Mark SIDIUS LED 368 Z, COB SPOT 100 User Manual

Rev. 13.07.01

SIDIUS LED 368 Z

User Manual / Instrucciones de Usuario

Every person involved with installation. operation and maintenance of this fixture has to

- be qualified

- follow the instruction of this manual

- consider this manual to be part of the total product

- Keep this manual for the entire service life of the product

- pass this manual to every future owner or use of the product

INTRODUCTION

Thank you for choosing our fixture, if you follow up the instruction given in this manual we be sure that
you will enjoy this product for a long period of time

SAFETY INSTRUCTION

This device has left our premises in absolutely perfect condition .In order to maintain this condition and
to ensure a safe operation, it is absolutely necessary for the user to follow the safety instruction and
warning notes written in this user manual.

Important: Damages caused by the disregard of this user manual are not subject o warranty, the dealer
will not accept liability for any resulting defects of problem. If the device had been exposed to drastic
temperature fluctuation (e.g. after transportation),do not switch it on immediately. The arising
condensation water might damage your device. Leave the device switched off until it had reached room
temperature. Please make sure that there are no obvious transport damages, should you notice any
damages on the AC connection cable or on the casing, do not take the device into operation and
immediately consult your local dealer.

The device falls under protection-class. The power plug must only be plugged into a protection class I
outlet. The voltage and frequency must exactly be the same as stated on the device. Wrong voltages or
power outlets can lead to the destruction of the device and mortal electrical shock.Always plug in the
power plug last. The power plug must always be inserted without force .Make sure that the plug is tightly
connected with the outlet.

Never let the power-cord come into contact with other cables! Handle the power-cord and all

CAUTION!

Be careful with your operations, With a dangerous voltage you can suffer a dangerous electric

shock when touching the wires.

CAUTION !

Keep this device away from rain and moisture

Unplug mains lead before opening the housing

For your own safety, please read this user manual carefully before you initially start-up

SIDIUS LED 368 Z User Manual/Manual de uso Page 1

EN

connections with the mains with particular caution! Never touch them with wet hands .as this could lead
to mortal electrical shock. Never modify, bend, strain mechanically, put pressure on, pull or heat up the
power cord. Never operate next to sources of heat or cold. Disregard can lead to power cord damages,
fire or mortal electrical shock. The cable insert or the female part in the device must never be strained.
There must always be sufficient cable to the device. Otherwise, the cable may be damaged which may
lead to mortal electrical shock. Make sure that the power-cord is never crimped or damaged by sharp
edges. Check the device and the power-cord from time to time.If extension cords are used, make sure
that the core diameter is sufficient for the required power consumption of the device. All warnings
concerning the power cords are also valid for possible extension cords.

OPERATING DETERMINATIONS

This device is designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects. Do not shake the device. Avoid brute force when
installing or operation the device. Never lift the fixture by holding it at the projector-head. As the
mechanics may be damaged. When choosing the installation-spot, please make sure that the device is
not exposed to extreme heat, moisture or dust. There should not be any cable lying around. Please
make sure that the fixture can not be touched or bumped. Your endanger your own and the safety of
others.

The housing must never touch surrounding surfaces or objects. Make sure that the area below the
installation place is blocked when rigging, dragging or servicing the fixture. For overhead use (mounting
height>100cm), always fix the fixture with an appropriate safety-rope. Fix the safety-rope at the correct
fixation points only. The safety-rope must never be fixed at the transport handles. Only operate the
fixture after having check that the housing is firmly closed and all screw are tightly fastened.

The maximum ambient temperature Ta=450C must never be exceeded. Operate the device only after
having become familiarized with its functions. Do not permit operation by persons not qualified for
operating the device. Most damages are the result of unprofessional operation. Please use the original
packaging if the device is to be transported. Please consider that unauthorized modifications on the
device are forbidden due to safety reasons! Never remove the serial barcode from the device as this
would make the guarantee void. If this device will be operated in any way different to the one described
in this manual, the product may suffer damages and the guarantee becomes void. Furthermore, any
other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.

DESCRIPTION OF THE DEVICE
Features

> 11 channel DMX-512 .
> Pan :630°/tilt:270°.

> > V

36 pcs 8W RGBW QUAD LED

ariable electronic strobe.
> Variable electronic dimmer(0-100%).
> LED display menu with invert.
> Reset to factory settings option.

> Pan/Tilt invert option

> > Zoom angle from 18º to 55º

Fan cooled

SIDIUS LED 368 Z User Manual/Manual de uso Page 2

EN

INSTALLATION

Rigging

The installation of the projector has to be built and constructed in a way that it can hold 10 times the
weight for 1 hour without any harming deformation.

IMPORTANT!OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including calculating
working load limits, installation material being used, and periodic safety inspection of all installation
material and the projector. If you lack these qualifications, do not attempt the installation yourself, but
instead use a professional structural rigger. Improper installation can result in bodily injury and or
damage to property. The projector had to be installed out of the reach of people

DANGER OF FIRE! When installing the device, make sure there is no highly-inflammable
material(decoration articles, etc.)within a distance of min.0.5m.

DMX 512 connection/ connection between fixture

The wires must not come into contact with each other, otherwise the fixture will not work at all or
properly. Please note the starting address depends upon which controller is being used. Only use a
DMX cable and 3-pin XLR-plugs and connectors in order to connect the controller with the fixture or one
fixture to another

Connection with the mains.

The earth has to be connected. The device must only be connected with an electric installation carried
out in compliance with IEC standards.

OPERATION

After you connected the effect to the mains, The fixture starts running
Stand Alone operation
In the stand alone mode, the fixture can be use without controller

SIDIUS LED 368 Z User Manual/Manual de uso Page 3

EN

Master/slave-operation

The master/slave-operation enables that several devices can be synchronized and controlled by one
master-device

DMX controlled operation

You can control the projectors individually via your DMX-controller

Addressing

The control board allows you to assign the DMX starting address,
Note;it’s necessary to insert the XLR termination plug (with 120ohm) in the last device in the link in order
to ensure proper transmission on the DMX data link.

CONTROL BOARD

The control board offer several features :you can simple set the starting address, run the
pre-programmed program or make a reset

The main menu is accessed by pressing the Mode/Esc

button, Browse through the submenu by pressing
Up or Down .Press the Enter-button in order to select the desired menu. You can change the selection
by pressing Up or Down, Confirm every selection by pressing the Enter-button. You can leave every
mode by pressing the Mode/Esc-button .The functions provided are described in the following setting.

MENU MAP
DMX Address

(DMX address 001-512)

Mode

(DMX mode 15 ch, Auto mode1~8,sound mode)

TEST mode

(X,Y,Red,Green,Blue,White)
Setting (ID code0-25,X reverse,Y reverse,Fade delay,dmx signal,endcode,temperature
Protection,Temperature,fans seepd,screen protection,screen reverse, factory reset, rest motor,

System info

(running time, total running time, software version, run mode, address, temperature
