USER MANUAL 3
20626/ 20140707 • Split 812
ALL RIGHTS RESERVED MARMITEK ©
™
2 © MARMITEK
ENGLISH
SAFETY WARNINGS
x To prevent short circuits, this product should only be used inside and
only in dry spaces. Do not expose the components to rain or moisture.
Do not use the product close to a bath, swimming pool etc.
x Do not expose the components of your systems to extremely high
temperatures or bright light sources.
x In case of improper usage or if you have altered and repaired the
product yourself, all guarantees expire. Marmitek does not accept
responsibility in the case of improper usage of the product or when the
product is used for purposes other than specified. Marmitek does not
accept responsibility for additional damage other than covered by the
legal product responsibility.
x This product is not a toy. Keep out of reach of children.
x Do not open the product: the device may contain live parts. The product
should only be repaired or serviced by a qualified expert.
x Only connect the adapter to the mains after checking whether the
mains voltage is the same as the values on the identification tags.
Never connect an adapter or power cord when it is damaged. In that
case, contact your supplier.
1. INTRODUCTION
Congratulations on your purchase of the Split 812™!
This HDMI splitter connects one HDMI source (Blu-ray player, digital TV
set-top box, game console, etc.) with two screens (HDTV, projector or even
an AV amplifier). Unlike ordinary HDMI splitters, the Split 812™ can
simultaneously display two different video resolutions. This allows you to
enjoy Ultra HD optimally, without having to replace all of your other
equipment. Suitable for 4k2k Ultra HD, 1080p Full HD and all 3D formats.
Marmitek products are manufactured with the utmost precision and are of
high quality. Please read this user manual first and follow the instructions so
you can make the most of this product's capabilities.
Split 812™ 3
2. PACKAGE CONTENTS
1x HDMI splitter
1x Power adapter
1x HDMI cable
1x Usage instructions
3. PRODUCT CHARACTERISTICS
x Split and scale your HDMI signal to a 2nd (Ultra) HDTV or projector.
x Enables playing video and audio from your HDMI device (Digital TV
Decoder, Blu-ray player or HDD recorder) simultaneously on 2 screens.
x Continue to use your non-Ultra HD-enabled equipment*, simply by
using the unique automatic output scaling feature, which prevents it
from switching back to a lower resolution.
x The Auto Scaling feature automatically detects the highest possible
resolution of your display, and can simultaneously display two different
video resolutions again (1080p and 4k2k).
x Suitable for 4k2k Ultra HD, 1080p Full HD and all 3D formats.
x Supports High Definition LPCM 7.1CH, Dolby TrueHD and DTS-HD
Master Audio.
* Devices supporting a maximum resolution of Full HD 1080p (v1.3), such
as an HDTV, Projector, AV Receiver, etc.
HDMI PROPERTIES
x Video bandwidth 300MHz (enables 4k2k Ultra HD image display)
x 3D (suitable for use with your own 3D equipment).
x Deep Color 36-bit (billions instead of millions of colours, better
reproduction of subtle gradation variances and higher contrasts).
x Dolby TrueHD & DTS HD Master Audio (high quality audio support).
x Lip-Sync (prevents synchronisation problems between image and
sound).
4 © MARMITEK
ENGLISH
4. INSTALLATION
1. Connect the HDMI source to the Split 812™ ‘input’ via an HDMI cable.
2. Connect the HDMI screens to the Split 812™ ‘output’ via HDMI cables.
3. Connect the power adapter to the Split 812™ and plug into the socket.
Tip for installation:
Only use High Speed HDMI® certified cables for the best picture and sound
quality. Do not use much force to connect or disconnect the HDMI cables
otherwise they may become damaged.
5. USE
On both outputs, the Split 812™ detects the highest resolution possible for
the connected HDMI screens. The automatic scaling function selects the
highest resolution possible for each HDMI output, prevents compatibility
issues and ensures the highest possible image quality.
What can you do with it?
x Watch an Ultra HD source (4k2k) on a standard HDTV (1080p)
x Watch an Ultra HD source (4k2k) on an Ultra HDTV (4k2k)
x Watch an HD source (1080p) on an Ultra HDTV (4k2k)
x Watch an HD source (1080p) on a standard HDTV (1080p)
PLEASE NOTE:
3D resolutions cannot be adapted to 4k2k, but will be displayed unchanged
on both HDMI outputs.
Split 812™ 5
6. FAQ
No (or bad) image and sound
If you see a bad image or no image at all after connecting the HDMI splitter,
try to establish what the problem is by connecting your devices, one by one,
to your screen (TV, monitor or projector). This will allow you to establish
whether the problem lies in the HDMI sources, the HDMI cables, the HDMI
splitter or the screen. HDMI equipment that has not been tested and
certified by ATC (Authorized Test Centers) may cause image and sound
problems.
x Check whether the Split 812 power adapter is connected and plugged
in;
x Only use High Speed HDMI® certified cables for the best picture and
sound quality;
x Do not use HDMI cables that are longer than specified in the technical
data;
x Check whether the HDMI cables and/or connectors are damaged;
x Both the HDMI source as well as your screen must fully support HDMI;
x Check whether your HDMI sources and screen support HDCP (High-
bandwidth Digital Content Protection).
No proper 3D picture
• Check whether the HDMI source has been set to 3D and/or that this is
set to automatic.
• Both the HDMI source as well as the HD screen must support the same
3D formats.
• Check whether the proper 3D picture is reproduced by directly
connecting the HDMI source to the screen with an HDMI cable.
Do you have a question that has not been answered here? Then have a
look at www.marmitek.com
6 © MARMITEK
ENGLISH
7. TECHNICAL INFORMATION
Resolution
Supported Resolutions 480i, 480p, 576i, 576p, 720p, 1080i,
1080p, 4k2k@23/24/30Hz
Supported 3D formats 1080p@23.98/24Hz,
720p@59.94/60/50Hz
Maximum Pixel Frequency (max.) 300MHz
Single link Bit Rate (max.) 3 Gbps
Video Data Rate (max.) 9 Gbps
Output Video HDMI HDCP1.0/1.1
Inputs and outputs
HDMI Input (19-pin female) 1 HDMI
HDMI Output (19-pin female) 2 HDMI
Maximum HDMI cable length 15m
Splitter housing
Dimensions (HxWxD) 124 x 70 x 27mm
Weight 170g
Environment
Ambient temperature +0 to +70°C
Ambient humidity 10% up to 85%
Power
External power adapter Input: 100-240VAC @50-60Hz
Output: 5VDC @ 2A
Specifications may be modified without prior notice.
Split 812™ 7
DECLARATION OF CONFORMITY
Hereby, Marmitek BV, declares that this Split 812™ is in compliance with
the essential requirements and other relevant provisions of the following
Directives:
Directive 2004/108/ec of the european parliament and of the council of 15
December 2004 on the approximation of the laws of the Member States
relating to electromagnetic compatibility
Directive 2006/95/EC of the European Parliament and of the Council of 12
December 2006 on the harmonisation of the laws of Member States relating
to electrical equipment designed for use within certain voltage limits
Directive 2002/95/EC of the European Parliament and of the Council of 27
January 2003 on the restriction of the use of certain hazardous substances
in electrical and electronic equipment
Commission Regulation (EC) No 278/2009 of 6 April 2009 implementing
Directive 2005/32/EC of the European Parliament and of the Council with
regard to ecodesign requirements for no-load condition electric power
consumption and average active efficiency of external power supplies
MARMITEK BV - P.O. BOX 4257 - 5604 EG EINDHOVEN – THE NETHERLANDS
Environmental Information for Customers in the European Union
European Directive 2002/96/EC requires that the equipment bearing this symbol on
the product and/or its packaging must not be disposed of with unsorted municipal
waste. The symbol indicates that this product should be disposed of separately from
regular household waste streams. It is your responsibility to dispose of this and other
electric and electronic equipment via designated collection facilities appointed by the
government or local authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. For more detailed information about the
disposal of your old equipment, please contact your local authorities, waste disposal service, or
the shop where you purchased the product.
8 © MARMITEK
Copyrights
Marmitek is a trademark of Pattitude B.V. Split 812™ is a trademark of
Marmitek B.V. All rights reserved.
Copyright and all other proprietary rights in the content (including but not
limited to model numbers, software, audio, video, text and photographs)
rests with Marmitek B.V. Any use of the Content, but without limitation,
distribution, reproduction, modification, display or transmission without the
prior written consent of Marmitek is strictly prohibited. All copyright and
other proprietary notices shall be retained on all reproductions.
Split 812™ 39
