DH 41 H
BG ИЗСУЧАВАЧ НА ВЪЗДУХ
ИИНСТРУКЦИЯ ЗА УПОТРЕБА
CZ ODVLHČOVAČ VZDUCHU NÁVOD K OBSlUZE
EE ÕHUKUIVATI KASUTAMISJUHEND
GB DEHUMIDIFIER OPERATING MANUAL
HR SUŠNICA ZRAKA INSTRUKCIJA OBSLUŽIVANJA
HU LEVEGİ SZÁRITÓ HASZNÁLATI UTASITÁS
IT DEUMIDIFICATORE MANUALE OPERATIVO
LT ORO SAUSINTUVAS EKSPLOATACIJOS INSTRUKCIJA
LV GAISA SAUSINĀTĀJS LIETOŠANAS INSTRUKCIJA
PL OSUSZACZ POWIETRZA INSTRUKCJA OBSŁUGI
RO DEUMIDIFICATOR INSTRUCłIUNI DE UTILIZARE
RS SUŠNICA VAZDUHA INSTRUKCIJA OBSLUŽIVANJA
RU ВОЗДУХООСУШИТЕЛЬ ИНСТРУКЦИЯ ОБСЛУЖИВАНИЯ
SI SUŠILNIK ZRAKA NAVODILO ZA UPORABO
SK ODVLHČOVAČ VZDUCHU NÁVOD NA POUŽITIE
2
BG ТЕХНИЧЕСКИ ДАНИ / CZ TECHNICKÉ ÚDAJE / EE ESPECIFICACIONES TÉCNICAS / GB TECHNICAL DATA / HR TEHNIČKI PODACI / HU MŐSZAKI
ADATOK / IT DATI TECNICI / LT TECHNINIAI DUOMENYS / LV TEHNISKIE DATI / PL DANE TECHNICZNE / RO INFORMAłII TEHNICE / RS TEHNIČKI
PODACI / RU ТЕХНИЧЕСКИЕ ДАННЫЕ / SI TEHNIČNE PODATKE / SK TECHNICKÉ PARAMETRE
DH 41 H
1 Humidity operating range [%]
40-95
2 Temperature operating range [0C]
5-40
3 Air displacement [m3/h]
450
4 Dehumidification rate [l/24h]
40,6
5 Refrigerant
R407c
6 Quantity of the refrigerant [g]
350
7 a phase
~ 1
b voltage [V]
220-240
Power supply
c frequency [Hz]
50
8 Power consumption [W]
750
9 Dimensions: [mm]
763x597x868
10 Weight [kg]
49
BG РИСУНКА / CZ OBRÁZKY / EE IMÁGENES / GB PICTURES / HR CRTEŽI / HU RAJZOK / IT FIGURE / LT PIEŠINIAI / LV ZĪMĒJUMI / PL RYSUNKI
/ RO DESENE TEHNICE / RU РИСУНКИ / SK OBRÁZKY / SI RISBE / RS CRTEŽI
1.
2.
3
3. 4.
5.
6.
7. 8.
12
GB
1. TECHNICAL DATA (page 2):
1) Humidity operating range
2) Temperature operating range
3) Air displacement
4) Dehumidification rate (T = 30 0C, UR = 80 %)
5) Refrigerant
6) Quantity of the refrigerant
7) Power supply
a) phase
b) voltage
c) frequency
8) Power consumption
9) Dimensions:
10) Weight
2. CONTROL PANEL (Figure 1)
a. main switch
b. heater switch
c. control lamp
d. defrosting indicator lamp
e. water reservoir filling indicator lamp
f. hour counter
g. humidistat adjustment knob
3. DESCRIPTION OF THE DEVICE
DH dehumidifiers are applied at places (rooms) requiring rapid
drying in order to provide protection from an uncontrolled
increase in air humidity.
The principle of operation of the DH dehumidifiers consists in
lowering the content of water steam in air by its condensation.
Figure 2 presents the construction of the device. Its main
elements are the compressor refrigerating system and the fan.
The air sucked by the fan (2) flows through the filter (7) and then
through the evaporator (5), where it is cooled to a temperature
lower than the dew point temperature. As a consequence of this,
part of the water steam contained in air is condensed on the walls
of the evaporator. In the case of lower temperatures, the water
condensing on the evaporator freezes on it. Then, the electronic
system (3) switches off the compressor every now and then,
starting to defrost the evaporator. Owing to this, water flows down
into the reservoir (9). Additionally, depending on the conditions
and the selected mode of operation, the device may operate with
an activated heater (6), whose function is to increase the capacity
of the device. The cooled and dried air from the evaporator flows
through the condenser (4), where it is heated to a temperature
higher than the room temperature.
Figure 2. construction of the dehumidifier:
1) compressor;
2) fan;
3) electronic system;
4) condenser;
5) evaporator;
6) heater;
7) filter;
8) float;
9) water reservoir.
The device is started automatically by a built-in humidistat, at the
moment, when the air humidity is higher than the required level.
The device is protected from use in too low or too high
temperatures. The electronic system controls the ambient
temperature and switches off the compressor and the fan in the
event of unfavourable operating conditions. In such a situation,
the user is notified about this fact by a back-lit control lamp (c).
NOTE: The drier may not be started, if the temperature at the
place of use is lower than 5ºC or higher than 40ºC.
In order for the drier to operate most effectively, place it in the
middle of the room. This will ensure a free air flow through the
device. The minimal distance from the walls amounts to 20-30
cm. Do not position the drier near sources of heat such as
heaters, ovens or near the doors and windows, which should be
closed during the operation of the device. The DH drier should
operate in closed rooms.
NOTE: No objects should lie on the drier during its
operation.
The water reservoir may be replaced by a direct connection of
the discharge hose to the connector.
NOTE: Operate, store and transport the device in a vertical
position. Otherwise irregularities in the operation of the
device may occur, or even the refrigerating system may be
damaged.
4. FIRST ASSEMBLY OF THE DEVICE
Each dehumidifier is delivered in an individual packaging
consisting of a pallet and a cardboard box. After the device is
taken out of the packaging, mount the upper holder.
Assembly of the upper holder:
1) detach the upper holder from the bottom one, to
which it
was attached during the transport (Fig. 3),
2) slide the upper holder over the bottom holder
(Fig. 4),
3) connect the holder with the dehumidifier housing
(Fig. 5) by means of screws attached to the device,
tighten the screws with a 5 mm hexagonal key,
check whether the holder is not loose in relation to
the housing, if needed, tighten the screws.
5. START OF THE DEHUMIDIFIER
In order to start the dehumidifier:
• connect the device to ~230 V, 50 Hz power supply;
• activate the switch (a) to the ON position (marked
with symbol), which will start the fan and the
compressor. The compressor is protected from
being started too frequently by a one-minute delay;
• set the required air humidity level.
6. DEHUMIDIFIER STOPPING
In order to switch off the drier, the switch (a) must be adjusted to
the OFF position.
7. OPERATION OF THE HEATER
The dehumidifier is equipped with a heater, whose operation is
controlled by a push button (b). If it is in the OFF position, the
heater is switched off. When the button is adjusted to the ON
position (marked with symbol) the heater is switched on and
operates in two modes, depending on the ambient temperature. If
the ambient temperature does not exceed 20ºC, the heater is
switched on during the whole operating time of the device. At
temperatures above 20ºC, the heater switches on automatically
only during the frosting process.
8. WATER RESERVOIR
When the reservoir is filled with water, the device stops the
operation and lights the filling indicator lamp (e). In order to restart the dehumidifier, empty the reservoir.
NOTE: Before the removal of the reservoir, switch off the
device by means of the main switch and disconnect it from
the mains. Only then, will it be possible to re-start the
device.
The water reservoir may be replaced by connecting the
condensate discharge hose to the connector. It is helpful in the
situation, when the device is switched on for a longer period of
time, and the control of the reservoir filling level is difficult.
In order to connect the hose, the condensate reservoir must be
removed from the device. Then, slide the hose of 10-12 mm in
diameter over the connector.
Fig. 6:
A. maximal height of the hose end position,
B. connector for the hose connection.
NOTE: The hose end, through which the condensed water
flows out, may not be placed higher than the connector of
the drier. The placement of the hose end above the
connector will lead to the damage of the device, it may also
cause electric shock.
13
9. MAINTENANCE
NOTE: Before starting the maintenance activities, switch off
the device by means of the switch (a) and disconnect it from
the mains.
In order to ensure efficient operation, clean the filter as well as
the internal elements of the dehumidifier periodically. The air filter
should be blown through with compressed air or washed in warm
water with soap.
NOTE: In order to remove the filter, loosen the lock screw
which is over the filter.
In order to clean the inside of the device, unscrew and remove
the front cover of the filter. The pollution must be removed by
means of a vacuum cleaner, making sure that the ribs of the
condenser, evaporator and fan blades are not damaged in the
process.
10. TRANSPORT
NOTE: In order to move or transfer the dehumidifier, switch
off the device by means of the main switch and pull the plug
out of the mains socket.
In order to move the dehumidifier, tilt it. This enables the
transport of the device on wheels (fig. 7).
NOTE: Do not transfer the dehumidifier in a horizontal
position.
The method of transfer of the dehumidifier along the stairs or a
steep surface is presented in fig. 8.
11. NOTES REGARDING THE DISASSEMBLY
In the compressor circulation system, there is a R407C
pressurized refrigerant.
Additionally, there is oil inside the compressor. For these
reasons, throwing the exploited device away is not allowed.
Disassemble it, and the respective elements must undergo
secondary processing or scrapping.
NOTE: The refrigerants must not be emitted into the
atmosphere. The refrigerant should be removed by qualified
persons.
The following items are necessary to remove the refrigerant:
• pliers for a removal of refrigerants,
• unit for forcing through the liquids,
• pressure vessel.
The refrigerant should be removed in the following way:
• connect the pliers and the pressure vessel to the
unit,
• puncture the drain pipe of the compressor with the
pliers and leave them clamped on the pipe,
• open both valves of the unit and start it, emptying
the used refrigerant from the drier,
• switch off the unit and shut both valves, then shut
the pressure vessel valve,
• remove the pliers from the pipe,
• if the pressure vessel is filled up, deliver it to a
specialist liquid waste removal point.
In order to remove the oil from the compressor, solder it out or
cut it off from the refrigerating system and unscrew it from the
base. Then, drill a hole in the compressor housing (from the
bottom), through which the oil may be poured out.
NOTE: Deliver the used oil to the oil removal point.
The remaining elements (mainly steel, copper and aluminium
elements) may be delivered for secondary processing.
12. FAULT DETECTION AND TROUBLE-SHOOTING
SYMPTOM POSSIBLE CAUSES PROCEDURE
The device cannot be started 1
2
3
4
5
Lack of supply voltage
Improper humidistat setting
The water reservoir is filled up (the
indicator lamp is back-lit)
Too low ambient temperature (the c
control lamp is back-lit)
Too high ambient temperature (the
c control lamp is back-lit)
1a
1b
2
3
4
5
Check whether the main switch
functions properly and whether it is
in the ON position
Check the supply voltage (230 V,
1~, 50 Hz)
Set the humidistat to the humidity
level lower than the room
temperature
Empty the reservoir as specified in
the section entitled Water reservoir
Check whether the ambient
temperature is higher than 5°C
Check whether the ambient
temperature is lower than 40°C
The fan and the compressor are
operable, but neither water nor ice
appears on the walls of the
evaporator
1
2
3
Too little air flow
Too low room temperature and/or
relative air humidity
Faulty operation of the refrigerating
system
1a
1b
2
3
Check whether the air inlet or air
outlet is not blocked
Check whether there is deposit on
the filter or ribbed condenser or
evaporator blocks
Check whether the temperature is
within the range of 5º- 40ºC, and
whether the relative humidity ranges
from 40 to 95%
Call the authorised service
The device stopped the operation,
the indicator lamp is back-lit (e)
1 The water reservoir is filled up 1 Empty the reservoir
The device stopped the operation, 1 The air flow is blocked 1 Remove the objects which obstruct
14
the control lamp is back-lit (c) – the
ribbed condenser block is
overheated
2
3
4
The air temperature is lower than
5ºC or higher than 40ºC
Failure of the fan drive
Faulty operation of the cooling
system
2
3
4
the airflow, switch on the
dehumidifier again
Apply the device only, when the
room temperature ranges from 5ºC
to 40ºC
Call the authorised service
Call the authorised service
The device stopped the operation,
the indicator lamp (c) is pulsating
1 Failure of the ambient temperature
sensor
1 Call the authorised service
The device stopped the operation,
the indicator lamp (d) is pulsating
1 Failure of the evaporating
temperature sensor
1 Call the authorised service
The device stopped the operation,
the indicator lamp (e) is pulsating
1 Failure of the condensing
temperature sensor
1 Call the authorised service
45
BG ЕЛЕКТРИЧЕСКА СХЕМА / CZ ELEKTRICKÉ SCHÉMA / EE ESQUEMA ELÉCTRICO / GB WIRING DIAGRAM / HR ELEKTRIČNA ŠEMA / HU ELEKTROMOS
KAPCSOLÁSI SÉMA / IT SCHEMA ELETTRICO / LT ELEKTRINö SCHEMA / LV ELEKTRISKĀ SHĒMA / PL SCHEMAT ELEKTRYCZNY / RO SCHEMĂ
ELECTRICĂ / RS ELEKTRIČNA ŠEMA / RU ЭЛЕКТРИЧЕСКАЯ СХЕМА / SI ELEKTRIČNA SHEMA / SK ELEKTRICKÁ SCHÉMA
W- switch, S1- ambient temperature sensor,
TIMER- operating timer , S2- condensing temperature indicator,
M- fan motor, S3- evaporating temperature indicator,
R- heating element, H- humidistat,
Comp- compressor, L- water level sensor,
C- condenser, I 1,2,3- operating condition indicators.
46
BG
ДЕКЛАРАЦИЯ НА СЪОТВЕТСТВИЕ С
НОРМИ ЕУ
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Polska
С това заявяваме, на нашата отговорност, че
изделието: Изсушавач на въздух:
Модел – DH 41H, е съгласно с нормата
EN 60335-2-40:2003+A1:2006+
A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+ A2:2005+IS1:2005
CZ
OSVĚDČENÍ SHODNOSTI S NORMAMI EU
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023 Gądki,
Polsko
Prohlašuje, s plnou zodpovědností, že spotřebič: Odvlhčovač
vzduchu: DH 41H, odpovídají normám
EN 60335-2-40:2003+A1:2006+A11:2004+
A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
EE
EL STANDARDITELE VASTAVUSE KINNITUS
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Poola,
avaldab käesolevaga oma vastutusel, et toode:
Õhukuivati, mudel – DH 41H, vastab standardile EN
60335-2-
40:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
GB
Certificate of compliance
with CE Standards.
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Polska
Declare on their own responsibility that the: Product
labelled "Dehumidifier", Models DH 41H complies
with the Directives No.
EN 60335-2-40:2003+A1:2006+
A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
HR
IZJAVA O SUGLASNOSTI SA NORMAMA EU
DESA Poland d.d. ul. Magazynowa 5a 62-023 Gądki,
Poljska
Ovim se izjavljuje sa punom odgovornošću da je
proizvod: Sušnica zraka: Model DH 41H suglasan sa
normama EN 60335-2-
40:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
HU
EU SZABVÁNYOKKAL VALÓ
EGYEZSÉGI NYILATKOZAT
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Lengyelország
Ezennel nyilatkozik saját felelıségére, hogy a termék:
Levegı száritó: Modell – DH 41H megfelel az EN
60335-1/2003 valamint EN 60335-2-
40:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
IT
CERTIFICATO DI CONFORMITÀ CON LE
DIRETTIVE DELL’UE
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Polonia
Dichiara sotto la propria responsabilità che il
prodotto: Deumidificatore: Modello – DH 41H è
conforme alla direttiva EN 60335-2-40:2003+
A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
LT
ATITIKIMO ES NORMOMS DEKLARACIJA
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Lenkija
pareiškia, prisiimdama atsakomybę, kad gaminys: Oro
sausintuvas: Modelis DH 41H atitinka EN 60335-240:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
LV
DEKLARĀCIJA PAR ATBILSTĪBU
ES DIREKTĪVĀM
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Polska
Līdz ar šo pasludina uz personīgu atbildību, ka produkts:
Gaisa sausinātāji: Modelis DH 41H atbilst direktīvām
EN 60335-2-40:2003+A1:2006+A11:2004+
A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
PL
DEKLARACJA ZGODNOŚCI Z
NORMAMI UE
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Polska
Oświadcza niniejszym na własną odpowiedzialność,
Ŝe produkt: Osuszacz powietrza: Model – DH 41H
jest zgodne z normą EN 60335-2-
40:2003+A1:2006+ A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
RO
DECLARAłIE DE CONFORMITATE
CU NORMELE UE
DESA Poland S.R.L. ul. Magazynowa 5a 62-023 Gądki,
Polska
Prin prezenta declar pe proprie răspundere că produsul :
Deumidificator: Model – DH 41H este realizat în
conformitate cu norma EN 60335-2-
40:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
RU
CERTIFIKAT O USKLADJENOSTI SA CE
STANDARDAMI
DESA Poland S.R.L. ul. Magazynowa 5a 62-023 Gądki,
Polska
Deklariše na sopstvenu odgovornost da je: Proizvod
označen kao "Isušivač" model DH41 uskladjen sa
direktivom br: EN 60335-2-
40:2003+A1:2006+A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
RU
ДЕКЛАРАЦИЯ СООТВЕТСТВИЯ
СТАНДАРТАМ ЕС
ООО «DESA Poland», ул. Magazynowa 5a 62-023
Gądki, Польша
Настоящим заявляет под собственную
ответственость, что продукт: Воздухоосушитель,
Модель - DH 41H соответствует стандартам
EN 60335-2-40:2003+A1:2006+A11:2004+
A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
SI
IZJAVA O SKLADNOSTI S
STANDARDI EU
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Poljska
S polno odgovornostjo izjavlja, da je izdelek: Sušilnik
zraka: Model – DH 41H skladen s standardom
EN 60335-2-40:2003+A1:2006+
A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-3:1995+A1:2001+A2:2005+IS1:2005
SK
PREHLÁSENIE ZHODNOSTI S NORMAMI EU
DESA Poland Sp. z o.o. ul. Magazynowa 5a 62-023
Gądki, Poľsko
Týmto na vlastnú zodpovednosť prehlasujeme, že
výrobok: Odvlhčovač vzduchu typu:
DH 41H zodpovedajú normám
EN 60335-2-40:2003+A1:2006+
A11:2004+A12:2005+AC:2006,
EN 60335-1:2002+A1:2004+A11:2004,
EN 50366:2003+A1:2006,
EN 55014-1:2006,
EN 61000-3-2:2006,
EN 55014-2:1997+A1:2001,
EN 61000-3-:1995+A1:2001+A2:2005+IS1:2005
47
BG
ИНФОРМАЦИЯ ОТНОСНО ОТСТРАНЯВАНЕ НА
ИЗНОСЕНО ЕЛЕКТРИЧЕСКО И ЕЛЕКТРОННО
ОБОРУДВАНЕ
Указаният по-горе знак поместен върху дадения уред
информира, че това е електрическо или електронно
оборудване, което - след износване - не бива да се събира
заедно с други видове отпадъци.
Износено електрическо и електронно оборудване съдържа
вещества вредни за околната среда. Такова оборудване не
бива да се складира по обикновените сметища, то трябва
да бъде подложено на рециклинг.
Информация относно система събиране на износеното
електрическо и електронно оборудване е достъпна по
местата на продаване на тези уреди, както и у
производителя или вносителя.
Тук призоваваме особено потребители на домашни уреди
в частни домакински стопанства. Тяхното участие в
селективно събиране на износените уреди е особено
значимо, понеже в този с ектор се намира мнозинството от
такова оборудване.
Забрана на поместване заедно с други отпадаци на
износеното електрическо и електронно оборудване се
налага върху потребителя от Европейската директива
2002/96/WE.
CZ
INFORMACE TÝKAJÍCÍ SE LIKVIDACE POUŽITÝCH
ELEKTRICKÝCH A ELEKTRONICKÝCH ZAŘÍZENÍ
Výše uvedený znak umístěný na zařízení informuje, že se
jedná o zařízení elektrické nebo elektronické, které nelze
umisťovat s jiným odpadem.
Použité elektrické a elektronické zařízení obsahuje příměsi
pro životní prostředí škodlivé. Takováto zařízení se nesmějí
uskladňovat na odpadních skládkách, ale musejí být předány
do recyklace.
Informace o systému sběru použitých elektrických a
elektronických zařízení je možné obdržet v prodejnách
zařízení a u producenta nebo dovozce.
Apel je určen zejména uživatelům zařízení v domácnostech.
Vzhledem k tomu, že do tohoto sektoru směřuje většina těchto
zařízení, je jejich účast při třídění použitých zařízení velmi
důležitá.
Zákaz umisťovat spolu s jiným odpadem použitá elektrická a
elektronická zařízení ukládá uživatelům evropská směrnice
2002/96/ES.
EE
INFORMATSIOON KASUTATUD ELEKTROONILISTE JA
ELEKRTISEADMETE LIKVIDEERIMISE KOHTA
See, seadmel olev märk informeerib, et tegemist on
elektrooniliste või elektriseadmetega, mida pärast lõplikku
kasutamist ei tohi hoida koos teiste jäätmetega.
Kasutatud elektrooniliste ja elektriseadmete koostises on
keskkonnale kahjulikke materjale. Selliseid seadmeid ei tohi
hoida prügilates, need tuleb anda ümbertöötlemiseks.
Informatsiooni kasutatud elektrooniliste ja elektriseadmete
kogumissüsteemist võib saada seadme müüjalt
müügikohtades ja tootjalt või maaletoojalt.
Erilist tähelepanu peaksid osutama tarbijad, kes kasutavad
nimetatud seadmeid eramajapidamises. Arvestades
asjaoluga, et sellesse sektorisse satub kõige rohkem
seadmeid, tähendab see, et nende osavõtt selektiivsest
kasutatud seadmete kogumisest on eriti tähtis.
Kasutatud elektrooniliste ja elektriseadmete hoidmine koos
teiste jäätmetega on tarbijaile keelatud vastavalt Euroopa
Liidu Direktiivile 2002/96/EB.
GB
INFORMATION RELATED TO WASTE
ELECTRICAL AND ELECTRONIC EQUIPMENT
If a device is marked with the above sign, it means this
electrical or electronic equipment must be collected separate
from other waste materials.
Waste electrical and electronic equipment contains substances
harmful for the natural environment. As such, it cannot be
disposed in a landfill; it must be recycled.
Information related to the collection of waste electrical and
electronic equipment can be obtained from the retail outlet or
the producer/importer.
This is especially addressed to individual households as most
of such devices are sold to that sector. This means that
individual users have a very significant contribution in the
collection of such waste equipment.
The ban on the disposal of waste electrical and electronic
equipment is enforced by the 2002/96/EC directive.
HR
INFORMACIJE KOJE SE TIČU UKLONJEVANJA
POTROŠENIH ELEKTRIČNIH ILI ELEKTRONSKIH
UREDJAJA
Gornji znak smješten na uredjaju informira, da ovo je uredjaj
električni ili elektronski kojega poslije potrošnje ne smije se
smještati sa drugim otpacima.
Potrošeni uredjaj električni ili elektronski sadrži tvari štetne za
prirodnu okolinu. Ne smije se takvih uredjaja stavljati na
stovarištima za smeće samo mora se predati za recykling.
Informacije o sistemu skupljanja potrošenih uredjaja
električnih ili elektronskih možete dobiti kod prodavaća i kod
proizvodjača ili uvoznika.
Posebnu pažnju molimo neka imaju potrošači uredjaja u
privatnom domaćinstvu jer do ovog sektora ide najveći broj
uredjaja. Znači, ih učešče u selektivnom zbiranju potrošenih
uredjaja ima bitan značaj.
Po direktivi evropskoj 2002/96/WE zabrajeno je smještavanje
potrošenih električnih ili elektronskih uredjaja zajedno sa
drugim otpacima.
HU
INFORMÁCIÓ A HASZNÁLT ELEKTROMOS ÉS
ELEKTRONIKAI BERENDEZÉSEK MEGSEMMÍTÉSÉRE
VONATKOZÓAN
A berendezésen elhelyezett fenntebb ábrázolt jel tájékoztat
arról, hogy ez egy elektromos vagy elektronikai eszköz,
melyet elhasználódás után nem szabad más hulladékokkal
közös hulladékgyőjtı helyeken tárolni.
A használt elektromos és elektronikai eszköz a természeti
környezetre káros anyagokat tartalmaz. Ilyen berendezést
nem szabad a szemétlerakó helyekre kitenni,
újrafeldolgozásnak kell alávetni.
A használt velektromos és elektronikai eszközök begyőjtési
rendszerérıl információ kapható a berendezés eladási helyén,
valamint a gyártónál vagy importernél
Külön felhívással fordulunk a háztartási berendezések
felhasználóihoz. Tekintettel arra, hogy ebben a szektorban
található a legtöbb ilyen készülék, ami azt jelenti, hogy nagyon
fontos a részvételük a használt berendezések szelektív
győjtésében.
A 2002/96/EK európai direktíva a felhasználóra nézve
kötelezıen írja elı a használt elektromos és elektronikai
eszközök más hulladékokkal való közös tárolásának tilalmát.
50
DESA EUROPE BV
Postbus 271, 4700 AG Roosendaal,
The Netherlands
www.desa.nl
DESA Italia SRL
Via Tione 12
Pastrengo, Verona (VR)
Italy 37010
www.desaitalia.com
DESA Poland Sp.z o.o.
ul. Magazynowa 5a
62-023 Gądki , Poland
www.desapoland.pl
DESA UK, Ltd.
Unit 3 Easter Court
Gemini Business Park
Warrington, Cheshire
WA5 7ZB United Kingdom
www.desauk.co.uk
Loading...
