UniView™
Operator's Manual
These operating instructions provide the necessary information for proper operation of all models of UniView. There may be information provided in this
manual that is not relevant for your system. General knowledge of pulse oximetry and an understanding of the features and functions of UniView are
prerequisites for its proper use. Do not operate UniView without completely reading and understanding these instructions.
Notice: Purchase or possession of this device does not carry any express or implied license to use with replacement parts which would, alone or in
combination with this device, fall within the scope of one of the relating patents.
CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician.
Masimo Corporation
52 Discovery
Irvine, CA 92618, USA
Tel.: 949-297-7000
Fax.: 949-297-7001
www.masimo.com
Patents: www.masimo.com/patents.htm
Masimo®, ®, O3®, Radical-7®, Radius-7®, rainbow®, Root®, and SedLine® are federally registered trademarks of Masimo Corporation.
Iris Gateway™, ISA™, Patient SafetyNet™, Rad-97™, and UniView™ are trademarks of Masimo Corporation. All other trademarks and registered trademarks
are property of their respective owners.
The use of the trademark PATIENT SAFETYNET is under license from University Health System Consortium.
© 2018 Masimo Corporation
Masimo Corporation www.masimo.com 1
Contents
About This Manual...................................................................................................................................................................................................................... 5
Product Description, Intended Use and Contraindications ........................................................................................................................................................ 7
Product Description ............................................................................................................................................................................................................... 7
Key Features ........................................................................................................................................................................................................................... 7
Intended Use ......................................................................................................................................................................................................................... 7
Contraindications .................................................................................................................................................................................................................. 7
Safety Information, Warnings and Cautions .............................................................................................................................................................................. 9
Safety Warnings and Cautions............................................................................................................................................................................................... 9
Performance Warnings and Cautions .................................................................................................................................................................................... 9
Cleaning and Service Warnings and Cautions..................................................................................................................................................................... 10
Compliance Warnings and Cautions ................................................................................................................................................................................... 10
Chapter 1: Description .............................................................................................................................................................................................................. 11
System Overview .................................................................................................................................................................................................................. 11
UniView Overview ................................................................................................................................................................................................................ 12
Chapter 2: Operation ................................................................................................................................................................................................................ 13
Opening the UniView Application ....................................................................................................................................................................................... 13
System Login ....................................................................................................................................................................................................................... 13
Selecting a Patient .............................................................................................................................................................................................................. 13
Selecting a Screen Layout ................................................................................................................................................................................................... 14
Visual Alarms Indicators ..................................................................................................................................................................................................... 20
Alarm Status Visualizer ....................................................................................................................................................................................................... 23
Changing Patients ............................................................................................................................................................................................................... 24
Advanced Features ............................................................................................................................................................................................................... 25
Chapter 3: Messages ................................................................................................................................................................................................................ 29
Messages .............................................................................................................................................................................................................................. 29
Chapter 4: Troubleshooting ...................................................................................................................................................................................................... 31
Troubleshooting UniView .................................................................................................................................................................................................... 31
Chapter 5: Specifications ........................................................................................................................................................................................................ 33
Compatible Masimo Systems ............................................................................................................................................................................................. 33
Symbols .............................................................................................................................................................................................................................. 33
Chapter 6: Warranty Information ............................................................................................................................................................................................ 35
Cleaning .............................................................................................................................................................................................................................. 35
Contacting Masimo ............................................................................................................................................................................................................. 35
Index ......................................................................................................................................................................................................................................... 37
Masimo Corporation www.masimo.com 3
About This Manual
This manual explains how to set up and use UniView™. Important safety information relating to general use of UniView appears in this manual. Read and
follow any warnings, cautions, and notes presented throughout this manual. The following are explanations of warnings, cautions, and notes.
A warning is given when actions may result in a serious outcome (for example, injury, serious adverse effect, death) to the patient or user.
WARNING: This is an example of a warning statement.
A caution is given when any special care is to be exercised by the patient or user to avoid injury to the patient, damage to this device, or damage to other
property.
CAUTION: This is an example of a caution statement.
A note is given when additional general information is applicable.
Note: This is an example of a note.
Masimo Corporation www.masimo.com 5
Product Description, Intended Use and Contraindications
Product Description
UniView is a supplemental display of parameter data and alarm conditions received from Point-of-Care (PoC) devices connected to Masimo Systems
(Patient SafetyNet or Iris Gateway).
The following PoC devices can display data on UniView via Patient SafetyNet or Iris Gateway Systems:
• Third-party devices
• Masimo devices
Key Features
UniView consists of the following components and/or features:
• Ability to communicate over an IEEE 802.11 (2.4 & 5 GHz) wireless or hard wired network.
• Ability to access parameter data from multiple PoC devices through Masimo Systems.
• Ability to display supplemental visual alarm conditions at different alarm priorities for parameter data received through a Masimo System.
• Multiple screen layout options:
• Overview Layout (See Overview Layout on page 15)
• Hemodynamics Layout (See Hemodynamics Layout on page 17)
• Oxygenation Layout (See Oxygenation Layout on page 18)
• Sedation Layout (See Sedation Layout on page 19)
Intended Use
UniView is a software application, intended to provide supplemental display of patient monitoring data, and run on off-the-shelf hardware devices.
UniView communicates with networked devices in healthcare environments.
Contraindications
There are no contraindications.
Masimo Corporation www.masimo.com 7
Safety Information, Warnings and Cautions
Note: Please refer to the Operator's Manual or Directions For Use for UniView host device.
Safety Warnings and Cautions
WARNING: Do not adjust, repair, open, disassemble, or physically modify the UniView host device. Injury to personnel or equipment damage could occur.
Return the UniView host device for servicing.
WARNING: If UniView host device fails any part of the setup procedures or electrical safety tests, remove the device from operation until qualified service
personnel have corrected the situation.
WARNING: Do not place the UniView host device where it may be accessible by patients.
WARNING: Do not use the UniView host device if it appears or is suspected to be wet or damaged.
WARNING: Do not use unauthorized devices with UniView. Possible loss of performance and/or patient injury may result.
WARNING: Do not place the UniView host device in any position that might cause it to fall on the patient.
WARNING: Do not use UniView in the presence of flammable anesthetics or other flammable substance in combination with air, oxygen-enriched
environments or nitrous oxide to avoid risk of explosion.
WARNING: UniView host device should only be used in clinical environments in which it is approved to prevent patient injury or damage.
WARNING: To protect against injury, follow the directions below:
• Avoid placing the host device or accessories on surfaces with visible liquid spills.
• Do not soak or immerse the host device in liquids.
• Use cleaning solutions only as instructed in this operator's manual.
Performance Warnings and Cautions
WARNING: UniView does not generate or manage audible alarms. The connected device's alarms, used in conjunction with clinical signs and symptoms,
are the primary sources for determining that an alarm condition exists.
WARNING: UniView may be used during defibrillation. However, to reduce the risk of electric shock, the operator should not touch the UniView during
defibrillation.
WARNING: Do not use the UniView during magnetic resonance imaging (MRI) or in an MRI environment.
CAUTION: UniView is intended to be a supplemental display. Medical decisions should be made using data from the primary display of a device in
conjunction with clinical signs and symptoms.
CAUTION: UniView is intended to operate across the facility's network. Unanticipated failure or alteration of network components (including but not
limited to: disconnection or malfunctioning of a networking device/switch/router/ethernet cable) may result in loss of connectivity of UniView to other
hospital systems. Altering or making changes to the hospital network should be done with proper knowledge.
CAUTION: The Quality of Service (QoS) of the connectivity to the Point-of-Care (PoC) devices may be affected by:
• Network failure
• Increased number of connected devices on the network
• Modifications to the network
• Presence of devices provided with radio transmitters
• Improper network configuration and/or on PoC
• Signal priorities of the network
• Latency
CAUTION: Network performance may be affected by changes in the network including the addition of additional network devices.
CAUTION: Host device performance may be affected by changes in the host device software settings or operating system updates.
CAUTION: PoC performance may be affected by changes in the PoC software settings or updates.
CAUTION: To prevent tampering and ensure security, follow the directions below:
• UniView should be located with responsible personnel
• Unauthorized changes should not be made to UniView
Masimo Corporation www.masimo.com 9
UniView Safety Information, Warnings and Cautions
CAUTION: Do not place the UniView host device on or near electrical equipment that may affect the device and prevent it from working properly.
CAUTION: To ensure proper system operation, always verify successful connection between PoC devices and UniView.
CAUTION: To ensure the host device receives enough signal strength, verify the host device is within range of the hospital network.
CAUTION: To prevent unauthorized access to patient information, enable security measures as part of the host device.
Note: Patient monitoring data displayed on the UniView is based upon the time stamp provide by the PoC device. UniView times may not be
synchronized to the PoC device.
Cleaning and Service Warnings and Cautions
WARNING: Do not autoclave, pressure sterilize, or gas sterilize the UniView host device.
WARNING: Clean and only use as instructed in the Operator's Manual for the UniView host device.
Note: Modifications to UniView's settings, and those of any components connected to UniView, should be made by qualified personnel only.
Note: UniView host device installation must be completed by Masimo or an authorized service personnel.
Compliance Warnings and Cautions
WARNING: Do not attempt to repair or modify any part of UniView host device doing so may void the warranty or the authorization to use the UniView
host device.
WARNING: The software settings of the UniView host device should be completed by authorized personnel only.
WARNING: Disposal of product - Comply with local laws in the disposal of UniView host device and/or its accessories.
WARNING: When using devices with wireless features, consideration should be taken to local government frequency allocations and technical parameters
to minimize the possibility of interference to/from other wireless devices.
WARNING: In accordance with international telecommunication requirements, the frequency band of 2.4 GHz and 5.15 to 5.25 GHz is only for indoor
usage to reduce potential for harmful interference to co-channel mobile satellite systems.
Note: Refer to the UniView host device's Operator's Manual or Directions For Use for UniView for FCC compliance information before use.
Masimo Corporation www.masimo.com 10
•
•
facility. See Adding a System on page 25.
•
• The UniView application is pre-installed on the host device and compatible only with an Android operating system.
Chapter 1: Description
System Overview
The diagram below describes how UniView receives patient data from PoC devices. The PoC devices, Masimo System, and UniView host device must be
configured to the same hospital network.
Ref Component Description
Point-of-Care (PoC)
1
2 Hospital Network
3 Masimo System
4 UniView
Devices
A device that provides bedside patient monitoring.
IEEE 802.11 (2.4 & 5 GHz) wireless or hard wired network communication
• PoC devices, Masimo System, and host device are configured to the same hospital network.
Note: Refer to the appropriate device operator's manual for network configuration instructions.
The Masimo System is a Patient SafetyNet/Iris Gateway server.
• The Masimo System receives patient data from PoC devices and sends patient data to UniView through a secured
connection.
• UniView displays patient data from one Masimo System. To view a different Masimo System, see Changing Systems
on page 27.
• Multiple Masimo Systems can be added to UniView to view patient data from different care stations in a hospital
UniView requires a host device and display.
• The host device is a computer or mobile device with an Android operating system.
Masimo Corporation www.masimo.com 11
UniView Chapter 1: Description
• Viewing the current version of UniView (See UniView Software Version on page 25)
•
• Sedation Layout (See Sedation Layout on page 19)
UniView Overview
The image and table below describe UniView features.
Ref Feature Description
Alarm Status
1
Icon
2 Main Menu
3 Room Number
4 Patient Label
View Selection
5
Menu
Supplemental visual indicator for alarm conditions of a PoC device connected to a Masimo System. (See Alarm Status Icon on
page 20)
Note: See the appropriate device operator's manual for setting alarm conditions.
Displays the following options:
• Enabling/disabling alarm status visualizer animation (See Enabling/Disabling Visualizer Animation on page 23)
• Viewing a different patient (See Changing Patients on page 24)
• Disconnecting from a Masimo System (See System Disconnection on page 27)
• Displays the patient's location within a hospital facility.
Displays the label of the patient currently being viewed.
Note: Patient labels are edited in the Patient SafetyNet application. See the Operator's Manual, Patient SafetyNet Supplemental
Alarm System, Series 5.5.X.X or higher for more information.
Displays the following screen layout options:
• Overview Layout (See Overview Layout on page 15)
• Hemodynamics Layout (See Hemodynamics Layout on page 17)
• Oxygenation Layout (See Oxygenation Layout on page 18)
Masimo Corporation www.masimo.com 12
Chapter 2: Operation
Opening the UniView Application
To open the UniView application:
1. Click the UniView icon to start the application . The splash screen will appear while the application is loading.
• If the application is not installed or incorrectly installed on the host device, see Contacting Masimo on page 35.
• If the application is being opened for the first time, a Masimo System must be added. See Adding a System on page 25.
• If the application was previously used, then the last used Masimo System will be automatically selected and appear at the top of the login
System Login
1. Open the UniView application. The last used Masimo System name will appear at the top of the login screen.
2. Enter the Masimo System username and password credentials. The username and password are provided by your hospital Patient SafetyNet
3. Click Login.
screen. See System Login on page 13.
administrator.
4. After successful login, the Select Patient screen is displayed. See Selecting a Patient on page 13. If unable to login to the Masimo System, see
Troubleshooting on page 31.
Selecting a Patient
After logging into a Masimo System in UniView, the Select Patient screen displays a patient list.
To select a patient:
1. Click the desired patient name in the patient list. If a patient is not in the list:
• The patient may have not been admitted to the Masimo System. Only authorized personnel can admit a patient to a Masimo System.
Contact your hospital Patient SafetyNet administrator.
• The patient may have been admitted to a different Masimo System. To switch to a different Masimo System, see Changing Systems on
page 27.
2. After selecting a patient, the Overview screen (the default layout screen) displays patient data. The selected patient's label and room number
will appear at the bottom of the screen.
3. Verify the patient label and room number displayed in UniView matches the patient label displayed on the PoC and the patient's actual room
number.
• For further description of the Overview screen, see Overview Layout on page 15.
• To select a different screen layout, see Selecting a Screen Layout on page 14.
• To view a different patient in the same Masimo System, see Changing Patients on page 24.
Masimo Corporation www.masimo.com 13
UniView Chapter 2: Operation
Selecting a Screen Layout
CAUTION: Always verify the parameter data displayed on the UniView layout screens match the parameter data displayed on the corresponding PoC. If
the parameter data is incorrect or not displayed, see Troubleshooting on page 31.
Four screen layout options are available to view patient data in UniView:
• See Overview Layout on page 15.
• See Hemodynamics Layout on page 17.
• See Oxygenation Layout on page 18.
• See Sedation Layout on page 19.
To select a screen layout option:
1. Login to a Masimo System and select a patient. See System Login on page 13.
2. In the bottom-left of the Overview screen, click the View Selection Menu [1] to view the screen layout options.
3. Click a screen layout option [2] to view a parameter data.
4. Click anywhere outside of the View Selection Menu to close the menu.
Masimo Corporation www.masimo.com 14
UniView Chapter 2: Operation
•
• No waveforms visible if
capnography is disconnected
Overview Layout
The Overview screen is the default layout screen displayed after selecting a patient.
The Overview screen displays 8 windows: [1] Anesthesia or Ventilator, [2] Capnography, [3] Infusion Pump, [4] SedLine, [5] O3 Regional Oximeter
(Forehead Right), [6] O3 Regional Oximeter (Forehead Left), [7] Third-Party Monitor, and [8] rainbow.
CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter
data does not match or does not display on UniView, see Troubleshooting on page 31.
Ref Window Description Parameter/Waveform Displayed Window Visibility
Anesthesia or
1
Ventilator
• Displays one Anesthesia or Ventilator
device.
• First connected Anesthesia or
Ventilator device has highest priority
and its data will be displayed.
• Window expands when capnography
and pump devices are disconnected
or powered off.
• Refer to the appropriate device
operator's manual for more
information.
PEEP, Ppeak, Pmean, PLAT, Vte, Ve,
, FiO2
EtO
2
Note: Parameters displayed if available
by device.
• Pressure, volume, and flow
waveforms
Note: Waveforms displayed if available
by device.
• Always visible
capnography is connected
• All 3 waveforms are visible if
capnography and pump are not
connected
•
Pressure waveform is visible if
pump is connected and
Masimo Corporation www.masimo.com 15
UniView Chapter 2: Operation
•
information.
•
INRMT
• Displays one SedLine device.
information.
•
information.
•
information.
•
• Displays multi-parameter rainbow
information.
Ref Window Description Parameter/Waveform Displayed Window Visibility
Displays one capnography device.
2 Capnography
• Window expands when pump devices
are disconnected or powered off.
Refer to the appropriate device
•
operator's manual for more
• EtCO2, FiCO2, RR
• CO2 waveform
• Visible when capnography
device is connected
3 Infusion Pump
4 SedLine
O3 Regional
5
Oximeter (Forehead
Right)
O3 Regional
6
Oximeter (Forehead
Left)
7 Third-Party Monitor
8 rainbow
• Refer to the appropriate device
operator's manual for more
information.
• Window expands when O3 Regional
Oximeter devices are disconnected
from Root.
•
Refer to the appropriate device
operator's manual for more
Forehead Right sensor data is
displayed left side of screen.
• Refer to the appropriate device
operator's manual for more
Forehead Left sensor data is displayed
right side of screen.
• Refer to the appropriate device
operator's manual for more
• Refer to the appropriate device
operator's manual for more
information.
parameter measurements from a
Masimo device.
• Window expands when the
third-party monitor is disconnected
or powered off.
•
Refer to the appropriate device
operator's manual for further
INVTB
• INVI
• INRT
•
• PSi, EMG, SR, SEFL, SEFR, ARTF
• EEG waveform
• rSO2, Delta Baseline (Δbase), Delta
(ΔSpO2)
SpO
2
• rSO2, Delta Baseline (Δbase), Delta
SpO
(ΔSpO2)
2
Temperature, NiBP Systolic, NiBP
Diastolic, ECG HR, PVC, CVP, ST
aVL, ST aVR
Note: Parameters displayed if available
by device.
• The first 8 parameters are
displayed (based on priority)
• Pleth, Signal IQ, and Resp Env
waveforms
• Visible when pump device is
connected
• Always visible
• Visible when an O3 sensor is
connected
• Visible when an O3 sensor is
connected
• Visible when connected
• Always visible
• Expands if third-party monitor
is not connected
Masimo Corporation www.masimo.com 16
UniView Chapter 2: Operation
•
Hemodynamics Layout
The Hemodynamics screen displays the following channels: [1] Masimo device or Third-Party Monitor, [2] rainbow, [3] Anesthesia or Ventilator, and [4]
Capnography.
Additionally, trend settings [5] for SpHB, PVi, and PR can be adjusted incrementally. See Trend Settings on page 20.
CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter
data does not match or does not display on UniView, see Troubleshooting on page 31.
Ref Description
• Displays Masimo device or third-party monitoring parameters.
1
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual
for further information about parameters.
Displays rainbow parameters:
• SpHB, PVi, and PR (Displayed with trends)
2
• SpO
and RRa
2
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual
for further information about parameters.
3
• Displays anesthesia or ventilator device parameters.
4
• Displays capnography device parameters and CO
waveform.
2
5 See Trend Settings on page 20.
Masimo Corporation www.masimo.com 17
UniView Chapter 2: Operation
•
Oxygenation Layout
The Oxygenation screen displays the following channels: [1] Masimo device or Third-Party Monitor, [2] rainbow, [3] Anesthesia or Ventilator, and [4]
Capnography.
Additionally, trend settings [5] for SpHB, ORi, and SpO
CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter
data does not match or does not display on UniView, see Troubleshooting on page 31.
Note: ORi is currently not available in the U.S.A. and territories relying on FDA market clearance.
can be adjusted incrementally. See Trend Settings on page 20.
2
Ref Description
• Displays Masimo device or third-party monitoring parameters.
1
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual
for further information about parameters.
Displays rainbow parameters:
• SpHB, ORi, and SpO2 (Displayed with trends)
2
• SpOC, SpCO, RRa, and Pleth waveform
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual
for further information about parameters.
Note: ORi is currently not available in the U.S.A. and territories relying on FDA market clearance.
3
• Displays anesthesia or ventilator device parameters, pressure waveform, and flow waveform.
4
• Displays capnography device parameters and CO
waveform.
2
5 See Trend Settings on page 20.
Masimo Corporation www.masimo.com 18
UniView Chapter 2: Operation
•
•
Sedation Layout
The Sedation View screen displays the following channels: [1] Masimo device or Third-Party Monitor, [2] rainbow, [3] Anesthesia or Ventilator, [4]
Capnography, [5] SedLine, and [6] O3 Regional Oximeter data.
Additionally, trend settings [7] for EMG, PSi, and SR can be adjusted incrementally. See Trend Settings on page 20.
CAUTION: Verify parameter data displayed on the UniView layout screen matches parameter data displayed on the corresponding PoC. If the parameter
data does not match or does not display on UniView, see Troubleshooting on page 31.
Ref Description
Displays Masimo device or third-party monitoring parameters.
1
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual for
further information about parameters.
Displays rainbow parameters SpO2 and SpHB.
2
Note: Masimo device parameters have the highest display priority over third-party parameters. Refer to the appropriate device operator's manual for
further information about parameters.
3
• Displays anesthesia or ventilator device parameters.
4
• Displays capnography device parameters.
5
• Displays SedLine device parameters and waveforms.
6
• Displays O3 device parameters.
7
• See Trend Settings on page 20.
Masimo Corporation www.masimo.com 19
UniView Chapter 2: Operation
Trend Settings
Use the trend setting buttons in the Hemodynamics, Oxygenation, and Sedation screen layouts to configure trend viewing.
To configure trend settings of specific parameters and measurements, see the appropriate device Directions for Use or Operator's Manual.
Option Factory Default Setting Configurable Settings
Default Duration 10 minutes
10, 20, 30, and 45 minutes
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 18, 24, 48, and 96 hours
Visual Alarms Indicators
Alarm Status Icon
The Alarm Status Icon is a visual indicator of a device's alarm status.
CAUTION: If the visual alarms are not displayed or incorrect, see Troubleshooting on page 31.
Note: UniView does not generate or manage alarms. The connected devices alarms are a primary for determining that an alarm condition exists.
Icon Appearance Description
There are currently no active alarms, and no alarms have been silenced.
There is currently at least one active alarm that has not been silenced.
Masimo Corporation www.masimo.com 20
UniView Chapter 2: Operation
•
• A red glow pulses behind the red pill shape.
• A red glow pulses behind the alarming parameter if the parameter is viewable in the screen layout.
• The alarming parameter font color is white during alarm.
Parameter Alarms
Alarming Parameters Displayed on a Layout Screen
If an alarming parameter is viewable on a layout screen [3], the parameter that has exceeded the alarm limit (for example, SpO
the screen [2].
) is displayed at the top of
2
Ref Description
1 The alarm icon is red during alarm.
2
3
4 The organ corresponding to the alarming parameter is colored red.
A red pill shape message at the top-center of the screen shows the alarming parameter.
• If more than 1 parameter is alarming, the parameters are shuffled.
Masimo Corporation www.masimo.com 21
UniView Chapter 2: Operation
•
The red glow pulses behind pill shape.
Alarming Parameters Not Displayed on a Layout Screen
If an alarming parameter is not viewable on a layout screen, then the source of the alarming parameter (for example, SEDLINE) and the parameter that
has exceeded the alarm limit (for example, PSi) are displayed at the top of the screen [2].
Ref Description
1 The alarm icon is red during alarm.
2
A red pill shape message at the top-center of the screen shows the source of the alarming parameter and the alarming parameter.
• If more than 1 parameter is alarming, the parameters are shuffled.
•
3 The organ corresponding to the alarming parameter is colored red.
Masimo Corporation www.masimo.com 22
UniView Chapter 2: Operation
• Disconnected PoC device
• No monitoring
• Successful connection to PoC device
•
the Masimo System
•
• Monitoring: alarm range
Alarm Status Visualizer
The Alarm Status Visualizer is a 3D image of a human body displayed on all layout screens. The 3D image displays organ animations and color coded
alarm conditions.
Enabling/Disabling Visualizer Animation
The lungs and heart in the 3D image can be animated based on rainbow parameter values. The lungs will animate based on RRa and RRp parameter
values, and the heart will animate based on PR parameter values.
To enable/disable the Alarm Status Visualizer animation:
1. In the upper-right corner of a layout screen, click the Options menu .
2. Select (enable) or deselect (disable) the Animation box.
Visualizer Color Description Table
Colors are used to represent the status of monitoring and alarm conditions.
1
Ref Color Description
1 Gray
2 Green
• Monitoring: normal range
Successful connection to PoC device
3 Yellow
4 Red
• Monitoring: Statuses, notifications, modifiers, notification devices not
assigned to patient, or patient has not been successfully admitted to
Successful connection to PoC device
2
3
4
Masimo Corporation www.masimo.com 23
UniView Chapter 2: Operation
Parameter Visualization Table
Monitoring and alarm status for various parameters and/or measurements are visualized using the following areas/organs on the screen:
Parameter or Measurement Area Displayed on Visualization Screen
PR Heart
PVi
Vascular
SpHb Vascular
SpMet Vascular
Pi N/A
SpOC N/A
SpO2 Lung
SpCO Lung
RRa Lung
ORi* Lung
PSi** Brain
rSO2*** Brain
*ORi is currently not available in the U.S.A. and territories relying on FDA market clearance.
** For use with SedLine Sedation Monitor, when connected to Root.
*** For use with O3 Regional Oximeter, when connected to Root.
Changing Patients
The Change Patient option is used to view different patients in the same Masimo System.
To change patients:
1. In the upper-right corner of a layout screen, click the Options menu .
2. Click Change Patient in the drop-down menu.
3. Click OK to confirm leaving the current patient. The Select Patient screen will be displayed.
4. In the Select Patient screen, click the desired patient name. The selected patient's data will be displayed on the Overview screen.
• For a description of the Overview screen, or to select a different screen layout, see Selecting a Screen Layout on page 14.
• If a patient is not in the Select Patient screen:
• The patient may need to be added to the Masimo System. To add a patient to a Masimo System, see the Operator's Manual, Patient
SafetyNet Supplemental Alarm System, Series 5.5.X.X or higher or see Contacting Masimo on page 35.
• The patient may have been added to a different Masimo System. To disconnect from the current system and login to a different
Masimo System, see Changing Systems on page 27.
Masimo Corporation www.masimo.com 24
UniView Chapter 2: Operation
Advanced Features
Setting Up and Installing
The UniView application is pre-installed on the host device. If the application is not installed or incorrectly installed on the host device, see Contacting
Masimo on page 35.
All required equipment and setup instructions are included with the host device. Refer to the host device instructions for host device video and network
connections.
UniView software updates are installed by authorized personnel. See Contacting Masimo on page 35.
If the host device was damaged during shipping, see Contacting Masimo on page 35.
WARNING: The software settings of the UniView host device should be completed by authorized personnel only.
UniView Software Version
To view the UniView software version:
1. In the upper-right corner of a layout screen, click the Options menu . The UniView version number release will be displayed below the
Masimo logo in the Options menu.
2. Click anywhere on the screen to close the Options menu.
Adding a System
Masimo System(s) must be added to UniView when UniView is opened for the first time. Additional Masimo Systems can be added to UniView after first
time use.
WARNING: The software settings of the UniView host device should be completed by authorized personnel only.
To add a Masimo System to UniView (first use of application):
1. Open the UniView application.
2. In the bottom-right of the Select System screen, click the add system icon .
3. In the Add System screen, enter the system information:
Item Description
Name Create a label for the Masimo System.
IP Address Enter the Masimo System server IP address.
Choose System Type Select either SafetyNet or Iris Gateway.
Note: Contact an authorized hospital Patient
SafetyNet administrator to obtain an IP address.
Secured Connection Enable secured connection (toggle blue).
Client Certification (.bks) Select the appropriate .bks file.
Password Enter the certificate password.
Masimo Corporation www.masimo.com 25
UniView Chapter 2: Operation
4. Click the check mark icon in the upper-right corner of the screen to save the system. The added system will appear in the Select System
screen.
5. Click the desired system to login. See System Login on page 13.
To add a Masimo System to UniView (after first use of application):
1. In the top-right corner of the System Login screen, click the switch screen icon .
2. In the bottom-right corner of the Select System screen, click the add system icon .
3. In the Add System screen, enter the system information:
Item Description
Name Create a label for the Masimo system.
IP Address Enter the Masimo System server IP address.
Note: Contact an authorized hospital Patient SafetyNet
administrator to obtain an IP address.
Choose System Type Select either SafetyNet or Iris Gateway.
Secured Connection Enable secured connection (toggle blue).
Client Certification (.bks) Select the appropriate .bks file.
Password Enter the certificate password.
4. When all required fields are completed, click the check mark icon in the upper-right corner of the screen to save the system. The added
system will appear in the Select System screen.
5. Click the desired system to login. See System Login on page 13.
Editing a System
A Masimo System can be edited when system information changes.
WARNING: The software settings of the UniView host device should be completed by authorized personnel only.
To edit a system in UniView:
1. Go to the login screen by doing one of the following:
• Open the UniView application and go to step 2, or
• Disconnect from the current Masimo System and go to step 3.
2. Click the switch screen icon .
3. In the Select System screen, click and hold anywhere on a system tile. The system information will appear.
4. Edit the system information as needed.
Note: Only qualified Masimo personnel can edit system information. See Contacting Masimo on page 35.
Note: If IP address information needs to be edited, contact an authorized hospital Patient SafetyNet administrator to obtain IP address
information.
Masimo Corporation www.masimo.com 26
UniView Chapter 2: Operation
5. To save the edits, click the check mark icon in the upper-right corner of the screen. The Select System screen will re-appear.
6. Click the desired system to login. See System Login on page 13.
Changing Systems
Patients in different Masimo Systems can be viewed by changing to a different system.
Note: To understand more about Masimo Systems, see the Operator's Manual, Patient SafetyNet Supplemental Alarm System, Series 5.5.X.X or higher.
To change to a different Masimo System:
1. While logged into a Masimo System, click the Options menu .
2. Click Disconnect in the drop-down menu.
3. Click OK to confirm disconnection from the current system. The Select System screen will be displayed.
4. In the Select System screen, click the desired system. If the desired system is not shown, see Adding a System on page 25. After selecting a
system, the system name is displayed at the top of the System Login screen.
5. In the login screen, type the Username and Password credentials.
6. Click Login.
7. After successful login, the Select Patient screen displays the system's patient list. See Selecting a Patient on page 13.
Deleting a System
CAUTION: If a system is accidentally deleted from UniView, only qualified Masimo personnel can add a system. See Contacting Masimo on page 35.
To delete a system in UniView:
1. Go to the login screen by doing one of the following:
• Open the UniView application and go to step 2, or
• Disconnect from the current Masimo System and go to step 3.
2. Click the switch screen icon .
3. In the Select System screen, click and hold anywhere on the system tile. The system information will appear.
4. In the upper-right corner of the screen, click the trash can icon to delete the system.
5. When the "Delete System?" message appears, click OK. After successful deletion, the Select System screen will re-appear without the deleted
system.
System Disconnect
To Disconnect from a Masimo System:
1. In the upper-right of a layout screen, click the Options menu .
2. Select Disconnect in the drop-down menu.
3. Select OK to confirm disconnection from the current system. After successfully disconnecting from the system, the Select System screen is
displayed.
Masimo Corporation www.masimo.com 27
• Enter a valid Masimo System username. To
hospital Patient SafetyNet administrator.
•
hospital Patient SafetyNet administrator.
and the name field is empty.
administrator.
• Displayed when adding a system
supplied.
•
empty.
•
no file explorer exists.
Chapter 3: Messages
Messages
Message Potential Causes Next Steps
Username Required
Password Required
Add a system to continue.
System Name Required
Valid System IP Address Required
Certificate Required
Certificate Password Required
No file explorer application installed
Unable to connect due to incompatible protocol
versions. The app protocol version is X.X.X.X, while
the system protocol version is X.X.X.X.
• Username field is empty.
• Password field is empty.
• Initial launch of UniView
• No systems added.
• Displayed when adding a system
and an invalid IP Address is
Displayed when adding a system
and the certificate selection is
• Displayed when adding a system
and the name field is empty.
Displayed when adding a system
and trying to select a certificate and
• Displayed when attempting to
connect to a system with an
incompatible protocol version.
obtain the Masimo System username, contact the
Enter a valid Masimo System password. To obtain
the Masimo System password, contact the
• Contact the hospital Patient SafetyNet
administrator.
• Contact the hospital Patient SafetyNet
• Contact the hospital Patient SafetyNet
administrator.
• Contact the hospital Patient SafetyNet
administrator.
• Contact the hospital Patient SafetyNet
administrator.
• Contact the hospital Patient SafetyNet
administrator.
• Contact the hospital Patient SafetyNet
administrator.
Masimo Corporation www.masimo.com 29
•
page 35.
•
• Masimo System settings have changed.
•
• Hospital network settings changed.
•
shipping.
Chapter 4: Troubleshooting
Troubleshooting UniView
The following section lists possible symptoms, the potential cause, and next steps.
Symptom Potential Causes Next Steps
UniView does not turn on
Masimo System cannot connect
to PoC
Forgot Masimo System login
and/or password
PoC device parameters are not
being displayed
• Internal failure
• The Masimo System, PoC, or host device is not
connected to a network.
• The Masimo System, PoC, or host device is not
on the same network.
• An incorrect IP address for the Masimo System
is entered into UniView.
• Masimo System software version is not
compatible with UniView software version.
• Hospital network stops working or is operating
incorrectly.
• Hospital network settings changed.
• Login and password are required to access a
Masimo System.
• The PoC may be disconnected or not powered
ON.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Ensure the PoC device is enabled for WiFi or Ethernet.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Ensure both the Masimo System and the PoC device are
configured to the same network.
• Ensure the destination IP address of the PoC device is
the Masimo System IP address.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact hospital Patient SafetyNet administrator.
• Contact hospital Patient SafetyNet administrator.
Confirm the PoC device is ON.
• Confirm the PoC device is displaying parameter data.
• Confirm the PoC device is connected to the same
network as the Masimo System and host device.
•
Contact Masimo Service. See Contacting Masimo on
Masimo Corporation www.masimo.com 31
The Masimo System and/or PoC device are not
connected to a network.
• The Masimo System stops working or operates
incorrectly.
• The Masimo System and PoC are not on the
same network.
Hospital network stops working or is operating
incorrectly.
Host device display not compatible to display
format.
• Host device settings or operating system
updates may be needed.
• Host device does not operate correctly or stops
operating.
Host device may have been damaged during
•
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact hospital Patient SafetyNet administrator.
• Refer to the host device setup instructions.
• Contact Masimo Service. See Contacting Masimo on
page 35.
UniView Chapter 4: Troubleshooting
SafetyNet.
page 35.
•
• Masimo System settings have changed.
•
• Hospital network settings changed.
•
shipping.
•
page 35.
software
page 35.
•
page 35.
•
• Masimo System settings have changed.
•
• Hospital network settings changed.
•
shipping.
Symptom Potential Causes Next Steps
•
Waveforms are not displayed
Waveforms have not been enabled in Patient
• Contact Masimo Service. See Contacting Masimo on
Incorrect patient monitoring data
being displayed
UniView is interrupted
intermittently
• The PoC may be disconnected or not powered
ON.
The Masimo System and/or PoC device are not
connected to a network.
• The Masimo System stops working or operates
incorrectly.
• The Masimo System and PoC are not on the
same network.
Hospital network stops working or is operating
incorrectly.
Host device display not compatible to display
format.
• Host device settings or operating system
updates may be needed.
• Host device does not operate correctly or stops
operating.
Host device may have been damaged during
•
• Power cord not connected to host device or
power outlet.
• Network equipment loses power.
• Confirm the PoC device is ON.
• Confirm the PoC device is displaying parameter data.
• Confirm the PoC device is connected to the same
network as the Masimo System and host device.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact hospital Patient SafetyNet administrator.
• Refer to the host device setup instructions.
• Contact Masimo Service. See Contacting Masimo on
page 35.
Check power cord connections and condition of power
cord.
• Refer to the host device setup instructions.
• Contact hospital Patient SafetyNet administrator.
•
Contact Masimo Service. See Contacting Masimo on
•
Unable to hear audible alarms
Unable to receive visual
message/alarm indicators
Masimo Corporation www.masimo.com 32
Audible alarms are not provided in your current
• The PoC may be disconnected or not powered
ON.
The Masimo System and/or PoC device are not
connected to a network.
• The Masimo System stops working or operates
incorrectly.
• The Masimo System and PoC are not on the
same network.
Hospital network stops working or is operating
incorrectly.
Host device display not compatible to display
format.
• Host device settings or operating system
updates may be needed.
• Host device does not operate correctly or stops
operating.
•
Host device may have been damaged during
• Contact Masimo Service. See Contacting Masimo on
Confirm the PoC device is ON.
• Confirm the PoC device is displaying parameter data.
• Confirm the PoC device is connected to the same
network as the Masimo System and host device.
•
Contact Masimo Service. See Contacting Masimo on
• Contact Masimo Service. See Contacting Masimo on
page 35.
• Contact hospital Patient SafetyNet administrator.
• Refer to the host device setup instructions.
• Contact Masimo Service. See Contacting Masimo on
page 35.
Chapter 5: Specifications
Compatible Masimo Systems
The following Masimo Systems are compatible with UniView:
System Version
Patient SafetyNet v5.5.x.x or higher
Iris Gateway v1.5.x.x or higher
Symbols
Symbols Definition
Follow Instructions for use
Non-Sterile
Not made with natural rubber latex
Instructions/Directions for Use/Manuals are available in electronic format @http://www.Masimo.com/TechDocs
Note: eIFU is not available for CE mark countries.
Masimo Corporation www.masimo.com 33
Chapter 6: Warranty Information
Cleaning
Refer to the host device Operator's Manual for cleaning and maintenance instructions.
Contacting Masimo
Masimo Corporation
52 Discovery
Irvine, California 92618
Tel:+1 949 297 7000
Fax:+1 949 297 7001
Limited Warranty
Masimo warrants to the initial buyer only that these products, when used in accordance with the directions provided with the Products by Masimo, will be
free of defects in materials and workmanship for a period of six (6) months. The foregoing is the sole and exclusive warranty applicable to the products
sold by Masimo to buyer. Masimo expressly disclaims all other oral, express or implied warranties, including without limitation any warranties of
merchantability or fitness for particular purpose. Masimo’s sole obligation and buyer’s exclusive remedy for breach of any warranty shall be, at Masimo’s
option, to repair or replace the product.
Exclusions
The warranty does not apply to any non-Masimo branded product or any software, even if packaged with the Product, or any Product that was: (a) not new
or in its original packaging when supplied to purchaser; (b) modified without Masimo’s written permission; (c) supplies, devices, or systems external to
the Product; (d) disassembled, reassembled, or repaired by anyone other than a person authorized by Masimo; (e) used with other products, like new
sensors, reprocessed sensors, or other accessories, not intended by Masimo to be used with the Product; (f) not used or maintained as provided in the
operator’s manual or as otherwise provided in its labeling; (g) reprocessed, reconditioned, or recycled; and (h) damaged by accident, abuse, misuse, liquid
contact, fire, earthquake or other external cause.
No warranty applies to any Product provided to Purchaser for which Masimo, or its authorized distributor, is not paid; and these Products are provided
AS-IS without warranty.
Limitation of Warranty
Except as otherwise required by law or altered by the purchase agreement, the above warranty is the exclusive warranty that applies to the Product and
software media, and Masimo does not make any other promises, conditions, or warranties regarding the Product. No other warranty applies, express or
implied, including without limitation, any implied warranty of merchantability, fitness for a particular purpose, satisfactory quality, or as to the use of
reasonable skill and care. See the licensing terms for the terms and conditions that apply to and Software accompanying the Product. Additionally,
Masimo will not be liable for any incidental, indirect, special, or consequential loss, damage, or expense arising from the use or loss of use of any Products
or Software. In no event shall Masimo’s liability arising from any Product or Software (under contract, warranty, tort, strict liability, or otherwise) exceed
the amount paid by purchaser for the Product or Software. The above limitations do not preclude any liability that cannot legally be disclaimed by
contract.
Sales & End-User License Agreement
This document is a legal agreement between you (“purchaser”) and Masimo Corporation (“Masimo”) for the purchase of this Product (“Product”) and a
license in the included or embedded Software (“Software”) except as otherwise expressly agreed in a separate contract for the acquisition of this Product,
the following terms are the entire agreement between the parties regarding your purchase of this Product. If you do not agree to the terms of this
agreement, promptly return the entire Product, including all accessories, in their original packages, with your sales receipt to Masimo for a full refund.
Masimo Corporation www.masimo.com 35
UniView Chapter 6: Warranty Information
Restrictions
1. Copyright Restrictions: The Software and the accompanying written materials are copyrighted. Unauthorized copying of the Software,
including Software that has been modified, merged, or included with other software, or the written materials is expressly forbidden. Purchaser
may be held legally responsible for any copyright infringement that is caused or incurred by Purchaser’s failure to abide by the terms of this
Agreement. Nothing in this License provides any rights beyond those provided by 17 U.S.C. §117.
2. Use Restrictions: Purchaser may physically transfer the Product from one location to another provided that the Software is not copied.
Purchaser may not electronically transfer the Software from the Product to any other device. Purchaser may not disclose, publish, translate,
release, distribute copies of, modify, adapt, translate, reverse engineer, decompile, disassemble, or create derivative works based on the
Software or the written materials.
3. Transfer Restrictions: In no event may Purchaser transfer, assign, rent, lease, sell, or otherwise dispose of the Product or the Software on a
temporary basis. Purchaser shall not assign or transfer this License, in whole or in part, by operation of law or otherwise without Masimo's prior
written consent; except that the Software and all of Purchaser’s rights hereunder shall transfer automatically to any party that legally acquires
title to the Product with which this Software is included. Any attempt to assign any rights, duties or obligations arising hereunder other than as
set forth in this paragraph shall be void.
4. U.S. Government Rights: If Purchaser is acquiring Software (including the related documentation) on behalf of any part of the United State
Government, the following provisions apply: the Software and documentation are deemed to be “commercial software” and “commercial
computer software documentation,” respectively pursuant to DFAR Section 227.7202 FAR 12.212, as applicable. Any use, modification,
reproduction, release, performance, display or disclosure of the Software (including the related documentation) by the U.S. Government or any
of its agencies shall be governed solely by the terms of this Agreement and shall be prohibited except to the extent expressly permitted by the
terms of this Agreement.
Masimo Corporation www.masimo.com 36
Index
Limited Warranty • 35
Login and Add System Messages • 29
A
About This Manual • 5
Adding a System • 11, 13, 25, 27
Advanced Features • 25
Alarm Status Icon • 12, 20
Alarm Status Visualizer • 23
C
Changing Patients • 12, 13, 24
Changing Systems • 11, 13, 24, 27
Chapter 1
Description • 11
Chapter 2
Operation • 13
Chapter 3
Messages • 29
Chapter 4
Troubleshooting • 13, 14, 15, 17, 18, 19, 20, 31
Chapter 5
Specifications • 33
Chapter 6
Warranty Information • 35
Cleaning • 35
Cleaning and Service Warnings and Cautions • 10
Compatible Masimo Systems • 33
Compliance Warnings and Cautions • 10
Contacting Masimo • 13, 24, 25, 26, 27, 31, 32, 35
Contraindications • 7
O
Opening the UniView Application • 13
Overview Layout • 7, 12, 13, 14, 15
Oxygenation Layout • 7, 12, 14, 18
P
Parameter Alarms • 21
Parameter Visualization Table • 24
Performance Warnings and Cautions • 9
Product Description • 7
Product Description, Intended Use and Contraindications • 7
R
Restrictions • 36
S
Safety Information, Warnings and Cautions • 9
Safety Warnings and Cautions • 9
Sales & End-User License Agreement • 35
Sedation Layout • 7, 12, 14, 19
Selecting a Patient • 13, 27
Selecting a Screen Layout • 13, 14, 24
Setting Up and Installing • 25
Symbols • 33
System Disconnect • 12, 27
System Login • 13, 14, 26, 27
System Overview • 11
D
Deleting a System • 27
T
Trend Settings • 17, 18, 19, 20
Troubleshooting UniView • 31
E
Editing a System • 26
Enabling/Disabling Visualizer Animation • 12, 23
Exclusions • 35
H
Hemodynamics Layout • 7, 12, 14, 17
I
Intended Use • 7
U
UniView Overview • 12
UniView Software Version • 12, 25
V
Visual Alarms Indicators • 20
Visualizer Color Description Table • 23
K
Key Features • 7
L
Limitation of Warranty • 35
Masimo Corporation www.masimo.com 37
www.masimo.com
39132/LAB-9770B-0618
Loading...
