MasterCraft 054-7232-8 Instruction Manual

INSTRUCTION MANUAL

0.5A DETAIL SANDER

054-7232-8

2

0.5A DETAIL SANDER - 054-7232-80.5A DETAIL SANDER - 054-7232-8

TABLE OF CONTENTS

TECHNICAL SPECIFICATIONS 3

SAFETY GUIDELINES 4

DESCRIPTION 9

OPERATING INSTRUCTIONS 10

MAINTENANCE 12

TROUBLESHOOTING 13

PARTS LIST 14

WARRANTY 16

If any parts are
missing or damaged,
or if you have any
questions, please call
our toll-free helpline
at 1-800-689-9928.

Read and understand this instruction manual
thoroughly before using the product. It contains
important information for your safety as well as
operating and maintenance advice.

Keep this instruction manual for future use. Should
this product be passed on to a third party, then this
instruction manual must be included.

3 4

0.5A DETAIL SANDER - 054-7232-80.5A DETAIL SANDER - 054-7232-8

SAFETY GUIDELINES

TECHNICAL SPECIFICATIONS

MOTOR 120V 60 Hz 0.5A

NO LOAD SPEED 11000 OPM

WEIGHT (WITHOUT BATTERY) 1 lb 8 oz (0.68 kg)

PAD TYPE Hook and loop fastening system

NOISE LEVEL Lp:73.2dB(A); Lw: 84.2dB(A)

VIBRATION a

hi

=4.085 m/s2 ; k=1.5

WARNING!

Safety symbols in this Instruction Manual are used to flag possible dangers. The safety
symbols and their explanations require your full understanding. The safety warnings do not,
by themselves, eliminate any danger, nor are they substitutes for proper accident prevention
measures.

WARNING!

This Safety Alert Symbol indicates caution, warning, or danger. Failure to obey a safety
warning can result in serious injury to yourself or others. To reduce the risk of injury, fire, or
electric shock, always follow the safety precautions.

Know your tool

Carefully read this Instruction Manual and all labels affixed to the detail sander before using it. Keep this
available for future reference.

Important

This tool should only be serviced by a qualified service technician. For more information, call the toll-free
helpline at 1-800-689-9928.

READ ALL INSTRUCTIONS THOROUGHLY.

SAVE THESE INSTRUCTIONS.

General safety guidelines for power tools

WARNING!

Read all safety warnings and instructions. Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
