Page 1
THE ULTIMATE
OUTDOOR EXPERIENCE
Refrigeration Ice MachinesBeer Dispensers
• •
Page 2
Page 3
Page 4
Energy-efcient
Durable Stainless
Appliances
Steel Construction
Page 5
World Class Refrigeration
Designed for the Elements
Exclusive
Dynamic Cooling
Technology™
C
Certied for Outdoor
Performance
US
Page 6
The Essential Elements
of Outdoor Living
Dynamic Cooling
Certied for performance to
Technology
Rapidly cools and delivers
the industry’s best
temperature stability
™
withstand the elements
Tested to 115° F
H
i
g
h
T
R
n
a
i
C
o
r
r
n
o
i
s
o
e
m
p
e
r
u
t
a
r
e
Energy-efcient appliances
with precise temperature
management
2
i
a
c
r
l
e
m
m
o
C
P
o
w
Corrosion-resistant
stainless steel exterior,
sturdy pro-style handle
and rugged toe kicks
G
r
a
d
e
d
r
o
e
C
r
H
i
g
h
H
u
Security locks standard on all
refrigerators and dispensers
m
y
t
i
d
i
Page 7
Refrigerators
24" Marvel Outdoor Refrigerator with MaxStore™
Utility Bin and Door Storage
Model # MO24RAS2**
• Dynamic Cooling Technology™ rapidly cools and
delivers the industry’s most even temperature stability
• Marvel Prime™ controls for precise, frost-free
temperature management between 34° and 42° F
• Audible alarms for door ajar and high/low temperature
ensure your contents stay at optimal temperature
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
• Fully-adjustable, cantilever FreshFlo™ stainless steel
slide-out full width shelf
Storage Capacity
Up to 146 12-oz cans
5.1 cu. ft.
Storage Conguration
(1) Full-width slide-out and (1) half-width cantilevered,
fully adjustable perforated stainless steel shelf
(1) Fixed steel-framed glass shelf
(1) MaxStore™ Utility Bin
Tall Bottle Door Storage
Product Dimensions
23 ⅞" W x 33 ¾" minimum H x 26 7/₃₂" D
(including handle)
• Easy-access door storage accommodates tall bottles
• Door lock provides added security
• Efcient white LED lighting illuminates arctic white interior
• Close Door Assist System™ gently nishes closing the door
• Corrosion-resistant stainless steel exterior, sturdy
pro-style handle and rugged 4" adjustable at toe grill
• Height adjustment up
to 1" with leveling legs
• 1-year warranty
Ordering Details
Solid Stainless Steel Door with
Lock, Right Hinge
Solid Stainless Steel Door with
Lock, Left Hinge
Model
Number
MO24RAS2RS
MO24RAS2LS
3
Page 8
Refrigerators
15" Marvel Outdoor
All Refrigerator
Model # MO15RAS2**
Storage Capacity
Up to 70 12-oz cans
2.7 cu. ft.
Storage Conguration
(2) cantilevered, fully
adjustable slide-out
stainless steel shelves
Product Dimensions
14 ⅞" W x 33 ¾" minimum H x
26
7
/₃₂" D (including handle)
Ordering Details
Model
Number
Solid Stainless Steel Door with
Lock, Right Hinge
MO15R AS2RS
Solid Stainless Steel Door with
Lock, Left Hinge
MO15RAS2LS
• Dynamic Cooling Technology™ rapidly
cools and delivers the industry’s most even
temperature stability
• Marvel Prime™ controls for precise, frost-free
temperature management between 34° and
42° F
• Audible alarms for door ajar and high/low
temperature ensure your contents stay at
optimal temperature
• Thermal-efcient insulated cabinet ensures
optimum energy efciency and cooling
performance
• Two fully-adjustable, cantilever FreshFlo™
stainless steel slide-out shelves
• Door lock provides added security
• Efcient white LED lighting illuminates arctic
white interior
• Close Door Assist System™ gently nishes
closing the door
• Corrosion-resistant stainless steel exterior,
sturdy pro-style handle and rugged 4"
adjustable at toe grill
• Filler kit available for 18" wide opening
• Height adjustment up to 1" with leveling legs
• 1-year warranty
55
24" Marvel Outdoor Refrigerator
Model # MO24RAS1**
• Dynamic Cooling Technology™ rapidly cools and delivers
the industry’s most even temperature stability
• Marvel Prime™ controls for precise, frost-free temperature
management between 34° and 42° F
• Audible alarms for door ajar and high/low temperature
ensure your contents stay at optimal temperature
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
• Two fully-adjustable, cantilever FreshFlo™ stainless steel
shelves
• Door lock provides added security
• Efcient white LED lighting illuminates arctic white interior
Storage Capacity
Up to 154 12-oz cans
5.3 cu. ft.
Storage Conguration
(2) cantilever, fully adjustable FreshFlo™ stainless steel
commercial-grade steel shelves
Product Dimensions
Refrigerators
23 ⅞" W x 33 ¾" minimum H x 26 7/₃₂" D (including handle)
4
• Close Door Assist System™ gently nishes closing the door
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handle and rugged
4” adjustable at
toe grill
• Height adjustment
up to 1” with
leveling legs
• 1-year warranty
Ordering Details
Solid Stainless Steel Door with
Lock, Right Hinge
Solid Stainless Steel Door with
Lock, Left Hinge
Model
Number
MO24RAS1RS
MO24RAS1LS
Page 9
15" Marvel Outdoor
All Refrigerator
Model # MO15RAS2**
• Dynamic Cooling Technology™ rapidly
cools and delivers the industry’s most even
temperature stability
• Marvel Prime™ controls for precise, frost-free
temperature management between 34° and
42° F
• Audible alarms for door ajar and high/low
temperature ensure your contents stay at
optimal temperature
• Thermal-efcient insulated cabinet ensures
optimum energy efciency and cooling
performance
• Two fully-adjustable, cantilever FreshFlo™
stainless steel slide-out shelves
• Door lock provides added security
• Efcient white LED lighting illuminates arctic
white interior
• Close Door Assist System™ gently nishes
closing the door
• Corrosion-resistant stainless steel exterior,
sturdy pro-style handle and rugged 4"
adjustable at toe grill
• Filler kit available for 18" wide opening
• Height adjustment up to 1" with leveling legs
• 1-year warranty
Refrigerators
Storage Capacity
Up to 70 12-oz cans
2.7 cu. ft.
Storage Conguration
(2) cantilevered, fully
adjustable slide-out
stainless steel shelves
Product Dimensions
14 ⅞" W x 33 ¾" minimum H x
7
26
/₃₂" D (including handle)
Ordering Details
Solid Stainless Steel Door with
Lock, Right Hinge
Solid Stainless Steel Door with
Lock, Left Hinge
Model
Number
MO15R AS2RS
MO15RAS2LS
55
Page 10
24" Marvel Outdoor Refrigerated Drawers
Model # MO24RDS3NS
• Dynamic Cooling Technology™ rapidly cools and delivers
the industry’s most even temperature stability
• Marvel Prime™ controls for precise, frost-free temperature
management between 34° and 42° F
• Audible alarms for door ajar and high/low temperature
ensure your contents stay at optimal temperature
• Thermal-efcient insulated cabinet ensures optimum energy
efciency and cooling performance
• Drawer interior durably constructed from stainless steel, the
most hygienic, easy-to-clean and stain-resistant of materials
• Drawer lock provides added security
• Efcient white LED lighting
• Close Door Assist System™ gently nishes closing the
drawer
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handles and rugged 4" adjustable at toe grill
• Height adjustment
up to 1" with leveling
legs
• 1-year warranty
Storage Capacity
Top Drawer:
Up to 73 12-oz cans
Bottom Drawer:
Up to 60 12-oz cans
Up to 133 12-oz cans in total
5.0 cu. ft.
Product Dimensions
Refrigerated Drawers
6
23 ⅞" W x 33 ¾" minimum H x 26 7/₃₂" D (including handle)
Ordering Details
Solid Stainless With Lock MO24RDS3NS
Model
Number
Page 11
Marvel Outdoor
Beer Dispensers
No other beer dispenser
compares to the storage
versatility of Marvel
Beer Dispensers
Half Barrel or
Slim Quarter
Two Sixth Barrels
or Cornelius Kegs
Full Beverage Storage
Tall Quarter Barrel or Pony
Keg with Beverage Storage
Double-insulated
tower reduces
foam on pour
and prevents
condensation
Easy to clean integrated
drain system keeps
spillage under control
7
Page 12
Marvel Outdoor Mobile & Built-In Beer Dispensers
Ordering Details (Single Tap, Built-in Models) Model Number
Solid Stainless Steel Door, Single Tap, Right Hinge MO24BSS2RS
Solid Stainless Steel Door, Single Tap, Left Hinge MO24BSS2LS
Ordering Details (Twin Tap, Built-in Models) Model Number
Solid Stainless Steel Door, Twin Tap, Right Hinge MO24BTS2RS
Solid Stainless Steel Door, Twin Tap, Left Hinge MO24BTS2LS
Ordering Details (Single Tap, Mobile Models) Model Number
Solid Stainless Steel Door, Single Tap, Right Hinge MO24BSSMRS
Ordering Details (Twin Tap, Mobile Models) Model Number
Solid Stainless Steel Door, Twin Tap, Right Hinge MO24BTSMRS
Model # MO24B*****
• Dynamic Cooling Technology™ rapidly cools and delivers
the industry’s most even temperature stability
• Two exclusive stow-on-board shelves convert unit to an
all-refrigerator capable of storing perishables
• Marvel Prime™ controls for precise, frost-free temperature
management between 34° and 46° F
• Audible alarms for door ajar and high/low temperature
ensure your contents stay at optimal temperature
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
• Lo-Boy coupler makes it easier to store, tap and swap out
tall barrels
• Secure CO2 tank storage area and drain bottle
• Includes tower, drain pan, 5 lb. CO2 tank, hoses,
Storage Capacity
Stores half barrel, quarter barrel (pony keg), sixth barrels/
Cornelius kegs, slim quarters, growlers, bottles or cans
5.7 cu. ft.
Storage Conguration
(2) stow-on-board, commercial-grade stainless steel
shelves convert unit to an all-refrigerator
connectors and oor shield
• Door lock provides added security
• Close Door Assist System™ gently nishes closing the door
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handle and rugged 4" adjustable at toe grill
• Locking casters and stainless steel mug rail for durable
mobility (Mobile Models)
• Rear port for external CO2 tank option
• 1-year warranty
Product Dimensions
Built-In
23 ⅞" W x 33 ¾" minimum H x 26 7/₃₂" D
(including handle)
Mobile
23 ⅞" W x 33 ¾" (+3 ¾" for casters) minimum H x 26 7/₃₂" D
(including handle)
Beer Dispensers
8
To view Marvel Beer Dispenser accessories, see page 12.
Page 13
The World's Best
Beer Dispenser
Beer Dispensers
Twin tap options available.
Mobile model features locking
casters and stainless steel mug rail
for durable mobility
9
Page 14
15" Marvel Outdoor Clear Ice Machine
Ice Machines
15" Marvel Outdoor
Crescent Ice Machine
Model # 25OiM-SS-F*
Ordering Details
Model
Number
Solid Stainless Door, Right Hinge 25OiM-SS-F-R
Solid Stainless Door, Left Hinge 25OiM-SS-F-L
• Produces up to 7 lbs. and stores 15 lbs. of crescent ice
cubes in 24 hours
• No drain required
• Removable ice bucket for easy serving and cleaning
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
• Close Door Assist System™ gently nishes closing the door
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handle and rugged 4” adjustable at toe grill
• Filler kit available for 18” wide opening
• Height adjustment up to 1” with leveling legs
• 1-year warranty
Storage Capacity
Up to 15 lbs of crescent ice
Product Dimensions
14 ⅞" W x 33 ¾" minimum H x 24 5/32" D (including handle)
11
Model # 3OiMT****
• Produces up to 34 lbs. and stores 30 lbs. of clear ice cubes
• Stainless steel ice cutter for consistent cube size and shape
• Sound-buffering ice deector greatly reduces cube
impact noise
• High-efciency, low maintenance condenser system
designed for built-in zero clearance installations
• Thermal-efcient insulated cabinet ensures optimum energy
efciency and cooling performance
• Equipped with cleaning mode
• Ice scoop included
• Close Door Assist System™ gently nishes closing the door
• Includes 20’ non-kink drain hose and clamp
• Available with or without factory-installed drain pump (see
model numbers for ordering)
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handle and rugged 4" adjustable at toe grill
• Filler kit available for 18” wide opening
• Height adjustment up to 1” with leveling legs
• 1-year warranty
Storage Capacity
Up to 30 lbs of clear ice
Product
Dimensions
14 ⅞" W x 33 ¾" minimum
H x 26 ¼" D
(including handle)
Enjoy crystal-clear
Ordering Details
Solid Stainless Door, Right Hinge 3OiMT-SS-F-R
Solid Stainless Door, Left Hinge 3OiMT-SS-F-L
Solid Stainless Door, Right Hinge
with factory installed drain pump
Solid Stainless Door, Left Hinge
with factory installed drain pump
"
¾
Model
Number
3OiMT-SS-F-R-P
3OiMT-SS-F-L-P
ice optimally shaped to
keep your beverages
cooler, longer.
Ice Machines
10
Page 15
15" Marvel Outdoor
Crescent Ice Machine
Model # 25OiM-SS-F*
• Produces up to 7 lbs. and stores 15 lbs. of crescent ice
cubes in 24 hours
• No drain required
• Removable ice bucket for easy serving and cleaning
• Thermal-efcient insulated cabinet ensures optimum
energy efciency and cooling performance
• Close Door Assist System™ gently nishes closing the door
• Corrosion-resistant stainless steel exterior, sturdy pro-style
handle and rugged 4” adjustable at toe grill
• Filler kit available for 18” wide opening
• Height adjustment up to 1” with leveling legs
• 1-year warranty
Ice Machines
Storage Capacity
Up to 15 lbs of crescent ice
Product Dimensions
14 ⅞" W x 33 ¾" minimum H x 24 5/32" D (including handle)
Ordering Details
Solid Stainless Door, Right Hinge 25OiM-SS-F-R
Solid Stainless Door, Left Hinge 25OiM-SS-F-L
Model
Number
11
Page 16
Beer Dispenser Accessories
Ice Machine Accessories
01. Twin Tap Dispenser Kit . . . . . . . 42249103
02. Single Tap Dispenser Kit . . . . . . 42249104
03. CO2 Tank - Empty . . . . . . . . . 42249028
04. Tap Cleaning Kit . . . . . . . . . . 42242373
05. Built-in Drain System Kit . . . . . . 42242374
06. Integrated Grate . . . . . . . . . . S41013407
07. Interior Floor Shield. . . . . . . . . 42242400
08. Casters Set of 4. . . . . . . . . . . 42249107
09. Vinyl Cover for Model
with Dispenser Tower. . . . . . . . 42243155
10. Vinyl Cover for Model
without Dispenser Tower . . . . . 42243156
11. Ice Machine Sanitizer,
16 oz. Bottle . . . . . . . . . . . . S41013790
12. Ice Machine Cleaner,
4 oz. Bottle . . . . . . . . . . . . . S41013789
13. Drain Pump . . . . . . . . . . . . 42248890
Accessories
12
01
03 04
02
05
Page 17
06
Accessories
07
08
11
12
09 10
13
13
Page 18
Product
Specications
For complete specications and
installation instructions, please visit
www.marvelrefrigeration.com
Refrigerators
Model Number
Width
Interior Finish
Capacity
Shelving
System
Shelf Fronts
Other Storage
Interior
Lighting
Handle
Temperature
Range
Lock
Length of
Power Cord
MO24RAS2 MO24RAS1 MO15RAS2
23 ⅞" 23 ⅞" 14 ⅞"
White White White
Up to 146 12-oz cans Up to 154 12-oz cans Up to 70 12-oz cans
Cantilever Cantilever Cantilever
Stainless Steel Stainless Steel Stainless Steel
MaxStore™ Utility Bin NA NA
2 White LED Pods 2 White LED Pods 1 White LED Pod
Professional Professional Professional
34° - 42° F 34° - 42° F 34° - 42° F
Ye s Ye s Ye s
5' 5' 5'
Product
Dimensions
23 ⅞" W x 33 ¾" H x 21 ½" D 23 ⅞" W x 33 ¾" H x 21 ½" D 14 ⅞” W x 33 ¾” H x 21 ½” D
Without Door
Depth to Front
of Door
Depth to
Handle
Depth with
door at 90°
Shipping
Weight
The information presented herein is based on the best data available and is believed to be correct. However, nothing
stated herein is to be taken as warranty, expressed or implied, regarding the accuracy of the information or the use of
our product or produc ts. Specications are subject to change without notice.
Specications are for reference only and should not be used for cutout dimensions. Please consult the installation guide
available at www.marvelrefrigeration.com before making any nal preparations for installation of these products.
14
23 23/32" 23 23/32" 23 23/32"
26 7/32" 26 7/32"
46 13/32" 46 13/32" 37 1/16"
160 lbs 160 lbs 125 lbs
26
7
/
"
32
Page 19
Beer Dispenser Ice Machines Refrigerated Drawers
Model Number
Width
Interior Finish
Capacity
Shelving
System
Shelf Fronts
Other Storage
Interior
Lighting
Handle
Temperature
Range
Lock
Length of
Power Cord
MO24RD MO24B 3OiMT 25OiM-SS-F
23 ⅞" 23 ⅞" 14 ⅞" 14 ⅞"
Stainless Steel White White White
Stores half barrel, quarter
Up to 133 12-oz cans
NA Drop in place NA NA
NA Stainless Steel NA NA
NA
1 LED pod per drawer NA NA NA
Professional Professional Professional Professional
34° - 42° F 34° - 46° F NA NA
Ye s Yes No No
5' 5' 5' 5'
barrel (pony keg), sixth
barrels/Cornelius kegs, slim
quarters, growlers, bottles
or cans
Drain pan, CO2 tank, hoses,
regulator, oor shield
Up to 30 lbs of clear ice Up to 15 lbs of crescent ice
NA NA
Product
Dimensions
Without Door
Depth to Front
of Door
Depth to
Handle
Depth with
door at 90°
Shipping
Weight
23⅞" W x 33 ¾" H x 21 ½" D 23 ⅞" W x 33 ¾" H x 21 ½" D 14 ⅞" W x 33 ¾" H x 21 ½" D 14 ¾" W x 33 ¾" H x 21 ½" D
23 23/32" 23 23/32" 23 7/8" 22 ¼"
7
26
/
" 26
32
41 21/32" 46 13/32" 37 1/16" 37 1/16"
160 lbs 160 lbs 90 lbs 90 lbs
7
/
"
32
26 ¼" 24
5
/32"
15
Page 20
When you choose
MARVEL, you’re choosing
over 120 years of
handcrafted quality and
leading innovation in
the luxury refrigeration
business. You’re choosing
American products,
and most importantly,
you’re choosing the best
undercounter refrigeration
technology available on
the market.
Our 139 quality checks and
exacting standards are what drive the
performance the industry has come
to expect from Marvel. Expert
technicians proudly build every
Marvel model right here in our
beautiful state of Michigan. And, our
new design was fueled by insights
given to us by real homeowners
and leading designers that use the
product to ensure we deliver the
styling and functionality that you
want for your home.
16
AGA MARVEL is committed to
building a quality product in an
environmentally friendly manner.
Our processes are tightly controlled
and closely monitored. We have
achieved certications in ISO 9001
for quality assurance, ISO 14001
for environmental management, and
OSHAS 18001 for occupational
health and safety from Lloyd's
Register Quality Assurance.
Page 21
1890s
Ranney ice box production
begins in Greenville, MI
Marvel History
1932
Marvel was founded when the company began
making undercounter ice boxes
1965
Marvel’s rst foamed
in place refrigerator
is developed
1991
Introduces the rst stainless
steel interior and glass
door built-in refrigerator for
residential use
2001
Marvel introduces
rst black interior
for wine cellars and
beverage centers
1952
Marvel introduces premium undercounter wine
storage and beverage center
2002
We invent the world’s largest
capacity unit, the 72" wide
built-in refrigerator freezer.
2014
AGA MARVEL unveils the industry's
leading line of ENERGY STAR®
rated undercounter products
Page 22
World. Class. Living.
AGA
With a rich, professional and catering heritage, AGA cast iron ranges
have a cooking solution for even the most discriminating home chef.
Whether it’s the new sleek and slim AGA City 24, the versatile energy
ef cient gas AGA Dual Control or the iconic AGA Total Control, there’s
an AGA for every home kitchen to suite your lifestyle.
MARVEL
MARVEL is the premium wine and food preservation leader. Choose
from counter depth and custom built-in refrigerators, an amazing
collection of wine storage units, and both indoor and outdoor
undercounter refrigerators, ice machines, and beer dispensers. All
share the MARVEL commitment to superior t and nish and
long-lasting performance.
Heartland
The Heartland Classic gas, electric and dual fuel ranges, refrigerators,
dishwashers and wood cookstoves are based on the legendary Oval
wood cookstove rst built in 1925. Heartland’s nostalgic beauty,
craftsmanship, attention to detail and modern performance features
deliver a truly unique kitchen experience.
La Cornue
The choice of culinary artists the world over, La Cornue’s famous
ranges and vaulted ovens, rotisseries, and cabinetry are found in
only the nest kitchens. The Chateâu Series, hand-made to order
in La Cornue’s atelier just outside Paris, is available in over 8,000
con gurations. The CornuFé and the new 1908 are designed for the
La Cornue enthusiast with a more modest budget.
www.agamarvel.com
© AGA MARVEL 2015, all rights reserved.
Printed 6/15 41013972-EN Rev. D
The information presented herein is based on the best data available at time of printing and is believed to be correct.
However, nothing stated herein is to be taken as warranty, expressed or implied, regarding the accuracy of the information
or the use of our product or products. Products might not appear exactly as shown in images. Specifi cations and product
esthetics are subject to change without notice.
United States
AGA MARVEL
1260 E Van Deinse Street
Greenville, MI 48838
800-223-3900
AGA MARVEL - SOFA Galleries
Canada
6900 Airport Road, Suite 205
Mississauga, ON L4V 1E8
855-213-2785
Loading...
