AQ112
Ultra-compact, vented sub-bass system
features
! Very high efficiency 102dB/W/m half space
! 12" (300mm) direct radiating LF driver with
3" (75mm) voice coil
! Ultra-compact, architecturally friendly styling
! Five year limited warranty
applications
! Clubs, bars and restaurants
! AV presentations
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: info@martin-audio.com
All information is Copyright © 2003 Martin Audio Ltd.
The AQ112 is a direct radiating sub-bass in an ultra-compact
heavily braced vented enclosure. It features a very efficient 12"
(300mm) long-throw bass driver with a high power 3" (75mm)
voice coil and generously sized low frequency ports for low
noise, high power operation.
The AQ112’s ultra-compact size makes it an ideal partner for AQ
Series full-range loudspeakers where space is at a premium or
where the sub enclosure needs to be hidden.
architectual
www.martin-audio.com
overall dimensions
technical specifications
TYPE Ultra-compact, vented sub-bass
FREQUENCY RESPONSE (1) 48Hz-150Hz ± 3dB
DRIVERS 12" (300mm)/3" (75mm) voice coil LF driver
RATED POWER (2) 400W AES, 1600W peak
RECOMMENDED AMPLIFIER 400-800W into 4 ohms
SENSITIVITY (6), (3) 96dB (open space), 102dB (half space)
MAXIMUM SPL 120dB continuous, 126dB peak (open space)
(calculated @ 1m) 126dB continuous, 132dB peak (half space)
NOMINAL IMPEDANCE 8 ohms
CROSSOVER 120Hz active (via AQX controller)
ENCLOSURE 52 litre, braced 18mm MDF
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 20 amp push-lock
FITTINGS
OPTIONS Passive low pass filter
DIMENSIONS (W) 475mm x (H) 385mm x (D) 410mm
(W) 18.7ins x (H) 15.2ins x (D) 16.2ins
WEIGHT 20kg (44lbs)
