PRODUCT INFORMATION PACKET

Model No: 254TTFL14009

Catalog No: C207A

15 HP General Purpose Motor, 3 phase, 3600 RPM, 230/460 V, 254TC Frame, TEFC

Three Phase TEFC Motors

Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 4

Product Information Packet: Model No: 254TTFL14009, Catalog No:C207A 15 HP General Purpose Motor, 3 phase, 3600 RPM, 230/460 V, 254TC
Frame, TEFC

Nameplate Specifications

Output HP 15 Hp Output KW 11.2 kW
Frequency 60 Hz Voltage 230/460 V
Current 35.0/17.5 A Speed 3510 rpm
Service Factor 1.15 Phase 3
Efficiency 90.2 % Power Factor 87.5
Duty Continuous Insulation Class F
Design Code B KVA Code F
Frame 254TC Enclosure Totally Enclosed Fan Cooled
Thermal Protection No Ambient Temperature 40 °C
Drive End Bearing Size 6309 Opp Drive End Bearing Size 6207
UL Recognized CSA Y
CE Y IP Code 43

Technical Specifications

Electrical Type Squirrel Cage Induction Run Starting Method Across The Line
Poles 2 Rotation Reversible
Resistance Main .675 Ohms Mounting Round
Motor Orientation Horizontal Drive End Bearing Ball
Opp Drive End Bearing Ball Frame Material Aluminum
Shaft Type T Overall Length 23.24 in
Frame Length 11.00 in Shaft Diameter 1.625 in
Shaft Extension 3.75 in Assembly/Box Mounting F1/F2 Capable

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created:01/11/2019
