Page 1
A55T
Ultra-Compact Two-Way On-Wall System
Features
• Contemporary, unobtrusive design
• High output capability
•
High fidelity sound
•
Low and high-frequency overload protection
•
70V/100V line transformer
Vertical or horizontal orientation
•
• Wide 110° x 80° coverage
• Wall bracket included
• 5-year warranty
Applications
• Retail outlets
Cafes, bars and restaurant chains
•
•
Hotels and convention centres
•
Educational facilities
• Corporate offices
INSTALLED SOUND
The A55T is a two-way passive speaker with an elegant design
that is perfect for architectural environments that require highfidelity sound from an unobtrusive, ultra-compact enclosure.
It brings class-leading performance, reliability and value
to a wide range of commercial sound applications — from
retail outlets, bars and restaurants to corporate offices and
convention centres.
The A55T is the perfect choice for background and foreground
systems which require superior performance. Its Martin Audio
signature sound characteristic also provides a seamless sonic
transition within a multi-zoned complex using larger Martin
Audio systems such as CDD or BlacklineX.
Comprising a 5.25” (135mm) LF driver and a 0.75” (19mm)
silk-dome HF driver on a 110° x 80° horn, it handles 50W
AES, 200W peak and can produce 113dB peak output at 1
metre. It has a smooth frequency response and strong bass
reproduction that extends down to 65Hz.
The A55T incorporates a high-quality transformer for 70V/100V
line operation, with transformer taps selected by a rotary switch.
Martin Audio Ltd
Century Point, Halifax Road, High Wycombe
Buckinghamshire HP12 3SL, England
All information is Copyright © 2018 Martin Audio Ltd.
Telephone: +44 (0) 1494 535 312
Facsimile: +44 (0) 1494 438 669
Email: info@martin-audio.com
The recommended amplifier is the VIA5002 in conjunction
with a suitable line transformer. For full-bandwidth protection,
the low and high-frequency sections are individually protected
against overload.
Available in black or white as standard, it can be readily painted
to match any décor, and can be wall-mounted vertically or
horizontally using the wall bracket supplied.
The VIA5002 amplifier in combination with a Martin Audio
DX0.5 controller will be perfect partners for small scale
efficient installations, or with the DX4.0 controller for larger
more complex installations, which could then also be managed
by Martin Audio’s VU-NET control software platform.
The Martin Audio SX110 subwoofer will extend the bandwidth
of ADORN on-wall speakers and is ideal for foreground music
applications which require increased impact and low frequency
performance.
www.martin-audio.com
Page 2
A55T
Ultra-Compact Two-Way On-Wall System
INSTALLED SOUND
Technical Specifications
TYPE Ultra-compact passive two-way system,
front ported bass reflex
FREQUENCY RESPONSE (1) 90Hz-17kHz ± 3dB
-10dB @ 65Hz
DRIVERS LF: 5.25” /1” high-temp voice coil, coated paper
cone, rubber surround, ferrite motor, pressed steel chassis
HF: 0.75” silk dome, neodymium motor
RATED POWER (2) 50W AES, 200W peak
RECOMMENDED AMPLIFIER VIA5002 [In conjunction with suitable line transformer]
SENSITIVITY (1) 90dB/1W/1m
MAXIMUM SPL (9) 113dB peak
NOMINAL IMPEDANCE 16 ohms
DISPERSION (-6dB) 110° H x 80° V
CROSSOVER 3.5kHz passive (LF and HF auto-resetting fuses)
TRANSFORMER TAPS 70V: 30w / 15w / 7.5w / 3.75w
100V: 30w / 15w / 7.5w
RECOMMENDED HIGH-PASS FILTER 60Hz 24dB/oct
ENCLOSURE ABS, UL 94V-0 rated
FINISH Black or white
GRILLE Perforated steel
CONNECTORS Push terminals
FITTINGS Wall bracket included
DIMENSIONS EXCL. BRACKET (W) 152mm x (H) 245mm x (D) 140mm
(W) 6in x (H) 9.6in x (D) 5.5in
WEIGHT 2.81kg (6.2lbs)
ACCESSORIES Waterproof connector cover
Water resistant grille
Notes
(1)
Measured on-axis in half (2pi) space at 2 metres, then referred to 1 metre.
AES Standard ANSI S4.26-1984.
(2)
(3)
Measured in half (2pi) space at 2 metres with 1 watt input, using band limited pink noise,
then referred to 1 metre.
(4)
Measured in half (2pi) space at 2 metres using band limited pink noise, then referred to 1
metre.
(5)
Measured on-axis in open (4pi) space at 2 metres, then referred to 1 metre.
Measured in open (4pi) space at 2 metres with 1 watt input, using band limited pink
(6)
noise, then referred to 1 metre.
(7) Measured in open (4pi) space at 2 metres using band limited pink noise, then referred to 1
metre.
(8)
Measured in open (4pi) space at 2 metres with 2.83v input, using band limited pink noise,
then referred to 1 metre.
(9)
Calculated at 1 metre.
(10)
Measured in half (2pi) space at 2 metres with 2.83V input, using band limited pink noise,
then referred to 1 metre.
Martin Audio Ltd
Century Point, Halifax Road, High Wycombe
Buckinghamshire HP12 3SL, England
All information is Copyright © 2018 Martin Audio Ltd.
A55T
Telephone: +44 (0) 1494 535 312
Facsimile: +44 (0) 1494 438 669
Email: info@martin-audio.com
www.martin-audio.com
