Marq Haze 700 User manual

User Guide

Guía del usuario

Guide d’utilisation

Guida per l’uso

Benutzerhandbuch

Appendix

English (3–6)

Español (7–10)

Français (11–14)

Italiano (15–18)

Deutsch (19–22)

English (23)

User Guide (English)

Introduction

Box Contents

Haze 700 User Guide Power Cable Safety & Warranty Manual Remote Control (wired)

Support

For the latest information about this product (documentation, technical specifications, system requirements, compatibility information, etc.) and product registration, visit marqlighting.com.

For additional product support, visit marqlighting.com/support.

Safety Notes

Important: In addition to the notes throughout this manual, please refer to the included safety &

warranty manual for additional safety information.

• Carry this product by the handles only. Do not shake it.

• Use this product indoors only. To prevent risk of fire or shock, do not expose this product to rain

or direct and excessive moisture.

• If the environment is significantly colder than the temperature of Haze 700, you may need to wait for it to adjust to the ambient temperature when you power it on.

• Do not use this product for permanent installations.

• Connect this product to grounded and protected circuits only.

• Always disconnect it from its power source before cleaning it or replacing the fuse. Replace the

fuse with another of the same type and rating.

• Do not clean it with solvents or harsh detergents. Use a soft, clean cloth.

• Before connecting the product to a power source, make sure the power cable is not crimped or

damaged.

• Make sure the power outlet’s voltage is within the range stated on this product (on its housing or decal).

• Never disconnect this product from the power cable by pulling or tugging on the cable itself.

• Always make sure this product is used in a location with adequate ventilation with at least 20”

(50cm) from adjacent surfaces. Make sure none of this product’s ventilation slots are obstructed.

• Do not use this product at ambient temperatures higher than 104 °F / 40 °C.

• Do not allow flammable materials near this product during use.

• Do not touch this product while it is powered on or immediately after powering it off. The product

and its housing can reach high temperatures.

• If you encounter a serious problem while using this product, stop using it immediately.

• Do not open this product’s housing. It contains no user-serviceable parts and will void your

warranty.

Features

Rear Panel

1. Cap: Twist this cap clockwise to tighten it or counterclockwise

2. Tank: Fill this tank with a high-quality, water-based haze fluid

3. Fluid Level Indicator: This transparent part of the tank shows

4. Power Cord: Connect this attached power cord to a power outlet.

5. Fuse: If the fuse is broken, disconnect the power cord from

6. Power Switch: Use this switch to power Haze 700 on or off.

7. Remote Control Input: Connect the remote control to this input.

Remote Control

1. Power Switch: Use this switch to power the remote on or off.

2. Power Light: This light will illuminate when Haze 700 is

3. Ready Light: This light will illuminate when Haze 700 is

4. Output: Turn this knob to control the amount of haze (0–100%).

to loosen it. The tube that passes through its center feeds the fluid in the tank to the heater.

only. Using non-water-based fluids with this product will void its warranty.

its current level of fluid. If this approaches the Low reading, fill the tank with the recommended water-based haze fluid.

the power outlet, and then unscrew this holder to replace the fuse. Replace it with a fuse with an appropriate rating (printed under on the rear panel). Using a fuse with an incorrect rating can damage the product and/or fuse.

After powering it on, wait for 2–3 minutes until the heater is warmed up and the Ready light on the remote control illuminates.

powered on. After powering it on, wait for 2–3 minutes until the heater is warmed up and the Ready light on the remote control illuminates.

warmed up and ready to use.

5 4

Operation

Fluid

We recommend using a high-quality, water-based haze fluid with Haze 700. You can purchase this from a local or online retailer.

Important: Using non-water-based fluids with this product will void its warranty.

Setup

Important: Use in well ventilated environment to prevent excessive concentration of vapor. Do not

use this product as a space heater or humidifier.

Any item not listed in Introduction > Box Contents is sold separately.

1. After unpacking the box, unscrew and remove the cap at the top of the tank.

2. Fill the tank with a water-based haze fluid (described above).

3. Screw the cap back onto the top of the tank so it is secure. Make sure the tube (that passes through the cap) is inserted as far into the tank as possible.

4. Connect the remote control to the rear panel of Haze 700.

5. Connect Haze 700 to a power outlet.

6. On the remote control, set the Power Switch to the On position. The Power light will illuminate, and Haze 700 will begin warming up.

Important: If the environment is significantly colder than the temperature of Haze 700, you may need to wait for it to adjust to the ambient temperature.

7. Wait for 2–3 minutes for Haze 700 to warm up. During this time, do not press any buttons on the remote control. The Ready light on the remote control will illuminate when it is ready to use.

Usage

If you are using the remote control:

When the Ready light on the remote control is on, turn the Output Volume knob to control the amount of haze.

If you are using the rear panel controls only (no remote control):

To set the amount of haze, press Volume. When H and 3 numbers appear, use the Up/Down

buttons to set a new value: 001 (low) to 005 (high).

When you are done using Haze 700, do not power it off immediately. Instead, turn the Output Volume knob completely counterclockwise, and then wait for about 1 minute. This will allow the heater to clear itself of any remaining fluid.

Important: Depending on the amount of haze generated, this product may set off smoke detectors. In certain environments after prolonged use, the haze produced may leave a slippery residue on floors and other surfaces.

Cleaning

We recommend cleaning it after each use to prevent eventual build-up or blockages, which can result in poor performance, overheating, and damage.

After each time you use Haze 700, turn the Output knob on the remote control completely counterclockwise, and then wait for 1–2 minutes. This will allow the heater to clear itself of any remaining fluid.

We also recommend wiping its metal housing with a soft, clean cloth. Remember to disconnect the power cord from its power outlet first.

Important: Do not clean Haze 700 using solvents or harsh detergents.

You may also use compressed air and soft brush or a vacuum to remove dust from the external vents or internal parts.

Guía del usuario (Español)

Introducción

Contenido de la caja

Haze 700 Guía de usuario Cable de corriente Manual de seguridad y garantía Control remoto (con cable)

Soporte

Para obtener la información más reciente acerca de este producto (documentación, especificaciones técnicas, requisitos de sistema, información de compatibilidad, etc.) y registrarlo, visite

marqlighting.com.

Para obtener soporte adicional del producto, visite marqlighting.com/support.

Notas sobre la seguridad

Importante: Además de las notas a lo largo de este manual, consulte el manual de seguridad y

garantía incluido para obtener información de seguridad adicional.

• Transporte este producto sujetándolo únicamente de las manijas. No lo sacuda.

• Use este producto solo en interiores. Para evitar el riesgo de incendio o choque eléctrico, no

exponga este producto a la lluvia o a la humedad directa y excesiva.

• Si el ambiente está significativamente más frío que la temperatura de este producto, puede que sea necesario esperar hasta que se adapte a la temperatura ambiente cuando lo encienda.

• No use este producto para instalaciones permanentes.

• Conecte este producto solo a circuitos protegidos y con descarga a tierra.

• Siempre desconecte el producto de su fuente de corriente antes de limpiarlo o reemplazar su

fusible. Remplace el fusible con otro del mismo tipo y capacidad.

• No lo limpie con solventes o detergentes agresivos. Utilice un paño suave y blando.

• Antes de conectar el producto a una fuente de corriente, asegúrese de que el cable de corriente

no esté pinzado ni dañado.

• Asegúrese de que el voltaje de la toma de corriente se encuentre dentro del rango indicado en este producto (en su carcasa o etiqueta).

• Nunca desconecte este producto tirando de su cable de corriente.

• Asegúrese de que este producto se use siempre en una ubicación con ventilación adecuada y al

menos 50 cm (20 pulg.) de distancia de superficies adyacentes. Asegúrese de que ninguna de las ranuras de ventilación de este producto queden obstruidas.

• No use este producto a temperaturas ambientes superiores a 104 °F / 40 °C.

• No acerque materiales inflamables a este producto durante su uso.

• No toque este producto mientras esté encendido o inmediatamente después de apagarlo. Este

producto y su carcasa pueden alcanzar temperaturas elevadas.

• Si se encuentra con un problema grave al usar este producto, deje de usarlo inmediatamente.

• No abra la carcasa de este producto. No contiene piezas reparables por el usuario y hacerlo

invalidará la garantía.

Características

Panel trasero

1. Tapa: Gire la tapa en sentido horario para apretarla o en sentido antihorario para aflojarla. El tubo que atraviesa su centro transporta el líquido en el tanque hacia el calentador.

2. Tanque: Llene este tanque sólo con fluidos para máquinas de niebla a base de agua de alta calidad. El uso de líquidos que no sean a base de agua en este producto invalidará su garantía.

3. Indicador de nivel de líquido: Esta parte transparente del tanque muestra su nivel actual de líquido. Si el nivel se acerca a la marca Low (Insuficiente) llene el tanque con el líquido para máquinas de niebla a base de agua recomendado.

4. Cable de alimentación: Conecte este cable de corriente incorporado a una toma de corriente.

5. Fusible: Si el fusible está roto, desconecte el cable de alimentación de la toma de corriente y desatornille este soporte para reemplazar el fusible. Reemplácelo por un fusible de la especificación apropiada (impresa en o debajo del portafusibles). Si utiliza un fusible de especificación incorrecta, puede dañarse la unidad y/o el fusible.

6. Interruptor de encendido: Utilice este interruptor para encender y apagar el Haze 700. Luego de encenderlo, espere de 2 a 3 minutos hasta que el calentador alcance la temperatura y se encienda la luz Ready (Listo) en el control remoto

7. Entrada del control remoto: Conecte a esta entrada el control remoto incluido.

Control remoto

1. Interruptor de encendido: Use este interruptor para encender y apagar el control remoto.

2. Luz de encendido: Esta luz se encenderá cuando el Haze 700 esté encendido. Luego de encenderlo, espere de 2 a 3 minutos hasta que el calentador alcance la temperatura y se encienda la luz Ready (Listo) en el control remoto.

3. Luz de humo listo: Esta luz se encenderá cuando el Haze 700 haya alcanzado la temperatura de funcionamiento y esté listo para utilizarse.

4. Output (Salida): Gire esta perilla para controlar la cantidad de niebla (0–100%).

5 4
