Master
Heat Gun
50 years
of Professional
Quality Heat
®
• The original Industrial
Quality Heat Gun introduced to the worldwide
marketplace in 1958.
Made in the USA and
used by legions of
professional craftsmen
for hundreds of applications that require fast,
reliable, flameless heat.
• Powerful universal motor
delivers strong 23 CFM
airflow at temperatures
up to 1000°F/540°C to
get the job done fast.
Double protected heating element and sturdy
die cast aluminum
housing provide years
of reliable service.
Master HG Series Heat Guns
• Easily replaceable
heating element and
motor brushes allow for
fast field maintenance, to
keep your Master Heat
Gun working year after
year in factories, laboratories, workshops and
jobsites.
• A broad range of
optional attachments
make Master Heat
Guns ideal for a wide
variety of heating,
shrinking, drying,
welding and soldering
applications.
®
MASTER HEAT GUN
Heavy Duty Industrial Quality Multiple Use Heat Gun
Wherever reliable flameless heat is required, the MASTER HEAT
GUN®does the job faster, safer and better.
igh temperature industrial jobs are done faster with the MASTER
H
HEAT GUN because of its higher power and air flow ratings.
Power ratings go up to 1000°F/540°C at 1740 watts (120V).
Air flow ratings are 23 CFM (651L/Min) average air volume.
he combination of these factors means high performance.
T
ASTER HEAT GUN provides a fast flow of heated air for
M
many applications.
MASTER HEAT GUN
The number one choice of industry with rugged die-cast aluminum housing and powerful universal motor.
Renovation
Flooring
Roofing Laboratory
Four HG models provide temperatures up to 300°F/150°C, 500°F/260°C, 750°F/400°C, 1000°F/538°C
Automotive
• Activate adhesives and
potting compounds
• Bend and form plastics and
plastic laminates
• Cure and set adhesives
• Defrost freezers and frozen
coils
• Dry conformal coatings on
circuit boards
• General heating and drying
applications
Shrink Wrap
• Melt solder off the backs
of printed circuit boards so
thru hole components can
be removed
• PVC bendings
• Preheat flux
• Remove dents in
fiberglass
• Remove plastic autobody
panels
• Remove windshield
caulking
Bend PVC Heat pipes and more
• Shrink and terminate
environmental splices
• Shrink and terminate heat
shrinkable insulated solder
preforms
• Shrink heat shrinkable
anti-static film
• Shrink heat shrinkable
molded parts
• Shrink heavy gauge shrink
packaging
• Shrink wide heavy-wall
and adhesive-lined tubing
• Spot dry paint fast
• Stretch vinyls
• Strip paint
• Thaw frozen pipes
• Hundreds of other uses
www.masterappliance.com
®
MASTER HEAT GUN
The number one Heat Gun choice of industry has a rugged die-cast
aluminum housing for heavy duty use. Four models provide temperatures of 300°F/150°C, 500°F/260°C, 750°F/400°C or
1000°F/538°C. "Wherever fast, reliable flameless heat is the need"
Master Heat Guns provide the following features:
High temperature and power ratings: up to 1000°F/540°C at 1740 watts
•
High air flow rating: 23 CFM at 3000 FPM gets the job done fast
•
Powerful high speed universal motor
•
Sturdy die cast aluminum housing is rugged and lightweight
•
Double protected heating element housing
•
Easily replaceable, reinforced, mica-insulated ceramic heating element
•
Externally accessible carbon brush holders for quick replacement
•
Three position “OFF-COLD-HOT” rocker switch
•
Contoured, well balanced handle
•
Non-slip rubber-backed base with 90° rotation
•
6 foot, 3-wire grounded cordset made with flexible, oil and
•
sunlight resistant rubber jacket
Optional momentary contact safety switch for added safety
•
UL and/or CSA Listed. Made in USA
•
Use to shrink tubing and packaging, bend plastics, cure adhesives,
•
dry and heat parts, strip paint, defrost frozen pipes, heat sensitive
materials, solder/desolder and more
Available in four
temperature ranges
see back page for details
Swivel base
for hands free use.
Master Heat Guns are available with
optional “Momentary Contact Safety Switch”
for instant-off when the trigger is released.
Master Heat Gun Kit includes:
Heat Gun, reducer 51544, spreader 51543,
reflector A-160-HG and carrying case.
Protect, store and carry your Master Heat Gun
and attachments in this rugged case. A well cared for
Master Heat Gun will provide years of service.
Durable construction along with user replaceable
heating elements and motor brushes mean your heat
gun will be ready for work.
www.masterappliance.com
Master Heat Gun
MADE IN
®
Attachments & Accessories
Professional quality attachments & accessories
provide the versatility to do more with your heat tool.
A-160-HG
Shrink attachment for
tubing up to 3/4”
A-170-HG
Shrink attachment for
tubing 3/4" to 2" O.D.
MASTER HEAT GUN
MODEL NO. DESCRIPTION ELEMENT
HG-201A 200-300°F 93-150°C 120V 60 Hz 5A 600W HAS-042K
HG-301A 300-500°F 150-260°C 120V 60 Hz 12A 1440W HAS-041K
HG-501A 500-750°F 260-400°C 120V 60 Hz 14A 1680W HAS-011K
HG-501A-D 500-750°F 260-400°C 120V 60 Hz 12A 1440W HAS-011DK
HG-751A-C 750-1000°F 400-540°C 120V 60 Hz 18A 2160W HAS-015K
HG-751B 750-1000°F 400-540°C 120V 60 Hz 14.5A 1740W HAS-043K
HG-202A 200-300°F 93-150°C 220V 50 Hz 3A 600W HAS-012K
HG-302A 300-500°F 150-260°C 220V 50 Hz 6A 1440W HAS-013K
HG-502A 500-750°F 260-400°C 220V 50 Hz 7A 1680W HAS-014K
HG-752A 750-1000°F 400-540°C 220V 50 Hz 9A 1740W HAS-016K
MASTER HEAT GUN
MODEL NO. DESCRIPTION ELEMENT
HG-201AK 200-300°F 93-150°C 120V 60 Hz 5A 600W HAS-042K
HG-301AK 300-500°F 150-260°C 120V 60 Hz 12A 1440W HAS-041K
HG-501AK 500-750°F 260-400°C 120V 60 Hz 14A 1680W HAS-011K
HG-751BK 750-1000°F 400-540°C 120V 60 Hz 14.5A 1740W HAS-043K
®
*
®
KITS
30202
Solder preform
attachment
51309
3/8" Pinpoint
attachment
51542
Glass protector
attachment
REPLACEMENT
REPLACEMENT
51543
2-1/4" Spreader
attachment
Get all 3!
35245
Three of our most
popular attachments
Replacement Heating Element
Brush, Spring and Cap Kit
Part Number 35257
*
51544
/8" Reducer
7
attachment
51013
Molded storage and
carrying case
NEMA 5-20 Plug
Momentary Contact Safety Switch:
An option for Master Heat Gun®models. To order add “MC” suffix to model number.
Example: HG-501A-MC.
Also, many international voltages/cordsets available upon request.
Contact our Sales Department for current certifications and appropriate model numbers.
Specifications
Air Volume: 23 CFM•Air Velocity: 3000 FPM
•
Motor: Universal•Nozzle Opening: 1.2" I.D., 1.5” O.D.
•
Cordset: 6 ft., 3-wire grounded•Dimensions: 9" L x 5.2" W
•
x 10.1" H
Tool: 5 lbs.
As with all electrical equipment and tools, for your safety, read the instruction manual before using.
All information including illustrations, is believed to be reliable. Users, however, should independently evaluate the suitability of this product for their application. The only obligations of Master
Appliance are those in the Standard Terms and Conditions of Sale for this product. In no case will
Master Appliance be liable for any incidental indirect, or consequential damages arising from the
sale, resale, use or misuse of this product.
Tool Net Weight: 3.7 lbs.•Shipping Weight
•
Shipping Weight Kit: 10 lbs.
•
Master Appliance Corp. • 2420 18th St. • Racine, WI 53403 USA • 800-558-9413 • 262-633-7791
Fax: 262-633-9745 • e-mail: sales@masterappliance.com • www.masterappliance.com
FOR MASTER PRODUCTS CONTACT:
Form # 58075 Rev. A
