place the chop saw near any
flammable liquids or items that can be
damaged by the sparks thrown by the chop
saw during cutting. The hot sparks can
ignite flammable liquids.
16
17
OPERATING INSTRUCTIONS
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 10
WARNING!
Always disconnect your chop saw from
the power source before checking the
automatic guard or the arbor cap screw.
CHECKING THE AUTOMATIC GUARD
The automatic guard must be checked to
ensure it is working properly.
1. Lift the guard (1) upward
approximately 3” (7.6 cm) and then
release it. If the guard is functioning
correctly, it will freely drop down to
its original position.
2. Lower the swing arm and cutting
blade assembly until the lower edge
of the guard (2) touches the chop saw
base. Continue to lower the swing
arm and cutting blade assembly. The
automatic guard should freely rise as
the cutting blade is lowered.
CHECKING THE ARBOR CAP SCREW
It is important to check the arbor cap
screw to make sure the cut-o blade is
fully tightened.
1. Lift swing arm fully upward as far as it
will go.
2. Lift the blade guard (1) fully upward
until it will stay in the upright position.
3. Press and hold the arbor lock (2) to
the right while rotating the cut-o
blade by hand.
NOTE: The guard should always rise and fall
freely when the swing arm is lowered and raised as
outlined in #1 & #2 above. If it does not, clean any
cuttings out from around the guard mechanism (3).
4. When the arbor lock engages the
arbor, tighten the arbor cap screw (3)
by turning it clockwise using the 17
mm wrench supplied.
5. When the arbor cap screw is fully
tightened, remove the wrench, release
the arbor lock and lower the blade
guard.
SETTING THE MITRE VISE ANGLE
The mitre vise can be set for cutting at
angles from 90°-45° either left or right.
1. Open the vise by turning the vise
adjustment handle (1) ve or six turns
counter-clockwise.
2. Loosen the mitre gauge cap screws
(2) by turning them counterclockwise using the 17 mm wrench
supplied.
3. Rotate the mitre gauge to the left or
right until the desired cutting angle
(3) lines up with the alignment mark
(4).
4. Tighten both mitre gauge cap screws
NOTE:
Do NOT over tighten the arbor cap screw,
as you could crack the hub of the cutting blade.
NOTE:
Always make a test cut on a scrap
workpiece to verify the mitre angle setting.
18
19
model no. 055-6701-6 contact us 1-800-689-9928
I
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Page 11
CUTTING 5"-7" (12.7-17.8 cm) WIDE
WORKPIECES
The vise is set up at the factory for
cutting workpieces up to 5
" (12.7 cm) in
width. This is the preferred set-up. If it is
necessary to cut workpieces between
5"- 7" (12.7-17.8 cm) in width, the mitre
gauge will have to be relocated on the
chop saw base.
1. Remove the front and rear mitre
gauge cap screws (1) using the 17 mm
wrench supplied.
2. Move the mitre gauge (2) back
approximately 1½" (3.81 cm) until the
hole and slot in the mitre gauge line
up with the next two holes (3) in the
chop saw base.
3. Reinstall and tighten the mitre gauge
cap screws in the two new holes (4).
OPERATING THE VISE QUICKRELEASE
The vise has a quick-release feature that
allows for making major adjustments
much quicker.
1. To operate the quick-release system,
turn the vise adjustment handle (1)
counter-clockwise two or three turns
to loosen the vise jaws.
2. Lift upward on the front of the quickrelease nut (2) to release the vise
screw (3).
3. While holding the quick-release nut
upward in the released position, pull
the vise adjustment handle toward
you to quickly open the vise.
4. To quickly close the vise, release the
quick-release nut and push the crank
away from you.
5. Use the crank to completely tighten
the vise on the workpiece.
ON/OFF SWITCH
To turn the chop saw On, squeeze the
switch trigger (1) until the chop saw
starts. To turn the chop saw O, release
the switch trigger.
REPLACING THE CUT-OFF DISC
The cut-o disc must be replaced when it
has become damaged in any way or it has
worn down to a diameter of less than
10" (25.4 cm).
NOTE: To cut workpieces between 7-9"
(17.8-22.9 cm) in width, locate the mitre gauge in
the back two holes (4) in the chop saw base.
WARNING!
Always make sure the workpiece is flat
against the chop saw base and securely
held in the vise before turning the saw On.
WARNING!
Always make sure the cut-o blade is NOT
touching the workpiece when the switch is
being turned On. Let the motor come to full
speed before beginning to cut.
WARNING!
Disconnect your chop saw from the power
source before attempting to change the
cut-o blade.
20
21
model no. 055-6701-6 contact us 1-800-689-9928
I
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Page 12
1. Lift the swing arm fully upward.
2. Lift the guard (1) fully upward until it
exposes the arbor cap screw (2).
3. Press and hold the arbor lock (3) to
the right while rotating the cut-o
blade by hand.
4. When the arbor lock engages the
arbor, loosen the arbor cap screw by
turning it counter-clockwise using the
17 mm wrench supplied.
5. Remove the arbor cap screw, the
small outer washer (4), the large outer
washer (5), the cut-o disc (6) and
large inner washer (7) from the arbor
(8).
6. Use a clean, dry brush or cloth to
carefully remove all cuttings from the
arbor and the motor housing.
7. Reinstall the washers, new cut-o disc
and arbor cap screw in the same order
in which they were removed.
8. Engage the arbor lock and tighten
the arbor cap screw using the 17 mm
wrench supplied.
9. Carefully rotate the cut-o disc
by hand to make sure it is rmly
tightened, that it is not damaged and
that it does not wobble.
10. With depth stop properly set and the
guard in the down position, turn the
switch On.
NOTES:
a) Make sure the LARGE outer surfaces of the large
and small washers are facing the cut-o disc.
b) Make sure the flats of the washer holes slide over
the matching flats of the arbor.
WARNING!
Reset the depth stop. The new blade will be
larger and will damage the work surface if
the depth stop is not readjusted.
NOTE:
If the cut-o disc wobbles or vibrates,
turn the switch O immediately. Recheck to make
sure the cut-o disc is installed correctly and that
the disc is not damaged.
WARNING!
Have you read GENERAL SAFETY
WARNINGS, POWER TOOL SAFETY,
SPECIFIC SAFETY RULES, EXTENSION
CORD SAFETY and SYMBOLS on pages
5-14 of this instruction manual? If not,
please do it now before you operate this
chop saw. Your safety depends on it!
Every time you use the chop saw you
should verify the following:
1. Cord is not damaged.
2. Cut-o disc is correct for the type of
material being cut.
3. Cut-o disc is in good condition and
securely tightened onto the arbor.
4. Safety glasses, dust mask and hearing
protection are being worn.
5. Guard is in good working order.
6. No ammable liquids are in the vicinity.
Failure to adhere to these safety rules can
greatly increase the chances of injury.
22
23
model no. 055-6701-6 contact us 1-800-689-9928
I
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Page 13
CUTTING METAL
1. Lift the swing arm fully upward as far
as it will go.
2. Adjust the mitre gauge as required.
3. Firmly lock the metal workpiece to be
cut in the vise.
4. Make sure you are wearing your safety
goggles, dust mask and hearing
protection.
5. Lower the cut-o blade until it
is about 1" (2.5 cm) above the
workpiece.
6. While holding the chop saw handle
rmly in your right hand, turn the
motor switch On.
7. Wait for motor to get up to its full
speed. Carefully lower the cut-o
blade until it contacts the workpiece.
8. Apply only slight pressure to the chop
saw handle as it begins to cut through
the workpiece. DO NOT apply too
much pressure to the handle, as this
will cause the motor to slow down,
slow the cutting action and damage
the motor.
NOTE: The cut-o disc MUST NOT be touching
the workpiece when the motor switch is turned On.
NOTE: Many sparks will be generated as soon as
the cut-o disc touches the workpiece.
WARNING!
Never touch the workpiece immediately
after a cut is completed. The metal in the
cutting area will be red hot and will cause
severe burns to your skin.
MAINTENANCE
9. When the cut-o disc has completely
cut through the workpiece, release
the trigger switch immediately. Wait
for the motor to come to a complete
stop before lifting the cut-o disc
away from the workpiece.
REPLACING CARBON MOTOR
BRUSHES
The carbon motor brushes will wear
down and require replacing. The time
intervals between replacements will vary
depending upon the type of materials
being cut and the hours of use. It is
recommended that the brushes be
checked after each 10 hours of use. When
the length of the carbon brush reaches
1/4” (6.35 mm), the brushes should be
replaced.
1. Use a #2 screwdriver and remove
four screws (1) from the motor end
cap (2).
2. Pull the motor end cap from the
motor housing (3).
3. Use needle-nose pliers to pull the
spade connector (4) from the spade.
4. Use needle-nose pliers to pull the
brush retainer spring (5) away from
the carbon brush (6).
WARNING!
Unplug the tool from the power source
before removing the motor end cap.
24
25
model no. 055-6701-6 contact us 1-800-689-9928
I
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
Page 14
5. While holding the brush retainer
spring o the carbon brush, pull the
carbon brush out of the brush holder
(7).
6. To install a new motor brush assembly,
reverse steps 3 through 6.
Replace the second carbon brush located
on the opposite side of the motor housing
using the procedure noted above. When
new motor brushes have been installed,
reinstall the motor end cap.
GENERAL MAINTENANCE
DO NOT use solvents when cleaning
plastic parts. Plastics are susceptible to
damage from various types of commercial
solvents and may be damaged by their
use. Use a clean cloth to remove dirt, dust,
oil, grease etc.
Keep the air vents cleared of any builtup dust to prevent the motor from
overheating. Remove accumulated dust
and debris regularly using a soft, DRY
brush.
DO NOT abuse power tools. Abusive
practices can damage the tool and the
workpiece.
LUBRICATION
All of the bearings in this tool are
lubricated with a sucient amount of
high-grade lubricant for the life of the unit
under normal conditions. Therefore, no
further lubrication is required.
WARNING!
Do not allow brake fluids, gasoline,
petroleum-based products, penetrating
oils, etc. to come into contact with plastic
parts. These substances contain chemicals
that can damage, weaken or destroy
plastic.
WARNING!
When servicing, use only identical
replacement parts. The use of any other
parts may create a hazard or cause damage
to the product.
WARNING!
DO NOT attempt to modify this chop saw
or create accessories. Any such alteration,
modication or unintended use is misuse
and could result in a hazardous condition
leading to possible serious injury. It will also
void the warranty.
WARNING!
Use safety goggles when using an air jet to
blow dust out of the chop saw.
26
27
MAINTENANCE
MAINTENANCE
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 15
WARNING!
When servicing, use only identical replacement parts. The use of any
other parts may create a safety hazard or cause damage to the chop
saw.
Any attempt to repair or replace electrical parts on this chop saw may
create a safety hazard unless repairs are performed by a qualied
technician. For more information, call the toll-free helpline, at
1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key
# Part # Description Qty
1 1280040002 Base 1
2 4050010046 Hex screw
M8X16
1
3 4040030004 Spring
washer
1
4 2030280012 Spark
damper
1
5 4050010038 Hex screw
M8X170
1
6 2030280005 Connecting
pipe cover
2
7 2050050034 Gemel
torsional
spring
1
8 2040320003 Connecting
pipe
1
9 4060090011 Hex lock
nut
1
10 2050050043 Hex screw
M10X25
1
11 2030280002 Little flange
plate
1
12 2030280001 Big flange
plate
2
13 3140160001 Rubber 1
14 1270030037 Movable
guard
1
Key
# Part # Description Qty
15 2040320001 Screw 2
16 4040010036 Flat washer 2
17 4060090001 Hex lock
nut M5
2
18 4020010024 Screw
M5X20
4
19 4040030003 Spring
washer
12
20 1270030036 Fixed guard 1
21 2040060001 Output
shaft
1
22 4010010110 6204-2RS
Bearing
1
23 3140060031 Rubber cup 1
24 2020240006 Gear
housing
cover
1
25 4120020009 Woodru
key
1
26 2040320007 Output gear 1
27 4100020021 Circlip for
shaft
1
28 4040040014 329-2RS
Bearing
1
28
29
EXPLODED VIEW
PARTS LIST
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 16
Key
# Part # Description Qty
29 2020240005 Gear
housing
1
30 2050090002 Spindle lock
spring
1
31 2030280011 Spindle lock 1
32 3120150005 Auxiliary
handle
1
33 4030010228 ST screw
5.9X70
2
34 4030010106 ST screw
3.9X19
4
35 4020010141 Screw
M5X35
4
36 4040010012 Flat washer 8
37 3160090092 Button
cover
1
38 1062020059 Switch 1
39 3120150003 Upper
handle
1
40 4030010096 ST screw
3.9X12
6
41 2030050003 Cable plate 1
42 1190030054 UL power
cable
1
43 3140010080 Cable guard 1
44 3120150002 Lower
handle
1
45 2040320002 Chain lock
pin
1
Key
# Part # Description Qty
46 2030020017 Flat washer 1
47 4040030013 Spring
washer
1
48 4060010006 M6 Net 1
49 4010010108 6202 2RS
Bearing
1
50 1040070003 Motor rotor 1
51 4010010132 6200-2RZ
Bearing
1
52 3150260001 Air
deflector
1
53 4030010227 ST screw
5X75
2
54 2030090033 Wire clamp 1
55 1050070003 Motor
stator
1
56 3012000003 Motor
housing
1
57 1230030021 Carbon
brush box
2
58 1230010137 Carbon
brush
2
59 2050020028 Volute
spring
2
60 4030010034 ST screw
2.9X16
4
61 4020010138 Screw
M5X45
4
62 3160010066 Motor cover 1
5-Year Limited Warranty
This Mastercraft Maximum product is guaranteed for a period
of 5 years from the date of original retail purchase against
defects in workmanship and materials, except for the following
component:
Component A: Accessories, which are guaranteed for a period
of 1-year from the date of original retail purchase against
defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if
returned to us with proof of purchase within the stated warranty period
and if covered under this warranty, will be repaired or replaced (with the
same model, or one of equal value or specication), at our option. We will
bear the cost of any repair or replacement and any costs of labour relating
thereto.
These warranties are subject to the following conditions and limitations:
a) a bill of sale verifying the purchase and purchase date must be
provided;
b) this warranty will not apply to any product or part thereof which is
worn or broken or which has become inoperative due to abuse, misuse,
accidental damage, neglect or lack of proper installation, operation
or maintenance (as outlined in the applicable owner’s manual or
operating instructions) or which is being used for industrial, professional,
commercial or rental purposes;
c) this warranty will not apply to normal wear and tear or to expendable
parts or accessories that may be supplied with the product that are
expected to become inoperative or unusable after a reasonable period of
use;
d) this warranty will not apply to routine maintenance and consumable
items such as, but not limited to, fuel, lubricants, vacuum bags, blades,
belts, sandpaper, bits, fluids, tune-ups or adjustments;
e) this warranty will not apply where damage is caused by repairs made or
attempted by others (i.e. persons not authorized by the manufacturer);
30
31
WARRANTY
PARTS LIST
model no. 055-6701-6 contact us 1-800-689-9928
I
Page 17
f) this warranty will not apply to any product that was sold to the original
purchaser as a reconditioned or refurbished product (unless otherwise
specied in writing);
g) this warranty will not apply to any product or part thereof if any part
from another manufacturer is installed therein or any repairs or alterations
have been made or attempted by unauthorized persons;
h) this warranty will not apply to normal deterioration of the exterior
nish, such as, but not limited to, scratches, dents, paint chips, or to any
corrosion or discolouring by heat, abrasive and chemical cleaners; and
i) this warranty will not apply to component parts sold by and identied
as the product of another company, which shall be covered under the
product manufacturer’s warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be
transferred. Neither the retailer nor the manufacturer shall be liable for any
other expense, loss or damage, including, without limitation, any indirect,
incidental, consequential or exemplary damages arising in connection with
the sale, use or inability to use this product.
Notice to Consumer
This warranty gives you specic legal rights, and you may have other
rights, which may vary from province to province. The provisions
contained in this warranty are not intended to limit, modify, take away
from, disclaim or exclude any statutory warranties set forth in any
applicable provincial or federal legislation.
Made in China
Imported by
Mastercraft Canda Toronto, Canada
M4S 2B8
Rev 1.7 11/06/2014
32
WARRANTY
model no. 055-6701-6 contact us 1-800-689-9928
I
Loading...
