ML-80i
SPECIFICATIONS
Frequency Response
60–20,000 Hz ±2 dB
Crossover Frequency
2,500 Hz
Sensitivity
90dB
Impedance
Compatible with 8 ohms
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
8” (21cm) mineral-filled polypropylene cone
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–90 Watts
Maximum Power Handling
60 Watts
Weight
4.4 lbs. each (2 kg)
Overall Size (dia. x depth)
10.5” x 4” (26.6 x 10cm)
Required ceiling opening (including tolerance)
9-3/8” (23.8cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
3.8” (9.5cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-67i
SPECIFICATIONS
Frequency Response
70–20,000 Hz ±2 dB
Crossover Frequency
2,500 Hz
Sensitivity
89dB
Aiming
Rotate speaker assembly
Impedance
Compatible with 8 ohms
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
6-1/2” (16.5cm) mineral-filled polypropylene cone
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–80 Watts
Maximum Power Handling
50 Watts
Weight
5.3 lbs. each (2.4 kg)
Overall Size (dia. x depth)
11.4” x 5.4” (29 x 13.5cm)
Required ceiling opening (including tolerance)
10-3/8” (26.3cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
5.2 (13cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-66i
SPECIFICATIONS
Frequency Response
75–20,000 Hz ±2 dB
Crossover Frequency
2,500 Hz
Sensitivity
89dB
Impedance
Compatible with 8 ohms
High-Frequency Driver
3/4” (1.9cm) titanium dome
Low-Frequency Drivers
Two 5-1/2” (14cm) mineral-filled polypropylene cones
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–100 Watts
Maximum Power Handling
70 Watts
Weight
5.9 lbs. each (2.7 kg)
Overall Size (H x W x D)
9.3” x 12.7” x 3.4” (23.7 x 32.3 x 8.6cm)
Required wall opening (including tolerance)
8-1/4” x 11-5/8” (20.9 x 29.5cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
3.2” (8.1cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-65i
SPECIFICATIONS
Frequency Response
70–20,000 Hz ±2 dB
Crossover Frequency
2,500 Hz
Sensitivity
89dB
Impedance
Compatible with 8 ohms
High-Frequency Driver
3/4” (1.9cm) titanium dome
Low-Frequency Driver
6-1/2” (16.5cm) mineral-filled polypropylene cone
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–90 Watts
Maximum Power Handling
60 Watts
Weight
3.5 lbs. each (1.6 kg)
Overall Size (H x W x D)
11.5” x 8.3” x 3.3” (29.1 x 21.2 x 8.5cm)
Required wall opening (including tolerance)
7-1/8” x 10-1/8” (18 x 25.7cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
3.1” (7.9cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-62i
SPECIFICATIONS
Frequency Response
70–20,000 Hz ±2 dB
Crossover Frequency
3,000 Hz
Sensitivity
89dB
Aiming
Rotate speaker assembly
Impedance
Compatible with 4 ohms mono / 8 ohms stereo
High-Frequency Drivers
Two 3/4” (1.9cm) titanium domes
Low-Frequency Driver
Dual voice-coil 6-1/2” (16.5cm) mineral-filled polypropylene cone
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–80 Watts mono / 15–40 Watts stereo
Maximum Power Handling
50 Watts
Weight
3.5 lbs. each (1.6 kg)
Overall Size (dia. x depth)
8.8” x 3.6” (22.4 x 9cm)
Required ceiling opening (including tolerance)
7-3/4” (19.6cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
3.4” (8.5cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-60i
SPECIFICATIONS
Frequency Response
70–20,000 Hz ±2 dB
Crossover Frequency
3,000 Hz
Sensitivity
89dB
Impedance
Compatible with 8 ohms
High-Frequency Driver
3/4” (1.9cm) titanium dome
Low-Frequency Driver
6-1/2” (16.5cm) mineral-filled polypropylene cone
Binding Post Inputs
Spring clip accommodates wire up to 12AWG
Suitable Amplifier Range
15–80 Watts
Maximum Power Handling
50 Watts
Weight
3.5 lbs. each (1.6 kg)
Overall Size (dia. x depth)
8.8” x 3.4” (22.4 x 8.5cm)
Required ceiling opening (including tolerance)
7-3/4” (19.6cm)
Projection from wall surface
0.2” (0.5cm)
Depth required behind wall surface
3.2” (8cm)
Specifications are subject to change without notice.
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while bezel-free paintable grilles that
are secured with high-strength magnets provide an aesthetic that
blends invisibly into any room. Each model comes with an extremely
robust mounting-lock system that couples with the speaker’s vibrationresistant ABS chassis when installed.
ML-75AW
SPECIFICATIONS
Frequency Response
75–20,000 Hz ±2 dB
Crossover Frequency
2,300 Hz
Sensitivity
93dB
Aiming
Swivels on U-Bracket
Impedance
Compatible with 8 ohms
Low-Frequency Extension*
50 Hz (DIN)
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
7-1/2” (19cm) mineral-filled polypropylene cone
Binding Post Inputs
5-way binding posts accommodate wire up to 5AWG
Suitable Amplifier Range
15–110 Watts
Maximum Power Handling**
80 Watts
Weight
10.6 lbs. each (4.8 kg)
Size (H x W x D)
12-1/2” x 8-13/16” x 9-1/8”
(31.7 x 22.4 x 23.2cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Colors Options:
Black
White
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled reinforced
enclosures provide protection from harsh weather elements. All
models have water & UV-resistant aluminum grilles, stainless steel
& polymer mounting brackets, brass hardware, and gold-plated
binding posts for superior toughness.
Installer Series
ML-65AW
SPECIFICATIONS
Frequency Response
80–20,000 Hz ±2 dB
Crossover Frequency
2,300 Hz
Sensitivity
91dB
Aiming
Swivels on U-Bracket
Impedance
Compatible with 8 ohms
Low-Frequency Extension*
55 Hz (DIN)
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
6-1/2” (16.5cm) mineral-filled polypropylene cone
Binding Post Inputs
5-way binding posts accommodate wire up to 5AWG
Suitable Amplifier Range
15–100 Watts
Maximum Power Handling**
70 Watts
Weight
8.8 lbs. each (4 kg)
Size (H x W x D)
11” x 7-1/2” x 7-15/16”
(28 x 19 x 20.2cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Colors Options:
Black
White
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled reinforced
enclosures provide protection from harsh weather elements. All
models have water & UV-resistant aluminum grilles, stainless steel
& polymer mounting brackets, brass hardware, and gold-plated
binding posts for superior toughness.
Installer Series
ML-55AW
SPECIFICATIONS
Frequency Response
85–20,000 Hz ±2 dB
Crossover Frequency
2,300 Hz
Sensitivity
90dB
Aiming
Swivels on U-Bracket
Impedance
Compatible with 8 ohms
Low-Frequency Extension*
60 Hz (DIN)
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
5-1/2” (14cm) mineral-filled polypropylene cone
Binding Post Inputs
5-way binding posts accommodate wire up to 5AWG
Suitable Amplifier Range
15–90 Watts
Maximum Power Handling**
60 Watts
Weight
6.75 lbs. each (3.05 kg)
Size (H x W x D)
9-11/16” x 7” x 7-5/8”
(24.6 x 17.8 x 19.4cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Colors Options:
Black
White
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled reinforced
enclosures provide protection from harsh weather elements. All
models have water & UV-resistant aluminum grilles, stainless steel
& polymer mounting brackets, brass hardware, and gold-plated
binding posts for superior toughness.
Installer Series
ML-45AW
SPECIFICATIONS
Frequency Response
90–20,000 Hz ±2 dB
Crossover Frequency
2,300 Hz
Sensitivity
88dB
Impedance
Compatible with 8 ohms
Low-Frequency Extension*
65 Hz (DIN)
High-Frequency Driver
1” (2.5cm) titanium dome
Low-Frequency Driver
4-1/2” (11.5cm) mineral-filled polypropylene cone
Binding Post Inputs
5-way binding posts accommodate wire up to 5AWG
Suitable Amplifier Range
15–80 Watts
Maximum Power Handling**
50 Watts
Weight
3.4 lbs. each (1.55 kg)
Size (H x W x D)
7-9/16” x 5-5/8” x 5-15/16”
(19.2 x 14.3 x 15.1cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Colors Options:
Black
White
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled reinforced
enclosures provide protection from harsh weather elements. All
models have water & UV-resistant aluminum grilles, stainless steel
& polymer mounting brackets, brass hardware, and gold-plated
binding posts for superior toughness.
Installer Series
ML-75R (stereo)
SPECIFICATIONS
Frequency Response
63–20,000 kHz ±2 dB
Crossover Frequency
2,5000 Hz
Sensitivity
90dB
Impedance
Stereo Mode - Compatible with 8 ohms
Mono Mode - Compatible with 4 ohms
Low-Frequency Extension*
42 Hz (DIN)
High-Frequency Drivers
Two 1” (2.5cm) titanium domes
Low-Frequency Driver
7-1/2” (19cm) mineral-filled polypropylene cone
with dual voice coil.
Inputs
Two pair pre-installed wires
Suitable Amplifier Range
Stereo Mode - 15–120 Watts
Mono Mode - 15–60 Watts
Maximum Power Handling**
Stereo Mode - 80 Watts
Mono Mode - 40 Watts
Weight
17 lbs. each (7.7 kg)
Size (H x W x D)
15-3/16” x 13-3/8” x 13”
(38.5 x 34 x 33cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Color:
Grey Stone
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled
reinforced enclosures with faux-stone finish provide protection
from harsh weather elements that will blend into the surrounding
landscape. All models have water & UV-resistant stainless steel grilles
for superior toughness.
ML-65R (stereo)
SPECIFICATIONS
Frequency Response
66–20,000 kHz ±2 dB
Crossover Frequency
3,000 Hz
Sensitivity
89dB
Impedance
Stereo Mode - Compatible with 8 ohms
Mono Mode - Compatible with 4 ohms
Low-Frequency Extension*
44 Hz (DIN)
High-Frequency Drivers
Two 1” (2.5cm) titanium domes
Low-Frequency Driver
6-1/2” (16.5cm) mineral-filled polypropylene cone
with dual voice coil.
Inputs
Two pair pre-installed wires
Suitable Amplifier Range
Stereo Mode - 15–100 Watts
Mono Mode - 15–55 Watts
Maximum Power Handling**
Stereo Mode - 70 Watts
Mono Mode - 35 Watts
Weight
12.1 lbs. each (5.5 kg)
Size (H x W x D)
12-3/16” x 11-1/8” x 10-5/8”
(31 x 28.2 x 27cm)
*DIN 45 500. Indicates -3 dB in a typical listening room.
**With typical program source, provided the amplifier
clips no more than 10% of the time.
Specifications are subject to change without notice.
Color:
Grey Stone
Installer Series
Affordable High-Performance Solutions
Installer Series is our affordable high-performance lineup, featuring custom installation
solutions for in-wall, in-ceiling, and outdoor applications.
Titanium dome tweeters and mineral-filled polypropylene drivers
ensure great performance, while fully sealed, mineral-filled
reinforced enclosures with faux-stone finish provide protection
from harsh weather elements that will blend into the surrounding
landscape. All models have water & UV-resistant stainless steel grilles
for superior toughness.
Loading...
