Mark SuperMultiParLED 120/4 User guide

SUPERMULTIPAR LED 120/4

12 X 10W LEDs (4 in 1)

User Manual/Manual de Uso

Rev. 140701

Please read this manual
carefully before operating
the LED light.

EN

LED DISPLAY FUNCTIONS

SLAE: Slave mode

DMX address

Manual red dimmer

Manual green dimmer

Manual blue dimmer

Manual white dimmer

Single color strobe

Multicolor strobe

Program 1

Program2

Program 3

DOWN

UP

d001 d512

UP

DOWN

000 255

UP

DOWN

000 255

UP

DOWN

b000 b255

UP

DOWN

H000 H255

UP

DOWN

1E00 1E20

UP

DOWN

2E00 2E20

UP

DOWN

1F00 1F20

UP

DOWN

2F00 2F20

UP

DOWN

3F00 3F20

UP

DOWN

SLAE

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

4F00

INC

4F20

UP

DOWN

UP

4U00 4U20

UP

DOWN

3U00 3U20

UP

DOWN

2U00 2U20

UP

DOWN

1U00 1U20

UP

DOWN

2J00 2J20

UP

DOWN

1J00 1J20

UP

DOWN

8F00 8F20

UP

DOWN

7F00 7F20

UP

DOWN

6F00 6F20

UP

DOWN

5F00 5F20

DEC

Program 4

DOWN

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

Sound 4

Sound 3

Sound 2

Sound 1

Program10

Program9

Program8

Program7

Program6

Program 5

SUPERMULTIPARLED 120/4 - 1 - User Manual/Manual de Uso

EN

DMX VALUES AND FUNCTIONS

Channel Values Functions

1 0-255 Manual red dimmer 0-100%
2 0-255 Manual green dimmer 0-100%
3 0-255 Manual blue dimmer 0-100%
4 0-255 Manual white dimmer 0-100%
5 0-255

6 0-255

7 0-255

8 0-255

Control the speed and strobe

0-16 no function, 17-255 choose the color.

(Channel 1-4 will not work in this mode. Channel 5
control the speed)

1-13 program 1, 14-27 program 2, 28-41 program 3,
42-55 program 4,56-69 program 5, 70-83 program 6,
84-97 program 7, 98-111program 8,112-125 program
9, 126-139 program 10,140-153 program 11,
154-167 program 12,168-181 program 13, 182-195
program 14, 196-209 program 15, 210-223 program
16, 224-237 program 17,238-251 program 18,
252-255 program19(Channel 1,2,3,4,6 will not work
in this mode. Channel 5 control the speed)

1-18 program 20,19-37 program 21, 38-56 program
22, 57-75 program 23, 76-94 program 24, 95-113
program 25, 114-132 program 26, 133-151 program
27, 152-170 program 28, 171-189 program 29,
190-208 sound 1, 209-227 sound 2, 228-246 sound
3, 247-255 sound 4. (Channel 1,2,3,4,6,7 will not
work in this mode. Channel 5 control the speed.)

SPECIFICATIONS

Rate Voltage: AC100V-240V 50Hz-60Hz
Rate Power: 104W
Color: RGBW
Lamp: Super bright, 4 in 1 LED lamps
Quantity of Lamp: 12pcs (10W each)
N.W.: 2.5kg

SUPERMULTIPARLED 120/4 - 2 - User Manual/Manual de Uso

Por favor, lea este manual
cuidadosamente antes de
hacer funcionar este proyector
LED.

ES

FUNCIONES DEL DISPLAY

SLAE: Modo Slave

Dirección DMX

Dimmer ROJO manual

Dimmer VERDE manual

Dimmer AZUL manual

Dimmer BLANCO manual

Strobo color simple

Strobo Multicolor

Programa 1

Programa 2

Programa 3

DOWN

UP

d001 d512

UP

DOWN

000 255

UP

DOWN

000 255

UP

DOWN

b000 b255

UP

DOWN

H000 H255

UP

DOWN

1E00 1E20

UP

DOWN

2E00 2E20

UP

DOWN

1F00 1F20

UP

DOWN

2F00 2F20

UP

DOWN

3F00 3F20

UP

DOWN

SLAE

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

4F00

INC

4F20

UP

DOWN

UP

4U00 4U20

UP

DOWN

3U00 3U20

UP

DOWN

2U00 2U20

UP

DOWN

1U00 1U20

UP

DOWN

2J00 2J20

UP

DOWN

1J00 1J20

UP

DOWN

8F00 8F20

UP

DOWN

7F00 7F20

UP

DOWN

6F00 6F20

UP

DOWN

5F00 5F20

DEC

Programa 4

DOWN

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

INC

DEC

Audio 4

Audio 3

Audio 2

Audio 1

Programa 10

Programa 9

Programa 8

Programa 7

Programa 6

Programa 5

SUPERMULTIPARLED 120/4 - 3 - User Manual/Manual de Uso

ES

VALORES DMX Y FUNCIONES

Canal

Valores

1 0-255 Dimmer Rojo manual 0 - 100%
2 0-255
3 0-255
4 0-255
5 0-255

6 0-255

7 0-255

8 0-255

Funciones

Dimmer Verde manual 0 - 100%
Dimmer Azul manual 0 - 100%
Dimmer Blanco manual 0 - 100%

Controla la velocidad del strobo

0-16 sin función, 17-255 elegir el color.

(Canales 1-4 no funcionan en este modo .
controla la velocidad)

1-13 program 1, 14-27 program 2, 28-41 program 3,
42-55 program 4,56-69 program 5, 70-83 program 6,
84-97 program 7, 98-111program 8,112-125 program
9, 126-139 program 10,140-153 program 11,
154-167 program 12,168-181 program 13, 182-195
program 14, 196-209 program 15, 210-223 program
16, 224-237 program 17,238-251 program 18,
252-255 program19(Canales 1,2,3,4,6 no funcionan
en este modo. Canal 5 controla la velocidad)

1-18 program 20,19-37 program 21, 38-56 program
22, 57-75 program 23, 76-94 program 24, 95-113
program 25, 114-132 program 26, 133-151 program
27, 152-170 program 28, 171-189 program 29,
190-208 audio 1, 209 -227 audio 2, 228 -246 audio
3, 247-255 audio 4. (Canales 1,2,3,4,6,7 no
funcionan en este modo. Canal 5 controla la veloc.)

Canal

5

ESPECIFICACIONES

Alimentación: AC100V-240V 50Hz-60Hz
Consumo: 104W
Color: RGBW
LEDs: LEDs 4 en 1 superbrillantes
Cantidad de LEDs: 12 LEDs (10W cada uno)
Peso.: 2.5kg

SUPERMULTIPARLED 120/4 - 4 - User Manual/Manual de Uso
