OWNER’S MANUAL and SAFETY INSTRUCTIONS
Double Edged (Models DEHT19, DEHT24)
Electric Hedge Trimmers
!
WARNING DANGER
BLADES ARE EXTREMELY SHARP.
TO AVOID INJURY WHEN UNPACKING
THE HEDGE TRIMMER,
DO NOT GRASP THE BLADES.
!
310706 Electric Trimmer EN_310700 Electric Trimmer.qxd 7/28/10 3:01 PM Page 2
TABLE OF CONTENTS
I. IMPORTANT INFORMATION
A. Introduction .......................................................................................................2
II. G
E
...........................................................................................3
NERALSAFETYRULES
A. Safety Decals......................................................................................................4
B. Safety Symbols Identification ...........................................................................4
C. Special Safety Rules ..........................................................................................5
D. Warnings — Dont’s ............................................................................................5
E. Warnings — Do’s................................................................................................5
Page
III. U
IV. O
NPACKING AND ASSEMBLY INSTRUCTIONS.............................................................6
PERATION
A. Instructions for Proper Operation ................................................................6-7
AINTENANCE
V. M
A. Lubrication.........................................................................................................7
B. Service Maintenance Guide ..............................................................................7
ERVICE
VI. S
A. Trouble Shooting ...............................................................................................8
B. Blade Adjustment ...............................................................................................8
VII. P
VIÎI. S
L
ARTS EXPLOSIONS............................................................................................9-11
PECIFICATIONS ...................................................................................Back Cover
IMITED SERVICE & WARRANTY POLICY.......................................................Back Cover
I. IMPORTANT INFORMATION
A. INTRODUCTION
On behalf of everyone at Mantis, we would
like to thank you for your purchase of a
Mantis Electric Powered Hedge Trimmer. This
professional trimming machine was designed
to the highest standards to ensure you many
hours of uninterrupted service.
2
This manual provides the information
necessary for safe and efficient operation and
service. For your safety, it is critically
important that you read and understand this
entire manual before operating your hedge
trimmer.
310706 Electric Trimmer EN_310700 Electric Trimmer.qxd 7/28/10 3:01 PM Page 3
II. GENERAL SAFETY RULES
Warning: When using electric tools, basic safety
precautions, including the following, should always be
ollowed to reduce the risk of fire, electric shock and
f
personal injury.
Read all these instructions before operating this
product and save these instructions.
For safe operations:
1)
Keep work area clean.
Cluttered areas and benches invite injuries.
2) Consider work area environment.
Do not expose power tools to rain. Do not use
power tools in damp or wet locations. Keep work
area well lit. Do not use power tools where there
is risk of fire or explosion.
Guard against electric shock.
3)
Avoid body contact with earthed or grounded
surfaces e.g. pipes, radiators, ranges, refrigerators.
4)
Keep children away.
Do not let visitors touch the tool or extension
cord. All visitors should be kept away from area.
5) Store idle tools.
When not in use, tools should be stored in a dry,
high or locked up place, out of reach of children.
6) Do not force the tool.
It will do the job better and safer at the rate for
which it was intended.
7) Use the right tool.
Do not force small tools or attachments to do the
job of a heavy duty tool. Do not use tools for
purposes not intended; for example, do not use
circular saws to cut tree limbs or logs.
8) Dress properly.
Do not wear loose clothing or jewelry that can be
caught in moving parts. Rubber gloves and nonskid footwear are recommended when working
outdoors. Wear protective hair covering to contain
long hair.
Use safety glasses.
9)
Use face or dust mask if the cutting operation is
dusty.
Do not abuse the cord.
10)
Never carry the tool by the cord or yank it to
disconnect if from the socket. Keep the cord away
from heat, oil and sharp edges.
Secure work.
11)
Use a vice to clamp the frame bar while adjusting
blades. It is safer than using your hand and it frees
both hands to operate the tools.
Do not overreach.
12)
Keep proper footing and balance at all times.
13) Maintain tool with care.
eep cutting tools sharp and clean for better and
K
safer performance. Follow instructions for
lubrication and changing accessories. Inspect tool
cord periodically and if damaged have it repaired
y Mantis. Inspect extension cords periodically
b
and replace, if damaged. Keep handles dry, clean
and free from oil and grease.
Disconnect tools.
14)
When not in use, before servicing and when
changing accessories such as blades, bits and
cutters.
15) Remove adjusting keys and wrenches.
Form the habit of checking to see that keys and
adjusting wrenches are removed from the tool
before turning it on.
Avoid unintentional starting.
16)
Do not carry a plugged in tool with a finger on the
switch. Ensure switch is off when plugging in.
17) Use outdoor extension leads.
When tool is used outdoors, use only extension
cords intended for outdoor use.
18) Stay alert.
Watch what you are doing . Use common sense.
Do not operate tool when you are tired.
19) Check damaged parts.
Before further use of the tool, a guard or other part
that is damaged should be carefully checked to
determine that it will operated properly and
perform its intended function. Check for
alignment of moving parts, free running of moving
parts, breakage of parts, mounting and any other
conditions that may affect its operation. A guard
or other part that is damaged should be properly
repaired or replaced by Mantis unless otherwise
indicated in this instruction manual. Have
defective switches replaced by Mantis. Do not use
the tool if the switch does not turn it on and off.
20) Warning.
The use of any accessory or attachment, other
than those recommended in this instruction
manual, may present a risk of personal injury.
Have your tool repaired by a qualified person.
21)
This electric tool conforms to relevant safety
requirements. Repairs should only be carried out
by qualified persons using original spare parts,
otherwise this may result in considerable danger
to the user.
3
310706 Electric Trimmer EN_310700 Electric Trimmer.qxd 7/28/10 3:01 PM Page 4
!
WARNING DANGER
!
THIS SYMBOL POINTS OUT
IMPORTANT SAFETY INSTRUCTIONS.
WHEN YOU SEE THIS SYMBOL,
!
HEED IT’S WARNING!!
STAY ALERT!!
!
A. SAFETY DECALS AND MOLDED SYMBOLS
Important parts of the safety system incorporated in
Double Edge trimmers are the warning and
informational decals and molded-in symbols found on
various parts of the trimmer. These decals must be
replaced in time due to abrasion, etc.
Loop Handle
!
WARNING DANGER
TO REDUCE THE POTENTIAL FOR
ACCIDENTS, COMPLY WITH THE
SAFETY INSTRUCTIONS IN THIS
MANUAL. FAILURE TO COMPLY MAY
RESULT IN SERIOUS PERSONAL
INJURY AND OR EQUIPMENT AND
PROPERTY DAMAGE.
It is your responsibility to replace the decals or molded
housing when they become hard to read. The locations
of these safety features are shown below. See page 11
for their part numbers when ordering replacements.
Double Edge Trimmer
!
Guard
On/Off Switch
(Molded into Part No. 310400 Main Housing Set}
!
B. SAFETY SYMBOLS IDENTIFICATION
WHAT THE SYMBOLS MEAN:
1. Read the instructions.
2. Do not expose to rain.
3. Remove plug from main (electric
power source) immediately if cable is
damaged or cut.
4. Double insulated.
Rear Handle
On/Off
Switch
Safety Symbols
123 4
!
WARNING DANGER
!
IF TRIMMER IS USED IMPROPERLY OR SAFETY PRECAUTIONS ARE NOT FOLLOWED,
THE USER RISKS SERIOUS INJURY TO THEMSELVES AND OTHERS.
READ AND UNDERSTAND THE RULES FOR SAFE OPERATION AND ALL
INSTRUCTIONS IN THIS MANUAL.
4
