MasterCraft 054-8296-0 Instruction Manual

INSTRUCTION
MANUAL

model no. 054-8296-0

IMPORTANT:

Please read this manual carefully before running this
heat gun and save it for reference.

CORDED HEAT GUN

headline bars

3

NOTE:

If any parts are missing or damaged, or if you have any questions, please call
our toll-free helpline at 1-800-689-9928.

SAVE THESE INSTRUCTIONS

This manual contains important safety and operating instructions. Read all
instructions and follow them with use of this product.

TABLE OF CONTENTS

TABLE OF CONTENTS

Technical specifications 4
General power tool safety warnings 5
Symbols 7
Key parts diagram 8
Accessories 9
Parts list 10
Operating instructions 12
Maintain tools with care 16
Troubleshooting 17
Warranty 18

headline bars

model no. 054-8296-0 | contact us 1-800-689-9928

4

TECHNICAL SPECIFICATIONS

TECHNICAL SPECIFICATIONS

Voltage: 120 V 60 Hz AC

Amps: 15 A

Temperature / flow rate: | = 25ºC (77ºF), 150 L/min

|| = 350ºC (662ºF), 300 L/min

||| = 550ºC (1022ºF), 500 L/min

Protection class:

/II

Cord length:

6’ (1.8 m)

Machine weight: 1 lb 14 oz (0.86 kg)

5

GENERAL POWER TOOL SAFETY WARNINGS

IMPORTANT SAFETY INSTRUCTIONS
WARNING!

Extreme care should be taken when stripping paint. The peelings, residue and vapours of paint may
contain lead, which is poisonous. Any pre-1977 paint may contain lead and paint applied to homes prior
to 1950 is likely to contain lead. Once deposited on surfaces, hand-to-mouth contact can result in the
ingestion of lead. Exposure to even low levels of lead can cause irreversible brain and nervous system
damage; young and unborn children are particularly vulnerable.

Before beginning any paint removal process you should determine whether the paint you are removing
contains lead. This can be done by your local health department or by a professional who uses a paint
analyzer to check the lead content of the paint to be removed. LEAD-BASED PAINT SHOULD ONLY BE
REMOVED BY A PROFESSIONAL AND SHOULD NOT BE REMOVED USING A HEAT GUN.

WARNING!

This product may contains lead, phthalate or other chemicals known to cause cancer, birth defects and
other reproductive harm. Please wash your hands after use.

Hidden areas such as behind walls, ceilings, floors, soffit boards and other panels may contain
flammable materials that could be ignited by the heat gun when working in these locations. The ignition
of these materials may not be readily apparent and could result in property damage and injury to
persons.

When working in these locations, keep the heat gun moving in a back-and-forth motion. Lingering or
pausing in one spot could ignite the panel or the material behind it.

WARNING!

Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference.

PERSONS REMOVING PAINT SHOULD BE FOLLOW THESE GUIDES:

1) Move the workpiece outdoors. If this is not possible, keep the work area well-ventilated. Open the windows
and put an exhaust fan in one of them. Be sure the fan is moving the air from inside to outside.

2) Remove or cover any carpets, rugs, furniture, clothing, cooking utensils and air ducts.

3) Place drop cloths in the work area to catch any paint chips or peelings. Wear protective clothing such as extra
work shirts, overalls and hats.

4) Work in one room at a time. Furnishings should be removed or placed in the centre of the room and covered.
Work areas should be sealed off from the rest of the dwelling by sealing doorways with drop cloths.

5) Children, pregnant or potentially pregnant women and nursing mothers should not be present in the work
area until the work is done and all clean up is complete.

6) Wear a dust respirator mask or a dual filter (dust and fume) respirator mask which has been approved
by the Occupational Safety and Health Administration (OSHA), the National Institute of Safety and Health
(NIOSH), or the United States Bureau of Mines. These masks and replaceable filters are readily available at
major hardware stores. Be sure the mask fits. Beards and facial hair may keep masks from sealing properly.
Change filters often. DISPOSABLE PAPER MASKS ARE NOT ADEQUATE.

headline bars

headline bars

model no. 054-8296-0 | contact us 1-800-689-9928

6

GENERAL POWER TOOL SAFETY WARNINGS

7) Use caution when operating the heat gun. Keep the heat gun moving as excessive heat will generate fumes
which can be inhaled by the operator.

8) Keep food and drink out of the work area. Wash hands, arms and face and rinse mouth before eating or
drinking. Do not smoke or chew gum or tobacco in the work area.

9) Clean up all removed paint and dust by wet mopping the floors. Use a wet cloth to clean all walls, sills
and any other surface where paint or dust is clinging. DO NOT SWEEP, DRY DUST OR VACUUM. Use a high
phosphate detergent or trisodium phosphate (TSP) to wash and mop areas.

10) At the end of each work session put the paint chips and debris in a double plastic bag, close it with tape or
twist ties and dispose of properly.

11) Remove protective clothing and work shoes in the work area to avoid carrying dust into the rest of the
dwelling. Wash work clothes separately. Wipe shoes off with a wet rag that is then washed with the work
clothes. Wash hair and body thoroughly with soap and water.

ADDITIONAL SAFETY RULES FOR YOUR HEAT GUN

1. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock,
this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

2. Always allow the heat gun to cool before storing. The hot nozzle can cause damage.

3. Never attempt to use the heat gun to dry animals, clothing or hair.

4. Dot leave the heat gun unattended when in use.

5. This product is designed for light domestic use only—it is not designed for industrial purposes. Even though
every care has been taken to make the heat gun safe, accidents can happen. By following this simple safety
guide, you can avoid serious accidents.

6. Be aware that heat may be conducted to combustible materials that are out of sight.

7. Double Insulation. When servicing, use only identical replacement parts.

8. To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Store indoors. Read
instruction manual before using.

9. If the supply cord is damaged, it must be replaced by special assembly available from a service agent.
