Marathon Electric R404 Product Information Packet
PRODUCT INFORMATION PACKET
Model No: 071T17FH5330
Catalog No: R404
0.33 HP General Purpose, 3 phase, 1800 RPM, 575 V, 71M Frame, TEFC Aluminium TEFC Motors
Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies. ©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 6
Product Information Packet: Model No: 071T17FH5330, Catalog No:R404 0.33 HP General Purpose, 3 phase, 1800 RPM, 575 V, 71M Frame, TEFC
Nameplate Specifications
Output HP |
0.33 Hp |
Output KW |
0.03 kW |
Frequency |
60 Hz |
Voltage |
575 V |
|
|
|
|
Current |
0.57 A |
Speed |
1700 rpm |
|
|
|
|
Service Factor |
1.15 |
Phase |
3 |
|
|
|
|
Efficiency |
68 % |
Power Factor |
66 |
|
|
|
|
Duty |
Continuous |
Insulation Class |
F |
|
|
|
|
Design Code |
B |
KVA Code |
J |
|
|
|
|
Frame |
71M |
Enclosure |
Totally Enclosed Fan Cooled |
|
|
|
|
Thermal Protection |
No |
Ambient Temperature |
40 °C |
|
|
|
|
Drive End Bearing Size |
6203 |
Opp Drive End Bearing Size |
6203 |
|
|
|
|
UL |
Recognized |
CSA |
Y |
|
|
|
|
CE |
Y |
IP Code |
43 |
|
|
|
|
Technical Specifications
Electrical Type |
Squirrel Cage Inverter Rated |
Starting Method |
Line Or Inverter |
Poles |
4 |
Rotation |
Reversible |
|
|
|
|
Resistance Main |
115.3 Ohms |
Mounting |
Rigid Base |
|
|
|
|
Motor Orientation |
Horizontal |
Drive End Bearing |
Ball |
|
|
|
|
Opp Drive End Bearing |
Ball |
Frame Material |
Aluminum |
|
|
|
|
Shaft Type |
IEC |
Shaft Diameter |
0.550 in |
|
|
|
|
Assembly/Box Mounting |
F1/F2 CAPABLE |
|
|
|
|
|
|
This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created:01/11/2019
2 of 6
