AQ5
Ultra-compact, wide angle system
features
! Very wide 120° x 60° dispersion
! Dual 5.25" (130mm) ICT™
! Light weight structural foam enclosure
! 1st & 2nd fix wall and ceiling brackets available
! Five year limited warranty
applications
! Clubs, bars and restaurants
! Theatres
! Places of worship
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2003 Martin Audio Ltd.
The ultra-compact AQ5 is equipped with two 5.25" (130mm)
ICT™ (Inductively Coupled Transducer) drivers optimally splayed
for smooth, very wide coverage. The AQ5’s HF diaphragms are
driven via inductive coupling, avoiding the tweeter burn-out
commonly associated with miniature loudspeakers. ICT™
technology also eliminates the need for a crossover as the
inductive coupling provides a complementary transfer function
for the tweeter.
architectual
www.martin-audio.com
overall dimensions
technical specifications
TYPE Ultra-compact, Dual ICT™, wide dispersion
vented trapezoid
FREQUENCY RESPONSE (1) 120Hz-20kHz ± 3dB
DRIVERS 2 x 5.25" (130mm) ICT™ full-range drivers
RATED POWER (2) 75W AES, 300W peak
RECOMMENDED 75-150W into 4 ohms
AMPLIFIER
SENSITIVITY (6) 91dB
MAXIMUM SPL (7) 109dB continuous, 115dB peak
NOMINAL IMPEDANCE Externally switchable 4 or 16 ohms
DISPERSION (-6dB) 120º horizontal, 60º vertical
CROSSOVER ICT™
ENCLOSURE 5 litre, structural foamed ABS
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 12 amp push-lock
FITTINGS 4 x M6 inserts for bracket
1 x M6 insert for safety point
OPTIONS 30W 100/70V line transformer
DIMENSIONS (W) 282mm x (H) 172mm x (D) 180mm
(W) 11.1ins x (H) 6.8ins x (D) 7.1ins
WEIGHT 5kg (11lbs)
