Marktech LC369MBL1-15Q Datasheet
COTCO LUMINANT DEVICE (HUIZHOU) LTD
Part #: LC369MBL1-15Q
Product Description: Blue 15º 3mm LED lamp with water transparent lens
Resin: Epoxy
Lens Color: Water Transparent
Lead Frame: Ag Plating Iron Alloy
Dice: InGaN/SiC
LC369MBL1-15Q
For Pricing and Delivery Information Contact:
Marktech Optoelectronics*
120 Broadway, Menands, NY 12204
Phone: 800.984.5337 FAX: 518.432.7454
Web Site: www.marktechopto.com
*Marktech is the exclusive North American Technical Sales and Marketi ng of fice for COTCO LED products
COTCO-D-074 REV.0
1/3
SPECIFICATION
Absolute Maximum Rating (T
Items Symbol Absolute maximum Rating Unit
= 25ºC)
a
LC369MBL1-15Q
Forward Current IF 25
Peak Forward Current
pulse width ≤0.1msec duty ≤1/10
Reverse Voltage VR 5
Power Dissipation PD 120
Operation Temperature T
Storage Temperature T
Lead Soldering Temperature T
Initial Electrical/Optical Characteristics (T
a
Items Symbol Condition Min. Typ. Max. Unit
Forward Voltage VF I
Reverse Current IR V
Wavelength
λ
D
Luminous Intensity IV I
50% Power Angle
2θ½
= 20mA 3.2 3.6 4.2 V
F
R
I
= 20mA 460 470 480 nm
F
= 20mA 280 550 --- mcd
F
IF = 20mA --- 15 --- deg
Luminous Intensity Combination
mA
100
I
FP
mA
V
mW
-20 ~ +75
opr
-30 ~ +80
stg
sol
(3mm from the base of the epoxy bulb)
260°C for 3 sec
ºC
ºC
= 25ºC)
= 5V --- --- 100 µA
Rank
Luminous Intensity
(If=20mA)
P Q R S
280-390 mcd 390-550 mcd 550-770 mcd 770-1100 mcd
*
One normal delivery will include all ranks listed above.
The quantity ratio of the ranks is decided by COTCO.
Measurement Uncertainty of the Luminous intensity : ±15%
