Challenger SRT8
O W N E R ’ S MA N U A L
2 0 0 8
2008 Chall enger SRT8
VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name
Chrysler LLC shall be deemed to be deleted and the
name Chrysler Canada Inc. used in substitution therefor.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-drinking
driver, call a cab, a friend, or use public transportation.
WARNING!
Driving after drinking can lead to an accident. Your
perceptions are less sharp, your reflexes are slower,
and your judgment is impaired when you have been
drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or optional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
Chrysler LLC reserves the right to make changes in
design and specifications, and/or make additions to or
improvements to its products without imposing any
obligation upon itself to install them on products previously manufactured.
Copyright © 2007 Chrysler LLC
SECTION PAGE
1
INTRODUCTION
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
4
UNDERSTANDING YOUR INSTRUMENT PANEL
5
STARTING AND OPERATING
6
WHAT TO DO IN EMERGENCIES
7
MAINTAINING YOUR VEHICLE
8
MAINTENANCE SCHEDULES
9
IF YOU NEED CONSUMER ASSISTANCE
TABLE OF CONTENTS
.............................................................3
...............................9
...............................71
................................... 145
.................................................211
...............................................279
...............................................293
..................................................345
..........................................351
1
2
3
4
5
6
7
8
9
10
INDEX
....................................................................361
10
CONTENTS
INTRODUCTION
1
m Introduction ...........................4
m How To Use This Manual ..................4
m Warnings And Cautions ...................6
m Vehicle Identification Number ...............6
m Vehicle Modifications/Alterations ............7
4 INTRODUCTION
INTRODUCTION
This Owner’s Manual has been prepared with the assistance of service and engineering specialists to acquaint
you with the operation and maintenance of your vehicle.
It is supplemented by a Warranty Information Booklet
and various customer-oriented documents. You are
urged to read these publications carefully. Following the
instructions and recommendations in this manual will
help assure safe and enjoyable operation of your vehicle.
NOTE: After you read the manual, it should be stored
in the vehicle for convenient reference and remain with
the vehicle when sold, so that the new owner will be
aware of all safety warnings.
When it comes to service, remember that your authorized
dealer knows your vehicle best, has the factory-trained
technicians and genuine MOPARt parts, and is interested in your satisfaction.
HOW TO USE THIS MANUAL
Consult the Table of Contents to determine which section
contains the information you desire.
The detailed Index at the back of this manual contains a
complete listing of all subjects.
Consult the following table for a description of the
symbols that may be used on your vehicle or throughout
this Owner’s Manual.
INTRODUCTION 5
1
6 INTRODUCTION
WARNINGS AND CAUTIONS
This Owner’s Manual contains WARNINGS against operating procedures that could result in an accident or
bodily injury. It also contains CAUTIONS against procedures that could result in damage to your vehicle. If you
do not read this entire manual, you may miss important
information. Observe all Warnings and Cautions.
VEHICLE IDENTIFICATION NUMBER
The Vehicle Identification Number (VIN) is on the left
front corner of the instrument panel and is visible from
outside of the vehicle through the windshield. This
number also appears on the Automobile Information
Disclosure Label affixed to a window on your vehicle, the
vehicle registration, and the title.
VIN Location
NOTE: It is illegal to remove the VIN.
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and
may lead to an accident resulting in serious injury or
death.
INTRODUCTION 7
1
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS
m A Word About Your Keys ..................12
▫ Wireless Ignition Node (WIN) .............12
▫ FOB With Integrated Key.................13
▫ Ignition Key Removal ...................14
▫ Key-In-Ignition Reminder ................15
m Sentry Keyt ...........................15
▫ Replacement Keys ......................16
▫ Customer Key Programming ..............17
▫ General Information ....................18
2
m Security Alarm System ....................18
▫ Rearming Of The System .................18
▫ To Arm The System .....................19
▫ To Disarm The System ...................19
m Illuminated Entry System ..................20
m Remote Keyless Entry .....................21
▫ To Unlock The Doors ...................21
▫ To Lock The Doors .....................23
▫ Express Down Window Feature ............24
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
▫ To Open The Trunk .....................25
▫ Using The Panic Alarm ..................25
▫ Programming Additional Transmitters ........25
▫ Transmitter Battery Service ...............25
▫ General Information ....................26
m Remote Starting System ...................27
▫ How To Use Remote Start ................27
m Door Locks ............................29
▫ Manual Door Locks .....................29
▫ Power Door Locks .....................30
m Windows .............................33
▫ Power Windows .......................33
▫ Wind Buffeting ........................34
m Trunk Lock And Release ...................35
m Trunk Safety Warning.....................36
▫ Trunk Emergency Release ................36
m Occupant Restraints ......................37
▫ Lap/Shoulder Belts .....................38
▫ Lap/Shoulder Belt Untwisting Procedure .....42
▫ Seat Belt Pretensioners ...................43
▫ Enhanced Seat Belt Reminder System
(BeltAlertt) ..........................43
▫ Automatic Locking Mode — If Equipped .....44
▫ Seat Belts And Pregnant Women ............45
▫ Seat Belt Extender ......................45
▫ Driver And Front Passenger Supplemental
Restraint System (SRS) - Airbag ............46
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11
▫ Event Data Recorder (EDR) ...............56
▫ Child Restraint ........................58
m Engine Break-In Recommendations ...........67
m Safety Tips ............................68
▫ Transporting Passengers .................68
▫ Lock Your Vehicle ......................68
▫ Exhaust Gas ..........................68
▫ Safety Checks You Should Make Inside
The Vehicle ..........................69
▫ Periodic Safety Checks You Should Make
Outside The Vehicle ....................70
2
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
A WORD ABOUT YOUR KEYS
Your vehicle uses a keyless ignition system. This system
consists of a Fob with Integrated Key and a Wireless
Ignition Node (WIN) with an integral ignition switch.
You can insert the double-sided integrated key into the
ignition switch with either side up.
Keyless Go Feature
This vehicle is equipped with the Keyless Go feature,
refer to Section 5 of this manual for more information.
Wireless Ignition Node (WIN)
The Wireless Ignition Node (WIN) operates similarly to
an ignition switch. It has four operating positions, three
of which are detented and one spring-loaded. The detented positions are LOCK, ACC, and ON. The START
position is a spring-loaded momentary contact position.
When released from the START position, the switch
automatically returns to the detented ON position.
1 — LOCK
2 — ACCESSORY
3—ON
4—START
Fob With Integrated Key
The Fob with Integrated Key operates the ignition switch.
It also contains the Remote Keyless Entry (RKE) transmitter and a valet key, which stores in the rear of the Fob.
The valet key allows for entry into the vehicle should the
battery in the vehicle or the Fob go dead. The valet key is
also for locking the glove box. You can keep the valet key
with you when valet parking.
To remove the valet key from the Fob, slide the mechanical latch at the top of the Fob sideways with your thumb
and then pull the key out of the Fob with your other
hand.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2
Valet Key Removal
NOTE: You can insert the double-sided valet key into
the lock cylinders with either side up.
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Ignition Key Removal
Place the shift lever in PARK. Turn the key to the LOCK
position and then remove the key.
NOTE: The power window switches, radio, power
sunroof (if equipped), and ignition-powered power outlets will remain active for up to 60 minutes after the
ignition switch is turned to the LOCK position. Opening
either door will cancel this feature. The time for this
feature is programmable. Refer to “Delay Power Off to
Accessories Until Exit,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4.
WARNING!
Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be seriously or fatally injured. Don’t leave the key in the
ignition. A child could operate power windows,
other controls, or move the vehicle.
CAUTION!
An unlocked car is an invitation to thieves. Always
remove key from the ignition and lock all doors
when leaving the vehicle unattended.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
Key-In-Ignition Reminder
If you open the driver’s door and the key is in the
ignition, a chime will sound to remind you to remove the
key.
NOTE: The Key-In-Ignition reminder only sounds
when the ignition key is placed in the LOCK or ACC
position.
SENTRY KEYT
The Sentry Keyt Immobilizer System prevents unauthorized vehicle operation by disabling the engine. The
system does not need to be armed or activated. Operation
is automatic, regardless of whether the vehicle is locked
or unlocked.
The system uses the factory-mated Remote Keyless Entry
(RKE) transmitter with integrated key and Wireless Ignition Node (WIN) to prevent unauthorized vehicle operation. Therefore, only RKE transmitters that are programmed to the vehicle can be used to start and operate
the vehicle. The system will not allow the engine to crank
if an invalid RKE transmitter is used to operate the
ignition switch.
After turning the ignition switch to the ON position, the
Vehicle Security Alarm Indicator Light will turn on for
three seconds for a bulb check. If the light remains on
after the bulb check, it indicates that there is a problem
with the electronics. This condition will result in the
engine being shut off after two seconds.
If the Vehicle Security Alarm Indicator Light turns on
during normal vehicle operation (vehicle running for
longer than 10 seconds), it indicates that there is a fault in
the electronics. Should this occur, have the vehicle serviced as soon as possible.
2
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
NOTE:
•
The Sentry Keyt Immobilizer System is not compatible with aftermarket remote starting systems. Use of
these systems may result in vehicle starting problems
and loss of security protection.
•
Exxon/Mobil Speedpass™, additional RKE transmitters, or any other transponder-equipped components
on the same key chain will not cause a fault unless the
additional part is physically held against the trans-
mitter being used to start the vehicle. Cell phones,
pagers, or other RF electronics will not cause interference with this system.
All of the RKE transmitters provided with your new
vehicle have been programmed to the vehicle electronics.
Replacement Keys
NOTE: Only RKE transmitters that are programmed to
the vehicle electronics can be used to start and operate
the vehicle. Once a transmitter is programmed to a
vehicle, it cannot be programmed to any other vehicle.
CAUTION!
Always remove the keys from the vehicle and lock all
doors when leaving the vehicle unattended.
At the time of purchase, the original owner is provided
with a four-digit Personal Identification Number (PIN).
Keep the PIN in a secure location. This number is
required for authorized dealer replacement of RKE transmitters. Duplication of RKE transmitters may be performed at an authorized dealer or by using the Customer
Key Programming procedure. This procedure consists of
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17
programming a blank transmitter to the vehicle electronics. A blank transmitter is one that has never been
programmed.
NOTE: When having the Sentry Keyt Immobilizer
System serviced, bring all vehicle RKE transmitters with
you to the authorized dealer.
Customer Key Programming
If you have two valid RKE transmitters with integrated
keys, you can program new transmitters to the system by
performing the following steps:
1. Insert the first valid integrated key into the ignition
switch and turn the ignition switch to the ON position for
at least three seconds, but no longer than 15 seconds.
Turn the ignition switch to the LOCK position and
remove the first key.
2. Insert the second valid integrated key and turn the
ignition switch to the ON position within 15 seconds.
After 10 seconds, a chime will sound and the Vehicle
Security Alarm Indicator Light will begin to flash. Turn
the ignition switch to the LOCK position and remove the
second key.
3. Insert a blank integrated key into the ignition switch
and turn the ignition switch to the ON position within 60
seconds. After 10 seconds, a single chime will sound and
the Vehicle Security Alarm Indicator Light will stop
flashing, turn on again for three seconds, and then turn
off.
The new integrated key is programmed. The RKE trans-
mitter will also be programmed during this procedure.
Repeat this procedure to program up to eight keys. If you
do not have a programmed RKE transmitter with integrated key, contact your authorized dealer for details.
2
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
NOTICE: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 du Canada
NOTICE: Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void the FCC authorization to operate this equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2.
Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced
radio/TV technician for help.
NOTE: If a programmed key is lost, see your authorized
dealer to have all remaining keys erased from the system’s memory. This will prevent the lost key from
starting your vehicle. The remaining keys must then be
reprogrammed. All vehicle keys must be taken to an
authorized dealer at the time of service to be reprogrammed.
General Information
The Sentry Keyt system complies with FCC rules Part 15
and with RSS-210 of Industry Canada. Operation is
subject to the following conditions:
•
This device may not cause harmful interference.
•
This device must accept any interference that may be
SECURITY ALARM SYSTEM
The Vehicle Security Alarm System monitors the vehicle
doors for unauthorized entry and the ignition switch for
unauthorized operation. If something triggers the alarm,
the system will prevent the vehicle from starting and
provide the following audible and visible signals: the
horn will pulse; the headlights will flash; the park lights
will flash; and the Vehicle Security Alarm Indicator Light
in the instrument cluster will flash.
Rearming Of The System
If something triggers the alarm, and no action is taken to
disarm it, the system will turn the horn off after three
minutes, turn all of the visual signals off after 15 minutes,
and then the system will rearm itself.
received, including interference that may cause undesired operation.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19
To Arm The System
Remove the key from the ignition switch and either press
a power door LOCK switch while the driver or passenger
door is open or press the LOCK button on the Remote
Keyless Entry (RKE) transmitter. After the last door is
closed, or if all doors are closed, the system will arm itself
in about 16 seconds. During that time, the Vehicle Security Alarm Indicator Light will flash. If it does not
illuminate, the system is not arming. In addition, if you
open a door during the arming period, the system will
cancel the arming process. If you wish to rearm the
system after closing the door, you must repeat one of the
previously-described arming sequences.
To Disarm The System
Either press the UNLOCK button on the RKE transmitter
or insert a valid ignition key into the ignition switch and
turn the key to the ON position.
NOTE:
•
The driver’s door key cylinder and the TRUNK button
on the RKE transmitter cannot arm or disarm the
system.
•
The system remains armed during trunk entry. Pressing the TRUNK button will not disarm the system. If
someone enters the vehicle through the trunk, and
opens any door, the alarm will sound.
•
When the system is armed, the interior power door
lock switches will not unlock the doors.
2
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
The Vehicle Security Alarm System is designed to protect
your vehicle; however, you can create conditions where
the system will give you a false alarm. If one of the
previously-described arming sequences has occurred, the
system will arm regardless of whether you are in the
vehicle or not. If you remain in the vehicle and open a
door, the alarm will sound. If this occurs, disarm the
system.
If the alarm system is armed and the battery becomes
disconnected, the system will remain armed when the
battery is reconnected. The exterior lights will flash, the
horn will sound, and the ignition will not start the
vehicle. If this occurs, disarm the system.
Tamper Alert
If something has triggered the system in your absence,
the horn will sound three times when you disarm the
system. Check the vehicle for tampering.
ILLUMINATED ENTRY SYSTEM
The courtesy lights will turn on when you press the
UNLOCK button on the Remote Keyless Entry (RKE)
transmitter or open any door.
The lights will fade to off after about 30 seconds or they
will immediately fade to off once the ignition switch is
turned ON from the LOCK position.
NOTE:
•
None of the courtesy lights will operate if the dimmer
control is in the “defeat” position (extreme downward
position), unless the overhead map/reading lights are
turned on manually.
REMOTE KEYLESS ENTRY
The Remote Keyless Entry (RKE) allows you to lock or
unlock the doors, open the trunk, or activate the Panic
Alarm from distances up to about 35 ft (11 m) using a
hand-held radio transmitter. The transmitter need not be
pointed at the vehicle to activate the system.
NOTE: Inserting the Fob with Integrated Key into the
ignition switch disables all buttons on that transmitter;
however, the buttons on the remaining transmitters will
continue to work. Driving at speeds 5 mph (8 km/h) and
above disables all transmitter buttons for all fobs.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2
Remote Keyless Entry (RKE) Transmitter
To Unlock The Doors
Press and release the UNLOCK button on the transmitter
once to unlock the driver’s door, or twice within five
seconds, to unlock both doors. The turn signal lights will
flash to acknowledge the unlock signal. The illuminated
entry system will also turn on.
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Remote Key Unlock, Driver Door/All Doors First
This feature lets you program the system to unlock either
the driver’s door or both doors on the first press of the
UNLOCK button on the transmitter. Refer to “Remote
Key Unlock,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4.
•
When not using the EVIC, perform the following
steps:
1. Press and hold the LOCK button on a programmed
transmitter for at least four seconds, but no longer than
10 seconds. Then, press and hold the UNLOCK button
while still holding the LOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle by press-
ing the LOCK/UNLOCK buttons on the transmitter with
the ignition switch in the LOCK position and the key
removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Pressing the LOCK button on the transmitter
while you are inside the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
Flash Lights with Remote Key Lock
This feature will cause the turn signal lights to flash when
the doors are locked or unlocked with the transmitter.
This feature can be turned on or turned off. Refer to
“Flash Lights with Remote Key Lock,” under 9Personal
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
Settings (Customer Programmable Features),” under
“Electronic Vehicle Information Center (EVIC)” in Section 4.
•
When not using the EVIC, perform the following
steps:
1. Press and hold the UNLOCK button on a programmed
transmitter for at least four seconds, but no longer than
10 seconds. Then, press and hold the LOCK button while
still holding the UNLOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle by pressing the LOCK/UNLOCK buttons on the transmitter with
the ignition switch in the LOCK position and the key
removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Pressing the LOCK button on the transmitter
while you are in the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
Turn Headlights On with Remote Key Unlock
This feature activates the headlights for up to 90 seconds
when the doors are unlocked with the transmitter. The
time for this feature is programmable. Refer to “Turn
Headlights On with Remote Key Unlock,” under “Per-
sonal Settings (Customer Programmable Features),” un-
der “Electronic Vehicle Information Center (EVIC)” in
Section 4.
To Lock The Doors
Press and release the LOCK button on the transmitter to
lock both doors. The turn signal lights will flash and the
horn will chirp to acknowledge the signal.
2
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Sound Horn with Remote Key Lock
This feature will cause the horn to chirp when the doors
are locked with the transmitter. This feature can be
turned on or turned off. Refer to “Sound Horn with
Remote Key Lock,” under “Personal Settings (Customer
Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4.
•
When not using the EVIC, perform the following
steps:
1. Press the LOCK button on a programmed transmitter
for at least four seconds, but no longer than 10 seconds.
Then, press the PANIC button while still holding the
LOCK button.
2. Release both buttons at the same time.
3. Test the feature while outside of the vehicle by pressing the LOCK button on the transmitter with the ignition
switch in the LOCK position and the key removed.
4. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Pressing the LOCK button on the transmitter
while you are in the vehicle will activate the Security
Alarm. Opening a door with the Security Alarm activated
will cause the alarm to sound. Press the UNLOCK button
to deactivate the Security Alarm.
Express Down Window Feature
This feature allows you to remotely lower both front door
windows at the same time. To use this feature, press and
release the UNLOCK button on the transmitter and then
immediately press and hold the UNLOCK button until
the windows lower to the level desired or until they
lower completely.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
To Open The Trunk
Press the TRUNK button on the transmitter two times
within five seconds to open the trunk.
Using The Panic Alarm
To turn the Panic Alarm feature ON or OFF, press and
hold the PANIC button on the transmitter for at least one
second and release. When the Panic Alarm is on, the
headlights and park lights will flash, the horn will pulse
on and off, and the interior lights will turn on.
The Panic Alarm will stay on for three minutes unless
you turn it off by either pressing the PANIC button a
second time or drive the vehicle at a speed of 15 mph (24
km/h) or greater.
NOTE:
•
The interior lights will turn off if you turn the ignition
switch to the ACC or ON position while the Panic
Alarm is activated. However, the exterior lights and
horn will remain on.
•
You may need to be less than 35 ft (11 m) from the
vehicle when using the transmitter to turn off the
Panic Alarm due to the radio frequency noises emitted
by the system.
Programming Additional Transmitters
Refer to Sentry Keyt, “Customer Key Programming.”
If you do not have a programmed transmitter, contact
your authorized dealer for details.
Transmitter Battery Service
The recommended replacement battery is one CR2032
battery.
NOTE:
•
Perchlorate Material — special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate
•
Do not touch the battery terminals that are on the back
housing or the printed circuit board.
2
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
1. Battery access is through a door located on the rear of
the fob. Insert a small, flat blade screwdriver into the slot
and gently pry open the access door.
1 — Battery Access Door
2. Remove and replace the batteries. Avoid touching the
new batteries with your fingers. Skin oils may cause
battery deterioration. If you touch a battery, clean it with
rubbing alcohol.
3. Reposition the access door panel over the battery
opening and snap into place.
General Information
This device complies with Part 15 of the FCC rules and
RSS 210 of Industry Canada. Operation is subject to the
following conditions:
•
This device may not cause harmful interference.
•
This device must accept any interference received,
including interference that may cause undesired operation.
NOTE: Changes or modifications not expressly ap-
proved by the party responsible for compliance could
void the user’s authority to operate the equipment.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
If your RKE transmitter fails to operate from a normal
distance, check for these two conditions:
1. A weak battery in the transmitter. The expected life of
the battery is a minimum of three years.
2. Closeness to a radio transmitter such as a radio station
tower, airport transmitter, and some mobile or CB radios.
REMOTE STARTING SYSTEM
This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conveniently from outside the
vehicle while still maintaining security. The system has a
targeted range of 328 ft (100 m).
NOTE: The vehicle must be equipped with an automatic transmission to be equipped with Remote Start.
How To Use Remote Start
All of the following conditions must be met before the
engine will remote start:
•
Shift lever in PARK
•
Doors closed
•
Hood closed
•
Trunk closed
•
Hazard switch off
•
Brake switch inactive (brake pedal not pressed)
•
Ignition key removed from ignition switch
•
Battery at an acceptable charge level, and
•
RKE PANIC button not pressed.
2
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
To Enter Remote Start Mode
Press and release the REMOTE START button
on the RKE transmitter twice, within five seconds. The parking lights will flash and the horn
will honk twice (if programmed). Then, the
engine will start and the vehicle will remain in the
Remote Start mode for a 15-minute cycle.
NOTE:
•
The park lamps will turn on and remain on during
Remote Start mode.
•
For security, power window and power sunroof operation (if so equipped) are disabled when the vehicle
is in the Remote Start mode.
•
The engine can be started two consecutive times (two
15-minute cycles) with the RKE transmitter. However,
the ignition switch must be cycled to the ON position
before you can repeat the start sequence for a third
cycle.
To Exit Remote Start Mode without Driving the
Vehicle
Allow the engine to run for the entire 15-minute cycle.
To Exit Remote Start Mode and Drive the Vehicle
Before the end of the 15-minute cycle, press and release
the UNLOCK button on the RKE transmitter to unlock
the doors and disarm the Vehicle Security Alarm (if
equipped). Then, prior to the end of the 15-minute cycle,
insert the key into the ignition switch and turn the switch
to the ON position.
NOTE:
•
The ignition switch must be in the ON position in
order to drive the vehicle.
•
For vehicles equipped with the Electronic Vehicle
Information Center (EVIC), the message “Insert Key/
Turn To Run” will flash in the EVIC until you insert
the key. Once inserted, the message “Turn To Run”
will flash in the EVIC until you turn the key to run.
To Turn Off the Engine While in Remote Start
Mode
Press and release the REMOTE START button one time.
NOTE: To avoid inadvertent shut downs, the system
will disable the one time press of the REMOTE START
button for two seconds after receiving a valid Remote
Start request.
DOOR LOCKS
Manual Door Locks
To lock each door, push the door lock plunger on each
door trim panel downward. Tounlock each door, pull the
door lock plunger on each door trim panel upward.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29
2
Door Lock Plunger
If the door lock plunger is down when you shut the door,
the door will lock. Therefore, make sure the key is not
inside the vehicle before closing the door.
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
•
For personal security and safety in the event of an
accident, lock the vehicle doors before you drive as
well as when you park and leave the vehicle.
•
When leaving the vehicle, always remove the key
from the ignition and lock your vehicle. Unsupervised use of vehicle equipment may cause severe
personal injuries and death.
•
Never leave children alone in a vehicle. Leaving
unattended children in a vehicle is dangerous for a
number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the key in
the ignition. A child could operate power windows, other controls, or move the vehicle.
Power Door Locks
The power door lock switch is located on each door trim
panel. Use this switch to lock or unlock the doors.
Power Door Lock Switch
If you press the power door lock switch while the key is
in the ignition, and any door is open, the power locks will
not operate. This prevents you from accidentally locking
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31
the key in the vehicle. Removing the key or closing the
door will allow the locks to operate. If a door is open, the
key is in the ignition, and the ignition is in the LOCK or
ACC position, a chime will sound as a reminder to
remove the key.
Automatic Door Locks
The doors will lock automatically if all of the following
conditions are met:
1. The Automatic Door Locks feature is enabled
2. The transmission is in gear
3. All doors are closed
4. The throttle is pressed
5. The vehicle speed is above 15 mph (24 km/h), and
6. The doors were not previously locked using the power
door lock switch or Remote Keyless Entry (RKE) transmitter.
Automatic Door Locks — If Equipped
The auto door lock feature can be enabled or disabled by
your authorized dealer. See your authorized dealer for
programming.
Automatic Unlock Doors on Exit
The doors will unlock automatically if:
1. The Automatic Unlock Doors On Exit feature is enabled
2. The transmission was in gear and the vehicle speed
returned to 0 mph (0 km/h)
3. The transmission is in NEUTRAL or PARK
4. The driver door is opened
5. The doors were not previously unlocked, and
6. The vehicle speed is 0 mph (0 km/h).
2
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Automatic Unlock Doors on Exit Programming
The Automatic Unlock Doors On Exit feature can be
enabled or disabled. Refer to “Unlock Doors Automatically on Exit,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4.
•
When not using the EVIC, perform the following
steps:
1. Enter the vehicle and close all doors.
2. Place the key in the ignition switch.
3. Within 15 seconds, cycle the ignition switch between
LOCK and ON and then back to LOCK four times ending
up in the LOCK position. However, do not start the
engine.
4. Within 30 seconds, depress the power door UNLOCK
switch to unlock the doors.
5. A single chime will indicate the completion of the
programming.
NOTE: If you do not hear the chime, it means that the
system did not enter the programming mode and you
will need to repeat the procedure.
6. Repeat these steps if you want to return this feature to
its previous setting.
NOTE: Use theAutomatic Unlock Doors On Exit feature
in accordance with local laws.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33
WINDOWS
Power Windows
The window controls on the driver’s door control both of
the door windows.
Power Window Switches
There is a single window control on the passenger’s door
trim panel that operates the window on the passenger’s
door. The window controls will operate only when the
ignition switch is in the ON or ACC position.
NOTE: The door window will lower slightly if it is
closed completely when opening the door. The window
will return to its fully closed position after closing the
door. This action allows the door to open without resistance and prevents window and top seal damage.
NOTE: You can remotely lower both the driver side and
passenger side windows at the same time. Refer to
“Remote Keyless Entry/Express Down Window Feature”
in this section.
2
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
Never leave children in a vehicle with the key in the
ignition switch. Occupants, particularly unattended
children, can become entrapped by the windows
while operating the power window switches. Such
entrapment may result in serious injury or death.
AUTO-Down Feature
The driver’s door power window switch and passenger door
power window switch on some models have an AUTOdown feature. Press the window switch to the second detent,
release, and the window will go down automatically.
To open the window part way, press the window switch
to the first detent and release it when you want the
window to stop.
To stop the window from going all the way down during
the AUTO-down operation, pull up on the switch briefly.
The power window switches will remain active for up to
60 minutes after the ignition switch is turned OFF.
Opening either door will cancel this feature. The time for
this feature is programmable. Refer to “Delay Power Off
to Accessories Until Exit,” under “Personal Settings (Customer Programmable Features),” under “Electronic Vehicle Information Center (EVIC)” in Section 4.
Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the sunroof (if equipped) in certain
open or partially open positions. This is a normal occurrence and can be minimized. If the buffeting occurs with
one window open, then open the other window to
minimize the buffeting. If the buffeting occurs with the
sunroof open, then adjust the sunroof opening to minimize the buffeting.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
TRUNK LOCK AND RELEASE
The trunk lid can be released from inside the vehicle by
pressing the Trunk Release button. The button is located
on the instrument panel to the left of the steering wheel.
NOTE: The transmission must be in PARK before the
switch will operate.
Trunk Release Button
The trunk lid can be released from outside the vehicle by
pressing the Trunk Release button on the Remote Keyless
Entry (RKE) transmitter twice within five seconds.
With the ignition switch in the ON position, the Trunk
Open symbol will display in the instrument cluster
indicating that the trunk is open. The odometer display
will reappear once the trunk is closed.
With the ignition switch in the LOCK position or the key
removed from the ignition switch, the Trunk Open symbol will display until the trunk is closed.
2
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
TRUNK SAFETY WARNING
WARNING!
Do not allow children to have access to the trunk,
either by climbing into the trunk from outside, or
through the inside of the vehicle. Always close the
trunk lid when your vehicle is unattended. Once in
the trunk, young children may not be able to escape,
even if they entered through the rear seat. If trapped
in the trunk, children can die from suffocation or
heat stroke.
Trunk Emergency Release
Emergency Release
The trunk of your vehicle is equipped with an emergency
release handle. It is located on the inside of the trunk lid,
near the latch, and is coated so that it glows in a darkened
trunk. Pull on the handle to open the trunk.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37
OCCUPANT RESTRAINTS
Some of the most important safety features in your
vehicle are the restraint systems. These include the front
and rear seat belts for the driver and all passengers, the
front airbags for both the driver and front passenger, and
the supplemental side curtain airbags for the driver and
passengers seated next to a window. If you will be
carrying children too small for adult-size belts, your seat
belts also can be used to hold infant and child restraint
systems.
Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passengers as safe as
possible.
WARNING!
In a collision, you and your passengers can suffer
much greater injuries if you are not properly buckled
up. Youcan strike the interior of your vehicle or other
passengers or you can be thrown out of the vehicle.
Always be sure you and others in your vehicle are
buckled up properly.
Buckle up even though you are an excellent driver, even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. This can happen
far away from home or on your own street.
2
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Research has shown that seat belts save lives, and they
can reduce the seriousness of injuries in a collision. Some
of the worst injuries happen when people are thrown
from the vehicle. Seat belts reduce the possibility of
ejection and the risk of injury caused by striking the
inside of the vehicle. Everyone in a motor vehicle should
be belted at all times.
Lap/Shoulder Belts
All seating positions in your vehicle are equipped with
lap/shoulder belts.
The belt webbing retractor is designed to lock during
very sudden stops or impacts. This feature allows the
shoulder part of the belt to move freely with you under
normal conditions. However, in a collision, the belt will
lock and reduce your risk of striking the inside of the
vehicle or being thrown out.
WARNING!
•
It is extremely dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in these areas
are more likely to be seriously injured or killed.
•
Do not allow people to ride in any area of your vehicle that is
not equipped with seats and seat belts.
•
Be sure everyone in your vehicle is in a seat and using a seat
belt properly.
•
Wearing a seat belt incorrectly is dangerous. Seat belts are
designed to go around the large bones of your body. These are
the strongest parts of your body and can take the forces of a
collision best.
•
Wearingyour belt in the wrong place could make your injuries
in a collision much worse. You might suffer internal injuries,
or you could even slide out of part of the belt. Follow these
instructions to wear your seat belt safely and to keep your
passengers safe, too.
•
Two people should never be belted into a single seat belt.
People belted together can crash into one another in an accident,
hurting one another badly. Never use a lap/shoulder belt or a lap
belt for more than one person, no matter what their size.
Lap/Shoulder Belt Operating Instructions
1. Enter the vehicle and close the door. Sit back and
adjust the front seat.
2. The seat belt latch plate is above the back of your seat.
Grasp the latch plate and pull out the belt. Slide the latch
plate up the webbing as far as necessary to make the belt
go around your lap.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2
Latch Plate
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
3. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a “click.”
Latch Plate To Buckle
WARNING!
•
A belt that is buckled into the wrong buckle will not protect
you properly. The lap portion could ride too high on your
body, possibly causing internal injuries. Always buckle your
belt into the buckle nearest you.
•
A belt that is too loose will not protect you as well. In a
sudden stop, you could move too far forward, increasing the
possibility of injury. Wear your seat belt snugly.
•
A belt that is worn under your arm is very dangerous. Your
body could strike the inside surfaces of the vehicle in a
collision, increasing head and neck injury.A belt worn under
the arm can cause internal injuries. Ribs are not as strong as
shoulder bones. Wearthe belt over your shoulder so that your
strongest bones will take the force in a collision.
•
A shoulder belt placed behind you will not protect you
from injury during a collision. You are more likely to hit your
head in a collision if you do not wear your shoulder belt. The
lap and shoulder belt are meant to be used together.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41
4. Position the lap belt across your thighs, below your
abdomen. To remove slack in the lap belt portion, pull up
a bit on the shoulder belt. To loosen the lap belt if it is too
tight, tilt the latch plate and pull on the lap belt. A snug
belt reduces the risk of sliding under the belt in a
collision.
WARNING!
• A lap belt worn too high can increase the risk of
internal injury in a collision. The belt forces won’t be
at the strong hip and pelvic bones, but across your
abdomen. Always wear the lap belt as low as possible and keep it snug.
A twisted belt cannot do its job as well. In a collision,
•
it could even cut into you. Be sure the belt is straight.
If you cannot straighten a belt in your vehicle, take it to
your authorized dealer and have it fixed.
5. Position the shoulder belt on your chest so that it is
comfortable and not resting on your neck. The retractor
will withdraw any slack in the belt.
2
Removing Slack From Belt
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
6. To release the belt, push the red button on the buckle.
The belt will automatically retract to its stowed position.
If necessary, slide the latch plate down the webbing to
allow the belt to retract fully.
WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do
not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (bent retractor, torn webbing,
etc.).
Lap/Shoulder Belt Untwisting Procedure
Use the following procedure to untwist a twisted lap/
shoulder belt.
1. Position the latch plate as close as possible to the
anchor point.
2. At about 6 to 12 in (15 to 30 cm) above the latch plate,
grasp and twist the belt webbing 180 degrees to create a
fold that begins immediately above the latch plate.
3. Slide the latch plate upward over the folded webbing.
The folded webbing must enter the slot at the top of the
latch plate.
4. Continue to slide the latch plate up until it clears the
folded webbing.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43
Seat Belt Pretensioners
The seat belts for both front seating positions are
equipped with pretensioning devices that are designed to
remove any slack from the seat belts in the event of a
collision. These devices improve the performance of the
seat belt system by assuring that the belt is tight around
the occupant in a collision. Pretensioners work for all size
occupants, including those in child restraints.
NOTE: These devices are not a substitute for proper seat
belt placement by the occupant. The seat belt still must be
worn snugly and positioned properly.
The pretensioners are triggered by the Occupant Restraint Controller (ORC). (Refer to information on Airbags in this section). Like the front airbags, the pretensioners are single use items. After a collision that is severe
enough to deploy the airbags and pretensioners, both
must be replaced.
Enhanced Seat Belt Reminder System (BeltAlertT)
If the driver’s seat belt has not been buckled within 60
seconds of starting the vehicle and if the vehicle speed is
greater than 5 mph (8 km/h), the Enhanced Warning
System (BeltAlertt) will alert the driver to buckle the seat
belt. The driver should also instruct all other occupants to
buckle their seat belts. Once the warning is triggered, the
BeltAlertt will continue to chime and flash the Seat Belt
Reminder Light for 96 seconds or until the driver’s seat
belt is buckled. The BeltAlertt will be reactivated if the
driver’s seat belt is unbuckled for more than 10 seconds
and the vehicle speed is greater than 5 mph (8 km/h).
BeltAlertt Programming
The BeltAlertt can be enabled or disabled by your
authorized dealer or by performing the following steps:
NOTE: Chrysler LLC does not recommend deactivating
the BeltAlertt.
2
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
1. With all doors closed, and the ignition switch in any
position except ON or START, buckle the driver’s seat
belt.
2. Turn the ignition switch to the ON position, but do not
start the engine. Wait for the Seat Belt Reminder Light to
turn off and then proceed to the next step.
NOTE: You must perform the following steps within 60
seconds of turning the ignition switch to the ON position.
3. Within 60 seconds of turning the ignition switch to the
ON position, unbuckle and then re-buckle the driver’s
seat belt at least three times, ending with the seat belt
buckled.
NOTE: Watch for the Seat Belt Reminder Light to turn
on while unbuckling the seat belt and turn off while
re-buckling the seat belt. It may be necessary to retract
the seat belt.
4. Turn the ignition switch to the LOCK position. A
single chime will sound to signify that you have successfully completed the programming.
The BeltAlertt can be reactivated by repeating this procedure.
NOTE: When the BeltAlertt is deactivated, the Seat Belt
Reminder Light will continue to illuminate as long as the
driver’s seat belt is unbuckled.
Automatic Locking Mode — If Equipped
In this mode, the shoulder belt is automatically prelocked. However, the belt will still retract to remove slack
in the shoulder belt. Use The Automatic Locking mode
any time a child safety seat is installed in a seating
position that has a seat belt with this feature. Children 12
years old and younger should be properly restrained in
the rear seat whenever possible.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45
How to Engage the Automatic Locking Mode
1. Buckle the combination lap and shoulder belt.
2. Grasp the shoulder portion and pull downward until
the entire belt is extracted.
3. Allow the belt to retract. As the belt retracts, you will
here a clicking sound. This indicates the safety belt is
now in the Automatic Locking mode.
How to Disengage the Automatic Locking Mode
Unbuckle the combination lap and shoulder belt and
allow it to retract completely to disengage the Automatic
Locking mode and activate the vehicle sensitive (emergency) locking mode.
Seat Belts and Pregnant Women
We recommend that pregnant women use the seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.
Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.
Seat Belt Extender
If a seat belt is too short even when fully extended and
when the adjustable upper shoulder belt anchorage (if so
equipped) is in its lowest position, your authorized
dealer can provide you with a seat belt extender. This
extender should be used only if the existing belt is not
long enough. When it is not required, remove the extender and store it.
2
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
Using a seat belt extender when not needed can
increase the risk of injury in a collision. Only use
when the seat belt is not long enough when it is worn
low and snug and in the recommended seating position. Remove and store the extender when not
needed.
Driver and Front Passenger Supplemental Restraint System (SRS) - Airbag
This vehicle has front airbags for both the driver and
front passenger as a supplement to the seat belt restraint
systems. The driver side front airbag is mounted in the
center of the steering wheel. The passenger side front
airbag is mounted in the instrument panel, above the
glove compartment. The words SRS AIRBAG are embossed on the airbag covers.
1 — Airbags
2 — Knee Bolsters
NOTE: The front airbags are certified to the Federal
regulations that allow less forceful deployment.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47
The front airbags have a multistage inflator design. This
allows the airbag to have different rates of inflation that
are based on collision severity.
WARNING!
•
Do not put anything on or around the front airbag
covers or attempt to open them. You may damage
the airbags and you could be injured because the
airbags are no longer functional. These protective
covers for the airbag cushions are designed to
open only when the airbags are inflating.
•
Do not drill, cut or tamper with the knee bolster in
any way.
•
Do not mount any accessories to the knee bolster
such as alarm lights, stereos, citizens band radios
etc.
This vehicle is also equipped with supplemental side
curtain airbags (located above the side windows) to
protect the driver and passenger sitting next to a window.
Their covers are also labeled SRS AIRBAG.
Side Window Airbag
NOTE: Airbag covers may not be obvious in the interior
trim, but they will open to allow airbag deployment.
2
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
•
Do not stack luggage or other cargo up high
enough to block the location of the side curtain
airbag. The area where the side curtain airbag is
located should remain free from any obstructions.
•
Do not have any accessory items installed which
will alter the roof, including adding a sunroof to
your vehicle. Do not add roof racks that require
permanent attachments (bolts or screws) for installation on the vehicle roof. Do not drill into the roof
of the vehicle for any reason.
NOTE: Do not use a clothing bar mounted to the coat
hooks in this vehicle. A clothing bar will impede the
proper performance of the curtain airbags.
Along with the seat belts, front airbags work with the
instrument panel knee bolsters to provide improved
protection for the driver and front passenger.Side curtain
airbags also work with seat belts to improve occupant
protection.
While the seat belts are designed to protect you in many
types of collisions, the front airbags will deploy in
moderate to severe frontal collisions. The supplemental
side curtain airbag on the crash side of the vehicle will
also trigger in moderate to severe side collisions. However, even in collisions where the airbags deploy, you
need the seat belts to keep you in the correct position for
the airbags to protect you properly.
Here are some simple steps you can take to minimize
the risk of harm from a deploying airbag.
1. Children 12 years old and younger should ride buckled up in the rear seat.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49
WARNING!
Infants in rear-facing child restraints should NEVER
ride in the front seat of a vehicle with a passenger
front airbag. An airbag deployment could cause
severe injury or death to infants in that position.
2. Children who are not big enough to wear the vehicle
seat belt properly should be secured in the rear seat in
child restraints or belt-positioning booster seats. (Refer to
information on Child Restraint in this section.)
3. Older children who do not use child restraints or
belt-positioning booster seats should ride properly buckled up in the rear seat. Never allow children to slide the
shoulder belt behind them or under their arm.
4. If a child from 1 to 12 years old must ride in the front
passenger seat because the vehicle is crowded, move the
seat as far back as possible and use the proper child
restraint. (Refer to information on Child Restraint in this
section.)
5. You should read the instructions provided with your
child restraint to make sure that you are using it properly.
6. All occupants should use their seat belts properly.
7. The driver and front passenger seats should be moved
back as far as practical to allow the airbags time to inflate.
8. Do not lean against the door, as the airbags will inflate
forcefully into the space between you and the door.
9. If the airbag system in this vehicle needs to be
modified to accommodate a disabled person, contact the
Customer Center. Phone numbers are provided in the 9If
You Need Customer Assistance9 section.
2
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
•
Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions, the airbags won’t deploy at all.
Always wear your seat belts even though you have
airbags.
•
Being too close to the steering wheel or instrument
panel during airbag deployment could cause serious injury. Airbags need room to inflate. Sit back,
comfortably extending your arms to reach the
steering wheel or instrument panel.
•
This vehicle has supplemental side curtain airbags, and they need room to inflate. Do not lean
against the door or window. Sit upright in the
center of the seat.
Airbag System Components
The airbag system consists of the following:
•
Occupant Restraint Controller (ORC)
•
Side Remote Acceleration Sensors
•
Side Door Pressure Sensors
•
Airbag Warning Light
•
Driver Airbag
•
Front Passenger Airbag
•
Supplemental Side Curtain Airbags above Side Windows
•
Steering Wheel and Column
•
Instrument Panel
•
Interconnecting Wiring
•
Seat Belt Reminder Light
•
Knee Impact Bolsters
•
Front Acceleration Sensors
•
Driver and Front Passenger Seat Belt Pretensioners
How the Airbag System Works
The Occupant Restraint Controller (ORC) determines
•
if a frontal collision is severe enough to require the
airbags to inflate. The front airbag inflators are designed to provide different rates of airbag inflation
from direction provided by the ORC. The ORC will not
detect rollover.
•
The ORC also determines if a side impact is severe
enough to deploy the supplemental side curtain airbag
as required for each type of impact.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51
•
The ORC also monitors the readiness of the electronic
parts of the system whenever the ignition switch is in
the START or ON position. These include all of the
items listed above except the knee bolster, the instrument panel, and the steering wheel and column. If the
key is in the LOCK position, in the ACC position, or
not in the ignition, the airbags are not on and they will
not inflate.
•
The ORC also turns on the Airbag Warning
Light in the instrument panel for six to eight
seconds as a self-check when the ignition is
first turned on. After the self-check, the
Airbag Warning Light will turn off. If the ORC detects
a malfunction in any part of the system, it turns on the
Airbag Warning Light either momentarily or continuously. A single chime will sound if the light comes on
again after initial start-up.
2
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
WARNING!
Ignoring the AIRBAG Warning Light in your instrument panel could mean you won’t have the airbags to
protect you in a collision. If the light does not come
on, stays on after you start the vehicle, or if it comes
on as you drive, have the airbag system checked right
away.
•
The Driver and Front Passenger Airbag/Inflator
Units are located in the center of the steering wheel
and the passenger side of the instrument panel. When
the ORC detects a collision requiring the airbags, it
signals the inflator units. A large quantity of nontoxic
gas is generated to inflate the front airbags. Different
airbag inflation rates may be possible based on collision severity. The steering wheel hub trim cover, and
the upper passenger side of the instrument panel
separate and fold out of the way as the bags inflate to
their full size. The bags fully inflate in about 50 to 70
milliseconds. This is about half of the time that it takes
to blink your eyes. The bags then quickly deflate while
helping to restrain the driver and front passenger. The
driver front airbag gas is vented through vent holes in
the sides of the airbag. The passenger front airbag gas
is vented through vent holes in the sides of the airbag.
In this way, the airbags do not interfere with your
control of the vehicle.
•
The Knee Impact Bolsters help protect the knees of
the driver and the front passenger and position everyone for the best interaction with the front airbag.
•
The Supplemental Side Impact SRS Side Curtain
Airbags are designed to activate only in certain side
collisions. When the ORC detects a collision requiring
the side curtain airbag to inflate, it signals the inflators
on the crash side of the vehicle. A quantity of nontoxic
gas is generated to inflate the side curtain airbag. The
inflating side curtain airbag pushes the outside edge of
the headliner out of the way and covers the window.
The airbag inflates in about 30 milliseconds (about
one-quarter of the time that it takes to blink your eyes)
with enough force to injure you if you are not belted
and seated properly, or if items are positioned in the
area where the side curtain airbag inflates. This especially applies to children. The side curtain airbag is
only about 3-1/2 in (9 cm) thick when it is inflated.
If a Deployment Occurs
The airbag system is designed to deploy when the ORC
detects a moderate-to-severe collision to help restrain the
driver and front passenger and then to immediately deflate.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53
NOTE:
need airbag protection will not activate the system. This
does not mean something is wrong with the airbag system.
If you do have a collision that deploys the airbags, any or
all of the following may occur:
•
•
A frontal collision that is not severe enough to
The nylon airbag material may sometimes cause abrasions and/or skin reddening to the driver and front
passenger as the airbags deploy and unfold. The
abrasions are similar to friction rope burns or those
you might get sliding along a carpet or gymnasium
floor. They are not caused by contact with chemicals.
They are not permanent and normally heal quickly.
However, if you haven’t healed significantly within a
few days or if you have any blistering, see your doctor
immediately.
As the airbags deflate, you may see some smoke-like
particles. The particles are a normal by-product of the
process that generates the nontoxic gas used for airbag
2
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
inflation. These airborne particles may irritate the skin,
eyes, nose, or throat. If you have skin or eye irritation,
rinse the area with cool water. For nose or throat
irritation, move to fresh air. If the irritation continues,
see your doctor. If these particles settle on your
clothing, follow the garment manufacturer’s instructions for cleaning.
•
It is not advisable to drive your vehicle after the
airbags have been deployed. If you are involved in
another collision, the airbags will not be in place to
protect you.
WARNING!
Deployed airbags cannot protect you in another collision. Have the airbags replaced by an authorized
dealer as soon as possible.
Enhanced Accident Response System
In the event of an impact that causes airbag deployment,
with the vehicle stopped, and the vehicle communication
network intact, and the power intact, the Enhanced
Accident Response System performs the following functions:
•
Cuts off fuel to the engine.
•
Flashes hazard lights.
•
Turns on the interior lights, which remain on as long as
the battery has power or until the ignition key is
removed.
•
Unlocks the doors automatically.
NOTE: The interior lights can only be deactivated if the
key is removed from the ignition switch or the vehicle is
driven.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55
Maintaining Your Airbag System
WARNING!
•
Modifications to any part of the airbag system could
cause it to fail when you need it. You could be injured
because the airbags are not there to protect you. Do
not modify the components or wiring, including
adding any kind of badges or stickers to the steering
wheel hub trim cover or the upper passenger side of
the instrument panel. Do not modify the front
bumper, vehicle body structure, or frame.
•
You need proper knee impact protection in a
collision. Do not mount or locate any aftermarket
equipment on or behind the knee impact bolster.
•
It is dangerous to try to repair any part of the
airbag system yourself. Be sure to tell anyone who
works on your vehicle that it has airbags.
NOTE:
apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Airbag Warning Light
an authorized dealer service the system promptly:
•
•
•
Perchlorate Material — special handling may
You will want to have the airbags ready to
inflate for your protection in an impact. While
the airbag system is designed to be maintenance free, if any of the following occurs, have
The Airbag Warning Light does not come on or flickers
during the six to eight seconds when the ignition
switch is first turned ON.
The light remains on or flickers after the six to eight
second interval.
The light flickers or comes on and remains on while
driving.
2
56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Event Data Recorder (EDR)
In the event of an accident, your vehicle is designed to
record up to five seconds of specific vehicle data parameters (see the following list) in an event data recorder
prior to the moment of airbag deployment, or near
deployment, and up to a quarter second of high-speed
deceleration data during and/or after airbag deployment. EDR data are ONLY recorded if an airbag deploys,
or nearly deploys, and are otherwise unavailable.
NOTE:
A near-deployment event occurs when the airbag sensor
1.
detects severe vehicle deceleration usually indicative of a
crash, but not severe enough to warrant airbag deployment.
2. Under certain circumstances, EDR data may not be
recorded (e.g., loss of battery power).
In conjunction with other data gathered during a complete accident investigation, the electronic data may be
used by Chrysler LLC and others to learn more about the
possible causes of crashes and associated injuries in order
to assess and improve vehicle performance. In addition
to crash investigations initiated by Chrysler LLC, such
investigations may be requested by customers, insurance
carriers, government officials, and professional crash
researchers, such as those associated with universities,
and with hospital and insurance organizations.
In the event that an investigation is undertaken by
Chrysler LLC (regardless of initiative), the company or its
designated representative will first obtain permission of
the appropriate custodial entity for the vehicle (usually
the vehicle owner or lessee) before accessing the electronic data stored, unless ordered to download data by a
court with legal jurisdiction (i.e., pursuant to a warrant).
Acopy of the data will be provided to the custodial entity
upon request. General data that does not identify particular vehicles or crashes may be released for incorporation in aggregate crash databases, such as those maintained by the U.S. government and various states. Data of
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57
a potentially sensitive nature, such as would identify a
particular driver, vehicle, or crash, will be treated confidentially. Confidential data will not be disclosed by
Chrysler LLC to any third party except when:
Used for research purposes, such as to match data with
1.
a particular crash record in an aggregate database, provided
confidentiality of personal data is thereafter preserved,
2. Used in defense of litigation involving a Chrysler LLC
product,
3. Requested by police under a legal warrant, or
4. Otherwise required by law.
Data Parameters that May Be Recorded:
•
Diagnostic trouble code(s) and warning light status for
electronically-controlled safety systems, including the
airbag system
•
Airbag disable light status (if equipped)
•
9Time9 of airbag deployment (in terms of ignition
cycles and vehicle mileage)
•
Airbag deployment level (if applicable)
•
Impact acceleration and angle
•
Seat belt status
•
Brake status (service and parking brakes)
•
Accelerator status (including vehicle speed)
•
Engine control status (including engine speed)
•
Transmission gear selection
•
Cruise control status
•
Traction/stability control status
•
Tire Pressure Monitoring System status (if equipped)
2
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Child Restraint
Everyone in your vehicle needs to be buckled up all the
time, including babies and children. Every state in the
United States and all Canadian provinces require that
small children ride in proper restraint systems. This is the
law, and you can be prosecuted for ignoring it.
Children 12 years and younger should ride properly
buckled up in a rear seat, if available. According to crash
statistics, children are safer when properly restrained in
the rear seats rather than in the front.
WARNING!
In a collision, an unrestrained child, even a tiny baby,
can become a missile inside the vehicle. The force
required to hold even an infant on your lap could
become so great that you could not hold the child, no
matter how strong you are. The child and others could
be badly injured. Any child riding in your vehicle
should be in a proper restraint for the child’s size.
There are different sizes and types of restraints for
children from newborn size to the child almost large
enough for an adult safety belt. Always check the child
seat Owner’s Manual to ensure you have the correct seat
for your child. Use the restraint that is correct for your
child.
Infants and Child Restraints
Safety experts recommend that children ride
•
rearward-facing in the vehicle until they are at least
one year old and weigh at least 20 lbs (9 kg). Twotypes
of child restraints can be used rearward-facing, infant
carriers and convertible child seats.
•
The infant carrier is only used rearward-facing in the
vehicle. It is recommended for children who weigh up
to about 20 lbs (9 kg). Convertible child seats can be
used either rearward-facing or forward-facing in the
vehicle. Convertible child seats often have a higher
weight limit in the rearward-facing direction than
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59
infant carriers do, so they can be used rearward-facing
by children who weigh more than 20 lbs (9 kg) but are
less than one year old. Both types of child restraints are
held in the vehicle by the lap/shoulder belt or the
LATCH child restraint anchorage system. Refer to
“LATCH — Child Seat Anchorage System (Lower
Anchors and Tether for CHildren)” in this section.
•
Rearward-facing child seats must NEVER be used in
the front seat of a vehicle with the front passenger
airbag unless the airbag is turned off. An airbag
deployment could cause severe injury or death to
infants in this position.
Older Children and Child Restraints
Children who weigh more than 20 lbs (9 kg) and who are
older than one year can ride forward-facing in the
vehicle. Forward-facing child seats and convertible child
seats used in the forward-facing direction are for children
who weigh 20 to 40 lbs (9 to 18 kg) and who are older
than one year. These child seats are also held in the
vehicle by the lap/shoulder belt or the LATCH child
restraint anchorage system. Refer to “LATCH — Child
Seat Anchorage System (Lower Anchors and Tether for
CHildren)” in this section.
The belt-positioning booster seat is for children weighing
more than 40 lbs (18 kg), but who are still too small to fit
the vehicle’s seat belts properly. If the child cannot sit
with knees bent over the vehicle’s seat cushion while the
child’s back is against the seatback, they should use a
belt-positioning booster seat. The child and beltpositioning booster seat are held in the vehicle by the
lap/shoulder belt.
2
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Children too Large for Booster Seats
Children who are large enough to wear the shoulder belt
comfortably and whose legs are long enough to bend
over the front of the seat when their back is against the
seatback should use the lap/shoulder belt in a rear seat.
•
Make sure that the child is upright in the seat.
•
The lap portion should be low on the hips and as snug
as possible.
•
Check belt fit periodically. A child’s squirming or
slouching can move the belt out of position.
•
If the shoulder belt contacts the face or neck, move the
child closer to the center of the vehicle. Never allow a
child to put the shoulder belt under an arm or behind
their back.
NOTE: For additional information, refer to
www.seatcheck.org or call 1–866–SEATCHECK.
WARNING!
•
Improper installation can lead to failure of an
infant or child restraint. It could come loose in a
collision. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.
•
A rearward-facing child restraint should only be
used in a rear seat. A rearward-facing child restraint in the front seat may be struck by a deploying passenger airbag, which may cause severe or
fatal injury to the infant.
Here are some tips on getting the most out of your child
restraint:
•
Before buying any restraint system, make sure that it
has a label certifying that it meets all applicable Safety
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61
Standards. We also recommend that you make sure
that you can install the child restraint in the vehicle
where you will use it before you buy it.
•
The restraint must be appropriate for your child’s
weight and height. Check the label on the restraint for
weight and height limits.
•
Carefully follow the instructions that come with the
restraint. If you install the restraint improperly, it may
not work when you need it.
•
Buckle the child into the seat according to the child
restraint manufacturer’s directions.
•
When your child restraint is not in use, secure it in the
vehicle with the seat belt or remove it from the vehicle.
Do not leave it loose in the vehicle. In a sudden stop or
collision, it could strike the occupants or seatbacks and
cause serious personal injury.
LATCH — Child Seat Anchorage System (Lower
Anchors and Tether for CHildren)
Your vehicle’s rear seat is equipped with the child
restraint anchorage system called LATCH. The LATCH
system provides for the installation of the child restraint
without using the vehicle’s seat belts, instead securing
the child restraint using lower anchorages and upper
tether straps from the child restraint to the vehicle
structure.
LATCH-compatible child restraint systems are now available. However, because the lower anchorages are to be
introduced over a period of years, child restraint systems
having attachments for those anchorages will continue to
have features for installation using the vehicle’s seat
belts. Child restraints having tether straps and hooks for
connection to the top tether anchorages have been available for some time. For some older child restraints, many
child restraint manufacturers offer add-on tether strap
2
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
kits or retrofit kits. You are urged to take advantage of all
the available attachments provided with your child restraint in any vehicle.
All three rear-seating positions have lower anchorages
that are capable of accommodating LATCH-compatible
child seats. You should NEVER install LATCHcompatible child seats so that two seats share a common
lower anchorage. If installing child seats in adjacent
rear-seating positions, or if your child restraints are not
LATCH-compatible, install the restraints using the vehicle’s seat belts.
LATCH Anchorages
Installing the LATCH-Compatible Child Restraint
System
We urge you to follow the manufacturer’s directions
carefully when installing your child restraint. Not all
child restraint systems will be installed as described here.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63
Again, carefully follow the installation instructions that
are provided with the child restraint system.
The rear seat lower anchorages are round bars
located at the rear of the seat cushion where it
meets the seatback and are just visible when
you lean into the rear seat to install the child
restraint. You will easily feel them if you run your finger
along the intersection of the seatback and seat cushion
surfaces.
In addition, there are tether strap anchorages
behind each rear seating position located in the
panel between the rear seatback and the rear
window. These tether strap anchorages are
under a plastic cover with this symbol on it.
Many, but not all restraint systems will be equipped with
separate straps on each side, with each having a hook or
connector for attachment to the lower anchorage and a
means of adjusting the tension in the strap. Forwardfacing toddler restraints and some rear-facing infant
restraints will also be equipped with a tether strap, a
hook for attachment to the tether strap anchorage and a
means of adjusting the tension of the strap.
You will first loosen the adjusters on the lower straps and
on the tether strap so that you can more easily attach the
hooks or connectors to the vehicle anchorages. Next,
attach the lower hooks or connectors over the top of the
seatcover material. Then rotate the tether anchorage
cover directly behind the seat where you are placing the
child restraint and attach the tether strap to the anchorage, being careful to route the tether strap to provide the
most direct path between the anchor and the child
restraint. Finally, tighten all three straps as you push the
child restraint rearward and downward into the seat,
removing slack in the straps according to the child
restraint manufacturer’s instructions.
2
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
NOTE:
•
Ensure that the tether strap does not slip into the
opening between the seatbacks as you remove slack in
the strap.
•
When using the LATCH attaching system to install a
child restraint, please ensure that all seat belts not
being used for occupant restraints are stowed and out
of reach of children. It is recommended that before
installing the child restraint, buckle the seat belt so the
seat belt is tucked behind the child restraint and out of
reach. If the buckled seat belt interferes with the child
restraint installation, instead of tucking the seat belt
behind the child restraint, route the seat belt through
the child restraint belt path and then buckle it. This
should stow the seat belt out of the reach of an
inquisitive child. Remind all children in the vehicle
that the seat belts are not toys and should not be
played with, and never leave your child unattended in
the vehicle.
WARNING!
Improper installation of a child restraint to the
LATCH anchorages can lead to failure of an infant or
child restraint. The child could be badly injured or
killed. Follow the manufacturer’s directions exactly
when installing an infant or child restraint.
Installing Child Restraints Using the Vehicle Seat
Belt
The passenger seat belts are equipped with either cinching latch plates or automatic locking retractors, which are
designed to keep the lap portion tight around the child
restraint so that it is not necessary to use a locking clip.
Pulling up on the shoulder portion of the lap/shoulder
belt will tighten the belt. The cinching latch plate will
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65
keep the belt tight; however, any seat belt system will
loosen with time, so check the belt occasionally and pull
it tight if necessary.
The seat belt must be in the Automatic Locking mode in
order to enable a child restraint to be tightly installed.
Refer to “Automatic Locking Mode” in this section. A
locking clip should not be necessary once the automatic
locking feature is enabled. Position the shoulder and lap
belt on the child restraint. The automatic locking retractor
is activated by first attaching the child seat, then pulling
all of the webbing out of the retractor, then allowing the
webbing to retract back into the retractor. Tighten webbing. To release, simply unbuckle the seat belt by depressing the button, allowing the webbing to retract into
the retractor.
In the rear seat, you may have trouble tightening the
lap/shoulder belt on the child restraint because the
buckle or latch plate is too close to the belt path opening
on the restraint. Disconnect the latch plate from the
buckle and twist the short buckle end belt several times
to shorten it. Insert the latch plate into the buckle with the
release button facing out.
If the belt still cannot be tightened, or if pulling and
pushing on the restraint loosens the belt, you may need
to do something more. Disconnect the latch plate from
the buckle, turn the buckle around, and insert the latch
plate into the buckle again. If you still cannot make the
child restraint secure, try a different seating position.
2
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
To attach a child restraint tether strap:
1. Rotate the cover over the anchor directly behind the
seat where you are placing the child restraint.
Tether Strap Mounting
2. Route the tether strap to provide the most direct path
for the strap between the anchor and the child seat.
3. Attach the tether strap hook (A) of the child restraint to
the anchor (B) and remove slack in the tether strap
according to the child restraint manufacturer’s instructions.
NOTE: Ensure that the tether strap does not slip into the
opening between the seatbacks as you remove slack in
the strap.
WARNING!
An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor positions directly behind
the child seat to secure a child restraint top tether
strap.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67
Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
ENGINE BREAK-IN RECOMMENDATIONS
A long break-in period is not required for the drivetrain
(engine, transmission, and rear axle) in your new vehicle.
Drive moderately during the first 500 mi (800 km). After
the initial 60 mi (100 km), speeds up to 50 or 55 mph (80
or 90 km/h) are desirable.
While cruising, brief full-throttle acceleration within the
limits of local traffic laws contributes to a good break-in.
However, wide-open throttle acceleration in low gear can
be detrimental and should be avoided.
The engine oil, transmission fluid, and axle lubricant
installed at the factory is high-quality and energyconserving. Oil, fluid, and lubricant changes should be
consistent with anticipated climate and conditions under
which vehicle operations will occur. The recommended
viscosity and quality grades is shown in Section 7.
CAUTION!
Never use Non-Detergent Oil or Straight Mineral Oil
in the engine or damage may result.
NOTE: A new engine may consume some oil during its
first few thousand miles (kilometers) of operation. This
should be considered as a normal part of the break-in and
not interpreted as an indication of difficulty.
2
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
SAFETY TIPS
Transporting Passengers
NEVER TRANSPORT PASSENGERS IN THE CARGO
AREA.
WARNING!
It is extremely dangerous to ride in a cargo area,
inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Lock Your Vehicle
Always remove the key from the ignition and lock all
doors when leaving the vehicle unattended, even in your
own driveway or garage. Try to park your vehicle in a
well-lit area and never invite theft by leaving articles of
value exposed.
Exhaust Gas
WARNING!
•
Exhaust gases can injure or kill. They contain
carbon monoxide (CO), which is colorless and
odorless. Breathing it can make you unconscious
and can eventually poison you. To avoid breathing
(CO) follow these safety tips.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69
Do not run the engine in a closed garage or in confined
areas any longer than needed to move your vehicle in or
out of the area.
If it is necessary to sit in a parked vehicle with the engine
running, adjust your heating or cooling controls to force
outside air into the vehicle. Set the blower at high speed.
If you are required to drive with the trunk open, make
sure that all windows are closed and the climate control
blower switch is set at high speed. DO NOT use the
recirculation mode.
The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.
Whenever a change is noticed in the sound of the exhaust
system, when exhaust fumes can be detected inside the
vehicle, or when the underside or rear of the vehicle is
damaged, have a competent mechanic inspect the complete exhaust system and adjacent body areas for broken,
damaged, deteriorated, or mispositioned parts. Open
seams or loose connections could permit exhaust fumes
to seep into the passenger compartment. In addition,
inspect the exhaust system each time the vehicle is raised
for lubrication or oil change. Replace as required.
Safety Checks You Should Make Inside The Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays, and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Front seat belt assemblies must be replaced after a
collision. Rear seat belt assemblies must be replaced after
a collision if they have been damaged (i.e., bent retractor,
torn webbing, etc.). If there is any question regarding belt
or retractor condition, replace the belt.
2
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Airbag Warning Light
The light should come on and remain on for six to eight
seconds as a bulb check when the ignition switch is first
turned ON. If the light is not lit during starting, see your
authorized dealer. If the light stays on, flickers, or comes
on while driving, have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield. See your
authorized dealer for service if your defroster is inoperable.
Periodic Safety Checks You Should Make Outside The Vehicle
Tires
Examine tires for excessive tread wear and uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect the tread and sidewall for
cuts and cracks. Check the wheel nuts for tightness.
Check the tires (including spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Door Latches
Check for positive closing, latching, and locking.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil, or other fluid leaks. Also, if gasoline
fumes are detected or if fuel, power steering fluid, or
brake fluid leaks are suspected, the cause should be
located and corrected immediately.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE
CONTENTS
m Mirrors ...............................75
▫ Automatic Dimming Inside Mirror ..........75
▫ Outside Mirrors .......................75
▫ Exterior Mirrors Folding Feature —
If Equipped ..........................76
m Hands-Free Communication (UConnectt)—
If Equipped ............................78
▫ Operation ............................80
▫ Phone Call Features ....................87
▫ UConnectt System Features ...............89
3
▫ Power Remote Control Mirrors .............76
▫ Heated Remote Control Mirrors —
If Equipped ..........................77
▫ Illuminated Vanity Mirrors — If Equipped ....77
▫ Advanced Phone Connectivity .............94
▫ Things You Should Know About Your
UConnectt System .....................96
▫ General Information ...................104
72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
m Voice Recognition System — If Equipped ......104
▫ Voice Recognition System (VR) Operation ....104
▫ Commands ..........................105
▫ Voice Training ........................108
m Seats ................................109
▫ Easy Entry Seats ......................109
▫ Power Seats .........................109
▫ Front Seat Back Recline .................110
▫ Lumbar Support ......................111
▫ Head Restraints ......................111
▫ Heated Seats ........................112
▫ Folding Rear Seat — If Equipped ..........113
m To Open And Close The Hood .............114
m Lights ...............................116
▫ Headlight Switch .....................116
▫ Automatic Headlights — If Equipped .......117
▫ Headlights On With Wipers
(Available With Auto Headlights Only) ......117
▫ Headlight Time Delay ..................117
▫ Daytime Running Lights — If Equipped .....118
▫ Lights-On Reminder ...................118
▫ Fog Lights ..........................118
▫ Multifunction Control Lever ..............119
▫ Overhead Console Map/Reading Lights .....120
▫ Interior Lights .......................121
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 73
m Windshield Wipers And Washers ............122
▫ Intermittent Wiper System ...............122
▫ Mist Feature .........................123
▫ Windshield Washers ...................123
▫ Headlights On With Wipers
(Available With Auto Headlights Only) ......124
▫ Adding Washer Fluid ..................124
m Tilt/Telescoping Steering Column ...........125
m Electronic Speed Control ..................126
▫ Electronic Speed Control Operation ........126
▫ To Activate ..........................127
▫ To Set At A Desired Speed ...............127
▫ To Deactivate ........................127
▫ To Resume Speed .....................128
▫ To Vary The Speed Setting ...............128
▫ To Accelerate For Passing ...............128
m Overhead Console ......................129
▫ Courtesy/Reading Lights ................129
▫ Sunglasses Storage ....................130
m Garage Door Opener — If Equipped .........130
▫ Programming HomeLinkt ...............131
▫ Gate Operator/Canadian Programming .....134
▫ Using HomeLinkt .....................134
▫ Reprogramming A Single HomeLinkt
Button .............................135
▫ Security ............................135
3
74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
▫ Troubleshooting Tips ...................135
▫ General Information ...................136
m Power Sunroof — If Equipped .............136
▫ Opening Sunroof - Manually .............137
▫ Opening Sunroof - Express ..............137
▫ Closing Sunroof - Manually ..............137
▫ Closing Sunroof - Express ...............138
▫ Pinch Protect Feature ...................138
▫ Pinch Protect Override .................138
▫ Venting Sunroof - Express ...............138
▫ Sunshade Operation ...................139
▫ Wind Buffeting .......................139
▫ Sunroof Maintenance ...................139
▫ Ignition Off Operation ..................139
▫ Sunroof Fully Closed ...................139
m Electrical Power Outlets ..................140
▫ Electrical Outlet Use With Engine Off .......141
m Cupholders ...........................142
▫ Front Cupholders .....................142
▫ Rear Cupholders ......................142
m Console Features .......................143
▫ Sliding Center Console Armrest ...........143
▫ Console Storage ......................143
m Rear Window Features ...................144
▫ Rear Window Defroster .................144
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 75
MIRRORS
Automatic Dimming Inside Mirror
This mirror automatically adjusts for annoying headlight
glare from vehicles behind you. You can turn the feature
on or off by pressing the button at the base of the mirror.
Alight next to the button will illuminate to indicate when
the dimming feature is activated.
Automatic Dimming Mirror
CAUTION!
To avoid damage to the mirror during cleaning, never
spray any cleaning solution directly onto the mirror.
Apply the solution onto a clean cloth and wipe the
mirror clean.
Outside Mirrors
To receive maximum benefit, adjust the outside mirror(s)
to center on the adjacent lane of traffic and a slight
overlap of the view obtained from the inside mirror.
NOTE: The passenger-side convex outside mirror will
give a much wider view to the rear, and especially of the
lane next to your vehicle.
3
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
WARNING!
Vehicles and other objects seen in the passenger-side
convex mirror will look smaller and farther away
than they really are. Relying too much on your
passenger-side convex mirror could cause you to
collide with another vehicle or other object. Use your
inside mirror when judging the size or distance of a
vehicle seen in the passenger-side convex mirror.
Exterior Mirrors Folding Feature — If Equipped
Some models have exterior mirrors that are hinged. The
hinge allows the mirror to pivot forward and rearward to
resist damage. The hinge has three detent positions, full
forward, full rearward, and normal.
Power Remote Control Mirrors
The power mirror switch is located on the driver’s door
trim panel next to the power door lock switch. A rotary
knob selects the left mirror, right mirror, or off position.
After selecting a mirror, move the knob in the same
direction you want the mirror to move. Use the center off
position to guard against accidentally moving a mirror
position.
Power Mirror Control
Heated Remote Control Mirrors — If Equipped
These mirrors are heated to melt frost or ice. This feature
is activated whenever you turn on the Electric Rear
Window Defroster.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
Illuminated Vanity Mirrors — If Equipped
An illuminated vanity mirror is on the sun visor. To use
the mirror, rotate the sun visor downward and swing the
mirror cover upward. The light turns on automatically.
Closing the mirror cover turns off the light.
3
Illuminated Vanity Mirror
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
HANDS-FREE COMMUNICATION (UConnectT)—
IF EQUIPPED
NOTE:
The sales code RER, REN and REU radios contain
an integrated Hands-Free Communication (UConnectt)
system. Refer to your “Navigation User’s Manual” for
UConnectt system operating instructions for these radios.
UConnectt is a voice-activated, hands-free, in-vehicle communications system. UConnectt allows you to dial a phone
number with your cellular phone using simple voice
commands (e.g., 9Call” { “Mike” {”Work9 or 9Dial” {
“248-555-12129). Your cellular phone’s audio is transmitted
through your vehicle’s audio system; the system will
automatically mute your radio when using the UConnectt
system.
NOTE: The UConnectt system requires a cellular phone
equipped with the Bluetootht9Hands-Free Profile,9 Ver-
sion 0.96 or higher. See the UConnectt website for
supported phones.
NOTE: For UConnectt customer support, visit the
following websites:
•
www.chrysler.com/uconnect
•
www.dodge.com/uconnect
•
www.jeep.com/uconnect
•
or call 1–877–855–8400
UConnectt allows you to transfer calls between the
system and your cellular phone as you enter or exit your
vehicle and enables you to mute the system’s microphone
for private conversation.
The UConnectt phonebook enables you to store up to 32
names, with four numbers per name. Each language has
a separate 32-name phonebook accessible only in that
language. This system is driven through your Bluetootht
“Hands-Free profile” cellular phone. UConnectt features
Bluetootht technology - the global standard that enables
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79
different electronic devices to connect to each other
without wires or a docking station, so UConnectt works
no matter where you stow your cellular phone (be it your
purse, pocket, or briefcase), as long as your phone is
turned on and has been paired to the vehicle’s
UConnectt system. The UConnectt system allows up to
seven cellular phones to be linked to the system. Only
one linked (or paired) cellular phone can be used with the
system at a time. The system is available in English,
Spanish, or French languages.
Phone Button
The rearview mirror contains the microphone
for the system (depending on the type of
mirror and radio equipped), and either the
radio or the mirror has the two control buttons
(PHONE Button and VOICE RECOGNITION button)
that will enable you to access the system.
Voice Recognition Button
Actual button location may vary with radio.
The individual buttons are described in the
“Operation” section.
The UConnectt system can be used with any Hands-Free
Profile certified Bluetootht cellular phone. See the
UConnectt website for supported phones. If your cellular phone supports a different profile (e.g., Headset
Profile) you may not be able to use any UConnectt
features. Refer to your cellular service provider or the
phone manufacturer for details.
The UConnectt system is fully integrated with the vehicle’s audio system. The volume of the UConnectt system
can be adjusted either from the radio volume control
knob or from the steering wheel radio control (right
switch), if so equipped.
3
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
The radio display will be used for visual prompts from
the UConnectt system such as 9CELL9 or caller ID on
certain radios.
Operation
Voice commands can be used to operate the UConnectt
system and to navigate through the UConnectt menu
structure. Voice commands are required after most
UConnectt system prompts. You will be prompted for a
specific command and then guided through the available
options.
•
Prior to giving a voice command, one must wait for
the beep, which follows the 9Ready9 prompt or another
prompt.
•
For certain operations, compound commands can be
used. For example, instead of saying 9Setup9 and then
9Phone Pairing,9 the following compound command
can be said: 9Setup Phone Pairing.9
•
For each feature explanation in this section, only the
combined form of the voice command is given. You
can also break the commands into parts and say each
part of the command when you are asked for it. For
example, you can use the combined form voice command 9Phonebook New Entry,9 or you can break the
combined form command into two voice commands:
9Phonebook9 and 9New Entry.9 Please remember, the
UConnectt system works best when you talk in a
normal conversational tone, as if speaking to someone
sitting a few feet/meters away from you.
Voice Command Tree
Refer to “Voice Tree” in this section.
Help Command
If you need assistance at any prompt, or if you want to
know your options at any prompt, say 9Help9 following
the beep. The UConnectt system will play all the options
at any prompt if you ask for help.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81
To activate the UConnectt system from idle, simply press
the PHONE button and follow the audible prompts for
directions. All UConnectt system sessions begin with a
press of the PHONE button on the radio control head.
Cancel Command
At any prompt, after the beep, you can say 9Cancel9 and
you will be returned to the main menu. However, in a
few instances the system will take you back to the
previous menu.
Pair (Link) UConnectt System to a Cellular Phone
To begin using your UConnectt system, you must pair
your compatible Bluetootht enabled cellular phone.
To complete the pairing process, you will need to reference your cellular phone Owner’s Manual. The
UConnectt website may also provide detailed instructions for pairing.
The following are general phone to UConnectt system
pairing instructions:
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Setup Phone Pairing.9
•
When prompted, after the beep, say 9Pair a Phone9 and
follow the audible prompts.
•
You will be asked to say a four-digit Personal Identification Number (PIN), which you will later need to
enter into your cellular phone. You can enter any
four-digit PIN. You will not need to remember this PIN
after the initial pairing process.
•
For identification purposes, you will be prompted to
give the UConnectt system a name for your cellular
phone. Each cellular phone that is paired should be
given a unique phone name.
3
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
•
You will then be asked to give your cellular phone a
priority level between 1 and 7, with 1 being the highest
priority. You can pair up to seven cellular phones to
your UConnectt system. However, at any given time,
only one cellular phone can be in use, connected to
your UConnectt system. The priority allows the
UConnectt system to know which cellular phone to
use if multiple cellular phones are in the vehicle at the
same time. For example, if priority 3 and priority 5
phones are present in the vehicle, the UConnectt
system will use the priority 3 cellular phone when you
make a call. You can select to use a lower priority
cellular phone at any time (refer to 9Advanced Phone
Connectivity9 in this section).
•
The system will prompt you to say the number you
want to call.
•
For example, you can say 9234-567-8901.9 The phone
number that you enter must be of valid length and
combination. Based on the country in which the vehicle was purchased, the UConnectt system limits the
user from dialing an invalid combination of numbers.
For example, in the U.S., 234-567-890 is nine digits
long, which is not a valid U.S. phone number - the
closest valid phone number has 10 digits.
•
The UConnectt system will confirm the phone number and then dial. The number will appear in the
display of certain radios.
Dial by Saying a Number
Press the PHONE button to begin.
•
•
After the 9Ready9 prompt and the following beep, say
9Dial.9
Call by Saying a Name
Press the PHONE button to begin.
•
•
After the 9Ready9 prompt and the following beep, say
“Call.9
•
The system will prompt you to say the name of the
person you want to call.
•
After the 9Ready9 prompt and the following beep, say
the name of the person you want to call. For example,
you can say 9John Doe,9 where John Doe is a previously stored name entry in the UConnectt phonebook.
To learn how to store a name in the phonebook, refer
to 9Add Names to Your UConnectt Phonebook,9 in
this section.
•
The UConnectt system will confirm the name and
then dial the corresponding phone number, which
may appear in the display of certain radios.
Add Names to Your UConnectt Phonebook
NOTE: Adding names to the phonebook is recom-
mended when the vehicle is not in motion.
•
Press the PHONE button to begin.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83
•
After the 9Ready9 prompt and the following beep, say
9Phonebook New Entry.9
•
When prompted, say the name of the new entry.Use of
long names helps the voice recognition and it is
recommended. For example, say 9Robert Smith9 or
9Robert9 instead of 9Bob.9
•
When prompted, enter the number designation (e.g.,
9Home,99Work,99Mobile,9 or 9Pager9). This will allow
you to store multiple numbers for each phonebook
entry, if desired.
•
When prompted, recite the phone number for the
phonebook entry that you are adding.
After you are finished adding an entry into the phonebook, you will be given the opportunity to add more
phone numbers to the current entry or to return to the
main menu.
3
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
The UConnectt system will allow you to enter up to 32
names in the phonebook with each name having up to
four associated phone numbers and designations. Each
language has a separate 32-name phonebook accessible
only in that language.
Phonebook Download
UConnectt allows the user to download entries from
their phone via Bluetootht. To use this feature, press the
PHONE button and say “Phonebook Download.” The
system prompts, “Ready to accept “V” card entry via
Bluetootht…” The system is now ready to accept phonebook entries from your phone using the Bluetootht
Object Exchange Profile (OBEX). Please see your phone
Owner’s Manual for specific instructions on how to send
these entries from your phone.
NOTE:
•
The phone handset must support Bluetootht OBEX
transfers of phonebook entries to use this feature.
•
Some phones cannot send phonebook entries if they
are already connected to any system via Bluetootht,
and you may see a message on the phone display that
the Bluetootht link is busy. In this case, the user must
first disconnect or drop the Bluetootht connection to
the UConnectt system, and then send the address
book entry via Bluetootht. Please see your phone
Owner’s Manual for specific instructions on how to
drop the Bluetootht connection.
•
If the phonebook entry is longer than 24 characters, it
will only use the first 24 characters.
Edit Entries in the UConnectt Phonebook
NOTE: Editing names in the phonebook is recom-
mended when the vehicle is not in motion.
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Phonebook Edit.9
•
You will then be asked for the name of the phonebook
entry that you wish to edit.
•
Next, choose the number designation (home, work,
mobile, or pager) that you wish to edit.
•
When prompted, recite the new phone number for the
phonebook entry that you are editing.
After you are finished editing an entry in the phonebook,
you will be given the opportunity to edit another entry in
the phonebook, call the number you just edited, or return
to the main menu.
9Phonebook Edit9 can be used to add another phone
number to a name entry that already exists in the
phonebook. For example, the entry John Doe may have a
mobile and a home number, but you can add ”John
Doe’s” work number later using the 9Phonebook Edit9
feature.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85
Delete Entries in the UConnectt Phonebook
NOTE: Editing phonebook entries is recommended
when the vehicle is not in motion.
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Phonebook Delete.9
•
After you enter the Phonebook Delete menu, you will
then be asked for the name of the entry that you wish
to delete. You can either say the name of a phonebook
entry that you wish to delete or you can say 9List
Names9 to hear a list of the entries in the phonebook
from which you choose. To select one of the entries
from the list, press the “Voice Recognition” button
while the UConnectt system is playing the desired
entry and say 9Delete.9
3
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
•
After you enter the name, the UConnectt system will
ask you which designation you wish to delete: home,
work, mobile, pager, or all. Say the designation you
wish to delete.
•
Note that only the phonebook entry in the current
language is deleted.
Delete All Entries in the UConnectt Phonebook
Press the PHONE button to begin.
•
•
After the 9Ready9 prompt and the following beep, say
9Phonebook Erase All.9
•
The UConnectt system will ask you to verify that you
wish to delete all the entries from the phonebook.
•
After confirmation, the phonebook entries will be
deleted.
•
Note that only the phonebook in the current language
is deleted.
List All Names in the UConnectt Phonebook
Press the PHONE button to begin.
•
•
After the 9Ready9 prompt and the following beep, say
9Phonebook List Names.9
•
The UConnectt system will play the names of all the
phonebook entries.
•
To call one of the names in the list, press the “Voice
Recognition” button during the playing of the desired
name, and say 9Call.9
NOTE: The user can also exercise 9Edit9 or 9Delete9
operations at this point.
•
The UConnectt system will then prompt you as to the
number designation you wish to call.
•
The selected number will be dialed.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87
Phone Call Features
The following features can be accessed through the
UConnectt system if the feature(s) are available on your
cellular service plan. For example, if your cellular service
plan provides three-way calling, this feature can be
accessed through the UConnectt system. Check with
your cellular service provider for the features that you
have.
Answer or Reject an Incoming Call - No Call
Currently in Progress
When you receive a call on your cellular phone, the
UConnectt system will interrupt the vehicle audio system, if on, and will ask if you would like to answer the
call. Press the PHONE button to accept the call. To reject
the call, press and hold the PHONE button until you hear
a single beep, indicating that the incoming call was
rejected.
Answer or Reject an Incoming Call - Call
Currently in Progress
If a call is currently in progress and you have another
incoming call, you will hear the same network tones for
call waiting that you normally hear when using your cell
phone. Press the PHONE button to place the current call
on hold and answer the incoming call.
NOTE: The UConnectt system compatible phones in
the market today do not support rejecting an incoming
call when another call is in progress. Therefore, the user
can only answer an incoming call or ignore it.
Making a Second Call While Current Call in Progress
To make a second call while you are currently on a call,
press the “Voice Recognition” button and say 9Dial9 or
9Call9 followedby the phone number or phonebook entry
you wish to call. The first call will be on hold while the
second call is in progress. To go back to the first call, refer
to 9Toggling Between Calls9 in this section. To combine
two calls, refer to 9Conference Call9 in this section.
3
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Place/Retrieve a Call From Hold
To put a call on hold, press the PHONE button until you
hear a single beep. This indicates that the call is on hold.
To bring the call back from hold, press and hold the
PHONE button until you hear a single beep.
Toggling Between Calls
If two calls are in progress (one active and one on hold),
press the PHONE button until you hear a single beep,
indicating that the active and hold status of the two calls
have switched. Only one call can be placed on hold at one
time.
Conference Call
When two calls are in progress (one active and one on
hold), press and hold the PHONE button until you hear
a double beep indicating that the two calls have been
joined into one conference call.
Three-Way Calling
To initiate three-way calling, press the “Voice Recognition” button while a call is in progress, and make a
second phone call, as described under 9Making a Second
Call While Current Call in Progress.9 After the second call
has established, press and hold the PHONE button until
you hear a double beep, indicating that the two calls have
been joined into one conference call.
Call Termination
To end a call in progress, momentarily press the PHONE
button. Only the active call(s) will be terminated and if
there is a call on hold, it will become the new active call.
If the active call is terminated by the far end, a call on
hold may not become active automatically. This is cell
phone-dependent. To bring the call back from hold, press
and hold the PHONE button until you hear a single beep.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89
Redial
Press the PHONE button to begin.
•
•
After the 9Ready9 prompt and the following beep, say
9Redial.9
•
The UConnectt system will call the last number that
was dialed from your cellular phone.
NOTE: This may not be the last number dialed from the
UConnectt system.
Call Continuation
Call continuation is the progression of a phone call on the
UConnectt system after the vehicle ignition key has been
switched to OFF. Call continuation functionality available on the vehicle can be any one of three types:
•
After the ignition key is switched to OFF, a call can
continue on the UConnectt system either until the call
ends, or until the vehicle battery condition dictates
cessation of the call on the UConnectt system and
transfer of the call to the mobile phone.
•
After the ignition key is switched to OFF, a call can
continue on the UConnectt system for a certain duration, after which the call is automatically transferred
from the UConnectt system to the mobile phone.
•
An active call is automatically transferred to the
mobile phone after the ignition key is switched to OFF.
UConnectT System Features
Language Selection
To change the language that the UConnectt system is
using:
•
Press the PHONE button to begin.
3
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
•
After the 9Ready9 prompt and the following beep, say
the name of the language you wish to switch to
English, Espanol, or Francais.
•
Continue to follow the system prompts to complete
language selection.
After selecting one of the languages, all prompts and
voice commands will be in that language.
NOTE: After every UConnectt language change opera-
tion, only the language-specific 32-name phonebook is
usable. The paired phone name is not language-specific
and usable across all languages.
Emergency Assistance
If you are in an emergency and the mobile phone is
reachable:
•
Pick up the phone and manually dial the emergency
number for your area.
If the phone is not reachable and the UConnectt system
is operational, you may reach the emergency number as
follows:
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Emergency9 and the UConnectt system will instruct
the paired cellular phone to call the emergency number. This feature is supported in the U.S., Canada, and
Mexico.
NOTE: The emergency number dialed is based on the
country where the vehicle is purchased (911 for the U.S.
and Canada and 060 for Mexico). The number dialed may
not be applicable with the available cellular service and
area.
The UConnectt system does slightly lower your chances
of successfully making a phone call as to that for the cell
phone directly.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91
Your phone must be turned on and paired to the
UConnectt system to allow use of this vehicle feature in
emergency situations, when the cell phone has network
coverage and stays paired to the UConnectt system.
Towing Assistance
If you need towing assistance:
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Towing Assistance.9
NOTE: The Towing Assistance number dialed is based
on the country where the vehicle is purchased (1-800-5282069 for the U.S., 1-877-213-4525 for Canada, 55-14-3454
for Mexico City and 1-800-712-3040 for outside Mexico
City in Mexico).
Please refer to the 24-Hour “Towing Assistance” coverage details in the Warranty Information Booklet and on
the 24–Hour Towing Assistance Card.
Paging
To learn how to page, refer to 9Working with Automated
Systems.9 Paging works properly except for pagers of
certain companies, which time out a little too soon to
work properly with the UConnectt system.
Voice Mail Calling
To learn how to access your voice mail, refer to 9Working
with Automated Systems.9
Working with Automated Systems
This method is used in instances where one generally has
to press numbers on the cellular phone keypad while
navigating through an automated telephone system.
You can use your UConnectt system to access a voice
mail system or an automated service, such as a paging
service or automated customer service line. Some services require immediate response selection. In some
instances, that may be too quick for use of the UConnectt
system.
3
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
When calling a number with your UConnectt system
that normally requires you to enter in a touch-tone
sequence on your cellular phone keypad, you can press
the “Voice Recognition” button and say the sequence you
wish to enter, followed by the word 9Send.9 For example,
if required to enter your PIN followed with a pound, (3 7
4 6 #), you can press the “Voice Recognition” button and
say, 93746#Send.9 Saying a number, or sequence of
numbers, followed by 9Send,9 is also to be used for
navigating through an automated customer service center menu structure, and to leave a number on a pager.
You can also send stored UConnectt phonebook entries
as tones for fast and easy access to voice mail and pager
entries. To use this feature, dial the number you wish to
call and then press the “Voice Recognition” button and
say, “Send.” The system will prompt you to enter the
name or number and say the name of the phonebook
entry you wish to send. The UConnectt system will then
send the corresponding phone number associated with
the phonebook entry, as tones over the phone.
NOTE:
•
You may not hear all of the tones due to cellular phone
network configurations; this is normal.
•
Some paging and voice mail systems have system time
out settings that are too short and may not allow the
use of this feature.
Barge In - Overriding Prompts
The “Voice Recognition” button can be used when you
wish to skip part of a prompt and issue your voice
recognition command immediately. For example, if a
prompt is asking 9Would you like to pair a phone, clear
a{,9 you could press the “Voice Recognition” button and
say, 9Pair a Phone9 to select that option without having to
listen to the rest of the voice prompt.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93
Turning Confirmation Prompts On/Off
Turning confirmation prompts off will stop the system
from confirming your choices (e.g., the UConnectt system will not repeat a phone number before you dial it).
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Setup Confirmations.9 The UConnectt system will
play the current confirmation prompt status and you
will be given the choice to change it.
Phone and Network Status Indicators
If available on the radio and/or on a premium display
such as the instrument panel cluster, and supported by
your cell phone, the UConnectt system will provide
notification to inform you of your phone and network
status when you are attempting to make a phone call
using UConnectt. The status is given for roaming, network signal strength, phone battery strength, etc.
Dialing Using the Cellular Phone Keypad
You can dial a phone number with your cellular phone
keypad and still use the UConnectt system (while dialing via the cell phone keypad, the user must exercise
caution and take precautionary safety measures). By
dialing a number with your paired Bluetootht cellular
phone, the audio will be played through your vehicle’s
audio system. The UConnectt system will work the same
as if you dial the number using voice recognition.
NOTE: Certain brands of mobile phones do not send the
dial ring to the UConnectt system to play it on the
vehicle audio system, so you will not hear it. Under this
situation, after successfully dialing a number the user
may feel that the call did not go through even though the
call is in progress. Once your call is answered, you will
hear the audio.
3
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Mute/Un-Mute (Mute Off)
When you mute the UConnectt system, you will still be
able to hear the conversation coming from the other
party, but the other party will not be able to hear you. In
order to mute the UConnectt system:
•
Press the “Voice Recognition” button.
•
Following the beep, say 9Mute.9
In order to un-mute the UConnectt system:
•
Press the “Voice Recognition” button.
•
Following the beep, say 9Mute off.9
Advanced Phone Connectivity
Transfer Call to and from Cellular Phone
The UConnectt system allows ongoing calls to be transferred from your cellular phone to the UConnectt system
without terminating the call. To transfer an ongoing call
from your UConnectt paired cellular phone to the
UConnectt system or vice versa, press the “Voice Recognition” button and say 9Transfer Call.9
Connect or Disconnect Link Between the
UConnectt System and Cellular Phone
Your cellular phone can be paired with many different
electronic devices, but can only be actively 9connected9
with one electronic device at a time.
If you would like to connect or disconnect the Bluetootht
connection between a UConnectt paired cellular phone
and the UConnectt system, follow the instructions described in your cellular phone User’s Manual.
List Paired Cellular Phone Names
Press the PHONE button to begin.
•
•
After the “Ready” prompt and the following beep, say
“Setup Phone Pairing.”
•
When prompted, say 9List Phones.9
•
The UConnectt system will play the phone names of
all paired cellular phones in order from the highest to
the lowest priority. To “select” or “delete” a paired
phone being announced, press the “Voice Recognition” button and say “Select” or “Delete.” Also, see the
next two sections for an alternate way to “select” or
“delete” a paired phone.
Select Another Cellular Phone
This feature allows you to select and start using another
phone paired with the UConnectt system.
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Setup Select Phone9 and follow the prompts.
•
You can also press the “Voice Recognition” button at
any time while the list is being played, and then
choose the phone that you wish to select.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95
•
The selected phone will be used for the next phone
call. If the selected phone is not available, the
UConnectt system will return to using the highest
priority phone present in or near (approximately
within 30 ft [9 m]) the vehicle.
Delete UConnectt Paired Cellular Phones
•
Press the PHONE button to begin.
•
After the 9Ready9 prompt and the following beep, say
9Setup Phone Pairing.9
•
At the next prompt, say 9Delete9 and follow the
prompts.
•
You can also press the “Voice Recognition” button at
any time while the list is being played, and then
choose the phone you wish to delete.
3
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Things You Should Know About Your UConnectT
System
UConnectt Tutorial
To hear a brief tutorial of the system features, press the
PHONE button and say “UConnectt Tutorial.”
Voice Training
For users experiencing difficulty with the system recognizing their voice commands or numbers, the UConnectt
system Voice Training feature may be used. To enter this
training mode, follow one of the two following procedures:
From outside the UConnectt mode (e.g., from radio
mode):
•
Press and hold the “Voice Recognition” button for five
seconds until the session begins, or,
•
Press the “Voice Recognition” button and say the
9Setup, Voice Training9 command.
Repeat the words and phrases when prompted by the
UConnectt system. For best results, the Voice Training
session should be completed when the vehicle is parked
with the engine running, all windows closed, and the
blower fan switched OFF.
This procedure may be repeated with a new user. The
system will adapt to the last trained voice only.
To restore the Voice Recognition system to factory default
settings, enter the Voice Training session via the above
procedure and follow the prompts.
Voice Recognition (VR)
•
For best performance, adjust the rearview mirror to
provide at least
1
⁄2in (1 cm) gap between the overhead
console (if equipped) and the mirror.
•
Always wait for the beep before speaking.
•
Speak normally, without pausing, just as you would
speak to a person sitting a few feet/meters away from
you.
•
Make sure that no one other than you is speaking
during a voice recognition period.
•
Performance is maximized under:
•
low-to-medium blower setting,
•
low-to-medium vehicle speed,
•
low road noise,
•
smooth road surface,
•
fully closed windows,
•
dry weather condition.
•
Even though the system is designed for users speaking
in North American English, French, and Spanish accents, the system may not always work for some.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97
•
When navigating through an automated system such
as voice mail, or when sending a page, at the end of
speaking the digit string, make sure to say 9Send.9
•
Storing names in the phonebook when the vehicle is
not in motion is recommended.
•
It is not recommended to store similar sounding
names in the UConnectt phonebook.
•
The UConnectt phonebook nametag recognition rate
is optimized for the person who stored the name in the
phonebook.
•
You can say 9O9 (letter 9O9) for 909 (zero). 98009 must be
spoken 9eight-zero-zero.9
•
Even though international dialing for most number
combinations is supported, some shortcut dialing
number combinations may not be supported.
•
In a convertible vehicle, system performance may be
compromised with the convertible top down.
3
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
Far End Audio Performance
Audio quality is maximized under:
•
•
low-to-medium blower setting,
•
low-to-medium vehicle speed,
•
low road noise,
•
smooth road surface,
•
fully closed windows,
•
dry weather conditions, and
•
operation from the driver’s seat.
•
Performance, such as audio clarity, echo, and loudness
to a large degree rely on the phone and network, and
not the UConnectt system.
•
Echo at the far end can sometimes be reduced by
lowering the in-vehicle audio volume.
•
In a convertible vehicle, system performance may be
compromised with the convertible top down.
Bluetootht Communication Link
Cellular phones have been found to lose connection to
the UConnectt system. When this happens, the connection can generally be re-established by switching the
phone off/on. Your cell phone is recommended to remain
in Bluetootht ON mode.
Power-Up
After switching the ignition key from OFF to either ON
or ACC position, or after a language change, you must
wait at least five seconds prior to using the system.
Loading...
