Marvel MLBV215-SG01A, MLBV215-IG01A, MLBV215-IS01A, MLBV215-SS01A Specification Sheet

Fresh Living Tip

Never seem to have enough space in your refrigerator for beverages? Simply swap a 15” cabinet with this slim model to easily add more cold storage to your home. And if built-in

installation is not an option, the nished cabinet

design makes for a polished freestanding look.

15” Marvel Beverage Center

MLBV215

Storage Adaptability

• 2.7 cu. ft. capacity stores (72) 12-oz cans and 3 wine bottles

• Black steel-framed glass shelves are cantilevered and fully adjustable

• Includes (1) 3-in-1 Convertible Shelf featuring removable glass pane with wine rack option

• Store food, beverages, or wine

FINISH OPTIONS

Cooling Performance

• Dynamic cooling technology delivers rapid cool down, frost-free operation and precise temperature stability

• Proprietary shelving design for cool air to circulate throughout cabinet for temperature consistency from top to bottom

• Thermal-efcient cabinet ensures optimum preservation and energy

efciency while maximizing capacity

• Argon-lled, UV-resistant tinted dual pane glass door protects contents from damaging ultraviolet light, while conserving energy

• Sound-buffering design

Convenient Controls

• Multifunction controls allow you to select a precise cabinet temperature from 34° F to 60° F

• Features easy-to-use settings and options

Fit & Finish

• Elegant midnight black interior and arctic white LED interior lighting

• Solid black shelf fronts

• Reversible door allows for right or left swing for adaptable installation

• Black toe kick adjustable to 4” with leveling legs

Warranty

• 1-year parts and labor warranty and 5-year sealed system parts warranty

Full-featured in a slim size, this 15” beverage center stores up to six 12-packs, and a convertible shelf lifts to reveal hidden wine storage!

DOOR STYLE MODEL NUMBER

Stainless Steel Frame Glass

Panel Ready Frame Glass

Solid Panel Ready

Solid Stainless Steel

LBV215-SG01A

LBV215-IG01A

LBV215-IS01A

LBV215-SS01A

marvelrefrigeration.com | 616.754.5601

Precise temp control

Arctic white

lighting

Reversible door

Adjustable cantilever

shelving system

Thermal-efcient nished cabinet design

H: 33 3/4“ W: 14 7/8” D: 26 7/32” (with handle)

Convertible Shelf

3-in-1

Line art not to scale. Intended for general reference only.

Rough In Dimensions*

“A” “B” “C”

15" 34-1/4" TO 35-1/4" 24"

(38.1 CM) (87 CM TO 89.5 CM) (61 CM)

*Stainless steel model dimensions only. For panel-ready models, see the owner’s guide online at marvelrefrigeration.com.

Capacity Control Type Sabbath Mode Temperature Range Handle Style Hinge Type Interior Lighting Shelving System Toe Grille Finish

2.7 CU. FT.

Electronic

Yes

34° F to 60° F

Slim (handle not included on panel-ready models)

Reversible

White LED

Cantilevered

Black

Cabinet Dimensions*

"D" "E" "F" "G" "H" "J"

14-7/8" 33-5/8" TO 34-5/8" 23-5/8"* 25-3/8"* 38-3/4"* 17-1/2"*

(37.8 CM) (85.4 CM TO 87.9 CM) (60 CM) (64.4 CM) (98.4 CM) (44.4 CM)

Lock Electrical Requirements Cord Length Shipping Dimensions Shipping Weight Agency Approval Refrigerant Type

For comprehensive installation instructions, including panel overlay details, please visit marvelrefrigeration.com to access the owner’s guide.

115V / 60 Hz / 15A

6 FT.

19” W x 31” D x 37” H

125 LBS

R600a

marvelrefrigeration.com | 616.754.56 01
