Marshall Electronics M-LYNX-10W User manual

Lynx LCD Monitor User Manual

Back Panel

Marshall Lynx LCD Monitor

M-Lynx-10W

User Manual

Marshall

Industrial Video/Security Div.

For more information, contact Marshall Electronics, Industrial Video & Security (800) 800-6608

www.mars-cam.com

Lynx LCD Monitor User Manual

IMPORTANT SAFEGUARDS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Caution:To reduce the risk of electric shock, do not remove the back. There are no user-serviceable parts inside. Always refer servicing to qualified personnel.

Graphic Symbol Explanation

The lightening ﬂash symbol inside the triangle is intended to

alert the user to the presence of un-insulated and dangerous

voltage within the product’s enclosure that may be of sufﬁcient

magnitude to constitute a risk of electric shock.

The exclamation point within the triangle is intended to alert the

user to the presence of important operating and maintenance

(servicing) instructions.

Caution

Please comply with warning regarding power requirements. The power source contains high voltage parts. If the cover is removed, it may cause ﬁre or electric shock. Do NOT remove the cover.

1. Read the Instructions: All safety and operating instructions should be read before the monitor is operated.

2. Follow the Instructions: All operating and user instructions should be followed.

3. Cleaning: Unplug the monitor from the wall outlet before cleaning. Do not use liquid

aerosol cleaners. Use only a damp, soft cloth.

4. Water and Moisture: Do not use the monitor in damp environments. For example, do not operate the monitor in bathrooms, sinks, laundry rooms, wet basements or near a swimming pool. Lynx monitors are not recommended for outdoor use.

5. Accessories: Always ensure that the monitor is placed on a solid, steady surface/stand. To avoid any possible danger and/or damage, do not place the monitor on an unsteady stand, stool, or other surface that could result in the monitor falling.

6. Ventilation: Slots and openings in the monitor’s cabinet are provided for ventilation and ensure reliable operation of the monitor and to protect it from over-heating. These openings must never be blocked. The monitor should never be placed near or over a radiator or head register. This monitor should not be placed or built in to a rack or bookshelf unless proper ventilation is provided and supplier instructions have been adhered to.

7. Object and Liquid Entry: Never push any kind of object into this monitor through an opening as it may touch dangerous voltage points or short out parts that would result in ﬁre or electric shock. Never spill liquid of any kind into the monitor.

8. Repair (Servicing): Do not attempt to repair this monitor yourself by opening or removing covers. This may expose you to dangerous voltage or other hazards. Refer to a qualiﬁed service technician if servicing is necessary. If monitor is opened by anyone other than a factory authorized service center, the warranty is voided. If serial number is removed or tampered with, the warranty is voided.

Warning– To Prevent Fire or Shock Hazard, DO NOT Expose this Monitor to Rain or Moisture

This product must be grounded.

Product specifications are subject to change without notice.

9. Parts Replacement: When part replacement is required, make sure it is performed by a qualiﬁed technician and that the parts are supported by the manufacturer.

10. Storage Temperature: The storage temperature of this device is -20º - +70ºC.

11. Safety Check: Upon completion of any service or repair to the monitor, ask the service technician to perform a safety check to ensure that the monitor is in proper operating condition.

12. Keep the Instructions: The safety and operating instructions should be kept for future reference.
