WIRED HEADPHONE
USER GUIDE
Applicable models: FXW, FXB
FLEX
Features:
•
• Bluetooth™ enabled for wireless connection
• SMD parts for powered amplification
• Built-in noise rejection circuitry
• Battery status LED with low battery audio indicator
• Auxiliary In & Out direct connection for music sharing
• 57mm oversized heavy duty speakers for high performance quality
• SUPER BASS button for powerful low frequency or enhanced sound quality
• Built in Omni-directional Microphone for phone calls with noise cancellation
• Multi-Function interface for Volume / Play / Pause / >> / << / Phone / Power / Mute
• USB Rechargeable lithium-ion battery with 30 Hours Music, 35 Hours Talk, 1200 Hours Standby
BBC™ Licensed collectable headphones
Specifications:
Connectivity: Wireless Bluetooth
Wireless Range: 33 Feet / 10 meters minimum
Direct Connect: 3.5mm Auxiliary In & Out
Drivers: 2 × 57mm , Dynamic
Battery Life: 30 hr. (varies upon volume and connection)
Battery: Rechargeable Lithium-ion via Micro USB
Impedance: 32 Ω
THD: ＜ 0.1%
Microphone: Omni-directional -43db, SNR>60dB
USB Port: Micro-USB, DC5V/1A
Frequency: 20Hz - 20KHz
Sensitivity: 110dB
™
Volume up / Next
Press button = volume up
Press and hold button = next song
Volume down / Previous
Press button = volume down
Press and hold button = previous song
Super Bass
Press both + & - on the Volume button to turn Super Bass on or off
Power ON-OFF / Play / Pause / Hands free / Force Paring / Mute
Press button = play or pause
Press and hold the button to power unit on or off
(If no Bluetooth connection is detected within 5 minutes the device will auto turn off)
When you receive a call, press once to answer, press once to mute and press once again to unmute , double click to end
Press and hold 2 seconds to reject phone calls
When you are on a call, press and hold the button to switch from headphone to phone
If you want to redial the last call, double click the button
Press and hold button for 3 seconds to Force pair Bluetooth
Button Interface
(1)
1 Volume up / Next track 4
2 Volume down / Previous track 5
3 Hands-free/ Force pairing 6
3 Play, Pause / Power On/Off 7
3 Power ON/OFF 8
3 Mute / Unmute 9
Superbass
Microphone
LED Indicator
USB charging port
AUX IN
AUX OUT
(8)
(2)
(3)
(4)
(5)
(6)
(7)
(9)
Bluetooth Pairing
MTBTH name is “TYPE 40 HEADPHONE”
MTWBTH name is ”DW HEADPHONE”
Turn on headphones, it will search for the last paired device and auto-pair to it
If no device can be auto-paired, the headphones will wait for a new device to connect
To force pair or un-pair hold the button for 3 seconds to start a new pairing
LED Indicator
Flashes blue = Looking for Bluetooth connection
Blue LED stays lit = Paired to device
Blue LED stays lit = Auxiliary connection
Blue LED stays lit = MIC & Speakers via USB active
Flashes red = Low Battery
Red LED stays lit = Unit is charging
Green LED stays lit = Unit is fully charged
Charging
We recommend turning off Headphones before charging
Connect headphones and power source via Micro-USB cable
The LED will be red while charging
The LED will be green when charging is completed
Auto Power Off
When no Bluetooth connection within 5 minutes
When the battery is too low
Accessories
Bluetooth headphone 1pcs
USB charging cable 0.8M 1pcs
AUX IN cable 1.3M 1pcs
User`s manual 1pcs
Warranty card 1pcs
Cloth bag 1pcs
TROUBLESHOOTING:
1 HEARING DISTORTION
A Lower the volume on your headphones and/or phone/device.
B Make sure it’s charged up. Check for low battery, then charge headphones via USB.
2 NOT LOUD ENOUGH?
A Turn up the volume on your phone/device or your Headphones.
B Make sure it’s charged up.
C Try plugging your headphones into your phone/device via 3.5mm cable.
3 UNABLE TO PAIR WITH BLUETOOTH® DEVICE?
A Confirm that your phone/device is Bluetooth™ compatible.
B Follow Bluetooth paring instructions in this guide page 4
C Visit www.massiveaudio.com/support
4 EXPERIENCING SIGNAL LOSS OR DROPOUTS VIA BLUETOOTH?
A Move headphones closer to your phone/device.
B Make sure it’s charged up.
C Turn off your headphones and phone/device, then power up and reconnect.
WARNING
Please read these safety warnings and cautions carefully to ensure your personal safety and prevent property damage.
Fire and Electric Shock Hazard
• Do not expose your Massive® Headphones to liquid, moisture, humidity, or rain. Do not use the Massive® Headphones near a bathtub, sink, sauna,
pool, or steam room. Exposure of the Massive® Headphones to moisture could result in electric shock.
• Do not drop, disassemble, open, crush, bend, deform, puncture, shred, microwave, incinerate, paint, or insert foreign objects in to the Massive®
Headphones. such actions could result in electric shock.
• Clean the Massive® Headphones only with a dry cloth.
• Do not expose your Massive® Headphones to extremely high or low temperatures.
• Do not leave your Massive® Headphones in direct sunlight for extended periods of time.
• Do not leave your Massive® Headphones near open flames such as cooking burners, candles, or fireplaces.
• Do not block any ventilation openings.
Battery/Charger Hazard
• Do not dispose of your Massive® Headphones in a fire. The battery could explode causing injury , death or paradox.
• Only charge the battery in accordance with the user instructions supplied with the Massive® Headphones.
• Do not attempt to disassemble the Massive® Headphones charger or force open the built-in battery because this may result in electric shock.
• Do not charge the Massive® Headphones in damp areas or in extremely high or low temperatures because this could result in electric shock.
• Do not clean the Massive® Headphones when it is being charged. Always unplug the charger first before cleaning the Headphones.
Automobile Accident Hazard
• Do not leave or store the Massive® Headphones near or over your automobile’s air bag because serious injury may result when an
air bag deploys.
• Do not place the Massive® Headphones on high surfaces such as shelves. During music playback the Headphones may fall.
CAUTION
• Do not use abrasive cleaners to clean your Massive® Headphones because this could cause scratches and damage.
• Do not bring your Massive® Headphones in to contact with any sharp objects because this could cause scratches and damage.
• Do not insert anything into your Massive® Headphones unless otherwise specified in the user instructions. This may damage the internal components.
• Do not attempt to repair, modify, or disassemble your Massive® Headphones yourself, it does not contain any user-serviceable components.
• Do not attempt to replace your Massive® Headphones battery, it is built-in and is not changeable.
• Keep out of the range of children under 10 years old to prevent choking on small removable parts.
• Use only the manufacturer suggested charger for your Massive® Headphones. Other chargers could result in electric shock and damage Headphones.
• Observe all signs and displays that require an electrical device or RF radio product to be switched off in designated areas.
• Turn off your Massive® Headphones prior to boarding an aircraft. Do not use the Massive® Headphones inside an aircraft unless allowed by your airline.
• Dispose of the Headphones and the Headphones’s battery in accordance with local regulations. Do not dispose of the battery with regular household waste.
• Any modification (such as removing the Headphones grill) to the device, without prior authorization from the manufacturer, may void your
warranty and authority to operate the device.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC NOTICE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1 This device may not cause harmful interference,
2 This device must accept any interference received, including interference that may cause undesired operation.
FCC CAUTION
• Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this
equipment.
• This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter.
This product is compliant with the CE directive. All returns must be made to the original place of purchase.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence
of un-isolated, dangerous voltage within the inside of the device that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and servicing
instructions in the literature accompanying the device. Read these instructions before operation. Keep these instructions for future
reference. Follow all instructions for installation, use and maintenance of the device. To avoid tilt or drop, place the device on a flat and
hard surface. To clean the device, turn off device first. Clean only with soft and dry cloth. To ensure compatibility, only use accessories
recommended by the manufacturer.When the device is suddenly moved from cold to warm surroundings, condensation may form in the
housing of the device. Before use, leave the device in the warm environment until the moisture evaporates. To ensure compatibility, only
use accessories recommended by the manufacture.
• Do not expose the device to sand or dust, or cover it with items, such as newspapers, table cloths, or curtains.
• Do not operate the device in an enclosed cabinet. Leave sufficient free space around the device for adequate ventilation.
Make sure that the power supply voltage is within the range indicated on the label on the device or power adapter. If you are not sure of
the type of power supply, consult you dealer or local power company. Do not attempt to repair or service the device yourself. Opening
or removing the cabinet may expose you to electric shock, and other hazards. If repair is required, contact your dealer and refer all
servicing to qualified service personnel. Do not use the device if any abnormality occurs. If any smoke or odor becomes apparent, unplug
the power cord and contact your dealer immediately. Do not try to repair the device yourself. Avoid using dropped or damaged appliances.
If the device is dropped and the housing is damaged, the internal components may not function normally. To reduce the risk of electric shock,
do not touch any connector with wet hands. Never remove the housing of the device. Never lubricate any part of the device. Never place the
device on top of any other electrical equipment. Never block ventilation openings. Install in accordance with manufactures instructions. This
equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection
to electrical earth.
RoHS COMPLIANCE
This product is in compliance with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction
of the use of certain hazardous substances in electrical and electronic equipment.
WEEE NOTICE
The directive on Waste Electrical and Electronic Equipment (WEEE0, which entered into force as European law on 13th February 2003,
resulted in a major change in the treatment at end of life. The purpose of this Directive is, as a first priority, the prevention of WEEE,
and in addition, to promote the reuse, recycle and other forms of recovery of such wastes so as to reduce disposal.mn The WEEE logo on the
product or on its box indicating collection for electrical and electronic equipment consists of the crossed-out wheeled bin, as shown above.
This product must not be disposed of or dumped with your other household waste. You are liable to dispose of all your electronic or electrical
Waste equipment by relocating over to the specified collection point for recycling of such hazardous waste. Isolated collection and proper
recovery of your electronic and electrical waste equipment at the time of disposal will allow us to help conserving natural resources . Moreover,
proper recycling of the electronic and electrical waste equipment will ensure safety of human health and environment. For more information
about electronic and electrical waste equipment disposal, recovery, and collection points, please contact your local city center, household waste
disposal service, shop from where you purchased the equipment, or manufacturer of the equipment.
GET MASSIVE SUPPORT
VISIT www.massiveaudio.com
CALL 1-323-262-2262
PURCHASE Other great Doctor Who™ products at www.massiveaudio.com
Become a fan of Massive Audio on Facebook® & Twitter
VISIT WWW.FACEBOOK.COM/TARDISSPEAKERS
VISIT WWW.TWITTER.COM/DRWHO_SPEAKERS
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Massive
Audio Inc. is under licence.
© 1999 Massive Audio, Inc. All rights reserved. MASSIVE® and LOGO are registered trademarks of Massive Audio, Inc. in the United
States and/or other countries.
©2014 MASSIVE. ALL RIGHTS RESERVED.
