Mastech I-CS-MS2030 User guide

MS2030

AUTO RS232

A
V

AC Digital Clamp Meter
User’s Manual

CAT III

600 V

CONTENTS CONTENTS

1.Introduct ion ........... ........... ........... .. .......1

2.Safety Info rmation...... ........... ............. ...1

2.1 Precaut ions ........... ..... ..... ..... ............ ..... 1

2.2 Safety Sy mbols........ ........... ........... .. ..3

3. Descriptio n............ ........... ............. .......4

3.1 Front Panel .. ........... ........... .. ........... ....4

3.2 Display . ........... .. ........... ........... .. .......6

4. Using the Mete r .... .. .. .........................7

4.1 Data Hold . ........... .. ........... ........... .. ....7

4.2 DC Voltage . ............. ........... ........... .. ..7

4.3 AC Voltage . ............. ........... ........... .. ..7

4.4 AC Curren t............ ........... ........... .. ....8

4.5 Resista nce.......... ........... ........... .. ......8

4.6 Continu ity ........... ........... ........... .. ......9

4.7 Diode Te st .......... ........... .. ........... .....10

5. Specificat ions ................... .. .. ..........11

5.1 General S pecifications ........... ...........11

5.2 Technical Spec if ications... ........... .. ....11

6. Maintenanc e......... .. .. .......................14

6.1 General Main tenan ce ........ ........... ........14

6.2 Replaci ng the Batteries. ........... .........15

6.3 Replaci ng Test Leads.. ........... .. .........15

7. Ac ce ssories ....................................15

1.Introduct ion

WARNING

Make sure to read an d follo w all saf ety pro cedures
to avoid electri c shock a nd/or i njury.

The MS2030 is a safe , relia ble, ye t small handheld 3 ½
digit dig ital cl amp met er. Capa ble of measuring AC
current, AC/DC vo ltage , resis tance, diode’s forw ard
voltage drop, an d conti nuity, it’s i deal fo r both home
users and profes siona ls.

2.Safety Inst ru ctions

The MS2030 meets E N6101 0-1 saf ety requiremen ts for
electrical tes ting in strum ents and handhel d digit al
multimeters. I t’s d esigned to compl y with EN 61010 -1
with a CAT III 600V safety ra ting an d pollu tion degree of 2.

• All safety guidel ines ou tline d should be follow ed
otherwise the pr otect ion pro vided by the instr ument
may be impaired.

• War ning sy mbols in the manua l alert u sers of p otential
dangerous situ ation s.

• Precautions ar e to prev ent the u ser from damagin g
the instrument o r the tes t objec t.

2.1 Precaution s

To avoid poss ible el ectri c shock , personal injur y or
damage to the mete r, pleas e obser ve the following :

1. Before using th e meter, c heck th e meter for damage
during transpo rt.

2. Check the test le ads for d amage t o the insulation o r
wires before use .

3. Ensure the mete r works p roper ly by testing a know n
voltage first. I f not wor king pr operl y, have th e meter
serviced befor e using .

4. Never exceed th e prote ction l imit values indi cated
in the specifica tions f or each r ange of measurem ent.

5. Always use cauti on when m aking v oltage
measurements a bove 60 V dc or 30V a c rms.

6. Make sure to use th e corre ct inpu t jack, function a nd
range when measu ring.

7. Do not place the me ter in an y envir onment with dust ,
explosive gas or v apor.

8. Always keep fing ers beh ind the p robe barriers.

9. Connect the com mon tes t lead fi rst, th en the hot le ad.
Disconnect in re verse o rder.

10. Turn off powe r and dis charge capacit ors bef ore
measuring resi stanc e, diod es or continuity.

11. Fail ure to fo llow sa fety guideline s may pre vent th e
meter’s b uilt in protecti on from w orkin g properly.

12. To avoid d amage o r incorre ct read ings, c heck fo r AC
voltage presen t befor e makin g DC voltage
measurements .

13. Do not use the met er with t he batt ery cover not
securely in plac e.

14. When the “ ”symb ol appe ars, re place t he batter ies
to avoid incorre ct read ings

15. Before openi ng the ca se, alw ays disconnect t est
leads from all ene rgize d circu its.

16. Only use the tes t leads p rovid ed with the meter.
Replace only wit h simil ar lead s with matching
specificatio ns.

17. Do not touch inp ut jack s durin g measurement to
avoid electric s hock.

18. Before switc hing fu nctio ns, remove test le ads fro m
an circuit.

01 02

2.2 Safety Symbo ls

AUTO RS232

A
V

Note- Impor tant sa fety in formatio n, refe r to the
instr uctio n manua l.

Application around and removal from UNINSULATED
HAZARDOUS LIVE conductors is permitted.

Cauti on, pos sibil ity of el ectric sho ck

Equip ment pr otect ed thro ughout by do uble
insul ation o r reinf orced i nsulatio n.

Conforms to UL STD. 61010-1, 61010-2-032,
61010-2-033; Certified to CSA STD C22.2 NO.
61010-1, 61010-2-032,61010-2-033

Compl ies wit h Europ ean (EU ) safety sta ndard s
Earth ( groun d) TE RMINA L

Direc t curre nt

Altern ating c urren t

CAT III: MEASUREMENT CATEGORY III is applicable to
test and measuring circuits connected to the distribution
part of the building's low-voltage MAINS installation.

CAT II: MEASUREMENT CATEGORY II is applicable to test
and measuring circuits connected directly to utilization points
(socket outlets and similar points) of the low-voltage MAINS
installation.
CAT IV: MEASUREMENT CATEGORY IV is applicable to
test and measuring circuits connected at the source of the
building’s low-voltage MAINS installation.

3. Descriptio n

3.1 Front Panel

8

7

6

1

2

3

4

5

03 04

Tip s for mea suring resista nce:

- Sometimes the re sisto r value a nd measured resi stanc e
diffe r.This i s due to th e meter’s o utput test curre nt goes
through all poss ible pa ths bet ween leads.

- For low resistan ce meas ureme nts, short the tes t leads
and record the res istan ce disp layed. Then co nnect t o
the circuit and su btrac t the rec orded resistan ce from
the measuremen t for the m ost acc urate r esults.

WARNING

To avoid i njury o r damag e to the me ter, make su re
to turn off all powe r and dis charg e all cap acitors
before measuri ng resi stanc e.

4.6 Continuity

1. Turn off all pow er and di scharge capaci tors on t he
circuit under te st.

2. Insert the red te st lead i n the “IN PUT” ja ck and the
black lead in the “C OM” jac k.

3. Move the rotary s witch t o the pos ition . Connect
the test leads acr oss the c ircui t to be mea sured.

4. Read measured r esist ance on t he display. If th e
measured resis tance i s less th an 70Ω, the meter’s
buzzer will soun d.

WARNING

To avoid i njury o r damag e to the me ter, make su re
to turn off all powe r and dis charg e all cap acitors
before measuri ng cont inuit y.

4.7 Diode Test

1. Turn off all pow er and di scharge capaci tors on t he
circuit under te st.

2. Insert the red te st lead i n the “IN PUT” ja ck and the
black lead in the “C OM” jac k.

3. Move the rotary s witch t o the pos ition . Connect
the test leads acr oss the c ircui t to be mea sured.

4.Read the measu red for ward bi ased voltage dro p on the
display. If the l eads ar e reversed, only “ 1” is dis playe d.

WARNING

To avoid i njury o r damag e to the me ter, make su re
to turn off all powe r and dis charg e all cap acitors
before measuri ng diod es.

09 10

5. Specificat ions

5.1 General Spec ifica tions

•Safety rating: C AT III 600V, pollution deg ree 2

•Max. operating a ltitu de: 200 0m

•Operating temp eratu re: 0~4 0°C, <80% RH

•Storage temper ature : -10~6 0°C, <70% RH
(battery remov ed)

•Temperatu re coeffic ient: 0.1 accura cy/°C
(<18°C or >28°C)

•Max. voltage bet ween te rmina ls and
ground: 600V DC or AC r ms

•Sample rate: app rox. 3 ti mes/s ec

•Display : 3 ½ digit L CD (max . displ ay: 1999)

•Over-range ind icati on: dis play only shows “1 ”

•Low battery indi catio n: when b attery voltage d rops
below operatin g volta ge,“ ”s ymbol appears on t he
display

•Polarity indic ation : autom atically displ ays “-“

•Power: 3x 1.5V AAA batte ries

•Dimensi ons: 19 8mmX7 9mmX3 8mm

•Weigh t: appr ox. 194 g (with battery)

•Max. jaw opening : 26mm

5.2 Tech nical S pecif ications

Accuracy: ±(% of r eadin g + digit s), 1 year warrant y.
Ambient temp: 18 °C~28 °C, hum idity: <75%.
Temperature coeffic ient: 0.1 accura cy/°C
(0°C~18°C or 28° C~40° C)

mark

conduc tor

mark

mark

For AC current meas ureme nt, kee p the conductor in t he
center of the clam p; othe rwise t he reading can dev iate
as much as 1.5% of act ual mea surem ent.

5.2.1 DC Voltag e
Range

600V

Resolution

1V

Accuracy

±(1.0% reading +3 dgt)

- Input impedanc e: 10M

- Overload prote ction : 600V DC o r AC rms

- Max. input volta ge: 600 V DC

5.2.2 AC Volta ge

Range

600V

Resolution

1V

Accuracy

±(1.5% reading +10 dgt)

- Input impedanc e: 10M

- Overload prote ction : 600V DC o r AC rms

- Max. input volta ge: 600 V AC rms

- Frequency rang e: 50Hz ~60Hz

- Response: Ave rage; c alibrated to rms s ine wav e

11 12

4.5V

7

6.2 Replacing T he Batteries

To avoid e lectr ic shoc k, make sure that th e test
leads have been cl early m ove awa y from the
circuit under me asure ment be fore op ening the
battery cover of t he mete r.

WARNING

Do not mix ol d and new b atterie s. Do not m ix
alkalin e, stan dard (c arbon-z inc), o r rechargeable
(n i-cad , ni-mh , etc) batt eries .

5.1.1 If the sign “ ” appe ars, it means th at th e
bat terie s should be replace d.

5.1.2 Loose n the fi xing screw of the bat tery cover an d
rem ove it.

5.1.3 Repla ce th e exhaus ted batter ies with new ones.

5.1.4 Put the batte ry co ver back and fix it again to its
ori gin form.

Note:

Do no t reverse the po larity of the batte ries.

WARNING

6.3 Replacing Test Leads

Replace test lea ds if lea ds beco me damaged or worn .

Use meet EN 61010-031 standard, rated CAT III 600V, or
better test leads.

WARNING
