Martin Archery Martin Traditional User Manual

RECUR VE / LONGBOW

OWNERS MANUAL

Thank you for selecting a Martin (Howatt) product. We feel
confident that you will experience many years of enjoyment from your
Martin bow.

Here at Martin Archery, we strive for excellence in all of our
products and always welcome any comments from our customers. We
also like to hear your success stories. Therefore, if you have any
comments, photos or information that you would like to share with
Martin Archery, feel free to call or write. We’ll do our best to answer
any questions and evaluate your comments.

Thank You

A Recurve Bow And Its Parts

Recurve

Lower limb

String

Handle Riser Section

Grip

Arrow Plate

Pivot Point

Sight Window

Arrow Rest

String (brace) Height

Serving

Martin Archery

3134 W. Highway 12
Walla Walla, WA 99362 U.S.A
www.martinarchery .com

Front

Upper Limb

String Notch

Tip

STRINGING YOUR BOW

Martin Archery recommends that you use a bowstringer when
stringing your bow. Proper use of a bowstringer will
prevent your bow’s limbs from becoming twisted. A bowstringer
also provides the safest method of stringing your bow as the limb tips
are away from you during the stringing and unstringing
process. (Avoid placing your head close to the limb tips when

stringing and unstringing your bow).

LIMB STRAIGHTENING (BUMPING)

Should a limb become twisted, it will remain twisted until you
straighten or ‘bump’ it back to the straight position. ‘Bumping’ in­volves the placement of one hand near the twisted section of the limb
and the other hand on the riser section. A twisted limb can be straight­ened in this manner by applying pressure in the opposite direction of
the twist. You should unstring your bow before
straightening a twisted limb.

Neglecting a twisted limb will only allow the twist to
become more severe. A brief inspection of each limb should be made
each time you string your bow.

ARROW REST

All Martin (Howatt) bows, with the exception of
traditional longbow models, are designed to be shot either from an
elevated arrow rest or directly off of the arrow shelf. An
elevated arrow rest provides increased fletching clearance and is help­ful when using plastic vanes. Shooting off of the shelf allows the
arrow to be held closer to the bowhand which is helpful to
instinctive shooting. It is recommended, when shooting off of the
shelf, that you pad the arrow shelf and the portion of the sight
window directly above the pivot point with a rug rest or hair rest.

Hair (rug) Rest

Elevator Rest

TAKE-DOWN LIMB INSTALLATION

Each of your Martin (Howatt) T ake-Down model limbs is denoted either with a “T” (top limb) or
a “B” (bottom limb). These markings are found on each limb near the mounting area.

Y our Take-Down model is designed to be shot with the limbs mounted securely against the riser .
Do not overtighten your limb bolts. A snug fit is all that is required. Overtightening can cause limb
damage. The draw weight is not adjustable on Take-Down model recurve bows.

CARE AND SAFETY

·You should unstring your bow when it is not being used.

·Never ‘dry-fire’ your bow.

This is shooting the bow without an arrow. A ‘dry-fire’ can severely damage your bow.

·Never draw , aim or shoot unless you are sure that line of fire is clear.

Remember: “Once an arrow is in flight, it cannot be recalled.”

·Store your bow in a cool, dry place and avoid prolonged exposure to excessive heat and

moisture.

·Occasionally waxing your bow with a quality furniture wax will help preserve its finish.

When cared for in this manner, your bow will provide you with many years of faithful service.

BRACE HEIGHT (FISTMELE)

The brace height of your bow is measured from the pivot point, or most inward point of the
grip, to the bowstring (see illustration, front page).

The recommended brace height for your bow is listed:
#2184 Rebel 7" - 7 3/4"

#2366 Victory 8 1/2" - 9 1/4"
#2370 Mamba 7 1/4" - 8"
#2515 Prodigy 7" - 7 3/4"
#2800 Hunter 7 3/4" - 8 1/2"
#2804 Gail Martin Classic 7 1/2" -8 1/4"

#2811 Hi-Speed 8" - 8 3/4"
#2814 Hatfield TD 7 1/4" - 8"
#ML-9 Stick 6 3/4" - 7 1/2"
#ML-12 Vision 7 1/4" - 8"
#ML-14 Mountaineer 6 1/4" - 7"
#X-200 Recurve 8" - 8 3/4"

#2805 Dream Catcher 8 1/2" - 9"

A higher brace height helps reduce bow vibration and noise and also minimizes the effects of
shooting errors. A lower brace height provides increased arrow velocity. Increased noise and poor
arrow flight can be the result of a brace height that is too low.

T wisting your bowstring will reduce its length and increase your brace height. Untwisting your
bowstring or installing a longer bowstring will decrease your brace height. (A void untwisting flemish
style bowstrings as string failure may occur). Experiment to find the brace height
measurement that allows your bow to perform at its best with your particular style of shooting.

STRING LENGTH

Your bow’s AMO (Archery Manufacturer and Merchant’ s Or ganization) length is marked on its
lower limb. To achieve the correct brace height you will need to use a bowstring of the same AMO
length. (Example: An AMO 62” bow requires an AMO 62” string). The actual length of your
bowstring will be 4”-5” shorter than its marked AMO length.

ARROWS

All types of arrows (wood, aluminum, carbon) can be shot from your Martin (Howatt) bow.
Regardless of arrow type, it is important that your arrows are correctly spined (have the correct spine
stiffness) for your draw weight. Check your arrow manufacturers recommendations to
determine the arrow size best suited for your bow.

7. Do you read target or 3-D magazines ? (If so which ones)

________________________________________________

Thank you for your valuable time

________________________________________________

________________________________________________

________________________________________________

________________________________________________

__ Performance

3. What brand and model quiver do you plan to use with this bow ?

4. What brand and model broadheads do you prefer ?

5. If you hunt, what is your favorite camo pattern ?

6. What outdoor magazines do you read regularly ?

2. Why did you choose a Martin bow ?

__ Accuracy __ Price

__ Appearance __ Pro Shooter Recommendation

__ Dealer Recommendation __ Winning Tournament Record

__ Friend Recommendation __ Other

(You may check more than one)

Your Name _________________________________________

Address ____________________________________________

City and State ________________ Zip ___________________

1. Is this your first bow ? Yes ____ No _____

Bow Color __________Weight _______ Draw length______

Bow model ________________ Date of purchase__________

CUSTOMER QUESTIONNAIRE

LIMITED WARRANTY

Your Martin (Howatt) bow is guaranteed to be free from defects in materials and workmanship for a
period of 2 (two) years from the date of purchase after which replacement or repairs will be made at a
COST of 50% of the retail price then in effect for a period of 5 (five) years from the date of purchase.

Whether your new bow is for hunting, 3-D, or for shooting targets, you have made the right decision in
choosing a MARTIN! Over forty years of archery experience are built into every MARTIN (Howatt)
bow. You can be confident that your new bow is designed to provide years of faithful service and that
MARTIN will always be around to back it with a rock-solid warranty!

This Limited Warranty is conditioned upon proof of purchase and other conditions listed below. IT IS
IMPORTANT THAT YOUR SALES RECEIPT BE FILED IN A SAFE PLACE FOR FUTURE
REFRENCE, AS WARRANTY REPAIRS WILL NOT BE PERFORMED UNDER WARRANTY
WITHOUT A COPY OF THE DATED SALES RECEIPT. Martin Archery, Inc., warrants that your
Martin (Howatt) bow will perform its intended function if used in accordance with the instructions
provided. This Limited Warranty covers ONLY the replacement parts, labor and return ground
transportationcosts performed by Martin Archery, Inc. to the consumer for the repaired bow. Transpor­tation charges for the return of the bow to Martin Archery , Inc. are not covered. NO C.O.D.’s WILL BE
ACCEPTED. MARTIN ARCHERY, INC. MAKES NO OTHER WARRANTY, WITHER EXPRESS
OR IMPLIED, EITHER OF FITNESS OR OF MERCHANTABILITY, except as stated above. ANY
SUCH ADDITIONAL W ARRANTY IS EXPRESSLY DISCLAIMED.
Warranty Limitations are as follows:

· If bow shows sign of misuse, alteration or mishandling, this warranty will be void.

· Claimant must be original purchaser. THIS WARRANTY IS NOT TRANSFERABLE.

· Returns to Martin Archery, Inc. must be pre-authorized. Owner must contact Martin Archery, Inc. at

[phone] prior to shipping in order to obtain a Return Authorization Number.

· All accessory items must be removed from the bow prior to shipping. MARTIN ARCHERY, INC.
WILL NOT BE RESPONSIBLE FOR DAMAGE OR LOSS OF ANY ACCESSORY ITEM LEFT
ON THE BOW.

· WARRANTY IS NOT EFFECTIVE UNLESS A COPY OF THE DATED SALES RECEIPT
ACCOMP ANIES THE BOW.

· This warranty gives you specific legal rights. You may also have other rights which vary from state
to state.

· Return bow to: MARTIN ARCHERY, INC., Rt. 5, Box 127, Walla Walla, WA 99362

· This policy is subject to change and/or cancellation at any time at our discretion.
