The complete range of versatile, high performance tractors
HP
86-145
MF
54005400
VISION INNOVATION LEADERSHIP QUALITY RELIABILITY SUPPORT PRIDE COMMITMENT
The MF 5400 Series
04 Pure quality inside and out
06 A wide range of choice
Engines
08 Powerful delivery
10 PowerBoost
12 Dyna-4 Transmission & Power control
PTO & Hydraulics
16 Total operating flexibility
18 The perfect linkage system
A better working environment
20 Cab suspension
22 Cab interior
26 The essential tractor & loader combination
Straightforward, intuitive technology
28 TopCon technology
The ultimate platform
30 MF 5400 Series Platform tractors
32 Fast, easy routine maintenance
Ensuring a cost effective future for your business
34 Manager Service and Extended Warranty Plan
36 AGCO Aftersales Support
38 Customer testimonials
40 Specifications
44 MF 5400 Series highlights
If you haven’t yet discovered what makes the MF 5400 Series so
popular, then do your business justice and take a look
at the versatile line-up of mid-horsepower tractors from
Massey Ferguson. Powerful, fuel efficient engines and comfortable
cabs come as standard, whilst full factory-fitted, front-end loaders
can also be specified. For unsurpassed levels of performance and
versatility, look no further than the MF 5400 Series.
Discover the perfect partnership.
The MF 5400 Series from
Massey Ferguson.
Contents
02
03
Pure quality, inside
and out
Simply the perfect all-round
workhorse. From small stock to
large mixed farms, arable and
contracting businesses as well as
the municipal sector. Wherever
there are demanding operations
to tackle, the MF 5400 Series will
deal with them - effortlessly.
Rugged power is delivered from
86-145 hp through reliable, workhungry yet fuel efficient engines.
Now you can get even more power
from 6 km/h, in 3rd or 4th range,
with Massey Ferguson’s new,
torque-filled, PowerBoost feature.
All nine models have the superior
Dyna-4, semi-powershift
transmission with
Massey Ferguson’s industryleading Power Control Lever.
The MF 5400 is straightforward to
operate, while the ease of access
makes light work of jumping in
and out of the tractor all day, as a
multitude of tasks are completed.
It’s your tractor – you specify
Whatever your business requires,
whatever the job, the MF 5400
range can handle the toughest
tasks you can throw at it. Whether
mounted with the MF 900
Series front loader, operating a
high-capacity mower, pulling a
cultivator or hauling trailers, you’re
guaranteed maximum productivity.
The MF 5400 Series carries a
range of choices in bonnet design,
cab height and visibility to enable
purchasers to tailor their new
machine to precisely match the
tasks required of it.
The Visio roof option can be
specified, together with factoryinstalled sub-frame and hydraulics
for an MF 900 Series front loader,
all perfect for both dairy and arable
businesses.
The MF 5400 Series.
Get the job done!
04
05
A wide range of choice
At Massey Ferguson,
we understand the needs of
every individual. Whether you are
running a large-scale dairy unit
or family farm, each feature
and optional extra in the
MF 5400 Series has been
designed specifically to suit
your needs.
Key features throughout the
range include:
Industry-leading loader options
Get the complete package to
ensure optimum productivity
with our industry-leading
MF 900 Series loaders.
Styling, with clean, modern lines
The pivoting bonnet allows
improved access for regular
maintenance of the air filter
and radiators.
Pivoting cooling package
on the MF 5465/75
For easier access
and maintenance.
Latest generation Tier III engines
Emissions compliant, fuel-
efficient power units providing
improved power and torque
characteristics and less
fuel consumption.
Every Massey Ferguson tractor has outstanding attributes that
makes it the most popular and enduring choice within the
mid-horsepower sector.
Engine PowerBoost
Increasing power from 6 km/h
and when it’s needed most Better pulling capacity, improved
performance, transporting
heavier loads faster and reducing
journey times.
The superb Dyna-4
transmission as standard
Simple to use, four speeds
‘under load and on the go’ equals
less power loss.
New (optional) Integrated Front
Linkage System (IFLS) with
heavy duty front axle support
on the MF 5465/75
For greater strength and
manoeuvrability.
Power Take-off
Four PTO options plus
groundspeed PTO are available
allowing you to meet the demands
of your farm precisely.
Cab options
MF 5400 Series cabs can be
uniquely specified to give you the
best performance and productivity.
Choose from high-spec cab or
platform with ROPS and suncanopy with either a pivoting or
‘steep-nose’ bonnet.
A lower profile cab is available
for working in restricted height
buildings, whilst the Visio roof
option provides excellent visibility
when using a loader at height.
Optional Cab suspension
Get more productivity and
enjoyment from your working day,
and operate effortlessly in comfort.
This new cab suspension allows
you to graft for longer in a variety
of applications.
06
07
Torque reserve
B
A
The torque curve shows how ‘pulling
power’ is maintained as engine speed
falls and how it is increased with
PowerBoost right down to idle
A: Normal torque curve
B: Boosted Performance: extra torque,
available when 3rd or 4th range
is selected.
Torque (Nm)
Engine speed - rev/min
Powerful delivery
B
A
Power increase
Power (PS)
Engine speed - rev/min
High power, with power increase as
engine speed falls between 2200 and
2000 rev/min
A: Normal power curve
B: Boosted Performance: extra power,
available when 3rd or 4th range
is selected.
08
Technologically advanced, high powered and economical;
benchmarks in engine design that others can only aspire to.
Outstanding power comes from the latest Tier III common rail and
four-valve engines. Within its class, every MF 5400 Series tractor
benefits from the highest levels of performance and power.
Model range
Model Cylinder Engine capacity Max Power. hp PowerBoost hp
1
MF 5425 4 4.4 86 MF 5435 4 4.4 96 MF 5445 4 4.4 100 110
MF 5455 4 4.4 112 125
MF 5460 4 4.4 125 135
MF 5465 6 6.6 132 144
MF 5470 4 4.4 135 145
MF 5475 6 6.6 144 156
MF 5480 4 4.9 145 155
1
hp figures - ISO TR14396.
09
MF 5400 Series tractors have highly responsive engines that offer uncompromised performance and strength.
The excellent build quality and latest engine technology guarantees optimum fuel efficiency, maximum power, reliability
and longevity.
MF 5425/MF 5435 with
PowerMax! – turbocharged
to provide 86 and 96 hp, with
intercooled mechanical fuel
injection. Tried and trusted
engines within this range
guarantee exceptional power
and torque whilst maintaining
low emissions.
Power and torque
Maximum power is achieved
at 2000 rev/min, resulting in
significant fuel savings and lower
noise levels. In fact, these tractors
have excellent power delivery
capabilities across an impressively
wide speed range, with a constant
power range exceeding
400 rev/min.
Reassuring torque back-up means
you can reduce engine speed
when pulling away under load, or
on headland turn manoeuvres,
with ease and in safety.
MF 5445/55/60/65/70/75/80 with
PowerBoost!
A new generation of
4 & 6-cylinder engines
Incorporating the same advanced
engine technology as our higher
horsepower models, electronic
common rail fuel injection and
16 valves combine to deliver
95 hp - 135 hp.
Featuring impressive torque
capabilities and PowerBoost,
all models have significantly
more power at 2000 rev/min
than previously produced at
2200 rev/min.
PowerBoost
Perfect for use in transport mode
and when hauling heavy loads over
long distances. PowerBoost gives
additional engine power across the
full engine speed range from idle to
2200 rev/mins.
With PowerBoost as standard on
all models (excluding MF 5425 &
MF 5435) jobs such as
transportation, top work, spraying
and spreading on larger arable
farms are simple, economical and
efficient. There are no buttons or
switches, just let the engine do the
thinking.
When the operator selects either
3rd or 4th range, the engine will
automatically create ‘boost’,
providing more power and torque
all the way from 6 Km/h up to
40 Km/h.
As well as providing higher
maximum power, PowerBoost
also provides additional power at
lower engine speed for improved
productivity and greater
fuel savings.
Enhanced performance
and flexibility with
PowerBoost
10
Whether in the field or on the road, the latest engine technology
allows engine performance to be enhanced to maximise
productivity in a wide range of applications.
Getting more power, with
less effort
PowerBoost provides more power
and ultimately more productivity
with effortless performance,
whenever 3rd or 4th range is
selected. This functionality is
available on models from
MF 5445 up to the MF 5480.
The fuel injection system in each
engine is electronically managed,
allowing the characteristics of
engine performance to change and
accommodate the toughest tasks.
Electronic Engine Management
(EEM) monitors and increases
the amount of fuel being supplied
to the engine, so depending on
the application, additional power
and torque can be available
automatically through an
automated system.
Power + Performance
Extra power equals extra
performance and essentially
more productivity, particularly in
transport and haulage applications.
However, as 3rd range provides
forward speeds as low as 6 km/h
@ 1400 rev/min, the extra power
and torque is readily available
for many field applications such
as mowing, fertiliser spreading,
cultivation and baling.
For additional power in feeder/
mixer wagon and slurry pump
applications, PowerBoost is also
provided when the PTO is engaged
and the tractor is stationary.
0.0
5.0 10.0
15.0
20.0
25.0
30.0
35.0
40.0
4
3
2
1
8
7
6
5
12
11
10
9
16
15
14
13
Manure/slurry spreading
Round baling
Ploughing/cultivating
Fertiliser spreading/spraying
Mowing
Transport
11
6 km/h
Boosted power from 3A
Km/h
Reasons why
PowerBoost pays!
PowerBoost perfectly •
optimises engine
power
PowerBoost provides •
extra power when it’s
needed most!
PowerBoost •
maximises fuel
efficiency
Extra power from •
idling to maximum
engine revs!
Efficient engine •
operation thanks to
4-valves per cylinder
Left-hand control
The left-hand Power Control lever
provides convenient forward/
reverse shuttle, powershift and
range changes and fingertip
de-clutching, leaving the right
hand free to operate the loader
or rear implements.
Right-hand control
Simply move the T-shaped
transmission control lever forwards
or backwards to change up or
down through the four Dynashift
ratios. To change range, simply
press the range selection button as
you move the lever.
When changing range,
Speedmatching automatically
selects the correct Dyna-4 ratio to
match the tractor’s forward speed.
Comfort control
Smooth or fast shuttling – the
choice is yours – adjust the
Comfort Control knob and you
have the perfect tractor for
loader work.
Creep and Supercreep options
Close control in specialist lowspeed tasks is assured with an
additional 8 (creep) or
16 (supercreep) gears, enabling
forward speeds as low as 500m/hr
and 160m/hr respectively to
be achieved.
How you will benefit:
Optimum field performance, •
four mechanical range
changes provide 16 forward
and 16 reverse speeds, all
available without having to
use the clutch pedal!
12
Unbeaten design:
and Power
Control
The straightforward & efficient design behind the Dyna-4
transmission continues to impress with incredibly smooth 4-speed,
powershift change in each of the four gears, giving you first-rate
productivity, everytime.
02
Neutral
De-clutch
Forward drive
Reverse drive
Change up ratio
Change down ratio
N
01
01
Operation is simple and less •
repetitive with ergonomically
placed controls, reducing
operator fatigue and stress
The left-hand Power Control •
lever enables convenient and
straightforward operation
For rapid and precise loader •
work, Comfort Control
maintains stability during
smooth or fast shuttling
Speedmatching minimises •
operator effort and maximises
productivity
Straightforward design and •
proven, reliable components
provide exceptionally smooth
operation with strength and
longevity
40
3020151050
4
1
2
3
1400 2200
A
B
C
D
Main Range
Field working
range
Dynashift Range
Engine Speed
Forward/Reverse Speed
(MF 5455 16.9R38)
km/h
04
03
01 Simple, multi-function,
left-hand Power Control lever
02 The Dyna-4 ratios
03 Dyna-4 controls include
left- or right-hand gear selection
plus variable, operator-controlled
forward/reverse shuttle take-up
04 The Dyna-4 transmission offers
four Dynashift changes in each
range, excellent ground speed
‘overlap’ and 40 km/h maximum
speed for efficient haulage
operations
13
Precision and performance from Massey Ferg
u
14
Loading...
