Marathon Electric Y452 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: 145TTDR5706

Catalog No: Y452

1 1/2,1800/1200,DP,145T,3/60/460

Other Purpose

Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 6

Product Information Packet: Model No: 145TTDR5706, Catalog No:Y452 1 1/2,1800/1200,DP,145T,3/60/460

Nameplate Specifications

Output HP
Frequency 60 Hz Voltage 460 V
Current
Service Factor
Efficiency 78.5 % Duty Continous
Insulation Class
KVA Code H Frame 145T
Enclosure Drip Proof Overload Protector No
Ambient Temperature
Opp Drive End Bearing Size 6203 UL Recognized
CSA
IP Code

1.50,0.67 Hp

2.3,1.3 A

1.15

B

40 °C

Y
22

Output KW

Speed
Phase

Design Code

Drive End Bearing Size

CE

1.1 kW

1725,1140 rpm
3

2VT

6205

Y

Technical Specifications

Electrical Type
Poles 4//6 Rotation Reversible

Squirrel Cage Induction Run

Starting Method

Across The Line

Mounting
Drive End Bearing Ball Opp Drive End Bearing Ball
Frame Material Rolled Steel Shaft Type T
Overall Length
Shaft Diameter 0.875 in Shaft Extension 2.28 in
Assembly/Box Mounting
Outline Drawing

Rigid base

12.99 in

F1 Only
A-100085-906

Motor Orientation

Frame Length

Connection Diagram

Horizontal

9.06 in

A-EE7317

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 07/02/2018

2 of 6

Regal Beloit America, Inc.

TM

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING I T IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, A ND/ OR USED, EXCEPT

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DEC.

INCH mm ANGLE
.X 0.1 [ 2.5] 7' 30"
.XX 0.03 [ 0.76]
.XXX 0.005 [ 0.127]
.XXXX 0.0005 [ 0.0127]
REMOVE BURRS & BREAK SHARP
EDGES: .003/.015 [.076/.381] X 45
CORNER FILLETS: R.02 [.51]
MACHINED SURFACES:

200 5.1

INCH mm
mm SHOWN IN [BRACKETS]

12

43

A

B

2

43

1

A

B

ECO DESCRIPTION

DATEAPPROVED BY

DATEREVISION BY

ECO

DRAWING REVISION

REFERENCE

MATERIAL

SHEET

DRAWING NUMBERSIZE

DESCRIPTION

THIRD ANGLE
PROJECTION

DRAWN BY

DATE

DATE

APPROVED BY

PROCESS/FINISH

B

1 OF 1

100085

GK

02-04-1988

FG

02-04-1998

E A. KEETHA 01-09-2018

ECO-0143026 PST 04/11/2018

OUTLINE CONVERSION PROJECT

OUTLINE

100085

140T & 56HZ - DR.PR.

1.CONDUIT BOX CAN BE ROTATED 180°.

NOTES:

DASH

NO.

"C" "BS"

706 10.99[279.14] 3.87[98.29]
756 11.49[291.84] 4.37[110.99]
806 11.99[304.54] 4.87[123.69]
856 12.49[317.24] 5.37[136.39]
906 12.99[329.94] 5.87[149.09]
956 13.49[342.64] 6.37[161.79]

2.28

57.90

(C)

BS

2.25

57.14

2.25

57.15

3.00

76.20

4.00

101.60

5.00

127.00

5.00

127.00

6.50

165.10

2.75

69.84

1.00

25.40

.8750
.8745

22.2237

22.2110

3.14

79.76

.50

12.70

.19[4.82]X.19[4.82]X1.38[35.05]

KEYWAY

NAMEPLATE READ FROM
CONDUIT BOX SIDE

6.50

165.10

5.50

139.70

2.75

69.85

.12

3.04

3.50

3.44

88.98

87.45

6.72

170.59

5.28

134.14

4.44

112.78

8.52

216.51

6.49

164.74

.82

20.83

1.81

45.97

.88

22.35

.44

11.18
.18

4.45

2-Ø1.09[27.68]
KNOCKOUTS

3-Ø.88[22.35]
KNOCKOUTS

Ø.34[8.63]-.35[8.89]
6 HOLES
(140T MTG.)

Regal Beloit America, Inc.

TM

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING I T IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, A ND/ OR USED, EXCEPT

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DEC.

INCH mm ANGLE
.X 0.1 [ 2.5] 7' 30"
.XX 0.03 [ 0.76]
.XXX 0.005 [ 0.127]
.XXXX 0.0005 [ 0.0127]
REMOVE BURRS & BREAK SHARP
EDGES: .003/.015 [.076/.381] X 45
CORNER FILLETS: R.02 [.51]
MACHINED SURFACES:

200 5.1

INCH mm
mm SHOWN IN [BRACKETS]

12

43

A

B

2

43

1

A

B

ECO DESCRIPTION

DATEAPPROVED BY

DATEREVISION BY

ECO

DRAWING REVISION

REFERENCE

MATERIAL

SHEET

DRAWING NUMBERSIZE

DESCRIPTION

THIRD ANGLE
PROJECTION

DRAWN BY

DATE

DATE

APPROVED BY

PROCESS/FINISH

B

1 OF 1

100085

GK

02-04-1988

FG

02-04-1998

E A. KEETHA 01-09-2018

ECO-0143026 PST 04/11/2018

OUTLINE CONVERSION PROJECT

OUTLINE

100085

140T & 56HZ - DR.PR.

1.CONDUIT BOX CAN BE ROTATED 180°.

NOTES:

DASH

NO.

"C" "BS"

706 10.99[279.14] 3.87[98.29]
756 11.49[291.84] 4.37[110.99]
806 11.99[304.54] 4.87[123.69]
856 12.49[317.24] 5.37[136.39]
906 12.99[329.94] 5.87[149.09]
956 13.49[342.64] 6.37[161.79]

Uncontrolled Copy

3 of 6

(1U) T1

(1U) T1
(1V) T2

(1V) T2

(1W) T3

(1W) T3

(2U) T11

(2U) T11
(2V) T12

(2V) T12

(2W) T13

(2W) T13

(1U) T1

(1U) T1
(1V) T2

(1V) T2

(1W) T3

(1W) T3

LOW SPEED

LOW SPEED

HIGHSPEED

HIGHSPEED

L1

L1
L2

L2
L3

L3

INSULATE

INSULATE
EACH

EACH
SEPARATELY

SEPARATELY

INSULATE

INSULATE
EACH

EACH
SEPARATELY

SEPARATELY

Uncontrolled Copy

THREE PHASE, SINGLE VOLT, 6 LEAD

THREE PHASE, SINGLE VOLT, 6 LEAD
2 SPEED REVERSIBLE MOTOR

2 SPEED REVERSIBLE MOTOR

T3

T3

T1

T1

T11

T11

T2

T2

T1 (1U)

T1 (1U)
T2 (1V)

T2 (1V)
T3 (1W)

T3 (1W)
T11 (2U)

T11 (2U)
T12 (2V)

T12 (2V)
T13 (2W)

T13 (2W)

L1

(2U) T11

(2U) T11
(2V) T12

(2V) T12

(2W) T13

(2W) T13

TO REVERSE ROTATION O N

TO REVERSE ROTATION O N
EITHER SPEED: INTERCHANGE

EITHER SPEED: INTERCHANGE
ANY 2 LEADS ON T H E

ANY 2 LEADS ON T H E
WINDING IN USE.

WINDING IN USE.

REVISION BY DATE

DRAWING REVISION

DRAWING REVISION

ECO

ECO

ECO DESCRIPTION

ECO DESCRIPTION

C

C

ECO-0132917

ECO-0132917

REVISED PER ECO & UPDATED TO STANDARDS

REVISED PER ECO & UPDATED TO STANDARDS

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATI ON OR OTHER FIRM RECEIVING IT IS DEEMED,

INFORMATION. ANY PERSON, CORPORATI ON OR OTHER FIRM RECEIVING IT IS DEEMED,

BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED

BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, AND/OR USED, EXCE P T

TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, AND/OR USED, EXCE P T

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

REVISION BY DATE

APPROVED BY DATE

APPROVED BY DATE

JJB

JJB
TLB

TLB

L1
L2

L2
L3

L3

10-25-2017

10-25-2017
10-30-2017

10-30-2017

DRAWN BY

DRAWN BY

DATE

DATE

01-05-1994

01-05-1994

APPROVED BY

APPROVED BY

DATE

DATE

01-17-1994

01-17-1994

REFERENCE

REFERENCE

THIRD ANGLE

THIRD ANGLE
PROJECTION

PROJECTION

T12

T12

T13

T13

VIEW OF TERMINAL END

VIEW OF TERMINAL END

TM

LZ

LZ

GK

GK

DESCRIPTION

DESCRIPTION

MATERIAL

MATERIAL

SIZE DRAWING NUMBER

SIZE DRAWING NUMBER

A

A

TM

Regal Beloit America , Inc.

Regal Beloit America , Inc.

CONN DIAGRAM-INTERNAL

CONN DIAGRAM-INTERNAL

3 PHASE - SINGLE - 2 SPEED REVERSIBLE

3 PHASE - SINGLE - 2 SPEED REVERSIBLE

4 of 6

EE7317

EE7317

PROCESS/FINISH

PROCESS/FINISH

SHEET

SHEET

1 OF 1

1 OF 1

CERTIFICATION DATA SHEET

Model#: 145TTDR5706 AD WINDING#: ZT(4-6)5 NONE 1
CONN. DIAGRAM: A-EE7317 ASSEMBLY: F1 ONLY
OUTLINE: A-100085-906

TYPICAL MOTOR PERFORMANCE DATA

HP KW SYNC. RPM F.L. RPM FRAME ENCLOSURE KVA CODE DESIGN

1 1/2&2/3 1.12&0.50 1200 1725&1140 145T DP H 2VT

PH Hz VOLTS FL AMPS START TYPE DUTY INSL S.F AMB°C ELEVATION

3 60/60 460 2.3&1.3 ACROSS THE

LINE

CONTINUOUSB3 1.15/1.15 40 3300

FULL LOAD EFF:

78.5&70.5

3/4 LOAD EFF: 70 1/2 LOAD EFF: 66.5 GTD. EFF ELEC. TYPE NO LOAD AMPS

FULL LOAD PF:

80&70.5

3/4 LOAD PF: 61 1/2 LOAD PF: 50 64.6 SQ CAGE IND RUN .8

F.L. TORQUE LOCKED ROTOR AMPS L.R. TORQUE B.D. TORQUE F.L. RISE°C

3.1 LB-FT 5 4.7 LB-FT 152 7.1 LB-FT 229 48

SOUND PRESSURE

@ 3 FT.

SOUND POWER ROTOR WK^2 MAX. WK^2 SAFE STALL TIME STARTS

/HOUR

APPROX. MOTOR

WGT

63 dBA 73 dBA 0.12 LB-FT^2 - LB-FT^2 - SEC. - - LBS.

*** SUPPLEMENTAL INFORMATION ***

DE BRACKET

TYPE

ODE BRACKET

TYPE

MOUNT

TYPE

ORIENTATION SEVERE

DUTY

HAZARDOUS

LOCATION

DRIP

COVER

SCREENS PAINT

STANDARD STANDARD RIGID HORIZONTAL FALSE NONE FALSE NONE BLUE

(POWDER)

BEARINGS GREASE SHAFT TYPE SPECIAL DE SPECIAL ODE SHAFT

MATERIAL

FRAME

MATERIAL

DE OPE

BALL BALL POLYREX EM T NONE NONE 1144

STRESSPROOF

(C-223)

ROLLED STEEL

6205 6203

THERMO-PROTECTORS THERMISTORS CONTROL SPACE /n HEATERS

THERMOSTATS PROTECTORS WDG RTDs BRG RTDs

NONE NOT NONE NONE NONE FALSE NONE VOLTS

If Inverter equals NONE, contact factory for further

information

*
N
O
T
E
S
*

INVERTER TORQUE: NONE
INV. HP SPEED RANGE: NONE

ENCODER: NONE
NONE NONE
NONE NONE PPR

BRAKE: NONE NONE
NONE P/N NONE
NONE NONE
NONE FT-LB NONE V NONE Hz

DATE: 06/21/2017 11:33:15 AM
FORM 3531 REV.3 02/07/99
** Subject to change without notice.
