Marathon Electric 143TTFR4010 Product Information Packet
PRODUCT INFORMATION PACKET
Model No: 143TTFR4010
Catalog No: U733
1.50 HP General Purpose Motor, 3 phase, 3600 RPM, 230/460 V, 143TC Frame, TEFC
Three Phase TEFC Motors
Regal and Marathon are trademarks of Regal Beloit Corporation or one of its affiliated companies.
©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 4
Product Information Packet: Model No: 143TTFR4010, Catalog No:U733 1.50 HP General Purpose Motor, 3 phase, 3600 RPM, 230/460 V, 143TC
Frame, TEFC
Nameplate Specifications
Output HP 1.50 Hp Output KW 1.1 kW
Frequency 60 Hz Voltage 230/460 V
Current 4.0/2.0 A Speed 3500 rpm
Service Factor 1.15 Phase 3
Efficiency 82.5 % Power Factor 84.5
Duty Continuous Insulation Class F
Design Code B KVA Code L
Frame 143TC Enclosure Totally Enclosed Fan Cooled
Thermal Protection No Ambient Temperature 40 °C
Drive End Bearing Size 6205 Opp Drive End Bearing Size 6203
UL Recognized CSA Y
CE Y IP Code 43
Technical Specifications
Electrical Type Squirrel Cage Induction Run Starting Method Across The Line
Poles 2 Rotation Reversible
Resistance Main 10.2 Ohms Mounting Rigid Base
Motor Orientation Horizontal Drive End Bearing Ball
Opp Drive End Bearing Ball Frame Material Rolled Steel
Shaft Type T Overall Length 12.87 in
Frame Length 7.56 in Shaft Diameter 0.875 in
Shaft Extension 1.96 in Assembly/Box Mounting F1 ONLY
This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created:01/11/2019
