FUNCTIONING PRINCIPLES
The unit is heating air that flows through it by combustion chamber and heat exchanger. Supply fuel is burnt in
combustion chamber. Flue gas goes through heat exchanger outside to the chimney.
Start of the device starts off the burner. After warming up the thermostat starts the fan. Cool air is sucked by fan.
After heating air id exhausted outside through outlet panel. The automatic and safe thermostat (with manual reset)
are responsible for safe and correct work of device. In case of too high temperature increase, automatic thermostat
cut of the fuel supply to the burner. After that unit is chilled to safe temperature and then starts again. In case of
critical temperature the unit is stopped by safe thermostat. Restart is only possible after chilling the unit and after
manual reset the safe thermostat. Can be operated optional in heat mode and vent mode (without burner).
TECHNICAL DATA
kW kW
Min capacity
Fuel consuption
Combustible Fan
Net weight
Gross weight
Noise level
Air displacement
Air outlet
Kcal/h Kcal/h
Btu/h Btu/h
kg/h 7,2
Oil / Kerosene
kg 200
kg 230
dB(A) 73
m³/h 6 200
mm 1 x 400
90
77 400
307 00
Max capacity
Fuel consuption
Power supply
Frequency
Rated current
Pressure
PACKING
Packaging dimensions
mm 1660 x 710 x 1660
110
94 600
375 000
kg/h 8,5
Plug-fan
V 220 - 240
Hz
A 6,8
Pa
50
500
Utilization dimensions
Pieces per pallet
Pieces per truck 80m³
mm 2150 x 720 x 1270
n° 1
n°
21
COMPONENTS
Burner
Nozzle
Igniter
Fuel filter
Motor
Fan
Room thermostat
Room thermostat
Tank
Air distribution hoses
Turning wheel
Mcs burner
2 GPH 60°S DANFOSS
electrodes
60 μm
asynchronous, monophase,
1400 g/1'
Plug fan Ø 600 mm
predisposed for connection to room thermostat
ACCESSORIES
thermostat TH5 - THD
150 l
flexible hoses 7,6 m
Pneumatic wheels
One way air-outlet panel
Other
Ø 400
Lifting arch, recirculation flange
WIRING DIAGRAM
