INSTRUCTION MANUAL
IMPACT WRENCH
054-1216-4
3
If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928.
Read and understand this instruction manual thoroughly before using the product. It contains important information for your safety as well as operating and maintenance advice.
Keep this instruction manual for future use. Should this product be passed on to a third party, then this instruction manual must be included.
TECHNICAL SPECIFICATIONS 4
SAFETY GUIDELINES 5–12
KEY PARTS DIAGRAM 13
ACCESSORIES 14
OPERATING INSTRUCTIONS 15–20
MAINTENANCE 21–22
EXPLODED VIEW 23
PARTS LIST 24
WARRANTY 25–26
TABLE OF CONTENTS
This symbol designates that this tool is listed by with both Canadian and U.S. requirements by Underwriters Laboratories.
IMPACT WRENCH 054-1216-4
61TN
E213739 JD2177U
IMPACT WRENCH 054-1216-4
4
!
!
!
5
Rating 120 V, 60 Hz, AC
Amperes 3.5 AMP
Impact speed 0–3,200 BPM
Torque 220 ft/lbs
Square drive 1/2”
Weight 4 lb 7 oz
(2.0 kg)
General safety warnings
WARNING: Before using this tool or any of its accessories, read this manual and
follow all Safety Rules and Operating Instructions. The important precautions, safeguards and instructions appearing in this manual are not meant to cover all possible situations. It must be understood that common sense and caution are factors which cannot be built into the product.
This instruction manual includes the following:
• General Safety Rules • Operation
• Specic Safety Rules and Symbols • Maintenance
• Functional Description • Accessories
• Assembly
EYE, EAR & LUNG PROTECTION
ALWAYS WEAR EYE PROTECTION THAT CONFORMS WITH CSA REQUIREMENTS or ANSI SAFETY STANDARD Z87.1
FLYING DEBRIS can cause permanent eye damage. Prescription eyeglasses ARE NOT a replacement for proper eye protection.
WARNING: Non-compliant eyewear can cause serious injury if broken during
the operation of a power tool.
WARNING: Use hearing protection, particularly during extended periods of
operation of the tool, or if the operation is noisy.
SAFETY GUIDELINES
TECHNICAL SPECIFICATIONS
IMPACT WRENCH 054-1216-4
WEAR A DUST MASK THAT IS DESIGNED TO BE USED WHEN OPERATING A POWER TOOL IN A DUSTY ENVIRONMENT.
SAVE THESE INSTRUCTIONS FOR REFERENCE
IMPACT WRENCH 054-1216-4
!
!
6
7
WARNING: Dust that is created by power sanding, sawing, grinding, drilling, and
other construction activities may contain chemicals that are known to cause cancer, birth defects, or other genetic abnormalities. These chemicals include:
• Lead from lead-based paints
• Crystalline silica from bricks, cement, and other masonry products
• Arsenic and chromium from chemically treated lumber
The level of risk from exposure to these chemicals varies, according to how often this type of work is performed. In order to reduce exposure to these chemicals, work in a well-ventilated area, and use approved safety equipment, such as a dust mask that is specically designed to lter out microscopic particles.
Electrical safety
WARNING: To avoid electrical hazards, re hazards or damage to the tool, use
proper circuit protection.
This tool is wired at the factory for 120 V AC operation. It must be connected to a 120 V AC, 15 A circuit that is protected by a time-delayed fuse or circuit breaker. To avoid shock or re, replace power cord immediately if it is worn, cut or damaged in any way.
Power tool safety
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
SAFETY GUIDELINES
Save all warnings and instructions for future reference.
Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
Electrical safety
Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will reduce risk of
electric shock.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the
risk of electric shock.
When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
If operating a power tool in a damp location is unavoidable, use a ground fault circuit interrupter (GFCI) protected supply. Use of a ground fault circuit interrupter (GFCI) reduces the risk of electric
shock.
Personal safety
Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
SAFETY GUIDELINES
Work area safety
Keep work area clean and well lit. Cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
SAVE THESE INSTRUCTIONS FOR REFERENCE
IMPACT WRENCH 054-1216-4
Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your nger on
the switch or energizing power tools that have the switch on invites accidents.
SAVE THESE INSTRUCTIONS FOR REFERENCE
IMPACT WRENCH 054-1216-4
8
!
!
9
Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
Power tool use and care
Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and
SAFETY GUIDELINES
any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for
operations different from those intended could result in a hazardous situation.
Hold power tool by insulated gripping surfaces, because the blade may contact its own cord.
Cutting a “live” wire may make exposed metal parts of the tool “live” and could give the operator an electric shock.
Service
Have your power tool serviced by a qualied repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
Specic safety rules
WARNING: Know your impact wrench. Read the Owner’s Manual carefully. Learn the
tool’s applications and limitations, as well as the specic potential hazards related to this tool. Following this rule will reduce the risk of electric shock, re or serious injury.
Always wear eye protection. Any power tool can throw foreign objects into your eyes and cause permanent eye damage. ALWAYS wear safety goggles (not glasses) that comply with ANSI safety standard Z87.1. Everyday glasses have only impact resistant lenses. They ARE NOT safety glasses.
WARNING: Glasses or goggles not in compliance with ANSI Z87.1 could cause
serious injury when they break.
Always use hearing protection when operating the impact wrench.
Use only impact sockets and accessories that are designed for use with an impact wrench. Do not use chrome plated sockets and accessories. Chrome plated sockets and accessories are designed for hand use only and MUST NOT be used with an impact wrench. They may shatter and possibly cause serious injury.
Before each use, check the impact sockets and accessories for excessive wear or cracks. Worn or damaged sockets or accessories may shatter and possibly cause serious injury. Worn accessories may allow the socket to come off during operation of the impact wrench.
Never use the impact wrench as a torque wrench. Always use a torque wrench to adjust the fastener to the specied torque.
SAFETY GUIDELINES
SAVE THESE INSTRUCTIONS FOR REFERENCE
IMPACT WRENCH 054-1216-4
SAVE THESE INSTRUCTIONS FOR REFERENCE
IMPACT WRENCH 054-1216-4
10
!
11
Keep the impact wrench handle and body clean and free of oil and grease. Always use a clean dry cloth when cleaning. Do not use solvents, brake uid, gasoline or other petroleum products to clean the tool. They will damage the tool.
Do not wear neckties or loose clothing.
When wearing gloves, they must be tight tting and slip resistant type. Leather gloves offer the best protection.
Always use two hands when operating the impact wrench. Use one hand on the handle and the other on the front of the tool body.
Never place your hand so it is touching the socket or accessory when the tool is turned ON. Your hand could be seriously injured.
Always remove the plug from the power source before installing or removing any socket or accessory.
Be ready for components to shift when removing any fastener. The speed of the fastener removal could cause unexpected shifting of the components.
SAFETY GUIDELINES
Extension cord safety
WARNING: Keep the extension cord clear of the working area. Position the cord
so it will not get caught on the workpiece, tools or any other obstructions while you are working with the power tool.
Make sure any extension cord used with this tool is in good condition. When using an extension cord, be sure to use one of heavy enough gauge to carry the current the tool will draw. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating.
The table below shows the correct size to use according to cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The smaller the gauge number the heavier the cord.
Be sure your extension cord is properly wired and in good condition. Always replace a damaged extension cord or have it repaired by a qualied electrician before using it. Protect your extension cord from sharp objects, excessive heat and damp or wet areas.
Use a separate electrical circuit for your power tools. This circuit must not be less than 14 gauge wire and should be protected with either a 15 A time delayed fuse or circuit breaker. Before connecting the power tool to the power source, make sure the switch is in the OFF position and the power source is the same as indicated on the nameplate. Running at lower voltage will damage the motor.
MINIMUM GAUGE (AWG) EXTENSION CORDS (120 V use only)
Amperage rating Total length
More
than
0 6 18 16 16 14
6 10 18 16 14 12 10 12 16 16 14 12 12 16 14 12 Not Applicable
Not more
than
25'
(7.5 m)
50'
(15 m)
100'
(30 m)
(45 m)
150'
SAFETY GUIDELINES
IMPACT WRENCH 054-1216-4
IMPACT WRENCH 054-1216-4
!
12
13
Symbols
WARNING: Some of the following symbols may appear on the impact wrench.
Study these symbols and learn their meaning. Proper interpretation of these symbols will allow
for more efcient and safer operation of this tool.
V …............ Volts
A ………... Amperes Hz ……… Hertz W ………. Watts
kW ........... Kilowatts
........ Microfarads
L ………... Litres Kg ……… Kilograms H ………... Hours
N/cm2 ....... Newtons per square
centimetre
Pa ……… Pascals BPM ….. Beats per minute Min ……. Minutes S ………... Seconds
or AC …... Alternating current
.. Three-phase alternating
current
SAFETY GUIDELINES
.. Three-phase alternating current with neutral
...... Read all safety warnings
and instructions
... Direct current
……….. No load speed
………. Alternating or direct current
………. Class II construction
….......... Splash-proof construction
…….. Watertight construction
………. Protective grounding at grounding terminal, Class I tools
per minute
0 ………….. Off position
……... Warning symbol
……. Wear your safety glasses
……... Wear hearing protection
… Revolutions or reciprocations
…........... Diameter
……. Directional arrow
KEY PARTS DIAGRAM
IMPACT WRENCH 054-1216-4
No. Description No. Description
1 Air vents 4 Forward/reverse button
2 Handle 5 1/2” square drive
3 Variable speed trigger switch
IMPACT WRENCH 054-1216-4
14
!
!
15
Illustration Description Size Qty
1/2” drive impact socket
Quick release adapter
1/4” hex drive nut driver
Screwdriver bit #1, #2, #3 3
Screwdriver bit #1, #2, #3 3
Blow moulded case
ACCESSORIES
1/2”, 5/8”, 3/4” 3
1/2” to 1/4” 1
3/16”, 1/4”, 9/32”, 5/16”, 11/32”, 3/8”, 7/16”
Installing impact sockets
WARNING: Use only impact
sockets and accessories that are designed for use with an impact wrench. Do not use chrome
plated sockets and accessories. Chrome plated sockets and accessories are designed for hand
7
1
use only and MUST NOT be used with an impact wrench. They may shatter and possibly cause serious injury.
WARNING: Always remove the
plug from the power source before changing any sockets or accessories. You may injure your hand if the tool is started accidentally.
To install a socket, press the square portion of the socket (1) onto the square drive (2) of the impact wrench (Fig. 1).
NOTE: Slide the socket fully onto the square drive so the socket retainer (3) will hold the socket rmly in place
g. 1
Installing the hex drive adapter
By installing the 1/2” square to 1/4” hex adapter, the impact wrench can be used as an impact driver for driving screws and for use with impact nut drivers.
1. Pull outward on the large quick connect collar (1) (Fig. 2).
g. 2
IMPACT WRENCH 054-1216-4
2. Slide the adapter over the impact wrench 1/2” drive (2).
3. When the adapter is fully on the 1/2” drive, release the collar.
IMPACT WRENCH 054-1216-4
OPERATING INSTRUCTIONS
16
!
17
4. When the collar is released, pull outward on the hex drive sleeve (3) to ensure the retaining balls inside the 1/2” drive collar are engaged with the 1/2” drive of the impact wrench.
Installing a screwdriver bit or nut driver in the hex adapter
1. To install a screwdriver bit, pull outward on the small hex drive sleeve (1) (Fig. 3). While holding the hex drive sleeve out, insert the bit (2) fully into the hex drive and then release the outer sleeve.
2. When the hex drive sleeve is released, pull outward on the bit to ensure the retaining balls inside the hex drive are engaged with the groove in the bit (3) to prevent the bit from sliding out of the hex drive. NOTE: Pulling outward on the bit will also ensure the adapter is fully locked onto the impact wrench 1/2” drive.
3. To remove the bit, pull outward on the hex drive sleeve and pull the bit out of the hex drive.
WARNING: Never use a
screwdriver bit, nut driver or any other 1/4” hex drive accessory that does NOT have the locking groove. These accessories will not be adequately held in the hex drive and could come loose and possibly injure the operator.
OPERATING INSTRUCTIONS
g. 3
Forward/reverse button
This impact wrench is equipped with a forward/ reverse button (1) (Fig. 4).
1. To operate the impact wrench in the reverse direction, press the forward/reverse button to the RIGHT. This direction of rotation will loosen the fastener.
2. To operate the impact wrench in the forward direction, press the forward/reverse button to the LEFT. This direction of rotation will tighten the fastener. NOTE: Never press the forward/reverse button while the tool it turned ON. Damage to the tool will result.
Variable speed trigger switch
This impact wrench is equipped with a variable­speed ON/OFF trigger switch.
1. To start impact wrench, gently squeeze the trigger switch (2) (Fig. 5). NOTE: The impact wrench will turn at its slowest speed when the trigger switch is depressed slightly. The impact wrench will turn at its fastest speed when the trigger switch is fully depressed.
2. To stop the impact wrench, release the trigger switch.
NOTE: If the tool gets warm while running at slow speeds, stop and allow it to cool.
g. 4
g. 5
OPERATING INSTRUCTIONS
IMPACT WRENCH 054-1216-4
IMPACT WRENCH 054-1216-4
18
!
!
!
WARNING
For safety reasons, the operator must read the sections of this Owner’s Manual entitled “GENERAL SAFETY WARNINGS”, “POWER TOOL SAFETY”, “SPECIFIC SAFETY RULES”, “EXTENSION CORD SAFETY” and “SYMBOLS” before using this impact wrench.
Verify the following every time the impact wrench is used:
1. Safety glasses and hearing protection are being worn.
2. Socket or accessory is “impact wrench” rated.
3. Socket or accessory is in good condition.
Failure to observe these safety rules will
signicantly increase the risk of injury.
Removing fasteners
One of the most common uses for the impact wrench is to remove car wheel nuts for rotating the tires. Car wheel nut removal is used for illustrative purposes.
1. Install the correct size of impact socket on the impact wrench as outlined in Fig. 1.
2. Set the forward/reverse button to the RIGHT for removing fasteners (Fig. 4).
3. Plug the impact wrench power cord into an appropriate power source.
4. Grasp the impact wrench handle (1) with one hand and the front housing of the impact wrench (2) with the other hand (Fig. 6).
5. Place impact socket (3) onto the wheel nut. NOTE: Make sure the socket is fully engaged with the nut to avoid potentially damaging the socket or the wheel nut.
6. While holding the tool level with the ground and with a rm grasp, squeeze the trigger switch (4).
When removing fasteners, do not operate the impact wrench for more than 15 seconds unless the fastener begins to turn. If the fastener fails to turn within 15 seconds, reverse the direction of rotation and operate the impact wrench in a forward direction on the fastener for a few seconds. Now switch back to reverse direction and remove the fastener. This procedure will usually break loose seized or “frozen” fasteners.
19
g. 6
DANGER: Before attempting
to remove a car wheel, make sure all jacking, wheel blocking and wheel removal safety procedures illustrated in the Owner’s Manual
OPERATING INSTRUCTIONS
for your car are followed exactly. Failure to follow those safety instructions could result in serious injury or death.
IMPACT WRENCH 054-1216-4
WARNING: Operating the
impact wrench for more that 15 seconds at a time on a seized or “frozen” fastener will place severe stress on the impact wrench and cause damage. It may also break the fastener.
IMPACT WRENCH 054-1216-4
OPERATING INSTRUCTIONS
!
20
21
Driving and removing screws
When driving or removing screws, always use the largest screwdriver bit that will properly t into the head of the screw to prevent damage to the screwdriver bit and the screw head. When starting the tool, make sure you are pressing the bit straight and rmly into the screw head. To avoid over driving screws or damaging the screw head or the screwdriver bit, start the tool at a slow speed and DO NOT allow it to continue to run in the impact mode for more than a few seconds.
Drilling
Drill bits with a 1/4” hex shank can be used in the 1/2” square to 1/4” hex adapter. Whenever possible, use a center punch to mark the location of the hole to be drilled. When starting the tool, make sure the drill bit is lightly touching the workpiece where the hole is to be drilled. This will ensure the drill starts in the correct location without “wandering” as you start drilling.
Replacing carbon motor brushes
The carbon motor brushes will wear down and require replacing. The time intervals between replacements will vary depending upon the torques being achieved and the hours of use. It is recommended that the brushes be checked after each 10 hours of use. When the length of the carbon brush reaches 1/4” (6.35 mm), the brushes should be replaced.
WARNING: Unplug the tool
from the power source.
1. Use a 3/16” (4 mm) slot screwdriver and remove one brush cap (1) (Fig. 7). Turn the brush cap counter clockwise to remove it from the motor housing.
2. Pull the spring & brush assembly (2) from the brush holder (3) in the motor housing (4).
3. Insert the new spring & brush assembly into the motor housing.
4. Compress the spring into the brush holder and thread the brush cap back into the motor housing. NOTE: Make sure the brush cap threads are not cross-threaded. Do NOT over tighten.
g. 7
MAINTENANCE
OPERATING INSTRUCTIONS
IMPACT WRENCH 054-1216-4
5. Repeat steps 1 to 4 and replace the second carbon brush located on the opposite side of the motor housing.
IMPACT WRENCH 054-1216-4
!
22
! !
General
WARNING: When servicing,
use only identical replacement parts. Use of any other part may create a hazard or cause product damage.
DO NOT use solvents when cleaning plastic parts. Plastics are susceptible to damage from various types of commercial solvents and may be damaged by their use. Use a clean cloth to remove dirt, dust, oil, grease etc.
WARNING: Do not at any time
allow brake uids, gasoline, petroleum-based products, penetrating oils, etc. to come into contact with plastic parts. They contain chemicals that can damage, weaken or destroy plastic.
DO NOT abuse power tools. Abusive practices can
MAINTENANCE
damage the tool as well as the workpiece.
WARNING: DO NOT attempt
to modify tools or create accessories. Any such alteration or modication is misuse and could result in a hazardous condition leading to possible serious injury. It will also void the warranty.
23
EXPLODED VIEW
Lubrication
All of the bearings in this tool are lubricated with a sufcient amount of high-grade lubricant for the life of the unit under normal conditions. Therefore, no further lubrication is required.
IMPACT WRENCH 054-1216-4
IMPACT WRENCH 054-1216-4
24
!
YEAR ANS
3
LIMITED WARRANTY
DE GARANTIE LIMITÉE
WARNING: When servicing, use only Mastercraft
other parts may create a safety hazard or cause damage to the impact wrench.
Any attempt to repair or replace electrical parts on this impact wrench may create a safety hazard unless repairs are performed by a qualied technician. For more information, call the Toll-free Helpline, at 1-800-689-9928.
®
replacement parts. The use of any
25
Always order by PART NUMBER, not by key number.
Key # Part # Part Name Qty
1 4030010114 ST3.9X25 4
2 4040030001 Spring washer 4mm 4
3 2020050059 aluminum casting 1
4 3140020017 "O" ring 1
5 2010080012 Shaft bushing 1
PARTS LIST
6 2030020034 Washer No.1 1
7 2040040088 Outer shaft 1
8 4080070001 Steel ball 5.5 2
9 2040200002 Torsion slot 1
10 4080040001 Steel ball 4 24
11 2030020035 Washer No.2 1
12 2050060178 Torsion spring 2
13 2040050022 Inner shaft 1
14 2010010027 Planetary gear 3
15 4110050003 Pin 3
16 2030020229 Washer No.3 1
17 4010010058 6002-2RS bearing 1
18 2010090067 Inner gear ring 1
Key # Part # Part Name Qty
19 3150070079 Gear box 1
20 4010010084 600-2RS bearing 1
21 1010180009 Rotor 1
22 3150140006 Carbon brush cap 2
23 3150060015 Brush holder 2
24 1230010030 Carbon brush 2
25 2030070027 Brush holder support 1
26 4010010053 607-2RS bearing 1
27 1020180008 Stator 1
28 3022280004 Enclosure 1
29 3120030017 Direction setting button 1
30 1061010002 Switch 1
31 4030010106 ST3.9X19 8
32 4030010098 ST3.9X13 2
33 3140010004 Cord guard 1
34 1190030012 UL plug & cord 1
35 3140100006 Casting shell rubber 1
This Mastercraft® product is guaranteed for a period of three years from the date of original retail purchase against defects in workmanship and materials, except for the following components:
a. Component A: Batteries, chargers and carrying case, which are guaranteed for a period of two
years from the date of original retail purchase against defects in workmanship and materials;
b. Component B: Accessories, which are guaranteed for a period of one year from the date of original
retail purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us with proof of purchase within the stated warranty period and if covered under this warranty, will be repaired or replaced (with the same model, or one of equal value or specication), at our option. We will bear the cost of any repair or replacement and any costs of labour relating thereto.
These warranties are subject to the following conditions and limitations:
a. A bill of sale verifying the purchase and the purchase date must be provided; b. This warranty will not apply to any product or part thereof that is worn, broken or that has become
inoperative due to abuse, misuse, accidental damage, neglect or lack of proper installation, operation or maintenance (as outlined in the applicable owner’s manual or operating instructions) or that is being used for industrial, professional, commercial or rental purposes;
c. This warranty will not apply to normal wear and tear or to expendable parts or accessories that
may be supplied with the product and that are expected to become inoperative or unusable after a reasonable period of use;
d. This warranty will not apply to routine maintenance and consumable items, including, but not
limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, uids, tune-ups or adjustments;
e. This warranty will not apply where damage is caused by repairs made or attempted by others (i.e.:
persons not authorized by the manufacturer);
f. This warranty will not apply to any product that was sold to the original purchaser as a
reconditioned or refurbished product (unless specied otherwise in writing);
WARRANTY
IMPACT WRENCH 054-1216-4
IMPACT WRENCH 054-1216-4
26
g. This warranty will not apply to any product or part thereof if any part from another manufacturer is installed therein or any repairs or alterations have been made or attempted by unauthorized persons; h. This warranty will not apply to normal deterioration of the exterior nish, including, but not limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners; and i. This warranty will not apply to component parts sold by and identied as the product of another company, which shall be covered under that product manufacturer’s warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser, and cannot be transferred. Neither the retailer nor the manufacturer shall be liable for any other expense, loss or damage, including, without limitation, but not limited to any indirect, incidental, consequential or exemplary damages arising in connection with the sale, use or inability to use this product.
Notice to Consumer
This warranty gives you specic legal rights, and you may have other rights, which may vary from
WARRANTY
province to province. The provisions contained in this warranty are not intended to limit, modify, take away from, disclaim or exclude any statutory warranties set forth in any applicable provincial or federal legislation.
Mastercraft is a superior line of products selected for their workmanship and materials. These products are designed to meet rigorous quality and performance standards, and are approved by our Quality Assurance laboratory.
TOLL-FREE HELPLINE: 1-800-689-9928
Rev 2.6 19/08/2013
IMPACT WRENCH 054-1216-4
Loading...
