Page 1
# Component Identification Qty.
0 HK™8 Neck Jets 2
1 HK™8 Jets 24
2 HK™12 Jets 10
3 HK™16 Jets 4
4 HK™40 Jets 9
5 Geyser Jet 1
6 Light (option) 1
7 Air Controls 2
8 Suction Fittings 3
9 Floor Drain 1
10 Jet Selectors 2
11 Neck Jet Valve 1
12 Bather’s Control Panel 1
13 Auxiliary Control (Jets & Light) 1
14 Filter Canisters 2
15 Spa Frog
®
1
16 Spa Frog® Return Fitting 1
17 Ozone Injector Fitting 1
18 Waterfall Valve 1
19 Adagio
TM
Speakers (option) 2
20 Constellation
TM
(option)
21 Cushioned Headrests 3
22 Water Feature 1
Physical Specifications Size
Dimensions 84" x 84"
Height 35"
Corner Radius 12"
Seating Capacity/Positions 5/5
Weight Dry/Lbs. 785
Weight Full/Lbs. 3621
Water Capacity/Gallons 340
Total Therapy Jets 50
THE WISH™
WISH™ EQUIPMENT DIAGRAM
# Component Quantity
1 Control Box and Heater 1
2 Ozonator (option) 1
3 Pumps 2
4 Check Valve (option) 1
5 Slice Valves 2
6 Pump Unions 4
7 Drain Valve 1
8 Adagio™ Stereo Head (option) 1
9 Stereo Power Supply (option) 1
10 Constellation™ LED Control (option) 1
11 Pump Plugs 2
12 Light 1
WISH CONTROL OPERATION
AUXILIARY LOUNGE CONTROL
Auxiliary panel controls the jets and lights.
(See SPA CONTROL OPERATION in the
Owner’s Manual.)
ADAGIO™ II AUDIO SYSTEM (OPTION)
Adagio™ II provides a safe enclosure and convenient remote control for your iPod music player. Please refer to the Poly-Planar
SpaTunes™ Audio System & iPod Controller Owner’s Manual.
Page 2
WISH™ THERAPY CONTROL
ZONE 1 JETS 1
Lounge leg and foot jets
ZONE 1 JETS 2
Upper-, mid-, and lower-back jets
ZONE 1 JETS 3
Lounge upper-back jets
ZONE 2 JETS 1
Upper- and mid-back jets
ZONE 2 JETS 2
Lower-back and Geyser jets
Neck jets operate in all zones
WISH™ THERAPY CONTROL
