Marathon Electric G1517 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: 5KC46PN0032

Catalog No: G1517

3/4 HP General Purpose Motor, 1 phase, 1800 RPM, 115/230 V, 56C Frame, TEFC

Single Phase TEFC Motors

Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2020 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 4

Product Information Packet: Model No: 5KC46PN0032, Catalog No:G1517 3/4 HP General Purpose Motor, 1 phase, 1800 RPM, 115/230 V, 56C Frame,
TEFC

Nameplate Specifications

Output HP 0.75 Hp Output KW 0.56 kW
Frequency 60 Hz Voltage 115/230 V
Current 11.0,5.5 A Speed 1725 rpm
Service Factor 1.15 Phase 1
Efficiency 70 % Power Factor 0
Duty Continuous Insulation Class B
KVA Code L Frame 56C
Enclosure Totally Enclosed Fan Cooled Thermal Protection N/R
Ambient Temperature 40 °C Drive End Bearing Size 6203
Opp Drive End Bearing Size 6203 UL Recognized
CSA Yes CE N

Technical Specifications

Electrical Type Capacitor Start Induction Run Starting Method SM
Poles 4 Rotation Counterclockwise/Clockwise
Mounting Round Motor Orientation ANY
Drive End Bearing LOCKED Opp Drive End Bearing Ball
Frame Material Rolled Steel Overall Length 11.83 in
Frame Length 6.55 in Shaft Diameter 0.630 in
Shaft Extension 1.88 in
Outline Drawing 52A107671P3 Connection Drawing 52A105381BA
